BT RRE140 Operating instructions

© BT
Repair Manual en
RRE140/160/180/200/250
Valid from serial number: 6051502
Order number: 261828-040
Issued: 2008-08-21 ITS

© BT Repair Manual RRE140/160/180/200/250
Document revisions:
This manual covers following truck models:
Issue date Publication
No.
Changes
2008-08-21 261828-040 Completely new issue.
T-code Model Serial number
815 RRE140, RRE140C, (RRE140CC),
RRE140E,RRE140EC, (RRE140ECC),
RRE160, RRE160C, (RRE160CC)
RRE160E, RRE160EC, (RRE160ECC)
6051502-
816 RRE180, RRE180C, (RRE180CC),
RRE180E, RRE180EC, (RRE180ECC),
RRE200, RRE200C, (RRE200CC),
RRE200E, RRE200EC, (RRE200ECC),
RRE250, RRE250C, (RRE250CC),
RRE250E, RRE250EC, (RRE250ECC)
6051502-

Contents
Publication No. Date Valid from serial number T-code
261828-040 2008-08-21 6051502 815, 816
© BT Repair Manual RRE140/160/180/200/250 1 – 1
1 – Contents
1 – Contents ............................................................................................. 1-1
2 – General introduction ......................................................................... 2-1
2.1 How to use the manual................................................................... 2-1
2.2 Warning symbols ........................................................................... 2-2
2.3 Pictograms..................................................................................... 2-2
3 – General safety rules .......................................................................... 3-1
3.1 Safety while working ...................................................................... 3-1
3.2 Electrical system ............................................................................ 3-2
3.3 Safe lifting ...................................................................................... 3-3
4 – Functions and parameters ................................................................ 4-1
4.1 Chassis 0000 ................................................................................. 4-1
4.1.1 Driver protection (0840) ................................................... 4-1
Tilt stops .......................................................................... 4-1
Overhead guard ............................................................... 4-2
4.2 Motors 1000 ................................................................................... 4-3
4.2.1 General ............................................................................ 4-3
4.2.2 Electric pump motor (1710) ............................................. 4-3
General ............................................................................ 4-3
Design ............................................................................. 4-3
4.2.3 Electric steering motor (1730) ......................................... 4-4
General ............................................................................ 4-4
Design ............................................................................. 4-4
4.2.4 Fan motor/fan (1740) ....................................................... 4-5
4.2.5 Electric drive motor (1760) .............................................. 4-6
General ............................................................................ 4-6
Design ............................................................................. 4-6
4.3 Drive gear – 2000........................................................................... 4-7
4.3.1 General ............................................................................ 4-7
4.3.2 Design ............................................................................. 4-8
4.4 Brake system 3100 ........................................................................ 4-9
4.4.1 General ............................................................................ 4-9
Travel brake ..................................................................... 4-9
Parking brake .................................................................. 4-9
Emergency brake ............................................................ 4-9
4.4.2 Drive motor brake (travel brake) .................................... 4-10
Accelerator released ...................................................... 4-10
Changing the direction of travel ..................................... 4-10
4.4.3 Multiple disc brake, support arm (travel brake) ............. 4-11
General .......................................................................... 4-11
Design ........................................................................... 4-11
4.4.4 Disc brake on the drive motor (parking brake) .............. 4-12
General .......................................................................... 4-12
Design ........................................................................... 4-12
4.5 Steering system 4000 .................................................................. 4-13
4.5.1 General .......................................................................... 4-13
Design ........................................................................... 4-13
4.6 Operator compartment................................................................. 4-14
4.6.1 Truck control, overview .................................................. 4-14

