1. Product Overview
1.1. Product features
1. 1. BIT-MSE-U1-312 is an industrial-grade and
high-performance product, and its ultra-high-definition
resolution supports even up to 8Kx2K@60Hz.
2. Maximum support 3 inputs and 12 outputs. All splicing
modes within 12 screens can be combined arbitrarily:
horizontal screens / vertical screens / odd-numbered
screens splicing, and supports large-scale parallel use.
3. 3. Adopt wide voltage (100~240V) centralized power supply,
low power consumption, energy saving and environmental
protection design. Conductive heat dissipation is adopted
internally, and no external heat dissipation measures are
required. High reliability.
4. . Support both wired network control and wireless network
control.
5. Using 28nm process high-end programmable FPGA chip, it
has full hardware and real-time processing architecture,
making processing speed ultra-fast without delay.

Shenzhen Bitvisus technology limited. Video News Co., Ltd
第4页 共 12 页
6. With Industrial-grade design, it has thickened 6-layer PCB
board, 16KV super anti-static ability, and tremendous stability.
7. Any splicing needs can be customized according to user
needs.
1.2. Application scenarios
Ultra-high resolution desktop applications, ultra-large screen
walls, command and dispatch systems, multi-screen video
surveillance, engineering display applications, multi-channel
projection, virtual reality, surround-screen theater, large
advertising walls, LCD/LED multi-screens, etc.
2. Specifications
Product name
BIT-MSE-U1-312 Ultra HD splicing
processor
Input Max. Pixel FPS
600MHz
Output Max. Pixel FPS
165MHz
4x4 highest resolution
7680x4320@60Hz
7x2 highest resolution
3840x7560@60Hz
2x7 highest resolution
13440x2160@60Hz

Shenzhen Bitvisus technology limited. Video News Co., Ltd
第5页 共 12 页
3x5 highest resolution
9600x3240@30Hz
5x3 highest resolution
5760x5400@30Hz
2x5 highest resolution
9600x2160@60Hz
5x2 highest resolution
3840x5400@60Hz
16x1 highest resolution
30720x1080@60Hz
1x16 highest resolution
1920x17280@60Hz
1x5 highest resolution
9600x1080@60Hz
1x7 highest resolution
13440x1080@60Hz
Factory default
resolution
3840x2160@60Hz
Support customized
arbitrary resolution
√
Types of input interface
4 DP
4 HDMI
1 RJ45 Lan
1 RJ45 Debug port
Types of output interface
3~12 HDMI
Size
482.6mm*396.8mm*44mm
Weight
5kg
Power
100~240V

Shenzhen Bitvisus technology limited. Video News Co., Ltd
第6页 共 12 页
Warranty
One year
3.Operation instructions
3.1. Device Connection
1) Connect the output of the computer graphics card to the
input of BIT-MSE-U1-312.
2) Connect the BIT-MSE-U1-312 output to the display device,
and each output port serial number should be connected to
the corresponding display screen.
3) BIT-MSE-U1-312 should be connected to 220V power.
4) After the correct connection is completed, the power light,
signal light and output light will show a steady state.

Shenzhen Bitvisus technology limited. Video News Co., Ltd
第7页 共 12 页
4. Common problems
4.1. Device problem
4.1.1 Red light problem
1. Check the power cord, 220V power cord should be used for
power supply.
2. Test whether the power supply to the device is stable
(whether the voltage is stable, etc.).
3. Replace other 220V power adapters to test whether it is the
power adapter.

Shenzhen Bitvisus technology limited. Video News Co., Ltd
第8页 共 12 页
4. The equipment light is damaged, or other equipment
malfunctions.
5. The line we provide should be use as the data line for
equipment input .

Shenzhen Bitvisus technology limited. Video News Co., Ltd
第9页 共 12 页
4.1.2 Green light problem
1. The input signal light is damaged, or other failures (EDID
chip damage, etc.).
2. The input signal light is damaged, or other failures
(computer graphics card problem, device resolution problem,
secondary device problem, and signal line problem, etc).
3. When there is input (the input indicator is always on) and
there is no output (the output indicator flashes/off), check
whether the computer graphics card has output. You can
connect the graphics card output to a monitor that can be
used normally to see if there is output. If several output ports
are normal, the normal output port can be exchanged with
the abnormal output port. After the exchange, the abnormal
port can output normally, it may be a problem with the output
line, so replace the output line.

Shenzhen Bitvisus technology limited. Video News Co., Ltd
第10 页 共 12 页
4.2. Computer graphics card problem
1. Check whether the graphics card needs additional power
supply. Multi-output graphics cards with multiple output
ports generally require additional power supply. Whether
there is output port switch control, please refer to the
instruction manual of the corresponding graphics card.
2. Confirm that the output port of the graphics card is a
bandwidth output above 300M.
3. It is not recommended to use other signals to convert to
HDMI. Please directly use the HDMI port on the graphics card
to connect with the device
4. If the computer graphics card is connected to the device,
check the graphics control panel to confirm if the device
name can be seen.
5. 5. It is best to install the latest version of the graphics card
driver, and download the latest graphics card driver from the
official website. Before installing the latest driver, uninstall the
old driver.
6. NVIDIA graphics driver download site：http://www.nvidia.cn
7. ATI graphics driver download site：www.amd.com

Shenzhen Bitvisus technology limited. Video News Co., Ltd
第11 页 共 12 页
4.3. Display device problem
1. In order to confirm whether the display device supports the
output resolution, you can directly connect the computer
graphics card to the device to test this resolution.
2. Turn on the signal receiving function (power on, search
signal function, etc.) to test Display whether the power supply
of the device is stable, and
3. According to the transmission distance from the
multi-screen treasure to the display device, select the
appropriate receiver.
4. 4. If you use a short cable to connect Multi-Screen and the
display device, there is still no output, it may be that the
resolution required by the display device is special, please
refer to the "custom resolution" operation.
5. 5. If the connection distance exceeds 1.5 meters, it is
recommended to use network transmission.

Shenzhen Bitvisus technology limited. Video News Co., Ltd
第12 页 共 12 页
4.4. Problem solve
Precondition
Problem
phenome
non
How to solve
The output
resolution is
correct
Image is
blue
Set computer properties, set to
"tiled" in desktop properties
Integrated
Graphics
No image
output
Change the discrete graphics card,
or contact a technician
5. Additional explanation：
