BUFFALO TURBINE BT-CYC8KKM Parts list manual

BUFFALO TURBINE
180 Zoar Valley Road
Springville, NY 14141
TEL: [phone] FAX: [phone]
EMAIL: [e-mail]
WEBSITE: www.buffaloturbine.com
BUFFALO TURBINE'S
BT-CYC8KKM
ORIGINAL INSTRUCTIONS AND PARTS MANUAL
04/22 -BT MAN

1
TABLE OF CONTENTS
Ref. Number
Description
Page Number
1.0
Introduction
2
2.0
Safety
3
2.1
Safety Decals
4
2.2
General Safety
4
2.3
Operating Safety
4
2.4
Maintenance Safety
5
2.5
Transport Safety
5
2.6
Storage Safety
5
2.7
Sign-off Form
5
3.0
Warranty Information
6
3.1
Warranty Registration Form
7
4.0
Operations
8
4.1
To the new operator or owner
9
4.2
Break-in
9
4.3
Pre-Operation Checks
9
4.4
Attaching Blower to Tractor
9
4.5
Field Operation
10
4.6
Operating RPM
10
4.7
Storage
10
5.0
Troubleshooting
10
6.0
Machine Specification
11
7.0
Maintenance
11
7.1
Maintenance Safety
12
7.2
Fluids
12
7.3
Greasing Interval
12
7.4
Belt Maintenance
12
7.5
Service Checklist
13
Declaration of Conformity
14
BT-CYC8KKM Parts Reference (Before Serial # 26323)
15
BT-CYC8KKM Parts Reference (Serial # 26323-35717)
16
BT-CYC8KKM Parts Reference (After Serial # 35718)
17
BT-CYC8KKM Parts Sub-Assemblies
18
Gyratory Atomizing Nozzle Parts Breakdown
19
Wiring Schematic for Control Box
20
Bill of Materials for BT-CYC8KKM
21
Nozzle Options
22
Buffalo Turbine Additional Products
23

2
1.0 INTRODUCTION
Congratulations on your choice of a Buffalo Turbine Monsoon. This equipment has been designed and
manufactured to meet the needs of the construction/demolition industry.
Safe, efficient and trouble-free operation of your Buffalo Turbine Monsoon requires that you and anyone else, who
will be operating or maintaining the Blower, read and understand all of the safety, operation, maintenance and
troubleshooting information contained within this Operator’s manual.
This Manual covers the BT-CYC8KKM Turbine Monsoon.
Keep this manual handy for frequent reference and to pass on to new operators or owners. Call your Buffalo
Turbine dealer or distributor if you need assistance, information, or additional copies of the manuals.
SERIAL NUMBER LOCATION
Always give your dealer the serial number of your Monsoon when ordering parts or requesting service or other
information.
The serial number plate(s) is located where indicated in the pictures below. Please document the number in the space
provided for easy reference.
OPERATOR ORIENTATION –The directions left, right, front and rear, as mentioned throughout the manual, are
as seen from the driver’s seat and facing in the direction of travel.
MODEL BT-CYC8KKM
TOP SURFACE OF FRAME
Serial Number: _______________
Serial #

