Brush Wolf Standard-Duty X Series User manual

EXCAVATOR/BACKHOE BRUSH CUTTERS
Standard-Duty X Series
4200X
4800X LF | 4800X SF | 4800X HF
Operator’s Manual
WHY READ THIS MANUAL?
Before operating your new Brush Wolf brush cutter, read this entire manual to understand
1) safety precautions, 2) operating instructions, and 3) maintenance schedule to help keep
you safe and your equipment running smoothly for years to come.

218-692-1050 | brushwolf.com
TAKE A MINUTE TO WRITE DOWN THE FOLLOWING INFORMATION
FOR FUTURE SERVICE, REPAIR, AND WARRANTY INQUIRIES.
DATE OF PURCHASE ____________________________________________________
MODEL NO. ____________________________________________________
SERIAL NO. ____________________________________________________
DEALER NAME ____________________________________________________
SALES REP NAME ____________________________________________________
DEALER PHONE NO. ____________________________________________________
DEALER EMAIL ____________________________________________________
DEALER ADDRESS ____________________________________________________
____________________________________________________
OWNER REFERENCE INFORMATION

1
218-692-1050 | brushwolf.com
THANK YOU
Welcome to the Brush Wolf family!
You’ve made a smart choice! We hope
you love your brush cutter as much as
we love making it. If you have any issues,
please contact us at any time. We’re
here to help.
Brush Wolf
218-692-1050
[email protected]
www.brushwolf.com
02/06/24
SAFETY FIRST! ..................................................2-3
OPERATING YOUR BRUSH CUTTER.....4-6
MAINTENANCE ..................................................7-9
TROUBLESHOOTING ......................................10
HOW TO REPLACE BLADES.......................11
PARTS SECTION
4200X ...............................................................12-13
4800X LF | 4800X SF ................................14-15
4800X HF........................................................16-17
WARRANTY INFORMATION .........................18
WHAT’S INSIDE

2
218-692-1050 | brushwolf.com
SITE INSPECTION
Before operating your brush cutter, carefully
inspect the area to be cleared. Remove any
items that may be picked up and thrown
by the cutting blades, such as wire, pipes,
rocks, etc. Mark objects that are too large
to move. This is an important step to avoid
personal injury, damage to property, the
brush cutter, or your excavator/backhoe. If
an object is struck while operating the brush
cutter, immediately shut down power to both
the brush cutter and the excavator/backhoe.
Any damage should be corrected and tested
before the continuation of cutting.
EXCAVATOR/BACKHOE AUXILIARY
HYDRAULIC FLOW
Check the specifications of your brush
cutter’s rated gallons per minute (GPM)
to correctly match the hydraulic flow of
your excavator/backhoe to ensure proper
operation.
FOR YOUR SAFETY, READ THESE INSTRUCTIONS.
The following safety instructions are provided to alert you to precautions that, if
not followed, may cause serious injury to yourself or to others. Please read these
instructions completely. Brush Wolf cannot cover every incident that might be a
hazard. Extreme caution should be used at all times. Only use your Brush Wolf
brush cutter for the purpose for which it has been designed.
EQUIPMENT INSPECTION
Disconnect the unit from the excavator/
backhoe. To inspect or to make repairs
under the cutter deck, always block the unit
securely to prevent accidental release of the
lift mechanism.
Inspect all hydraulic connections to ensure
they are tight, and hoses and shields are in
good condition before applying pressure.
Hydraulic fluid can escape under pressure
and may cause serious injury or death. If
this type of injury occurs, seek medical
attention immediately.
SAFETY GEAR
Wear safety goggles, hearing protection,
and a hard hat. Only operate the excavator/
backhoe behind a shatterproof forestry-
rated door and cab.
SAFETY FIRST!

