Brocade Communications Systems 5300 Manual

HARDWARE INSTALLATION GUIDE
Brocade 5300
Hardware Installation Guide
53-1000858-07
28 February 2017

© 2017, Brocade Communications Systems, Inc. All Rights Reserved.
Brocade, the B-wing symbol, and MyBrocade are registered trademarks of Brocade Communications Systems, Inc., in the United States and in other
countries. Other brands, product names, or service names mentioned of Brocade Communications Systems, Inc. are listed at www.brocade.com/en/legal/
brocade-Legal-intellectual-property/brocade-legal-trademarks.html. Other marks may belong to third parties.
Notice: This document is for informational purposes only and does not set forth any warranty, expressed or implied, concerning any equipment,
equipment feature, or service oered or to be oered by Brocade. Brocade reserves the right to make changes to this document at any time, without
notice, and assumes no responsibility for its use. This informational document describes features that may not be currently available. Contact a Brocade
sales oce for information on feature and product availability. Export of technical data contained in this document may require an export license from the
United States government.
The authors and Brocade Communications Systems, Inc. assume no liability or responsibility to any person or entity with respect to the accuracy of this
document or any loss, cost, liability, or damages arising from the information contained herein or the computer programs that accompany it.
The product described by this document may contain open source software covered by the GNU General Public License or other open source license
agreements. To nd out which open source software is included in Brocade products, view the licensing terms applicable to the open source software, and
obtain a copy of the programming source code, please visit http://www.brocade.com/support/oscd.
Brocade 5300 Hardware Installation Guide
2 53-1000858-07

Contents
Preface...................................................................................................................................................................................................................................7
Document conventions............................................................................................................................................................................................................................7
Notes, cautions, and warnings.....................................................................................................................................................................................................7
Text formatting conventions.........................................................................................................................................................................................................7
Command syntax conventions....................................................................................................................................................................................................8
Brocade resources.....................................................................................................................................................................................................................................8
Document feedback..................................................................................................................................................................................................................................8
Contacting Brocade Technical Support............................................................................................................................................................................................ 9
Brocade customers..........................................................................................................................................................................................................................9
Brocade OEM customers............................................................................................................................................................................................................. 9
About This Document..................................................................................................................................................................................................... 11
Supported hardware and software...................................................................................................................................................................................................11
What’s new in this document............................................................................................................................................................................................................. 11
Device Overview............................................................................................................................................................................................................... 13
Brocade 5300 overview......................................................................................................................................................................................................................13
Port side of the Brocade 5300.........................................................................................................................................................................................................14
Non-port side of the Brocade 5300..............................................................................................................................................................................................16
Brocade 5300 Management.............................................................................................................................................................................................................16
Ports on Demand license.................................................................................................................................................................................................................... 17
Brocade Inter-Switch Link (ISL) Trunking..................................................................................................................................................................................... 17
Preparing for Installation.................................................................................................................................................................................................19
General precautions............................................................................................................................................................................................................................... 19
ESD precautions......................................................................................................................................................................................................................................19
Power precautions.................................................................................................................................................................................................................................. 20
RTC battery................................................................................................................................................................................................................................................20
Environmental considerations............................................................................................................................................................................................................20
EIA rack considerations........................................................................................................................................................................................................................21
Recommendations for cable management..................................................................................................................................................................................21
Items included with the Brocade 5300.........................................................................................................................................................................................22
Mounting the Device........................................................................................................................................................................................................23
Mounting options....................................................................................................................................................................................................................................23
Installing a standalone Brocade 5300...........................................................................................................................................................................................23
Installing the 1U, 1.5U, and 2U Mid-Mount Kit for Two-Post Racks (XBR-000165, XBR-000175, and XBR-R000292)................ 24
Time and items required.............................................................................................................................................................................................................24
Parts list............................................................................................................................................................................................................................................. 24
Attaching the front brackets to the device........................................................................................................................................................................... 25
Attaching the device to a rack...................................................................................................................................................................................................26
Attaching the rear brackets to the rack..................................................................................................................................................................................27
Attaching the rear brackets to the device.............................................................................................................................................................................28
Installing the 1U and 2U Fixed-Mount Rack Kit for Four-Post Racks (XBR-R000162)........................................................................................29
Time and items required.............................................................................................................................................................................................................29
Parts list............................................................................................................................................................................................................................................. 30
Attaching the front brackets.......................................................................................................................................................................................................32
Installing the device in the rack................................................................................................................................................................................................ 33
Brocade 5300 Hardware Installation Guide
53-1000858-07 3

