Brother DCP-J562DW Technical manual

Online User's Guide
DCP-J562DW
MFC-J480DW
MFC-J680DW
MFC-J880DW
© 2015 Brother Industries, Ltd. All rights reserved.

Table of Contents
Before You Use Your Brother Machine ............................................................................................... 1
Applicable Models .......................................................................................................................................... 2
Definitions of Notes ........................................................................................................................................ 3
Trademarks .................................................................................................................................................... 4
Important Note ............................................................................................................................................... 5
Introduction to Your Brother Machine................................................................................................. 6
Before Using Your Machine ........................................................................................................................... 7
Control Panel Overview ................................................................................................................................. 8
LCD Overview .............................................................................................................................................. 12
Cloud Service Notifications ................................................................................................................ 19
Settings Screen Overview ........................................................................................................................... 20
Navigate the Touchscreen............................................................................................................................ 24
Access Brother Utilities (Windows®) ............................................................................................................ 25
Uninstall the Brother Software and Drivers (Windows®) .................................................................... 26
Paper Handling.................................................................................................................................... 27
Load Paper................................................................................................................................................... 28
Load Paper in the Paper Tray ............................................................................................................ 29
Load Photo or Photo L Paper in Photo Paper Tray ............................................................................ 40
Load Paper in the Manual Feed Slot.................................................................................................. 43
Unprintable Area ................................................................................................................................ 47
Paper Settings.................................................................................................................................... 48
Acceptable Paper and Other Print Media........................................................................................... 52
Load Documents .......................................................................................................................................... 61
Load Documents in the Automatic Document Feeder (ADF) ............................................................. 62
Load Documents on the Scanner Glass ............................................................................................ 64
Unscannable Area.............................................................................................................................. 66
Print ...................................................................................................................................................... 67
Print from Your Computer (Windows®) ........................................................................................................ 68
Print a Photo (Windows®)................................................................................................................... 69
Print a Document (Windows®)............................................................................................................ 70
Cancel a Print Job (Windows®) .......................................................................................................... 71
Print More Than One Page on a Single Sheet of Paper (N in 1) (Windows®).................................... 72
Print as a Poster (Windows®)............................................................................................................. 73
Print on Both Sides of the Paper Automatically (Automatic 2-sided Printing) (Windows®) ................ 74
Print as a Booklet Automatically (Windows®)..................................................................................... 77
Print a Colour Document in Greyscale (Windows®) ........................................................................... 79
Prevent Smudged Printouts and Paper Jams When Printing on Both Sides of the Paper
(Windows®) ........................................................................................................................................ 80
Use a Preset Print Profile (Windows®) ............................................................................................... 81
Change the Default Print Settings (Windows®) .................................................................................. 84
Print Settings (Windows®) .................................................................................................................. 85
Print from Your Computer (Macintosh)......................................................................................................... 90
Print a Photo (Macintosh)................................................................................................................... 91
Home > Table of Contents
i