1 – 2 Repair Manual RRE140/160/180/200/250 © BT
Contents
T-code Valid from serial number Date Publication No.
815, 816 6051502 2008-08-21 261828-040
Right-hand control panel, single control ........................ 4-14
Right-hand control panel, multi-control .......................... 4-14
Emergency switch off .................................................... 4-14
Steering module ............................................................ 4-15
Pedals ............................................................................ 4-16
4.6.2 Single control ................................................................. 4-17
4.6.3 Multi-control ................................................................... 4-18
4.6.4 Central Information Display – CID ................................. 4-19
CID LED symbols .......................................................... 4-19
CID information symbols in the display area ................. 4-20
CID disable indications in the display area .................... 4-21
CID service symbols in the display area ........................ 4-22
Driver parameter symbols ............................................. 4-23
Navigation ...................................................................... 4-24
4.6.5 Load Information Display – LID (option) ........................ 4-27
LID LED symbols ........................................................... 4-27
LID symbols in the display area ..................................... 4-28
4.7 Operation and connection sequences.......................................... 4-29
4.8 Functions ..................................................................................... 4-43
4.8.1 General overview ........................................................... 4-43
Key ................................................................................ 4-43
Components .................................................................. 4-43
4.8.2 MCU – Main Control Unit ............................................... 4-44
General .......................................................................... 4-44
System communication ................................................. 4-44
4.8.3 ACT/ACH transistor regulators ...................................... 4-44
General .......................................................................... 4-45
4.8.4 Start-up .......................................................................... 4-45
4.8.5 Shutdown ....................................................................... 4-45
4.8.6 Driving ........................................................................... 4-46
Introduction .................................................................... 4-46
Acceleration and speed reduction ................................. 4-46
Reversing ...................................................................... 4-47
Brake ............................................................................. 4-47
Travel speed .................................................................. 4-48
4.8.7 Steering ......................................................................... 4-49
Steering position check ................................................. 4-49
Steering speed .............................................................. 4-49
Steering reference ......................................................... 4-50
Travel speed limitation ................................................... 4-50
Compass card ............................................................... 4-50
4.8.8 Hydraulic system ........................................................... 4-51
Definitions ...................................................................... 4-51
Controls ......................................................................... 4-51
Lift .................................................................................. 4-51
Reach movement .......................................................... 4-52
Lift height limitation ........................................................ 4-52
Maximum height limitation ............................................. 4-52
Auxiliary/Extra functions (option) ................................... 4-53
4.9 Height preselector, description of function ................................... 4-54
4.9.1 Using the height preselector .......................................... 4-54
4.9.2 Symbols ......................................................................... 4-54
4.9.3 Buzzer ........................................................................... 4-54
4.9.4 Height preselector levels ............................................... 4-55
4.9.5 Level selection ............................................................... 4-55
4.9.6 Height programming ...................................................... 4-56

Contents
Publication No. Date Valid from serial number T-code
261828-040 2008-08-21 6051502 815, 816
© BT Repair Manual RRE140/160/180/200/250 1 – 3
4.9.7 Height preselector and TruckCom ................................. 4-57
4.9.8 Lift/lowering movement .................................................. 4-57
4.10 Hydraulic system 6000................................................................. 4-58
4.10.1 General .......................................................................... 4-58
4.10.2 Tank ............................................................................... 4-58
4.10.3 Filter ............................................................................... 4-58
Return filter .................................................................... 4-58
Dehumidification filter .................................................... 4-58
4.10.4 Hydraulic pump .............................................................. 4-59
4.10.5 Valve block .................................................................... 4-59
Main valve block ............................................................ 4-59
Other valve blocks ......................................................... 4-60
4.10.6 Cylinders ........................................................................ 4-61
Main lift cylinder ............................................................. 4-61
Free lift cylinder ............................................................. 4-61
Cylinders for the reach movement, cabin tilt, sideshift and fork
tilt ................................................................................... 4-61
4.10.7 Lift and lowering function ............................................... 4-62
Lifting and lowering of free lift ........................................ 4-62
Transition from free lift to main lift ................................. 4-62
Lifting and lowering of main lift ...................................... 4-62
Reach movement, in and out ......................................... 4-62
Simultaneous operation of mast lift and reach movement . 4-
63
4.10.8 Extra functions ............................................................... 4-63
4.10.9 Cabin tilt (RRE Ergo) ..................................................... 4-63
Hydraulic priority system ............................................... 4-63
Cabin tilt (RRE Ergo) during servicing ........................... 4-64
Cabin tilt in the event of hydraulic or electrical power loss 4-
64
4.11 Mast 7000 .................................................................................... 4-65
4.11.1 Mast and reach carriage ................................................ 4-65
4.12 Lifting devices .............................................................................. 4-66
4.12.1 Fork extensions ............................................................. 4-66
4.12.2 Telescopic forks ............................................................. 4-66
4.13 Parameters .................................................................................. 4-68
4.13.1 General .......................................................................... 4-68
4.13.2 Displaying/changing parameters ................................... 4-69
4.13.3 Parameters .................................................................... 4-69
Operator parameters, overview ..................................... 4-69
Service parameters, overview ....................................... 4-70
Factory parameters, overview ....................................... 4-75
Calibration parameters, overview .................................. 4-77
5 – Installation ......................................................................................... 5-1
5.1 Transporting the truck .................................................................... 5-1
Method 1 .......................................................................... 5-1
Method 2 .......................................................................... 5-1
5.2 Initial operation............................................................................... 5-2
5.2.1 Placing the battery ........................................................... 5-2
5.2.2 Parameters on initial operation ........................................ 5-3
Battery ............................................................................. 5-3
Load indicator .................................................................. 5-3
Ergo cabin ....................................................................... 5-3
Cold store cabin ............................................................... 5-4