Attaching the rear brackets to the front brackets..............................................................................................................................................................34
Attaching the rear brackets to the rack posts.....................................................................................................................................................................35
Slide Rack Mount Kit (XBR-R000070)........................................................................................................................................................................................ 36
Safety precautions ........................................................................................................................................................................................................................37
Time and items required.............................................................................................................................................................................................................37
Parts list............................................................................................................................................................................................................................................. 37
Installing the device.......................................................................................................................................................................................................................39
Installing the 1U and 2U Non-Port Side Fixed-Mount Rack Kit (24") for Four-Post Racks (XNA-000073 and XNA-100073)........53
Time and items required.............................................................................................................................................................................................................54
Parts list............................................................................................................................................................................................................................................. 54
Attaching front brackets.............................................................................................................................................................................................................. 55
Installing the device in the rack................................................................................................................................................................................................ 55
Attaching the rear brackets to front brackets......................................................................................................................................................................56
Attaching the rear brackets to the rack posts.....................................................................................................................................................................57
Initial Setup and Verication.......................................................................................................................................................................................... 59
Items required for initial setup............................................................................................................................................................................................................59
Providing power to the switch............................................................................................................................................................................................................59
Creating a serial connection................................................................................................................................................................................................................59
Switch IP address....................................................................................................................................................................................................................................60
Using DHCP to set the IP address.........................................................................................................................................................................................60
Setting a static IP address..........................................................................................................................................................................................................60
Date and time settings..........................................................................................................................................................................................................................61
Time zones.......................................................................................................................................................................................................................................61
Local time synchronization........................................................................................................................................................................................................61
Setting the date...............................................................................................................................................................................................................................62
Setting time zones.........................................................................................................................................................................................................................62
Synchronizing local time using NTP......................................................................................................................................................................................63
Monitoring the Device..................................................................................................................................................................................................... 65
Powering the Brocade 5300 on and o.......................................................................................................................................................................................65
LED activity interpretation................................................................................................................................................................................................................... 65
Brocade 5300 LEDs...................................................................................................................................................................................................................65
LED locations..................................................................................................................................................................................................................................65
LED patterns....................................................................................................................................................................................................................................67
POST and boot specications...........................................................................................................................................................................................................69
POST..................................................................................................................................................................................................................................................69
Boot.....................................................................................................................................................................................................................................................70
Interpreting POST results....................................................................................................................................................................................................................70
Brocade 5300 Maintenance..............................................................................................................................................................................................................70
Installing an SFP............................................................................................................................................................................................................................ 70
Field Replaceable Units (FRUs)...............................................................................................................................................................................................71
Removal and Replacement Procedures.......................................................................................................................................................................73
Removing and replacing a mid-size switch power supply.....................................................................................................................................................73
Time required...................................................................................................................................................................................................................................74
Items required..................................................................................................................................................................................................................................74
Replacing a power supply.......................................................................................................................................................................................................... 74
Removing and replacing a fan assembly......................................................................................................................................................................................77
Time required...................................................................................................................................................................................................................................78
Items required..................................................................................................................................................................................................................................78
Replacing a fan assembly.......................................................................................................................................................................................................... 78
Brocade 5300 Hardware Installation Guide
4 53-1000858-07

