brondell SimpleSpa Eco SSE-15 User manual

SimpleSpa Eco
Bidet Attachment with
Adjustable Single Nozzle
Models: SSE15
SSE25
User Manual

2
PRODUCT INFORMATION
3Product Features
4Product Dimensions
5Product Parts
PRODUCT INSTALLATION
6Before Installation
7Installation
10 Installing the Bidet Attachment
PRODUCT OPERATION
12 Using the SimpleSpa Eco
TECHNICAL INFORMATION
14 Maintenance
15 Product Speciications
16 Warranty
17 Contact Information
TRANSLATIONS
18 Espanol
34 Francais
This manual contains important safety
information. Before operating your
SimpleSpa Eco, please read this manual
thoroughly and retain it for future
reference.
SSE15SSE25 OWNER’S MANUAL
Contents

3
PRODUCT INFORMATION
Product Features
SSE15  SSE25 FEATURES
Made with 65% recycled plastic
Side-arm control panel with aluminum knobs
and easy nozzle adjuster
Adjustable nozzle position for front and rear
washes
Self-cleaning, retractable nozzle
Ambient temperature bidet wash
Adjustable water pressure
All-metal ⅞” T-Valve
Braided-metal cold water hose
No electricity or batteries required
Simple, DIY installation—universal,
adjustable it
All accessories included for standard
installation
1-year limited warranty
SSE25 DUAL TEMPERATURE
FEATURES ONLY
Fully adjustable water temperature and
pressure
High-temperature hot water
lex tubing
All-metal ⅜” T-Valve

4
PRODUCT INFORMATION
Product Dimensions
5.04” /
12.8 cm
2.72” /
6.9 cm
9.69” / 24.6 cm
12.68” / 32.2 cm
Deepest point on
control:
2.49”/ 6.32 cm
Thickness:
0.33” / 0.85 cm
7.52” /
19.1 cm

5
PRODUCT INFORMATION
Product Parts
1. Bidet attachment
2. Adjustable mounting brackets
3. Cold water T-Valve connector
(⅞” x ⅞” x ⅜”)
4. Cold water braided-metal hose
Hose length: 23.62”
5. Large rubber washer (2)
6. White rubber mounting washer (2)
SSE25 Dual Temperature Only
1. Hot water ⅜” T-valve with ¼” pressure
connector and pressure cap
2. Hot water tubing pressure connector
with pressure cap
3. ¼” hot water lex tubing
Hose length: 78.74”
4. Small rubber washers (2)
5. Hot water supply cap
21 3 54
21 3 54 6

6
IMPORTANT:
Please be advised that the provided cold
water T-Valve should be installed at the
ill valve under the toilet tank. Do not
disconnect from water supply valve on
the wall.
For SSE-25 Dual Temperature Model Only
Check the size of the hot water supply
connection (most likely under the
sink/washbasin). This should be a ⅜”
connection to properly it and install the
enclosed T-Valve.
Check water supply line
Check the water supply line that connects
the toilet tank ill valve to the water shut-o
valve at the wall.
• If it is a rigid pipe, you will need to
purchase a lexible water supply hose
to replace it before installing the
SimpleSpa Eco.
• The length of the hose may vary, and
the top connection size should be ⅞”
ballcock to connect to the T-Valve that
you will install under the toilet tank.
• The bottom connection will vary
(most common are ⅜” and ½” female
compression).
PRODUCT INSTALLATION
Before Installation
NOTE: The hot water T-Valve will be
installed at the hot water supply under
your bathroom sink. If you do not have
access to the ill valve under the toilet
tank, visit us at www.brondell.com
or contact us at 1-888-542-3355 for
further assistance.
NOTE: If the connection is a ½”
connection, you will need to
purchase the following reducing
adapter available online and at many
plumbing hardware stores: Reducing
Adapter, ½” Female NPT x ⅜” Male
Compression
CAUTION:Only use the hoses,
T-Valves, and components that are
included with your product as they
have been speciically designed and
tested for safe use with this Bidet
Attachment. Please note that use
of unauthorized or non-Brondell
approved parts could result in injury,
leaking, or damages that Brondell will
not be held liable for.