1 – 4 Repair Manual RRE140/160/180/200/250 © BT
Contents
T-code Valid from serial number Date Publication No.
815, 816 6051502 2008-08-21 261828-040
5.2.3 Parameters for optional equipment ................................. 5-4
Height measurement (option) .......................................... 5-4
Travel speed limitation, height-dependent ....................... 5-4
Travel speed limitation, reach movement dependent ...... 5-4
Travel speed limitation, parameter-dependent ................ 5-5
Collision sensor (BT) ....................................................... 5-5
5.2.4 Mast, fitting ...................................................................... 5-5
6 – Maintenance ....................................................................................... 6-1
6.1 Introduction, maintenance.............................................................. 6-1
6.2 Periodic maintenance .................................................................... 6-2
6.2.1 Every 500 B-hours/180 days ........................................... 6-2
6.2.2 Every 1000 B-hours/360 days ......................................... 6-4
6.2.3 Every 2000 B-hours/720 days ......................................... 6-9
6.2.4 Every 3000 B-hours/1080 days ....................................... 6-9
6.2.5 Every 5000 B-hours/1800 days ..................................... 6-11
6.2.6 Annual status inspection ................................................ 6-11
6.3 Maintenance instructions ............................................................. 6-12
6.3.1 Cleaning and washing ................................................... 6-12
High-pressure washers .................................................. 6-12
Degreasing agents ........................................................ 6-12
Cleaning the exterior ..................................................... 6-12
Cleaning the chain ......................................................... 6-13
Cleaning the motor compartment .................................. 6-13
Electrical components ................................................... 6-13
7 – Troubleshooting ................................................................................ 7-1
7.0.1 Error log menu ................................................................. 7-1
Error information menu .................................................... 7-1
7.1 Service diagnostics menu .............................................................. 7-2
7.1.1 General ............................................................................ 7-2
7.1.2 Diagnostics states ........................................................... 7-3
State 1 – Voltage from levers .......................................... 7-3
State 2 – Digital signals from truck controls to MCU ....... 7-4
State 3 – Voltages to MCU .............................................. 7-5
State 4 – Digital input signals to MCU ............................. 7-6
State 5 – Digital output signals from MCU ....................... 7-7
State 6 – PWM outputs from MCU .................................. 7-8
State 7 – FCU (not used) ................................................. 7-8
State 8 – FCU (not used) ................................................. 7-8
State 9 – GFU (not used) ................................................ 7-8
State 10 – GFU (not used) .............................................. 7-8
State 11 – Temperature signals ...................................... 7-9
State 12 – Voltage levels ................................................. 7-9
State 13 – Travel information ........................................ 7-10
State 14 Steering information ........................................ 7-11
State 15 – Lift/lowering information ............................... 7-12
State 16 – Reach movement ......................................... 7-13
State 17 – Hydraulic information ................................... 7-14
7.2 Warning and error codes.............................................................. 7-15
Abbreviations used in this section ................................. 7-15
Error code structure ....................................................... 7-15
7.2.1 Error codes ................................................................... 7-17
7.3 ACT/ACH transistor regulators .................................................... 7-34
7.3.1 Cable connections and pole bolts .................................. 7-34

Contents
Publication No. Date Valid from serial number T-code
261828-040 2008-08-21 6051502 815, 816
© BT Repair Manual RRE140/160/180/200/250 1 – 5
7.3.2 Connections on the MCU .............................................. 7-36
7.4 Symptom tables ........................................................................... 7-38
7.4.1 Brake ............................................................................. 7-38
7.4.2 Telescopic forks ............................................................. 7-39
8 – Frame/Chassis 0000 .......................................................................... 8-1
8.1 General .......................................................................................... 8-1
8.2 Motor hood (0340).......................................................................... 8-1
8.2.1 Opening the motor compartment ..................................... 8-1
RRE 160-RRE 250 .......................................................... 8-1
8.3 Operator cabin (0500).................................................................... 8-2
Cabin tilting RRE 160-250 Ergo ...................................... 8-2
8.4 Operator compartment (0600)........................................................ 8-3
8.4.1 Internal fittings (0680) ...................................................... 8-3
8.5 Safety equipment (0800)................................................................ 8-4
8.5.1 Checking the overhead guard (0810) .............................. 8-4
8.5.2 Adjusting the tilt stops (0840) .......................................... 8-5
9 – Motors 1000 ........................................................................................ 9-1
9.1 Motor sensors ................................................................................ 9-1
9.1.1 Temperature sensor ........................................................ 9-1
Retrofitting of external temperature sensor ..................... 9-1
9.1.2 Replacing the motor speed sensor .................................. 9-2
9.2 Pump motor (1710) ........................................................................ 9-3
9.2.1 General ............................................................................ 9-3
The pump motor dismantled ............................................ 9-3
9.2.2 Replacing the bearing on the pump motor ...................... 9-4
Dismantling the pump motor ............................................ 9-4
Assembling the pump motor ............................................ 9-6
9.3 Steering motor and steering unit (1730)......................................... 9-7
9.3.1 General ............................................................................ 9-7
9.3.2 Layout of the flange holes ............................................... 9-7
9.3.3 Removing the steering motor from the truck ................... 9-8
9.3.4 Placing the steering motor in the truck ............................ 9-8
9.4 Fan motor/fan (1740) ..................................................................... 9-9
9.4.1 General ............................................................................ 9-9
9.4.2 Replacing the frequency converter cooling fan ............... 9-9
Standard truck ................................................................. 9-9
Ergotruck ......................................................................... 9-9
9.4.3 Replacing the motor compartment cooling fan .............. 9-11
9.5 Drive motor (1760) ....................................................................... 9-12
9.5.1 General .......................................................................... 9-12
The drive motor dismantled ........................................... 9-12
9.5.2 Removing the drive motor from the truck ...................... 9-13
9.5.3 Dismantling the drive motor ........................................... 9-15
9.5.4 Cleaning ........................................................................ 9-16
9.5.5 Assembling the drive motor ........................................... 9-17
9.5.6 Fitting the drive motor to the truck ................................. 9-19
10 – Drive gear 2000 .............................................................................. 10-1
10.1 General ........................................................................................ 10-1
10.1.1 Leakage from the bottom cap ........................................ 10-1
10.1.2 Replacing the drive gear ................................................ 10-2
Special tools .................................................................. 10-2

