SUGGESTED RETAIL
PRICE LIST
Effective October 23, 2006
Grill Heads, Mountings,
Shelving and Accessories
P3 on PC2 Cart, with
Side Burner, and
Stainless Steel Shelves

Superb by Broilmaster Stainless Steel Grills
SSG 36 – The Ultimate Grill 1
SBG 2500 – 36,000 Btu 2
SBG-2501 – 36,000 Btu, plus 12,000 Btu Infrared Rotisserie 2
SBG-2801 – 48,000 Btu, plus 12,000 Btu Infrared Rotisserie 2
Broilmaster Premium Gas Grills
P3S and P3SN (Nat) – Top of the Line 3
P3FBL and P3FBLN (Nat) – Stainless Steel Flavor Screen 3
P4FBL and P4FBLN (Nat) – Stainless Steel Flavor Screen 3
P3BL and P3BLN (Nat) – Charmaster Briquets 4
P4BL and P4BLN (Nat) – Charmaster Briquets 4
T3 and T3N (Nat)– New for 2007! 5
Broilmaster Carts and Posts 6
Broilmaster Shelves & Side Burner 7
Grill Tools 8
Broilmaster Accessories 9
Contents Page

MODEL SSG36LP SSG36NAT
Suggested Retail Price $4,500.00 $4,500.00
Type of Gas LP Nat
Specifications
Total Cooking Area 691 Sq. In.
Direct Broiling Area 576 Sq. In.
Warming Rack Area 115 Sq. In
Housing Width, Left to Right 55-1/4 In.
Housing Height,Top to Bottom 26-3/4 In.
Housing Depth, Front to Back 25”
Overall Width with Shelves and 1 Sideburner 83-1/4”
Overall Height (with optional Cart) 56-3/4”
Shipping Weight, lbs. 326
Standard Features
Stainless Steel Burners 5 at 12,000 Btu ea.
2 Independently Controlled C e ramic Rotisserie Burn e rs 24,000 total Btu
Cast Stainless Steel Side Burner 30,000 Btu
Stainless Steel Side Shelf with Cup Tray Optional
Flat/Raised Two-Sided Stainless Steel Cooking Grids Included
Rotary Ignitors Included
2 Heat Indicators (Main and Grill Warming Area) Included
User's Guide Included
OPTIONS Model Weight Price
Stainless Steel Doors SGD-36 28 $402.00
Stainless Steel Cart SCG-36 109 $1,400.00
Insulation Jacket GIJ-36 39 $470.00
Large Cover (Cart) VCC-36 13 $338.00
Small Cover (Island) VCB-36 7 $180.00
Stainless Steel Side Shelf GSS-36 10.5 $191.00
Steamer Pan Set SSP-1 4 $46.00
1
SUPERB BY BROILMASTER SSG SERIES STAINLESS STEEL GRILL
SSG36 on Optional Stainless
Steel Cabinet Cart with
optional side shelf
114,000 total Btu
SSG36 with GIJ Insulation
Jacket built into
Custom Island
114,000 total Btu

MODEL
Suggested Retail Price $799.00 $999.00 $1,249.00
Type of Gas (Ships as LP, includes Conversion Kit) LP LP LP
Specifications
Total Cooking Area 580 580 660
Direct Broiling Area 440 440 500
Warming Rack Area (Chromed Wire) 140 140 160
Housing Depth, Front to Back 24 24 26
Overall Width with Standard Shelves 57 57 60
Overall Height (with Cart) 48 3/4 48 3/4 48 3/4
Shipping Weight, lbs. 165 170 180
Standard Features
Stainless Steel Burners 3 at 12,000 Btu 3 at 12,000 Btu 4 at 12,000 Btu
Rear Infrared Rotisserie Burner NA 8,000 Btu 12,000 Btu
Motorized Rotisserie NA Included Included
Porcelain-Coated Flame Tamers Included Included Included
Side Shelves 2 Painted 2 Stainless Steel 2 Stainless Steel
Porcelain Cast Iron Cooking Grids Included Included Included
Push-Button Electronic Ignitor Included Included Included
Heat Indicator Included Included Included
Cart Painted Stainless Steel Stainless Steel
Casters 4 4 4
Cutting Board 2 Included 2 Included 2 Included
User’s Guide Included Included Included
OPTIONS Model Weight Price
Black Grill Cover SBA005 4 $68.00
Side Burner DPASBC 10 $149.00
2
SUPERB BY BROILMASTER STAINLESS STEEL GRILLS
SBG 2501
SBG 2500 SBG 2801
SBG2801
4 Main Burners - 48,000 Btu
12,000 Btu IR Burner
Stainless Shelves
and Cart
SBG2501
3 Main Burners - 36,000 Btu
8,000 Btu IR Burner
Stainless Shelves
and Cart
SBG2500
36,000 Btu
Painted Shelves
and Cart

