LASER PRINTER
PARTS REFERENCE LIST
HL-1660e

NOTE FOR USING THIS PARTS REFERENCE LIST
1. In the case of ordering parts, it needs mentioning the following items:
(1) Code
(2) Q'ty
(3) Description
(4) Symbol ( PCB No., Revision , and Parts location mounted on the PCB.)
Note : No orders without Parts Code or Tool No. can be accepted.
< Example >
REF.NO. CODE Q’TY DESCRIPTION SYMBOL REMARK
Revision No.: marked on the printed circuit board.
B48K056 - 201A
2. Design-changed parts :
If the parts are changed, any one of the following symbols is indicated in the REMARKS
column.
#A : compatible between old and new
#B : replaceable from old to new
#D : incompatible
# : newly established
3. The original of this list was made based on the information available in November, 1997.
4. Parts are subject to change in design without prior notice.
(1) (4)
(3)
(2)
Design change indication
Specification No .
Pattern alteration No.
Circuit board No.

CONTENTS
1. POWER CORDS & HARNESSES........................................................1
2. PAPER FEEDER PCB..........................................................................1
3. CONTROL PANEL................................................................................3
4. PCB ATTACHMENTS...........................................................................3
5. MAIN PCB.............................................................................................5
6. HIGH-VOLTAGE POWER SUPPLY.....................................................7
7. LOW-VOLTAGE POWER SUPPLY......................................................7
8. COVERS...............................................................................................9
9. CHASSIS..............................................................................................9
10.TRANSFER.........................................................................................11
11.PAPER TRAY.....................................................................................11
12.PAPER FEEDER.................................................................................13
13.SCANNER...........................................................................................15
14.FIXING UNIT, 120V/230V...................................................................15
15.DOCUMENTS.....................................................................................17
16.PACKING MATERIALS.......................................................................19
17.OPTIONAL PARTS SET.....................................................................19
18.ADJUSTING TOOL KIT.......................................................................21

1 .POWER CORDS & HARNESSES
MODEL HL-1660e
54T-U03-050/070
2 .PAPER FEEDER PCB
MODEL HL-1660e 54T-U03-090
1A
1B
1C
1D
1E
1I
1H
1F
1G
4
3
2
6
5
3
2
1
B48K139-2
95 96
21
P4
(MP SOL) JW18
JW13
JW2
JW3
1
2
19
20 P5 (ENGINE)
R1 RH1
JW12
R3
R4
R5
R6R7
R8 C6
JW4
RH2
C3
C4
C5
JW17
JW21
JW20
JW19
R12
Q2
Q1
Q3
JW26
P2 1
5
JW14
JW23
JW24
R10 R11
R15
R16
R13
R14
12
#1
PH4
JW7
JW6 JW5 JW1
JW9 JW8
JW11
JW10
C1
C2
R2
PH3
JW15
R9
JW22
JW25
JW16
18
17
16
P1 (FEED MOTOR)
1
2
P3 (CASOL)
PH5
95 96
B48K140-2
51
SW1
SW2
SW3
SW4
P1
+
JW27

1. POWER CORDS & HARNESSES
REF.NO. CODE Q'TY DESCRIPTION REMARK
1A UH1052001 1AC CORD, VDE
1B UH1053001 1AC CORD, SEV
1C UH1055001 1AC CORD, SAA
1D UH1054001 1AC CORD, BS
1E UH1051001 1AC CORD, UL/CSA
1F U34320001 1AC CORD #4, BS WO/PLUG
1G UK4094001 1AC CORD #5, DEMKO
1H U34322001 1AC CORD #6, ISRAEL
1I U34342001 1AC CORD #8, BS/SINGAPORE
2UK2502001 1HV HARNESS 16P
3UK2505000 1FEED FLAT CABLE 20P
4UK2506001 1LV HARNESS 8P
5UK2507001 1FUSER HARNESS 4P
6UK2508001 1DC MOTOR HARNESS 4P
MODEL HL-1660e 54T-U03-050/070
T/I NO. PR98046
2. PAPER FEEDER PCB
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1UK2701001 1P FEED/SIZE-SW PCB ASSY (SP) B48K139/140-
200B/200B
2UH2410000 1SIZE SWITCH SPRING
3087320616 2TAPTITE, CUP S M3X6
MODEL HL-1660e 54T-U03-090

