Brother ImageCenter ADS-3600W User manual

Confidential
Brother Advanced Document Scanner
SERVICE MANUAL
Read this manual thoroughly before maintenance work.
Keep this manual in a convenient place for quick and easy reference at all times.
Nov., 2015
SM-PT084
(2)
MODEL:
ADS-2800W/3600W

Confidential
© Copyright Brother 2015
All rights reserved.
No part of this publication may be reproduced in any form or by any means without permission in writing
from the publisher.
All other product and company names mentioned in this manual are trademarks or registered
trademarks of their respective holders.
Specifications are subject to change without notice.

Confidential
TRADEMARKS
BROTHER is either a trademark or a registered trademark of Brother Industries, Ltd.
Microsoft, Windows, Windows Vista, Windows Server, Outlook and Internet Explorer are either
registered trademarks or trademarks of Microsoft Corporation in the United States and/or other
countries.
Apple, Macintosh, Mac OS and Safari are trademarks of Apple Inc., registered in the United States and
other countries.
Nuance, the Nuance logo, PaperPort and ScanSoft are trademarks or registered trademarks of Nuance
Communications, Inc. or its affiliates in the United States and/or other countries.
PowerPC is a registered trademark of IBM in the United States and/or other countries.
WPA, WPA2, Wi-Fi Protected Access and Wi-Fi Protected Setup are marks of the Wi-Fi Alliance.
Wi-Fi, Wi-Fi Alliance and Wi-Fi Direct are registered marks of the Wi-Fi Alliance.
AMD is a trademark of Advanced Micro Devices, Inc.
ISIS, Captiva and QuickScan are either registered trademarks or trademarks of EMC Corporation in the
United States and/or other countries.
Intel is a trademark of Intel Corporation in the U.S. and/or other countries.
Adobe and Photoshop are either registered trademarks or trademarks of Adobe Systems Incorporated
in the United States and/or other countries.
Each company whose software title is mentioned in this manual has a Software License Agreement
specific to its proprietary programs.
Any trade names and product names of companies appearing on Brother products, related
documents and any other materials are all trademarks or registered trademarks of those
respective companies.
Compilation and Publication
Under the supervision of Brother Industries, Ltd., this manual has been compiled and published,
covering the latest product descriptions and specifications.
The contents of this manual and the specifications of this product are subject to change without notice.
Brother reserves the right to make changes without notice in the specifications and materials contained
herein and shall not be responsible for any damages (including consequential) caused by reliance on
the materials presented, including but not limited to typographical and other errors relating to the
publication.
Copyright and License
© 2015 Brother Industries, Ltd. All rights reserved.
This product includes software developed by the following vendors:
© 2008 Devicescape Software, Inc.
This product includes the “KASAGO TCP/IP” software developed by ZUKEN ELMIC,Inc.

iConfidential
CONTENTS
SAFETY INFORMATION............................................................................................ v
CHAPTER 1 SUPPLEMENTAL SPECIFICATIONS
1. GENERAL .................................................................................................................................... 1-1
2. NETWORK CONNECTIVITY........................................................................................................ 1-3
3. SERVICE INFORMATION............................................................................................................ 1-3
4. CONSUMABLE PARTS ............................................................................................................... 1-3
5. PAPER ......................................................................................................................................... 1-4
5.1 Paper Handling .................................................................................................................... 1-4
5.2 Media Specifications............................................................................................................ 1-4
6. SCANNER .................................................................................................................................... 1-5
CHAPTER 2 ERROR INDICATIONS & TROUBLESHOOTING
1. INTRODUCTION .......................................................................................................................... 2-1
1.1 Precautions.......................................................................................................................... 2-1
1.2 Checks before Commencing Troubleshooting..................................................................... 2-2
2. OVERVIEW .................................................................................................................................. 2-3
2.1 Cross-section Drawing......................................................................................................... 2-3
2.2 Paper Feeding ..................................................................................................................... 2-4
2.3 Operation of Each Part ........................................................................................................ 2-5
2.4 Block Diagram ..................................................................................................................... 2-6
2.5 Main Components................................................................................................................ 2-7
3. ERROR INDICATIONS................................................................................................................. 2-8
3.1 Error Codes ......................................................................................................................... 2-8
3.2 Error Messages ................................................................................................................. 2-13
4. TROUBLESHOOTING ............................................................................................................... 2-14
4.1 Error Cause and Remedy .................................................................................................. 2-14
4.2 Troubleshooting for Image Defects.................................................................................... 2-18
4.2.1 Defect examples.................................................................................................... 2-18
4.2.2 Troubleshooting according to image defect .......................................................... 2-18
4.3 Troubleshooting for Document Paper Feeding Problems.................................................. 2-22
4.3.1 No document is fed ............................................................................................... 2-22
4.3.2 Multiple documents are fed ................................................................................... 2-22
4.3.3 Document becomes jammed................................................................................. 2-23
4.3.4 Document becomes wrinkled ................................................................................ 2-23
4.4 Troubleshooting for Software Problems ............................................................................ 2-24