PREMIUM GAS GRILL HEADS
P3S P3SN P3FBL P3FBLN P4FBL P4FBLN
Suggested Retail Price $1,162.00 $1,143.00 $932.00 $913.00 $809.00 $790.00
Type of Gas Propane Propane Propane
Includes Includes Includes
Natural Natural Natural Natural Natural Natural
Conversion Kit Conversion Kit Conversion Kit
Total Cooking Area 695 Sq. In. 695 Sq. In. 695 Sq. In. 695 Sq. In. 473 Sq. In. 473 Sq. In.
Direct Broiling Area 442 Sq. In. 442 Sq. In. 442 Sq. In. 442 Sq. In. 360 Sq. In. 360 Sq. In.
Warming Rack Area 253 Sq. In 253 Sq. In 253 Sq. In. 253 Sq. In. 113 Sq. In. 113 Sq. In.
Housing Width, 26-3/4" 26-3/4" 26-3/4" 26-3/4" 24" 24"
Left to Right
Housing Height, 19" 19" 19" 19" 19" 19"
Top to Bottom
Housing Depth, 18-3/4" 18-3/4" 18-3/4" 18-3/4" 16-1/4" 16-1/4"
Front to Back
Approximate . 99 99 90 90 76 76
Shipping Weight, lbs
User's Guide & Cookbook Included Included Included Included Included Included
Porcelain/Cast Iron Not Available Not Available Included Included Included Included
Cooking Grids (3 piece)
Cast Stainless Steel Included Included Accessory Accessory Accessory Accessory
Cooking Grids (3 piece) DPA101 DPA101 DPA102 DPA102
Warming Rack - Stainless Steel Included Included Included Included Included Included
Twin Stainless Steel 40,000 40,000 40,000 40,000 40,000 40,000
Bow-Tie Burners-BTU
Electronic Igniter Included Included Included Included Included Included
Drop-Down Side Shelf See Shelving See Shelving See Shelving See Shelving See Shelving See Shelving
Heat Indicator Included Included Included Included Included Included
Drip Shield - Stainless Steel Included Included Included Included Included Included
Adjustable Lid Stop - Included Included Included Included Included Included
Stainless Steel
Propane Hose & Regulator Included Not Available Included Not Available Included Not Available
Grill Cover See Grill Covers See Grill Covers See Grill Covers See Grill Cove rs See Grill Covers See Grill Cove rs
Charmaster™ Briquets Not Required Not Required Not Required Not Required Not Required Not Required
Flavor Screen - Included Included Included Included Included Included
Stainless Steel
Smoker Shutter - Included Included Accessory Accessory Not Not
Stainless Steel Stainless Steel Stainless Steel DPA100 DPA100 Available Available
All prices subject to change.
All dimensions and measurements are approximate.
Prices for Broilmaster propane models do not include 20 lb. propane tanks.
3
Super
Premium
SUPER PREMIUM & PREMIUMGASGRILLHEAD

