Advanced User’s Guide
MFC-L8650CDW
DCP-L8400CDN
Version 0
CHN-ENG

i
User’s Guides and where do I find them?
Which Guide? What’s in it? Where is it?
Product Safety
Guide
Read this Guide first. Please read the Safety
Instructions before you set up your machine.
See this Guide for trademarks and legal
limitations.
For Chinese:
Printed / In the Box
For English:
(Windows®)
PDF file / CD-ROM / In the Box
(Macintosh)
PDF file / Brother Solutions
Center 1
Quick Setup Guide Follow the instructions for setting up your
machine and installing the drivers and
software for the operating system and
connection type you are using.
For Chinese:
Printed / In the Box
For English:
(Windows®)
PDF file / CD-ROM / In the Box
(Macintosh)
PDF file / Brother Solutions
Center 1
Basic User's Guide Learn the basic Fax (MFC models only),
Copy, Scan and Direct Print operations and
how to replace supplies. See
troubleshooting tips.
For Chinese:
Printed / In the Box
For English:
(Windows®)
PDF file / CD-ROM / In the Box
(Macintosh)
PDF file / Brother Solutions
Center 1
Advanced User's
Guide
Learn more advanced operations: Fax (MFC
models only), Copy, security features,
printing reports and performing routine
maintenance.
(Windows®)
PDF file / CD-ROM / In the Box
(Macintosh)
PDF file / Brother Solutions
Center 1
Software and
Network User's
Guide
This Guide provides instructions for
Scanning, Printing and other operations that
can be performed by connecting your
Brother machine to a computer. You can
also find useful information about using the
Brother ControlCenter utility, using your
machine in a network environment, and
frequently used terms.
(Windows®)
HTML file / CD-ROM / In the Box
(Macintosh)
HTML file / Brother Solutions
Center 1
Google Cloud Print
Guide
This Guide provides details on how to
configure your Brother machine to a Google
account and use Google Cloud Print™
services for printing over the Internet.
PDF file / Brother Solutions
Center 1

ii
1Visit http://solutions.brother.com/.
Mobile Print/Scan
Guide for Brother
iPrint&Scan
This Guide provides useful information
about printing from your mobile device and
scanning from your Brother machine to your
mobile device when connected on a Wi-Fi®
network.
PDF file / Brother Solutions
Center 1
Which Guide? What’s in it? Where is it?

iii
Table of Contents
1 General Setup 1
Memory storage.....................................................................................................1
Set tone or pulse dialling mode .............................................................................1
Set the Time Zone .................................................................................................2
Ecology features ....................................................................................................2
Toner Save ......................................................................................................2
Sleep Time ......................................................................................................3
Deep Sleep mode............................................................................................3
Auto Power Off (DCP models only) .................................................................3
Quiet mode feature ................................................................................................4
Quiet mode ......................................................................................................4
Touchscreen ..........................................................................................................4
Setting the backlight brightness.......................................................................4
Setting the Dim Timer for the backlight ...........................................................5
Dial Prefix (MFC models only) ...............................................................................5
Setting up the prefix number ...........................................................................5
Changing the prefix number ............................................................................6
Setting the Fax Logic (sending and receiving sequence) ......................................6
2 Security features 7
Secure Function Lock 3.0 ......................................................................................7
Before you begin to use Secure Function Lock 3.0 .........................................8
Turning Secure Function Lock on/off...............................................................8
Configure Secure Function Lock 3.0 Using Web Based Management ...........9
Setting up and changing the Public user mode .............................................10
Switching Users.............................................................................................10
Active Directory Authentication............................................................................11
Turning Active Directory Authentication Lock on/off......................................12
IPSec ...................................................................................................................12
Setting Lock .........................................................................................................13
Setting up the administrator password ..........................................................13
Changing the Setting Lock administrator password ......................................14
Turning Setting Lock on/off............................................................................14
Dial Restriction (MFC models only) .....................................................................15
Dial pad restriction.........................................................................................15
Address Book restriction................................................................................15
Shortcuts restriction .......................................................................................15
LDAP server restriction..................................................................................16

