SINGLE-PACKAGE
ELECTRIC HEATING
COOLING UNITS
HRVBBLHU
HRVBBSVC
HRVBBLVU
Heat Recovery Ventilators
Form No. PDS HRV.71.1
The Heat RecoveryVentilation (HRV) system offered by Bryant
is the finest unit on the market today.
The HRVB provides efficient and cost-effective heat recovery
during the heating season when needed most.
As temperatures drop below 23°F (–5°C), indoor air is
recirculated periodically through the heat exchanger core to
prevent frost from forming. Competitors’methods of
supplementary electric defrost waste energy.Unlike rotary
wheel heat exchangers which mix air streams, these cross flow
or counterflow heat exchangers ensure that there is no mixing
of the stale air stream with the fresh outdoor air stream.
A filter installed on the incoming outdoor air stream removes
large airborne particles from the intake air stream before they
enter the heat exchanger and reduces the maintenance
required.
The units’acoustically engineered design makes them the
quietest on the market and ensures that comfort is felt, not
heard.
Unlatching 2 suitcase style latches allows easy removal of the
filters and core for cleaning.
FEATURES
• Energy saving defrost cycle
• Cross flow, counterflow heat exchangers
• Two filters on incoming outdoor air stream to protect the HRV
core
• Acoustical design
• No-tools maintenance
• Polypropylene heat exchanger core
HRVBBSVC
HRVBBLHU
HRVBBLVU

—2—
Model number nomenclature
HRV BB LHU 1 150
Maximum Capacity
(CFM)
150 CFM
200 CFM
250 CFM
330 CFM
Electrical Supply:
1 — 115 volts
Descriptor:
LHU — Large Horizontal Unit
SVU — Small Vertical Unit
LVU — Large Vertical Unit
Brand:
Bryant
Equipment Type:
Heat Recovery
Ventilator
Climate Map for Energy and Heat Recovery Ventilators
ERV Recommended w/HRV or ERV Wall Control
ERV Recommended
HRV Recommended
Honolulu
Sacramento Salt Lake
City
Boise
Salem
Vancouver
Helena
Edmonton
Calgary Regina Winnipeg
Bismark
Topeka
Denver
Oklahoma City
Austin Baton Rouge
Orlando
Atlanta Columbia
Raleigh
Washington D.C.
Nashville
Indianapolis
Springfield
Chicago
Des Moines
Minneapolis
Green Bay
Milwaukee
Detroit
Madison
Harrisburg Hartford
Boston
Syracuse
Montreal
Ottawa
Timmins
A00099
TESTED/CERTIFIED
HOME VENTILATING INSTITUTE
DIVISION OF AMCA

—3—
Controls and accessories part no. nomenclature
ACCESSORIES
K V B CN 01 01 BAU
CONTROL DESCRIPTION
BAU — Bryant Automatic Control
BBS — Bryant Basic Control
BST — Bryant Standard Control
ACCESSORY DESCRIPTION
6FM — 6 in. Flowmeters (2)
7FM — 7 in. Flowmeters (2)
8FM — 8 in. Flowmeters (2)
EXH — Exhaust Hood
HOD — Intake Hood
KIT — Balancing Kit
FIR — Interlock Relay
TIMER DESCRIPTION
20C — 20-Minute Timer Kit Carrier
60M — 60 Minute Adjustable Timer Kit
FILTER DESCRIPTION
112 — 11-1/2 x 12-3/4
116 — 11-7/8 x 16-5/8
123 — 12-15/16 x 13-1/2
145 — 14-3/8 x 15-1/2
713 — 7-13/16 x 13-1/2
810 — 8-1/8 x 10-3/4
812 — 8-7/8 x 12-3/4
916 — 9 x 16-5/8
01 — Single Pack
01 — Part Number
AC — Accessory
CN — Control
FL — Filter Media
TM — Timer
A — Original Series
B — Second Series
V — Heat Recovery Ventilator (HRV)
K — Accessory Kit
Kit Number Description Where Used
KVBCN0101CBS
Basic HRV Control Used with all HRVs
KVBCN0101CST Standard HRV Control Used with all HRVs
KVBCN0101CAU Automatic HRV Control HRVBLSVU, HRVBBLVU
KVAAC0101FIR Interlock Relay When combining an HRV with a Furnace or Fan Coil
KVATM010120C 20 Minute Push ButtonTimer Used with all HRVs when 20 minute manual operation is required
KVATM010160M 60 Minute Timer Used with all HRVs, time is adjustable between 10 and 60 minutes
KVAAC0101HOD Exterior Intake and Exhaust Hood 2 Required
KVAAC0101KIT Start up Balancing Kit Start up Balancing Kit, includes (2) 6 in.Flow Meter Collars & Magnehelic Gage
KVAAC01016FM 6 in. Flow Meter Collar At start up, when 6 in. duct work is connected to HRV
KVAAC01017FM 7 in. Flow Meter Collar At start up, when 7 in. duct work is connected to HRV
KVAAC01018FM 8 in. Flow Meter Collar At start up, when 8 in. duct work is connected to HRV
KVAFK0101150 Internal Filter Used with HRVBBLHU 1150 Unit 11 3/4 x 12 7/8 x 3/4 (2)
KVAFK0201200 Internal Filter Used with HRVBBLHU 1250 Unit 11 3/4 x 16 3/4 x 3/4 (2)
KVAFL0101713 Internal Filter Used with HRVBBSVU 1150 Unit 7 13/16 x 13 1/2 (2)
KVAFL0101123 Internal Filter Used with HRVBBSVU 1200 Unit 12 15/16 x 13 1/2 (2)
KVAFL0101123 Internal Filter Used with HRVBBLVU 1200 Unit 12 15/16 x 13 1/2 (2)
KVAFL0101145 Internal Filter Used with HRVBBLVU 1200 Unit 14 3/8 x 15 1/2
KVAFL0101810 Internal Filter Used with HRVBBLVU 1330 Unit 8 1/8 x 10 3/4 (1)
KVAFL0101145 Internal Filter Used with HRVBBLVU 1330 Unit 14 3/8 x 15 1/2 (1)
KVAFL0101810 Internal Filter Used with HRVBBLVU 1200 Unit 8 1/8 x 10 3/4 (1)

