Buffalo TeraStation TS5800D User manual

TeraStationUserManual
35012627 ver.02

1
Contents
Chapter1Installation...................................................9
Installation.......................................................................................9
TurningontheTeraStation...........................................................14
TurningofftheTeraStation..........................................................14
ChangingthePassword................................................................15
Chapter2Configuration.............................................18
OpeningtheWebAdminInterface..............................................18
OpeningtheEasySetupScreenintheWebAdminInterface....19
Chapter3AccessRestrictions....................................22
ConfiguringAccessRestrictionsonUsersandGroups...............22
AddingaSharedFolder..............................................................................................22
Restrictions.......................................................................................................................24
AddingUsers...................................................................................................................26
AddingGroups...............................................................................................................28
AccessRestrictions........................................................................................................29
AccessRestrictionsonActiveDirectory.......................................30
Restrictions.......................................................................................................................32
AccessRestrictionsonanNTDomain..........................................32
Restrictions.......................................................................................................................34
AccessRestrictionsbyDelegatingAuthoritytoanExternalSMB
Server.............................................................................................35
Restrictions.......................................................................................................................37

2
Chapter4ManagingyourStorage............................39
RAIDArrays....................................................................................39
UsingNormalMode......................................................................................................41
ChangingRAIDMode..................................................................................................41
ConfiguringaHotSpare.............................................................................................43
RMM(RAIDModeManager)......................................................................................44
RAIDScanning................................................................................................................46
AddinganExternalHardDrive.....................................................46
ConnectanExternalDrive..........................................................................................46
FormattingExternalDrives........................................................................................47
AccessRestrictionsonExternalDrives..................................................................47
RemovingHardDrives..................................................................47
DismountingwiththeFunctionButton...............................................................48
DismountingfromtheWebAdminInterface....................................................48
Restrictions.......................................................................................................................49
CheckingDrives.............................................................................49
FormattingDrives.........................................................................50
EncryptingDrives..........................................................................52
MediaCartridgeSystem................................................................52
EraseDataontheTeraStationCompletely..................................53
DiskQuotas....................................................................................54
DiskSpaceQuotasforUsers......................................................................................54
DiskSpaceQuotasforGroups..................................................................................58
LimitsonAvailableSizeforEachVolume............................................................63
UsingtheTeraStationasaniSCSIDevice.....................................66
Introduction.....................................................................................................................66
UsingtheiSCSIHardDiskConnectionTool........................................................72
CreatingandExpandingVolumes..........................................................................75

3
SettingAccessRestrictions........................................................................................77
HardDriveReplacementProcedure.............................................79
Notes:..................................................................................................................................80
HardDriveReplacementExamples........................................................................81
Chapter5Backup........................................................87
BackUpfromtheTeraStation......................................................87
PreparingaBackupLocation....................................................................................87
ConfiguringaBackupJob..........................................................................................92
Restrictions.......................................................................................................................94
UsingTeraStationBatchBackup..................................................95
Replication.....................................................................................95
Restrictions.......................................................................................................................97
Failover...........................................................................................98
Configuration............................................................................................................... 102
BackingUpYourMacwithTimeMachine.................................104
BackingUpDatafromaUSBDevice..........................................108
AmazonS3(AmazonSimpleStorageService)..........................109
Chapter6RemoteAccess.........................................112
UsingWebAccess.........................................................................112
WhatisWebAccess?.................................................................................................. 112
Configuration............................................................................................................... 112
FTPServer....................................................................................116
Restrictions.................................................................................................................... 118

4
Chapter7BitTorrent.................................................119
DownloadingFilesUsingBitTorrent..........................................119
WhatisBitTorrent?..................................................................................................... 119
HowItWorks................................................................................................................ 119
Configuration............................................................................................................... 120
Chapter8Multimedia...............................................122
DLNA.............................................................................................122
WhatisDLNA?.............................................................................................................. 122
Configuration............................................................................................................... 122
ConnectingtotheTeraStationandFilePlayback.......................................... 124
ConnectedDLNA-compatibleDevices.............................................................. 124
StreamingtoDLNA-compatibleDevices.......................................................... 125
DisablingPlaybackfromSpecificDevices........................................................ 126
IfYourDLNAClientDeviceDoesn'tRecognizetheTeraStation.............. 127
WhenFilesCannotBePlayedBack...................................................................... 127
UsingiTunesServer.....................................................................128
WhatisiTunesserver?............................................................................................... 128
Configuration............................................................................................................... 128
UsingSqueezeboxServer...........................................................129
WhatisSqueezeboxServer?.................................................................................. 129
Configuration............................................................................................................... 129
Chapter9SurveillanceCamera................................132
Overview......................................................................................132
WhatisSurveillanceCameras?.............................................................................. 132
RequiredItems............................................................................................................. 132
InitialSetup..................................................................................133

