BST HEATING BST-Series User manual

INFRARED PANEL HEATER
HANDLEIDING/MANUAL
BST-SERIES

- 2 - -
SYMBOLS USED IN THIS MANUAL
Warning
This indicates a hazard which can result in serious injury or
death.
Warning of electrical shock
This symbol indicates electrical shock with possibly lethal
result.
Subject to printing errors

- 3 - -
INDEX
ENGLISH
1┃WARNING & PRECAUTION 4
2┃FEATURES 6
3┃TECHNICAL INFORMATION 6
4┃WHAT IS IN THE BOX 7
5┃INSTALLATION 7
6┃MAINTENANCE & CLEANING 9
7┃STORAGE 10
8┃DISPOSAL 10
9┃OPTIONAL CEILING MOUNTING 11
10┃SMART MIRROR 14
NEDERLANDS
1┃VEILIGHEIDSVOORSCHRIFTEN 16
2┃KENMERKEN 18
3┃TECHNISCHE INFORMATIE 18
4┃IN DE DOOS 19
5┃INSTALLATIE 19
6┃ONDERHOUD 21
7┃OPSLAG 22
8┃VERWIJDEREN 22
9┃OPTIONELE PLAFOND MONTAGE 23
10┃SMART MIRROR 26

- 4 - -
2┃WARNING & PRECAUTION
Read this manual carefully before starting or using the device. Failure to follow
the warnings and instructions in this manual may result in electrical shock, fire
and/or serious injury. Keep this manual in a safe place so you can always
quickly find and read these instructions.
Warning
Closely check whether the panels you have bought are for the
wall or the ceiling. Wall panels can only be mounted on the
wall, while ceiling panels can be mounted to the ceiling and
the wall. Follow these guidelines closely in order to avoid
overheating.
Warning
This appliance can be used by children of 8 years and above
and persons with reduced capabilities. However, supervision
is advisable and instructions should be given on how to use
the appliance in a safe way and to understand the hazards
involved.
The device is not a toy and children should not play with the
device. Children without supervision should not maintain nor
clean the heating panels.
Warning
Children under 3 years of age should be kept away from the
device unless constantly supervised.
Children between 3 and 8 years of age shall
only switch the device on/off provided that it has
been placed or installed in its intended normal
operating position and they have been given
instructions concerning the use of the device in a safe way so
they understand the hazards involved.

- 5 - -
Children between 3 and 8 years of age shall not plug in, clean
the device or perform user maintenance.
Warning
Do not use the device in small rooms where people are
present that cannot leave the room independently and
who are not under constant supervision.
Warning
Some parts of this product can become very hot and could
cause burns when touched for a longer period. Particular
attention has to be given if children and/or vulnerable people
are too close to the device.
It is dangerous to install the device close to curtains and other
inflammable materials.
• Remove all the protective films (both on the front and on the back)
before using.
• Be sure the input voltage is between 220-240V/50Hz with a grounded
power supply in accordance with IEC rules.
• Ensure a sufficient large fuse when connecting the panels to your
electrical system.
• Use the device in an upright and stable position. Do not move the
device during operation.
• Do not place objects such as towels and/or clothes above or directly in
front of the device.
• Do not sit on the device.
• Ensure that the electric cables are not damaged before use.
• Never drill holes into the heating device.
• Do not use this device in the near vicinity of water (bathtubs, showers,
etc) due to risk of electric shock.
• The device can be used in the bathroom in the dedicated zone.

- 6 - -
2┃FEATURES
Infrared heating is a very good alternative for air heating systems. By warming
objects instead of the air, warmth is kept longer in the room due to the fact
that objects stay longer warm than air. This creates a comfortable climate.
The device is designed to provide an efficient, comfortable and healthy heating
system for domestic and/or office use.
These devices reduce air circulation and can help to maintain a clean, silent
and dust free environment.
3┃TECHNICAL INFORMATION
Heating method
Far infrared heating
Voltage
220-240V/50Hz
Surface temperature
Wall mounted: 75-95℃
Ceiling mounted: 80-100℃
Frame
Aluminum
IP grade
IP54 (exclude plug)
Overheating protection
Yes
Power cord
1.9m
Model
Size
(mm)
Power
(W)
Rated
Current
Mounting
way
BST36
595*595*25
270
1.17
Wall/Ceiling
BST72
1195*595*25
550
2.4
Wall/Ceiling
BST36M
600*600*12
320
1.4
Wall only
BST36SM
600*600*23
200
0.87
Wall only

- 7 - -
4┃WHAT IS IN THE BOX
This manual
A. 1 x infrared heating panel/mirror
B. 4 x screws
C. 4 x wall plug
D. 1 x drilling template
This kit can only be used for wall mounting. A kit for ceiling mounting is
optionally available. Please consult your supplier for more information.
5┃INSTALLATION
First remove all the protective film from the front and the back of the panel.
The instructions below are only for wall mounting.
1. Choose the mounting position while keeping the required minimum
distances from the walls in the room (see figure 1 below).
Distances required for device mounting
In front of the panel
Minimum 30cm
Left
Minimum 10cm
Right
Minimum 10cm
Top
Minimum 50cm

- 8 - -
2. Mark the positions for the holes on the drilling template (D) according to
your panel size. Place the drilling template on the wall.
Drill the holes with an 8mm drill bit (see figure 2 below).
3. Insert the wall plugs in the holes and screw the screws into the plugs (see
picture 3).
The screws should protrude approximately 0.5 cm from the plugs.
4. Place the infrared heating device over the screws (see picture 4).
5. Slide the infrared heating device and position it over the screws into the
correct positions as shown in picture 5.