ii Confidential
4.4.1 Does not respond to operation from a computer ................................................... 2-24
4.4.2 Cannot read data .................................................................................................. 2-24
4.5 Troubleshooting for Control Panel Problems..................................................................... 2-25
4.5.1 Nothing is displayed on the LCD ........................................................................... 2-25
4.5.2 Control panel is inoperable.................................................................................... 2-25
4.6 Troubleshooting for Network Problems ............................................................................. 2-26
4.6.1 Cannot scan via network connection..................................................................... 2-26
4.6.2 Cannot connect to access point ............................................................................ 2-26
4.7 Troubleshooting for Other Problems.................................................................................. 2-27
4.7.1 Machine does not turn ON .................................................................................... 2-27
4.7.2 Cannot update firmware ........................................................................................ 2-27
4.7.3 Cannot save data in USB flash memory ............................................................... 2-27
4.7.4 USB device connection error................................................................................. 2-27
4.7.5 Cannot register...................................................................................................... 2-28
4.7.6 Counter does not reset even the consumable part has been replaced................. 2-28
4.7.7 Installation using USB flash memory is not operable ............................................ 2-28
CHAPTER 3 DISASSEMBLY/REASSEMBLY
1. SAFETY PRECAUTIONS............................................................................................................. 3-1
2. PACKING ..................................................................................................................................... 3-2
3. SCREW CATALOGUE................................................................................................................. 3-3
4. SCREW TORQUE LIST ............................................................................................................... 3-4
5. LUBRICATION ............................................................................................................................. 3-5
6. OVERVIEW OF GEARS............................................................................................................... 3-6
7. HARNESS ROUTING................................................................................................................... 3-7
8. DISASSEMBLY FLOW CHART................................................................................................. 3-10
9. DISASSEMBLY PROCEDURE .................................................................................................. 3-11
9.1 Reverse roller / Pick up roller............................................................................................. 3-12
9.2 Bottom cover ASSY / Exit stopper..................................................................................... 3-14
9.3 Back cover ......................................................................................................................... 3-15
9.4 Side cover L/R ................................................................................................................... 3-17
9.5 Wireless LAN PCB ASSY.................................................................................................. 3-19
9.6 USB host PCB ASSY......................................................................................................... 3-20
9.7 Main PCB ASSY................................................................................................................ 3-21
9.8 Front cover L/R .................................................................................................................. 3-28
9.9 Front cover ASSY .............................................................................................................. 3-30
9.10 Panel unit / Panel flat cable / Panel PCB / LCD / Touch panel unit / NFC PCB ASSY ..... 3-31
9.11 Second side CIS unit / Second side CIS flat cable / Flat cable support film...................... 3-36
9.12 Eject jam sensor PCB........................................................................................................ 3-38
9.13 Document scanning position sensor PCB ......................................................................... 3-39

