Brocade Communications Systems 7840 Quick user guide

53-1003127-02
13 October 2014
Brocade 7840 Extension
Switch
Hardware Reference Manual

© 2014, Brocade Communications Systems, Inc. All Rights Reserved.
Brocade, the B-wing symbol, Brocade Assurance, ADX, AnyIO, DCX, Fabric OS, FastIron, HyperEdge, ICX, MLX, MyBrocade, NetIron,
OpenScript, VCS, VDX, and Vyatta are registered trademarks, and The Effortless Network and the On-Demand Data Center are trademarks
of Brocade Communications Systems, Inc., in the United States and in other countries. Other brands and product names mentioned may be
trademarks of others.
Notice: This document is for informational purposes only and does not set forth any warranty, expressed or implied, concerning any
equipment, equipment feature, or service offered or to be offered by Brocade. Brocade reserves the right to make changes to this document
at any time, without notice, and assumes no responsibility for its use. This informational document describes features that may not be
currently available. Contact a Brocade sales office for information on feature and product availability. Export of technical data contained in
this document may require an export license from the United States government.
The authors and Brocade Communications Systems, Inc. assume no liability or responsibility to any person or entity with respect to the
accuracy of this document or any loss, cost, liability, or damages arising from the information contained herein or the computer programs that
accompany it.
The product described by this document may contain open source software covered by the GNU General Public License or other open
source license agreements. To find out which open source software is included in Brocade products, view the licensing terms applicable to
the open source software, and obtain a copy of the programming source code, please visit http://www.brocade.com/support/oscd.

Contents
Preface.....................................................................................................................................5
Document conventions......................................................................................5
Text formatting conventions.................................................................. 5
Command syntax conventions.............................................................. 5
Notes, cautions, and warnings.............................................................. 6
Brocade resources............................................................................................ 7
Contacting Brocade Technical Support.............................................................7
Document feedback.......................................................................................... 8
About This Document................................................................................................................ 9
Supported software........................................................................................... 9
What’s new in this document............................................................................ 9
Introducing the Brocade 7840 Extension Switch......................................................................11
Overview of Brocade 7840 Extension Switch................................................. 11
Brocade 7840 software features......................................................... 11
Brocade 7840 hardware features........................................................12
Brocade 7840 feature licensing...........................................................12
Port side of the switch..................................................................................... 13
Nonport side of the switch...............................................................................14
Switch management........................................................................................16
Installing and Configuring the Switch.......................................................................................19
Installation and safety considerations............................................................. 19
Installation Precautions................................................................................... 20
General precautions............................................................................20
Power Precautions.............................................................................. 20
Items included with the switch.........................................................................21
Setting up the Brocade 7840 as a standalone unit......................................... 21
Installing in an EIA rack...................................................................................22
Initial setup of the switch................................................................................. 22
Providing power to the switch............................................................. 23
Connecting to the switch using the serial connection......................... 23
Setting the switch IP address..............................................................24
Changing the switch name and chassis name....................................24
Creating an Ethernet connection.........................................................25
Setting the domain ID of the switch.....................................................25
Setting the date and time of the switch............................................... 25
Synchronizing local time with an external source............................... 26
Correcting the time zone of a switch................................................... 26
FCIP and Fibre Channel routing services configuration......................27
Installing transceivers and cabling the switch..................................... 27
Verifying correct operation and backing up the configuration............. 28
Recommendations for cable management..................................................... 30
Operating the Switch...............................................................................................................31
Brocade 7840 Extension Switch Hardware Reference Manual 3
53-1003127-02

