PARTS REFERENCE LIST
MODEL: PT-9400 (For Europe)

NOTES FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it needs mentioning the following items:
(1) Code
(2) Q'ty
(3) Description
(4) Symbol (PCB No., Revision , and Parts location mounted on the PCB.)
Note : No orders without Parts Code or Tool No. can be accepted.
[ Example ]
(4) (1) (2) (3)
REF. NO. SYMBOL CODE Q’TY DESCRIPTION REMARKS
Revision No. : marked on the printed circuit board.
B48J300 - 101 A
Design change indication
Specification No.
Pattern alteration No.
Circuit board No.
2. Design-changed parts:
When the parts are changed, any one of the following symbols is indicated in the REMARKS column.
CHNG#A : compatible between old and new
CHNG#B : replaceable from old to new
CHNG#D : incompatible
ADD : newly established
3. The original of this list was made based on the information available in Nov., '98.
4. Parts are subject to change in design without prior notice.

CONTENTS
1.PRINT MECHANISM....................................................................1
2.COVERS......................................................................................3
3.KEYBOARD.................................................................................5
4.DETECTORS...............................................................................5
5.MAIN PCB ASSEMBLY................................................................7
6.POWER SUPPLY PCB................................................................9
7.INTERFACE PCB........................................................................9
8.LCD PCB....................................................................................11
9.ATTACHMENTS..........................................................................11
10.PRINTED MATTER......................................................................13
11.PACKING MATERIALS................................................................13

-1-
MODEL PT-9400 5V2-701-045
1 . PRINT MECHANISM PT99033

-2-
1 . PRINT MECHANISM PT2000026
REF.NO. CODE Q'TY DESCRIPTION REMARKS
1
LA2073001
1
FRAME PRO ASSY
2
Z26596001
1
TAPE FEED MOTOR, BP242516M12-PP (OLD : Refer to the T/I #. PT2000020)
2
Z26599001
1
TAPE FEED MOTOR, BP242516M12-PP (NEW : From APR. 2000. Refer to the T/I #.
PT2000020)
3
UB3848001
2
SCREW, PAN M2.6X3.5
4
LA0014001
1
ROLLER HOLDER ASSY (SP) (OLD : Refer to the T/I #. PT2000020)
4
LA2031001
1
ROLLER HOLDER ASSY (SP) (NEW : From APR. 2000. Refer to the T/I #. PT2000020)
5
UT0895001
1
ROLLER HOLDER SHAFT
6
048025346
1
RETAINING RING, E2.5
7
UT0591001
1
HEAD ASSY KSH384 BW (SP) (OLD : Refer to the T/I #. PT2000020)
7
LA2071001
1
HEAD ASSY KSH384 BW (SP) (NEW : From APR. 2000. Refer to the T/I #. PT2000020)
8
UT0901001
1
ROLLER HOLDER RELEASE SPRING
9
UT0239000
1
RELEASE LEVER
10
UT0240000
1
RELEASE ROD
11
UB5507000
1
RELEASE ROD ROLLER
12
048025346
1
RETAINING RING, E2.5
13
UT1549001
1
RELEASE LEVER SPRING PRO
14
0A4301005
2
SCREW, PAN (S/P WASHER) M3X10
15
UT0254000
2
CUTTER DOUBLE GEAR
16
UT1434001
1
CUTTER MOVING GEAR PRO
17
UB3733001
1
WASHER 2.6
18
UT1436001
1
FEEDING FORK SUB ASSY
19
048020346
1
RETAINING RING, E2
20
UT0256001
1
SPRING
21
UT1439001
1
ACTUATOR
22
UT1440001
1
HALF CUTTER FRAME PRO ASSY
23
060300516
3
SCREW, BIND M3X5
24
LA4064001
1
CUTTER ASSY (SP) CHNG#A
25
UT1449001
1
HALF CUTTER PRO ASSY
26
UT0932001
1
HALF SPACER
27
0A4401205
2
SCREW, PAN (S/P WASHER) M4X12
28
UT1452001
1
EJECT UNIT PRO ASSY
29
UT1461001
1
EJECT CONNECTING ROD
30
UT1462001
1
EJECT FIXED ROLLER
31
UT1463001
1
EJECT FIXED ROLLER HOLDER
32
060300516
1
SCREW, BIND M3X5
33
UT0961001
1
FULL CUTTER SENSOR ASSY
34
UT0855001
1
SCREW, PAN M1.7X6
35
UT1466001
1
FULL CUTTER SENSOR PRO ASSY
36
UT0855001
1
SCREW, PAN M1.7X6
37
UT1468001
1
HALF CUTTER MOTOR PRO ASSY
38
UB3848001
2
SCREW, PAN M2.6X3.5
39
UT1470001
1
FULL CUTTER MOTOR PRO ASSY
40
UB3848001
2
SCREW, PAN M2.6X3.5
41
UT1472001
1
SENSOR HOLDER PRO
42
060300516
1
SCREW, BIND M3X5
43
U62189000
1
PLATEN PROTECT PAD
44
048020346
1
RETAINING RING, E2
MODEL PT-9400 EUROPE 5V2-701-045

