Brother ImageCenter ADS-2000 Operating manual

1
Using the
documentation 1
Please read this booklet before attempting to
operate the machine, or before attempting any
maintenance. Failure to follow these
instructions may result in an increased risk of
personal injury or damage to property,
including through fire, electrical shock, burns
or suffocation.
Read all of the instructions. Save them for later
reference.
Symbols and conventions
used in the documentation 1
The following symbols and conventions are
used throughout the documentation.
Follow all warnings and instructions marked
on the machine.
Note
The illustrations in this guide show the
ADS-2000.
Product Safety Guide 1
ADS-2000 and ADS-2500W
WARNING
WARNING indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injuries.
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injuries.
Important
Important indicates a potentially hazardous
situation which, if not avoided, may result in
damage to property or loss of product
functionality.
Prohibition icons indicate actions
that must not be performed.
This icon indicates that flammable
sprays may not be used.
This icon indicates that organic
solvents such as alcohol and liquids
may not be used.
Electrical Hazard icons alert you to
possible electrical shock.
Fire Hazard icons alert you to the
possibility of fire.
Notes tell you how you should
respond to a situation that may arise
or give tips about how the operation
works with other features.
Bold Bold typeface identifies specific
keys on the machine’s control
panel or on the computer
screen.
Italics Italicized typeface emphasizes
an important point or refers you
to a related topic.
Courier
New
Text in Courier New font
identifies messages on the
LCD of the machine.
Version A
USA/CAN

2
Compilation and Publication 1
Under the supervision of Brother Industries, Ltd., this manual has been compiled and published,
covering the latest product descriptions and specifications.
The contents of this manual and the specifications of this product are subject to change without
notice.
Brother reserves the right to make changes without notice in the specifications and materials
contained herein and shall not be responsible for any damages (including consequential) caused
by reliance on the materials presented, including but not limited to typographical and other errors
relating to the publication.
Choosing a location 1
Put your machine on a flat, level, stable surface that is free of vibration and shocks, such as a
desk. Put the machine near a standard grounded electrical socket. Choose a location where the
temperature remains between 41F and 95F (5C and 35C) and the humidity is between 20%
to 80% (without condensation).
WARNING
DO NOT expose the machine to direct sunlight, excessive heat, open flames, corrosive gasses,
moisture or dust.
DO NOT place your machine on a carpet or rug, as this will expose it to dust. Doing so may
create a risk of an electrical short or fire. It may also damage the machine and/or render it
inoperable.

3
DO NOT place the machine near heaters, air conditioners, electric fans, refrigerators, radiators,
or water. Doing so may create the risk of a short circuit or fire should water come into contact
with the machine (including condensation from heating, air conditioning, and/or ventilation
equipment that may be sufficient to create a short circuit or fire).
DO NOT place the machine near chemicals or in a place where chemicals could be spilled on
it. Should chemicals come into contact with the machine, there may be a risk of fire or electric
shock. In particular, organic solvents or liquids such as benzene, paint thinner, polish remover,
or deodorizer may melt or dissolve the plastic cover and/or cables, resulting in a risk of fire or
electric shock. These or other chemicals may also cause the machine to malfunction or become
discolored.
The product should be placed so as not to come into contact with any wall or other device.
Otherwise, it could create a risk of overheating and/or fire.
Instead:
• Place the machine on a solid surface, never on a bed, sofa, rug, or other similar soft surface.
• Do not place this machine in a “built-in” installation unless adequate ventilation is provided.
CAUTION
Avoid placing your machine in a high-traffic area. If you must place it in a high-traffic area,
ensure that the machine is in a safe location where it cannot be accidentally knocked-over,
which could cause injury to you and serious damage to the machine.
Ensure that cables and cords leading to the machine are secured so as not to pose a tripping
hazard.
DO NOT place this machine on an unstable or tilted cart, stand, table or on any tilted/slanted
surface. The machine is heavy and may fall, causing injury to you and serious damage to the
machine.