3
2.0 SAFETY
YOU are responsible for the SAFE operation and maintenance of your Buffalo Turbine Monsoon. YOU must
ensure that you and anyone else, who is going to operate, maintain or work around the Buffalo Turbine Monsoon
be familiar with the operating and maintenance procedures and related SAFETY information contained in this
manual. This manual will take you step-by-step through your working day and alerts you to all good safety practice
while operating the Monsoon.
Remember YOU are the key to safety. Good safety practices not only protect you but also the people around you. Make these
practices a working part of your safety program. Be certain that EVERYONE operating this machine is familiar with the
procedures recommended and follows safety precautions. Remember most accidents can be prevented. Do not risk injury or
death by ignoring good safety practices.
Monsoon owners must give operating instructions to operators or employees before allowing them to operate the Blower,
and at least annually thereafter.
The most important safety device on this equipment is a SAFE operator. It is the operator’s responsibility to read and
understand ALL Safety and Operating instructions in the manual and to follow these. All accidents can be avoided.
A person who has not read and understood all operating instructions is not qualified to operate the machine. An untrained
operator exposes themselves and bystanders to possible serious injury or death.
Do not modify the equipment in any way. Unauthorized modification may impair the function and/or safety which could
affect the life of the equipment.
Think SAFETY! Work SAFELY!
This Safety Alert symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
The Safety Alert symbol identifies important safety messages on the Buffalo Turbine Monsoon and in the manual. When you
see this symbol, be alert to the possibility of personal injury or death. Follow the instructions in the safety message.
SIGNAL WORDS: Note the use of the signal words DANGER, WARNING and CAUTION with the safety messages. The
appropriate signal word for each message has been selected using the following guidelines
1. DANGER –injury or death if the proper precautions are not taken.
2. WARNING -- A specific hazard or unsafe practice that COULD result in severe personal injury or death if proper
precautions are not taken.
3. CAUTION –Unsafe practices that COULD result in personal injury if proper practices are not taken, or as a reminder of
good safety.
The Safety Alert symbol identifies important safety messages on the Buffalo Turbine Monsoon and in the manual.
When you see this symbol, be alert to the possibility of personal injury or death. Follow the instructions in the
safety message.
Why is SAFETY important to you?
3 Big Reasons: Accidents Disable and Kill
Accidents Cost
Accidents Can Be Avoided

4
2.1 SAFETY DECALS
The types of decals on the blower unit are shown below. Good safety requires that you familiarize yourself with the
various Safety Decals, the type of warning and the area, or particular function related to that area that requires your
SAFETY AWARENESS.* THINK SAFETY! WORK SAFELY!
REMEMBER –If safety decals have been damaged, removed, become illegible or parts replaced without decals, new
decals must be applied. New decals are available from your authorized dealer.
2.2 GENERAL SAFETY
1. Read and understand the Operator’s Manual and all safety signs before operating, maintaining, and adjusting.
2. Provide a first-aid kit for use in case of an accident. Store in a highly visible place.
3. Provide a fire extinguisher for use in case of an accident. Store in a highly visible place.
4. Wear appropriate protective gear. This list includes but is not limited to:
A hard hat
Protective shoes with slip resistant soles
Protective glasses or goggles
Heavy gloves
Wet weather gear
Hearing protection
5. Do not operate without guards or shields properly installed.
6. Do not allow riders.
7. Wear appropriate ear protection for prolonged exposure to excessive noise.
8. (All Models) Set Monsoon on the ground, stop engine, set park brake, remove ignition key and wait for all moving
parts to stop before dismounting to service or adjust.
9. Clear the area of people, especially small children, before starting the unit.
10. Review all safety related items annually with all personnel who will be operating or maintaining the Blower.
11. Keep hands, feet, hair and clothing away from moving parts. Operate equipment only while seated in the operator’s seat.
2.3 OPERATING SAFETY
1. Read and understand the Operator’s Manual and all safety signs before operating, servicing or adjusting.
2. Before servicing or repairing, Set blower on the ground, disengage PTO, stop engine, set park brake, Turn Off
Tractor Engine, remove key, and wait for all moving parts to stop.
!ATTENTION!
1. KEEP HANDS, FEET AND CLOTHING AWAY FROM POWER DRIVEN PARTS.
2. STOP ENGINE AND REMOVE KEY BEFORE LEAVING OPERATOR’S POSITION.
3. MACHINE MUST COME TO A COMPLETE STOP BEFORE ANY MAINTENANCE, TO
INCLUDE ADJUSTING, LUBRICATING OR CLEANING, IS PERFORMED.
4. KEEP PEOPLE AND PETS AT SAFE DISTANCE FROM MACHINE.
5. KEEP ALL GUARDS AND SHIELDS IN PLACE.
Never operate without ear
protection due to prolonged
exposure to excessive noise
Never operate without guards
in place because there are
sharp rotating components
that will cause serious injury.
Never attempt to service or touch the
driveline with the PTO Engaged and/or
guards removed.