—4—
CONTROL FEATURES
Basic Control: Allows the user to manually set fan speed to low or high as required to maximize comfort.
Standard Control: Offers automatic dehumidistat control and the option to select continuous or intermittent fan
operation.Setting the wall control to low will activate the continuous mode.
Automatic Control: In addition to the features found with standard control, this package offers a recirculation mode.
These controls may only be used to operate stand-alone units with the defrost option which enables the recirculation
feature.
* Air exchange with outside.
† No air exchange with outside.
‡ Use only on units with defrost.
CONTROL DESCRIPTION AND USAGE
Fan Speed Control — Enables user to modulate fan speed from low to high air exchange with outside.
Dehumidistat Control — Allows the user to select the relative humidity level at which the unit would change fan speed
for dehumidification in the winter months.
Continuous Mode — If the relative humidity inside the building is lower than selected, air exchange occurs with the
outside at low speed.If the relative humidity inside the house is higher than selected, air exchange occurs with the
outside at high speed. Ensures continuous air exchange for constant air quality.
Intermittent Mode — If the relative humidity inside the building is lower than selected, no air exchange occurs and the
system turns off. If the relative humidity inside the house is higher than selected, air exchange occurs with the outside
at high speed. Ensures minimum air exchange level when the building is unoccupied to minimize operating costs.
Circulation Mode —Ifthe relativehumidity insidethebuildingislowerthanselected,the ambient airwouldbe circulated
and filtered at high speed.If the relative humidity inside the house is higher than selected, air exchange would occur with
the outside at high speed. Ensures continuous movement and filtration of air for maximum comfort. Available with
automatic control only.
AUTOMATIC DEFROST CYCLE FEATURES
All models offer a non-electric defrost cycle feature which prevents frost and ice buildup within the heat recovery core.
When the outside air temperature falls below 23°F (–5°C) it is electronically sensed and the dampers close the outside
air ports.This allows warm indoor air to recirculate within the heat recovery core.The frequency of this cycle increases
as the outside air temperature decreases.
* All defrost times are in the standard mode (as shipped)
† Time between defrost when within specified temperature range
CONTROL
DESCRIPTION
FAN
SPEED
CONTROL DEHUMIDISTAT CONTROL CONTINUOUS MODE* INTERMITTENT MODE* CIRCULATION MODE†
Basic
Yes No Yes No No
Standard Yes Yes Yes Yes No
Automatic‡ Yes Yes Yes Yes Yes
MODEL 23°FTO 55°F (–5°CTO –15°C) 4°FTO –17°F (–15.6°CTO –27.3°C) BELOW –18°F (–27.8°C) DEFROST* EXCHANGE† DEFROST* EXCHANGE† DEFROST* EXCHANGE†
HRVBBLHU 6 Minutes 60 Minutes 6 Minutes 32 Minutes 6 Minutes 20 Minutes
HRVBBSVU 6 Minutes 60 Minutes 6 Minutes 32 Minutes 6 Minutes 20 Minutes
HRVBBLVU 6 Minutes 60 Minutes 6 Minutes 32 Minutes 6 Minutes 20 Minutes

