RG308-18 PRODUCT MANUAL.

110 1.4Kw & 2.8Kw MODELS.

THIS MANUAL CO ERS:

230 2.8Kw,

QUARTZ INFRA-RED ELECTRIC HEATER

WARNINGS

The service engineer.

For internal use only. Do not use out of doors.•

E tension cables should be correctly rated for the load,fully•

unwound and never run through water or over sharp edges.

Failure to follow these instructions may result in risk of•

personal injury or damage to the equipment.

Damage due to a Failure to follow these instructions will •

invalidate the warranty.

The appliance must be serviced by qualified engineers•

in compliance with local regulations.

The appliance must be switched off and disconnected from•

the power supply before any work is carried out.

There are no user controls inside the appliance casing.•

Do not place anything on top of the appliance.•

Do not operate this appliance without first fitting the support legs•

and handle.

Only use in an upright position.•

An air gap of at least 400mm should be allowed on the sides •

and rear of the unit to ensure a clear airflow. Do not site the

unit close to combustible materials. The front of the machine

must not be obstructed. Do not cover. This appliance gets

very hot during use, site in a location where accidental

contact is unlikely.

IMPORTANT ! The minimum safe distance at the front of

the appliance is 2M.

The fire guard reaches high temperatures. Care must be taken.•

The heater should not be moved whilst connected to the power •

supply.

Do not operate with guards removed.•

This appliance must be earthed.•

Do not disconnect the appliance from the supply under load.•

Do not use this heater in the immediate surroundings of a bath,•

shower or swimming pool.

These instructions should be read by:

The specifying engineer.

The installation engineer.

The user.

P 2 OF 9

TOOLS REQUIRED:

PACKAGE CONTENTS:

OPERATING THIS APPLIANCE WITHOUT THE SUPPORT LEGS WILL BLOCK THE BOTTOM AIR VENTS

DO NOT OPERATE THE APPLIANCE WITHOUT FIRST FITTING THE SUPPORT LEGS.

FITTING THE SUPPORT LEGS AND CASTORS:

AND COULD CAUSE PERSONAL INJURY OR DAMAGE THE UNIT.

P 3 OF 9

Spe ifi ations:

EMC 2014/30/EU

LVD 2014/35/EU

STANDARDS APPLIED:

EN 60335-1:2012+A11:2014

EN 60335-2-30:2009+A11:2012

EN 61000-6-3:2007+A1:2011+AC:2012

HEATER CASING 1

SUPPO RT LEG ASSEM BLY 2

HANDLE 1

QUART Z BULB 2

FITTING S PACK CO NT AINING :

M6 X 45m m HEXAGO NAL BOLT S 4

PLASTIC SADDLE W ASHER 4

M8 X 40m m HEXAGO NAL BOLT S 4

INST RUCTIO NS 1

TECHNICAL SPECIFICATIONS. RG308-18

Model

230V 13A

Heating apa ity. 2.8kw 2.8kw 1.4kw

Power supply. 230V. 13A. 50Hz

Maximum running urrent. 12A 26A 13A

Weight . 16.54kg

IP Rating. IP20 IP20 IP20

SNIPS

14mm SPANNER

10mm SPANNER

No2 PHILIPS SCREWDRIVER

Gloves

110V 32A 110V 16A

110V. 32A. 50Hz 110V. 16A. 50Hz

17.06kg 16.6kg

EN 61000-6-1:2007

EN 61000-3-2:2014

EN 61000-3-3:2013

Saddle washer.

M6 x 45mm bolts.

M8 x40mm bolts.

Fit each leg support assembly to the case

using 4x M8x40mm hexagonal bolts.

Pinch tight.

: FITTING THE HANDLE TO THE MAINCASE:

hexagonal bolts. Pinch tight.

P 4 OF 9

Fit the handle to the case using 4x M6x45mm

2: FITTING THE SUPPORT LEGS

DO NOT OPERATE THIS MACHINE WITHOUT FITTING THE HANDLE.

THE TOP OF THIS APPLIANCE REACHES HIGH TEMPERATURES

THAT ARE UNCOMFORTABLE TO TOUCH!

Fire guard.

screws.

Fixing

Quartz bulbs.

DO NOT OPERATE THE APPLIAN E WITHOUT THE FIRE GUARD!

It is important that the bulbs are free of grease or finger prints as these will cause

ATTEMPTING TO FIT OR HANGE THE BULBS!

ALWAYS ENSURE THE APPLIAN E IS ISOLATED FROM THE POWER SUPPLY BEFORE

FITTING THE QUARTZ INFRA-RED BULBS:

It will be necessary to remove the fire guard to to access the bulbs.