5
2.4 MAINTENANCE SAFETY
1. Read and follow ALL general, operating, maintenance and safety information in this manual.
2. Support the machine with blocks or safety stands when changing tires or working beneath it.
3. Set Blower on the ground, stop engine, set park brake, remove ignition key and wait for all moving parts to stop before
operating, servicing or adjusting.
4. Do not adjust the drive belt when it is rotating.
5. Make sure all guards are in place and properly secured when operating or maintaining the Monsoon.
2.5 TRANSPORT SAFETY
1. Turf trailer Receptacle Uses a Pin Hitch Only. Use Presto Pin. Do Not Exceed 15 MPH (24KPH) At Any Time. Use a
DOT Approved trailer for Highway Use and for speeds exceeding 15 MPH (24KPH). Make sure you are in compliant
with all local DOT regulations regarding transporting Buffalo Turbine equipment on public roads and highways.
2. The CYC8KKM can be made into a Skid Model by removing the trailer package and can easily be transported and
operated in the bed of a standard pick-up truck or utility vehicle. Be sure to block, anchor and secure the unit before
operating or transporting. Do not use the top of the Turbine housing to strap or tie down blower unit.
2.6 STORAGE SAFETY
1. Store the Monsoon on a firm, level surface.
2. Store away from areas of human activity. Do not permit children to play on or around the stored machine.
3. Make sure the unit is sitting, or blocked up firm and solid and will not tip or sink into a soft area.
4. Cover with a weatherproof tarpaulin and tie down securely.
2.7 SIGN-OFF FORM
Buffalo Turbine recommends that anyone who will be operating and/or maintaining the Buffalo Turbine Monsoon must
read and clearly understand ALL Safety, Operating and Maintenance information presented in this manual.
Do not operate or allow anyone else to operate this equipment until such information has been reviewed. Annually
review this information before the season start-up.
Make these periodic reviews of SAFETY and OPERATION a standard practice for all of your equipment. We feel
that an untrained operator is unqualified to operate this machine.
A sign-off sheet is provided for your record keeping to show that all personnel who will be working with the equipment have
read and understand the information in the Operator’s Manual and have been instructed in the operation of the equipment.
SIGN-OFF FORM
DATE
EMPLOYEES SIGNATURE
EMPLOYERS SIGNATURE