Print a Document (Macintosh)............................................................................................................ 92
Print on Both Sides of the Paper Automatically (Automatic 2-sided Printing) (Macintosh) ................ 93
Print More Than One Page on a Single Sheet of Paper (N in 1) (Macintosh).................................... 94
Print a Colour Document in Greyscale (Macintosh) ........................................................................... 95
Prevent Smudged Printouts and Paper Jams When Printing on Both Sides of the Paper
(Macintosh)......................................................................................................................................... 96
Print Options (Macintosh)................................................................................................................... 97
Scan.................................................................................................................................................... 103
Scan Using the Scan Button on Your Brother Machine ............................................................................. 104
Scan Photos and Graphics............................................................................................................... 105
Save Scanned Data to a Folder as a PDF File ................................................................................ 107
Save Scanned Data to a Memory Card or USB Flash Drive............................................................ 109
Scan Multiple Business Cards and Photos (Auto Crop)................................................................... 114
Scan to an Editable Text File Using OCR......................................................................................... 116
Scan to E-mail Attachment............................................................................................................... 118
Web Services for Scanning on Your Network (Windows Vista® SP2 or greater, Windows® 7 and
Windows® 8)..................................................................................................................................... 120
Change Scan Button Settings from ControlCenter4 (Windows®)..................................................... 125
Change Scan Button Settings from ControlCenter2 (Macintosh)..................................................... 129
Scan from Your Computer (Windows®)...................................................................................................... 132
Scan Using ControlCenter4 Home Mode (Windows®) ..................................................................... 133
Scan Using ControlCenter4 Advanced Mode (Windows®)............................................................... 148
Scan Using Nuance™ PaperPort™ 14SE or Other Windows® Applications .................................... 163
Scan Using Windows® Photo Gallery or Windows® Fax and Scan ................................................. 167
Install BookScan Enhancer and Whiteboard Enhancer (Windows®) ............................................... 171
Scan from Your Computer (Macintosh) ...................................................................................................... 172
Scan Using ControlCenter2 (Macintosh).......................................................................................... 173
Scan Using Presto! PageManager or other TWAIN-Compliant Applications (Macintosh)................ 188
Copy ................................................................................................................................................... 194
Copy a Document ..................................................................................................................................... 195
Enlarge or Reduce Copied Images ............................................................................................................ 198
Sort Copies ................................................................................................................................................ 200
Make Page Layout Copies ( N in 1 or Poster)............................................................................................ 201
Page Layout Options for Copies ...................................................................................................... 203
2-sided Copy .............................................................................................................................................. 206
Copy on Both Sides of the Paper (1-sided to 2-sided/2-sided to 2-sided) ....................................... 207
Copy an ID Card ........................................................................................................................................ 210
Copy in Ink Save Mode ............................................................................................................................. 212
Copy Options ............................................................................................................................................. 213
Fax ...................................................................................................................................................... 217
Send a Fax................................................................................................................................................. 218
Send a Fax from Your Brother Machine ........................................................................................... 219
Send a Fax Manually........................................................................................................................ 222
Send a Fax at the End of a Conversation ........................................................................................ 223
Send the Same Fax to More than One Recipient (Broadcasting) .................................................... 224
Send a Fax in Real Time .................................................................................................................. 227
Home > Table of Contents
ii

Send a Fax at a Specified Time (Delayed Fax)................................................................................ 228
Cancel a Fax in Progress ................................................................................................................. 229
Check and Cancel a Pending Fax.................................................................................................... 230
Fax Polling........................................................................................................................................ 231
Fax Options ...................................................................................................................................... 235
Receive a Fax ............................................................................................................................................ 237
Receive Mode Settings .................................................................................................................... 238
Fax Preview...................................................................................................................................... 245
Shrink Page Size of an Oversized Incoming Fax ............................................................................. 249
Set the Fax Receive Stamp.............................................................................................................. 250
Receive a Fax at the End of a Telephone Conversation .................................................................. 251
Memory Receive Options ................................................................................................................. 252
Remote Fax Retrieval....................................................................................................................... 260
Fax Polling........................................................................................................................................ 266
Voice Operations and Fax Numbers .......................................................................................................... 274
Voice Operations .............................................................................................................................. 275
Store Fax Numbers .......................................................................................................................... 278
Set up Groups for Broadcasting ....................................................................................................... 285
Telephone Services and External Devices................................................................................................. 290
Distinctive Ring................................................................................................................................. 291
Caller ID ........................................................................................................................................... 295
FaxAbility.......................................................................................................................................... 297
Voice Over Internet Protocol (VoIP/Telephone Line Interference).................................................... 299
External TAD (Telephone Answering Device)................................................................................... 300
External and Extension Telephones ................................................................................................. 304
Fax Reports ............................................................................................................................................... 310
Set the Transmission Verification Report's Style .............................................................................. 311
Set the Fax Journal's Interval Period................................................................................................ 312
PC-FAX ...................................................................................................................................................... 314
PC-FAX for Windows®...................................................................................................................... 315
PC-FAX for Macintosh...................................................................................................................... 339
PhotoCapture Center ........................................................................................................................ 342
Print Photos Directly from Media................................................................................................................ 343
Compatible Memory Cards and USB Flash Drives .......................................................................... 344
Important Information about PhotoCapture Center .......................................................................... 345
Print Photos from Media Using the Photo Button on the Brother Machine ...................................... 346
Copy Photos from Media to a Computer.................................................................................................... 360
Before Copying Photos .................................................................................................................... 361
Copy Photos from Media Over a Local Connection ......................................................................... 362
Copy Photos from Media Over a Network Connection..................................................................... 363
Print Photos from ControlCenter4 (Windows®).......................................................................................... 364
Edit Photos Using ControlCenter4 (Windows®) ............................................................................... 366
Network .............................................................................................................................................. 368
Get Started................................................................................................................................................. 369
Supported Basic Network Features.................................................................................................. 370
Network Management Software and Utilities ............................................................................................. 371
Learn about Network Management Software and Utilities ............................................................... 372
Home > Table of Contents
iii