iv
3 Sending a fax (MFC models only) 17
Additional sending options................................................................................... 17
Sending faxes using multiple settings ........................................................... 17
Changing a 2-sided fax layout ...................................................................... 18
Contrast ......................................................................................................... 19
Changing Fax Resolution ..............................................................................19
Additional sending operations.............................................................................. 20
Sending a fax manually .................................................................................20
Dual access ................................................................................................... 20
Broadcasting..................................................................................................21
Real Time Transmission................................................................................ 23
Overseas Mode .............................................................................................23
Delayed Fax .................................................................................................. 24
Delayed batch transmission ..........................................................................24
Checking and cancelling waiting jobs............................................................25
Setting your changes as the new default.......................................................25
Restoring all fax settings to the factory settings ............................................ 26
Saving fax options as a Shortcut ...................................................................26
Electronic cover page ....................................................................................27
Destination Display........................................................................................29
4 Receiving a fax (MFC models only) 30
Memory Receive Options ....................................................................................30
Fax Forwarding..............................................................................................30
Fax Storage ................................................................................................... 31
Changing Memory Receive Options.............................................................. 31
Turning off Memory Receive Options ............................................................ 32
Remote retrieval ..................................................................................................33
Setting a Remote Access Code.....................................................................33
Using your Remote Access Code..................................................................33
Remote fax commands..................................................................................34
Retrieving fax messages ...............................................................................35
Changing the Fax Forwarding number ..........................................................35
Additional receiving operations............................................................................ 36
Printing a reduced incoming fax .................................................................... 36
2-sided printing for Fax mode........................................................................36
Setting the Fax Receive Stamp .....................................................................37
Printing a fax from the memory ..................................................................... 37
Out of Paper Reception .................................................................................37
5 Dialling and storing numbers (MFC models only) 38
Additional dialling operations ............................................................................... 38
Combining Address Book numbers ...............................................................38
Additional ways to store numbers........................................................................ 39
Storing Address Book numbers from Outgoing Calls .................................... 39
Setting up Groups for Broadcasting ..............................................................39

v
6 Printing reports 42
Fax reports (MFC models only) ...........................................................................42
Transmission Verification Report...................................................................42
Fax Journal (Activity Report) .........................................................................42
Reports ................................................................................................................43
How to print a report ......................................................................................43
7 Making copies 44
Copy settings .......................................................................................................44
Stop copying..................................................................................................44
Improving copy quality...................................................................................44
Enlarging or reducing copies .........................................................................45
2-sided Copying.............................................................................................46
Tray selection ................................................................................................48
Adjusting Density and Contrast .....................................................................48
Sorting copies................................................................................................49
Making N in 1 copies (page layout) ...............................................................50
2 in 1 ID Copy................................................................................................52
Adjusting the Colour Saturation.....................................................................53
Making 2-sided N in 1 copies (MFC-L8650CDW) .........................................53
Removing Background Colour.......................................................................54
Saving copy options as a Shortcut ................................................................55
Saving paper .................................................................................................55
A Routine maintenance 56
Checking the machine .........................................................................................56
Printing the Test Print ....................................................................................56
Checking the Page Counters.........................................................................56
Checking the remaining life of toner cartridges .............................................56
Checking the remaining life of parts ..............................................................56
Replacing periodic maintenance parts.................................................................57
Packing and shipping the machine ......................................................................58
B Options 61
Options ................................................................................................................61
Optional paper tray ..............................................................................................62
Memory board......................................................................................................62
SO-DIMM Types ............................................................................................62
Installing extra memory .................................................................................63
C Glossary 65
D Index 68