6
Buffalo Turbine Warranty Policy
3.0 MACHINE WARRANTY INFORMATION
Buffalo Turbine warrants the DEBRIS BLOWER, to the original owner, to be free from defects in material and workmanship,
under normal use and service. All machines must have a completed registration form sent to Buffalo Turbine within 30
days of purchase for warranty to apply. Obligation under this warranty shall extend for a period of 10 years from date of
purchase and, at the option of Buffalo Turbine, replacement of any parts found, upon inspection by Buffalo Turbine, to be
defective. Any parts replaced under warranty will have the remainder of the warranty from the original date of purchase.
Warranty parts during first 2 years will be shipped free of charge via standard ground shipping
*If expedited shipping is required charges will be paid by the end user*
Year 1: parts and labor
Year 2: parts only
Customer will be required to pay shipping charges for years 3-10
Year 3: Engine, per engine manufacturer’s standard / Turbine Assembly / Frame (parts only)
Year 4-10: Turbine Assembly / Frame (parts will be prorated)
Buffalo Turbine reserves the right to incorporate improvements in material and design of its
products without notice and is not obligated to make the same improvements to equipment
previously manufactured.
ALL WARRANTY REPAIRS NEED PRE-APPROVAL BY A FACTORY PERSON (FROM BUFFALO
TURBINE) PRIOR TO COMMENCING WITH A WARRANTY REPAIR TO INCLUDE SERIAL
NUMBER AND HOURS FROM HOUR METER (IF EQUIPPED). PRE-APPROVAL WILL BE
REQUIRED BY THE END USER AND DEALER/DISTRIBUTOR LEVEL.
Factory ordered Buffalo Turbine parts must be used when filing a warranty claim.
LIMITATIONS OF LIABILITY
This warranty is expressly in lieu of all other warranties expressed or implied and all other obligations or liabilities on our part
of any kind or character, including liabilities for alleged representations or negligence. We neither assume nor authorize any
other person to assume on our behalf, any liability in connection with the subsequent sale of the DEBRIS BLOWER.This
warranty shall not apply to any DEBRIS BLOWER, which has been altered outside the factory in any way so as, in the
judgment of Buffalo Turbine, to affect its operation or reliability, or which has been subject to misuse, neglect, or accident.
This warranty does not cover parts and accessories, which are under separate guarantee from the manufacturers and service
can be, obtained from their service facilities. No warranty is extended to regular service items such as lubricants, belts, paint
and the like.
Original Instruction Manual
The Purchaser acknowledges having receiving training in the safe operation of the DEBRIS BLOWER and further
acknowledges that Buffalo Turbine does not assume any liability resulting from the operation of the DEBRIS BLOWER in
any manner other than described in the Operator’s Manual supplied at the time of purchase.
WARRANTY VOID IF NOT REGISTERED (see Page 2 for warranty registration form)
DO NOT SPLIT THE TURBINE HOUSING FOR ANY REASON.
DO NOT ATTEMPT TO SERVICE OR DISASSEMBLE THE TURBINE BLOWER.
DO NOT USE THE TOP OF THE TURBINE HOUSING TO STRAP OR TIE DOWN BLOWER UNITS.
Unauthorized service work on the Turbine Blower will null and void all warranties.
If there are any questions regarding any of our products call Buffalo Turbine at 716 592 2700.

7
3.1 Warranty Registration Form
BUFFALO TURBINE
WARRANTY REGISTRATION FORM & INSPECTION REPORT
Any units not registered with Buffalo Turbine are not eligible for warranty claims
This form must be filled out by the dealer and signed by both the dealer and the customer at the time of delivery
Customer's Name _______________________ Dealer’s Name __________________________
Address _______________________ Address __________________________
City, State, Zip, Country ____________________ City, State, Zip, Country______________________
Email Address (important) ___________________ Email Address ____________________________
Telephone Number _______________________
Blower Model _______________________ Circle one:
Serial Number _______________________ Commercial Use
Delivery Date _______________________ Private Use
DEALER INSPECTION REPORT SAFETY CHECKS
________ Tire Pressure Check -- Model KB ________ All Decals Installed
_________ Wheel Bolts ________ Review Operating and Safety Instructions
_________ Belt Tension
_________ Lubricate Machine ________ Guards in Place
_________ Fasteners Tight _______ Trailer assembly bolts properly installed and tightened
ALL 3 POINT HITCH MODELS: PTO SHAFTS MUST TELESCOPE IN EVERY POSITION
I have thoroughly instructed the buyer on the above described equipment which reviews the included Operator's Manual
content, equipment care, adjustments, safe operation and applicable warranty policy.
Date __________________ Dealer's Rep. Signature ____________________________
The above equipment and Operator's Manual has been received by me and I have been thoroughly instructed as to the care,
adjustments, safe operation and applicable warranty policy.
Date __________________ Owner's Signature _________________________________
PLEASE EMAIL TO BUFFALO TURBINE AT - [email protected]
Or fax to 716 592 2460

