BUMPSUIT ARMADILLO User manual

IMPORTANT!
READ CAREFULLY AND KEEP
FOR FUTURE REFERENCE.
READ ALL INSTRUCTIONS BEFORE ASSEMBLING AND USING YOUR CARRIER.
FAILURE TO FOLLOW EACH INSTRUCTION CAN RESULT IN SERIOUS INJURY
OR DEATH TO YOUR BABY. KEEP INSTRUCTIONS AND REVIEW THEM BEFORE
ATTEMPTING NEW CARRYING POSITIONS.
ARMADILLO BABY CARRIER
INSTRUCTION MANUAL

3
WARNINGS
CARE AND MAINTENANCE
WARNINGS
USER GUIDE
CARE AND MAINTENANCE
USING THE BABY CARRIER
COMPONENTS LIST
PARENT FACING POSITION
WORLD FACING POSITION
CONTACTS
CUSTOMER SERVICE
3
6
7
8
10
14
20
CONTENTS
2
CONTENTS
• WARNING: YOUR
BALANCE MAY BE
ADVERSELY AFFECTED
BY YOUR MOVEMENT
AND THAT OF YOUR
CHILD.
• WARNING: TAKE CARE
WHEN BENDING OR
LEANING FORWARD OR
SIDEWAYS.
• WARNING: THIS
CARRIER IS NOT
SUITABLE FOR USE
DURING SPORTING
ACTIVITIES.
• CHECK TO ASSURE
ALL BUCKLES,
SNAPS, STRAPS, AND
ADJUSTMENTS ARE
SECURE BEFORE EACH
USE.
• CHECK FOR RIPPED
SEAMS, TORN STRAPS
OR FABRIC, AND
DAMAGED FASTENERS
BEFORE EACH USE.
• ENSURE PROPER
PLACEMENT OF CHILD
IN PRODUCT INCLUDING
LEG PLACEMENT.
• CHILD MUST FACE
TOWARDS YOU UNTIL
THEY CAN HOLD THEIR
HEAD UPRIGHT.
• PREMATURE
INFANTS, INFANTS
WITH RESPIRATORY
PROBLEMS, AND
INFANTS UNDER
4 MONTHS ARE AT
GREATEST RISK OF
SUFFOCATION.
• FOR LOW BIRTH WEIGHT
BABIES AND CHILDREN
WITH MEDICAL
CONDITIONS, SEEK
ADVICE FROM A HEALTH
PROFESSIONAL BEFORE
USING THIS PRODUCT.
PLEASE READ THESE INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE SOFT CARRIER. KEEP
THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE,
AS IT CONTAINS IMPORTANT INFORMATION.
⚠WARNING
FAILURE TO FOLLOW THESE WARNINGS
AND THE INSTRUCTIONS COULD RESULT IN
SERIOUS INJURY OR DEATH.

5
WARNINGS
4
WARNINGS
⚠WARNING
FALL AND SUFFOCATION HAZARD
FALL HAZARD – INFANTS CAN FALL THROUGH A
WIDE LEG OPENING OR OUT OF CARRIER.
• ADJUST LEG OPENINGS TO FIT BABY’S LEGS
SNUGLY.
• BEFORE EACH USE, MAKE SURE ALL FASTENERS
ARE SECURE.
• TAKE SPECIAL CARE WHEN LEANING OR
WALKING.
• NEVER BEND AT WAIST; BEND AT KNEES.
• ONLY USE THIS CARRIER FOR BABIES BETWEEN
7 LBS AND 45 LBS (SUITABLE FROM NEWBORN).
SUFFOCATION HAZARD – INFANTS UNDER 4
MONTHS
CAN SUFFOCATE IN THIS PRODUCT IF FACE IS
PRESSED TIGHT AGAINST YOUR BODY.
• DO NOT STRAP INFANT TOO TIGHT AGAINST
YOUR BODY.
• ALLOW ROOM FOR HEAD MOVEMENT.
• KEEP INFANT’S FACE FREE FROM
OBSTRUCTIONS AT ALL TIMES.
THIS PRODUCT COMPLIES WITH SAFETY
REQUIREMENTS OF ASTM F2236 &16 CFR 1226
⚠WARNING
FAILURE TO FOLLOW THESE WARNINGS
AND THE INSTRUCTIONS COULD RESULT IN
SERIOUS INJURY OR DEATH.
• NEVER USE A SOFT
CARRIER WHEN
BALANCE OR MOBILITY
IS IMPAIRED BECAUSE
OF EXERCISE,
DROWSINESS, OR
MEDICAL CONDITIONS.
• NEVER USE A SOFT
CARRIER WHILE
ENGAGING IN
ACTIVITIES SUCH
AS COOKING AND
CLEANING WHICH
INVOLVE A HEAT
SOURCE OR EXPOSURE
TO CHEMICALS.
• CHECK SURROUNDINGS
FOR HAZARDS
IN DOMESTIC
ENVIRONMENT BEFORE
EACH USE, SUCH AS
EXPOSED FLAMES,
HEAT SOURCES, OR HOT
DRINKS WHICH MAY BE
SPILLED.
• NEVER WEAR A SOFT
CARRIER WHILE
DRIVING OR BEING A
PASSENGER IN A MOTOR
VEHICLE.
• BEFORE EACH USE,
INSPECT THIS PRODUCT
FOR DAMAGED STRAPS,
BUCKLES, SNAPS,
MISSING PARTS OR
SHARP EDGES. DO
NOT USE IF ANY PARTS
ARE MISSING OR
BROKEN. CONTACT THE
MANUFACTURER FOR
REPLACEMENT PARTS
AND INSTRUCTIONS
IF NEEDED. NEVER
SUBSTITUTE PARTS.
• WHEN USING THE SOFT
CARRIER, MONITOR
YOUR CHILD.