1 – 6 Repair Manual RRE140/160/180/200/250 © BT
Contents
T-code Valid from serial number Date Publication No.
815, 816 6051502 2008-08-21 261828-040
Exposing the drive gear ................................................. 10-2
Removing a drive motor from the truck ......................... 10-2
Removing a steering motor from the truck .................... 10-2
Removing the drive gear from the truck ........................ 10-3
10.1.3 Replacing the pinion gear, input shaft ........................... 10-5
Remove the pinion gear ................................................ 10-5
Placing a new ball bearing ............................................. 10-6
Fitting the sealing ring ................................................... 10-6
Inserting the pinion gear in the drive gear ..................... 10-6
10.1.4 Placing the drive gear in the truck ................................. 10-7
Placing the steering motor in the truck .......................... 10-8
Placing the drive motor in the truck ............................... 10-8
10.1.5 Refitting ......................................................................... 10-8
11 – Brake and wheel 3000 ................................................................... 11-1
11.1 Travel brake system (3100) ......................................................... 11-1
11.1.1 Removing the support arm's multiple disc brake ........... 11-1
11.1.2 Dismantling the multiple disc brake ............................... 11-1
Inspection ...................................................................... 11-2
Adjusting play ................................................................ 11-2
Assembling the multiple disc brake ............................... 11-3
11.1.3 Placing the multiple disc brake in the truck ................... 11-3
11.2 Parking brake (3300) ................................................................... 11-4
11.2.1 General .......................................................................... 11-4
11.2.2 Emergency release of the parking brake ....................... 11-5
11.2.3 Checking the brake force ............................................... 11-5
11.2.4 Removing the parking brake from the truck ................... 11-6
Dismantling and checking wear ..................................... 11-6
Assembling the parking brake ....................................... 11-7
Adjusting play ................................................................ 11-7
11.2.5 Placing the parking brake in the truck ........................... 11-8
11.3 Drive wheel (3530)....................................................................... 11-9
11.3.1 General .......................................................................... 11-9
11.3.2 Removing the drive wheel from the truck ...................... 11-9
11.3.3 Placing the drive wheel on the truck .............................. 11-9
11.4 Wheel bolt (3530)....................................................................... 11-10
General ........................................................................ 11-10
11.4.1 Replacing wheel bolts .................................................. 11-10
11.5 Support arm wheel (3550).......................................................... 11-11
11.5.1 Removing the support arm wheel from the truck ......... 11-11
11.5.2 Replacing a wheel bearing – braked wheel (A) ........... 11-12
11.5.3 Replacing a wheel bearing – unbraked wheel (B) ....... 11-13
11.5.4 Placing the support arm wheel in the truck .................. 11-14
12 – Steering system 4000 .................................................................... 12-1
12.1 Electric steering wheel (4310)...................................................... 12-1
12.1.1 General .......................................................................... 12-1
12.1.2 Replacing the pulse transducer on the steering wheel module
12-1
12.1.3 Removing the operating console from the truck ............ 12-2
12.1.4 Replacing the wiring harness in the operating console . 12-3
12.1.5 Placing the operating console in the truck ..................... 12-5
12.2 Steering reference sensor (4350) ................................................ 12-6
General .......................................................................... 12-6
12.2.1 Replacing the reference sensor ..................................... 12-6