—5—
A
20"
(508.0)
B
15"
(381.0)
G
4
3
/
4
"
(120.6)
D
C
30
1
/
4
"
(768.3)
2
5
/
16
"
(58.7)
18
1
/
8
"
(460.4)
16
7
/
8
"
(428.6)
NOTES: 1.FRESH AIR FROM OUTSIDE 2.FRESH AIR FROM HRV TO HOUSE 3.STALE AIR FROM HOUSE TO HRV 4.STALE AIR FROM HR TO OUTSIDE
4
3 1
2
E
F
5
7
/
8
" DIA
(149.2) 4 PLCS
2
3
/
16
"
(56.2)
4 PLCS 1"
(25.4) 2 PLCS
DIMENSIONS
MODEL NO. ABCDEFG
in. mm in. mm in. mm in. mm in. mm in. mm in. mm
HRVBBLHU1150
15-1/8 384.2 4-1/16 104 5/58 143.3 14-1/2 368.9 10-3/8 288.9 4-3/8 111.3 7-3/4 196.9
HRVBBLHU1250
19 483 5-13/16 147.7 5-1/16 128.1 14-1/2 368.9 11-3/16 283.9 4-3/8 111.3 10-1/16 255.6
A98002

—6—
5 3⁄4″
[146.0] D
2
27″
[685.8]
22 1/16″
[560.4]
1″
[25.4]
2 PLCS
15 11⁄16″
[398.5]
E
3
1
4
1 15⁄16″
[23.8]
3 3⁄16″
[81.0]
4 9⁄16″
[115.9)]
F DIA 2 PLCS
19 3⁄4″
[501.7]
5 7⁄8″DIA
[149.2] 2 PLCS
WALL CONTROL WIRING 3⁄8″DIA
[9.5]
A
G
DRAINS
11⁄16″ DIA.
[17.5] 2 PLCS
B
C
2 3⁄16″
[55.6] 4 PLCS
POWER CORD
NOTES: 1. FRESH AIR FROM OUTSIDE TO HRV 2. FRESH AIR FROM HRV TO HOUSE 3. STALE AIR FROM HOUSE TO HRV 4. STALE AIR FROM HRV TO OUTSIDE
DIMENSIONS (continued)
A98003
MODEL NO. ABCDEFG
in. mm in. mm in. mm in. mm in. mm in. mm in. mm
HRVBBSVU1150
18-1/2 469.9 4-11/16 119.1 13-5/16 388.2 15-7/16 392.1 13-9/16 344.5 5-7/8 149.2 19-15/16 506.2
HRVBBSVU1200
24-1/2 622.2 8-3/16 208.0 19-5/16 490.6 14-9/16 369.9 16-15/16 430.2 6-7/8 174.6 19-15/16 506.2

—7—
HRVBBLVU1200 or HRVBBLVU1330
A98001
17 9⁄16″
[446.9]
4 3⁄4″
[120.6]
8 1⁄8″ DIA
[206.4]
2 PLCS
5 13⁄16″
[147.6]
5 7⁄8″ DIA
[148.2]
2 PLCS
6 15⁄16″
[176.2]
7 1⁄8″
[181.0]
18 5⁄16″
[465.1] 2 3⁄16″
[55.6]
2 PLCS
12 3⁄4″
[323.9]
23 15⁄16″
[608.0]
43″
(1092.2)
19 1⁄16″
[484.2] 8 3⁄16″
[208.0]
7 3⁄16″
[182.6]
DRAIN
11⁄16″DIA.
[17.5] 2 PLCS
24 1⁄16″
[611.2]
1 1⁄2″
[38.1]
2 PLCS
22 3⁄8″
[568.3]
41″
[1041.4]
1″ [25.4]
2 PLCS
15 1⁄2″
[393.7]
3
1
2
4
NOTES: 1. FRESH AIR FROM OUTSIDE TO HRV 2. FRESH AIR FROM HRV TO HOUSE 3. STALE AIR FROM HOUSE TO HRV 4. STALE AIR FROM HRV TO OUTSIDE
WALL CONTROL WIRING 3⁄8″DIA
[9.5]
POWER CORD
DIMENSIONS (continued)