Brocade 5300 Technical Specications..................................................................................................................................................................... 81
Switch components................................................................................................................................................................................................................................81
Weight and physical dimensions...................................................................................................................................................................................................... 81
Facility requirements..............................................................................................................................................................................................................................82
Power supply specications............................................................................................................................................................................................................... 82
Environmental requirements.............................................................................................................................................................................................................. 82
General specications........................................................................................................................................................................................................................... 83
Data transmission ranges....................................................................................................................................................................................................................84
Memory specications..........................................................................................................................................................................................................................84
Fibre Channel port specications.....................................................................................................................................................................................................84
Serial port specications...................................................................................................................................................................................................................... 85
Regulatory certications.......................................................................................................................................................................................................................85
Regulatory compliance (EMC) ................................................................................................................................................................................................ 85
Regulatory compliance (safety) ...............................................................................................................................................................................................85
Regulatory compliance (environmental) ..............................................................................................................................................................................86
Regulatory Statements....................................................................................................................................................................................................87
BSMI statement (Taiwan).....................................................................................................................................................................................................................87
Canadian requirements.........................................................................................................................................................................................................................87
CE statement............................................................................................................................................................................................................................................ 87
China CCC statement............................................................................................................................................................................................................................88
China ROHS............................................................................................................................................................................................................................................. 88
FCC warning (US only)..........................................................................................................................................................................................................................88
KCC statement (Republic of Korea)................................................................................................................................................................................................. 89
VCCI statement........................................................................................................................................................................................................................................89
Cautions and Danger Notices........................................................................................................................................................................................91
Cautions......................................................................................................................................................................................................................................................91
General cautions.............................................................................................................................................................................................................................91
...............................................................................................................................................................................................................................................................91
Electrical cautions..........................................................................................................................................................................................................................92
Danger Notices........................................................................................................................................................................................................................................ 93
General dangers.............................................................................................................................................................................................................................93
Electrical dangers...........................................................................................................................................................................................................................93
Dangers related to equipment weight................................................................................................................................................................................... 95
Brocade 5300 Hardware Installation Guide
53-1000858-07 5

Brocade 5300 Hardware Installation Guide
6 53-1000858-07

Preface
• Document conventions...................................................................................................................................................................................... 7
• Brocade resources............................................................................................................................................................................................... 8
• Document feedback............................................................................................................................................................................................8
• Contacting Brocade Technical Support.......................................................................................................................................................9
Document conventions
The document conventions describe text formatting conventions, command syntax conventions, and important notice formats used in
Brocade technical documentation.
Notes, cautions, and warnings
Notes, cautions, and warning statements may be used in this document. They are listed in the order of increasing severity of potential
hazards.
NOTE
A Note provides a tip, guidance, or advice, emphasizes important information, or provides a reference to related information.
ATTENTION
An Attention statement indicates a stronger note, for example, to alert you when trac might be interrupted or the device might
reboot.
CAUTION
A Caution statement alerts you to situations that can be potentially hazardous to you or cause damage to hardware,
rmware, software, or data.
DANGER
A Danger statement indicates conditions or situations that can be potentially lethal or extremely hazardous to you. Safety
labels are also attached directly to products to warn of these conditions or situations.
Text formatting conventions
Text formatting conventions such as boldface, italic, or Courier font may be used to highlight specic words or phrases.
Format Description
bold text Identies command names.
Identies keywords and operands.
Identies the names of GUI elements.
Identies text to enter in the GUI.
italic text Identies emphasis.
Identies variables.
Identies document titles.
Courier font Identies CLI output.
Brocade 5300 Hardware Installation Guide
53-1000858-07 7

