BT EDGE 2100 User manual

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
User Guide
BT EDGE 2100

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
Section
Digital call quality with a range of up to 300 metres
outdoors and up to 50 metres indoors.
100 Name and number directory.
Caller Display* lets you see who is calling and keep track
of unanswered calls.
With Call Waiting*, when you are on a call a soft beep
alerts you to another waiting call.
Register up to 5 handsets to the base without the need
for additional wiring, giving you a complete phone
system on a single line.
* You must subscribe to your network provider’s Caller Display or Call Waiting
service for these features to work. A quarterly fee is payable.
Please note that this equipment is not designed for making emergency
telephone calls when the power fails. Alternative arrangements should be made
for access to emergency services.
Welcome…
to your BT Edge 2100 digital
cordless telephone

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
Section
This User Guide provides you with all
the information you need to get the
most from your phone.
You must first set up your phone
before you can use it. This doesn’t
take long and is easy to do. Just
follow the simple instructions on the
next few pages.
Need help?
If you have any problems setting up or using your BT
Edge 2100, contact the Helpline on 0870 605 8047.
Alternatively, you may find the answer in ‘Help’ at the
back of this guide.
Got everything?
BT Edge 2100 handset
BT Edge 2100 base unit
Mains power adaptor
(Item code: 872260)
Telephone line cord
2 x NiMH AAA
rechargeable batteries
If you have purchased
aBT Edge 2100 multiple
pack you will also
receive the following for
each additional handset.
BTEdge 2000 handset
BT Edge 2000 charger
Mains power adaptor
(Item code: 021299)
2 x NiMH AAA
rechargeable batteries

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
Getting started
Location . . . . . . . . . . . . . . . . . . . . . . .6
Setting up . . . . . . . . . . . . . . . . . . . . . .6
Getting to know your phone
Handset buttons . . . . . . . . . . . . . . . . .9
Handset display icons . . . . . . . . . . . . .10
Base . . . . . . . . . . . . . . . . . . . . . . . . . .11
Navigating the menus . . . . . . . . . . . . .12
Character map . . . . . . . . . . . . . . . . . .12
Menu map . . . . . . . . . . . . . . . . . . . . . .13
Using the phone
Make an external call . . . . . . . . . . . . . .14
Preparatory dialling . . . . . . . . . . . . . . .14
End a call . . . . . . . . . . . . . . . . . . . . . .14
Receive a call . . . . . . . . . . . . . . . . . . . .14
Earpiece volume . . . . . . . . . . . . . . . . .15
Secrecy . . . . . . . . . . . . . . . . . . . . . . . .15
Handsfree . . . . . . . . . . . . . . . . . . . . . .16
Paging . . . . . . . . . . . . . . . . . . . . . . . . .17
100 Name and number directory . . . . .17
Store a name and number . . . . . . . . . .17
View and dial a name and number . . . .18
Edit a name and number . . . . . . . . . . .19
Delete a name and number . . . . . . . . .19
Redial the last number called . . . . . . . .20
Redial a number from the redial list . . .20
Copy a number from the redial list
to the directory . . . . . . . . . . . . . . . . . .21
Delete a redial number . . . . . . . . . . . .22
Delete all numbers from the
redial list . . . . . . . . . . . . . . . . . . . . . . .22
Base settings
Base ringer volume . . . . . . . . . . . . . . .23
Base ringer melody . . . . . . . . . . . . . . .23
Dial mode . . . . . . . . . . . . . . . . . . . . . .24
Restore default settings . . . . . . . . . . . .25
Handset settings
Keypad lock . . . . . . . . . . . . . . . . . . . . .26
Set the time . . . . . . . . . . . . . . . . . . . .26
Handset ringer volume . . . . . . . . . . . .27
Handset ringer melody . . . . . . . . . . . .27
Handset warning tones . . . . . . . . . . . .28
Auto answer . . . . . . . . . . . . . . . . . . . .29
Handset name . . . . . . . . . . . . . . . . . . .29
Handset language . . . . . . . . . . . . . . . .30
BT Calling Features
Caller Display . . . . . . . . . . . . . . . . . . .31
4 In this guide