iii Confidential
9.14 Paper feed jam sensor PCB / Multi feeding sensor PCB ASSY (Sent) ............................. 3-42
9.15 Document detection sensor PCB ASSY ............................................................................ 3-44
9.16 First side CIS unit / First side CIS flat cable ...................................................................... 3-45
9.17 Front cover sensor............................................................................................................. 3-47
9.18 Feed belt / Feed motor ...................................................................................................... 3-48
9.19 Paper feed belt / Paper feed motor.................................................................................... 3-50
9.20 Multi feeding sensor PCB ASSY (Receive) ....................................................................... 3-52
CHAPTER 4 ADJUSTING AND UPDATING SETTINGS
AS REQUIRED AFTER PARTS REPLACEMENT
1. IF YOU REPLACE THE MAIN PCB ASSY .................................................................................. 4-1
1.1 Installing Firmware (Sub3 Firm / Main Firm)........................................................................ 4-2
1.1.1 Checking firmware version ...................................................................................... 4-2
1.1.2 Installing firmware ................................................................................................... 4-3
1.2 Adjust Touch Panel.............................................................................................................. 4-5
1.3 Setting by Country ............................................................................................................... 4-5
1.4 Initializing the EEPROM of the Main PCB ASSY................................................................. 4-5
1.5 Setting Serial Number.......................................................................................................... 4-6
1.6 Setting Multi Feeding Sensor Threshold.............................................................................. 4-7
1.7 Check Sensor Operation ..................................................................................................... 4-8
1.8 Check Multi Feeding Operation ........................................................................................... 4-8
1.9 Checking Operation after Repair ......................................................................................... 4-9
1.10 Resetting to Factory Shipping State .................................................................................. 4-10
2. IF YOU REPLACE THE CIS UNIT ............................................................................................. 4-11
2.1 Acquire White Level Data and Set CIS Scan Area............................................................ 4-11
2.2 Checking Operation after Repair ....................................................................................... 4-13
3. IF YOU REPLACE THE MULTI FEEDING SENSOR ................................................................ 4-15
3.1 Setting Multi Feeding Sensor Threshold............................................................................ 4-15
3.2 Check Multi Feeding Operation ......................................................................................... 4-17
3.3 Checking Multi Feeding Sensor Operation ........................................................................ 4-17
4. IF YOU REPLACE THE PANEL ASSY...................................................................................... 4-18
4.1 Adjusting Touch Panel....................................................................................................... 4-18
4.2 Checking LCD Operation................................................................................................... 4-19
4.3 Checking Control Panel Operation .................................................................................... 4-20
5. IF YOU REPLACE THE PICK UP ROLLER / REVERSE ROLLER .......................................... 4-21
5.1 Resetting Pick Up Roller / Reverse Roller Counters ......................................................... 4-21
CHAPTER 5 SERVICE FUNCTIONS
1. MAINTENANCE MODE................................................................................................................ 5-1
1.1 How to Enter Maintenance Mode ........................................................................................ 5-1

iv Confidential
1.1.1 Method of entering maintenance mode for service personnel ................................ 5-1
1.1.2 Method of entering end-user accessible maintenance mode.................................. 5-2
1.2 List of Maintenance Mode Functions ................................................................................... 5-3
1.3 Details of Maintenance Mode Functions.............................................................................. 5-4
1.3.1 Initialize EEPROM parameters (function code: 01, 91)........................................... 5-4
1.3.2 ADF performance test (function code: 08) .............................................................. 5-5
1.3.3 Set worker switches (WSW) (function code: 10) ..................................................... 5-6
1.3.4 Check LCD operation (function code: 12) ............................................................... 5-7
1.3.5 Check control panel key operation (function code: 13) ........................................... 5-8
1.3.6 Save NetConfig data (function code: 18) ................................................................ 5-8
1.3.7 Display software version (function code: 25)........................................................... 5-9
1.3.8 Acquire machine log information (function code: 31) ............................................ 5-10
1.3.9 Check sensor operation (function code: 32).......................................................... 5-11
1.3.10 Change USB No. return value (function code: 45) ................................................ 5-12
1.3.11 Fine-tune scanning position (function code: 54).................................................... 5-13
1.3.12 Acquire white level data and set CIS scan area (function code: 55) ..................... 5-14
1.3.13 Adjust touch panel (function code: 61) .................................................................. 5-16
1.3.14 Setting by country (function code: 74)................................................................... 5-17
1.3.15 Display machine log information (function code: 80)............................................. 5-18
1.3.16 Display machine error code (function code: 82).................................................... 5-19
1.3.17 Quit maintenance mode (function code: 99) ......................................................... 5-19
CHAPTER 6 WIRING DIAGRAM
1. WIRING DIAGRAM ...................................................................................................................... 6-1
CHAPTER 7 PERIODICAL MAINTENANCE
1. PERIODICAL MAINTENANCE PARTS ....................................................................................... 7-1
APPENDIX 1 SERIAL NUMBERING SYSTEM
APPENDIX 2 DELETING USER SETTING INFORMATION
APPENDIX 3 INSTALLING THE MAINTENANCE PRINTER DRIVER

vConfidential
SAFETY INFORMATION
WARNING
WARNING indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injuries.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injuries.
Important
Important indicates a potentially hazardous situation which, if not avoided, may result in
damage to property or loss of product functionality.
Prohibition icons indicate actions that must not be performed.
Electrical Hazard icons alert you to possible electrical shock.
Fire Hazard icons alert you to the possibility of fire.
Unplug icons indicate that you should unplug the machine.
Note Notes indicates advice about how you should respond to a situation that may arise
with your machine and/or advice about how the operation of the machine works with
other features.
This icon indicates that flammable sprays may not be used.
This icon indicates that organic solvents such as alcohol and liquids may not be used.
Follow all warnings and instructions marked on the machine.