3
218-692-1050 | brushwolf.com
BRUSH WOLF OPERATOR’S MANUAL | SAFETY FIRST!
DO NOT operate near bystanders, vehicles,
pets, livestock, or buildings. Objects may
discharge while cutting with the brush cutter
and has the potential to cause serious injury.
DO NOT operate the brush cutter until
everyone on your work crew is alerted to the
dangers of walking up to the brush cutter while
in operation.
DO NOT operate the brush cutter in conditions
with poor visibility.
DO NOT operate while intoxicated or if taking
medications that may impair your senses or
reactions.
DO NOT allow children to operate the brush
cutter. Only individuals with excavator/backhoe
experience who are well acquainted with the
rules of safe operation should be allowed to
operate the brush cutter.
DO NOT operate the excavator/backhoe
without a shatterproof forestry-rated door and
cab.
DO NOT place hands, feet, or other objects
under the deck while the brush cutter is in
operation.
DO NOT allow anyone or any item on top of the
mower deck while in operation.
DO NOT expose the underside of the blades
towards the cab while in operation.
DO NOT continue operation if an unexpected
object is struck. IMMEDIATELY shut down
power to both the brush cutter and the
excavator/backhoe. Disconnect the hydraulic
couplers from the power source. Evaluate the
damage, repair, and then test the unit before
operation.
DO NOT leave the brush cutter unattended
while in a raised position. Always make sure
both the runners are placed firmly on the
ground and shut down the excavator/backhoe.
DO NOT attempt to straighten blades. Order
replacement blades if blades are bent, cracked,
or damaged.

4
218-692-1050 | brushwolf.com
Verify your excavator’s/backhoe’s
hydraulic flow to ensure it is within the
brush cutter’s rating range. The brush
cutter’s gallons per minute (GPM)
rating is located on the serial tag of the
brush cutter.
OPERATING YOUR BRUSH CUTTER
CHECK BLADES
Inspect blades to ensure they are sharp,
tightened correctly, and intact. Look for
damage, dullness, and cracks. See page 8
for details.
CHECK HYDRAULIC FLUID
A low level could indicate a leak and require
a closer inspection of your unit. See page 8
for details.
CHECK NUTS & BOLTS
Tighten the 1) blade carrier to the gearbox,
2) blade bolts/nuts, and 3) hydraulic motor
mount nuts to torque specification listed on
page 9.
INSPECT THE DRIVE COMPONENTS
Remove any foreign material.
 IMPORTANT: CHECK THESE ITEMS PRIOR TO OPERATING
 START HERE
FIGURE 1: SERIAL TAG

5
218-692-1050 | brushwolf.com
1) Ensure pins or quick couplers are properly
connected from the brush cutter to your
excavator/backhoe.
NOTE: All Brush Wolf brush cutters come
from the factory with the female flat faced
coupler on the pressure line and the male
coupler on the return line.
2) Inspect the hydraulic couplers and wipe
off water, dust, or any debris which can
damage hydraulic components. Once
cleaned, connect the couplers from the
cutter to the auxiliary hydraulic system on
the excavator/backhoe. If you have a HIGH
FLOW excavator/backhoe and brush cutter,
attach the case drain to the excavator/
backhoe. Twist the collars of the quick
connect couplers to secure the hydraulic
connections. Do not operate the brush
cutter on high flow hydraulics (over 30 GPM)
unless the brush cutter is equipped with a
high flow motor as this may cause damage
to the motor and void the warranty.
3) Make sure the hoses are routed in a way
that allows the head to make a full range of
motion. If hoses are too long and pinching
or binding, they can be made shorter by
loosening the hose bracket and feeding
additional hose length back to the cutter
deck.
4) Confirm all safety measures have been
completed per the Safety First! section
(pages 2-3). Most importantly, make sure
the area is clear of people and pets.
 CONNECTING THE BRUSH CUTTER
BRUSH WOLF OPERATOR’S MANUAL | OPERATING YOUR BRUSH CUTTER
FIGURE 2: HOSE ENDS
PRESSURE
RETURN
CASE DRAIN
(IF REQUIRED)