Contents
Publication No. Date Valid from serial number T-code
261828-040 2008-08-21 6051502 815, 816
© BT Repair Manual RRE140/160/180/200/250 1 – 7
12.3 Steering bearings (4380).............................................................. 12-7
12.3.1 Removing a steering bearing from the drive gear ......... 12-7
12.3.2 Placing a steering bearing on the drive gear ................. 12-7
13 – Electrical system 5000 .................................................................. 13-1
13.1 Battery (5110) .............................................................................. 13-1
13.1.1 Battery recommendation ............................................... 13-1
Exide gel batteries (Sonnenschein, for example) .......... 13-1
Hawker Evolution gel batteries ...................................... 13-1
13.1.2 Battery installation ......................................................... 13-2
13.1.3 Setting battery parameters ............................................ 13-2
Parameter settings for valve-controlled batteries (VRLA) 13-
2
Instructions for verifying parameter settings .................. 13-2
13.2 Control console (5510)................................................................. 13-3
13.2.1 General .......................................................................... 13-3
13.2.2 Replacement/installation of a control ............................. 13-3
13.2.3 Removing the control console from the truck ................ 13-4
13.2.4 Replacing the access card's circuit board ..................... 13-5
13.2.5 Dismantling the control console ..................................... 13-6
General .......................................................................... 13-6
Installing an extra push button ....................................... 13-8
Replacing the travel direction selector with signal button 13-
8
Replacing the display .................................................... 13-9
13.2.6 Assembling the control console ..................................... 13-9
13.2.7 Placing the control console in the truck ....................... 13-10
13.3 Parameter settings..................................................................... 13-11
13.3.1 Configuration menu ..................................................... 13-11
Calendar/hour counter menu ....................................... 13-11
Parameter menu (PAR) ............................................... 13-11
Driver parameter modification ..................................... 13-12
PIN menu ..................................................................... 13-13
13.4 Calibrations................................................................................ 13-14
13.4.1 Valve calibration .......................................................... 13-14
Free lift and main lift valve calibration ......................... 13-14
Free lowering and main lowering valve calibration ...... 13-14
Reach movement valve calibration .............................. 13-15
13.4.2 Joystick calibration ...................................................... 13-16
13.4.3 Weight calibration ........................................................ 13-16
Calibrating the weight indicator ................................... 13-16
13.4.4 Height measurement/reach movement length calibration 13-
17
Calibrating height measurement (option) .................... 13-17
Calibrating reach movement length ............................. 13-18
13.4.5 Transition/mast separation calibration ......................... 13-19
14 – Hydraulic system 6000 .................................................................. 14-1
14.1 Hydraulic unit (6100).................................................................... 14-1
14.1.1 Hydraulic tank, draining ................................................. 14-2
14.1.2 Hydraulic system, bleeding ............................................ 14-3
14.1.3 Removing the pump motor from the truck ..................... 14-4
14.1.4 Replacing the hydraulic pump ....................................... 14-5
14.1.5 Fitting the pump motor in the truck ................................ 14-6
14.2 Main valve (6210)......................................................................... 14-7

1 – 8 Repair Manual RRE140/160/180/200/250 © BT
Contents
T-code Valid from serial number Date Publication No.
815, 816 6051502 2008-08-21 261828-040
14.2.1 Emergency lowering of forks ......................................... 14-7
14.2.2 Replacing the complete main valve block ..................... 14-8
14.2.3 Adjustment of maximum opening point ....................... 14-10
14.3 Hydraulic connections (6230) .................................................... 14-11
14.3.1 Tightening torque for hydraulic connections ................ 14-11
Conical connection with O-ring .................................... 14-11
Tredo seal .................................................................... 14-11
Pipe coupling ............................................................... 14-12
14.3.2 Quick change connector .............................................. 14-14
Assembling the quick change connector ..................... 14-14
Dismantling the quick change connector ..................... 14-15
14.4 Hydraulic system, mast (6300)................................................... 14-16
14.4.1 Mast-mounted hose reel (6370) .................................. 14-16
General ........................................................................ 14-16
14.4.2 Fitting the hose reel ..................................................... 14-16
Spring preloading (turns) ............................................. 14-16
14.4.3 Checks after fitting ....................................................... 14-17
14.5 Main lift cylinder (6610).............................................................. 14-18
General ........................................................................ 14-18
14.5.1 Removing the air cylinder from the mast ..................... 14-18
14.5.2 Replacing the hose rupture valve ................................ 14-18
14.5.3 Fitting the cylinder to the mast ..................................... 14-19
14.6 Free lift cylinder (6620) .............................................................. 14-20
General ........................................................................ 14-20
14.6.1 Removing the free lift cylinder from the truck .............. 14-20
14.6.2 Replacing the hose rupture valve, free lift cylinder ...... 14-20
14.6.3 Placing the free lift cylinder in the truck ....................... 14-21
14.7 Reach cylinder (6650)................................................................ 14-22
14.7.1 General ........................................................................ 14-22
14.7.2 Removing the reach cylinder from the truck ................ 14-22
14.7.3 Placing the reach cylinder in the truck ......................... 14-22
14.8 Fork tilt cylinder (6660)............................................................... 14-23
14.8.1 General ........................................................................ 14-23
14.8.2 Removing the tilt cylinder from the fork carriage ......... 14-23
15 – Mast/Lift system 7000 ................................................................... 15-1
15.1 Main mast 1.6-2.5 t (7100) ........................................................... 15-1
15.1.1 Replacing the full mast .................................................. 15-1
15.1.2 Replacing the mast damper plates ................................ 15-2
15.1.3 Removing the mast from the truck ................................. 15-3
15.1.4 Adjusting mast play ....................................................... 15-6
General .......................................................................... 15-6
Preparations .................................................................. 15-6
Adjusting lateral play ..................................................... 15-9
Adjustment of radial play ............................................. 15-10
Adjusting the damper parts .......................................... 15-10
Adjusting the damper plate .......................................... 15-11
Refitting the mast ......................................................... 15-11
15.1.5 Placing the mast on the truck ...................................... 15-12
15.2 Main lift chain system (7120) ..................................................... 15-16
15.2.1 General ........................................................................ 15-16
15.2.2 Inspecting the chain ..................................................... 15-16
Noise ........................................................................... 15-16
Surface rust ................................................................. 15-16
Rusty links ................................................................... 15-16

