Brocade Communications Systems A7990A - StorageWorks SAN Director 4/16 Blade... Service manual

Publication Number: 53-1000241-01
Publication Date: 9/29/06
Fabric OS
MIB Reference
Supporting Fabric OS v3.1.x, v3.2.x, v4.1.x, v4.2.x, v4.4.x,
v5.0.x, v5.1.x, 5.2.x

Copyright © 2006, Brocade Communications Systems, Incorporated.
ALL RIGHTS RESERVED.
Brocade, the Brocade B weave logo, Fabric OS, File Lifecycle Manager, MyView, Secure Fabric OS, SilkWorm, and
StorageX are registered trademarks and Tapestry is a trademark of Brocade Communications Systems, Inc., in the
United States and/or in other countries. FICON is a registered trademarks of IBM Corporation in the U.S. and other
countries. All other brands, products, or service names are or may be trademarks or service marks of, and are used to
identify, products or services of their respective owners.
Notice: The information in this document is provided “AS IS,” without warranty of any kind, including, without
limitation, any implied warranty of merchantability, noninfringement or fitness for a particular purpose. Disclosure of
information in this material in no way grants a recipient any rights under Brocade's patents, copyrights, trade secrets or
other intellectual property rights. Brocade reserves the right to make changes to this document at any time, without
notice, and assumes no responsibility for its use.
The authors and Brocade Communications Systems, Inc. shall have no liability or responsibility to any person or entity
with respect to any loss, cost, liability, or damages arising from the information contained in this book or the computer
programs that accompany it.
Notice: The product described by this document may contain “open source” software covered by the GNU General
Public License or other open source license agreements. To find-out which open source software is included in Brocade
products, view the licensing terms applicable to the open source software, and obtain a copy of the programming source
code, please visit http://www.brocade.com/support/oscd.
Export of technical data contained in this document may require an export license from the United States Government.
Brocade Communications Systems, Incorporated
Corporate Headquarters
Brocade Communications Systems, Inc.
1745 Technology Drive
San Jose, CA 95110
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Asia-Pacific Headquarters
Brocade Communications Singapore Pte. Ltd.
9 Raffles Place
#59-02 Republic Plaza 1
Singapore 048619
Tel: [phone]
Fax: [phone]
Email: [e-mail]
European and Latin American Headquarters
Brocade Communications Switzerland Sàrl
Centre Swissair
Tour A - 2ème étage
29, Route de l'Aéroport
Case Postale 105
CH-1215 Genève 15
Switzerland
Tel: [phone]
Fax: [phone]
Email: [e-mail]

Document History
The following table lists all versions of the Fabric OS MIB Reference.
Document Title Publication
Number Summary of Changes Publication Date
Brocade MIB Reference Manual v2.3 53-0000069-02 December 2000
Brocade MIB Reference Manual v3.0 53-0000134-03 July 2001
Brocade MIB Reference Manual v3.0,
4.0 53-0000184-02 March 2002
Brocade MIB Reference Manual
(v4.1, v4.0.x, v3.1, v3.0.x, v2.6.x) 53-0000521-02 Added Brocade- specific Entity and
HA-MIBs.
April 2003
Brocade MIB Reference Manual
(v4.1.2, v4.1, v4.0.x, v3.1, v3.0.x,
v2.6.x)
53-0000521-03 Added FICON
information. May 2003
Brocade MIB Reference Manual
(v4.1.2, v4.1, v4.0.x, v3.1, v3.0.x,
v2.6.x)
53-0000521-04 Revised FICON
information. October 2003
Brocade MIB Reference Manual
(v4.2.0, v4.1.2, v4.1, v4.0.x, v3.1, v3.0.x,
v2.6.x)
53-0000521-06 Update to support the
SilkWorm 3250, 3850,
and 24000 switches.
December 2003
Brocade Fabric OS MIB Reference
Manual 53-0000521-08 Updated to support the SilkWorm 4100. September 2004
Brocade Fabric OS MIB Reference
Manual 53-0000521-09 Updated to support the SilkWorm 48000 and
200E.
April 2005
Brocade Fabric OS MIB Reference
Manual 53-1000045-01 Updated to support the SilkWorm 4900, 7500,
and FR4-18i blade.
January 2006
Brocade Fabric OS MIB Reference 53_1000241_01 Changed name,
updated to support
Fabric OS 5.2.x
September 2006

