BSi BT-61 User manual

BT-61
FOREHEAD THERMOMETER FOR FEVER
OBJECT SURFACE THERMOMETER
OPERATION MANUAL
1. SAFETY RULES
To ensure the device is used safely, follow the operation manual's safety and operating
instructions. If the device is not used as described in this operation manual, the safety
features of this device might be impaired.
Keep out of reach of children.
2. INTERNATIONAL SYMBOLS
3. SPECIFICATIONS
Important information
see manual
Measurement Range Body Temperature 32.0 ~ 42.9°C (89.6 ~ 109.2°F)
Object surface Temperature 0.0 ~ 200.0°C (32.0 ~ 392.0°F)
Infrared Thermometer Forehead & Object surface types
Description
4. THERMOMETER DESCRIPTIONS
5. OPERATION
WARNING
Do not place the device too close to the electromagnetic scope. (Radio, mobile
phone, etc.)
Hair and sweat on the forehead may a󰀨ect the accuracy of measurements. Di󰀨erent
skin colours and thicknesses may give slightly di󰀨erent measuring temperatures.
When the tested person comes from a di󰀨erent temperature environment, one shall
stay in the measuring environment for 15 minutes before measuring.
5.1 Three-colours screen fever guidance
Display Function
Normal - Green backlight 34~37.3 °C
5.2 Function Selection
°C or °F Press and hold the "M" button, and click the "+" Button.
Short press the backlight button to turn the backlight on or o󰀨.
Historical data viewing: The instrument will automatically
record up to 32 historical measurement data. To view data,
quickly press the "M" button & release and then "+" or
"-". Press "-"to view the last temperature record, and press
"+" for the farthest record. Press + or – again to view them
one by one.
The sequence of the 32 memories data will follow by the
relevant readings.
1)
2)
3)
•
•
5.4 LCD Error Messages
The Thermometer incorporates visual diagnostic messages as follows:
‘Hi’ or ’Lo’ is displayed when the temperature being
measured is outside of the measurement range. It is invalid
measurement. These measurement results will not be
recorded nor counted.
The Thermometer is a non-contact infrared thermometer and always with Real-Time Maximum
(MAX) data. Please remember to keep away from children and not use them for safety-related
issues.
Backlight
Memory (Only on Body
temperature mode)
」「
」「
Memories 32 Recalls (Forehead type only)
Measuring Distance
Atmospheric Pressure
2 ~ 10 cm
70 kpa ~ 106 kpa
Indicating Unit Resolution
Accuracy in °C /
Body Temperature Mode
0.1 °C
10 °C ~ 40 °C
Within range 35.0 °C ~ 42.0 °C : ± 0.2 °C
Out of range (2 ~10 cm) 35.0 °C ~ 42.0 °C : ± 0.3 °C
Within range 0.0 °C ~ 200.0 °C : ± 0.4 °C
Out of range (2 ~ 10 cm) 0.0 °C ~ 200.0 °C : ± 0.6 °C
Accuracy in °C /
Object Temperature Mode
Operating Temperature
Automatic Sleep Mode
Language
Product Size (L x W x H)
Product Weight
After 30 Sec.
Bilingual- English & Chinese (Default English)
10 cm x 4.6 cm x 16 cm
125g (Without Battery)
1. Infrared Sensor
2. Measuring Port
3. LCD Screen
4. "Body Temp (Default) or
Object Temp (Blank) mode
5. Buzzer
6. Backlight
7. °C / °F
8. "+" Button
9. "-" Button
10. "M" Function enable Button
11. Backlight Button
12. Buzzer Button
13. Measuring Button
14. Battery Cover
15. Handle
2
1
4
3
8
11
13
14
5
6
7
9
10
12
15
High - Amber backlight 37.4~38 °C
Fever - Red backlight 38.1~42.9 °C
The condition of the measuring spot should be stable without ample airow, i.e. Fan
or air-con blower.
4)
Do not take measurements in a place near strong sunlight.5)
Body temperature and
Object temperature
switching
The default setting of the Thermometer is Body temperature.
Change to Object temperature: press and hold the "M"
button, and click the buzzer button to measure Object surface
temperature (note: Object temperature has no icon shown on
LCD).
Change to Body temperature: press and hold the "M" button
and click the backlight button to measure body temperature
(note: Body temperature has an icon on LCD).
English and Chinese
mode switching
Press and hold the "M" button, and click the "-" Button.
(Default is English)
Short press the buzzer button to turn the sound on or o󰀨.
Sound
Measure non-body
temperature
When you need to measure non-body temperature
(object surface temperature), it can be switched to object
temperature mode as described above.
The use of this Thermometer is not a substitute for a doctor’s diagnosis.6)
Battery 6F22 9V (Alkaline battery recommended)

6. MAINTENANCE
6.1 Fitting and replacing the Battery
The Thermometer incorporates visual low battery indication as follows:
When the Low Battery icon "LOB" indicates the Battery is low, Battery should be replaced
with a 6F22 9V battery.
Pay attention to the polarity of the battery connection. This device is designed with an anti-
reverse connection to the Battery. It will not damage the device but will not work until the
correct connection is made.
Do not use a rechargeable battery; an alkaline Battery is recommended.
1.
2.
3.
6.2 Storage & Cleaning
The sensor lens is the most delicate part of the Thermometer. The lens should be kept clean at
all times; care should be taken when cleaning the lens using only a soft cloth or cotton swab with
water or medical alcohol. Allowing the lens to dry entirely before using the Thermometer. Do not
submerge any part of the Thermometer. The Thermometer should be stored at room temperature
between -20 to +65°C (-4~149°F) and 85% of relative humidity with no condensation or less.
7. ACCESSORIES
The accessories contained inside the packaging are the following:
DC9V Battery
English instruction manual
••
8. SERVICE
8.1 Limited Warranty Conditions
This Thermometer is guaranteed against any material fault or manufacturer’s defect under the
general conditions of sale. During the warranty period (12 months from shipment date), faulty
parts may be replaced, with the manufacturer reserving the right to repair or replace the product.
The customer pays the inward outward transporter when returning the Thermometer to the
after-sales service or a regional branch. The delivery must be agreed upon in advance with the
consignee.
For delivery, indicate the reasons for returning it through an enclosed note as simple as possible.
Use only the original packing.
Any damage caused by shipment using NOT the original packaging will be charged in any case
to the consignor.
The manufacturer will not be responsible for any damage to persons or things.
The warranty does not apply to the following cases:
Accessories and batteries are not included in the warranty.
Unsuitable use of the Thermometer or combining the latter with incompatible Thermometer
or accessories.
Repairs resulting from incorrect shipping.
•
•
•Repairs resulting from servicing carried out by a person not approved by the company.
•Modications to the Thermometer without explicit authorization from our technical
department.
•
Inappropriate applications are not provided for by the denition of the Thermometer or by the
instruction manual.
•
The contents of this manual may not be reproduced in any form whatsoever without the
manufacturer’s authorization.
8.2 Before calling Service
If the Thermometer should not work correctly, check the battery condition before contacting the
DEALER OR THE SERVICE CENTRE. Change it if necessary.
If the Thermometer still does not work, check if your operating procedure agrees with the
description in this manual.
FOR TECHNICAL ASSISTANCE,
PLEASE CONTACT:
Remarks: Due to our policy of continual product development, we reserve
the right to amend the specications of the mentioned products without
notice.
BT-61
REV1.0/AUG22
If the device is not used for a long time, remove the Battery from the device and store it in
a cool, dry place.
4.
