Broil King T3-1 User manual

Page 1B101051-0-1106
Premium "T" Gas Grill
Owner’s Manual
T3-1, T3N-1 Models
T3C-1, T3CN-1 Models
T3CF-1, T3CFN-1 Models

Page 2 B101051-0-1106
WARNING
Reference this manual for proper installation and maintenance instructions. Improper installa-
tion, adjustment, alteration, service or maintenance can cause personal injury or property dam-
age. For assistance or additional information consult a qualified installer, service agency or the
gas supplier.
WARNING
Broilmaster® Gas Grills must ONLY use propane cylinders equipped with an Overfill Protection
Device (OPD). Use only a reputable propane dealer when exchanging or filling cylinders. An
overfilled or improperly filled propane cylinder can be dangerous.
!
DANGER
IF YOU SMELL GAS:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open the grill lid.
4. If odor continues, keep away from the appliance and immediately
call your gas supplier or fire department.
CAUTION:
Parts may have sharp edges. Wear leather work gloves and handle parts carefully during the
unpacking, assembly and installation.
!
WARNING
1. Do not store or use gasoline or other flammable liquids or vapors in the vicinity of this or any
other appliance.
2. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
IMPORTANT
This manual should be read thoroughly by the person installing the grill and all persons who will
use and maintain the grill. The installer should be sure the manual is left in the possession of the
user. The user should retain this manual for future reference when using or cleaning the grill and
to properly identify any repair parts that may be required.

Page 3B101051-0-1106
Congratulations!
Welcome to the beauty, durability, and prestige of a Premium Gas Grill by
Broilmaster®. With award-winning excellence built into every feature and du-
rability that surpasses other Premium gas grills, Broilmaster has manufactured
the ultimate gas grill for discriminating outdoor chefs for over 30 years.
At Broilmaster, we continually strive to enhance the performance and quality
of our products for your grilling enjoyment. Every effort will be made to en-
sure that Broilmaster continues to be your choice as the Premium grill of the
future.
Whether you are at the lake or in the privacy of your own backyard, the Broil-
master Premium Gas Grill performs far beyond the ordinary and is designed to
provide your family with years of outdoor cooking pleasure.
Thank You!

Page 4 B101051-0-1106
Model No. Dealer
Serial No. Dealer Phone No.
Gas Type: Propane Natural Date of Purchase
Your Broilmaster Premium Gas Grill is identified by model number, serial number, and gas type. This
information is provided on a product identification label located on the grill’s control panel. For your
convenience, complete this section for future reference when contacting your dealer.
Hardware Package ............................................................................................................................................... 5
Parts Diagram .......................................................................................................................................................6
Parts List .................................................................................................................................................................7
Grill Assembly ...............................................................................................................................................8-12
Propane Gas Grills ........................................................................................................................................13-15
Gas Conversion ..................................................................................................................................................16
Natural Gas Grills ..............................................................................................................................................17
Operation- Propane & Natural Grills ............................................................................................................18-19
Maintenance ...........................................................................................................................................................20
Troubleshooting ....................................................................................................................................................21
Warranty ................................................................................................................................................................22
Notes ......................................................................................................................................................................23
Congratulations!
You have chosen the finest grill for your outdoor cooking pleasure. Please take time to read this entire manual
before assembling your Premium Broilmaster gas grill.
TABLE OF CONTENTS

Page 5B101051-0-1106
HARDWARE PACKAGE
B069743 SPACER, IGNITOR
B069747 LUG, IGNITOR GROUND
B073097 FOAM GRIP
B101048 WIRE, IGNITOR GROUND
B076529 BATTERY, AA
R3918 KNOB
B072217 SCREW 1/4-20 X 3/4 PH TRUSS HEAD SS
B073978 SCREW #10-24 X 1 PHILLIPS TRUSS STAINLESS

Page 6 B101051-0-1106
All repair part orders should be placed through your local Broilmaster dealer. To locate a dealer in your area,
contact Broilmaster Customer Service at 800-851-3153 • www.broilmaster.com. To ensure prompt and accurate
service, please provide the following information when placing a repair part order: Model Number, Serial Number,
Part Name, Part Number, and Quantity of parts needed.
PARTS DIAGRAM
5
4
3
2
1
5
6
7
8
11
9
15 12
10 13
14
16
17
19
18
24
23
20
21
22