5
InstallingtheClientToolsonYourComputer................................................. 133
ConnectingDevicestotheNetwork................................................................... 133
EnablingtheSurveillanceCamera....................................................................... 134
EnablingtheFreeLicense....................................................................................... 135
RegisteringtheRecordingPolicyoftheNetworkCamera......................... 137
CheckingRecording.................................................................................................. 141
EmailNotificationofErrors..................................................................................... 142
Configuration...............................................................................142
Viewingsavedvideo................................................................................................. 142
ExportingRecordedDataasaMOVVideoFile............................................... 143
ViewingVideothatisCurrentlyBeingRecorded........................................... 145
MovingRecordedVideoDatatoAnotherTeraStation................................ 145
BackingUpRecordedVideotoAnotherTeraStation................................... 146
AutomaticallyDeletingOldRecordedVideoDatawhenAvailableSpace
BecomesLow............................................................................................................... 147
ChangingtheTeraStationwhereRecordedVideoIsSaved...................... 149
OverviewofClientUtilities.........................................................150
CameraPolicies........................................................................................................... 150
LiveViewer.................................................................................................................... 150
DataServicePolicies.................................................................................................. 151
VaultAdmin.................................................................................................................. 152
SurveillanceVideoManager................................................................................... 152
NetworkActivity.......................................................................................................... 153
MiniVaultStats............................................................................................................ 154
AdditionalLicenseActivationProcedure..................................154
WhentheTeraStationisConnectedtotheInternet.................................... 154
WhentheTeraStationIsNotConnectedtotheInternet............................ 156
Troubleshooting..........................................................................159

6
Chapter10AdvancedFeaturesandAddingHardware
.....................................................................................162
AntivirusSoftware.......................................................................162
ActivatingVirusScanning....................................................................................... 162
OpeningTrendMicroNASSecuritySettings................................................... 162
ConnectingthroughaProxyServer.................................................................... 163
RegisteringtheLicense,orExtendingtheLicensePeriod......................... 164
Updating........................................................................................................................ 165
ExcludingaSpecificFolderfromAntivirusScanning................................... 166
VirusScanning............................................................................................................. 167
CheckingtheLog........................................................................................................ 168
OpeningtheOnlineHelp........................................................................................ 168
EmailNotification........................................................................169
SleepMode..................................................................................171
WakeonLAN................................................................................173
UPS(UninterruptiblePowerSupply).........................................174
PortTrunking...............................................................................175
ConnectingaPrinter...................................................................177
SettingupaPrinteronWindows7orWindowsVista................................. 177
SettingupaPrinteronWindowsXP................................................................... 178
TeraSearch(TextSearch)............................................................179
OfflineFiles..................................................................................181
DFS(DistributedFileSystem).....................................................184
AccessingfromaNFS(NetworkFileSystem)Client.................186
EncryptingDataTransmission....................................................190
EncryptingDataintheWebAdminInterface................................................. 190
EncryptingFTPTransferData................................................................................. 190
SSLKey............................................................................................................................ 191

7
WebServer...................................................................................191
MySQLServer...............................................................................193
SNMP............................................................................................194
SavingandRecoveringSettings.................................................194
SavingSettings............................................................................................................ 195
RecoveringSettingsfromtheWebAdminInterfaceDuringTeraStation
Operation....................................................................................................................... 196
RecoveringbyChangingtheBootModeSwitchontheRearPanelWhen
StartingtheTeraStation........................................................................................... 197
CheckingtheTeraStationLogs...................................................198
RestoringFactoryDefaults.........................................................199
OnlineUpdate..............................................................................199
Name,Date,TimeandLanguage...............................................200
BeepAlerts...................................................................................202
LCDandLEDs...............................................................................202
JumboFrames..............................................................................203
ChangingtheIPAddress.............................................................204
Chapter11Utilities...................................................206
NASNavigator2(Windows)........................................................206
AssignasNetworkDrive.......................................................................................... 209
NASNavigator2(MacOSX).........................................................209
MountingasaNetworkDrive................................................................................ 210
iSCSIHardDiskConnectionTool(Windows).............................211
Menu................................................................................................................................ 213
TurboCopy(Windows)................................................................214