Contents
Publication No. Date Valid from serial number T-code
261828-040 2008-08-21 6051502 815, 816
© BT Repair Manual RRE140/160/180/200/250 1 – 9
Stiff links ...................................................................... 15-17
Bolt rotation ................................................................. 15-17
Loose bolts .................................................................. 15-17
Plate wear .................................................................... 15-18
Elongation .................................................................... 15-19
Damage ....................................................................... 15-19
Damaged plates .......................................................... 15-20
Damaged bolts ............................................................ 15-20
Dirty chain .................................................................... 15-20
15.2.3 Lubricating the chain ................................................... 15-20
15.2.4 Main lift chain system, adjusting the fork-to-floor distance ....
15-21
15.3 Reach carriage (7190) ............................................................... 15-22
15.3.1 Adjusting radial play in the reach carriage ................... 15-22
15.3.2 Adjusting axial play in the reach carriage .................... 15-24
15.4 Lifting devices (7400)................................................................. 15-25
15.4.1 Forks ............................................................................ 15-25
General ........................................................................ 15-25
Inspection .................................................................... 15-25
Inspection intervals ...................................................... 15-25
Surface cracks ............................................................. 15-25
Difference in height between the fork tips ................... 15-26
Position locks ............................................................... 15-26
Legible markings ......................................................... 15-26
Fork blades and shafts ................................................ 15-26
Mounting fixings on the fork ......................................... 15-26
15.4.2 Forks, repairs and testing ............................................ 15-27
Repairs ........................................................................ 15-27
Testing the yield point .................................................. 15-27
Fork ............................................................................. 15-27
15.5 Fork carriage.............................................................................. 15-28
15.5.1 Checking the fork carriage’s wear strip ....................... 15-28
15.5.2 Lubricating the fork carriage ........................................ 15-29
15.6 Fork spread unit ......................................................................... 15-30
15.6.1 Servicing the fork spread unit ...................................... 15-30
Replacing bearings ...................................................... 15-31
Replacing the rollers .................................................... 15-31
15.7 Fork extensions with adjustable fork length ............................... 15-32
15.8 Manual telescopic forks.............................................................. 15-34
15.8.1 Fitting ........................................................................... 15-34
15.8.2 Maintenance ................................................................ 15-35
15.9 Hydraulic telescopic forks .......................................................... 15-36
15.9.1 Telescopic forks with separate flow dividers ............... 15-37
Fitting instructions ........................................................ 15-38
Initial operation of telescopic forks with separate flow dividers
15-38
15.9.2 Telescopic forks with integrated flow dividers ............. 15-39
Fitting instructions ........................................................ 15-40
Initial operation of telescopic forks with integrated flow divid-
ers ................................................................................ 15-40
15.9.3 Maintenance of telescopic forks .................................. 15-41
15.9.4 Dismantling telescopic forks ........................................ 15-42
15.9.5 Assembling telescopic forks ........................................ 15-43