PREMIUM GAS GRILL HEADS
P3BL P3BLN P4BL P4BLN
Suggested Retail Price $879.00 $861.00 $769.00 $743.00
Type of Gas Propane Propane
Includes Includes
Natural Natural Natural Natural
Conversion Kit Conversion Kit
Total Cooking Area 695 Sq. In. 695 Sq. In. 473 Sq. In. 473 Sq. In.
Direct Broiling Area 442 Sq. In. 442 Sq. In. 360 Sq. In. 360 Sq. In.
Warming Rack Area 253 Sq. In. 253 Sq. In. 113 Sq. In. 113 Sq. In.
Housing Width, 26-3/4" 26-3/4" 24" 24"
Left to Right
Housing Height, 19" 19" 19" 19"
Top to Bottom
Housing Depth, 18-3/4" 18-3/4" 16-1/4" 16-1/4"
Front to Back
Approximate 105 105 91 91
Shipping Weight, lbs.
User's Guide & Cookbook Included Included Included Included
Porcelain/Cast Iron Included Included Included Included
Cooking Grids (3 piece)
Cast Stainless Steel Accessory Accessory Accessory Accessory
Cooking Grids (3 piece) DPA101 DPA101 DPA102 DPA102
Warming Rack - Stainless Steel Included Included Included Included
Twin Stainless Steel 40,000 40,000 40,000 40,000
Bow-Tie Burners-BTU
Electronic Igniter Included Included Included Included
Drop-Down Side Shelf See Shelving See Shelving See Shelving See Shelving
Heat Indicator Included Included Included Included
Drip Shield - Stainless Steel Included Included Included Included
Adjustable Lid Stop - Included Included Included Included
Stainless Steel
Propane Hose and Regulator Included Not Available Included Not Available
Grill Cover See Grill Covers See Grill Covers See Grill Covers See Grill Covers
Charmaster™ Briquets Included Included Included Included
Flavor Screen - Accessory Accessory Accessory Accessory
Stainless Steel DPA103 DPA103 DPA104 DPA104
Smoker Shutter - Accessory Accessory Not Not
Stainless Steel DPA100 DPA100 Available Available
All prices subject to change.
All dimensions and measurements are approximate.
Prices for Broilmaster propane models do not include 20 lb. propane tanks.
PREMIUMGASGRILLHEAD
4

Suggested Retail Price $699.00 $679.00 $739.00 $719.00 $799.00 $779.00
Type of Gas Propane
Includes
Natural
Conversion Kit
Natural
Propane
Includes
Natural
Conversion Kit
Natural
Propane
Includes
Natural
Conversion Kit
Natural
Total Cooking Area 601 Sq. In. 601 Sq. In. 695 Sq. In. 695 Sq. In. 695 Sq. In. 695 Sq. In.
Direct Broiling Area 442 Sq. In. 442 Sq. In. 442 Sq. In. 442 Sq. In. 442 Sq. In. 442 Sq. In.
Warming Rack Area 159 Sq. In. 159 Sq. In. 253 Sq. In. 253 Sq. In. 253 Sq. In. 253 Sq. In.
Housing Width,
Left to Right
26-3/4” 26-3/4” 26-3/4” 26-3/4” 26-3/4” 26-3/4”
Housing Height,
Top to Bottom
19” 19” 19” 19” 19” 19”
Housing Depth,
Front to Back
18-3/4” 18-3/4” 18-3/4” 18-3/4” 18-3/4” 18-3/4”
Approximate
Shipping Weight, lbs.
105 105 105 105 105 105
User’s Guide & Cookbook Included Included Included Included Included Included
Porcelain/Cast Iron
Cooking Grids (2 piece)
Included Included Included Included Included Included
Cast Stainless Steel
Cooking Grids (3 piece)
Accessory
DPA101
Accessory
DPA101
Accessory
DPA101
Accessory
DPA101
Accessory
DPA101
Accessory
DPA101
Control Panel Black Black Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Warming Rack Chrome Chrome Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Twin Stainless Steel
Burners - Btu
36,000 40,000 36,000 40,000 36,000 40,000
Electronic Igniter Included Included Included Included Included Included
Drop-Down Side Shelf See Shelving See Shelving See Shelving See Shelving See Shelving See Shelving
Heat Indicator Included Included Included Included Included Included
Drip Shield - Stainless Steel Included Included Included Included Included Included
Adjustable Lid Stop -
Stainless Steel
Accessory
DPA106
Accessory
DPA106 Included Included Included Included
Propane Hose & Regulator Included NA Included NA Included NA
Grill Cover See Grill Covers See Grill Covers See Grill Covers See Grill Covers See Grill Covers See Grill Covers
Charmaster™ Briquets Included Included Included Included NA NA
Flavor Screen -
Stainless Steel
Accessory
DPA103
Accessory
DPA 103
Accessory
DPA103
Accessory
DPA103 Included Included
Smoker Shutter -
Stainless Steel
Accessory
DPA100
Accessory
DPA100
Accessory
DPA100
Accessory
DPA100
Accessory
DPA100
Accessory
DPA100
5
DELUXEGASGRILLS
T3GasGrillshown
withPC2CartT3 T3C T3CF
T3N T3CN T3CFN