3 .CONTROL PANEL
MODEL HL-1660e54T-U03-150
4PCB ATTACHMENTS
54T-U03-450
READY
DATA
ALARM
ON LINE
SEL MODE FONT FORM FEED SET CONTINUE
EMULATION ECONOMY FEEDER COPY SHIFT RESET TEST
COPY PAGES
FEEDER
ORIENTATION
DUPLEX
1
3
1-2
1
2
3
69
8
7
5
4
MODEL HL-1660e
2
10
T/I NO. PR98309

3. CONTROL PANEL
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1-2 UK3024001 1CONTROL PANEL UNIT (SP) (B48K143-200B)
1UK2500000 1SWITCH FLAT CABLE 21P
2UH2011001 1PANEL STOPPER, GRAY1227
3UH1451001 1PANEL SHEET, HL-1660e
MODEL HL-1660e 54T-U03-150
4. PCB ATTACHMENTS
REF.NO. CODE Q'TY DESCRIPTION REMARK
1UH2121001 1REMOTE SWITCH
2UH2122000 1PS SWITCH WIRE
3UH2124001 1DC FAN MOTOR
4083313515 2TAPTITE, PAN B M3X35
5UH2144001 1HOLDER SPACER
6UK2826001 1CORE:RI-12-15-8.5
7UK3213000 1CORE:FPC-16-12
8UK3214000 1CORE:ZCAT1518
9UK3215000 1CABLE CLAMP
10 UH2123001 1SWITCH ATTACHMENT
MODEL HL-1660e 54T-U03-450
T/I NO. PR98309

5 .MAIN PCB
MODEL HL-1660e 54T-U03-103
4
4
4
1-2
2
6
4
5
3
4
1

5. MAIN PCB
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1-2 UK3799001 1MAIN PCB ASSY (SP), HL1660e B48K294-100E
1UK4280000 1MROM23C32000-01 #26
2UK4281000 1MROM23C32000-02 #14
3UK3785001 1MIO CONNECTOR PCB ASSY B48K295-100
4087320616 7TAPTITE, CUP S M3X6
5087320616 1TAPTITE, CUP S M3X6
6UK2466000 1EPROM:27C8000DZ(BLANK EPROM)(SP)(#1)
MODEL HL-1660e 54T-U03-103
T/I NO. PR98017 / PR98055 / PR98278

6 .HIGH-VOLTAGE POWER SUPPLY
MODEL HL-1660e 54T-U03-200
7 .LOW-VOLTAGE POWER SUPPLY
54T-U03-300
1
2
1-2
3
3
1
3
3
32
MODEL HL-1660e

6. HIGH-VOLTAGE POWER SUPPLY
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1UK2702001 1HIGH-VOLTAGE PS PCB ASSY (SP) B48K186-300E
2087320616 2TAPTITE, CUP S M3X6
MODEL HL-1660e 54T-U03-200
7. LOW-VOLTAGE POWER SUPPLY
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1-2 UK2753001 1LOW-VOLT PS PCB ASSY, 115VM(SP)
1-2 UK2754001 1LOW-VOLT PS PCB ASSY, 230VM(SP)
1UK2756001 1GLASS FUSE, 10A-125VM (PS PCB 115VM) (SP) F1
1UK2759001 1GLASS FUSE, 6A-250VM (PS PCB 230VM) (SP) F1
2UK2757001 1GLASS FUSE, 5A-125VM (PS PCB 115VM) (SP) F2
2UK2760001 1GLASS FUSE, 3A-250VM (PS PCB 230VM) (SP) F2
3UH2036001 6TAPTITE, PAN S M3X8
MODEL HL-1660e 54T-U03-300
T/I NO. PR98205

54T-U03-400
9 .CHASSIS
54T-U03-500
1
2
4
5
6
8
7
12
12
9
9
10
11
3
7-8
8 .COVERS
1
2
34
5
6
7
8
4
9
10
11 12
13
14 15
15
15
15
21
20
22
16
4
17
19
18
MODEL HL-1660e
MODEL HL-1660e