7
Pease read these instructions carefully
before installing your SimpleSpa Eco.
Failure to do so could result in looding,
leaking or damage to the product.
1. Existing toilet seat removal
a. Lift hinge covers and use lathead or
Phillips-head screwdriver to remove
the mounting bolts. Alternatively, you
may need to loosen the mounting
bolts underneath the seat.
b. Remove the toilet seat, and set the seat,
mounting bolts, and hardware aside.
2. Turn o water supply valve and lush
toilet
a. Turn o water supply valve to stop the
low of water.
b. Flush toilet and hold down handle to
completely empty tank.
c. Disconnect water supply hose from
toilet tank; do not disconnect from the
water supply valve.
3. Connect cold water T-Valve to the toilet
tank ill valve
a. Install the ⅞” cold water T-Valve
with one or both of the large rubber
washers to the incoming water
connection on the bottom of your
toilet tank.
b. Connect the cold water supply line
coming from the wall to the bottom of
the T-Valve.
4. Connect bidet hose to T-Valve
Connect one end of the braided-metal cold
water bidet hose to the remaining open
side of the installed T-Valve.
FOR AMBIENT TEMPERATURE MODEL,
STOP HERE AND PROCEED TO
“INSTALLING THE BIDET ATTACHMENT”
ON PAGE 10. FOR DUAL TEMPERATURE
MODEL, CONTINUE.
PRODUCT INSTALLATION
Installation
Step 3
Step 2c
Step 4
Step 1b

8
5. Install the hot water supply cap
a. If you are only connecting the cold
water supply, then you must install the
hot water supply cap (provided - see
Page 5) over the hot water connection
on your bidet (see diagram).
b. After installing hot water cap, proceed
to “Installing the Bidet Attachment” on
Page 10. If you wish to connect your
hot water supply, proceed to the next
steps.
6. Disconnect the hot water supply
a. Locate the hot water supply line
in your bathroom under your sink/
washbasin and turn the water supply
valve all the way o.
b. Drain the hot water line by turning the
sink tap on the hot setting until no
more water comes out.
c. Disconnect hot water supply hose to
sink from shut-o valve. You may have
to use a ⅜” compatible wrench or a
similar tool (not supplied).
7. Install the hot water ⅜” T-Valve and the
small rubber washers as needed onto the
hot water shut-o valve under the sink
8. Reconnect hot water supply line to open
end (top) of T-Valve
9. If not already removed, unscrew the
pressure cap covering the pressure
connector on the T-Valve
a. Slide the pressure cap over the open
end of the of hot water lex tubing
with the inside threads facing towards
the open end.
b. Push the hot water lex tubing over the
pressure connector.
Step 5a
PRODUCT INSTALLATION
Dual Temperature Model Installation
IMPORTANT: Failure to connect or
cap the hot water supply will result in
leaking during use.
NOTE: There may be some residual
water in the hose; use a small container
or towel to catch any residual water.
Step 6c
Step 9a
Steps 7,8

9
c. Slide the pressure cap down until the
cap meets the pressure connector.
d. Screw the cap onto the T-Valve until
secure and tight.
IMPORTANT:Be sure to slide the hot
water lex tubing over the pressure
connector until the tubing slides past
the “lip” of the pressure connector and
it cannot go any further.
CAUTION:Do not overtighten the
pressure cap. You will risk damaging
the tubing.
Step 9b
Step 9c
Step 9d
PRODUCT INSTALLATION
Installation (Cont’d)

10
PRODUCT INSTALLATION
Installing the Bidet Attachment
1. Install adjustable mounting brackets into
the bidet attachment
Place circular mounting brackets into
the circular openings of the bidet
attachment.
2. Install bidet attachment on toilet
a. Place the bidet attachment on the
toilet with the nozzle close to the
back of the toilet, leaving a slight gap
between the toilet and the nozzles.
This will vary by toilet.
b. Make sure the adjustable brackets line
up with the holes in the toilet ixture.
You may need to rotate the adjustable
brackets accordingly to line up properly.
c. Add large white mounting washers if
needed for a better it.
d. Replace the toilet seat on top of the
bidet attachment and secure using
original toilet seat hardware. Make
sure to tighten so that the bidet
attachment and seat do not move.
e. Ensure the bidet control knob is in
the off position to prevent water
from accidently spraying out of the
toilet bowl.
3. Connect bidet hose to bidet attachment
Connect the open end of bidet hose
to the cold connection under the bidet
attachment.
4. Connect hot water tube to bidet
attachment (SSE-25 dual temperature
model only)
a. Take the hot water tubing pressure
connector and remove the pressure
cap.
b. Slide the pressure cap over the open
end of the of hot water lex tubing
with the inside threads facing towards
the open end.
Step 1
Step 3
Step 2d Step 4b
Step 2b
NOTE:If you have already installed the
hot water supply cap over the hot water
supply on your SSE-25 Dual Temperature
model, skip to Step 5 on Page 11.
Otherwise, proceed to the next steps.