1 – 10 Repair Manual RRE140/160/180/200/250 © BT
Contents
T-code Valid from serial number Date Publication No.
815, 816 6051502 2008-08-21 261828-040
16 – External Equipment 8000 .............................................................. 16-1
16.1 Introduction .................................................................................. 16-1
17 – Options 9000 .................................................................................. 17-1
17.1 Introduction .................................................................................. 17-1
18 – Appendix “Destruction instructions” .......................................... 18-1
18.1 General ........................................................................................ 18-1
18.2 Marking of plastics ....................................................................... 18-1
18.2.1 General marking of products and packaging material ... 18-1
18.2.2 Marking according to our standard ................................ 18-2
Abbreviations ................................................................. 18-2
Marking examples ......................................................... 18-2
18.3 Pressure vessels.......................................................................... 18-3
18.3.1 Gas dampers ................................................................. 18-3
18.4 Sorting categories........................................................................ 18-4
19 – Wiring diagrams ............................................................................ 19-1
19.1 Components ................................................................................ 19-1
19.2 Overview...................................................................................... 19-6
19.3 Wiring diagrams........................................................................... 19-7
20 – Hydraulics schematics ................................................................. 20-1
20.1 Main valve.................................................................................... 20-1
20.1.1 RRE Std. ....................................................................... 20-1
20.1.2 RRE Ergo ..................................................................... 20-2
20.2 Hydraulics schematics ................................................................. 20-3
20.2.1 Schematics designations ............................................... 20-3
20.2.2 List of symbols ............................................................... 20-4
20.2.3 Wiring diagrams RRE/RRE Ergo ................................... 20-5
21 – Tool ................................................................................................. 21-1
21.1 AMP connectors........................................................................... 21-1
21.2 AMP microtimer ........................................................................... 21-2
21.3 MQS contacts .............................................................................. 21-3
21.4 Other tools ................................................................................... 21-5
22 – Appendix “Service data and grease specifications” .................. 22-1
22.1 General tightening torques........................................................... 22-1
22.1.1 Galvanised non-oiled bolts ............................................ 22-1
22.1.2 Untreated oiled bolts ...................................................... 22-2
22.2 Oil and grease specifications ....................................................... 22-3
23 – Technical data ............................................................................... 23-1

General introduction
How to use the manual
Publication No. Date Valid from serial number T-code
261828-040 2008-08-21 6051502 815, 816
© BT Repair Manual RRE140/160/180/200/250 2 – 1
2 – General introduction
2.1 How to use the manual
The service manual is divided into chapters containing the following
information:
• Functions and parameters – This chapter contains a basic descrip-
tion of the main functions of the truck and the control system para-
meters.
• Installation and initial operation – This chapter describes the work
that needs to be done before the truck is used for the first time.
• Maintenance – This chapter contains a general periodic mainte-
nance schedule and a detailed description of the maintenance to be
carried out.
• Troubleshooting – This chapter describes the error codes that ap-
pear in the display when the truck completely or partly stops work-
ing. The chapter also describes the reason why the errors occur and
suggested remedies.
• Step by step – This chapter describes the various parts of the truck,
for example the hydraulic system, including what the parts look like
and the service activities that need to be carried out. The various de-
scriptions are organised according to BT's C-code system.
• Appendixes – The appendixes contain:
- instructions for disposal
- information about electrical components and wiring diagrams
- hydraulics diagrams
- list of required tools
- information about general tightening torques
- oil and grease specifications
- Technical data.

2 – 2 Repair Manual RRE140/160/180/200/250 © BT
General introduction
Warning symbols
T-code Valid from serial number Date Publication No.
815, 816 6051502 2008-08-21 261828-040
2.2 Warning symbols
The following warning symbols are used in the service manual:
DANGER!
The word DANGER! means there is a risk of accident potentially lead-
ing to death or serious injury and material loss or damage. Always ac-
companied by the warning symbol.
WARNING!
The word WARNING! means that there are components sensitive for
electro-static discharges.
Follow applicable ESD-routines to protect the device.
IMPORTANT
The word IMPORTANT means there is a risk of material loss or dam-
age if the instructions are not followed. Also used to draw attention to
a non-standard torque.
2.3 Pictograms
Where suitable, pictograms are used to describe some actions. Mainly
this applies to the release and fastening of screws:
The pictogram gives information about type of screw head and turning
direction indicated with an arrow.
Additional text below the pictogram gives information about
‘s’: key size, ‘n’: number of screws and, where applicable, recommend-
ed torque.
One example of another pictogram type is “Cut tie wrap”:
The pictogram might have additional information below, saying how
many ties to cut.
× n
s mm

General safety rules
Safety while working
Publication No. Date Valid from serial number T-code
261828-040 2008-08-21 6051502 815, 816
© BT Repair Manual RRE140/160/180/200/250 3 – 1
3 – General safety rules
Only personnel trained in servicing and repairing this type of truck are
authorised to carry out service and repair activities.
3.1 Safety while working
To ensure that you work safely and to prevent accidents while working
on a truck, remember the following:
• keep the area where servicing activities are performed clean. Oil or
water will make the floor slippery.
• use the correct working position. Service activities often involve
kneeling or bending forward. Try sitting on a toolbox, for example, to
relieve the strain on your knees and back.
• loose articles and jewellery may become trapped in the moving parts
of the truck. So never wear loose articles or jewellery while working
on the truck.
• use the correct tools for the work you are carrying out.
• keep all tools well maintained.
• store and transport old oil according to applicable local regulations.
• do not flush solvents, etc. down the drain unless they are intended to
be disposed of in this way.
Follow the local disposal regulations.
• heated paint gives off harmful gases. So use sanding or a paint strip-
per to remove the paint at least 100 mm around an area where any
welding/grinding is to take place.