-3-
MODEL PT-9400 5V2-701-061
2 . COVERS PT99002

-4-
2 . COVERS PT2000049
REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS
1UT1473001 1BODY COVER PRO UK, GRAY1395
2UT1475001 1BOTTOM COVER PRO UK ASSY
3UT1477001 1CASSETTE COVER PRO UK
4UT1478001 1CASSETTE PRESSER PRO, GRAY1395
5UT1479001 1CASSETTE PRESSER SPRING
6UT1481001 1LCD PANEL PRO UK (GBR/IRL/NLD/CHE/DNK/SWE/BEL/FIN/NOR/ZAF/ESP) CHNG
6UT1482001 1LCD PANEL PRO GE (DEU)
6UT1483001 1LCD PANEL PRO FR (FRA)
7UT1226001 1LIGHT PLATE ASSY
8UT1484001 1LCD HOLDER
9085270815 4TAPTITE, BIND B M2.6X8
10 UT1485001 1LOCK ARM
11 UT1486001 1LOCK ARM RETURN SPRING
12 085270815 1TAPTITE, BIND B M2.6X8
13 UT1487001 1ARM GUIDE
14 UT1504001 1RELEASE BUTTON US, GRAY1395
15 UT1489001 1RELEASE BUTTON RETURN SPRING
16 UT1505001 1ON/OFF KEY US, ORANGE3159
17 085270815 2TAPTITE, BIND B M2.6X8
18 UT1506001 1PRINT KEY US, BLUE6189
(GBR/IRL/NLD/CHE/DNK/SWE/BEL/FIN/NOR/ZAF/ESP) CHNG
18 UT1490001 1PRINT KEY GE, BLUE6189 (DEU)
18 UT1491001 1PRINT KEY FR, BLUE6189 (FRA)
19 085270815 2TAPTITE, BIND B M2.6X8
20 UT1492001 1COVER FRAME
21 U05404003 2TAPTITE, BIND B M3X8
22 060300516 4SCREW, BIND M3X5
23 UT1493001 1POWER SUPPLY COVER
24 UT1494001 1SHIELD PLATE D
25 U05404003 2TAPTITE, BIND B M3X8
26 U05404003 4TAPTITE, BIND B M3X8
27 084311016 2SCREW, FLAT B M3X10
28 0A5400805 1SCREW, PAN (S/P WASHER) M4X8
29 0A5400805 1SCREW, PAN (S/P WASHER) M4X8
30 U05404003 4TAPTITE, BIND B M3X8
31 U05404003 8TAPTITE, BIND B M3X8
32 U05404003 2TAPTITE, BIND B M3X8
33 UT1495001 1SHEET A
34 UT0267001 1LETTERING STICK TZ36
35 UB4431001 2LOWER FOOT
36 A UT0578001 1TAPE CAUTION LABEL PP EC
37 UT0850000 1WIRE SADDLE WS-1NS
38 UN4594000 1GROUND PLATE 350
39 060300516 1SCREW, BIND M3X5
40 085270815 2TAPTITE, BIND B M2.6X8
41 LJ4421001 1MARKING LABEL N/S
42 UT0544001 1SHIELD SHEET
MODEL PT-9400 EU 5V2-701-061

-5-
MODEL PT-9400 5V2-701-100
3 . KEYBOARD
MODEL PT-9400 5V2-701-003
4 . DETECTORS

-6-
3 . KEYBOARD
REF.NO. CODE Q'TY DESCRIPTION REMARKS
1UT1508001 1KB UNIT UK (GBR/IRL/NLD/CHE/DEK/SWE/FIN/NOR/ZAF)
1UT1509001 1KB UNIT GE (DEU)
1UT1510001 1KB UNIT FR (FRA)
1UT1511001 1KB UNIT BG (BEL)
MODEL PT-9400 5V2-701-003
4 . DETECTORS
REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS
1B55L038-1 UT1513001 2SW PCB ASSY PRO
2B55L026-1 UT0545001 1SENSOR PCB ASSY PROPC (SP)
3B55L028-1 UT0546001 1TAPE END SENSOR ASSY (SP)
4UT0830001 1INLET ASSY PP
MODEL PT-9400 5V2-701-100

-7-
MODEL PT-9400 5V2-701-101
5 . MAIN PCB ASSEMBLY PT2000020

-8-
5 . MAIN PCB ASSEMBLY PT2000020
REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS
1-6 B55L029-3
UT0846001
1
MAIN PCB PRO ASSY (SP) (OLD : Refer to the T/I #. PT2000020)
1-6 B55L029-3
CODE LABEL 01
LA2069001
1
MAIN PCB PRO ASSY (SP) (NEW : From APR. 2000. Refer to the T/I #.
PT2000020) ADD
1 #4
UT1517000
1
MPU:MB91104
2 #5
UT0816000
1
GATE ARRAY:D65625GF115
3 #1
LA1457001
1
MASK ROM:UPD23C16000 (OLD : Refer to the T/I #. PT2000020)
3 #1
LA2030001
1
MASKROM:UPD23C16000(NEW:FromAPR.2000.RefertotheT/I#.
PT2000020) ADD
4 #3
UT0042000
1
SRAM:SRM2B257SLM
5 #2
UK3104000
1
DRAM:4260SOJ-80
6B1
UT1335000
1
LITHIUM BATTERY:CR2032HE4
MODEL PT-9400 EUROPE 5V2-701-101