4
Make sure that no part of the machine protrudes from the desk or stand where the machine is
located. In particular, do not leave the output tray open when the machine is located on the edge
of a table, stand, etc. Make sure that the machine is located on a flat, level, and stable surface
free from vibration. Failure to observe these precautions could cause the machine to fall,
causing injury to you and serious damage to the machine.
Important
• DO NOT place your machine next to sources of interference, such as speakers or the base
units of non-Brother cordless telephones. Doing so may interfere with the operation of the
machine's electronic components.
• DO NOT connect your machine to an AC power outlet controlled by wall switches or automatic
timers. Disruption of power can delete information from the machine's memory, and repeated
cycling of the power can damage the machine.

5
To use the machine safely 1
WARNING
ELECTRICAL HAZARDS
Failure to follow the warnings in this section may create the risk of an electrical shock. In
addition, you could create an electrical short, which may create the risk of a fire.
There are high-voltage electrodes inside the machine. Before you access the inside of the
machine, including for routine maintenance such as cleaning, make sure you have unplugged
the power cord from the AC power outlet, as well as any Ethernet (RJ-45) (ADS-2500W only)
cables from the machine.
DO NOT push objects of any kind into this machine through slots or openings in the cabinet, as
they may touch dangerous voltage points or short out parts.
DO NOT handle the plug with wet hands.
Always make sure the plug is fully inserted.
DO NOT use the machine or handle the cord if the cord has become worn or frayed. If
unplugging your machine, DO NOT touch the damaged/frayed part.

6
DO NOT continue using the machine if it has been dropped or the cabinet has been damaged.
Instead, unplug the machine from the power outlet and contact Brother Authorized Service
Personnel.
If water, other liquids, or metal objects get inside the machine, immediately unplug the machine
from the AC power outlet and contact Brother Authorized Service Personnel.
This machine should be connected to an AC power source within the range indicated on the
rating label. DO NOT connect it to a DC power source or inverter. Doing this might cause an
electrical shock. If you are not sure what kind of power source you have, contact a qualified
electrician.
Power Cord Safety:
• This machine is equipped with a 3-wire grounded plug. This plug will only fit into a grounded
power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, call
your electrician to replace your obsolete outlet. DO NOT defeat the purpose of the grounded
plug.
• Use only the power cord supplied with this product.
• DO NOT allow anything to rest on the power cord.
• DO NOT place this machine where people can walk on the cord.
• DO NOT place this machine in a position where the cord is stretched or strain is otherwise
put on the cord, as it may become worn or frayed.
• Brother strongly recommends that you DO NOT use any type of extension cord.
FIRE HAZARDS
Failure to follow the warnings in this section may create the risk of a fire.
DO NOT use flammable substances, any type of spray or an organic solvent/liquid that contains
alcohol or ammonia to clean the inside or outside of the machine. Doing this may cause a risk
of fire or electrical shock.

7
Do not disassemble or modify the machine, otherwise fire or electric shock may result. If the
machine requires repair, contact the place of purchase or Brother authorized service personnel.
DO NOT use this machine in the vicinity of combustible dust.
If the machine becomes hot, releases smoke, or generates any strong smells, immediately
unplug the machine from the AC power outlet. Call Brother Customer Service.
This product was packaged in a plastic bag. To avoid suffocation, keep such plastic bag away
from babies and children. Do not use the bag in cribs, beds, carriages or play pens. The bag
is not a toy.

8
CAUTION
DO NOT sit or stand on the machine or use it for any purpose beyond its intended purpose.
Wait until pages have exited the machine before picking them out. Otherwise, you could cause
injury to your fingers by trapping them in a roller.
DO NOT put your hands on the edge of the machine. Doing this may cause injury to your fingers
by pinching them.

9
DO NOT touch the shaded area shown below when the top cover is open. Doing this may cause
injury to your fingers by pinching them.
Be careful when touching the Separation Pad and its surrounding area in the machine.
Otherwise, you could cause injury to you and serious damage to the machine.