6
218-692-1050 | brushwolf.com
When done, lower lift arms, make sure the
cutter is placed flat on the ground, throttle
down on the excavator/backhoe, and shut off
the hydraulic flow to the brush cutter. Stop the
engine and engage the parking brake before
leaving the cab. Noise at shut down is normal.
DISCONNECTING HOSES:
To disconnect hoses, use proper hand
protection as the couplers may be hot. Always
replace caps on hoses once removed to
prevent contamination.
 OPERATING STEPS
 WHEN DONE CUTTING
1) Enter the shatter-proof cab door, engage
the seat belt, release the brake, and start
the engine. The runners of the brush
cutter should be as close to the ground as
possible.
2) Slowly apply hydraulics to the brush cutter
and increase the engine speed to high idle.
Make sure the unit is operating smoothly
before moving the excavator/backhoe
forward.
3) Check for proper blade rotation. Blades
should spin COUNTERCLOCKWISE as
viewed from above (see Figure 3). If
rotation is reversed (clockwise), either
inverse the flow from your machine or switch
the QD couplers on the hose ends.
When temperatures are below zero, allow
additional time for hydraulic fluid to warm
up.
4) Maintain excavator/backhoe speed
appropriate for the volume of brush to
prevent stalling.
5) Stay alert for drop-offs, rocks, holes,
abandoned wells, and septic tanks. Do not
operate or drive across a steep embankment
as this may cause a rollover and possible
injuries or death.
6) To cut large diameter brush and trees,
move forward slowly to make the cut.
FIGURE 3: BLADE ROTATION
COUNTERCLOCKWISE
BRUSH WOLF OPERATOR’S MANUAL | OPERATING YOUR BRUSH CUTTER

7
218-692-1050 | brushwolf.com
BRUSH WOLF BRUSH CUTTERS ARE BUILT TO STRICT STANDARDS AND
WILL DELIVER YEARS OF DEPENDABLE SERVICE WHEN YOU FOLLOW THESE
MAINTENANCE GUIDELINES...
MAINTENANCE
 MAINTENANCE SCHEDULE
See pages 8-9 for details.
ITEM BEFORE
EACH USE
DAILY OR
EVERY 8 HOURS
AS
NEEDED
Blades Inspect
Gearbox Lubricant Check Oil
Blade Bolt/Nuts Torque to 775 -lbs
Gearbox Castle Nut Torque to 450 -lbs
Gear Mounting Bolts Torque to 275 -lbs
Hydraulic Motor Mount Bolts Torque to 75 -lbs
Block (high flow units only) Torque to 420 -lbs
Shear Bolt Grade 2 Torque to 75 -lbs
Hoses & Hose Safety Shield Inspect
Gearbox Shaft Inspect
Brush Cutter Clean
CAUTION: Perform maintenance on a level surface with the unit firmly on the ground and
blocked. Shut down the excavator/backhoe and remove hydraulic hoses from the power
source.
DO NOT loan your brush cutter to another excavator/backhoe owner. The potential exists for
hydraulic contamination and could shorten the life of your excavator/backhoe or the hydraulic
motor on your brush cutter. Contamination of the hydraulic motor voids the warranty.

8
218-692-1050 | brushwolf.com
INSPECT BLADES
Inspect blades before each use to ensure
they are sharp, tightened correctly, and
intact. Look for damage, dullness, and
cracks. Blades should rotate freely and be
clear of obstructions. Replace the entire set
of blades if damaged.
CAUTION: Always replace the entire set of
blades. Never weld or straighten damaged
blades, as loss of blade integrity may result.
CHECK HYDRAULIC HOSES AND HOSE
SAFETY SHIELD
Check for wear, damage, or leaks. Replace if
damaged.
INSPECT THE DRIVE COMPONENTS
Inspect before each use and remove foreign
material.
BRUSH WOLF OPERATOR’S MANUAL | MAINTENANCE
 BEFORE EVERY OPERATION
1
2
1. Fill Hole with
breather cap.
2.Plug for oil level.
Oil should be at
the same level.
DO NOT overfi ll.
FIGURE 4: GEARBOX LUBRICATION
DIAGRAM
CHECK THE GEARBOX FOR PROPER
LUBRICANT
To check the lubricant level, remove the
pipe plug from the side of the gearbox. The
lubricant should be the same level as the
plug (see Figure 4). If low, add 85W-140
gear lube.
IMPORTANT: DO NOT overfill as too much
lubricant may rupture the gearbox seals.
Co� er pin