Additional Methods of Configuring Your Brother Machine for a Wireless Network .................................... 373
Before Configuring Your Brother Machine for a Wireless Network................................................... 374
Configure Your Machine for a Wireless Network Using the One Push Method of Wi-Fi Protected
Setup™ (WPS) or AOSS™................................................................................................................ 375
Configure Your Machine for a Wireless Network Using the PIN Method of Wi-Fi Protected
Setup™ (WPS).................................................................................................................................. 377
Configure Your Machine for a Wireless Network in Ad-Hoc Mode Using a New SSID .................... 380
Configure Your Machine for a Wireless Network Settings When the SSID is Not Broadcast........... 382
Use Wi-Fi Direct®............................................................................................................................. 385
Advanced Network Features...................................................................................................................... 398
Print the Network Configuration Report............................................................................................ 399
Technical Information for Advanced Users................................................................................................. 400
Reset the Network Settings to Factory Default ................................................................................ 401
Print the WLAN Report..................................................................................................................... 402
Security .............................................................................................................................................. 405
Lock the Machine Settings ......................................................................................................................... 406
About Using Memory Security.......................................................................................................... 407
About Using TX Lock........................................................................................................................ 411
Mobile/Web Connect......................................................................................................................... 415
Use Web Services from Your Brother Machine.......................................................................................... 416
Use Brother Web Services......................................................................................................................... 417
Print with Google Cloud Print™.................................................................................................................. 419
Print with AirPrint........................................................................................................................................ 420
Print with Mopria™...................................................................................................................................... 421
Print and Scan from a Mobile Device......................................................................................................... 422
Print and Scan Using Near-Field Communication (NFC)........................................................................... 423
ControlCenter .................................................................................................................................... 424
ControlCenter4 (Windows®)....................................................................................................................... 425
Change the Operation Mode in ControlCenter4 (Windows®) .......................................................... 426
Scan Using ControlCenter4 Home Mode (Windows®) ..................................................................... 428
Scan Using ControlCenter4 Advanced Mode (Windows®)............................................................... 429
Set Up the Brother Machine Using ControlCenter4 (Windows®) ..................................................... 430
Create a Custom Tab Using ControlCenter4 Advanced Mode (Windows®)..................................... 432
ControlCenter2 (Macintosh) ....................................................................................................................... 434
Scan Using ControlCenter2 (Macintosh).......................................................................................... 435
Set Up the Brother Machine Using ControlCenter2 (Macintosh)...................................................... 436
Turn the AutoLoad Feature On (Macintosh)..................................................................................... 438
Troubleshooting ................................................................................................................................ 439
Error and Maintenance Messages ............................................................................................................. 440
Transfer Your Faxes or Fax Journal Report ..................................................................................... 455
Document Jams ......................................................................................................................................... 460
Document is Jammed in the Top of the ADF Unit ............................................................................ 461
Document is Jammed inside the ADF Unit....................................................................................... 462
Remove Paper Scraps Jammed in the ADF .................................................................................... 463
Printer Jam or Paper Jam .......................................................................................................................... 464
Paper is Jammed Inside and in the Front of the Machine (Jam A Inside/Front) .............................. 465
Home > Table of Contents
iv