Format Description
Identies command syntax examples.
Command syntax conventions
Bold and italic text identify command syntax components. Delimiters and operators dene groupings of parameters and their logical
relationships.
Convention Description
bold text Identies command names, keywords, and command options.
italic text Identies a variable.
value In Fibre Channel products, a xed value provided as input to a command option is printed in plain text, for
example, --show WWN.
[ ] Syntax components displayed within square brackets are optional.
Default responses to system prompts are enclosed in square brackets.
{ x | y | z } A choice of required parameters is enclosed in curly brackets separated by vertical bars. You must select
one of the options.
In Fibre Channel products, square brackets may be used instead for this purpose.
x | yA vertical bar separates mutually exclusive elements.
< > Nonprinting characters, for example, passwords, are enclosed in angle brackets.
... Repeat the previous element, for example, member[member...].
\ Indicates a “soft” line break in command examples. If a backslash separates two lines of a command
input, enter the entire command at the prompt without the backslash.
Brocade resources
Visit the Brocade website to locate related documentation for your product and additional Brocade resources.
White papers, data sheets, and the most recent versions of Brocade software and hardware manuals are available at www.brocade.com.
Product documentation for all supported releases is available to registered users at MyBrocade.
Click the Support tab and select Document Library to access product documentation on MyBrocade or www.brocade.com. You can
locate documentation by product or by operating system.
Release notes are bundled with software downloads on MyBrocade. Links to software downloads are available on the MyBrocade landing
page and in the Document Library.
Document feedback
Quality is our rst concern at Brocade, and we have made every eort to ensure the accuracy and completeness of this document.
However, if you nd an error or an omission, or you think that a topic needs further development, we want to hear from you. You can
provide feedback in two ways:
• Through the online feedback form in the HTML documents posted on www.brocade.com
• By sending your feedback to [e-mail]
Provide the publication title, part number, and as much detail as possible, including the topic heading and page number if applicable, as
well as your suggestions for improvement.
Brocade resources
Brocade 5300 Hardware Installation Guide
8 53-1000858-07

Contacting Brocade Technical Support
As a Brocade customer, you can contact Brocade Technical Support 24x7 online or by telephone. Brocade OEM customers should
contact their OEM/solution provider.
Brocade customers
For product support information and the latest information on contacting the Technical Assistance Center, go to www.brocade.com and
select Support.
If you have purchased Brocade product support directly from Brocade, use one of the following methods to contact the Brocade
Technical Assistance Center 24x7.
Online Telephone
Preferred method of contact for non-urgent issues:
• Case management through the MyBrocade portal.
• Quick Access links to Knowledge Base, Community, Document
Library, Software Downloads and Licensing tools
Required for Sev 1-Critical and Sev 2-High issues:
• Continental US: 1-800-752-8061
• Europe, Middle East, Africa, and Asia Pacic: +800-AT FIBREE
([phone])
•Toll-free numbers are available in many countries.
• For areas unable to access a toll-free number:
[phone]
Brocade OEM customers
If you have purchased Brocade product support from a Brocade OEM/solution provider, contact your OEM/solution provider for all of
your product support needs.
• OEM/solution providers are trained and certied by Brocade to support Brocade® products.
• Brocade provides backline support for issues that cannot be resolved by the OEM/solution provider.
• Brocade Supplemental Support augments your existing OEM support contract, providing direct access to Brocade expertise.
For more information, contact Brocade or your OEM.
• For questions regarding service levels and response times, contact your OEM/solution provider.
Contacting Brocade Technical Support
Brocade 5300 Hardware Installation Guide
53-1000858-07 9

Brocade 5300 Hardware Installation Guide
10 53-1000858-07

About This Document
• Supported hardware and software..............................................................................................................................................................11
• What’s new in this document........................................................................................................................................................................11
Supported hardware and software
Although many dierent software and hardware congurations are tested and supported by Brocade Communications Systems, Inc. for
Fabric OS v6.1.0 and later, documenting all possible congurations and scenarios is beyond the scope of this document.
This document is specic to the Brocade 5300 and Fabric OS 5.3.0. To obtain information about a Fabric OS version other than v5.3.0,
see the documentation specic to that OS version.
What’s new in this document
This section lists items in this document that are new or signicantly revised from preceding version.
•Modied battery danger statement in RTC battery on page 20.
• Removed "In-band support" column from "Management Options for the Brocade 5300 Switch" table in Brocade 5300
Management on page 16 as this no longer applies to Brocade products.
• Editorial revisions in rack mount kit procedures.
Brocade 5300 Hardware Installation Guide
53-1000858-07 11