9
218-692-1050 | brushwolf.com
BRUSH WOLF OPERATOR’S MANUAL | MAINTENANCE
 BEFORE EVERY OPERATION
CHECK NUTS & BOLTS
Every Brush Wolf brush cutter is tested at
the factory and all nuts and bolts have been
tightened to specifications. We recommend
you check the nuts and bolts after the first 4
to 6 hours of operation; then daily or every
eight (8) hours.
Tighten the nuts that secure the blades
to the blade carrier every eight (8) hours.
Torque the nuts to 775 ft-lbs with a 1-11/16”
socket wrench. The nuts are located under
the access plate on the top of the blade
carrier (see Figure 5).
 AS NEEDED
CLEAN THE BRUSH CUTTER as needed
and look for potential damage or obstruction
that could result in poor performance.
Make sure all SAFETY DECALS are visible.
Also, tighten the castle nut holding the blade
carrier to the output shaft of the gearbox.
Torque to 450 ft-lbs with a 1-1/2” socket
wrench. Insert cotter pin through hole on
gearbox output shaft (see Figure 4).
Tighten gear mounting bolts daily or every
eight (8) hours. Torque the bolts to 275 ft-
lbs.
Tighten hydraulic motor mount bolts daily or
every eight (8) hours. Torque the bolts to 75
ft-lbs.
Tighten block (high flow units only) daily or
every eight (8) hours. Torque to 420 ft-lbs.
Tighten shear bolt grade 2 daily or every
eight (8) hours. Torque to 75 ft-lbs.
Shear bolt protection (also known as
butter bolt) at the motor coupler. It is
recommended to carry additional shear
bolts (½-13 x 3” GRD 2) obtained at most
hardware stores. Only use grade 2 when
replacing.
ACCESS COVER
BLADE NUT
FIGURE 5: ACCESS COVER

10
218-692-1050 | brushwolf.com
TROUBLESHOOTING
*May damage hydraulic motor and void warranty.
ISSUE POTENTIAL CAUSES
CONSULT YOUR DEALER OR CONTACT BRUSH WOLF FOR
ANY QUESTIONS OR ADDITIONAL HELP.
Loss of Power
• Low hydraulic fluid level
• Overheated hydraulic fluid*
• Contaminated hydraulic fluid*
• Low gearbox lubricant level
• Broken gearbox/motor shear pin
• Missing input shaft key
Excessive
Unit Vibration
• Dull, broken, or damaged blades
• Bent gearbox shaft
• Blade carrier out of balance
• Loose nuts and bolts
• New blade or bolts matched with worn blade or bolts
• Wire or rope wrapped around blades
Leaking Oil
• Loose hydraulic connections
• Ruptured hydraulic motor seals
• Bent gearbox shaft
• Loose or missing motor drain plug

11
218-692-1050 | brushwolf.com
HOW TO REPLACE BLADES
1) Take off the access cover (see Figure 5 on
page 9) by removing the nuts and washers.
2) Through the exposed access hole, rotate
the blade carrier to line up the nut of the
blade for access.
3) Insert a 1-11/16” socket through the
access hole and remove the nut and
drop the bolts. Caution: once nuts are
removed, blades will fall to the ground if not
supported.
4) Clean new bolts, lock-nuts, and washer
with cleaner/degreaser. Prior to assembly,
ensure all hardware is dry and free of
any contaminants including the carrier
assembly.
5) Use Primer Loctite on the bolts and nuts
according to the directions on the label.
Apply Loctite #243 to the first 10 bolt
threads to ensure coverage.
6) Assemble the new blade, the bolt, and the
nut to the carrier. The blade carrier cuts in
one direction, counterclockwise.
7) Torque the blade bolts to 775 ft-lbs. using a
1-11/16” socket.
8) Confirm the blade carrier rotates freely and
is clear of any obstructions.
9) Reinstall the access cover plate.
Perform replacement on a level surface with the brush cutter blocked off the ground.
Shut off the hydraulic power supply and disconnect hydraulic couplers.

