Brother QL-1050 User manual

DK-11241 | 200 labels/roll
102mm x 152mm
Large Shipping
Label
QL-1050 QL-1050
Contact:
Brother International (Aust) Pty Ltd
Web-site: www.brother.com.au Technical Help Web-site:http://solutions.brother.com
NSW/ACT 7 Khartoum Rd. North Ryde NSW 2113 Phone: [phone] Fax: [phone]
VIC 1/733 Whitehorse Rd. Mont Albert VIC 3127 Phone: [phone] Fax: [phone]
QLD/NT 245 Riverside Drive.West End QLD 4101 Phone: [phone] Fax: [phone]
SA/TAS Unit 4, 13 King William Rd. Unley SA 5061 Phone: [phone] Fax: [phone]
WA 117 Great Eastern Highway. Belmont WA 6104 Phone: [phone] Fax: [phone]
All specifications subject to change without notice
Brother QL-1050
QL-1050
Professional PC Label Printer
QL-1050
QL-1050
QL-1050
Continuous Length Film
White tape DK-22212 62mm x15.24m
Yellow tape DK-22606 62mm x 15.24m
Clear tape DK-22113 62mm x 15.24m
White tape DK-22211 29mm x 15.24m
.
• Wide range of labels to choose from.
• Easy to load label rolls.
CONTENTS
• QL-1050 label printer
• 1 x DK11241 (40 large shipping labels (102mmx152mm)
• 1 x DK22205 (8m continuous paper tape roll (62mm x 8m)
• Label catch tray • USB cable • AC power cord
• CD-ROM (Software/Driver/User Guide) • Quick start guide
• Label supplies guide
Die-Cut Paper Labels
<Always at your side
44522174771
NO SMOKING
Continuous Length Paper Tape
White Tape DK-22214 12mm x 30.48m
White Tape DK-22210 29mm x 30.48m
White Tape DK-22205 62mm x 30.48m
White Tape DK-22243 102mm x 30.48m
White Tape DK-44205 Removable Adhesive (62mm x 30.48m)
Yellow Tape DK-44605 Removable Adhesive (62mm x 30.48m)
DDIIEE--CCUUTTPPAAPPEERRLLAABBEELLSS
■Standard Address Labels
DK-11201 400/roll
29mm x 90mm
■Large Address Labels
DK-11208 400/roll
38mm x 90mm
■Small Address Labels
DK-11209 800/roll
29mm x 62mm
■Shipping / Name Badge
Labels
DK-11202 300/roll
62mm x 100mm
■Large Shipping Labels
DK-11241 200/roll
102mm x 152mm
■Multi-Purpose/Return Labels
DK-11204 400/roll
17mm x 54mm
■Large Multi-Purpose Labels
DK-11240 600/roll
102mm x 51mm
■File Folder Labels
DK-11203 300/roll
17mm x 87mm
■CD/DVD Labels (Film)
DK-11207 100/roll
58mm x 58mm
■Round Labels
(24mm diameter)
DK-11218 1000/roll
■Round Labels
(12mm diameter)
DK-11219 1200/roll
DDuurraabblleeFFiillmmTTaappeess
■Medium Width Tape
DK-22211
Black Print on White
29mm x 15.24M
■Wide Tape
DK-22212
Black Print on White
62mm x 15.24M
■Wide Tape
DK-22606
Black Print on Yellow
62mm x 15.24M
■Wide Tape
DK-22113
Black Print on Clear
62mm x 15.24M
DDuurraabblleeWWhhiitteePPaappeerrTTaappeess
■Narrow Width Tape
DK-22214
12mm x 30.48M
■Medium Width Tape
DK-22210
29mm x 30.48M
■Wide Tape
DK-22205
62mm x 30.48M
■Extra Wide Tape
DK-22243
102mm x 30.48M
CCOONNTTIINNUUOOUUSSLLEENNGGTTHHTTAAPPEESS
RReemmoovvaabblleeAAddhheessiivveePPaappeerrTTaappeess
■Wide Tape
DK-44205
Black Print on White
62mm x 30.48M
■Wide Tape
DK-44605
Black Print on Yellow
62mm x 30.48M
OPTIONAL LABEL AND TAPE SUPPLIES Technical Information
Hardware
Print Method Thermal Line Printing
Maximum Label Width 102mm (4")
Maximum Print Height 98.6 mm
Maximum Label Length 3 metres (Windows) / 1 metre (non-Windows)
Print Resolution 300 dpi
Maximum Print Speed 110 mm / sec | 69 labels/minute*
Cutter Sensor Yes
Cover Open Sensor Yes
Roll Size Detection Yes
Interfaces USB, Serial(RS-232C).