PC2CART DC2CART
Suggested Retail Price $336.00 $225.00
Material Stainless Steel Painted Steel
ShippingWeight,lbs. 34 34
Fits P Series P Series
T Series T Series
SideShelves See Shelving - Page 8 See Shelving - Page 8
12'Hose/QuickDisconnect Not Included Not Included
SSP48 SSPB26 BPB26 BP48
Suggested Retail Price $158.00 $204.00 $188.00 $115.00
Material Stainless Steel Stainless Steel Post Painted Steel Post Painted Steel
w/Cast Iron Base w/Cast Iron Base
ShippingWeight,lbs. 13 33 33 13
Fits P Series P Series P Series P Series
T Series T Series T Series T Series
SideShelves See Shelving Page 8 See Shelving Page 8 See Shelving Page 8 See Shelving Page 8
12'Hose/QuickDisconnect Not Included Not Included Not Included Not Included
GardenCart GC3 GC4
Suggested Retail Price $245.00 $245.00
Material Painted Steel Painted Steel
ShippingWeight,lbs. 25 24
Fits P3 Series P4 Series
SideShelfIncludes 1 SKFPBLACK Includes 1 SKFPBLACK
LOWER MOUNTINGS
Seepage 9 forPostandCartconversionkitstofitT3tooldstylepostsandcarts.
6

FKBLACK FKCHAR FKTAU FKSS FKWOOD
(Black) (Charcoal) (Taupe) (Stainless Steel) (Wood)
Front Shelf Front Shelf Front Shelf Front Shelf Front Shelf
Suggested Retail Price $62.00 $62.00 $62.00 $110.00 $56.00
Material Drop-Down Drop-Down Drop-Down Drop-Down Drop-Down
(Bracket) Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel
(Shelf) Composite Composite Composite Stainless Steel Wood
Width 27-1/2" 27-1/2" 27-1/2" 24" 24"
Depth 10-1/2" 10-1/2" 10-1/2" 9" 9"
Shipping77 7 77
Weight,lbs.
SKCHAR SKTAU SKSS SKWOOD
(Charcoal) (Taupe) (Stainless Steel) (Wood)
Side Shelf Side Shelf Side Shelf Side Shelf
Suggested Retail Price $77.00 $65.00 $122.00 $53.00
Material (Bracket) Stationary Stainless Steel Stationary Stainless Steel Stationary Stainless Steel Stationary Stainless Steel
(Shelf) Composite Composite Stainless Steel Wood
Width 12" 12" 13" 9-1/2"
Depth 14" 14" 12" 11-1/4"
Shipping55 5 5
Weight,lbs.
SKBLACK SKFPBLACK SKFBLACK
replaces SKGRAY replaces SKFPGRAY replaces SKFGRAY DPSBSS
(Black) (Black) (Black) (Stainless Steel)
Side Shelf Side Shelf Side Shelf Side Burner
Suggested Retail Price $85.00 $90.00 $115.00 $299.00
Material (Bracket) Stationary Stainless Steel Drop-Down Painted Drop-Down Stainless Steel Stainless Steel
(Shelf) Solid Surface Solid Surface Solid Surface
Width 16" 16" 16" 12-1/2"
Depth 21" 21" 21" 17"
Shipping88 815
Weight,lbs.
SHELVING(FITSALLCURRENTBROILMASTERMODELS)
7