—8—
PHYSICAL DATA
PERFORMANCE DATA
ELECTRICAL DATA
MODEL DESCRIPTION CONVENTIONAL COMPACT HIGH EFFICIENCY
Model No.
HRVBBVHU1150 HRVBBVHU1260 HRVBBSVC1150 HRVBBSVC1200 HRUBBLVU1150 HRUBBLVU1200 HRUBBLVU1330
Port Locations Sides Sides Top Top Top Top Top
CoreType Polypropylene
Cross Flow Polypropylene Cross Flow Polypropylene Cross Flow Polypropylene Cross Flow Polypropylene Cross Flow Polypropylene Counterflow Polypropylene Counterflow
Weight — lb (kg) 65 (29.5) 73 (33.2) 60 (27) 80 (36.3) 80 (36.3) 120 (54.5) 120 (54.5)
ShippingWeight — lb (kg) 75 (34) 83 (37.6) 75 (34) 89 (40.4) 89 (40.4) 143 (64.9) 143 (64.9)
Shipping Dimensions (in.)
Height
Width
Depth
23 1/16
36 1/16
17 13/16
22 15/16
35 1/16
22 5/16
31.5
23.25
26.00
31.5
23.25
26.00
31.5
23.25
26.00
47.5
26.0
26.0
47.5
26.0
26.0
MODEL DESCRIPTION CONVENTIONAL COMPACT HIGH EFFICIENCY
Model No.
HRVBBLHU1150 HRVBBLHU1250 HRVBBSVC1150 HRVBBSVC1200 HRVBBLVU1150 HRVBBLVU1200 HRVBBLVU1330
Capacity — CFM @ 0.5–
0.3ESP (in. wc)
130–168 191–210 106–150 177–211 123–141 189–209 300–334
Efficiency (Sensible) —
percent
32°F (0°C)
–13°F (–25°C)
65
65 65 60 69 60 77 67 81 69 84 72 80 74
Efficiency (Latent) —
percent
@ all temperatures
0000000
Heat Core Exchange Area
— cu ft (cu m)
120
3.4 166 4.7 90 8.4 144 13.3 144 13.3 210 19.5 210 19.5
CONVENTIONAL COMPACT HIGH EFFICIENCY
Model
HRVBBLHU1150 HRVBBLHU1250 HRVBBSVC1150 HRVBBSVC1200 HRVBBLVU1150 HRVBBLVU1200 HRVBBLVU1330
Voltage 120 120 120 120 120 120 120
Max Power — watts 150 218 115 195 115 250 500
Max Amps 1.4 1.9 1.2 1.8 1.2 2.2 5.4

—9—
METHODS TO SIZE HRV’S
METHOD 1
1. Calculate cu ft of occupied space.
2. Multiply by recommended air changes per hr (AC/h).
3. Divide by 60 minutes per hr to convert to CFM.
EXAMPLE: 2000 sq ft with 8 ft ceiling
0.35 air changes per hr (AC/h)
(2000 sq ft x 8 ft ceiling x 0.35 AC/h) / 60 min/h = 93.3 CFM
METHOD 2
1. Multiply number of people times 15 CFM/person.
2. Multiply number of bath rooms 20 CFM/each.
3. Add 25 CFM for kitchen.
EXAMPLE: 2 people
2 baths
1 kitchen
(2 x 15) + (2 x 20) + 25 = 95 CFM
ADDITIONAL HEATING AND COOLING LOAD CHARTS
Although the ventilators process the outside air before it enters the home, additional heating and cooling loads need to
be considered.
HEATING LOAD BTU
The heating load chart shows the heating loads in Btuh for a range of winter design temperatures for each model of
ventilator.
EXAMPLE: The heating design temperature for Milwaukee, WI is –4°F. At –5°F, the additional heating load of the
HRVBBLHU1250 is 8417 Btuh.This additional load should be taken into consideration when sizing the
heating equipment.
Outside
Temp °F Heat Load (Btuh) @ Inside DesignTemp 72°F HRVBBLHU1150 HRVBBSVC1250 HRVBBSVC1150 HRVBBSVC1200 HRVBBLVU1150 HRVBBLVU1200 HRVBBLVU1330
–25
4,688 8,165 6,970 7,690 5,500 6,650 9,990
–20 4,466 7,744 6,470 7,090 5,030 6,070 9,310
–15 4,598 8,008 5,990 6,520 4,590 5,510 8,650
–10 4,334 7,547 5,520 5,970 4,160 4,970 8,000
–5 4,069 7,087 5,070 5,440 3,750 4,470 7,380
0 3,805 6,627 4,550 4,840 3,300 3,910 6,640
5 3,541 6,167 4,130 4,360 2,940 3,470 6,060
10 3,502 6,100 3,730 3,900 2,600 3,050 5,500
15 3,220 5,608 3,290 3,400 2,240 2,600 4,870
20 2,938 5,116 2,930 3,000 1,940 2,240 4,350
25 2,950 5,138 2,580 2,610 1,670 1,910 3,850
30 2,636 4,591 2,240 2,250 1,410 1,600 3,370
35 2,322 4,045 1,900 1,880 1,160 1,300 2,870
40 2,009 3,498 1,600 1,560 1,940 1,040 2,430