LED activity................................................................................................... 31
LEDs on the port side of the Extension Switch................................. 31
LEDs on the nonport side of the switch............................................ 34
Interpreting POST results..............................................................................36
Switch maintenance......................................................................................36
Diagnostic tests.................................................................................36
Field-replaceable units......................................................................37
Powering off the switch................................................................................. 37
Removing and replacing transceivers...........................................................38
Time and items required................................................................... 38
Removing an SFP+ transceiver........................................................ 38
Replacing an SFP+ transceiver........................................................ 38
Removal and Replacement of Power Supplies and Fans.........................................................41
Removal and replacement introduction........................................................ 41
Before beginning replacement.......................................................... 41
Power supply removal and replacement.......................................................42
Determining the need to replace a power supply..............................42
Time and items required................................................................... 43
Replacing a power supply.................................................................43
Fan removal and replacement...................................................................... 44
Determining the need to replace a fan..............................................45
Time and items required................................................................... 45
Replacing a Brocade 7840 fan..........................................................45
Brocade 7840 Technical Specifications................................................................................ 47
Regulatory Statements..........................................................................................................55
BSMI statement (Taiwan)..............................................................................55
Canadian requirements.................................................................................55
CE Statement................................................................................................55
China CC statement......................................................................................56
FCC warning (US only)................................................................................. 56
Germany....................................................................................................... 57
KCC statement (Republic of Korea)..............................................................57
VCCI statement.............................................................................................57
Cautions and Danger Notices................................................................................................59
Cautions........................................................................................................59
Danger Notices............................................................................................. 61
Index.................................................................................................................................... 65
4Brocade 7840 Extension Switch Hardware Reference Manual
53-1003127-02

Preface
● Document conventions......................................................................................................5
● Brocade resources............................................................................................................ 7
● Contacting Brocade Technical Support.............................................................................7
● Document feedback.......................................................................................................... 8
Document conventions
The document conventions describe text formatting conventions, command syntax conventions, and
important notice formats used in Brocade technical documentation.
Text formatting conventions
Text formatting conventions such as boldface, italic, or Courier font may be used in the flow of the text
to highlight specific words or phrases.
Format Description
bold text Identifies command names
Identifies keywords and operands
Identifies the names of user-manipulated GUI elements
Identifies text to enter at the GUI
italic text Identifies emphasis
Identifies variables and modifiers
Identifies paths and Internet addresses
Identifies document titles
Courier font Identifies CLI output
Identifies command syntax examples
Command syntax conventions
Bold and italic text identify command syntax components. Delimiters and operators define groupings of
parameters and their logical relationships.
Convention Description
bold text Identifies command names, keywords, and command options.
italic text Identifies a variable.
Brocade 7840 Extension Switch Hardware Reference Manual 5
53-1003127-02

Convention Description
value In Fibre Channel products, a fixed value provided as input to a command
option is printed in plain text, for example, --show WWN.
[ ] Syntax components displayed within square brackets are optional.
Default responses to system prompts are enclosed in square brackets.
{ x | y | z } A choice of required parameters is enclosed in curly brackets separated by
vertical bars. You must select one of the options.
In Fibre Channel products, square brackets may be used instead for this
purpose.
x | yA vertical bar separates mutually exclusive elements.
< > Nonprinting characters, for example, passwords, are enclosed in angle
brackets.
... Repeat the previous element, for example, member[member...].
\Indicates a “soft” line break in command examples. If a backslash separates
two lines of a command input, enter the entire command at the prompt without
the backslash.
Notes, cautions, and warnings
Notes, cautions, and warning statements may be used in this document. They are listed in the order of
increasing severity of potential hazards.
NOTE
A Note provides a tip, guidance, or advice, emphasizes important information, or provides a reference
to related information.
ATTENTION
An Attention statement indicates a stronger note, for example, to alert you when traffic might be
interrupted or the device might reboot.
CAUTION
A Caution statement alerts you to situations that can be potentially hazardous to you or cause
damage to hardware, firmware, software, or data.
DANGER
A Danger statement indicates conditions or situations that can be potentially lethal or
extremely hazardous to you. Safety labels are also attached directly to products to warn of
these conditions or situations.
Notes, cautions, and warnings
6 Brocade 7840 Extension Switch Hardware Reference Manual
53-1003127-02