Paper is Jammed in the Front of the Machine (Jam B Front)........................................................... 469
Paper is Jammed in the Back of the Machine (Jam C Rear) ........................................................... 472
If You Are Having Difficulty with Your Machine .......................................................................................... 474
Paper Handling and Printing Problems ............................................................................................ 475
Telephone and Fax problems ........................................................................................................... 481
Other Problems ................................................................................................................................ 488
Network Problems ............................................................................................................................ 490
Check the Machine Information ................................................................................................................. 499
Reset Your Brother Machine ...................................................................................................................... 500
Reset Functions ............................................................................................................................... 501
Routine Maintenance ........................................................................................................................ 502
Replace the Ink Cartridges......................................................................................................................... 503
Clean Your Brother Machine ...................................................................................................................... 506
Clean the Scanner............................................................................................................................ 507
Clean the Print Head from Your Brother Machine ............................................................................ 509
Clean the Print Head from Your Computer (Windows®)................................................................... 511
Clean the Print Head from Your Computer (Macintosh) ................................................................... 512
Clean the Machine's LCD................................................................................................................. 513
Clean the Outside of the Machine .................................................................................................... 514
Clean the Machine's Printer Platen .................................................................................................. 516
Clean the Paper Feed Rollers .......................................................................................................... 517
Clean the Paper Pick-up Rollers ...................................................................................................... 519
Check Your Brother Machine ..................................................................................................................... 520
Check the Print Quality..................................................................................................................... 521
Check the Print Alignment from Your Brother Machine .................................................................... 525
Check the Ink Volume ...................................................................................................................... 527
Monitor Machine Status from Your Computer (Windows®) .............................................................. 529
Monitor Machine Status from Your Computer (Macintosh)............................................................... 534
Correct the Paper Feed to Clear Vertical Lines.......................................................................................... 536
Pack and Ship Your Brother Machine ........................................................................................................ 537
Machine Settings............................................................................................................................... 540
Change Machine Settings from the Control Panel ..................................................................................... 541
In the Event of Power Failure (Memory Storage) ............................................................................. 542
General Settings............................................................................................................................... 543
Save Your Favourite Settings as a Shortcut..................................................................................... 559
Print Reports .................................................................................................................................... 562
Settings and Features Tables........................................................................................................... 565
Change Machine Settings from Your Computer......................................................................................... 588
Change the Machine Settings Using Remote Setup ........................................................................ 589
Appendix............................................................................................................................................ 602
Specifications ............................................................................................................................................. 603
Enter Text on Your Brother Machine .......................................................................................................... 611
Supply Specifications ................................................................................................................................. 613
Glossary............................................................................................................................................. 614
Home > Table of Contents
v

Home > Before You Use Your Brother Machine
Before You Use Your Brother Machine
•Applicable Models
•Definitions of Notes
•Trademarks
•Important Note
1

Home > Before You Use Your Brother Machine > Applicable Models
Applicable Models
This User's Guide applies to the following models:
1.8 inch LCD models: MFC-J480DW
2.7 inch Touchscreen LCD models: DCP-J562DW/MFC-J680DW/MFC-J880DW
Related Information
•Before You Use Your Brother Machine
2

Home > Before You Use Your Brother Machine > Definitions of Notes
Definitions of Notes
We use the following symbols and conventions throughout this User's Guide:
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious
injuries.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate
injuries.
IMPORTANT
IMPORTANT indicates a potentially hazardous situation which, if not avoided, may result in damage to
property or loss of product functionality.
NOTE
NOTE specifies the operating environment, conditions for installation, or special conditions of use.
Tips icons provide helpful hints and supplementary information.
Electrical Hazard icons alert you to possible electrical shock.
Bold
Bold style identifies buttons on the machine's control panel or computer screen.
Italics
Italicised style emphasises an important point or refers you to a related topic.
[Courier New]
Courier New font identifies messages shown on the machine's LCD.
Related Information
•Before You Use Your Brother Machine
3