12
218-692-1050 | brushwolf.com
PARTS: 4200X
DETAIL A
A
25
29
1
31
27
26
24
16
28
13
14
2
15
12
6
33 22
3
3
22
33
25
29
4
4X
4X
TYP
2X
2X
4X
4X
21
4
17
18
11
20
20
20
32
33
5
19
232630 2X
8
7
10
9

13
ONLY USE GENUINE OEM PARTS. ORDER PARTS FROM BRUSH WOLF AT 218-692-1050
ITEM ITEM
QTY
PART
NUMBER DESCRIPTION
1 1 15054 PLATE, ACCESS, 2 HOLE, 5.250 X 3.250 X 0.250
2 1 15103 GAURD, COUPLING, BW, X MODEL, STD
32 15108 ROD, ROUND, 0.375 X 41.000
4 1 15151 WELDMENT, FRAME, BW 4200X
5 1 15132 DECAL KIT, BW 4200X
6 1 15167 WELDMENT, BLADE CARRIER, 20.000 DIA X 1.000
7 2 15265 BLADES, 14.750 X 4.000 X .500
8 2 15066 BOLT, D-BOLT, 1 1/8-12, BW
9 2 15148 NUT, TOP LOCK, 1 1/8-12, GRADE C, PLAIN
10 2 30089 WASHER, FLAT, 1 1/8, F436, ZINC
11 2 15595 HOSE WHIP ASSEMBLY, -8 ORFS, FEMALE SWIVEL COUPLINGS, 0.500 X 90.000 HOSE
12 62 15068 CHAIN, 0.313, 5 LINK, PROOF COIL
13 1 15078 COUPLER, FLAT FACED, 1/2 FEMALE, 7/8-14, O-RING BOSS
14 1 15079 COUPLER, FLAT FACED, 1/2 MALE, 7/8-14, O-RING BOSS
15 1 15093 GEAR BOX, 62HP, 1:1.93 RATIO
16 1 15123 COUPLING, STD, 1.250 MOTOR, 1.375 GB, 5.500
17 1 15263 CLAMP, BODY, TWO PIECE, 22MM, TWO HOSE
18 1 15264 COVER PLATE, CLAMP, 22MM, TWO HOSE
19 1 15352 MOTOR, 4.9 CU IN, SAE “A” 2 BOLT, 7/8-14 SAE O-RING PORTS, 1.250 DIA X 1.250 KEYED
SHAFT, 3500/750 RELIEF, EATON
20 4 15584 ADAPTER, STRAIGHT, #8 MORFS, #10 MORB
21 1 30052 BOLT, HH, 5/16-18 X 1 3/4, GRD 5, ZINC
22 2 30024 BOLT, HH, 1/2-13 X 1 1/4 UNC, GRD 5, ZINC
23 230026 BOLT, HH, 1/2-13 X 2 UNC, GRD 5, ZINC
24 1 30029* BOLT, HH, 1/2-13 X 3, GRD 2, ZINC
25 6 30065 NUT, NYLOCK, 3/8-16, ZINC
26 3 30062 NUT, NYLOCK, 1/2-13, ZINC
27 4 30064 NUT, NYLOCK, 3/4-10, ZINC
28 2 30078 SET SCREW_CP_1_4-20X3_8 UNC
29 6 30083 WASHER, FLAT, 3/8, ZINC
30 215381 WASHER, NORD-LOCK, 0.500 X 1.000 OD, ZINC
31 415379 WASHER, NORD-LOCK, 0.750 X 1.210 OD, ZINC
32 130091 WASHER, SPRING LOCK, 5/16, ZINC
33 3 30093 WASHER, SPRING LOCK, .500, ZINC
** SHEAR BOLT

14
218-692-1050 | brushwolf.com
PARTS: 4800X LF
|
4800X SF
DETAIL A
A
25
29
1
31
27
26
24
16
28
13
14
2
15
12
33 23
3
3
23
33
25
29
18
4X
4X
TYP
21
17
6
32
222630
33
4
20
20
20
11
2X
8
7
9
10
2X
2X
4X
4X
5
19