Fabric OS MIB Reference v
Publication Number: 53-1000241-01
Contents
About This Document
How This Document Is Organized . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Supported Hardware and Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
What’s New in This Document. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Document Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv
Getting Technical Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
Document Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvii
Chapter 1 Understanding Brocade SNMP
Understanding SNMP Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Understanding MIBs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Understanding SNMP Traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Object Instances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Loading Brocade MIBs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Brocade MIB Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Before Loading MIBs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
MIB Loading Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
SilkWorm 7500 / FR4-18i and Brocade MIBs . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Firmware Upgrades and Enabled Traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Fabric OS Commands for Configuring SNMP. . . . . . . . . . . . . . . . . . . . . . . . 1-8
Chapter 2 MIB-II (RFC1213-MIB)
MIB II Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
System Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Interfaces Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11
AT Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

vi Fabric OS MIB Reference
Publication Number: 53-1000241-01
IP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
ICMP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
TCP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
UDP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30
EGP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
Transmission Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
SNMP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
Chapter 3 FE MIB Objects
FE MIB Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
FIBRE-CHANNEL-FE-MIB (MIB-II branch). . . . . . . . . . . . . . . . . . . . . . . . 3-1
Definitions for FIBRE-CHANNEL-FE-MIB. . . . . . . . . . . . . . . . . . . . . . . . . 3-6
fcFeConfig Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
fcFeStatus Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
fcFeError Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
feFcAccounting Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
fcFeCapability Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-22
FCFABRIC-ELEMENT-MIB (Experimental Branch). . . . . . . . . . . . . . . . . . 3-24
fcFeConfig Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-32
fcFeOp Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-37
fcFeError Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-42
fcFeAcct Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-44
fcFeCap Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-44
Chapter 4 Entity MIB Objects
Entity MIB Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Entity MIB System Organization of MIB Objects . . . . . . . . . . . . . . . . . . 4-2
Definitions for Entity MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Textual Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Entity MIB Objects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Physical Entity Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Logical Entity Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13

Fabric OS MIB Reference vii
Publication Number: 53-1000241-01
Entity Mapping Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
General Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
Entity MIB Trap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
Entity MIB Conformance Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
Chapter 5 SW-MIB Objects
SW MIB Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
SW-MIB System Organization of MIB Objects. . . . . . . . . . . . . . . . . . . . 5-2
Textual Conventions for SW-MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
sw Traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
swSystem Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
Flash Administration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
swFabric Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-27
SW Agent Configuration Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-30
Fibre Channel Port Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-31
Name Server Database Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-37
Event Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-40
Fabric Watch Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-41
End Device Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-50
Switch Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-51
ASIC Performance Monitoring Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-53
Trunking Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-55
Chapter 6 High-Availability MIB Objects
HA MIB Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
High-Availability Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
FRU Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
FRU History Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
CP Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
HA-MIB Traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
HA-MIB Traps and Sample Triggers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10

viii Fabric OS MIB Reference
Publication Number: 53-1000241-01
Chapter 7 FICON MIB Objects
FICON MIB Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
SNMP Traps for FICON. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
FICON MIB System Organization of MIB Objects. . . . . . . . . . . . . . . . . 7-2
Textual Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
ficonRNID Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
ficonLIRR Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
ficonRLIR Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
linkIncidentMIBTraps Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Chapter 8 FibreAlliance MIB Objects
FibreAlliance MIB Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
FCMGMT-MIB System Organization of MIB Objects . . . . . . . . . . . . . . 8-1
Definitions for FCMGMT-MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7
ConnSet Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Statistics Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-33
Service Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-41
SNMP Trap Registration Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-43
Revision Number Scalar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-45
Unsupported Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-46
FibreAlliance MIB Traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-46
Appendix A MIB Object Groupings
Switch Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Sensor Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Port Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Event Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
ISL and End Device Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
SNMP Configuration Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3