Brocade 5300 Hardware Installation Guide
12 53-1000858-07

Device Overview
• Brocade 5300 overview.................................................................................................................................................................................13
• Port side of the Brocade 5300................................................................................................................................................................... 14
• Non-port side of the Brocade 5300.........................................................................................................................................................16
• Brocade 5300 Management....................................................................................................................................................................... 16
• Ports on Demand license...............................................................................................................................................................................17
• Brocade Inter-Switch Link (ISL) Trunking................................................................................................................................................17
Brocade 5300 overview
The Brocade 5300 is an 80-port 1, 2, 4, or 8 Gbps Fibre Channel switch that delivers Brocade sixth generation ASIC technology and
architecture for Fibre Channel Storage Area Networks (SANs). The Brocade 5300 is designed for the needs of enterprise environments
that require a high-port footprint for port aggregation.
With its high auto-sensing port count and ports-on-demand exibility, the Brocade 5300 is an ideal solution as a fan-out switch from a
director core, or as the core switch in a fabric. The Brocade 5300 satises demanding Reliability, Availability, and Serviceability (RAS),
performance and scalability requirements of an enterprise switch while delivering interoperability and ease-of-use advantages found only
in the Brocade product family. The Brocade 5300 is the latest enterprise oering from the Brocade family of entry-to-enterprise
products, and oers the following features and capabilities:
• Up to 80 auto-sensing ports of high-performance 8 Gbps technology in a single domain.
• Ports On Demand scaling from 48 to 64 or 80 ports.
• Full 1:1 subscription on all 80 ports at 8 Gbps.
• 1, 2, 4 and 8 Gbps auto-sensing Fibre Channel switch and router ports.
• FICON and FICON Control Unit Port ready.
• Fibre Channel Routing (FCR) service, which provides improved scalability and fault isolation, along with multi-vendor
interoperability through the optional Integrated Routing license.
• Two hot-swappable, redundant power supply FRUs.
• Three hot-swappable fan FRUs in an N+1 conguration to provide hardware-redundant cooling.
• Universal ports that self-congure as E, F, M or FL ports. Ex_Ports are activated on a per port basis with the optional Integrated
Routing license.
• An RJ45 Ethernet management port, in conjunction with EZSwitchSetup, that supports switch IP address discovery and
conguration, eliminating the need to attach a serial cable to congure the switch IP address and greatly increasing the ease of
use.
• USB port that provides storage for rmware updates, output of the supportSave command and storage for conguration
uploads and downloads.
• A system motherboard that features a Freescale MPC8548 Reduced Instruction Set Computer (RISC) CPU running at 1.3 GHz
with integrated peripherals, and that provides high performance with low power consumption.
• Inter-Switch Link (ISL) Trunking (licensable), which allows up to eight ports (at 1, 2, 4, or 8 Gbps speeds) between a pair of
switches combined to form a single, logical ISL with a speed of up to 64 Gbps (128 Gbps full duplex) for optimal bandwidth
utilization and load balancing.
• Dynamic Path Selection (DPS), which optimizes fabric-wide performance and load balancing by automatically routing data to
the most ecient available path in the fabric.
Brocade 5300 Hardware Installation Guide
53-1000858-07 13

• Rack-mount design using existing rail kits (xed, sliding, and mid-mount/Telco rail kits) on a 19" EIA rack.
• Industry-leading extended distance support, which enables native Fibre Channel extension greater than 590 km (366 miles).
• Brocade Small Form-Factor Pluggable (SFP) or SFP+ optical transceivers that support any combination of Short Wavelength
(SWL), Long Wavelength (LWL), or Extended Long Wavelength (ELWL) optical media among the switch ports.
• Unicast, multicast (255 groups), and broadcast data trac type support.
• Brocade Fabric Operating System (FOS), which delivers distributed intelligence throughout the network and enables a wide
range of value-added applications including Brocade Advanced Web Tools and Brocade Zoning. Optional Fabric Services
include: Adaptive Networking with QoS, Brocade Extended Fabrics, Brocade Enhanced Group Management, Brocade Fabric
Watch, ISL Trunking, Integrated Routing, and End-to-End Performance Monitoring (APM).
• Port-to-port latency minimized to 2100 nanoseconds through the use of cut-through frame routing at 8 Gbps.
• Extensive diagnostics and system-monitoring capabilities for enhanced high Reliability, Availability, and Serviceability (RAS)
• The Brocade EZSwitchSetup wizard that makes SAN conguration a three-step point-and-click task.
Port side of the Brocade 5300
The port side of the Brocade 5300 includes the system status LED, console port, Ethernet port and LEDs, USB port, and Fibre Channel
ports and the corresponding port status LEDs.
FIGURE 1 Port side view of the Brocade 5300
1. Brocade 5300
2. Switch ID pull-out tab
3. System status LED (top); System power LED (bottom)
4. Console port
Port side of the Brocade 5300
Brocade 5300 Hardware Installation Guide
14 53-1000858-07