1
1
1
NOTE
• This manual shows the LCD messages of
the MFC-L8650CDW unless specified.
• Most of the illustrations in this User’s
Guide show the MFC-L8650CDW.
Memory storage 1
Your settings are stored permanently, and in
the event of a power failure will not be lost.
Temporary settings (for example, Contrast
and Overseas Mode 1) will be lost. Also,
during a power failure the machine will retain
the date and time and programmed fax timer
jobs (for example, Delayed Fax) 1for up to 60
hours. Other fax jobs in the machine’s
memory will not be lost 1.
1For MFC models only
Set tone or pulse
dialling mode 1
Your machine comes set for a Tone dialling
service. If you have a Pulse dialling (rotary)
service, you need to change the dialling
mode.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display Initial Setup.
Press Initial Setup.
dSwipe up or down, or press aor bto
display Tone/Pulse.
Press Tone/Pulse.
ePress Pulse (or Tone).
fPress .
General Setup 1

Chapter 1
2
Set the Time Zone 1
You can set the time zone (not summer time
but standard time) on the machine for your
location. For example, the time zone for
Eastern Time in the USA and Canada is
UTC-05:00.
aPress .
bPress (Date &
Time).
cPress Time Zone.
dEnter your time zone.
Press OK.
ePress .
Ecology features 1
Toner Save 1
You can save toner using this feature. When
you set Toner Save to On, print appears
lighter. The factory setting is Off.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display General Setup.
dPress General Setup.
eSwipe up or down, or press aor bto
display Ecology.
fPress Ecology.
gPress Toner Save.
hPress On or Off.
iPress .
NOTE
We do not recommend Toner Save for
printing Photo or Greyscale images.

General Setup
3
1
Sleep Time 1
The Sleep Time setting can reduce power
consumption. When the machine is in Sleep
mode (Power Save mode) it acts as though it
is turned off. The machine will wake up and
start printing when it receives a print job.
You can choose how long the machine must
be idle before it goes into Sleep mode. The
timer will restart if any operation is carried out
on the machine, such as receiving a fax 1or a
print job. The factory setting is three minutes.
When the machine goes into Sleep mode, the
Touchscreen backlight turns off.
1For MFC models only
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display General Setup.
dPress General Setup.
eSwipe up or down, or press aor bto
display Ecology.
fPress Ecology.
gPress Sleep Time.
hUsing the Touchscreen's keyboard,
enter the length of time (0-50 minutes)
the machine will remain idle before
entering Sleep mode.
Press OK.
iPress .
Deep Sleep mode 1
If the machine is in Sleep mode and does not
receive any jobs for a certain length of time,
the machine will go into Deep Sleep mode
automatically. Deep Sleep mode uses less
power than Sleep mode. The machine will
wake up when it receives a job or if you press
the Touchscreen.
When the machine is in Deep Sleep mode,
the Touchscreen backlight turns off and
blinks.
Auto Power Off (DCP models
only) 1
If the machine is in Deep Sleep mode for a
certain length of time, it will go into Power Off
mode automatically. To wake the machine
from Power Off mode, press on the
Touchpanel, and then send the print data.
You can choose how long the machine must
be in Deep Sleep mode before it goes into
Auto Power Off mode. The factory setting is
Off.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display General Setup.
dPress General Setup.
eSwipe up or down, or press aor bto
display Ecology.
fPress Ecology.
gPress Auto Power Off.
hSwipe up or down, or press aor bto
display a option you want. Press Off,
1hour, 2hours, 4hours or 8hours.
iPress .

Chapter 1
4
Quiet mode feature 1
Quiet mode 1
The Quiet mode setting can reduce noise
while printing. When Quiet Mode is turned On,
the print speed becomes slower. The factory
setting is Off.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display General Setup.
dPress General Setup.
eSwipe up or down, or press aor bto
display Ecology.
fPress Ecology.
gPress Quiet Mode.
hPress On or Off.
iPress .
Touchscreen 1
Setting the backlight
brightness 1
You can adjust the brightness of the
Touchscreen LCD backlight. If you are having
difficulty reading the Touchscreen, try
changing the brightness setting.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display General Setup.
dPress General Setup.
eSwipe up or down, or press aor bto
display LCD Settings.
fPress LCD Settings.
gPress Backlight.
hPress Light, Med or Dark.
iPress .

