Buffalo iSCSI TeraStation Pro User manual

QUICK SETUP GUIDE
www.bualotech.com
EN DE FR IT ES PT NL SV NO DA FI
iSCSI TeraStation Pro
TS-IGL/R5
i
S

1
EN
Bualo iSCSI TeraStation Pro (TS-IGL/R5)
Package contents includes:
• iSCSI TeraStation Pro
• Ethernet Cable
• Power Cable
• TeraStation Installation CD
• Quick Setup Guide
• Warranty Statement
Thank you for purchasing a Bualo iSCSI TeraStation Pro.
Package Contents
TeraStation Layout 1
Fig: 1
Power Switch Display Mode Switch
Front Panel lock
(Turn counter-clockwise to release)

EN
2
TeraStation Layout 1
Fig: 3
Init Button
(Hold down to reset all settings)
Hard Drives
(Squeeze tabs to release)
Fig: 2
USB in
Ethernet
(to router)
UPS
Power Cable
Front With Panel Removed
Back Panel

3
EN
Installation 2
Fig: 4
Fig: 5
Insert the TeraNavigator CD into your computer’s CD-ROM drive.
On a PC, setup should launch automatically. If it does not, manually launch
TSnavi.exe by pressing Start and selecting the Run... option. When the Run
dialog opens, type d:\TSnavi.exe (where d is the drive letter of your CD-ROM
drive). Press OK to continue. (Fig: 4)
Then press the Begin Installation button to start. (Fig: 5)
Fig: 6
Easy Setup will step you through physically connecting your TeraStation. It
will then install software.
Advanced Setup skips the connection tutorial and goes directly to installing
software. (Fig: 6)

EN
4
If your TeraStation is connected correctly, it will be highlighted in the drop-
down list. If you have multiple units to set up, select the correct TeraStation
from the list. (Fig: 7)
Installation 2
Fig: 7 Fig: 8
Select First Setup for the initial installation.
To install the software on additional computers, chose Additional Setup.
(Fig: 8)
Once the TeraStation is installed, you’ll need to install the iSCSI connection
tool. Click Next, and step through the wizard until the iSCSI connection tool
is installed. (Fig: 9)
Fig: 9 Fig: 10
Click Yes to launch the iSCSI connection tool. (Fig: 10)

5
EN
Installation 2
Click Register the iSCSI Hard Disk, and then OK. (Fig: 11)
Fig: 11 Fig: 12
Check Resume connection at start up and then click Connect.(Fig: 12)
Fig: 13 Fig: 14
If Disk Management does not open automatically, you may launch it
manually. From the Setup menu at the top of the window, choose Launch
Disk Management. (Fig: 13)
Your iSCSI TeraStation now appears as a hard drive in Disk Management.
Double-click on the black bar above it. (Fig: 14)

EN
6
Installation 2
Fig: 15 Fig: 16
The New Volume Wizard will open. Click Next. (Fig: 15)
Choose your desired volume type. Click Next. (Fig: 16)
Fig: 17 Fig: 18
Add all dynamic disks that will be included in the volume to the Selected
column. (Fig: 17)
Choose your desired drive letter. Click Next. (Fig: 18)

7
EN
Installation 2
Fig: 19 Fig: 20
Choose your desired format and volume label. Click Next. (Fig: 19)
Your new volume is installed and ready to use. (Fig: 20)

EN
8
Technical Specications
This is a Class B product. In a domestic environment, this product may cause
radio interference, in which case the user may be required to take adequate
measures.
CE Mark Warning
LAN Standards: IEEE 802.3u 100BASE-TX; IEEE 802.3 10BASE-T
Transmission: 1000/100Mbps/10 Mbps, 1000BASE-T: 8B1Q4,
X 4B/5B, MLT-3; 10BASE-T Manchester Coding
Access Media: CSMA/CD
Media Interface: RJ-45
USB Standard: USB 2.0
Hi-Speed (HS)
Full-Speed (FS)
Low-Speed (LS)
USB Connector: USB A Connector (2)
Data Transmission Speed: Max: 480 Mbps (HS Mode)
Max: 12 Mbps (FS Mode)
Electric Current: 100-240V A/C
Power Consumption: ~86W (Varies with size)
Dimensions: 170 x 235 x 310 mm
Weight: 8 Kg (Weight varies with size)
Operating Temperature: 0-45˚ C; 20-80% non-condensing