—10—
COOLING LOAD BTU
The cooling load chart shows loads in Btuh as well.To use the cooling load chart, first find the design enthalpy from a
psychrometric chart using the design dry bulb and wet bulb temperatures.(See psychrometric chart on p.11.) The
cooling load can then be found for a range of enthalpies for each ventilator.
EXAMPLE: The cooling design dry bulb temperature for Milwaukee, WI is 87°F and the average wet bulb at that
temperatureis73°F.Onthepsychrometric chart the enthalpyisabout37.7Btu/lbofdry air which will round
up to 38 Btu/lb of dry air.In the left column, at 38 Btu/lb the HRVBBLHU1250 would have an additional
cooling load of 6428 Btuh.This additional load should be taken into account when sizing the air cooling
equipment.
Outside
Enthalpy
Btu/lb
Cooling Load (Btuh) @ Inside DesignTemp 75°F and 50% Relative Humidity
HRVBBLHU1150 HRVBBLHU1250 HRVBBSVC1150 HRVBBSVC1200 HRVBBLVU1150 HRVBBLVU1200 HRVBBLVU1330
30
670 1,071 780 990 770 990 1,390
31 1,090 1,741 1,300 1,650 1,290 1,650 2,310
32 1,509 2,411 1,820 2,310 1,800 2,310 3,240
33 1,928 3,080 2,340 2,970 2,310 2,970 4,170
34 2,347 3,750 2,860 3,630 2,830 3,630 5,090
35 2,766 4,419 3,380 4,290 3,340 4,290 6,020
36 3,185 5,089 3,910 4,950 3,860 4,950 6,940
37 3,604 5,759 4,430 5,610 4,370 5,610 7,870
38 4,023 6,428 4,950 6,270 4,890 6,270 8,790
39 4,442 7,098 5,470 6,930 5,400 6,930 9,720
40 4,861 7,767 5,990 7,590 5,910 7,590 10,650
41 5,280 8,437 6,510 8,250 6,430 8,250 11,570
42 5,699 9,107 7,030 8,910 6,940 8,910 12,500

—11—
.025
.024
.023
.022
.021
.020
.019
.018
.017
.016
.015
.014
.013
.012 .95
.90
.85
.80
.75
.70
.65
.60
.55
.50
.45
.40
.35
.011
.010
.009
.008
.007
.006
.005
.004
.003
.002
.001
0
Sensible
heat
factor
Pounds of moisture
per pound of dry air
789
10 11
12
32 33
34 35
36
37 38
39 40
41
42 43
44 45
47
48 49
46
27 28
29 30
31
19 20
21 22
23
24 25
26
12 13
14 15
16
17
18
Wet Bulb, Dewpoint or Saturation Temperature F
Dry Bulb Temperature F 20
Below 32˚F, properties and enthalpy deviation lines are for ice.
25
25 30 35
40
45 50 55
60
65
70 75
80
30 35 40
85 90 95 100 105 180
170
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
0
45 50 55 60 65 70 75 80 85 90 95 100 105 110
Enthalpy at saturation, Btu per pound of dry air Grains of moisture
per pound of dry air
14.0 cu ft
14.5 cu ft per pound of dry air
13.5 cu ft
13.0 cu ft
12.5 cu ft
90% Relative Humidity
80%
70%
60%
50%
40%
30%
20%
10%
-.02 BTU
-.01 BTU
-.02 Btu
-.04 Btu
-.06 Btu
-.08 Btu
+0.1 Btu
+0.2 Btu
+0.3 Btu
+0.4 Btu
+0.5 Btu
80% 60% 40% 20%
Btu per
pound of dry air -0.3 Btu
Enthalpy deviation
PSYCHROMETRIC CHART
A98394

—12—
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
UNIT MUST BE INSTALLED IN ACCORDANCE
WITH INSTALLATION INSTRUCTIONS
Cancels: New
FORM PDS HRV.71.1
© 2000 Bryant Heating & Cooling Systems, 7310 W. Morris St., Indpls., IN 46231 PRINTED IN U.S.A. Catalog No. 12HR-VBO 3-00
HRV INSTALLED WITH FORCED AIR SYSTEM
HRV INSTALLED WITH INDEPENDENT AIR DISTRIBUTION
A99297
A99298