Brocade resources
Visit the Brocade website to locate related documentation for your product and additional Brocade
resources.
You can download additional publications supporting your product at www.brocade.com. Select the
Brocade Products tab to locate your product, then click the Brocade product name or image to open the
individual product page. The user manuals are available in the resources module at the bottom of the
page under the Documentation category.
To get up-to-the-minute information on Brocade products and resources, go to MyBrocade. You can
register at no cost to obtain a user ID and password.
Release notes are available on MyBrocade under Product Downloads.
White papers, online demonstrations, and data sheets are available through the Brocade website.
Contacting Brocade Technical Support
As a Brocade customer, you can contact Brocade Technical Support 24x7 online, by telephone, or by e-
mail. Brocade OEM customers contact their OEM/Solutions provider.
Brocade customers
For product support information and the latest information on contacting the Technical Assistance
Center, go to http://www.brocade.com/services-support/index.html.
If you have purchased Brocade product support directly from Brocade, use one of the following methods
to contact the Brocade Technical Assistance Center 24x7.
Online Telephone E-mail
Preferred method of contact for non-
urgent issues:
•My Cases through MyBrocade
•Software downloads and licensing
tools
•Knowledge Base
Required for Sev 1-Critical and Sev
2-High issues:
• Continental US: 1-800-752-8061
• Europe, Middle East, Africa, and
Asia Pacific: +800-AT FIBREE
([phone])
• For areas unable to access toll
free number: [phone]
•Toll-free numbers are available in
many countries.
[email protected]
Please include:
• Problem summary
• Serial number
• Installation details
• Environment description
Brocade OEM customers
If you have purchased Brocade product support from a Brocade OEM/Solution Provider, contact your
OEM/Solution Provider for all of your product support needs.
• OEM/Solution Providers are trained and certified by Brocade to support Brocade® products.
• Brocade provides backline support for issues that cannot be resolved by the OEM/Solution Provider.
Brocade resources
Brocade 7840 Extension Switch Hardware Reference Manual 7
53-1003127-02

• Brocade Supplemental Support augments your existing OEM support contract, providing direct
access to Brocade expertise. For more information, contact Brocade or your OEM.
• For questions regarding service levels and response times, contact your OEM/Solution Provider.
Document feedback
To send feedback and report errors in the documentation you can use the feedback form posted with
the document or you can e-mail the documentation team.
Quality is our first concern at Brocade and we have made every effort to ensure the accuracy and
completeness of this document. However, if you find an error or an omission, or you think that a topic
needs further development, we want to hear from you. You can provide feedback in two ways:
• Through the online feedback form in the HTML documents posted on www.brocade.com.
• By sending your feedback to [email protected].
Provide the publication title, part number, and as much detail as possible, including the topic heading
and page number if applicable, as well as your suggestions for improvement.
Document feedback
8 Brocade 7840 Extension Switch Hardware Reference Manual
53-1003127-02

About This Document
● Supported software........................................................................................................... 9
● What’s new in this document............................................................................................ 9
Supported software
This document includes information specific to the Brocade 7840 running Brocade Fabric version OS
7.3 and later.
What’s new in this document
The following changes have been made since this document was last released:
• Added information about the SFPs included with the switch.
• Reorganized the table listing the weight specifications of the switch.
Brocade 7840 Extension Switch Hardware Reference Manual 9
53-1003127-02

What’s new in this document
10 Brocade 7840 Extension Switch Hardware Reference Manual
53-1003127-02

Introducing the Brocade 7840 Extension Switch
● Overview of Brocade 7840 Extension Switch................................................................. 11
● Port side of the switch..................................................................................................... 13
● Nonport side of the switch...............................................................................................14
● Switch management........................................................................................................16
Overview of Brocade 7840 Extension Switch
The Brocade 7840 Extension Switch is intended as a platform for Fibre Channel over IP (FCIP). This
enables transmission of Fibre Channel data over long distances by way of IP networks by wrapping
Fibre Channel frames in IP packets. Each end of the FCIP communication path must be a compatible
FCIP device.
The switch can operate independently or in a fabric containing multiple extension switches.
Brocade 7840 software features
The Brocade 7840 provides the following software features:
• Multiple logical FCIP tunnels with maximum tunnel bandwidth up to 20Gbps allow for scalable
connectivity between sites. Note that the 7840 does not support FCIP connectivity with any other
products including the Brocade 7800 and FX8-24.
• FCIP Trunking feature allows multiple IP source and destination address pairs (defined as FCIP
circuits) via multiple 1/10GbE or 40GbE interfaces to provide high bandwidth FCIP tunnel and
lossless failover resiliency. In addition, each FCIP circuit supports four QoS classes (Class-F, High,
Medium and Low Priority), each as a TCP connection.
• ARL feature meets minimum bandwidth guarantee for each tunnel while making the full utilization of
the available network bandwidth without adverse throughput performance impact at high traffic load.
• Hardware-based compression delivers the ability to maximize throughput over lower bandwidth links
in the wide area network, optimizing the cost efficiencies of FCIP. The 7840 compresses FC frames
before they are encapsulated into FCIP packets.
• Key protocol features are enabled in the FCIP implementation to optimize performance of Extension
over IP networks, including FX8-24 and WAN Optimized TCP (WO-TCP), 9K jumbo frame and end-
to-end Path MTU auto discovery.
• Hardware-based IPsec supports mix of secure and non-secure tunnels on the same Ethernet port,
jumbo frames, and VLAN tagged connections. The Brocade 7840 IPsec function is capable of
supporting both IPv4 and IPv6.
• FastWrite, Open Systems Tape Pipelining and Advanced Accelerator for FICON mitigate the latency
effect of a long distance FCIP distance connection over IP WAN.
• FCIP HCL (Hot Code Load) provides In-service firmware upgrade for supporting 24/7 non-stop
business operations
• Built-in WAN link tester generates traffic over an IP connection to test for maximum throughput,
congestion, loss percentage, out of order deliver, latency, and other network conditions. It helps
determine the health of a WAN link before deploying it for use.
• Fabric Vision advanced monitoring provides the following functions:
Brocade 7840 Extension Switch Hardware Reference Manual 11
53-1003127-02