Home > Before You Use Your Brother Machine > Trademarks
Trademarks
Microsoft, Windows, Windows Vista, Windows Server, SharePoint, Internet Explorer, Word, Excel, PowerPoint,
OneNote and Windows Phone are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
Apple, Macintosh, Safari, iPad, iPhone, iPod touch and OS X are trademarks of Apple Inc., registered in the
United States and other countries.
AirPrint is a trademark of Apple Inc.
Nuance and PaperPort are trademarks or registered trademarks of Nuance Communications, Inc. or its affiliates
in the United States and/or other countries.
Memory Stick PRO Duo, Memory Stick Duo, Memory Stick Micro and M2 are trademarks of Sony Corporation.
The SDHC Logo is a trademark of SD-3C, LLC.
AOSS is a trademark of Buffalo Inc.
Wi-Fi, Wi-Fi Alliance, Wi-Fi Direct and Wi-Fi Protected Access are registered trademarks of Wi-Fi Alliance®.
WPA, WPA2, Wi-Fi Protected Setup and Wi-Fi Protected Setup logo are trademarks of Wi-Fi Alliance®.
Flickr is a trademark of Yahoo! Inc.
Android, Android Market, Google Cloud Print, Google Drive, Picasa Web Albums, Google Play and Google
Chrome are trademarks of Google, Inc. Use of these trademarks are subject to Google Permissions.
Mozilla and Firefox are registered trademarks of the Mozilla Foundation.
UNIX is a registered trademark of The Open Group in the United States and other countries.
Linux is the registered trademark of Linus Torvalds in the U.S. and other countries.
The Bluetooth word mark is owned by the Bluetooth SIG, Inc. and any use of such marks by Brother Industries,
Ltd. is under license.
Intel is a trademark of Intel Corporation in the U.S. and/or other countries.
Evernote is a trademark of Evernote Corporation and used under a license.
Mopria is a trademark of Mopria Alliance, Inc.
WordPerfect is a registered trademark of Corel Corporation and/or its subsidiaries in Canada, the United States
and/or other countries.
Each company whose software title is mentioned in this manual has a Software License Agreement specific to its
proprietary programs.
Any trade names and product names of companies appearing on Brother products, related documents
and any other materials are all trademarks or registered trademarks of those respective companies.
Related Information
•Before You Use Your Brother Machine
4

Home > Before You Use Your Brother Machine > Important Note
Important Note
• Do not use this product outside the country of purchase as it may violate the wireless telecommunication and
power regulations of that country.
• Not all models are available in all countries.
• Windows® XP in this document represents Windows® XP Professional, Windows® XP Professional x64
Edition and Windows® XP Home Edition.
• Windows Server® 2003 in this document represents Windows Server® 2003, Windows Server® 2003 x64
Edition, Windows Server® 2003 R2 and Windows Server® 2003 R2 x64 Edition.
• Windows Server® 2008 in this document represents Windows Server® 2008 and Windows Server® 2008 R2.
• In this User's Guide, the LCD messages of the MFC-J880DW are used unless otherwise specified.
• In this User's Guide, the illustrations of the MFC-J880DW are used unless otherwise specified.
• Unless otherwise specified, the screens in this manual are from Windows® 7 and OS X v10.9.x. Screens on
your computer may vary depending on your operating system.
• This documentation is for both MFC and DCP models. Where it says 'MFC' in this User's Guide, read 'MFC-
xxxx' as 'DCP-xxxx'.
Related Information
•Before You Use Your Brother Machine
5

Home > Introduction to Your Brother Machine
Introduction to Your Brother Machine
•Before Using Your Machine
•Control Panel Overview
•LCD Overview
•Settings Screen Overview
•Navigate the Touchscreen
•Access Brother Utilities (Windows®)
Brother Utilities is an application launcher that offers convenient access to all Brother applications installed on your
computer.
6