8. COVERS
REF.NO. CODE Q'TY DESCRIPTION REMARK
1UH2065001 1UPPER COVER ASSY, GRAY1227
2UH2071001 1TONER CARTRIDGE LID, GRAY1227
3UH2072001 1FONT COVER ASSY, GRAY1227
4UH2076001 1CLEANER BRUSH
5UH2077001 1SIDE COVER L, GRAY1227
6UH2027001 1SIDE COVER R2 ASSY, GRAY1227
7-8 UH2082001 1REAR COVER ASSY, GRAY1227
7-8 UH2104001 1REAR COVER ASSY, GRAY 1227(TMT-17)
7UH2085001 1CHANGEOVER GUIDE, GRAY1227
8UH2103001 1JAM REMOVE COVER, GRAY1227
9087320616 2TAPTITE, CUP S M3X6
10 087320616 1TAPTITE, CUP S M3X6
11 087320616 1TAPTITE, CUP S M3X6
12 087321016 2TAPTITE, CUP S M3X10
MODEL HL-1660e 54T-U03-400
T/I NO. PR98175
9. CHASSIS
REF.NO. CODE Q'TY DESCRIPTION REMARK
1UH2229001 1CARTRIDGE STOPPER ASSY
2UH2233001 1DC GEAR HOLDER ASSY
3UH2814001 1DC MOTOR ASSY 2 (SP)
4087320616 3TAPTITE, CUP S M3X6
5UH2238000 1GEAR 39
6UH2239000 1GEAR 20/50
7UH2240000 1GEAR 24/72
8UH2241000 1GEAR 22/55
9UH2242000 1GEAR 48
10 UH2243000 1GEAR 21
11 UH2244000 1GEAR 28
12 UH2245001 1GEAR 48 SPRING
13 026100136 1WASHER, PLAIN S 10
14 UH2255001 1PAPER DELIVERY GEAR ASSY
15 U74234001 4TAPTITE, CUP M4X5
16 UH2250001 1PAPER DELIVERY HOLDER SPRING
17 UH2252000 1SPACER 2
18 UH2254000 2SPACER 1
19 T31242001 2PCB SPACER F
20 UH2263001 1SCANNER FAN MOTOR
21 083313015 2TAPTITE, PAN B M3X30
22 087320616 1TAPTITE, CUP S M3X6
MODEL HL-1660e 54T-U03-500

10 .TRANSFER
54T-U03-600
11 .PAPER TRAY
54T-U03-650/651
1
2
3
1
23
4
6
1-10
88
5
9
10 7
MODEL HL-1660e
MODEL HL-1660e

10. TRANSFER
REF.NO. CODE Q'TY DESCRIPTION REMARK
1UH2787001 1TRANSFER BASE ASSY (SP)
2UH1834001 1TRANFER ROLLER A ASSY (SP)
3087321016 1TAPTITE, CUP S M3X10
MODEL HL-1660e 54T-U03-600
T/I NO. PR98174
11. PAPER TRAY
REF.NO. CODE Q'TY DESCRIPTION REMARK
1-10 UH2806001 1PAPER TRAY UNIT SO, USA (SP) GRAY1227
1-10 UH2799001 1PAPER TRAY UNIT S, EUR (SP) GRAY1227
1-10 UH2802001 1PAPER TRAY UNIT S, CAN (SP) GRAY1227
1UH2487001 1SEPARATION PAD ASSY T
2UH2841001 1SEPARATION PAD SPRING 200
3UH2360000 1ROLLER
4UH2459000 1ROLLER HOLDER
5UH2469000 1PAPER FRONT GUIDE, BLUE6155
6UH2463001 1GEAR 56T LINK
7UH2465001 1SIZE DRUM
8085310815 3TAPTITE, BIND B M3X8
9UH2472001 1TRAY GUIDE PLATE 1
10 UH2804001 1ADJUST KNOB STOPPER
MODEL HL-1660e 54T-U03-650/651

12 .PAPER FEEDER
54T-U03-630
110
3
36
37
5
6
7
9
14
17
18
19
20
21
22
23
25
26
24
27
31
28
29
1-35 30
11
11
11 12
13
8
15
4
13
1113
12
2
16
33
35
34
32
MODEL HL-1660e
T/I No. PR98202