5. Ethernet port
6. USB port
7. FC ports 0-7
8. FC ports 8-15
9. FC ports 16-23
10. FC ports 24-31
11. FC ports 32-38
12. FC ports 40-47
13. FC ports 48-55
14. FC ports 56-63
15. FC ports 64-71
16. FC ports 72-79
NOTE
You can also use port index and PIDs to identify a port. For more information, refer to the Fabric OS Administrator's Guide
FIGURE 2 Trunking port groups and port numbers of the Brocade 5300
1. Trunking port group 1; FC ports 00-07
2. Trunking port group 2; FC ports 08-15
3. Trunking port group 3; FC ports 16-23
4. Trunking port group 4; FC ports 24-31
5. Trunking port group 5; FC ports 32-38
6. Trunking port group 6; FC ports 40-47
7. Trunking port group 7; FC ports 48-55
8. Trunking port group 8; FC ports 56-63
Port side of the Brocade 5300
Brocade 5300 Hardware Installation Guide
53-1000858-07 15

9. Trunking port group 9; FC ports 64-71
10. Trunking port group 10; FC ports 72-79
Non-port side of the Brocade 5300
The following gure shows the non-port side of the Brocade 5300, which contains the power supplies (including the AC power
receptacle and AC power switch) and fans.
FIGURE 3 Non-port side of the Brocade 5300
1 Brocade 5300 5 Fan assembly #2
2 Non-port side of switch 6 Fan assembly #1
3 Power supply #2 7 Power supply #1
4 Fan assembly #3
Brocade 5300 Management
You can use the management functions built into the Brocade 5300 to monitor the fabric topology, port status, physical status, and
other information to help you analyze switch performance and to accelerate system debugging.
The Brocade 5300 automatically performs power-on self-test (POST) each time it is turned on. Any errors are recorded in the system
error log. For more information about POST, see POST and boot specications on page 69.
For information about upgrading the version of Fabric OS installed on your switch, see the Brocade Fabric OS Administration Guide
You can manage the Brocade 5300 using any of the management options listed in the following table.
Non-port side of the Brocade 5300
Brocade 5300 Hardware Installation Guide
16 53-1000858-07

TABLE 1 Management Options for the Brocade 5300 Switch
Management Tool Out-of-band Support
Command line interface (CLI)
Up to two admin sessions and four user sessions simultaneously. For more information,
refer to the Fabric OS Administrator’s Guide and the Fabric OS Command Reference
Manual .
Ethernet or serial connection
Brocade Web Tools
For information, refer to the Web Tools Administrator’s Guide .
Ethernet or serial connection
Standard SNMP applications
For information, refer to the MIB Reference Manual .
Ethernet or serial connection
Brocade Fabric Manager (option to purchase)
For information, refer to the Fabric Manager Administrator’s Guide .
Ethernet or serial connection
Management Server
For information, refer to the Fabric OS Administrator’s Guide and the Fabric OS
Command Reference Manual .
Ethernet or serial connection
EFCM (option to purchase)
For information, refer to theEFCM documentation set.
Ethernet or serial connection
NOTE
To achieve in-band support for IP over Fibre Channel, the software must be run on both the HBA and the switch, and it must be
supported by both the HBA and HBA driver.
Ports on Demand license
The Brocade 5300 has 80 ports. By default, ports 0-47 are enabled. As your needs increase, you can activate unlicensed ports by
purchasing and installing the Brocade Ports on Demand (POD) optional licensed product. After it has been installed, the license appears
in the licenseShow command output as Ports on Demand license .
To install a Ports on Demand license, you can either use the supplied license key or generate a license key. Typically the switch is shipped
with a paper pack that species the transaction key to use with the Software License Keys link. Use this transaction key on the Brocade
Web site at www.brocade.com /licensekeys and follow the instructions to generate the key. You can also use this site to generate other
license keys for your switch.
After you have installed the license keys, you must enable the ports. You can do so without disrupting switch operation by using the
portEnable command on each port individually. Alternatively, you can disable and re-enable the switch to activate all ports
simultaneously.
For detailed information on enabling additional ports using the Ports on Demand license, refer to the Fabric OS Administrator’s Guide .
Brocade Inter-Switch Link (ISL) Trunking
Brocade ISL Trunking is optional software that allows you to create trunking groups of ISLs between adjacent switches. Each eight port
group on the Brocade 5300 can be used as a trunking group. For more information about Brocade ISL Trunking, see the Brocade
Fabric OS Administration Guide.
Brocade Inter-Switch Link (ISL) Trunking
Brocade 5300 Hardware Installation Guide
53-1000858-07 17