Fabric OS MIB Reference ix
Publication Number: 53-1000241-01
Appendix B MIB OIDs and Their Matching Object Names
MIB OIDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Index

xFabric OS MIB Reference
Publication Number: 53-1000241-01

Fabric OS MIB Reference xi
Publication Number: 53-1000241-01
About This Document
This reference document is for SNMP administrators who need to configure and administer the SNMP
interface to manage a fabric. “About This Document” contains the following sections:
•“How This Document Is Organized,” next
•“Supported Hardware and Software” on page xii
•“What’s New in This Document” on page xii
•“Document Conventions” on page xiii
•“Additional Information” on page xiv
•“Getting Technical Help” on page xvi
•“Document Feedback” on page xvii
How This Document Is Organized
This document is organized to help you find the particular information that you want as quickly and
easily as possible.
The document contains the following components:
•Chapter 1, “Understanding Brocade SNMP” provides an introduction to Brocade SNMP and MIBs.
•Chapter 2, “MIB-II (RFC1213-MIB)” provides information for MIB-II.
•Chapter 3, “FE MIB Objects” provides information for FE MIB object types.
•Chapter 4, “Entity MIB Objects” provides information for Entity MIB object types.
•Chapter 5, “SW-MIB Objects” provides information for FC Switch MIB (SW-MIB) object types.
•Chapter 6, “High-Availability MIB Objects” provides information for High-Availability MIB
object types.
•Chapter 7, “FICON MIB Objects” provides information for FICON MIB (LINK-INCIDENT-MIB)
object types.
•Chapter 8, “FibreAlliance MIB Objects” provides information for FibreAlliance MIB (FCMGMT-
MIB) object types.
•Appendix A, “MIB Object Groupings” is a function-based listing of MIB objects.
•Appendix B, “MIB OIDs and Their Matching Object Names” provides a listing of the MIB object
names and the corresponding MIB Object ID (OID) associated with each.

xii Fabric OS MIB Reference
Publication Number: 53-1000241-01
Supported Hardware and Software
This document supports Brocade Fabric OS versions Fabric OS v3.1.x, v3.2.x, v4.1.x, v4.2.x, v4.4.0,
5.0.x, v5.1.x, v 5.2.x, and all switches supporting these Fabric OS versions, including:
•SilkWorm 200E switch
•SilkWorm 3014 switch
•SilkWorm 3016 switch
•SilkWorm 3200 switch
•SilkWorm 3250 switch
•SilkWorm 3800 switch
•SilkWorm 3850 switch
•SilkWorm 3900 switch
•SilkWorm 4012 switch
•SilkWorm 4100 switch
•SilkWorm 4020 switch
•SilkWorm 4900 switch
•SilkWorm 7500 switch
•SilkWorm 12000 director
•SilkWorm 24000 director
•SilkWorm 48000 director (including the FR4-18i, FC4-16IP, and FC4-48 blades)
Although many different software and hardware configurations are tested and supported by Brocade
Communications Systems, Inc. for the Fabric OS v5.2.0 release, documenting all possible
configurations and scenarios is beyond the scope of this document. This document supports only the
Fabric OS versions and switches listed above.
What’s New in This Document
The following changes have been made since this document was last released:
•Information that was changed:
-General formatting changes
-swFCPortFlag MIB variable has been added to SW MIB
-snmpEngineID values have been modified

Fabric OS MIB Reference xiii
Publication Number: 53-1000241-01
Document Conventions
This section describes text formatting conventions and important notices formats.
Text Formatting
The narrative-text formatting conventions that are used in this document are as follows:
bold text Identifies command names
Identifies the names of user-manipulated GUI elements
Identifies keywords and operands
Identifies text to enter at the GUI or CLI
italic text Provides emphasis
Identifies variables
Identifies paths and Internet addresses
Identifies document titles
code text Identifies CLI output
Identifies syntax examples
For readability, command names in the narrative portions of this guide are presented in mixed
lettercase: for example, switchShow. In actual examples, command lettercase is often all lowercase.
Otherwise, this manual specifically notes those cases in which a command is case sensitive.
Notes, Cautions, and Warnings
The following notices appear in this document.
Special Term Uses
For definitions of SAN-specific terms, visit the Storage Networking Industry Association online
dictionary at http://www.snia.org/education/dictionary.
N
ote
A note provides a tip, emphasizes important information, or provides a reference to related information.
C
aution
A caution alerts you to potential damage to hardware, firmware, software, or data.
W
arning
A warning alerts you to potential danger to personnel.