- 9 - -
5. Plug in to start using the heating device.
6┃MAINTENANCE & CLEANING
Please read the following guidelines when performing maintenance
activities:
• First unplug the heating panel.
• Do not touch the mains plug with wet hands.
• Hold the mains plug while pulling the power cable out of the socket.
• Allow the device first to completely cool down.
• Do not open the housing of the panel to avoid electrical shock.
Maintenance must only be carried out by an authorized specialist.
Please read the following guidelines when cleaning the panel:
• Never immerse the device in water.
• Clean the device with a soft, damp and lint-free cloth. Ensure that no
moisture enters the housing. Protect electrical components from
moisture. Do not use any aggressive cleaning agents such as cleaning
sprays, solvents, alcohol-based or abrasive cleaners to dampen the
cloth.
• Dry the housing after cleaning.
• Do not operate the device when it is still wet.

- 10 -
-
7
┃
STORAGE
When the infrared panel is not in use, please follow the following storage
conditions:
• Store the panel at a dry location protected from frost and heat.
• Store the panel in vertical position.
• Store the panel protected from dust and direct sunlight.
• Place no objects on top of the panel to prevent it from being damaged.
8┃DISPOSAL
This equipment must not be disposed of with household waste at the end of its
lifetime. You will find collection points for free return of electrical and
electronic equipment in your neighborhood.

- 11 -
-
9┃OPTIONAL CEILING MOUNTING
The ceiling mounting set is not included in the delivery and should be ordered
separately. In that package is included:
4 x
1. Drill four holes in the ceiling with correct distance A and distance B. Use
proper plugs for hanging the 4 units to the ceiling.
Panel size (mm)
Hole distances (mm)
605*605
A = 310, B = 474
1205*605
A = 660, B = 474
2. Mount the four hanging units onto ceiling with screws and fasten them
tightly.

- 12 -
-
3. Take off all the four plastic caps at the rear of the panel.
4. Move the panel in such a way that the ceiling units slide into the designated
openings. Then move the panel close to the ceiling and slide it in the
opposite direction such that the ceiling units slide into the other openings.
See the figure below for detailed pictures.

- 13 -
-
The below picture shows how the panel is mounted on the ceiling:

- 14 -
-
10
┃
SMART MIRROR
The picture below shows the layout of the smart mirror:
Operating instructions:
• Plug in power and the backlit of the touch button will light up white
indicating the active mode.
• Single-click the touch button for switching on/off the LED light.
• Double-click the touch button for switching on/off the weather display.
Note: The weather display first needs to be configured; please check
the instructions via the QR code/weblink below.
• Long press the touch button to turn on/off the heating function. When
the heating function is active, the backlit of the touch button is blue.
For the configuration of the weather display via tablet/smart
phone, please scan the QR code or surf to
www.BSTHeating.com/SmartMirror/APP_Installation
1
Mirror surface
2
LED strip
3
Touch button
4
Display screen
5
Mounting bracket
6
Temperature and
humidity sensor
7
Not used

- 15 -
-
NEDERLANDS – SYMBOLEN IN DEZE HANDLEIDING
Waarschuwing
Dit icoon geeft een gevaar aan dat (dodelijk) letsel kan
veroorzaken.
Waarschuwing voor elektrische schok
Dit icoon geeft gevaar aan voor elektrische schok met
mogelijk de dood tot gevolg.
Drukfouten voobehouden

- 16 -
-
1
┃
VEILIGHEIDSVOORSCHRIFTEN
Lees deze handleiding zorgvuldig door voor gebruik van het paneel. Indien deze
veiligheidsvoorschriften niet worden opgevolgd, kan dit resulteren in
elektrische schok, brand en/of lichamelijk letsel. Bewaar deze handleiding op
een veilige plaats, zodat je deze altijd als referentie kunt gebruiken.
Waarschuwing
Controleer of de aangeschafte panelen voor de muur of het
plafond zijn. Muurpanelen mogen alleen op de muur worden
gemonteerd, terwijl plafondpanelen aan de wand en het
plafond kunnen worden opgehangen. Volg deze
aanbevelingen om oververhitting te voorkomen.
Waarschuwing
Dit apparaat kan worden bediend door kinderen van 8 jaar en
ouder en door personen met beperkingen. Toezicht is echter
geadviseerd en instructies moeten zijn gegeven hoe het
paneel op een veilige manier kan worden gebruikt, zodat de
gevaren bekend zijn.
Het paneel is geen speelgoed en kinderen mogen het paneel
niet onderhouden en/of schoonmaken zonder toezicht van
een volwassene.
Waarschuwing
Kinderen onder 3 jaar moeten uit de buurt worden gehouden
van het paneel, tenzij er permanent toezicht beschikbaar is.
Kinderen tussen 3 en 8 jaar kunnen alleen het paneel aan- of
uitzetten mits het paneel stevig is vastgezet en instructies
betreffende het veilig gebruik zijn gegeven.
Kinderen tussen 3 en 8 jaar mogen het paneel niet inpluggen,
schoonmaken en onderhouden.