8
4.0 OPERATIONS
4.1 TO THE NEW OPERATOR OR OWNER
Buffalo Turbine Debris Monsoon are designed to spray a fine mist of water particles to control dust. The material is conveyed on a stream
of high volume and velocity of air and water to remove it from the area of concern.
Many of the features incorporated into the machine are the result of suggestions made by customers like you. Read the manual carefully to
learn to operate the machine safely and how to set it to provide maximum efficiency. The manual will take you step-by-step through your
working day. By following the operating instructions in conjunction with a good maintenance program, your Blower will provide many
years of trouble-free service.
Potential Mechanical Hazards while operating your machine:
Never operate the debris blower around others to prevent the possibility of being run over by equipment.
Never ride on your debris blower to prevent the possibility of being thrown off the machine or hurt severely.
Potential Crushing Hazards while operating your machine:
Between Trailer Tongue and mounting hitch on towing vehicle
Between each nozzle
4.2 BREAK-IN
Although there are no operational restrictions on the Blower when it is used for the first time, it is recommended that the
following mechanical items be checked:
A. Operating for first ½ hour
1. Re-torque all wheel bolts, axle nuts and trailer mounting bolts and nuts.
2. Re-torque all other fasteners and hardware.
3. Check set screw (nozzle pulley) to ensure it tightened.
B. Operating for first 5 hours
1. Re-torque all hardware and fasteners.
2. Check set screw (nozzle pulley) to ensure it tightened.
3. Go to the normal servicing and maintenance schedule as defined in the Maintenance Section of the manual.
4.3 PRE-OPERATION CHECKS
Efficient and safe operation of the Buffalo Turbine Blower requires that each operator reads and understands the operating procedures and
all related safety precautions outlined in this section. A pre-operation checklist is provided for the operator. It is important for both personal
safety and maintaining the good mechanical condition of the machine that this checklist is followed.
BATTERY MUST BE CONNECTED BEFORE OPERATION (DISCONNECTED FOR SHIPPING).
Before Operating the Blower and each time thereafter, the following areas should be checked off.
1. For fuel, oil, and operating information of the Kohler Engine, refer to the Manufacturers specs included with this manual.
2. The Model CYC8KKM turf trailer is not designed for highway towing. For highway use or speeds above 15mph (24kph)
an optional DOT approved trailer must be used.
3. Insure the Monsoon unit is attached to a proper receiver mounted on the towing vehicle. A pin hitch receptacle is
standard with the model CYC8KKM. Attach the CYC8KKM trailer using the proper size hitch pin with a locking presto
pin.
4. Make sure all guards and shields are in place, secured and functioning as designed.
5. Check that all clamp bands are secure.
6. Check the belts and pulleys for proper tension and alignment.
CAUTION ! DO NOT ALLOW LEAVES OR DEBRIS TO ACCUMULATE ON OR NEAR THE
ENGINE OR EXHAUST SYSTEM OF THE MODEL KB BLOWER, TRACTOR ENGINE OR ANY
INTERNAL COMBUSTION ENGINE.
WARNING:
This Product can expose you to chemicals including carbon
monoxide and benzene, which are known to the State of
California to cause cancer and birth defects or
other reproductive harm.
For more information go to www.P65Warnings.ca.gov.