vi Confidential
To use the Machine Safely
Please keep these instructions for later reference and read them before attempting any
maintenance. If you do not follow these safety instructions, there is a possibility of a fire,
electrical shock, burn or suffocation.
WARNING
DO NOT expose the machine to direct sunlight, excessive heat, open flames,
corrosive gasses, moisture or dust.
DO NOT place your machine on a carpet or rug, as this will expose it to dust. Doing
so may create a risk of an electrical short or fire. It may also damage the machine
and/or render it inoperable.
DO NOT place the machine near heaters, air conditioners, electric fans, refrigerators,
radiators, or water. Doing so may create the risk of a electrical short or fire should
water come into contact with the machine (including condensation from heating, air
conditioning, and/or ventilation equipment that may be sufficient to create a electrical
shock, short circuit or fire).
DO NOT place the machine near chemicals or in a place where chemicals could be
spilled on it. Should chemicals come into contact with the machine, there may be a
risk of fire or electric shock. In particular, organic solvents or liquids such as benzene,
paint thinner, polish remover, or deodorizer may melt or dissolve the plastic cover
and/or cables, resulting in a risk of fire or electric shock. These or other chemicals
may also cause the machine to malfunction or become discolored.
The product should be placed so as not to come into contact with any wall or other
device. Otherwise, it could create a risk of overheating and/or fire.
Instead:
• Place the machine on a solid surface, never on a bed, sofa, rug, or other similar soft
surface.
• Do not place this machine in a “built-in” installation unless adequate ventilation is
provided.
Slots and openings in the casing, back or bottom of the product are provided for
ventilation. To avoid blocking or covering these openings, the product should be
placed where it will not touch any wall or other device. Blocking the unit's ventilation
could create a risk of overheating and/or fire.
IMPORTANT
• Always place the unit on a solid surface, never on a bed, sofa, rug, or similar soft
surfaces.
• DO NOT place the unit in a "built-in" installation.
CAUTION
Avoid placing your machine in a high-traffic area. If you must place it in a high-traffic
area, ensure that the machine is in a safe location where it cannot be accidentally
knocked-over, which could cause injury to you or others and serious damage to the
machine.

vii Confidential
Ensure that cables and cords leading to the machine are secured so as not to pose a
tripping hazard.
DO NOT place this machine on an unstable or tilted cart, stand, table or on any tilted/
slanted surface. The machine is heavy and may fall, causing injury to you and serious
damage to the machine.
Make sure that no part of the machine protrudes from the desk or stand where the
machine is located. In particular, do not leave the output tray open and extended
beyond the edge of a cabinet, table or stand when the machine is located on the edge
of a cabinet, table, stand, etc. As previously cautioned, make sure that the machine is
located on a flat, level, and stable surface free from vibration. Failure to observe these
precautions could cause the machine to fall, causing injury to you or others and
serious damage to the machine.
Important
• DO NOT place your machine next to sources of interference, such as speakers or
the base units of non-Brother cordless telephones. Doing so may interfere with the
operation of the machine's electronic components.
• DO NOT connect your machine to an AC power outlet controlled by wall switches or
automatic timers. Disruption of power can delete information from the machine's
memory, and repeated cycling of the power can damage the machine.
• DO NOT put objects on top of the unit.
WARNING
ELECTRICAL HAZARDS
Failure to follow the warnings in this section may create the risk of an electrical shock.
In addition, you could create an electrical short, which may create the risk of a fire.