GRILL TOOLS SUGGESTED
RETAIL PRICE
DPA20 Professional Quality 4-pc. BBQ Set with Spatula,Tong, Fork, and Brush $55.00
with Broilmaster Logo Burned into Rosewood Handles
DPA21 Deluxe Brass Bristle Brush — a must for Porcelain. $12.00
DPA27 Cast Iron Smoking Box. Use with all Smoking Chips. $20.00
STTP-1 Digital Remote Temperature Probe and Timer $49.00
ROTISSERIEUNITS/BASKETS/GRIDDLES
DPA11 Hugga-Rack Rotisserie with Flat Basket for P3/P4 and T3 (B070425) $189.00
DPA51 Heavy Duty Standard Rotisserie for P3/P4 and T3 (B070425) $102.00
GR3 Griddle for size 3 grill head $73.00
GR4 Griddle for size 4 grill head $56.00
GRILLCOVERS
DPA110 Full Length Broilmaster Premium Grill Cover for P and T Series grill $52.00
with Two Cup-Holder Side Shelves. Available in Black only.
DPA109 Full Length Broilmaster Premium Grill Cover for P and T Series grill $47.00
with One Cup-Holder Side Shelf. Available in Black only.
DPA8 Full Length Broilmaster Premium Grill Cover for P and T Series grill $42.00
without Side Shelves. Available in Black only.
DPA45 Built-In Kit Premium Grill Cover for P3 Head Built into Broilmaster $47.00
BIK Surround Covers Head and Control Panel. Available in Black only.
8

BROILMASTERACCESSORIES SUGGESTED
RETAIL PRICE
DPA34 Replacement Charmaster™ Briquets $19.00
DPP100 Stainless Steel Base Shroud (fits SSPB26 and BPB26) $264.00
DPA100 Smoker Shutter for size 3 grill head $122.00
DPP11 Set of Porcelainized Cast Iron Cooking Grids for P3 (Set of 3) $142.00
DPP12 Set of Porcelainized Cast Iron Cooking Grids for P4 (Set of 3) $120.00
DPA101 Cast Stainless Steel Cooking Grids for size 3 grill head (set of 3) $257.00
DPA102 Cast Stainless Steel Cooking Grids for size 4 grill head (set of 3) $213.00
DPA103 Flavor Screen for P3,T3 and D3 grill head $79.00
DPA104 Flavor Screen for size 4 grill head $71.00
DPA18BL 12 oz. High Temperature Touch-Up Paint-Black $17.00
DPP101 U3TS44R Stainless Steel Burner fits P3 & D3 $106.00
DPP102 200TS44LP Stainless Steel Burner fits P4 & D4 $91.00
DPP6SS Stainless Steel Heat Shield/Wind Deflector (fits P3 and D3) $25.00
DPP18C Heavy-Duty Chrome Plated Heat Indicator $12.00
DPP18SS Stainless Heat Indicator $15.00
DPP19 "P"/"D" Series Replacement Rotary Piezo Igniter complete with Collector Box $34.00
DPP20 Electronic Igniter Kit $40.00
DPA105 Natural Gas Regulator Kit $20.00
DPA106 Adjustable Lid Stop $24.00
DPA107 Grid Lifter Kit $16.00
NG12 12' Natural Gas Hose with Quick Connect $92.00
FC4 Flavor Catalyst fits P4 & D4 $174.00
POST AND CART CONVERSIONKIT
(AllowsT3headtofitPre-2007mountings)
B101026 Painted Control Housing for DC2 Carts $10.00
B101027 Stainless Steel Control Housing for PC2 Carts $30.00
B101076 Painted Control Housing for Painted Posts (26 & 48-inch) $10.00
B101060 Stainless Steel Control Housing for Stainless Steel Post (26 & 48-inch) $30.00
9

BRM-743 Rev. A 2/07
Registered Trademarks of
Empire Comfort Systems Inc.
918 Freeburg Avenue
Belleville, IL 62222
Phone [phone] or 1-800-851-3153
Fax [phone] or 1-800-443-8648
www.broilmaster.com