- 17 -
-
Waarschuwing
Gebruik het paneel niet in kleine ruimtes waar personen
verblijven die niet zelfstandig de ruimte kunnen verlaten en
die niet onder toezicht zijn.
Waarschuwing
Sommige onderdelen van dit product kunnen zeer heet
worden en brandwonden veroorzaken. Speciale aandacht
moet worden geschonken als kinderen of kwetsbare personen
te dicht bij het paneel komen.
Het is gevaarlijk het paneel te dicht bij gordijnen of andere
brandgevaarlijke materialen in de buurt te zetten. Let op voor
dit soort situaties.
• Verwijder als eerste alle beschermfolie van de voor- en achterkant van
het paneel.
• Zorg dat de aangesloten spanning 220-240V/50Hz met een geaarde
spanningsbron is in overeenstemming met IEC regels.
• Zorg voor een voldoende grote zekering in de meterkast bij het
aansluiten van de panelen.
• Gebruik het paneel in stabiele stand. Verplaats het paneel niet als het
aanstaat.
• Plaats geen voorwerpen zoals handdoeken en/of kleding op of direct
voor het paneel.
• Ga niet op het paneel zitten.
• Boor geen gaten in het paneel.
• Gebruik het paneel niet in de buurt van water (bad, douche, etc.).
• Het paneel kan worden gebruikt in de badkamer in de toegestane
zone.

- 18 -
-
2
┃
KENMERKEN
Infrarood verwarming is een goed alternatief voor luchtverwarming zoals een
CV. Doordat voorwerpen worden verwarmd en niet de lucht, wordt warmte
langer vastgehouden in de ruimte, zodat een aangenaam klimaat wordt
gecreëerd.
Het paneel is zodanig ontworpen om als een efficiënt, comfortabel en gezond
verwarmingselement te dienen voor zowel thuis als op kantoor.
Het paneel reduceert luchtcirculatie en zorgt voor een schone stofvrije
omgeving.
3
┃
TECHNISCHE INFORMATIE
Verwarming methode
Far Infrared heating
Voltage
220-240V/50Hz
Oppervlakte temperatuur
Aan de muur: 75-95℃
Aan het plafond: 80-100℃
Frame
Aluminium
IP graad
IP54 (exclusief stekker)
Oververhitting bescherming
Ja
Stroomkabel
1.9m
Model
Afmetingen
(mm)
Vermogen
(W)
Stroom
(A)
Ophangen
BST36
595*595*25
270
1.17
Muur/Plafond
BST72
1195*595*25
550
2.4
Muur/Plafond
BST36M
600*600*12
320
1.4
Muur
BST36SM
600*600*23
200
0.87
Muur

- 19 -
-
4
┃
IN DE DOOS
Deze handleiding
A. 1 x infrarood verwarmingspaneel
B. 4 x schroeven
C. 4 x pluggen
D. 1 x boormal
Deze onderdelen kunnen alleen worden gebruikt voor wandmontage. Een
optionele kit voor plafondmontage is separaat beschikbaar. Neem contact op
met de leverancier voor meer informatie.
5
┃
INSTALLATIE
Verwijder als eerste alle beschermfolie van de voor- en achterkant van het
paneel. De instructies hieronder zijn alleen voor montage aan de muur.
1. Kies de plaats waar het paneel moet komen te hangen. Houd rekening
met de afstand ten opzichte van de muren in de kamer (zie figuur 1
hieronder).
Afstand van de muur voor montage
Voor het paneel
Minimaal 30cm
Links
Minimaal 10cm
Rechts
Minimaal 10cm
Boven
Minimaal 50cm

- 20 -
-
2. Markeer de posities voor de boorgaten op de boormal (D) volgens de
markeringen op de mal. Plaats de boormal op de muur.
Gebruik een 8mm boortje om de gaten te boren (zie figuur 2 hieronder).
3. Duw de pluggen in de gaten en schroef de schroeven in de pluggen (zie
figuur 3). De schroeven moeten ongeveer 0.5cm uitsteken.
4. Plaats het paneel over de schroeven (zie figuur 4).
5. Laat het paneel over de uitstekende schroeven zakken zodat het vast
komt te hangen zoals op figuur 5 is getoond.
This manual suits for next models
4
Table of contents
Languages:
Popular Heater manuals by other brands

Tecnogas
Tecnogas TECNOBREEZE Stealth Wind Installation and use manual

DeLonghi
DeLonghi TRD40615T-6A Instructions for use

Rheem
Rheem RXHK-D01 installation instructions

Mistral
Mistral MCH5/1000 operating instructions

MILL
MILL PTC Series Assembly and instruction manual

SINED
SINED CALDO-VETRO-NERO-2000 manual
