SPECIFICATION SHEET
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
70M 99044151A
QDE SERIES
RANGE HOOD
SPECIFICATIONS
HVI-2100 CERTIFIED RATINGS comply with new testing technologies and
procedures prescribed by the Home Ventilating Institute, for off-the-shelf
products, as they are available to consumers. Product performance is rated
at 0.1 in. static pressure, based on tests conducted in a state-of-the-art test
laboratory. Sones are a measure of humanly-perceived loudness, based on
laboratory measurements.
LISTED
TYPICAL SPECIFICATION
Range hood shall be Broan QDE Series.
Unit will have clean, contoured appearance with no sharp
edges. Finish to be baked-on polyester paint (matte nish
stainless steel). It must have a fully-enclosed bottom and
dishwasher-safe, full lters.
Hood to be convertible between 3¼" x 10" vertical and
horizontal ducted (using two washable aluminum lters).
Range hood to have a centrifugal blower and (2) 13-watt
(max.) uorescent lights. Blower and lights shall be operated
using rocker-type controls.
Air delivery shall be no less than 100 cfm and sound level
no greater than 0.9 Sones (280 cfm and 5.5 Sones on High
Speed). Air and sound ratings to be certied by HVI.
Unit shall be U.L. and CU.L. listed and Energy Star
qualied.
Broan-NuTone LLC Hartford, Wisconsin www.broan.com 800-558-1711
Volts 120
HZ 60
Amps 1.2
CFM (Normal) 100
Max. CFM (High) 280
Sones (Normal) 0.9
Sones (High) 5.5
Controls 2-sp rocker
Fluorescent Light CFQ13W/G24q †
† 2 bulbs included.
A sleek, contemporary styled range hood with high-
performance capability and Energy Star qualification.
FEATURES
• Clean, sleek appearance
• Durable, baked-on polyester nish paint or brushed nish
stainless steel
• Over 50% quieter than the average range hood
• Large, full filter design - dishwasher-safe for easy
cleaning
• Dual uorescent lights provide lighting for cooktop visibility
(lamps included)
• Centrifugal blower provides increased performance and
quieter operation.
• Flush-mounted rocker controls
• Versatile design allows for 3¼" x 10" vertical and horizontal
ducting
• Available in 30" width in White, Black, and Stainless Steel