8
TurboPC(Windows).....................................................................214
Chapter12Appendix................................................215
DiagramsandLayout..................................................................215
TS5800D......................................................................................................................... 215
TS5600D......................................................................................................................... 215
TS5400D......................................................................................................................... 215
TS5200D......................................................................................................................... 216
LCDMessageList.........................................................................218
NormalDisplay............................................................................................................ 218
StatusDisplay............................................................................................................... 218
ErrorDisplay,WarningDisplay.............................................................................. 222
DefaultSettings...........................................................................223
Specifications...............................................................................225
ComplianceInformation.............................................................226
FCCWarning................................................................................................................. 226
CEMarkWarning........................................................................................................ 226
EnvironmentalInformation.................................................................................... 227
KC...................................................................................................................................... 227
BSMI................................................................................................................................. 227
CCC................................................................................................................................... 227

9
Chapter 1 Installation
Installation
1 Insert the TeraNavigator CD into your computer.
TeraNavigator will launch.
2 Click [Begin Installation].
Notes:
• If TeraNavigator does not launch automatically in Windows, open the CD and double-click the icon.
• If you are using Windows 7 or Vista, the autoplay screen may appear. Click [Run LSNavi.exe]. If "Do you want to
allow the following program to make changes to this computer?" is displayed by Windows 7, click [Yes]. If "A
program needs your permission to continue" is displayed by Windows Vista, click [Continue].
• If your computer does not have a CD drive, you may download the TeraNavigator software from www.
buffalotech.com.
• For Mac OS X, double-click on the TeraNavigator icon in the TeraNavigator CD.
• If you have problems installing, temporarily disable your antivirus software and software firewall. After setup is
complete, re-enable the software.
3 Follow the steps on the screen to connect the TeraStation's Ethernet and power cables and turn it on.
TS5800D

10
TS5600D
TS5400D
TS5200D
Note:
Use LAN port 1 for initial setup. After setup, you may connect a second cable to LAN port 2. If used, congure the IP
address of LAN port 2 at [Network] - [IP Address] in the TeraStation's Web Admin interface or NAS Navigator2.
4 Follow the steps on the screen to install NAS Navigator2.
5 Click [Complete].
NAS Navigator2 will start.
Notes:
• To start NAS Navigator2 after the initial setup, perform the operations below.
For Windows, double-click the icon on the desktop.
For Mac OS X, click the icon in the Dock.
• To install additional software, click [Software Installation].

11
6 Right-click on your TeraStation's icon, then click [Properties].
Note:
For Mac OS X, click the TeraStation icon while holding down the control key, then click [Congure].
7 Click the [IP Settings] tab, enter the desired settings, and click [OK].
Notes:
• If you don't know how to configure these settings, check [Obtain IP address automatically via DHCP]. For Mac
OS X, check [Use DHCP].
• If you are prompted to enter the administrator's password, enter the TeraStation's password (it is set to
"password" by factory default).

12
8 The Web Admin interface will open.
Note:
The Web Admin interface is compatible with Internet Explorer 9 or later, Firefox 8 or later, Google Chrome 15 or
later, and Safari 5 or later.
9 Change the administrator password in the displayed screen.
Note:
The default username and password are "admin" and "password" respectively.
1 0 Click [Management] - next to [Name/Time/Language] - [Time] - [Edit], then congure the TeraStation's clock
with the Web Admin interface.
Notes:
• By default, the TeraStation adjusts its clock automatically by using an NTP server. The internal clocks of the
TeraStation and other devices on your network may run at slightly different speeds. Over a long period of time
your network devices may show somewhat different times, which can cause network problems. If clocks on
your network vary by more than 5 minutes it may cause unexpected behavior. For best results, keep all clocks
on the network set to the same time by adjusting them regularly, or use an NTP server to correct them all
automatically.
• NTP may not be usable in some networks. The default NTP Server (ntp.jst.mfeed.ad.jp) belongs to Internet Multi
Feed Inc. For more information, please visit www.jst.mfeed.ad.jp. Use NTP at your own risk. Buffalo Technology is
not responsible for any loss or damage caused by using of this service, stopping the service, or missing service.
• If the TeraStation cannot automatically obtain the time from an NTP server, check the TeraStation's DNS server
address settings. If the NTP server is specified by a hostname instead of an IP address, a DNS server address

13
must be set in [Network] - [IP Address] of the Web Admin interface.
1 1 To congure a RAID scan, click [Drives], then change the icon next to [RAID Scanning] from -> .
Note:
RAID scans check RAID arrays to conrm that they can be read properly and have no bad sectors. If any problems
are found, they will be repaired automatically.
1 2 This creates a USB memory device that can be used to restore default settings or transfer settings to another iden-
tical TeraStation.
1. In the TeraStation's Web Admin interface, click [Management] - next to [Restore/Erase].
2. Connect a USB memory device (not included) with 1 GB or larger to a USB 2.0 port on the TeraStation.
3. Select [Create a special USB drive for password recovery]. This recovery USB drive will also reset the TeraStation's
administrator password to its default.
4. Select the connected USB memory device, then click [Execute].
To return the TeraStation to the default settings using the created USB memory device, see "Recovering by
Changing the Boot Mode Switch on the Rear Panel When Starting the TeraStation" in Chapter 9.
1 3 In NAS Navigator2, double-click your TeraStation's icon. This will open the shared folder of the TeraStation.
Notes:
• For Mac OS X, the TeraStation is mounted as a drive icon on the desktop, or it is displayed in the sidebar of the