General Setup
5
1
Setting the Dim Timer for the
backlight 1
You can set how long the Touchscreen LCD
backlight stays on after you go back to your
Home screen.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display General Setup.
dPress General Setup.
eSwipe up or down, or press aor bto
display LCD Settings.
fPress LCD Settings.
gPress Dim Timer.
hPress Off, 10Secs, 20Secs or
30Secs.
iPress .
Dial Prefix
(MFC models only) 1
The Dial Prefix setting will automatically dial a
predefined number before every fax number
you dial. For example: If your telephone
system requires a 9 to dial an outside
number, use this setting to automatically dial
9 for every fax you send.
Setting up the prefix number 1
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display Initial Setup.
dPress Initial Setup.
eSwipe up or down, or press aor bto
display Dial Prefix.
fPress Dial Prefix.
gPress On (or Off).
hPress Dial Prefix.
iEnter the prefix number (up to 5 digits)
using the Touchscreen's keyboard.
Press OK.
NOTE
• You can use the numbers and symbols 0
to 9, #, and l. (You cannot use ! with any
other numbers or symbols.)
• If your telephone system requires a time
break recall (hookflash), press !on the
Touchscreen.
• If pulse dialing mode is on, # and lare not
available to use.
jPress .

Chapter 1
6
Changing the prefix number 1
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display Initial Setup.
dPress Initial Setup.
eSwipe up or down, or press aor bto
display Dial Prefix.
fPress Dial Prefix.
gPress On (or Off).
You can turn off the prefix number by
pressing Off. The prefix number will
remain off until you press On.
hPress Dial Prefix.
iDo one of the following using the
Touchscreen's keyboard.
To change the prefix number, press
dor cto position the cursor under the
digit to be deleted and press the
Back Space button . Then press
the correct digit.
Repeat until the prefix number is
correct, and then press OK.
To exit without making a change,
press OK.
NOTE
• You can use the numbers and symbols 0
to 9, #, and l. (You cannot use ! with any
other numbers or symbols.)
• If your telephone system requires a time
break recall (hookflash), press !on the
Touchscreen.
• If pulse dialing mode is on, # and lare not
available to use.
jPress .
Setting the Fax Logic
(sending and receiving
sequence) 1
You can change the process of manual fax
send or receive. If you often send or receive
a fax manually to/from the other party at the
end of a conversation, set the Fax Mode to
Easy Mode.
If you set to Easy Mode : You can send or
receive a fax manually just simply press
Fax
Start
. Make sure the other party's machine is
ready to send or receive a fax. If you are a caller,
press
Fax Start to send a fax. If you are a
receiver, press
Fax Start to receive a fax.
If you set to Advanced Mode : No matter you
are a caller or receiver, you can choose you will
send or receive a fax manually. When you press
Fax Start , the machine will ask you to
choose
Send or Receive . If you want to send
a fax, press
Send to send a fax. If you want to
receive a fax, press
Receive to receive a fax.
NOTE
Even if you set either Easy Mode or
Advanced Mode and if there is a
document in the ADF, the document in the
ADF will be sent by pressing Fax Start.
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display Fax.
dPress Fax.
eSwipe up or down, or press aor bto
display Miscellaneous.
fPress Miscellaneous.
gPress Fax Mode.
hPress Easy Mode or Advanced Mode.
iPress .

7
2
2
Secure Function Lock
3.0 2
Secure Function Lock lets you restrict Public
access to the following machine operations:
Fax TX (Fax Sending) 1
Fax RX (Fax Receiving) 1
Copy
Scan (Remote) 23
Scan (Direct) 34
USB Direct Print
Print 5
Color Print 56
Page Limits 6
1For MFC models only
2Scan except Scan to USB
3Scan includes scan jobs via Brother iPrint&Scan.
4Scan to USB
5Print and Color Print include print jobs via Google
Cloud Print™ and Brother iPrint&Scan.
6Available for Print, USB Direct Print, Copy.
This feature also prevents users from
changing the default settings of the machine
by limiting access to the machine’s settings.
Before using the security features you must
first enter an administrator password.
The administrator can set up restrictions for
individual users along with a user password.
Make a careful note of your password. If you
forget it, you will have to reset the password
stored in the machine. For information about
how to reset the password, contact Brother
customer service.
NOTE
• Secure Function Lock can be set by using
Web Based Management or BRAdmin
Professional 3 (Windows®only).
• Only administrators can set limitations
and make changes for each user.
Security features 2