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
5In this guide
Call list . . . . . . . . . . . . . . . . . . . . . . . .31
View and dial from the Calls list . . . . . .31
Copy a Calls list number
to the directory . . . . . . . . . . . . . . . . . .32
Delete a Calls list number . . . . . . . . . .33
Delete the whole Calls list . . . . . . . . . .33
Call Waiting . . . . . . . . . . . . . . . . . . . . .34
Using additional handsets
Registering your handset . . . . . . . . . . .35
Select a base . . . . . . . . . . . . . . . . . . . .36
De-register a handset . . . . . . . . . . . . .37
Internal calls . . . . . . . . . . . . . . . . . . . .37
Transferring calls . . . . . . . . . . . . . . . . .37
3-Way Call . . . . . . . . . . . . . . . . . . . . . .38
Help ..........................39
General information
Safety .........................44
Cleaning . . . . . . . . . . . . . . . . . . . . . . .45
Environmental . . . . . . . . . . . . . . . . . . .45
Guarantee . . . . . . . . . . . . . . . . . . . . . .46
Returning your phone . . . . . . . . . . . . .48
How many telephones can
you have? . . . . . . . . . . . . . . . . . . . . . .48
R&TTE . . . . . . . . . . . . . . . . . . . . . . . .49
Declaration of Conformance . . . . . . . .50
Connecting to a switchboard . . . . . . . .51
Insert a pause . . . . . . . . . . . . . . . . . . .51
Recall . . . . . . . . . . . . . . . . . . . . . . . . .51

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
WARNING
Do not place your BT Edge 2100 in
the bathroom or other humid
areas.
The BT Edge 2100 has a range of
300m outdoors when there is a
clear line of sight between the base
and the handset. When there is no
clear line of sight between the
handset and the base, e.g. the
base is indoors and the handsets is
either indoors or outdoors, the
range could be reduced to 50m.
Thick stone walls will severely
affect the range.
Signal strength
The symbol on your handset
indicates when you are in range.
When you are out of range a beep
will sound every minute.
IMPORTANT
Do not connect the telephone line
until your handset is fully charged.
The base station must be plugged
into the mains power at all times.
Location
You need to place your BT Edge 2100 within 2 metres of
the mains power socket and telephone socket so that the
cables will reach.
Make sure it is at least 1 metre away from other
electrical appliances to avoid interference.
Your BTEdge 2100 works by sending radio signals
between the handset and base. The strength of the
signal depends on where you site the base. Putting it
as high as possible ensures the best signal.
Setting up
1. Insert the 2 x AAA NiMH batteries supplied into the
handset .Slide the battery compartment into place .
21
Getting started 6
Which socket?
Power socket
Telephone line socket
Line
1 2

2. Plug the mains power cord into the underside of the base
and into the mains power.
The green Power/In use light comes on.
3. Place the handset on the base to charge for at least 24
hours. The red Charging light comes on. When the
handset is fully charged the display shows the symbol.
4. After 24 hours, plug one end of the telephone line cord
into your BT Edge 2100 base and the other end into the
telephone wall socket.
7Getting started
The red Charging light stays on
even when the batteries are fully
charged.
Talk/Standby time
Under ideal conditions, fully
charged handset batteries should
give about 10 hours talk time or
100 hours standby time on a single
charge.
BATTERY LOW WARNING
If the symbol is empty and
flashing, and you hear a warning
beep every 10 -15 seconds, you
will need to recharge your handset
before you can use it.
Battery performance
To keep your batteries in the best
condition, leave the handset off
the base for a few hours at a time
(after the initial 24 hour charge).
New NiMH batteries do not reach
full capacity until they have been in
normal use for several days.
Running the batteries right down
at least once a week will help them
last as long as possible.
The charge capacity of
rechargeable batteries will reduce
with time as they wear out, so
reducing the talk/standby time of
the handset. Eventually they will
need to be replaced. New batteries
can be obtained from the BT Edge
Helpline 0870 605 8047.
BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
Line

Additionally, if you have purchased a BT Edge 2100
multiple pack.
For each additional handset and charger:
1. Connect the power adaptor to the charger and switch on.
2. Insert the 2 x AAA NiMH batteries supplied into
the handset.
3. Place the handset on the charger and charge for at
least 24 hours. The red charging light will come on.
Your BT Edge 2000 additional handset comes pre-
registered to the base. The handset number will be
shown on the display.
Your BT Edge 2100 is now ready to use.
8 Getting started
BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
Getting to know your phone 9
Handset buttons
Keypad
Recall/Call Waiting/Intercom
For use with a switchboard/PBX
and BT Calling Features, page 31.
For use with Call Waiting, page 34.
Use to make internal calls, page 37.
Talk / Handsfree
Press to make or receive calls,
page 14.
Also used to switch
handsfree on and off, page 16.
Option buttons
Let you select options shown on
the display, page 12.
Menu/Volume/Up and Down
Press to access and scroll through
the menu options, page 12.
Use to adjust the handset volume,
page 27.
End Call / Clear
Press to end a call, page 14.
Press and hold to exit the menu
and return to standby.
Redial/Pause
Use to redial any of the last 20
numbers called, page 20.
Press to enter a pause in a
number, page 51.