10
DO NOT carry the machine by holding the top cover. Doing this may cause the machine to slip
out of your hands. Only carry the machine by placing your hands under the entire machine.
Use caution when operating the machine to prevent clothing (particularly sleeves, neckties,
etc.), hair, or accessories from being drawn into the machine, otherwise injury may result. In the
event that an object is drawn into the machine, immediately disconnect the machine from the
power source.
Important
• Disruption of power can wipe out information in the machine’s memory.
• DO NOT put objects on top of the machine.
• If the machine does not operate normally when the operating instructions are followed, adjust
only those controls that are covered by the operating instructions. Improper adjustment of other
controls may result in damage or minor exposure to electromagnetic waves and will often
require extensive work by a qualified technician to restore the machine to normal operation.
• A distinct change in the machine’s performance may indicate a need for service.
• Lightning and power surges can damage this machine. We recommend that you use a quality
surge protection device on the AC power line and any Ethernet (RJ-45) (ADS-2500W only)
cable plugged into the machine, or that you unplug the cords during a lightning storm.
• (ADS-2500W only)
DO NOT touch the Touchscreen immediately after plugging in the power cord or turning on the
machine. Doing this may cause an error.

11
Important safety instructions 1
DO NOT attempt to service this machine yourself because opening or removing covers may
expose you to dangerous voltage points and other risks and may void your warranty. Refer all
servicing to a Brother Authorized Service Center. For the location of your nearest Brother
Authorized Service Center, please call:
In USA: 1-877-BROTHER (1-877-276-8437)
In Canada: 1-877-BROTHER

12
Regulation 1
WARNING
This product must be installed near an AC power outlet that is easily accessible. In case of an
emergency, you must unplug the power cord from the AC power outlet to shut off the power
completely.
Important
• Brother cannot accept any financial or other responsibilities that may be the result of your use
of this information, including direct, special or consequential damages. There are no
warranties extended or granted by this document.
• This machine has been certified to comply with FCC standards, which are applied to the USA
only.
Federal Communications Commission (FCC) Declaration of
Conformity (USA only) 1
declares, that the products
Product Name: ADS-2000 and ADS-2500W
comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Responsible Party: Brother International Corporation
100 Somerset Corporate Boulevard
Bridgewater, NJ 08807-0911 USA
TEL: [phone]

13
Consult the dealer or an experienced radio/TV technician for help.
(ADS-2500W only)
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
Important
• Changes or modifications not expressly approved by Brother Industries, Ltd. could void the
user’s authority to operate the equipment.
• A specific shielded interface cable should be used to ensure compliance with the limits for a
Class B digital device.
Industry Canada Compliance Statement (Canada only) 1
This Class B digital apparatus complies with Canadian ICES–003.
Cet appareil numérique de la classe B est conforme à la norme NMB–003 du Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of this device.
L'utilisation de ce dispositif est autorisée seulement aux conditions suivantes:
(1) il ne doit pas produire de brouillage et (2) l'utilisateur du dispositif doit être prêt à accepter tout
brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le
fonctionnement du dispositif.
For use in the USA or Canada only 1
These machines are made for use in the USA and Canada only. We cannot recommend using
them overseas because the power requirements of your machine may not be compatible with the
power available in foreign countries. Using USA or Canada models overseas is at your own risk
and may void your warranty.
LAN connection (ADS-2500W only) 1
Important
DO NOT connect this product to a LAN connection that is subject to over-voltages.

14
International ENERGY STAR®Qualification Statement
(ADS-2500W only) 1
The purpose of the International ENERGY STAR®Program is to promote the development and
popularization of energy-efficient equipment.
As an ENERGY STAR®Partner, Brother Industries, Ltd. has determined that this product meets
the ENERGY STAR®specifications for energy efficiency.