Dimensions 170mm(W) x 220mm(D) x 147.5mm(H)
Weight 1.7kg (without DK roll)
Power Internal Switched Power Supply
Colour Black/Silver
Total/User Memory 4MB/2MB
Print Head MTBF** 30km / 1300 die-cut rolls
Cutter MTBF** 150,000 cuts (continuous rolls)
300,000 cuts (die-cut rolls)
Built-In Firmware
Command Types Raster, ESC/P, Label Template
Built in Fonts Bit-map fonts: Helsinki, Brussels, Letter Gothic Bold, San Diego, Brougham
Outline fonts: Helsinki, Brussels, Letter Gothic
Character Size Bitmap fonts: 24dots, 32dots, 48dots
Outline fonts: 33dots - 400dots (22sizes)
Font Style Bold, Outline, Solid, Shadow, Italic, Vertical
1D Barcode Support Code39, EAN13, EAN8, UPC-A, UPC-E, Codabar, ITF, Code128, EAN128
2D Barcode Support QR Code, Micro QR, PDF417
Direct Connection & ESC/P Template Support
Max Templates 99
Max Lines/Template 1,000
Character code set Windows 1252 Western Europe
Windows 1250 Eastern Europe
Standard character code
Changeable Data Text, Barcode
Object Rotation Yes
Multiple line support Yes
Horizontal text alignment Yes
Text layout formatting Shrink to Fit, Clip text, Long text, Automatic length, Free size
Cutter options Auto cut (Including cut at any number of labels) Cut at end
System Requirements
Operating System PC Windows 2000 Pro / XP Pro / XP Home
CPU Minimum Intel Pentium 266 MHz
Recommended 700MHz or higher
Memory (RAM) 128MB or more
Hard Disk Free Space 70MB or more
Interface USB 1.1 or later specification/RS-232 9 pin D-Sub
Monitor SVGA with high colour graphics card
Other CD-ROM drive for installation
Operating System MAC OS 10.1-10.4.7 (PowerPC)
OS 10.4.4-10.4.7 (Intel)
CPU PowerPC or Intel
Interface USB 1.1 or later specification
Other CD-ROM drive for installation
UP TO
WIDE LABELS
102mm/4”
HIGH RESOLUTION PRINTING
DPI
300
PRINT SPEED
PER SECOND
110mm
UP TO
PER MINUTE*
69 Labels
* Standard Address Labels

Brother labels are available in a wide
choice of widths and sizes, either as a
continuous length roll that can be cut
to your required length (from 25mm to
3 metres), or the more standard die-cut
labels. Our paper labels have a special
coating applied to help prevent against
accidental marks or scratches. Our
durable plastic film labels have a
strong resistance to tearing, and the
fine gloss finish on them, makes them
ideal for temporary signage.
All our rolls are mounted on a special
roll guide. This ensures that the labels
are installed correctly and also tells the
machine and software which size of
label is currently installed. They cannot
be inserted upside down, and the
guide ensures that each label is print-
ed straight, whatever size of label you
produce. It couldn't be easier.
QL-1050
High speed printing of quality labels
102mm print width
Print speed of up to 110mm/second
Built-in automatic cutter
Self-cleaning printhead
Support for over 20 different sized die cut and continuous
length label rolls
Label design software supplied as standard
Easy to install rolls
Choice of connection by USB, RS-232 serial or by the optional
PS-9000 network print server
Choose from a variety of built-in fonts and barcodes
QL-1050
*Standard address label, 4 line, text only
PC Label Printer
The QL-1050 is the newest addition to the
Brother range of Professional Label Printers
and boasts many excellent features, includ-
ing a wide, high-resolution print head, dual
interfaces and a durable built-in cutter.
Brother supplies its label printing software in the box, at no additional cost. With the QL-1050, three
programs are included. Choose the best program for your particular labelling application from the fol-
lowing software:
• A simple "Highlight, click and print" Add-In for popular Microsoft Office applications
• “Address Book” for shipping and postage labels
• P-touch Editor advanced label design software
P-touch Editor is a desktop publishing program specifically developed for the QL-1050.
Some of the main features of this powerful program include:
BARCODES - 17 industry standard barcode protocols, including 2D barcodes.
DATABASE CONNECTION - Connect to Microsoft Excel, Access or CSV file to print larger quantities of labels
automatically – ideal for warehouses, logistics and stock control.
CLIP ART/SYMBOLS - Hundreds of clip-art images are included, perfect when using the continuous length
rolls for signage purposes.
GRAPHIC IMAGE IMPORT - Support for most of the popular graphic image formats, which include jpg, bmp,
tif and png files, enabling you to include your company logo or specialist symbols on your labels.
AUTOMATIC DATE/TIME PRINTING - Add one or more time and date to your label to show when the label
was printed, or you can even let the software calculate and print a future date or time automatically, every
time you print. Ideal for laboratory labels to show best before or use by expiry information.
Software for all types of users
Solutions for advanced users
B-PAC SDK
Add label printing to your existing Windows software with the optional b-PAC SDK (Software
Development Kit). Designed for programmers and software developers, b-PAC is a powerful tool that
places text and barcodes onto your label design and sends this to the Windows printer driver. This is
available as a download from http://solutions.brother.com.
DIRECT CONNECTION TO OTHER DEVICES
QL-1050 can print independently, without the need of a PC.
Design a label and upload it to the memory of the QL-1050, then connect a compatible device directly
to the serial port without the need for a computer (such as a barcode scanner or test equipment).
Whenever the machine receives the text or barcode number it will add the data onto the required
design and print your label. If needed, add special commands to change the printing options.
Features
Perfect for a wide range of uses:
• Barcode printing
• Shipping and Postage
• Temporary or Indoor Signage
• Visitor & Event badges
• “Best Before / Use By” labels
• Office files, folders and organisation
• Logistics and Warehouse
• Packaging Industry
• Hospitality & Events Management
• Medical & Healthcare
• Manufacturing & Production Facilities
• Offices