3 – 2 Repair Manual RRE140/160/180/200/250 © BT
General safety rules
Electrical system
T-code Valid from serial number Date Publication No.
815, 816 6051502 2008-08-21 261828-040
3.2 Electrical system
When working on the electrical system of the truck, remember the fol-
lowing:
• a short circuit may occur if metal objects come into contact with live
connections. This can result in burns. So remove watches, rings and
other metal jewellery before starting work.
• always use insulated tools while working on the electrical system.
• always switch off the truck's power supply before opening the hoods
to the drive assembly and the electrical system.
• disconnect the battery when using electric welding equipment. The
welding current may damage the battery.
• always remove the battery plug when carrying out maintenance on
the truck, unless the instructions in this service manual state other-
wise.
• blow electric motors clean using compressed air.
• clean electrical panels, electronic cards, connectors, contactors, so-
lenoid valves, etc. with a moist cloth and a cleaning agent that will
not damage the part.
IMPORTANT
Risk of short-circuiting that may damage electrical components.
Do not break the warranty seal on the electronic cards.

General safety rules
Safe lifting
Publication No. Date Valid from serial number T-code
261828-040 2008-08-21 6051502 815, 816
© BT Repair Manual RRE140/160/180/200/250 3 – 3
3.3 Safe lifting
All lifting must be carried out on a flat, nonslip and stable surface.
Asphalt floors must be avoided if possible.
• To prevent the truck moving while it is being lifted, it must not be lift-
ed with anyone on the platform or with the tiller arm in the lowered
position.
• If the drive wheel, which is braked, is being lifted the other wheel
must be chocked to stop the truck moving.
• Select the lifting point so that the lift is as light as possible, for exam-
ple one corner at a time. If the truck has marked lifting points on the
lower part of the chassis, these should be used for a well-balanced
lift.
• Ensure the area where you place the jack is clean and free of oil and
grease.
• Ensure there is no grease or oil on your hands or the jack lever.

3 – 4 Repair Manual RRE140/160/180/200/250 © BT
General safety rules
Safe lifting
T-code Valid from serial number Date Publication No.
815, 816 6051502 2008-08-21 261828-040
• Use the lever supplied with the jack. If the lever is too short, it will re-
quire more effort than is necessary. If the lever is too long there is a
risk that the jack will be overloaded.
DANGER!
Risk of crushing – a poorly chocked truck may fall.
• Never work under a truck that is not blocked with supports or secured
by a lifting device.
• Place supports:
- as close to the raised part of the chassis as possible to reduce the
falling height if the truck tips over
- so that the truck cannot roll.
•Never place a support under the jack to increase the lifting height.
•Never work under a lifted truck without appropriate supports.

Functions and parameters
Chassis 0000
Publication No. Date Valid from serial number T-code
261828-040 2008-08-21 6051502 815, 816
© BT Repair Manual RRE140/160/180/200/250 4 – 1
4 – Functions and parameters
4.1 Chassis 0000
4.1.1 Driver protection (0840)
Tilt stops
To increase truck capacity, tilt stops are fitted to some trucks. Tilt stops
are also available as an option.
It is, however, permissible to temporarily remove tilt stops when trans-
porting the truck, between different warehouses, for instance; but the
truck may not in this case be used to transport loads.
WARNING!
Reduced stability.
Trucks without tilt stops can tip over, if used to transport loads.
Ensure that tilt stops are refitted at the correct floor distance if they
have been temporarily removed.
The tilt stops are located on the rear corner of the support arm and con-
sist of stops (c), shims (b), bolts (d), and nuts (a) on the inside of the
chassis.
.
a
b
cc
b
a
d
d

4 – 2 Repair Manual RRE140/160/180/200/250 © BT
Functions and parameters
Chassis 0000
T-code Valid from serial number Date Publication No.
815, 816 6051502 2008-08-21 261828-040
Overhead guard
The cabin is protected from falling objects by a casing with bars (c) bolt-
ed into the roof of the cabin shell.
The casing can be supplemented by a guard of finer mesh (b) and a
transparent top (a).
The truck may be fitted out with a protective grating (d) between the
cabin and the mast.
a
b
c
d