-9-
MODEL PT-9400 5V2-701-104
6 . POWER SUPPLY PCB
MODEL PT-9400 5V2-701-102
7 . INTERFACE PCB

-10-
6 . POWER SUPPLY PCB
REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS
1MPW1433 UT0844001 1PS PCB ASSY, 230V (SP)
2UT0837001 1RELAY HARNESS ASSY
MODEL PT-9400 5V2-701-102
7 . INTERFACE PCB
REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS
1B55L037-1 UT0849001 1I/F PCB PRO ASSY (SP)
MODEL PT-9400 5V2-701-104

-11-
MODEL PT-9400 5V2-701-910
8 . LCD PCB
MODEL PT-9400 5V2-701-108
9 . ATTACHMENTS

-12-
8 . LCD PCB
REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS
1NCOG040
UT0847001
1
LCD ASSY (SP)
2B55L030-1
UT0848001
1
LED PCB PRO ASSY (SP)
MODEL PT-9400 EC 5V2-701-108
9 . ATTACHMENTS PT2001018
REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS
1A
UH1054001
1
AC CORD, BS (GBR/IRL)
1B
UH1052001
1
AC CORD, VDE (DEU/FRA/NLD/SWE/BEL/FIN/NOR/ESP)
1C
UH1053001
1
AC CORD, SEV (CHE)
1D
UK4094001
1
AC CORD, DEMKO (DNK)
1E
U34320001
1
AC CORD #4, BS (ZAF)
2
UN7385001
1
I/F CABLE WIN/MAC, SERIAL I/F
3
LA3716001
1
CD-ROM ASSY USB EC CHNG#D
MODEL PT-9400 EC 5V2-701-910

-13-
MODEL PT-9400 EU 5V2-701-930
10 . PRINTED MATTER PT2001018
MODEL PT-9400 EU 5V2-701-920
11 . PACKING MATERIAL PT2100018

-14-
10 . PRINTED MATTER PT2001018
REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS
1
UT1532001
1
USER'S MANUAL, GERMAN (DEU)
1
UT1533001
1
USER'S MANUAL, ENGLISH (GBR/IRL/FIN/ZAF/ESP)
1
UT1534001
1
USER'S MANUAL, FRENCH (FRA)
1
UT1535001
1
USER'S MANUAL, DUTCH (NLD/BEL)
1
UT1536001
1
USER'S MANUAL, CHE GERMAN (CHE)
1
UT1537001
1
USER'S MANUAL, CHE FRENCH (CHE/BEL)
1
UT1538001
1
USER'S MANUAL, DANISH (DNK)
1
UT1539001
1
USER'S MANUAL, SWEDISH (SWE)
1
UT1540001
1
USER'S MANUAL, NORWEGIAN (NOR)
2
UH3662001
1
WARRANTY CARD UK-A (GBR)
2
UH3663001
1
WARRANTY CARD UK-B (GBR)
2
UB3650001
1
WARRANTY CARD, FRENCH (FRA)
2
2
UB2565001
UH3851001
1
1
WARRANTY CARD, SWEDISH (SWE)
WARRANTY CARD, EUR
2
UU0605001
1
WARRANTY CARD, SPA (ESP)
3
UN4239001
1
TAPE CATALOG UK
4
UT1400001
1
UNPACKING INSTRUCTION 9400
5
LA1456001
1
INSERTION PT9400 EC
6
LA1667001
1
INSERTION PT9400 EC-2
7
LA2367001
1
INSERTION SHEET
8
LA4997001
1
EMC INSERTION SHEET, (EUROPE)
9
LA4945001
1
INSERTION PT E3. 1 ADD
MODEL PT-9400 EU 5V2-701-920
11 . PACKING MATERIALS PT2001018
REF.NO. CODE Q'TY DESCRIPTION REMARKS
1
UT0460001
1
CARTON PRO UK
2
UT0463000
1
BODY FRAME PRO
3
UT0461000
1
BODY HOLDER PRO
4
UT0467000
2
CORRUPAD L PRO
5
UT0468001
1
ACCESSORIES CARTON PRO ASSY
6
UT0458001
1
BAG, 500X640H (BODY)
7
UN5224001
1
BAG, 215X360H (INSTALLATION GUIDE)
8
UT0594001
1
BAG, 130X350 (AC CODE)
9
LA3939001
2
WINDOW 2000 LABEL ADD
MODEL PT-9400 EU 5V2-701-930