10 Getting to know your phone
BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
Handset name
The handset name is displayed in standby mode.
Handset number
The handset number is displayed in standby mode.
Battery levels
Shows handset battery status. Scrolls when the
handset is charging in the base.
Directory
Select icon to view the directory.
Calls list*
Flashes to indicate new Calls list entries.
The number of new entries is displayed above.
Range
Displayed in standby mode to indicate handset is in
range of the base. Flashes if you go out of range.
Handset display icons –These are the symbols you will see on your handset’s screen.
*You must subscribe to your network provider’s Caller Display service for this feature to work.
Sec
Edge 2100
HS1
Ext
Int
09:30
Sec
BT Edge HS1
02
Ext
Keypad lock
Displayed when the keypad is locked.
External
Displayed when an external call is
being received or in progress.
Internal
Displayed when an internal call is
being received or in progress.
Handsfree
Displayed when in handsfree mode.
Secrecy
The option to switch secrecy on.
02

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
11Getting to know your phone
Base
BT Edge 2100
Charging
Power /
In Use
Page
Page
Press to page the handset,
page 17.
Power/In use light
(GREEN)
On when the power is on.
Flashes when the handset
is in use.
Charging light (RED)
Comes on when the
handset is charging
on the base.

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
Navigating the menus
Your BT Edge 2100 has an easy to use menu system.
Each menu has a list of options, which you can see on
the menu map on the following page.
When the handset is switched on and in standby:
1. Press to open the main menu then press or
to scroll to the menu option you want.
2. The buttons below the display allow you to select
options within each menu.
Character map
The following table shows you where each letter and
punctuation character can be found. This will be helpful
when storing a name in the directory, see page 17.
Menu
RLNR
Select the option displayed by
pressing the button underneath it.
Exit or go back one level in
the menu
Press to go back one level
or press and hold to return
to standby.
If no buttons are pressed for 20
seconds, the handset reverts to
standby automatically.
12 Getting to know your phone
Button Upper Lower
case case
@-1 @-1
ABC2 abc2
DEF3 def3
GHI4 ghi4
JKL5 jkl5
MNO6 mno6
Button Upper Lower
case case
PQRS7 pqrs7
TUV8 tuv8
WXYZ9 wxyz9
,.* ,.*
Space + & 0 Space + & 0
##

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
13Getting to know your phone
Menu map
H
Ha an nd ds se et tS Se et tt ti in ng gs s
Time Setting
Handset Ringer Volume
Handset Ringer Melody
Auto Answer
Handset Name
Language
Warning Tones
Base Settings
Base Ringer Volume
Base Ringer Melody
PIN Code
Dial Mode
Restore Settings
R
Re eg gi is st tr ra at ti io on n
Register Base
Select Base
De-Register Handset

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
Using the phone 14
Make an external call
1. Lift the handset and press .
The green In Use light on the base flashes and the
Ext
icon is displayed.
2. When you hear the dialling tone, dial the number
you want.
Preparatory dialling
1. First enter the number to be dialled. The number
is shown on the display.
2. Press to dial the number. The display
shows
Dialling .
End a call
1. Press .
Or
Place the handset back on the base.
Receive a call
When the phone rings External Call is displayed.
1. If your handset is on the base, pick it up to answer
the call.
Call timer
Your handset will automatically
time the duration of all external
calls. The handset display shows
the call duration both during and
for a few seconds after your call.
Press to delete any incorrect
digits
The symbol on the display
indicates when you are in range of
the base. If the symbol flashes and
you hear a warning beep, you are
out of range and will need to move
closer to the base.
Caller Display
If you have subscribed to your
network’s Caller Display service,
the caller’s number (or name
if stored in the directory) is
displayed. See page 31 for
more information.
Auto answer
As long as you have auto answer
set to ON you can just pick the
handset up off the base to answer
the call. If you have switched it off,
you will need to press the .
Auto answer is the default setting.

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
15Using the phone
Or
If your handset is off the base, press .
Earpiece volume
During a call you can adjust the volume of the
earpiece/handset receiver.
1. Press or to increase or decrease the volume.
As you increase or decrease the volume, the boxes on
the display show the volume level.
Maximum volume
Mid volume
Minimum volume
Secrecy
During a call, you can talk to someone nearby without
your caller hearing.
1. Select Sec option.
Secrecy On appears in the display and your caller is put
on hold and cannot hear you.
2. Select Off option again to return to your caller.
If auto answer is set to off, you will
need to press at all times, see
page 29.