viii Confidential
There are high-voltage electrodes inside the machine. Before you access the inside
of the machine, including for routine maintenance such as cleaning, make sure you
have unplugged the power cord from the AC power outlet, as well as unplugged any
Ethernet ables from the machine.
DO NOT push objects of any kind into the machine through slots or openings in the
casing, as they may touch dangerous voltage points or short out parts.
DO NOT continue using the machine if it has been dropped or the cabinet has been
damaged. Instead, unplug the machine from the power outlet and contact Brother
Authorized Service Personnel.
The machine should be connected to an AC power source within the range indicated
on the rating label. DO NOT connect it to a DC power source or inverter. Doing this
might cause an electrical shock or fire. If you are not sure what kind of power source
you have, contact a qualified electrician.
If water, other liquids, or metal objects get inside the machine, immediately unplug the
machine from the AC power outlet and contact Brother Authorized Service Personnel.
Power Cord Safety:
• Use only the power cord supplied with this product.
• DO NOT allow anything to rest on the power cord.
• DO NOT place the machine where people can walk on the cord.
• DO NOT place the machine in a position where the cord is stretched or strain is
otherwise put on the cord, as it may become worn or frayed.
• DO NOT use the machine or handle the cord if the cord has become worn or frayed.
If unplugging the machine, DO NOT touch the damaged/frayed part.
• Brother strongly recommends that you DO NOT use any type of extension cord.
This product was packaged in a plastic bag. To avoid suffocation, keep this plastic
bag away from babies and children. Do not use the bag in cribs, beds, carriages or
play pens. The bag is not a toy.
AC Adapter Safety
Only use the supplied AC adapter with the unit. Only plug the AC adapter into a power
outlet with voltage that is within the range indicated on Specifications in the User’s
Guide. Failure to do so may result in injury to yourself or others, or damage to the
machine or other property. Brother does not assume any responsibility for any
damage resulting from using an AC adapter other than the one specified.

ix Confidential
DO NOT use the unit near any liquids, for example, near a bath tub, wash bowl,
kitchen sink or washing machine, in a wet basement or near a swimming pool.
DO NOT use a damaged AC adapter.
DO NOT place heavy objects on, damage, or modify the AC adapter.
DO NOT forcibly bend the cord of the AC adapter.
DO NOT forcibly pull the cord of the AC adapter.
DO NOT drop, hit, or otherwise damage the AC adapter.
DO NOT touch the unit during a thunderstorm when the AC adapter is plugged in.
There may be a remote risk of electric shock from lightning when the machine is used
during a thunderstorm.
When disconnecting the AC adapter from the machine or from the power outlet,
always hold the connector, not the cable, and pull firmly. Failure to do so may result in
exposed or broken power cord wires and/or create a risk of fire, or electric shock.
Make sure that one end of the power cord is firmly plugged into a standard power
outlet and the other end is firmly plugged into the adapter block. Do not use an outlet
that is loose. If the power cord is not completely plugged into the power outlet and
adapter block, the adapter may become hot and/or catch fire.
DO NOT exceed the rated input or output of the AC adapter.
DO NOT connect the supplied AC adapter to other products.

xConfidential
Never insert any objects into the slots in the machine’s casing, since they may touch
dangerous voltage points or short out parts resulting in the risk of fire or electric
shock.
FIRE HAZARDS
Failure to follow the warnings in this section may create the risk of a fire.
DO NOT use flammable substances, any type of spray or an organic solvent/liquid
that contains alcohol or ammonia to clean the inside or outside of the machine. Doing
this may cause a risk of fire or electrical shock. Please use a dry cloth to clean the
unit.
Do not disassemble or modify the machine, otherwise fire or electric shock may
result. If the machine requires repair, contact the place of purchase or Brother
Authorized Service Personnel.
If the machine becomes hot, releases smoke, or generates any strong or unusual
odors, immediately unplug the machine from the power outlet and call Brother
Customer Service.
DO NOT handle the plug with wet hands.
CAUTION
DO NOT put pressure or weight on the unit or use it for any purpose beyond its
intended purpose.
To avoid cutting yourself, do not slide or scrape your hand or fingers along the edge of
the Carrier Sheet.
Wait until the machine ejects the pages to avoid trapping your fingers in the rollers.

xi Confidential
Some areas of the machine can cause injury if covers (shaded) are closed with force.
Take care when placing your hand in the areas shown in the illustrations.
DO NOT carry the machine by holding the Extendable Automatic Document Feeder
(ADF). Doing this may cause the Extendable Automatic Document Feeder (ADF) to
detach from the machine. Only carry the machine by placing your hands under the
entire machine.
Use caution when operating the machine to prevent clothing (particularly sleeves,
neckties, etc.), hair, or accessories from being drawn into the machine, otherwise an
injury may occur. In the event that an object is drawn into the machine, immediately
disconnect the unit from the power source.
DO NOT swing the AC adapter around or play with it. Doing so may result in injury to
yourself or others.
IMPORTANT
(ADS-2800W, ADS-3600W only)
DO NOT touch the Touchscreen immediately after plugging in the power cord or
turning the machine on. Doing this may cause an error.
Use caution when operating the machine to prevent clothing (particularly sleeves,
neckties, etc.), hair, or accessories from being drawn into the machine, otherwise
injury may result. In the event that an object is drawn into the machine, immediately
disconnect the machine from the power source.