9
4.4 MODEL BT-CYC8KKM Assembly Instructions
4.5 FIELD OPERATION
1. Do not direct debris blower towards people, pets, autos, windows, etc.
2. Starting Monsoon unit: Always start engine at a lower engine speed with nozzle pointed down or away.
3. The air stream direction is changed (in either direction) by moving the rocker switch located on the hand control box. The nozzle
will stop turning by releasing the rocker switch. ALWAYS CHECK THE GROUND CLEARANCE WHEN OPERATING THE
NOZZLE IN THE DOWN VERTICAL POSITION.
4. Stopping Monsoon unit: Shut engine off above ½ throttle by turning key switch to off position to avoid engine backfire.
5. Allow the monsoon fan speed to come to a stop before disconnecting from tow vehicle.
NOTE: Make sure the control box wire harness is clear of all moving parts.
4.6 Operating RPM (All Models)
The manufacturer’s tractor section normally recommends the unit be run at a RPM that will insure efficient operation. The
Monsoon can operate at a slower RPM if it can effectively move the debris. Increase engine RPM as needed.
4.7 Storage
At the end of the working season or before storing the Monsoon unit, prepare the machine by following this procedure:
1. Select a storage area that is dry, level and free of debris.
2. Thoroughly wash the machine with a water hose to remove all debris and residue.
3. Run the machine at low RPM to dry the Monsoon Components.
4. Touch up all paint chips and scratches to prevent rusting.
5. Inspect for worn or failed components. Order the replacement parts and repair the monsoon unit when time allows. This
will eliminate unnecessary down time at the start of next season.
6. Store in an enclosed building. If space is not available, cover with a waterproof tarpaulin and tie it down securely.
7. Store the machine away from areas of human activity.
8. Do not allow children to play around the stored unit.
1. Fill engine oil to proper level. (overseas shipments)
2. Attach both stub axle assembly (part# 2422) with 2 U-bolts each (part# 1707) and 4 nyloc nuts (part# 1180).
Tighten each side at this time.
3. Attach the tongue (part# 2421) using the 2 U-bolts (part # 1707) and 4 nyloc nuts (part # 1180), center on the frame
then tighten evenly. Equal pressure must be applied on each hex. Note: The tongue is reversible and will allow for
2 different heights. Determine the desired height before attaching the tongue.
4. Recheck all mounting bolts to assure that they are tight.
5. Bolt on tires. USE PRESTO PIN TO KEEP HITCH PIN IN PLACE WHILE OPERATING
Part # 2504
Stub Axle
Assy.
with Hub
Part #
2421
U Bolts
Part #1707
and
½ “ Nyloc nuts
Part #1180
U Bolts
Part # 1707
and
½ “ Nyloc nuts
Part # 1180

10
5.0 TROUBLE SHOOTING
The Buffalo Turbine Monsoon uses a high volume and velocity of air and water to move material from one place to another.
The system is simple and reliable requiring minimal maintenance.
If you encounter a problem that is difficult to solve, even after reading through this trouble shooting section, please call your
local dealer or distributor. Before calling, please have this Operator’s Manual and the serial number from your Monsoon
ready.
In the following section, we have listed causes and solutions to the problems that you may have encountered.
TURN OFF ENGINE, REMOVE KEY, AND DISCONNECT BATTERY BEFORE SERVICING MONSOON UNITS.
INSTALL GUARDS BEFORE OPERATING.
PROBLEM
CAUSE
SOLUTION
No air flow
Buildup of debris inside turbine
Broken coupling
Remove nozzle and clean debris from inside turbine
Replace coupling
No air flow
Blower fan not turning
See solutions above
Reduced or no air flow
Blower fan turns
Air intake or exhaust restricted
Shut off engine
Blower or tractor –remove restrictions
Debris cannot be allowed to build up between the
blower fan and stationary vanes
Machine vibrates or
Unusual sounds
Bearing or coupling failure
Out-of-balance
Replace bearings or coupling
Have your dealer check blower for damaged blades.
Wash and clean blower fan blades
6.0 Machine Specifications
Model CYC8KKM Series
Length:
95” With nozzle and tongue installed
Width:
Height:
Weight:
44” with stub axle and tires
37”with stub axle and tires
360 lbs
Fuel Capacity:
1.7 Gallons
Electrical System:
Input Power:
Input RPM:
12 Volt electric remote
14 HP Kohler Engine
Up to 3200 RPM
Outlet Size:
Approximately 12”