xiv Fabric OS MIB Reference
Publication Number: 53-1000241-01
Additional Information
This section lists additional Brocade and industry-specific documentation that you might find helpful.
Brocade Resources
The following related documentation is provided on the Brocade Documentation CD-ROM and on the
Brocade Web site, through Brocade Connect.
Fabric OS
•Fabric OS Administrator’s Guide
•Fabric OS Command Reference
•Fabric OS Message Reference
•Brocade Glossary
Fabric OS Optional Features
•Web Tools Administrator’s Guide
•Fabric Watch Administrator’s Guide
•Fabric Manager Administrator’s Guide
•Secure Fabric OS Administrator’s Guide
For practical discussions about SAN design, implementation, and maintenance, you can obtain Building
SANs with Brocade Fabric Switches through:
http://www.amazon.com
For additional Brocade documentation, visit the Brocade SAN Info Center and click the Resource
Library location:
http://www.brocade.com
Optional Brocade Features
Optional Brocade features include:
Advanced Performance Monitoring
Enables more effective end-to-end SAN performance analysis to enhance
performance tuning, increase productivity, optimize resource utilization, and reduce
costs.
N
ote
Go to http://www.brocade.com and click Brocade Connect to register at no cost for a user ID and
password.

Fabric OS MIB Reference xv
Publication Number: 53-1000241-01
Extended Fabrics Supports the reliable, high-speed connectivity of SilkWorm switches over dark fiber
or Dense Wave Division Multiplexing (DWDM) equipment at distances up to 500 km
to enhance business continuance operations.
Fabric Watch Continuously monitors SAN fabrics for potential faults based on thresholds set for a
variety of SAN fabric elements and events—automatically alerting administrators to
potential problems before they become costly failures.
ISL Trunking Optimizes the performance and availability of SAN fabrics while simplifying ISL
management. Two 4 Gbit/sec SilkWorm switches can automatically group up to eight
ISLs into a single logical “trunk” with a total throughput of up to
32 Gbit/sec.
Advanced ZoningAutomatically groups SAN fabric-connected devices into logical zones that restrict
access to “member” devices in the zone. Advanced Zoning uses hardware
enforcement at both the port and WWN level to provide more robust data protection.
Secure Fabric OSProvides a comprehensive security solution to help protect mission-critical data. Key
features include centralized policy-based security management, management data
encryption, and authentication to create a fabric-wide trusted environment with
control over all levels of fabric access and communication.
FICON®CUP Enables IBM host-based management programs to manage FICON fabric switches
in-band by sending commands to the Fabric OS emulated control device.
Other Industry Resources
In addition to this manual, the following information about fabric security and the Secure Fabric OS
product is available:
•White papers, online demos, and data sheets are available through the Brocade Web site at:
http:// www.brocade.com/products/software.jhtml
•Best practice guides, including the SAN Security Best Practice Guide, white papers, online demos,
data sheets, and other documentation is available through the Brocade Partner Web site.
•The CERT®Coordination Center of Carnegie Mellon University provides industry-level
information about certification at:
http://www.cert.org
For additional resource information, visit the Technical Committee T11 Web site. This Web site
provides interface standards for high-performance and mass storage applications for Fibre Channel,
storage management, and other applications:
http://www.t11.org
For information about the Fibre Channel industry, visit the Fibre Channel Industry Association Web
site:
http://www.fibrechannel.org

xvi Fabric OS MIB Reference
Publication Number: 53-1000241-01
Getting Technical Help
Contact your switch support supplier for hardware, firmware, and software support, including product
repairs and part ordering. To expedite your call, have the following information available:
1. General Information
•Technical Support contract number, if applicable
•Switch model
•Switch operating system version
•Error numbers and messages received
•supportSave command output
•Detailed description of the problem and specific questions
•Description of any troubleshooting steps already performed and results
•Serial console and telnet session logs
•syslog message logs
2. Switch Serial Number
The switch serial number and corresponding bar code are provided on the serial number label, as
shown here:
:
The serial number label is located as follows:
•SilkWorm 2000-series switches: Bottom of chassis.
•SilkWorm 3014 switches: Top of chassis, under the insertion arm.
•SilkWorm 3016 and 4012 switches: Side of switch module.
•SilkWorm 200E, 3200, and 3800 switches: nonport side of chassis.
•SilkWorm 3250, 3850, 3900, 4100, 4900, and 7500 switches: Bottom of chassis.
•SilkWorm 24000, and 48000 directors: Inside the front of the chassis, on the wall to the left of
the ports.
•SilkWorm Multiprotocol Router Model AP7420: On the bottom of the chassis and on the back
of the chassis.
3. World Wide Name (WWN)
•SilkWorm 200E, 3014, 3016, 3250, 3600, 3850, 3900, 4012, 4100, 4900, 7500 switches and
SilkWorm 24000, and 48000 directors: Provide the license ID. Use the licenseIdShow
command to display the license ID.
•SilkWorm Multiprotocol Router Model AP7420: Provide the switch WWN. Use the
switchShow command to display the switch WWN.
•All other SilkWorm switches: Provide the switch WWN. Use the wwn command to display the
switch WWN.
*FT00X0054E9
FT00X0054E9