Home > Introduction to Your Brother Machine > Before Using Your Machine
Before Using Your Machine
Before attempting any printing operation, confirm the following:
• Make sure you have installed the Brother software and drivers.
• For USB or network cable users: Make sure the interface cable is physically secure.
Selecting the correct type of paper
For high quality printing, it is important to select the correct type of paper. Be sure to read the information about
acceptable paper before buying paper, and to determine the printable area depending on the settings in the
printer driver.
Simultaneous printing, scanning and faxing
Your machine can print from your computer while sending or receiving a fax into memory or while scanning a
document into the computer. Fax sending will not be stopped during printing from your computer. However, when
the machine is copying or receiving a fax on paper, it pauses the printing operation, and then continues printing
when copying or fax receiving has finished.
DCP models do not support the fax feature.
Firewall (Windows®)
If your computer is protected by a firewall and you are unable to network print, network scan, or PC-FAX, you
may need to configure the firewall settings. If you are using the Windows® Firewall and you installed the Brother
software and drivers from the CD-ROM, the necessary firewall settings have already been set. If you are using
any other personal firewall software, see the User's Guide for your software or contact the software
manufacturer.
Related Information
•Introduction to Your Brother Machine
7

Home > Introduction to Your Brother Machine > Control Panel Overview
Control Panel Overview
MFC-J480DW
01. 01. 2016
FaxFax
0101
32
1
1. 1.8"(44.9 mm) Liquid Crystal Display (LCD)
Displays messages to help you set up and use the machine.
Adjust the angle of the control panel by lifting it.
2. Mode buttons
FAX
Press to switch the machine to FAX Mode.
SCAN
Press to switch the machine to SCAN Mode.
COPY
Press to switch the machine to COPY Mode.
WEB
Press to switch the machine to WEB Mode.
3. Settings buttons
Clear
Press to delete characters or to go back to the previous menu level.
8

Settings
Press to access the main menu.
OK
Press to choose a setting.
d or c
Press to adjust the ring volume while the machine is idle.
• Press to store Speed Dial and Group numbers in the machine's memory.
• Press to look up and dial numbers that are stored in the machine's memory.
Press to configure the wireless settings while the machine is idle.
a or b
Press to scroll through the menus and options.
d or c
Press to move the cursor left or right on the LCD.
54
8
76
4. Telephone buttons
Hook
Press before dialing to ensure a fax machine answers, and then press Mono Start or Colour Start.
If the machine is in Fax/Tel (F/T) Mode and you pick up the handset of an external telephone during the
F/T ring (pseudo/double-ring), press Hook to talk.
Redial/Pause
• Press to dial the last 30 numbers you called.
• Press to insert a pause when dialling numbers.
9

5. Dial Pad
• Use to dial fax and telephone numbers.
• Use as a keyboard to enter text or characters.
6. Stop/Exit
• Press to stop an operation.
• Press to exit from a menu.
7. Power On/Off
Press to turn on the machine.
Press and hold down to turn off the machine. The LCD will display [Shutting Down] and will stay on
for a few seconds before turning itself off. If you have connected an external telephone or TAD, it is always
available.
If you turn off the machine using , it will still clean the print head periodically to maintain print quality. To
prolong print head life, provide better ink efficiency, and maintain print quality, keep your machine connected
to a power source at all times.
8. Start buttons
Mono Start
• Press to start sending faxes in monochrome.
• Press to start making copies in monochrome.
• Press to start scanning documents (in colour or monochrome depending on the scan setting).
Colour Start
• Press to start sending faxes in full colour.
• Press to start making copies in full colour.
• Press to start scanning documents (in colour or monochrome depending on the scan setting).
DCP-J562DW/MFC-J680DW/MFC-J880DW
The control panel will vary depending on your model.
32 4
1
1. NFC (Near Field Communication) logo
(MFC-J880DW)
10

• If your Android™ device supports the NFC feature, you can print from your device or scan documents to
your device by touching it to the NFC logo on the control panel. You must download and install Brother
iPrint&Scan to your Android™ device to use this feature.
• Make sure the NFC settings of both your Brother machine and your Android™ device are set to On.
2. 2.7"(67.5 mm) Touchscreen Liquid Crystal Display (LCD)
Access menus and options by pressing them on this Touchscreen.
Adjust the angle of the Touchscreen LCD and Touchpanel by lifting it.
3. Touchpanel
(Back)
Press to go back to the previous menu.
(Home)
Press to return to the Home screen.
While the machine is in Sleep Mode, the Home icon blinks.
(Cancel)
Press to cancel an operation (available when illuminated in red).
4. Power On/Off
Press to turn the machine on.
Press and hold down to turn the machine off. The Touchscreen will display [Shutting Down] and will
stay on for a few seconds before turning itself off. If you have connected an external telephone or TAD, it is
always available.
If you turn the machine off using , it will still clean the print head periodically to maintain print quality. To
prolong print head life, provide better ink efficiency, and maintain print quality, keep your machine connected
to a power source at all times.
Related Information
•Introduction to Your Brother Machine
•Print and Scan Using Near-Field Communication (NFC)
11