‐Policy based monitoring monitors FCIP connectivity and WAN anomalies using multi-layer
metrics.
‐Flow monitoring reports IOPS and data rate of individual I/O flows of inter-DC replication
and tape backup operations.
‐Flow generator generates FC frames for a defined flow with default or custom size and
pattern and sent across FCIP tunnel to help validate end to end network setup and
configuration.
• Brocade Fabric OS delivers distributed intelligence throughout the network and enables a wide
range of value-added applications.
Brocade 7840 hardware features
The Brocade 7840 provides the following hardware features:
• 24 Fibre Channel ports with link speeds of 2, 4, 8, and 16 Gbps, compatible with short wavelength
(SWL), long wavelength (LWL) and extended long wavelength (ELWL) SFP+ transceivers
• Rack-mountable 2U chassis
• Sixteen 1 GbE/10 GbE ports, compatible with copper, ultra short reach (USR), short reach (SR) and
long reach (LR) SFP/SFP+ transceivers
• Two 40 GbE ports, compatible with short reach (SR) and long reach (LR) QSFP transceivers
• One RJ-45 Ethernet management port with 10/100/1000 Mbps autonegotiating capability
• One USB port that provides storage for firmware updates, output of the supportSave command,
and storage for configuration uploads and downloads
• Two redundant, hot-swappable 1100 W AC/DC power supply units (PSUs) with integral fans
• 3 port-side exhaust DC fan FRUs
NOTE
QSFPs used in the FC16-64 blades (and 8510 core blades) are not compatible with the Brocade 7840.
Brocade 7840 feature licensing
The Brocade 7840 provides the following licensing features:
• Tiered WAN throughput licensing provides coverage of multiple customer segments with one
physical platform:
NOTE
The application throughput numbers shown in the following table assume that some degree of data
compression is occurring. However, Brocade makes no promises, guarantees, or any indication that
some level of compression is possible for customer-specific data. Some data is highly compressible
and some data cannot be compressed. The amount of application throughput varies depending on
data compressibility and the selected compression mode.
Product
configuration
FC Ports Ethernet Ports WAN rate limiting Approximate
Application
throughput
Base configuration 24 16G 16 1/10GbE 5 Gbps 15 Gbps (see note
above)
Brocade 7840 hardware features
12 Brocade 7840 Extension Switch Hardware Reference Manual
53-1003127-02