Chapter 2
8
Before you begin to use
Secure Function Lock 3.0 2
You can configure the Secure Function Lock
settings using a web browser. Before
configuration, the following preparations are
needed.
aStart your web browser.
bType “vmachine’s IP address/” into
your browser’s address bar (where
“machine’s IP address” is the IP address
of the Brother machine).
For example:
v192.168.1.2/
NOTE
You can find the machine’s IP address in
the Network Configuration List
(see Software and Network User's Guide).
cType an Administrator password in the
Login box. (This is a password to log on
to the machine’s web page.) Click .
NOTE
If you are using a web browser to
configure the machine’s settings for the
first time, set a password (see
Software and Network User's Guide).
Turning Secure Function
Lock on/off 2
aClick Administrator.
bClick User Restriction Function.
cSelect Secure Function Lock or Off.
dClick Submit.
NOTE
The Secure Function Lock icon is
displayed beneath the time and date.

Security features
9
2
Configure Secure Function
Lock 3.0 Using Web Based
Management 2
Set up groups with restrictions and users with
a password. You can set up to 100 restricted
groups and 100 users. Configure these
settings using a web browser. To set up the
web page, see Before you begin to use
Secure Function Lock 3.0 on page 8. Then
follow these steps:
aClick Administrator.
bClick Restricted Functions xx-xx.
cType an alphanumeric Group name (up
to 7 characters for Chinese or 14
characters for alphanumeric) in the
User List / Restricted Functions field.
dIn the Print and other columns, clear the
check box to restrict access to
operations. To configure the maximum
page count, select the On check box in
Page Limits, and then type the number
in the Max. Pages box.
eClick Submit.
fClick User List xx-xx.
gIn the User List field, type the user
name up to 10 characters for Chinese or
20 characters for alphanumeric.
hIn the PIN Number box, type a four-digit
password.
iSelect User List / Restricted
Functions from the drop-down list for
each user.
jClick Submit.

Chapter 2
10
Setting up and changing the
Public user mode 2
Public user mode restricts the operations that
are available for all users who do not have a
password.
When you set up restrictions for Public users,
you must do it through Web Based
Management or BRAdmin Professional 3
(Windows®only) (see
Software and Network User's Guide).
aClick Administrator.
bClick Restricted Functions xx-xx.
cIn the Public Mode row, clear the check
box to restrict the operation in Public
user mode. To configure the maximum
page count, select the On check box in
Page Limits, and then type the number
in the Max. Pages box.
dClick Submit.
Switching Users 2
This setting allows you to switch between
registered restricted users or Public mode
when Secure Function Lock is turned on.
Changing to restricted user mode 2
aPress or
.
(Where xxxxx is the user’s name.)
bPress Change User.
cSwipe up or down, or press aor bto
display your user name.
dPress your user name.
eEnter your four-digit user password
using the Touchscreen's keyboard.
Press OK.
NOTE
• If the current ID is restricted for the
operation you want, Access Denied
appears on the Touchscreen.
• If your ID has page limit restrictions and
has already reached the maximum
number of pages, the Touchscreen
displays Limit Exceeded or No
Permission when you try to print.
Contact your administrator to check your
Secure Function Lock Settings.
• If your ID has Color Print restrictions set
to disabled, the Touchscreen displays No
Permission or Function Locked
when you try to print coloured documents.
Public
XXXXX