Brocade 5300 Hardware Installation Guide
18 53-1000858-07

Preparing for Installation
• General precautions..........................................................................................................................................................................................19
• ESD precautions................................................................................................................................................................................................ 19
• Power precautions.............................................................................................................................................................................................20
• RTC battery.......................................................................................................................................................................................................... 20
• Environmental considerations...................................................................................................................................................................... 20
• EIA rack considerations...................................................................................................................................................................................21
• Recommendations for cable management............................................................................................................................................21
• Items included with the Brocade 5300................................................................................................................................................... 22
General precautions
When using this product, observe all danger, caution, and attention notices in this manual. The notices are accompanied by symbols that
represent the severity of the safety condition.
NOTE
Refer to Cautions and Danger Notices on page 91 for translations of safety notices for this product.
DANGER
The procedures in this manual are for qualied service personnel.
CAUTION
Changes or modications made to this device that are not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
ESD precautions
This product contains electrostatic discharge (ESD) sensitive eld-replacable units (FRUs) When working with any FRU, use correct ESD
procedures.
CAUTION
Before plugging a cable into any port, be sure to discharge the voltage stored on the cable by touching the electrical
contacts to ground surface.
CAUTION
Static electricity can damage the chassis and other electronic devices. To avoid damage, keep static-sensitive devices in
their static-protective packages until you are ready to install them.
Wear a wrist grounding strap connected to chassis ground (if the device is plugged in) or a bench ground.
DANGER
For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor.
Brocade 5300 Hardware Installation Guide
53-1000858-07 19

Power precautions
To install and operate the switch successfully, ensure the following:
• The primary outlet is correctly wired, protected by a circuit breaker, and grounded in accordance with local electrical codes.
DANGER
Make sure that the power source circuits are properly grounded, then use the power cord supplied with the device
to connect it to the power source.
• The supply circuit, line fusing, and wire size are adequate, as specied by the electrical rating on the switch nameplate.
• This switch might have more than one power cord. To reduce the risk of electric shock, disconnect both power cords before
servicing.
DANGER
Remove both power cords before servicing.
DANGER
Disconnect the power cord from all power sources to completely remove power from the device.
• This product is designed for an IT power system with phase-to-phase voltage of 230V. After operation of the protective device,
the equipment is still under voltage if it is connected to an IT power system.
DANGER
To avoid high voltage shock, do not open the device while the power is on.
• The power supply standards provided in Power supply specications on page 82
RTC battery
Do not attempt to replace the real-time clock (RTC) battery. There is danger of explosion if the battery is incorrectly replaced or disposed
of. Contact your switch supplier if the real-time clock begins to lose time.
DANGER
Batteries used for RTC/NVRAM backup are not located in operator-access areas. There is a risk of explosion if a battery
is replace by an incorrect type. Dispose of used components containing batteries according to the local ordinance and
regulations.
Environmental considerations
For successful installation and operation of the switch, ensure that the following environmental requirements are met:
• At a minimum, adequate cooling requires that you install the switch with the non-port side, which contains the air intake vents,
facing the cool-air aisle.
• All equipment in the rack should force air in the same direction to avoid intake of exhaust air.
CAUTION
Ensure that the airow direction of the power supply unit matches that of the installed fan tray. The power supplies
and fan trays are clearly labeled with either a green arrow with an "E", or an orange arrow with an "I."