14
Finder.
• You can now use the TeraStation's shared folder to save files just like any other folder.
This completes the setup.
Turning on the TeraStation
Press the power button on the TeraStation to turn it on.
Turning off the TeraStation
The TeraStation might be damaged if it is unplugged suddenly without powering it down properly rst. Follow one of
the procedures below to turn o the TeraStation properly.
Using the Power Button
Press the power button twice within 3 seconds to shut down the TeraStation.
Using the TeraStation's Web Admin interface
1 Double-click the icon on the desktop.
NAS Navigator2 will start.
Note:
For Mac OS X, click the icon in the Dock.
2 Right-click on the TeraStation icon, then select [Open Web setting].
Note:
For Mac OS X, click the TeraStation icon while holding down the control key, then select [Open Web setting].

15
3 Enter the username and password, then click [OK].
Note:
The default username and password are "admin" and "password" respectively.
4 The Web Admin interface will open.
5 Click the on the right top of the Web Admin interface, then click [Shut Down].
When all the LEDs on the front of the TeraStation turn o, the shutdown process is complete.
Changing the Password
After initial setup, follow the procedure below to change your password.
1 Double-click the icon on the desktop.

16
NAS Navigator2 will start.
Note:
For Mac OS X, click the icon in the Dock.
2 Right-click on the TeraStation icon, then select [Open Web setting].
Note:
For Mac OS X, click the TeraStation icon while holding down the control key, then select [Open Web setting].
3 Click [Easy Admin].
4 Click [Change Password].

17
5 Enter the desired password for new password and conrm new password.
6 Click [OK].
You have now changed the admin password.

18
Chapter 2 Configuration
To congure and administer your TeraStation, use the Web Admin interface. It lets you congure all the TeraStation's set-
tings from a browser window. To open it, use the procedure below, or type the TeraStation's IP address into the URL eld
of your browser.
Opening the Web Admin Interface
1 Double-click the icon on the desktop.
NAS Navigator2 will start.
Note:
For Mac OS X, click the icon in the Dock.
2 Right-click on the TeraStation icon, then select [Open Web setting].
Note:
For Mac OS X, click the TeraStation icon while holding down the control key, then select [Open Web setting].
3 Enter the username and password, then click [OK].

19
Notes:
• The default username and password are "admin" and "password" respectively.
• If you are logged in with the admin account, all settings are available.
• Alternately, you may log in as a guest (if the guest account is enabled) or with your username.
• To log in as a guest, enter "guest" as the username and leave the password blank. If you are logged in as guest,
you can check the TeraStation's name, IP address, workgroup, drive status, and firmware version.
• If you log in with your username and password, you can check the TeraStation's name, IP address, workgroup,
drive status, and firmware version, and you can change your password.
• Click [Easy Admin] to open the Easy setup screen. Click [Secure Connection] to encrypt data during
communication.
• The Web Admin interface is compatible with Internet Explorer 9 or later, Firefox 8 or later, Google Chrome 15
or later, and Safari 5 or later. If using Internet Explorer, if there are a large number of registered users, groups,
or shared folders, the Web Admin interface screen may not be displayed correctly. Use of Firefox 8 or later is
recommended.
• If a proxy server is enabled in the browser settings, the Web Admin interface cannot be displayed properly.
Disable the proxy server if it is enabled.
• The Web Admin interface may not display correctly in Internet Explorer due to your browser security settings.
If this happens, navigate to [Tools] - [Internet Options] - [Security] on Internet Explorer, and set the Security
Settings to [Local intranet].
4 The Web Admin interface will open.
This completes the opening of the Web Admin interface.
Note:
Mac OS X allows you to log in to the Web Admin interface with an alternative procedure using Bonjour. Follow the
procedure below to use this alternative method to log in to Mac OS X 10.4 or later:
1. Start the Safari Internet browser.
2. From the Safari menu, click [View] - [Show Bookmarks Bar]. Set so that the Safari bookmark bar is displayed.
3. From Bookmarks, click [Bonjour] - [(TeraStation name)].
The Web Admin interface will open.
Opening the Easy Setup Screen in the Web Admin Interface
Use the Easy Setup screen to make common changes to settings. Follow the procedure below to open the Easy Setup
