Installation Instructions
KVBCN0101BLT
WALL CONTROL INSTALLATION
OneTouch Control
INTERMITTENT
MAX
MIN
!WARNING
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal
injury or death.
Before installing, modifying, or servicing, main electrical
disconnect switch must be in the OFF position. There
may be more than 1 disconnect switch. Lock out and tag
switch with a suitable warning label.
CAUTION
!
UNIT OPERATION HAZARD
Failure to follow this caution may result in equipment
damage or improper operation.
Never install more than one KVBCN0101BLT wall
control per unit.
NOTE: If this wall control is installed with any of the following
Bryant units the integrated control of those units must be turned
OFF; HRVBBSHA1100, HRVBBSVA1100, ERVBBSHA1100,
or ERVBBSVA1100, HRVBBLHA1150, HRVBBLHA1250.
NOTE: To ensure proper operation remove Jumper G on JU1 pin
IF this wall control is installed with another ERV or HRV Bryant
unit.
CAUTION
!
UNIT OPERATION HAZARD
Failure to follow this caution may result in equipment
damage or improper operation.
Ensure that the wires do not short-circuit between
themselves or by touching any othercomponents on the
wall control. Avoid poor wiring connections. To reduce
electrical interference (noise) potential, do not run wall
control wiring next to another control contactor or near
light dimming circuits, electrical motors,
dwelling/business power or lighting wires, or power
distribution panels.

2
Color Mode Suggested Use
Green Intermittent Select this mode when you are away from the house for a few days, or when
you deem the inside air is too dry in heating season or too humid in cooling
season. In this mode the unit is OFF for 40 minutes per hour and ventilates at
minimum speed the remaining 20 minutes of the hour.
Yellow Minimum Speed
Ventilation
For normal daily operation
Red Maximum Speed
Ventilation
For excess pollutants and humidity
(Parties,odors,smoke,etc.)
INSTALLATION
Step 1—Cut a 2 3/8 in. high by 1 3/8 in. wide hole in the wall.
See Fig. 1.
Step 2—Temporarily place the switch in the hole to mark the
correct locations for the 2 wall anchors.
Step 3—Remove the switch, drill the 2 wall--anchor holes and
insert the wall anchors into the wall.
Step 4—Using Fig. 2 as a guide, connect the electrical wiring.
Step 5—Finish mounting KVBCN0101BLT wall control. Plug
the unit in and test the wall control operation.
1 3/8 in.
2 3/8 in.
A05294
Fig. 1 -- Wall Control Installation
NO C NC I OC OL Y R G B
BG
OC
KVBCN0101BLT Control
REAR VIEW
GB
Y
A05295
Fig. 2 -- Wall Control Wiring