Home > Introduction to Your Brother Machine > LCD Overview
LCD Overview
MFC-J480DW
This screen shows the machine’s status when the machine is idle. This Home screen is also called the Ready
Mode screen. When displayed, this indicates that your machine is Ready for the next command.
01. 01. 2016
FaxFax
0101
1
346
2
5
1. Quiet Mode
The (Quiet Mode) icon appears when the [Quiet Mode] setting is set to [On].
The Quiet Mode setting can reduce printing noise. When Quiet Mode is turned on, the print speed becomes
slower.
2. Wireless Status
Each icon in the following table shows the wireless network status.
The wireless setting is disabled.
Wireless network is connected.
A three-level indicator in the LCD displays the current wireless signal strength.
The wireless access point cannot be detected.
You can configure wireless settings by pressing on the control panel. For more information, see the
Quick Setup Guide.
3. Ink
Displays the available ink volume.
When an ink cartridge is near the end of its life or having a problem, an error icon is displayed on the ink
colour.
4. Date & Time
Displays the date and time set on the machine.
5. Faxes in memory
Displays how many received faxes are in the machine's memory.
6. Receive Mode
Displays the current Receive Mode.
•[Fax] (Fax Only)
•[F/T] (Fax/Tel)
•[TAD] (External TAD)
•[Mnl] (Manual)
12

(For some countries)
When the Distinctive Ring feature is turned on, the LCD displays [D/R].
(For New Zealand)
When the FaxAbility feature is turned on, the LCD displays [D/R].
MFC-J680DW/MFC-J880DW
There are two Home screens that you can access by pressing d or c.
From the Home screens, you can access Wi-Fi setup, Shortcuts, Ink levels and Setup screens.
Home Screen 1
1
7
6
3
45
2
This screen shows the machine’s status when the machine is idle. This Home screen is also called the Ready
Mode screen. When displayed, this indicates that your machine is Ready for the next command.
Home Screen 1 provides access to [Fax], [Copy] and [Scan] operations.
Home Screen 2
1
7
6
3
45
2
Home Screen 2 provides access to additional features, such as [Photo], [Web] and [Apps] operations.
1. Date & Time
Displays the date and time set on the machine.
2. Quiet Mode
This icon appears when the [Quiet Mode] setting is set to [On].
The Quiet Mode setting can reduce printing noise. When Quiet Mode is turned on, the print speed becomes
slower.
3. Wireless Status
Each icon in the following table shows the wireless network status.
Your machine has not been connected to the wireless access point.
Press this button to configure wireless settings. For more information, see the Quick Setup Guide.
Wireless network is connected.
A three-level indicator in each of the Home screens displays the current wireless signal strength.
13

The wireless access point cannot be detected.
The wireless setting is disabled.
You can configure wireless settings by pressing the Wireless Status button.
4. [Shortcuts]
Create Shortcuts for frequently-used operations such as sending a fax, copying, scanning and using Web
Connect.
• There are three Shortcuts screens. You can program four shortcuts on each screen.
• To display the other Shortcuts screens, press d or c.
5. [Ink]
Displays the available ink volume. Press to access the [Ink] menu.
When an ink cartridge is near the end of its life or having a problem, an error icon is displayed on the ink
colour.
6. [Settings]
Press to access the [Settings] menu.
7. Modes:
• [Fax]
Press to access Fax mode.
• [Copy]
Press to access Copy mode.
• [Scan]
Press to access Scan mode.
• [Photo]
Press to access Photo mode.
• [Web]
Press to connect the Brother machine to an Internet service.
For more information, see the Web Connect Guide: solutions.brother.com/manuals
• [Apps]
Press to connect the Brother machine to the Brother Apps service.
14