Page 7B101051-0-1106
PARTS LIST
Index
Number
Description T3
Part
Number
T3C
Part
Number
T3CF
Part
Number
T3N
Part
Number
T3CN
Part
Number
T3CFN
Part
Number
1 GRILL BODY TOP - BLACK B101039 B101039 B101039 B101039 B101039 B101039
2 HEAT INDICATOR (STAINLESS) DPP18SS DPP18SS DPP18SS DPP18SS DPP18SS DPP18SS
3 LID HANDLE (STAINLESS) B070486 B070486 B070486 B070486 B070486 B070486
4 FOAM GRIP B073097 B073097 B073097 B073097 B073097 B073097
5 RETRACT-A-RACK B100594 B072695 B072695 B100594 B072695 B072695
6 COOKING GRID (SET OF 2) DPP103 DPP103 DPP103 DPP103 DPP103 DPP103
6 COOKING GRID (SINGLE) B101053 B101053 B101053 B101053 B101053 B101053
7 BRIQUET RACK B101061 B101061 N/A B101061 B101061 N/A
8 BURNER DPP104 DPP104 DPP104 DPP104 DPP104 DPP104
9 FLAVOR SCREEN N/A N/A DPA103 N/A N/A DPA103
10 COLLECTOR BOX ASSEMBLY B101031 B101031 B101031 B101031 B101031 B101031
11 IGNITOR SPACER B069743 B069743 B069743 B069743 B069743 B069743
12 GROUND LUG B069747 B069747 B069747 B069747 B069747 B069747
13 RADIATION SHIELD DPP106 DPP106 DPP106 DPP106 DPP106 DPP106
14 GRILL BODY BOTTOM - BLACK B101044 B101044 B101044 B101044 B101044 B101044
15 LID STOP KIT N/A DPA106 DPA106 N/A DPA106 DPA106
16 VALVE SHIELD B101046 B101046 B101046 B101046 B101046 B101046
17 VALVE ASSEMBLY (NO ORIFICE) B101042 B101042 B101042 B101042 B101042 B101042
18 MANIFOLD AND VALVE ASSEMBLY B101040 B101040 B101040 B101112 B101112 B101112
19 ELECTRONIC IGNITOR B072218 B072218 B072218 B072218 B072218 B072218
20 CONTROL PANEL ASSEMBLY B101033 B101066 B101066 B101033 B101066 B101066
21 CONTROL PANEL LABEL B101028 B101028 B101028 B101028 B101028 B101028
22 VALVE KNOB R3918 R3918 R3918 R3918 R3918 R3918
23 HOSE AND LP REGULATOR B069756 B069756 B069756 N/A N/A N/A
24 PIN, SHELF B073963 B073963 B073963 B073963 B073963 B073963
N/S CHAR-MASTER BRIQUETS B058122 B058122 N/A B058122 B058122 N/A
N/S HARDWARE PACK B101047 B101047 B101047 B101047 B101047 B101047
N/S IGNITOR GROUND WIRE B101048 B101048 B101048 B101048 B101048 B101048
N/S BRIDGE PIN B057805 B057805 B057805 B057805 B057805 B057805
N/S HINGE PIN B057804 B057804 B057804 B057804 B057804 B057804
N/S NATURAL GAS CONVERSION KIT B101062 B101062 B101062 N/A N/A N/A
N/S ORIFICE, LP #55 B101111 B101111 B101111 N/A N/A N/A
N/S ORIFICE, NAT #49 N/A N/A N/A B101063 B101063 B101063

Page 8 B101051-0-1106
Recommended Tools
These items are recommended for the assembly of your
grill:
• Phillips screwdriver
• Adjustable wrench set
• Socket set
• Soapy water solution (to test for leaks)
• Liquid soap (for foam grip)
Grill Mountings
Assemble your base option before assembling your Broil-
master grill head.
Refer to the Broilmaster Cart, Base, and Post instructions
provided with each accessory for assembly, installation, and
mounting procedures.
Before You Begin
All Broilmaster grills require some assembly and installation.
Follow all instructions unless noted to apply only to other
specific models.
If you purchased an accessory with your Broilmaster, follow
the instructions provided with the accessory for assembly
and installation. If an instruction refers to a step that is not
required for your grill model, please continue to the next
step.
In each step, parts are identified with “Key” numbers. Key
numbers appear in parenthesis after a part name is mentioned
for the first time in the instructions. You can reference each
part by its key number on the Parts List if you need help in
identifying a part.
Compare the parts found in the shipping container to the
parts list provided. If any parts are missing contact your
Broilmaster dealer before beginning assembly.
CAUTION: FOR YOUR SAFETY
Parts may have sharp edges. Wear leather work
gloves and handle parts carefully during the unpack-
ing, assembly and installation.
GRILL ASSEMBLY

Page 9B101051-0-1106
1. Mount grill onto cart, post or base per the mounting in-
structions.
2. Place radiation shield (13) (flange side up) onto four
raised bosses located on the interior bottom of the grill.
Secure with four 1/4-20 x 3/4 screws. See Figure 1.
3. Place burners (8) into grill and insert burner tubes over
orifice fittings on valve (17). Secure each burner with
one (1) 1/4-20 x 3/4 phillips screw. See Figures 2, 3 and
4.
GRILL ASSEMBLY
Figure 1
Figure 2
Figure 3
Figure 4

Page 10 B101051-0-1106
4. Slide ignitor spacers (11) onto collector box assem-
blies (10) and secure with nuts. See Figure 5.
Attention: Do not cut or damage ignitor wires.
5. Insert collector box assemblies into holes adjacent to
burners. See Figure 6.
6. Slide ground lugs (12) over ignitor wires and onto col-
lector box assemblies. Slide nuts over ignitor wires and
secure collector box assemblies to grill. See Figure 7.
7. Attach ignitor ground wire ends onto ground lugs. See
Figure 8.
8. Attach ignitor wires to terminals on the ignitor. See Fig-
ure 9.
GRILL ASSEMBLY
Figure 5
Figure 6
Figure 7
Figure 8
Figure 9