15
Trademarks 1
The Brother logo is a registered trademark of Brother Industries, Ltd.
Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United
States and/or other countries.
Microsoft, Windows, Windows Server, Outlook and Internet Explorer are either registered
trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
Apple, Macintosh, Mac OS and Safari are trademarks of Apple Inc., registered in the United States
and other countries.
Nuance, the Nuance logo, PaperPort and ScanSoft are trademarks or registered trademarks of
Nuance Communications, Inc. or its affiliates in the United States and/or other countries.
PowerPC is a registered trademark of IBM in the United States and/or other countries.
AOSS is a trademark of Buffalo Inc.
WPA, WPA2, Wi-Fi Protected Access and Wi-Fi Protected Setup are marks of the Wi-Fi Alliance.
Wi-Fi and Wi-Fi Alliance are registered marks of the Wi-Fi Alliance.
AMD is a trademark of Advanced Micro Devices, Inc.
Linux is the registered trademark of Linus Torvalds in the U.S. and other countries.
Android is a trademark of Google Inc.
ISIS is registered trademark of EMC Corporation.
Each company whose software title is mentioned in this manual has a Software License
Agreement specific to its proprietary programs.
Any trade names and product names of companies appearing on Brother products, related
documents and any other materials are all trademarks or registered trademarks of those
respective companies.
Open Source Licensing Remarks 1
This product includes open-source software.
To see the open source licensing remarks, please go to the manual download section on your
model’s home page of Brother Solutions Center at http://solutions.brother.com/.

16
Legal limitations for copying 1
Observe all copyright laws when using this product.
Color reproductions of certain documents are illegal and may result in either criminal or civil
liability. This memorandum is intended to be a guide rather than a complete listing of every
possible prohibition. In case of doubt, we suggest that you check with counsel as to any particular
questionable documents.
The following documents issued by the United States/Canadian Government or any of its
Agencies may not be copied:
Money
Bonds or other certificates of indebtedness
Certificates of Deposit
Internal Revenue Stamps (canceled or uncanceled)
Selective Service or draft papers
Passports
United States/Canadian Postage Stamps (canceled or uncanceled)
Food Stamps
Immigration Papers
Checks or drafts drawn by Governmental agencies
Identifying badges or insignias
Copyrighted works cannot be copied. Sections of a copyrighted work can be copied for 'fair use'.
Multiple copies would indicate improper use.
Works of art should be considered the equivalent of copyrighted works.

17
Notice Regarding the Faithful Reproduction of
Scanned Documents 1
After scanning a document, confirm that the accuracy and quality of the corresponding scan data
meets your needs by confirming the size of the scan data, the amount of image data captured,
image fidelity, color tones, etc.
Always confirm the scan data before destroying the original document.
It is possible that a portion of the scan data may be lost or damaged, therefore, read all instructions
carefully and keep the following in mind.
Depending on the condition of the document, the document may become worn thin, distorted,
dirty, or cracked during scanning. In this case, some or all of the scan data may be lost.
Confirm that the document has no wrinkles, bends, or holes.
If the inside of the machine is dirty, the document may become worn thin, distorted, dirty, or
cracked during scanning. In this case, some or all of the scan data may be lost.
Clean the inside of the machine carefully and regularly.
The following may occur depending on the scan settings, such as document size, scanning
resolution, color-related settings, single-side or double-side scanning settings, auto deskew,
blank page skip, etc.
• Text may be illegible or unclear if image resolution is too low.
• Scan data of a color document may be captured in black-and-white.
• Only one side of a two-sided document may be captured.
• A portion of the document may not be scanned, or the size may be too small.
• The document may only be scanned up to a certain point, after which scan data will be lost.
• Blank pages may not be deleted, or pages may be deleted unnecessarily.
• Margins may be added to the edges of the scan data.
Refer to the User’s Guide for information about how to configure the scan settings.
Depending on the condition of the document (such as if it has wrinkles, bends, or holes) and
consumables, multiple pages of a document may be fed at once, causing some pages to be
missing from the scanned data.
Confirm that the document has no wrinkles, bends, or holes.
Replace all consumables periodically.
When scanning documents that are not within the recommended guidelines, or depending on
the condition of the document (such as if it has wrinkles, bends, or holes), consumables, or the
paper feeding mechanisms inside the machine, documents may become jammed inside the
machine during scanning. In this case, some or all of the scan data may be lost. (Documents
may be destroyed as a result of a paper jam.)
Refer to “Acceptable Documents” in the User’s Guide for information about acceptable
documents.

18
When scanning documents that have been marked with a fluorescent marker, marked areas
may not be seen properly in the scan data, or the marker color may not be reproduced properly,
depending on the color and density of the marker ink.
You may achieve more desireable results by increasing the scanning resolution. Refer to the
User’s Guide for information about resolution settings.

www.brotherearth.com