15
ITEM ITEM
QTY
PART
NUMBER DESCRIPTION
1 1 15054 PLATE, ACCESS, 2 HOLE, 5.250 X 3.250 X 0.250
2 1 15103 GAURD, COUPLING, BW, X MODEL, STD
32 15109 ROD, ROUND, 0.375 X 47.000
4 1 15376* LOW FLOW BRUSH CUTTER - DECAL KIT, BW 4800X LF
4 1 15134* STANDARD FLOW BRUSH CUTTER -DECAL KIT, BW 4800X
5 1 15171 WELDMENT, FRAME, BW 4800X
6 1 15179 WELDMENT, BLADE CARRIER, 26.000 DIA X 1.000
7 2 15265 BLADES, 14.750 X 4.000 X .500
8 2 15066 BOLT, D-BOLT, 1 1/8-12, BW
9 2 15148 NUT, TOP LOCK, 1 1/8-12, GRADE C, PLAIN
10 2 30089 WASHER, FLAT, 1 1/8, F436, ZINC
11 2 15593 HOSE WHIP ASSEMBLY, -8 ORFS, FEMALE SWIVEL COUPLINGS, 0.750 X 90.000 HOSE
12 70 15068 CHAIN, 0.313, 5 LINK, PROOF COIL
13 1 15078 COUPLER, FLAT FACED, 1/2 FEMALE, 7/8-14, O-RING BOSS
14 1 15079 COUPLER, FLAT FACED, 1/2 MALE, 7/8-14, O-RING BOSS
15 1 15093 GEAR BOX, 62HP, 1:1.93 RATIO
16 1 15123 COUPLING, STD, 1.250 MOTOR, 1.375 GB, 5.500
17 1 15248 CLAMP, BODY, TWO PIECE, 30MM, TWO HOSE
18 1 15249 COVER PLATE, CLAMP, 30MM, TWO HOSE
19 1 15352* LOW FLOW BRUSH CUTTER - MOTOR, 4.9 CU IN, SAE “A” 2 BOLT, 7/8-14 SAE O-RING
PORTS, 1.250 DIA X 1.250 KEYED SHAFT, 3500/750 RELIEF, EATON
19 1 15353* STANDARD FLOW BRUSH CUTTER - MOTOR, 6.2 CU IN, SAE “A” 2 BOLT, 7/8-14-12 SAE
O-RING PORTS, 1.250 DIA X 1.250 KEYED SHAFT, 3500/750 RELIEF, EATON
20 4 15584 ADAPTER, STRAIGHT, #8 MORFS, #10 MORB
21 1 30053 BOLT, HH, 5/16-18 X 2 1/2, GRD 5, ZINC
22 2 30026 BOLT, HH, 1/2-13 X 2 UNC, GRD 5, ZINC
23 230024 BOLT, HH, 1/2-13 X 1 1/4 UNC, GRD 5, ZINC
24 1 30029** BOLT, HH, 1/2-13 X 3, GRD 2, ZINC
25 6 30065 NUT, NYLOCK, 3/8-16, ZINC
26 3 30062 NUT, NYLOCK, 1/2-13, ZINC
27 4 30064 NUT, NYLOCK, 3/4-10, ZINC
28 2 30078 SET SCREW_CP_1_4-20X3_8 UNC
29 6 30083 WASHER, FLAT, 3/8, ZINC
30 215381 WASHER, NORD-LOCK, 0.500 X 1.000 OD, ZINC
31 415379 WASHER, NORD-LOCK, 0.750 X 1.210 OD, ZINC
32 130091 WASHER, SPRING LOCK, 5/16, ZINC
33 3 30093 WASHER, SPRING LOCK, .500, ZINC
* DEPENDS ON THE MODEL OF BRUSH CUTTER
** SHEAR BOLT
ONLY USE GENUINE OEM PARTS. ORDER PARTS FROM BRUSH WOLF AT 218-692-1050

16
218-692-1050 | brushwolf.com
PARTS: 4800X HF
DETAIL A
A
30
35
1
32 38
31
28 34
17 18
2
19
16
39 29
3
3
29
39
30
35
4X
TYP
5
5
6
22
27 31 36 37
15
39
25
24
23
23
23 21
33
4
14
20
8
7
10
9
2X
2X
4X
8X
11
26