Medium
configuration (Base
+ WAN Rate
Upgrade 1)
24 16G 16 1/10GbE 10 Gbps 30 Gbps (see note
above)
Max configuration
(Base + WAN Rate
Upgrade 1 and
WAN Rate Upgrade
2)
24 16G 16 1/10GbE + 2
40GbE
Unlimited 80 Gbps (see note
above)
• Two base unit SKUs:
‐One SKU with SWL SFPs (Enterprise Bundle and Advanced Extension are included)
‐One SKU with LWL SFPs (Enterprise Bundle and Advanced Extension are included)
• Streamlined feature licensing:
‐The Brocade 7840 uses common licenses with other midrange products (e.g. Brocade
6510) for IR and CUP.
‐A new SKU for Advanced Acceleration for FICON license on the Brocade 7840 is
introduced.
• All ports and interfaces on the switch are active except for the 40GE interfaces. The 40GE interfaces
are enabled as part of WAN Rate Upgrade 2.
Available licenses
The following features are available with the purchase of a specific license key for the Brocade 7840:
• Integrated Routing (IR)
• Advanced Acceleration for FICON
• FICON CUP
• WAN Rate Upgrade 1
• WAN Rate Upgrade 2
For information on these features, refer to the Fabric OS Administrator's Guide.
Port side of the switch
The following figures show the port side of the switch.
1 System Status LED
2 Power Status LED
3 USB port
4 Ethernet Management port
5 Console port (RJ-45)
6 Serial number pull-out tab
Available licenses
Brocade 7840 Extension Switch Hardware Reference Manual 13
53-1003127-02

7 16 GbE FC ports (24) 8 40 GbE FCIP ports (QSFP) (2)
9 1/10 GbE FCIP ports (16)
FIGURE 1 Port side view of the Brocade 7840 Extension Switch
The Fibre Channel ports are numbered from left to right on the faceplate, as shown in the following
figure.
1 FC ports (16 GbE) 0 through 7
2 FC ports (16 GbE) 8 through 15
3 FC ports (16 GbE) 16 through 23
4 FCIP ports (40 GbE) 0 and 1 (QSFP)
5 FCIP ports (1/10 GbE) 2 through 9
6 FCIP ports (1/10 GbE) 10 through 17
FIGURE 2 Port numbering in the switch
You can have two Brocade Trunk groups on a fully licensed switch. Group 1 would consist of FC ports
0 through 7 and group 2 would be ports 8 through 15.
Nonport side of the switch
The following figure shows the nonport side of the switch, which contains two power supply FRUs and
three fan FRUs.
FIGURE 3 Nonport side of the switch
1 Fan FRUs 2 Power supply FRUs with integral fans
The following figure shows more details about the power supply and fan FRUs.
Nonport side of the switch
14 Brocade 7840 Extension Switch Hardware Reference Manual
53-1003127-02

FIGURE 4 Power supply and fan details
1 AC power socket 5 AC status LED
2 Handle 6 Fan air inlet
3 Integral fan air inlet 7 Handle
4 DC status LED
The following figure shows the airflow labels on the power supply and fan FRUs.
FIGURE 5 Power supply and fan airflow labels
1 Airflow label for PSU integral fan 2 Airflow label for fan FRU
Introducing the Brocade 7840 Extension Switch
Brocade 7840 Extension Switch Hardware Reference Manual 15
53-1003127-02

The following figure shows the fan airflow (Intake only) for the Brocade 7840. Exhaust airflow is not
supported in this release.
FIGURE 6 Fan airflow
Switch management
You can use the management functions built into the switch to monitor the fabric topology, port status,
physical status, and other information to help you analyze switch performance and to accelerate
system debugging.
For information about upgrading the version of Fabric OS installed on your switch, refer to the Fabric
OS Administrator's Guide
You can manage the switch using any of the management options listed in the following table.
Management options for the Brocade 7840TABLE 1
Management tool Out-of-band support In-band support
Command line interface (CLI)
Up to two admin sessions and four user sessions simultaneously.
For more information, refer to the Fabric OS Administrator's
Guide and the Fabric OS Command Reference.
Ethernet (preferred) or
console port connection
IP over Fibre
Channel
Brocade Network Advisor Ethernet (preferred) or
console port connection
IP over Fibre
Channel
Brocade Web Tools
For information, refer to the Web Tools Administrator's Guide.
Ethernet (preferred) or
console port connection
IP over Fibre
Channel
Standard SNMP applications
You can download the Brocade-specific MIB files from the
downloads area of the MyBrocade site under the applicable
Fabric Operating System (FOS) release.
For information about SNMP support in Fabric OS and how to
use MIBs, refer to the Fabric OS Administrator's Guide. For
release-specific SNMP enhancements, refer to the release notes.
NOTE
Distribution of standard MIBs has been stopped. Download the
required standard MIBs from the www.oidview.com or
www.mibdepot.com web sites.
Ethernet (preferred) or
console port connection
IP over Fibre
Channel
Switch management
16 Brocade 7840 Extension Switch Hardware Reference Manual
53-1003127-02