Fabric OS MIB Reference xvii
Publication Number: 53-1000241-01
Document Feedback
Because quality is our first concern at Brocade, we have made every effort to ensure the accuracy and
completeness of this document. However, if you find an error or an omission, or you think that a topic
needs further development, we want to hear from you. Forward your feedback to:
[e-mail]
Provide the title and version number and as much detail as possible about your comment, including the
topic heading and page number and your suggestions for improvement.

xviii Fabric OS MIB Reference
Publication Number: 53-1000241-01

Fabric OS MIB Reference 1-1
Publication Number: 53-1000241-01
Chapter
1
Understanding Brocade SNMP
The Simple Network Management Protocol (SNMP) is an industry-standard method of monitoring and
managing network devices. This protocol promotes interoperability, because SNMP-capable systems
must adhere to a common set of framework and language rules.
Understanding the components of SNMP makes it possible to use third-party tools to view, browse, and
manipulate Brocade switch variables (MIBs) remotely as well as to set up an enterprise-level
management process. Every Brocade switch and director supports SNMP.
This chapter discusses the following:
•“Understanding SNMP Basics,” next
•“Loading Brocade MIBs” on page 1-5
•“SilkWorm 7500 / FR4-18i and Brocade MIBs” on page 1-8
•“Firmware Upgrades and Enabled Traps” on page 1-8
•“Fabric OS Commands for Configuring SNMP” on page 1-8
Understanding SNMP Basics
Every Brocade SilkWorm switch carries an agent and management information base (MIB), as shown
in Figure 1-1. The agent accesses information about a device and makes it available to an SNMP
network management station.
Figure 1-1 SNMP Structure
When active, the management station can get information or set information when it queries an agent.
SNMP commands, such as - get, set, getnext, setnext, and getresponse - are sent from the management
station, and the agent replies once the value is obtained or modified (see Figure 1-2). Agents use
variables to report such data as the number of bytes and packets in and out of the device, or the number
of broadcast messages sent and received. These variables are also known as managed objects. All
managed objects are contained in the MIB.
Agent
Management Station SNMP MIB

1-2 Fabric OS MIB Reference
Publication Number: 53-1000241-01
Understanding SNMP Basics
1
Figure 1-2 SNMP Query
The management station can also receive traps, unsolicited messages from the switch agent if an
unusual event occurs. See “Understanding SNMP Traps” on page 1-4 for more information.
Figure 1-3 SNMP Trap
The agent can receive queries from one or more management stations and can send traps to up to six
management stations.
Understanding MIBs
The management information base (MIB) is a database of monitored and managed information on a
device, in this case a Brocade switch. The MIB structure can be represented by a tree hierarchy. The
root splits into three main branches: International Organization for Standardization (ISO), Consultative
Committee for International Telegraph and Telephone (CCITT), and joint ISO/CCITT. These branches
have short text strings and integers (OIDs) to identify them. Text strings describe object names, while
integers allow software to create compact, encoded representations of the names.
Each MIB variable is assigned an object identifier (OID). The OID is the sequence of numeric labels on
the nodes along a path from the root to the object. For example, as shown in Figure 1-4, the Brocade
SW.MIB OID is:
1.3.6.1.4.1.1588
The corresponding name is:
iso.org.dod.internet.private.enterprise.bsci
The other branches are part of the standard MIBs, and the portions relevant to configuring SNMP on a
Brocade switch are referenced in the remainder of this reference.
Management Station Agent
get, getnext, set
reply
TRAP
Management Station Agent