xii Confidential
Important
• Disruption of power can wipe out information in the machine’s memory.
• DO NOT put objects on top of the unit.
• If the machine does not operate normally when the operating instructions are
followed, adjust only those controls that are covered by the operating instructions.
Improper adjustment of other controls may result in damage or minor exposure to
electromagnetic waves and will often require extensive work by a qualified
technician to restore the machine to normal operation.
• A distinct change in the machine’s performance may indicate a need for service.
• (ADS-2800W, ADS-3600W only)
DO NOT touch the Touchscreen while the machine is booting up. Doing this may
cause an error.
Important safety instructions
DO NOT attempt to service the unit yourself because disassembling the unit may
expose you to dangerous voltage points and other risks and may void your warranty.
Refer all servicing to a Brother Authorized Service Center. For the location of your
nearest Brother Authorized Service Center, please call:
In USA: 1-877-BROTHER (1-877-276-8437)

1-1 Confidential
CHAPTER 1 SUPPLEMENTAL
SPECIFICATIONS
1. GENERAL
Specifications are subject to change without notice.
Part ADS-2800W ADS-3600W
Scanning Method Dual CIS
Resolution From ADF
(Optical)
Max 600 x 600 dpi
Resolution (Interpolated) Max 1200 x 1200 dpi
Scanning
Speed
One-sided
monochrome
30 ppm 300 dpi
(2.0 seconds (A4/LTR))
50 ppm 300 dpi
(1.2 seconds (A4/LTR))
One-sided
Color
30 ppm 300 dpi
(2.0 seconds (A4/LTR))
50 ppm 300 dpi
(1.2 seconds (A4/LTR))
Two-sided
monochrome
60 ipm (30 ppm) 300 dpi
(60 image per min.)
(2.0 seconds (A4/LTR))
100 ipm (50 ppm) 300 dpi
(100 image per min.)
(1.2 seconds (A4/LTR))
Two-sided
Color
60 ipm (30 ppm) 300 dpi
(2.0 seconds (A4/LTR))
100 ipm (50 ppm) 300 dpi
(1.2 seconds (A4/LTR))
CPU Cortex-A9 800 MHz
Memory 512 MB
Interface USB Hi-Speed 2.0,
10Base-T/100Base-TX/
1000Base-T
USB Super-Speed 3.0,
10Base-T/100Base-TX/
1000Base-T
Power
consumption
Scanning Approx. 27 W Approx. 30 W
Ready Approx. 3.7 W Approx. 4.9 W
Sleep Approx. 1.9 W Approx. 2.9 W
Power off Approx. 0.12 W Approx. 0.12 W
Noise level Sound
power
Scanning 62.8 dB 63.9 dB
Environment Temperature Operating: 5 to 35
°C
Storage: 0 to 40 °C
Humidity Operating: 20 to 80%
Storage: 10 to 90% (without condensation)
Dimensions
(WxDxH)
Carton Size 382 x 254 x 330 mm
Machine Size 306 x 258 x 250 mm
Weights Machine Weight 4.55 kg
with Carton US/CAN/GER/ASA/JPN: 6.2 kg
UK/PAN-NOR/CEE-GEN: 6.3 kg
LCD LCD Type/Size 3.7 inch 93.4 mm TFT
Touch panel 3.7 inch TP