11
7.0 MAINTENANCE SECTION
7.1 Maintenance Safety
1. Set Monsoon on a level surface, stop engine, set park brake, remove ignition key and wait for all moving parts to stop
before dismounting to service, adjust or repair.
2. Reinstall and secure all guards removed for servicing before starting to use machine again. *We recommend wearing
gloves when removing or installing the guard to avoid getting cut*
3. Securely support machine with blocks or safety stands when changing tires or working beneath it.
7.2 Fluids
Change oil per Mnaufacturer’s specification (see Engine owner’s manual section).
A Teflon spray type lubricant on the nozzle base and slides provides for freer rotation.
7.3 Greasing Interval
Grease the fittings on your new Cyclone 8000 Blower after the first 8hours of operation.
40 Hours: Flange bearing (1) - approx. 2 shots of grease. Use a grease gun extension.
DO NOT OVER GREASE
Grease
fitting
Flange
Bearing
Figure 1

12
7.4 Belt Maintenance
After using the Blower unit for a long period of time, the belt will stretch and wear and need replacing.
REPLACING THE BELT
USE THE ILLUSTRATION FROM BELOW FOR REFERENCE
To change the belt follow this procedure:
Remove the guard around belts and pulleys.
Loosen mounting bolts and nuts (Figure 3)
Remove belt.
Replace belts with type
Tighten mounting bolts and nuts on engine.
Check pulley alignment with a straight edge and re-check belt tension. (Figure 2)
Belt tension is 15 in/lbs at 1/4” deflection
GUARD REMOVED FOR CLARITY
Figure 2
Check pulley
alignment using
straight edge.
Belt tension
should be
15in. /lbs at 1/4”
Mounting
Bolts (4)
Figure 3

13
7.5 SERVICE CHECKLIST
See Lubrication and Maintenance sections for details of service. Copy this page to continue record.
TURN OFF ENGINE, REMOVE KEY & DISCONNECT BATTERY BEFORE SERVICING BLOWER UNIT
CODE: LUBRICATE-(L) / CHECK-(*) / CHANGE-(C) / REPLACE-(B) / CLEAN-(CL)
SCHEDULED MAINTENANCE HOURS ________________________
SERVICED BY ____________________
MAINTENANCE
8 hrs or daily
(*) Remove all debris that has settled between the blower wheel fan and the stationary vanes.
Helps maintain peak performance.
(*) Check engine oil and fill to proper level –Do not overfill
(*) Check air filter and precleaner
(CL) Clean debris from air intake and other cooling areas on the engine
(*) Check tire pressure (Max. 50 PSI)
(*) Check Clamp Band Bolt for tightness
40 hours or weekly
(L) Flange bearing greasing
(*) Inspect battery terminals for any corrosion, broken wires, or loose connections.
(*)Remove Battery and clean debris from inside of battery box
(L) Nozzle base slides (Teflon spray)
(*) Check set screw (nozzle pulley) to ensure it is tightened
(*) Wash and Clean any dirt or grime build up that has accumulated on blower wheel
fan blades. Helps to minimize vibration balance and maintain peak performance.
200hrs or annually
(CL) Machine
DO NOT OPERATE BLOWER UNIT WITHOUT GUARDS SECURELY ATTACHED

14
Declaration of Conformity
According to EC Machinery Directive 2006/42/EC, Annex II B
We, Buffalo Turbine of Springville, New York, USA herewith declare, that the following described
machine/machinery part is to be incorporated into a(n) machine/assembly with other machinery to make
one machine and that its setting into operation is prohibited unless the machine, which shall be
incorporated into the lower mentioned, complies with the requirement of the EC Machinery Directive
2006/42/EC.
Product: Engine Debris blower
Type: BT-CYC8KKM
Serial Number:
Order Number:
Applicable EC Directives: Machinery Directive 2006/42/EC
Noise Emissions Directive 2000/14/EC +
Amendment 2005/88/EC
Applicable Harmonized Standards: BSENISO 12100:2010
ISO 3744:2010
ISO 11094:1991
With a measured sound power level of:
Lwa 117 dB
With a guaranteed sound power level of:
Lwa 120dB
Buffalo Turbine
180 Zoar Valley Road
Springville, NY 14141
Tel: [phone]
Fax: [phone]
[e-mail]

15

16

17

18

19