Management options for the Brocade 7840 (Continued)TABLE 1
Management tool Out-of-band support In-band support
Management Server
For information, refer to the Fabric OS Administrator's Guide and
the Fabric OS Command Reference.
Ethernet (preferred) or
console port connection
Native in-band
interface (over HBA
only)
Introducing the Brocade 7840 Extension Switch
Brocade 7840 Extension Switch Hardware Reference Manual 17
53-1003127-02

Switch management
18 Brocade 7840 Extension Switch Hardware Reference Manual
53-1003127-02

Installing and Configuring the Switch
● Installation and safety considerations............................................................................. 19
● Installation Precautions................................................................................................... 20
● Items included with the switch.........................................................................................21
● Setting up the Brocade 7840 as a standalone unit......................................................... 21
● Installing in an EIA rack...................................................................................................22
● Initial setup of the switch................................................................................................. 22
● Recommendations for cable management..................................................................... 30
Installation and safety considerations
You can install the switch in the following ways:
• As a standalone unit on a flat surface.
• In an EIA rack using the Universal Two-Post Rack Kit or Universal Four-Post Rack Kit.
To install and operate the switch successfully, ensure that the following requirements are met:
• The primary AC input is 100-240 VAC (Brocade 7840 autosenses input voltage), 50-60 Hz. 200-240
VAC is recommended.
• The primary outlet is correctly wired, protected by a circuit breaker, and grounded in accordance with
local electrical codes. It is best practice that each power supply obtain its power from a different
protected and wired source. It is best practice that each power supply obtain its power from a
different protected and wired source.
• The supply circuit, line fusing, and wire size are adequate, as specified by the electrical rating on the
Brocade 7840 nameplate.
For power supply information, refer to Power supplies and fans on page 37.
To ensure adequate cooling, install the Brocade 7840 with the nonport side, which contains the air
intake vents, facing a cool-air aisle.
CAUTION
Make sure the airflow around the front, sides, and back of the device is not restricted.
Verify that the ambient air temperature does not exceed 40°C ( 104°F) and that the ambient humidity
remains between 20 and 85 percent while the Brocade 7840 is operating.
CAUTION
Do not install the device in an environment where the operating ambient temperature might
exceed 40°C (104°F).
If installing the Brocade 7840 in a rack:
• The rack must be a standard EIA rack.
• Plan for a rack space that is 2U ( 8.89 cm; 3.5 in.), (19 in.) 48.3 cm wide, and at least 61cm (24 in.)
deep.
• Ground all equipment in the rack through a reliable branch circuit connection and maintain ground at
all times. Do not rely on a secondary connection to a branch circuit, such as a power strip.
Brocade 7840 Extension Switch Hardware Reference Manual 19
53-1003127-02

• Ensure that airflow and temperature requirements are met on an ongoing basis.
• Verify that the additional weight of the Brocade 7840 does not exceed the rack’s weight limits or
unbalance the rack in any way.
DANGER
Make sure the rack housing the device is adequately secured to prevent it from becoming
unstable or falling over.
Installation Precautions
Review all installation precautions before installing the device.
General precautions
DANGER
The procedures in this manual are for qualified service personnel.
CAUTION
Changes or modifications made to this device that are not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
DANGER
All fiber-optic interfaces use Class 1 lasers.
Power Precautions
This Extension Switch might have more than one power cord. To reduce the risk of electric shock,
disconnect both power cords before servicing.
DANGER
Remove both power cords before servicing.
DANGER
Disconnect the power cord from all power sources to completely remove power from the
device.
CAUTION
Before plugging a cable into to any port, be sure to discharge the voltage stored on the cable
by touching the electrical contacts to ground surface.
Connect the power cord only to a grounded outlet.
DANGER
Make sure that the power source circuits are properly grounded, then use the power cord
supplied with the device to connect it to the power source.
Installation Precautions
20 Brocade 7840 Extension Switch Hardware Reference Manual
53-1003127-02