1-2 Confidential
<Computer requirements>
Specifications are subject to change without notice.
Computer Platform &
Operating System Version
Supported
PC
Software
Functions
PC Interface
Processor
Minimum
Speed
Hard Disk Space
to install
For
Drivers
For
Applications
Windows®
Operating
System
Windows®XP
Home *2
Windows®XP
Professional
(only 32 bit) *2
Scanning USB *1
10/100/1000
Base-TX
(Ethernet)
802.11 b/g/n
(Wireless)
Intel®
Pentium®II
or
equivalent
150 MB 1 GB
Windows
Vista® *2 Intel®
Pentium®4
or
equivalent
64-bit
(Intel®64 or
AMD 64)
supported
CPU
500 MB
Windows®7 *2 650 MB
Windows®8
Windows®8.1
Windows
Server®2003
(only 32 bit)
Windows
Server®2008
Windows
Server®2008
R2
Windows
Server®2012
Windows
Server®2012
R2 *3
Macintosh
Operating
System
OS X v10.8.5 Intel®
Processor
80 MB 1 GB
OS X v10.9.x
OS X v10.10.x
*1 Third-party USB ports are not supported.
*2 NuanceTM Paper portTM 12SE supports Windows®XP Home (SP3 or greater),
XP Professional (SP3 or greater), Windows Vista®(SP2 or greater) and Windows® 7.
*3 Server OS is supported Scanner Driver Only.

1-3 Confidential
2. NETWORK CONNECTIVITY
Specifications are subject to change without notice.
3. SERVICE INFORMATION
Specifications are subject to change without notice.
4. CONSUMABLE PARTS
Specifications are subject to change without notice.
Part All Models
Wired
network
Network node
type
NC-04h
Network type 10Base-T/100Base-TX/1000Base-T
Network
security
SMTP-AUTH,
SSL/TLS (HTTPS, SMTP), SSH, SNMP v3,
802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS),
Kerberos, IPsec
Wireless
network
Network node
type
NC-05w
Network type IEEE802.11 b/g/n (Infrastructure Mode/Ad-hoc Mode)
IEEE802.11 g (Wi-Fi DirectTM)
Network
security
SMTP-AUTH,
SSL/TLS (HTTPS, SMTP), SNMP v3,
802.1x (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS),
Kerberos, IPsec
Part Approximate Life (pages)
Machine life 500,000 sheets (A4/LTR)
MTBF 4,000 hours
MTTR 0.5 hours
Maximum monthly volume ADS-2800W: 60,000 sheets (A4/LTR)
ADS-3600W: 100,000 sheets (A4/LTR)
Part All Models
Reverse Roller Up to 200,000 sheets (A4/LTR) (User replacement parts)
Pick up Roller Up to 200,000 sheets (A4/LTR) (User replacement parts)

1-4 Confidential
5. PAPER
5.1 Paper Handling
Specifications are subject to change without notice.
5.2 Media Specifications
* For best performance it is recommended to use a carrier sheet for the following weights: 27 to
39 g/m2.
Specifications are subject to change without notice.
Part All Models
ADF Input 50 sheets
ADF Output 50 sheets
Duplex (Scan) Yes
Part All Models
Paper
Input
ADF Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled
Paper, Post Card (JPN), Business Card, Plastic Card
Media
Weight
ADF
(multiple paper)
27 to 413 g/m2
ADF (single paper) Plain paper/Long paper 27 to 209 g/m2
Thick paper 209 to 413 g/m2
Media
Size
ADF (multiple paper) Width 51 to 215.9 mm, Length 51 to 355.6 mm
ADF (single paper) Width 51 to 215.9 mm, Length 51 to 5,000 mm

1-5 Confidential
6. SCANNER
Specifications are subject to change without notice.
Color/Black Yes/Yes
TWAIN
Compliant
Windows®Windows®XP (32 bit only) *1 / Windows Vista®/
Windows® 7, 8, 8.1 / Windows Server®2003 (only 32 bit) /
Windows Server®2008 / Windows Server®2008 R2 /
Windows Server®2012 / Windows Server®2012 R2 *3
Macintosh OS X 10.8.x / 10.9.x / 10.10.x (Download only) *2
WIA
Compliant
Windows®Windows®XP (32 bit only) *1 / Windows Vista®/
Windows® 7, 8, 8.1, 10
ICA
Compliant
Macintosh OS X 10.8.x / 10.9.x / 10.10.x (Download only) *2
ISISTM
Compliant
Windows®Windows Vista®/ Windows® 7, 8, 8.1, 10
Color Depth Input 30 bit color Processing
Output 24 bit color Processing
Resolution Interpolated Up to 1200 x 1200 dpi
Optical Up to 600 x 600 dpi
Scanning Width Up to 215 mm
Gray Scale 256 levels
*1 Windows®XP in this Service Manual includes Windows®XP Home Edition and Windows®
XP Professional.
*2 For the latest driver updates for the Mac OS X you are using, visit us at
http://support.brother.com/.
*3 Server OS is supported Scanner Driver Only.