Handsfree
Handsfree lets you talk to your caller without holding
the handset. It also enables other people in the room to
listen to your conversation over the loudspeaker.
Make a call in handsfree
1. Dial the number then press .
2. Press again. The icon is displayed and you hear
your call over the loudspeaker.
3. Press to end the call.
Answer a call in handsfree
When the phone rings:
1. Press twice. The call is transferred to
the loudspeaker.
Switch to handsfree during a call
During a call:
1. Press .The call is transferred to the loudspeaker.
2. Press to end the call.
16 Using the phone
During a handsfree call, press
or to change the volume.
To switch handsfree off and
return to the handset at any time,
press .
BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032

17Using the phone
BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
Paging
You can alert a handset user that they are wanted or
locate a missing handset.
1. Press on the base. The paged handset(s) rings
2. Press to stop the paging ring
Or
Press any button on the handset.
100 Name and Number Directory
You can store up to 100 names and numbers in the
Directory. Names can be up to 13 characters long and
numbers up to 20 digits.
There is a character map on page 12 to help you when
entering names.
Store a name and number
1. Select option, then New option.
Enter Name is displayed.
2. Enter the name using the keypad.
3. Select OK option to confirm.
Enter Number is displayed.
Page
Page
Paging calls cannot be answered
by a handset.
The paging ring will stop
automatically after one minute
if no button is pressed and your
handset will return to standby.
Entering names
Use the keypad letters to enter
names, e.g. to store TOM:
Press once to enter T.
Press three times to enter O.
Press once to enter M.
Writing tips
Press CLEAR to delete the last
character or digit.
Select A-a option to switch
between upper and lower case.
Press to insert a space.
Use , , and for
other punctuation characters, see
page 12 for full character map.
You MUST enter a name and a
number, otherwise the display will
show Error and then return to the
number entry display.

To search alphabetically
Press the relevant keypad button,
e.g. for TOM, press 8then scroll
through the entries under T.
4. Enter the telephone number. (Enter the full telephone
number including the dialling code if you subscribe to a
Caller Display service and want the name of your caller
displayed instead of the number.)
5. Select OK option to confirm.
6. The handset ringer melody options are displayed. Use the
or to scroll through the options. You will hear a
sample melody. Press Save to confirm the setting.
Display shows
Entry Saved .
7. Press and hold to exit and return to standby.
View and dial a name and number
1. Select option.
The first directory entry is displayed.
If there are no entries stored
Directory Empty will be
displayed.
2. Use or to scroll and find the entry you want or
search alphabetically.
3. Press button to dial the displayed number.
18 Using the phone
The ringer melody option means
that when you receive a call from
a number stored in your directory
the ringtone you choose will be
played.
To enter a pause in a directory
number, press the button.
For more information on pauses,
see page 51.
BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032

19Using the phone
BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
Edit a name and number
1. Select option.
The first directory entry is displayed.
2. Use or to scroll and find the entry you want to
edit or search alphabetically.
3. Select Edit option.
Edit Name and the name is displayed.
4. Press to delete any incorrect characters, then enter
new ones and select OK option to confirm.
Edit Number is displayed.
5. Press to delete any incorrect digits, then enter new
ones and select OK option to confirm.
6. The handset ringer melody options are displayed. Use the
or to scroll through the options. You will hear a
sample melody. Press Save to confirm the setting.
Display shows
Entry Saved .
7. Press and hold to exit and return to standby.
Delete a name and number
1. Select option.
The first directory entry is displayed.
2. Use or to scroll and find the entry you want or
search alphabetically.
Menu
RLNR

BT Edge 2100 – Issue 2 – Edition 1.0 – 25.08.05 – 7032
3. Select Del option. Delete Entry? is displayed.
4. Select Del option to confirm.
Entry Deleted is displayed and you hear a confirmation
beep.
5. Press and hold to exit and return to standby.
Redial
The last 20 telephone numbers called are saved to a
redial list. You can then select any of the numbers to
redial, delete or copy to the directory.
Redial the last number called
1. Press , wait for the dialling tone then press .
The last number you called is displayed and dialled.
Redial a number from the redial list
1. Press . The last number called is displayed.
2. Use or to scroll through the redial list to the
number you want.
3. Press to redial.
If you decide not to delete, select
Save option.
If the number is stored in the
Directory and a name/number
match is found, the name will be
displayed instead.
You will not be able to copy a
number to the Directory if the
Directory is already full. If you try
to, the display will show
Directory Full. You will need to
delete a number in the Directory
first, see page 19.
The copy option will not be
presented if the redial number
already appears in the directory.
20 Using the phone