17
ITEM ITEM
QTY
PART
NUMBER DESCRIPTION
1 1 15054 PLATE, ACCESS, 2 HOLE, 5.250 X 3.250 X 0.250
2 1 15104 GUARD, COUPLING, BW, X MODEL, HF
32 15109 ROD, ROUND, 0.375 X 47.000
4 1 15350 DECAL KIT, BW 4800X HF
5 1 15311 WELDMENT, FRAME, BW 4800X HF
6 1 15179 WELDMENT, BLADE CARRIER, 26.000 DIA X 1.000
7 2 15265 BLADES, 14.750 X 4.000 X .500
8 2 15066 BOLT, D-BOLT, 1 1/8-12, BW
9 2 15148 NUT, TOP LOCK, 1 1/8-12, GRADE C, PLAIN
10 2 30089 WASHER, FLAT, 1 1/8, F436, ZINC
11 1 15418 PLATE, STAUFF, 3 HOLE COVER, 1.25 X 5.875
12 2 15590 HOSE WHIP ASSEMBLY, -12 ORFS, FEMALE SWIVEL COUPLINGS, 0.750 X 90.000 HOSE
13 1 15591 HOSE WHIP ASSEMBLY, -6 ORFS, FEMALE SWIVEL COUPLINGS, 0.375 X 96.000 HOSE
14 1 15149 MOTOR, 11.9 CU IN, SAE “CC” 4 BOLT, 0.750 DIA SPLIT FLANGE STAGGERED PORTS, 1.500
DIA X 1.625 KEYED SHAFT BW
15 1 15125 BLOCK, CROSSOVER RELIEF MANIFOLD, 6K MOTOR, ALUMINUM
16 70 15068 CHAIN, 0.313, 5 LINK, PROOF COIL
17 1 15114 COUPLER, FLAT FACED, 5/8 FEMALE, 1 1/6-12, O-RING BOSS
18 1 15115 COUPLER,FLAT FACED, 5/8 MALE, 1 1/6-12, O-RING BOSS
19 1 15092 GEAR BOX, 62HP, 1:1.46 RATIO
20 1 15053 COUPLING, HF, 1.500 MOTOR, 1.375 GB, 5.500
21 1 15407 ADAPTER, STRAIGHT, #6 MORFS, #4 MORB
22 1 15401 CLAMP, BODY, TWO PIECE, 30-30-18, THREE HOSE, BLACK
23 4 15405 ADAPTER, STRAIGHT, #12 MORF, #12 MORB
24 1 15408 ADAPTER, STRAIGHT, #6 MORFS, #8 MORB
25 1 15414 COUPLER, FLAT FACED, 3/8 FEMALE, 3/4-16, O-RING BOSS
26 2 30044 BOLT, HH, 3/8-16 X 3, GRD 5, ZINC
27 4 30025 BOLT, HH, 1/2-13 X 2 1/2 UNC, GRD 5, ZINC
28 1 30029* BOLT, HH, 1/2-13 X 3, GRD 2, ZINC
29 2 30024 BOLT, HH, 1/2-13 X 1 1/4 UNC, GRD 5, ZINC
30 630065 NUT, NYLOCK, 3/8-16, ZINC
31 530062 NUT, NYLOCK, 1/2-13, ZINC
32 430064 NUT, NYLOCK, 3/4-10, ZINC
33 830076 SCREW, SHCS, 3/8-16 X 3 1/2 GRD8
34 230078 SET SCREW_CP_1_4-20X3_8 UNC
35 630083 WASHER, FLAT, 3/8, ZINC
36 430084 WASHER, FLAT, 1/2, ZINC
37 415381 WASHER, NORD-LOCK, 0.500 X 1.000 OD, ZINC
38 415379 WASHER, NORD-LOCK, 0.750 X 1.210 OD, ZINC
39 3 30093 WASHER, SPRING LOCK, .500, ZINC
* SHEAR BOLT
ONLY USE GENUINE OEM PARTS. ORDER PARTS FROM BRUSH WOLF AT 218-692-1050

18
Warranties are valid from date of purchase with a warranty registration on file. Scan the QR code below
or go to brushwolf.com/warranty to file a claim and view warranty details.
Structural Components
Materials & Weldment
Bearing Housing
1.5-YEAR LIMITED WARRANTY
Gearbox
1.5-YEAR LIMITED WARRANTY
Hydraulic Motor
1.5-YEAR LIMITED WARRANTY
Cylinders
1.5-YEAR LIMITED WARRANTY
PROTECT YOUR PURCHASE.
WARRANTY INFORMATION