Security features
11
2
Changing to Public mode 2
aPress .
(Where xxxxx is the user’s name.)
bPress Go to Public.
NOTE
• After a restricted user has finished using
the machine, it returns to Public mode
after one minute.
• If the operation you want is restricted for all
users,
Access Denied will appear on the
Touchscreen and the Change User screen
will appear. You cannot access the
operation. Contact your administrator to
check your Secure Function Lock Settings.
•IfPublic Mode has Color Print
restrictions set to disabled, the
Touchscreen displays No Permission
or Function Locked when you try to
print coloured documents.
Active Directory
Authentication 2
Active Directory Authentication restricts the
use of the Brother machine. If Active
Directory Authentication is enabled, the
machine's control panel will be locked. The
machine's settings cannot be changed until
the user enters the user ID, domain name and
password.
Active Directory Authentication includes the
following features:
Store incoming faxes
Obtain the machine's email address from
the LDAP server
You can change the Active Directory
Authentication setting using Web Based
Management or BRAdmin Professional 3
(Windows®).
For more information about Active Directory
Authentication, see
Software and Network User's Guide.
XXXXX

Chapter 2
12
Turning Active Directory
Authentication Lock on/off 2
aStart your web browser.
bType “http://machine’s IP address/” into
your browser’s address bar (where
“machine’s IP address” is the IP address
of the Brother machine).
For example:
http://192.168.1.2/
cClick Administrator.
dClick User Restriction Function.
eSelect Active Directory
Authentication or Off.
fClick Submit.
NOTE
• You need to configure Active Directory
Server Settings to enable Active Directory
Authentication.
• Control Panel Lock is enabled if Active
Directory Server is correctly configured.
IPSec 2
IPsec (Internet Protocol Security) is a security
protocol that uses an optional Internet
Protocol function to prevent manipulation and
ensure the confidentiality of data transmitted
as IP packets. IPsec encrypts data carried
over the network, such as print jobs sent from
computers to a printer. Because the data is
encrypted at the network layer, applications
that use a higher-level protocol use IPsec
even if the user is not aware of its use.
IPsec supports the following operations:
IPsec transmissions
IPsec settings
For more information about IPsec,
see Software and Network User's Guide.

Security features
13
2
Setting Lock 2
Setting Lock lets you set a password to stop
other people from accidentally changing your
machine’s settings.
Make a careful note of your password. If you
forget it, you will have to reset the passwords
stored in the machine. Contact your
administrator or Brother customer service.
While the Setting Lock is On, you cannot
access the machine's settings.
(For MFC models only)
Machine settings cannot be changed through
the Remote Setup utility while Setting Lock is
On.
Setting up the administrator
password 2
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display General Setup.
dPress General Setup.
eSwipe up or down, or press aor bto
display Setting Lock.
fPress Setting Lock.
gEnter a four-digit number for the new
password using the Touchscreen's
keyboard.
Press OK.
hEnter the new password again when the
Touchscreen displays Verify:.
Press OK.
iPress .

Chapter 2
14
Changing the Setting Lock
administrator password 2
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display General Setup.
dPress General Setup.
eSwipe up or down, or press aor bto
display Setting Lock.
fPress Setting Lock.
gPress Set Password.
hEnter the old four-digit password using
the Touchscreen's keyboard.
Press OK.
iEnter a four-digit number for the new
password using the Touchscreen's
keyboard.
Press OK.
jRe-enter the new password again when
the Touchscreen displays Verify:.
Press OK.
kPress .
Turning Setting Lock on/off 2
If you enter the wrong password, the
Touchscreen displays Wrong Password.
Enter the correct password.
Turning Setting Lock on 2
aPress .
bPress All Settings.
cSwipe up or down, or press aor bto
display General Setup.
dPress General Setup.
eSwipe up or down, or press aor bto
display Setting Lock.
fPress Setting Lock.
gPress Lock OffOn.
hEnter the registered four-digit
administrator password using the
Touchscreen's keyboard.
Press OK.
Turning Setting Lock off 2
aPress
on the Touchscreen.
bEnter the registered four-digit
administrator password using the
Touchscreen's keyboard.
Press OK.