The bulbs are supplied in carboard tubes that are cable-tied to the inside of the fire guard.

hotspots and shorten the life of the bulb. Use gloves to handle the bulbs.

1: Remove the two fixing screws securing the fire guard with a No2 Philips screwdriver.

2: arefully lift away the fireguard and using snips remove the cable-ties securing

the bulbs.

3: Using gloves, remove the bulbs from their packaging.

4: Fit the bulbs into the spring loaded ceramic holders at either end of the reflectors.

Ensure they are correctly seated.

5: Re-fit the fire guard.

P 5 OF 9

•

ALWAYS ISOLATE THE APPLIANCE FROM THE POWER SUPPLY

BEFORE CARRYING OUT MAINTENANCE!

See page 5.

P 6 OF 9

•

D sconnect the heater from the power supply.•

Remove the f re guard and bulbs. Clean w th a soft dry cloth.•

Do not use abras ve cleaners as a scratched reflector may cause the appl ance to•

overheat

•

Th s s normal.

MAINTENANCE:

• Care should be taken. The f re guard can reach h gh temperatures dur ng operat on.

by two rocker sw tches located on the s de of the mach ne.

damage the cable should be replaced.

Regular checks of the power cable should be carr ed out. If there are any s gns of

hotspots and shorten the l fe of the bulb. Use gloves to handle the bulbs.

It s mportant that the bulbs are free of grease or f nger pr nts as these w ll cause

• The heater has two heat sett ngs, half power and full power. These are controlled

Ensure the power nd cator lamp s llum nated.

The suppl er recommends that extra protect on be prov ded by the use of a 30mA RCD.

• Connect the appl ance to the power supply. Check the dataplate for the correct supply.

mach ne w thout apply ng the brakes.

OPERATING THE HEATER:

S te the appl ance on a f rm level surface and apply the castor brakes. Do not operate the

CLEANING THE REFLECTORS:

The reflectors should be cleaned regularly.•

Ensure the heater s cool before commenc ng work.•

REPLACING THE HEATING BULBS:

Ensure the heater s cool before commenc ng work.•

D sconnect the heater from the power supply.

SAFETY DEVICES:

Th s appl ance s f tted w th a t lt sw tch. Th s w ll prevent the mach ne from operat ng on

extreme grad ent or ly ng down.

12

1

2

3

4

56

7

8

9

11

10

13

P 7 OF 9

RG308-18 Spare Parts:

Drawing

N Descripti n Part N

1. Swivel Cast r. ME010224

2. Steel case. BW0202111

3. Fire Guard. BW020809

4. Heating bulb. 1400watts. 230v. HE010220

4. Heating bulb. 1400watts. 110v. (N t Sh wn) HE010221

4. Heating bulb. 700watts. 110v. (N t Sh wn) HE010222

5. Tube Handle. BW0202112

6. Reflect r Assembly. BW0202113

7. Rear Panel. BW0202114

8. Cable Ear. BW0202115

9. Illuminated R cker Switch. EL030147

10. Indicat r Lamp. 230v. EL030711

10. Indicat r Lamp. 110v. (N t Sh wn). EL030712

11. Mains Cable. 13A 230v. UK m ulded plug. EL020129

11. Mains Cable. 32A 110v. (N t Sh wn). EL020130

11. Mains Cable. 16A 110v. (N t Sh wn). EL020131

12. Tilt Switch. EL030148

13. L cking Cast r. ME010225

Main

Earth terminal.

Quartz bulb

Ceramic terminal

Tilt switch.

230v- 13A 50Hz.

ower supply.

ower supply. E

E

N

L

RG308-18 230v. WIRING DIAGRAM

ower switch II

ower switch IIower switch II

ower switch II ower switch I

ower switch Iower switch I

ower switch I

Earth terminal.

Rear panel.

ower indicator

lamp.

terminal block.

P 8 OF 9

Main

Earth terminal.

Quartz bulb

Ceramic terminal

Tilt switches.

110v- 32A 50Hz.

ower supply.

ower supply. E

E

N

L

RG308-18 110v.32A. WIRING DIAGRAM

ower switch II

ower switch IIower switch II

ower switch II ower switch I

ower switch Iower switch I

ower switch I

Earth terminal.

Rear panel.

ower indicator

lamp.

terminal block.

P 9 OF 9

Main

Earth terminal.

Quartz bulb

Ceramic terminal

Tilt switch.

110v- 16A 50Hz.

P wer supply.

P wer supply. E

E

N

L

RG308-18 110v.16A. WIRING DIAGRAM

P wer switch II

P wer switch IIP wer switch II

P wer switch II P wer switch I

P wer switch IP wer switch I

P wer switch I

Earth terminal.

Rear panel.

P wer indicat r

lamp.

terminal bl ck.