12. PAPER FEEDER
REF.NO. CODE Q'TY DESCRIPTION REMARK
1-35 UH2824001 1PAPER FEED CHASSIS UNIT 2 (SP)
(WITH PCB/SW SPRING/SCREW)
1UH2357001 1PAPER FEED MOTOR ASSY
2087320616 2TAPTITE, CUP S M3X6
3UH2359000 1MP PAPER DETECTION ACTUATOR
4085310815 2TAPTITE, BIND B M3X8
5UH2362001 1PAPER PICK-UP ROLLER ASSY
6UH2364001 2PAPER PICK-UP ROLLER COLLAR
7UH2366000 2BEARING
8085320616 2TAPTITE, BIND S M3X6
9UH2416001 1PAPER FEED ROLLER ASSY 60
10 UH2367001 2PAPER FEED ROLLER ASSY 70
11 UL0633000 6WASHER, PLAIN
12 UH2366000 3BEARING
13 085320616 3TAPTITE, BIND S M3X6
14 UH2369001 2PAPER PICK-UP SOLENOID
15 085320416 2TAPTITE, BIND S M3X4
16 UH2428000 1BEARING CALLOR
17 UH2379000 1TRAY SENSOR HOLDER
18 UH2380000 1PE SENSOR ACTUATOR TRAY
19 UH2381000 1PE ACTUATOR LINK
20 UH2382000 1DU DETECTION ACTUATOR
21 UH2383000 1PE SENSOR ACTUATOR MP
22 UH2384000 1REGIST SENSOR ACTUATOR
23 UH2136001 1LATCH
24 UH2797000 1MP PAPER FEED GUIDE ASSY (SP)
25 UH2393001 1SEPARATION PAD ASSY
26 UH2433001 1SEPARATION PAD SPRING MP
27 UH2397001 1MP TRAY ASSY
28 UH2400000 1MP PE SUB ACTUATOR
29 UH2406000 1MP TRAY COVER
30 UH2407000 1MP EXTENSION TRAY
31 UH2823001 1SPACER
32 UH2401000 1MP PAPER GUIDE
33 UH2402000 1MP RELEASE PLATE
34 UH2403000 1MP RELEASE SUPPORTER
35 UH2404000 1MP SPRING
36 UH2821001 1PAPER PICK-UP ROLLER ASSY 3
37 UH2822001 2PAPER PICK-UP ROLLER COLLAR 30
MODEL HL-1660e 54T-U03-630
T/I NO. PR98202

13 .SCANNER
54T-U03-700
14 .FIXING UNIT, 120V/230V
54T-U03-770/771
3
1
3
2
4
7
1
2
2
9
3
4
5
6
7
10
94 B48K142-2
R1P2 41P1 2
1
R2
C
K
E
A
PH1
1-6
8
8
9
MODEL HL-1660e
MODEL HL-1660e
T/I NO. PR98054, PR98061

13. SCANNER
REF.NO. CODE Q'TY DESCRIPTION REMARK
1UH2815001 1SCANNER UNIT ASSY C (SP)
2UK2503000 1SCN FLAT CABLE 6P
3087321616 4TAPTITE, CUP S M3X16
4UK3254001 1POLYGON HARNESS 5P
MODEL HL-1660e 54T-U03-700
14. FIXING UNIT, 120V/230V
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1-6 UH2816001 1FIXING UNIT, 120V C (SP)
1-6 UH2817001 1FIXING UNIT, 230V C (SP)
1UH2793001 1HEAT ROLLER (SP)
2UH2608001 2RETAINING RING, 25
3UK2451001 1FIXING PCB ASSY B48K142-200
4085310815 1TAPTITE, BIND B M3X8
5UH2623001 1PAPER DELIVERY ACTUATOR
6UH2794001 1HALOGEN HEATER, 120V (SP)
6UH2795001 1HALOGEN HEATER, 230V (SP)
7087421015 2TAPTITE, CUP S M4X10
8UH2645001 2HEATER SUPPORT SPRING S
9UH2646001 2HEATER PRESS SPRING
10 UH2628001 1THERMISTOR ASSY PT7
MODEL HL-1660e 54T-U03-770/771
T/I NO. PR98054, PR98061

15 .DOCUMENTS
54T-U03-920
MODEL HL-1660e
5
4
7
6
8
T/I NO. PR98209 / PR98263 / PR98280 / PR98310
1
2
3