6 7
USER GUIDE
CARE & MAINTENANCE
PARENT FACING POSITION, APPROX 0-24 MONTHS
(BABY FACING TOWARDS YOU)
UNTIL YOUR CHILD IS ABLE TO HOLD THEIR HEAD UPRIGHT, THIS
IS THE CORRECT POSITION. IT AFFORDS YOUR BABY LOTS OF
CLOSE PHYSICAL CONTACT AND ATTENTION, WHILE LEAVING YOUR
HANDS FREE IN THIS POSITION. YOU CAN ENTERTAIN AND BOND
WITH YOUR NEWBORN BY TALKING, TOUCHING, PLAYING, OR JUST
MAKING EYE-CONTACT.
HOW DO YOU KNOW IF YOUR BABY IS AT THE RIGHT HEIGHT WHEN
WORN IN THE FRONT? YOU SHOULD BE ABLE TO TILT FORWARD
SLIGHTLY AND KISS THE TOP OF YOUR CHILD’S HEAD.
WORLD FACING POSITION APPROX 6-24 MONTHS
(BABY FACING AWAY FROM YOU)
ONCE YOUR CHILD IS ABLE TO HOLD THEIR HEAD UP, YOUR BABY
IS READY FOR A NEW ADVENTURE. THIS POSITION ALLOWS THEM
TO VISUALLY EXPLORE THEIR SURROUNDINGS WHILE MAINTAINING
CLOSE CONTACT WITH YOU.
WHEN PLACING YOUR BABY IN OR TAKING THEM OUT OF THE
CARRIER, SITTING DOWN WILL MAKE THE PROCEDURE EASIER.
UNTIL YOU ARE FAMILIAR WITH THE PLACEMENT OF THE BABY, IT IS
ALSO RECOMMENDED TO DO SO OVER A SOFT SURFACE.
IT IS BEST TO LIMIT THE USE OF YOUR CARRIER TO 10-20 MINUTES
UNTIL YOU AND YOUR BABY ARE BOTH COMPLETELY COMFORTABLE
IN IT TOGETHER.
• SPOT CLEAN.
• LINE DRY.
• ALWAYS ALLOW THE FABRICS TO DRY NATURALLY AWAY FROM
STRONG HEAT SOURCES SUCH AS FIRES, RADIATORS AND OUT
OF DIRECT SUNLIGHT.
HELPFUL HINTS
CARE INSTRUCTIONS

9
COMPONENTS LIST
COMPONENTS LIST
FORWARD FACING – FRONT
PARENT FACING
WORLD FACING
UV/WEATHER
SHIELD
POCKET
UV/WEATHER
SHIELD
POCKET
PADDED
SHOULDER
STRAP
PADDED
SHOULDER
STRAP
BUCKLE/
TIGHTENER
BUCKLE/
TIGHTENER
MESH
STORAGE
POCKET
MESH
STORAGE
POCKET
ADJUSTABLE
GUARD/LEG
OPENING
ADJUSTABLE
GUARD/LEG
OPENING
COMPONENTS LIST
BACK
PADDED
SHOULDER
STRAP
WAIST BELT
BUCKLE WITH
TIGHTENER
PADDED LUMBAR
BACK SUPPORT
BELT SUPPORT
BUCKLE WITH
ADJUSTER
SIDE
BUCKLE
WITH
ADJUSTER
SIDE BUCKLE
WITH
ADJUSTER
8

10
PARENT FACING POSITION
IMPORTANT! YOUR BABY MUST FACE TOWARD YOU UNTIL
THEY ARE ABLE TO HOLD THEIR HEAD UPRIGHT.
WHEN USING THIS CARRIER IN THE PARENT FACING
POSITION, PLEASE FIT IT TO THE USER BEFORE PLACING
THE BABY IN THE CARRIER.
KEEP ONE HAND ON THE BABY UNTIL ALL THE BUCKLES
AND STRAPS ARE PROPERLY FASTENED.
STEP 1
UNFASTEN THE WAIST BELT
BUCKLES.
POSITION THE CARRIER BELT AT
HIP LEVEL AND SECURE STRAP &
WAIST BELT BY FASTENING THE
BELT BUCKLE UNTIL YOU HEAR A
CLICK SOUND.
PULL WAIST BELT ADJUSTER TO
TIGHTEN UNTIL THE WAIST BELT
FEELS SECURE AND AND FITS
SNUGLY AROUND YOUR WAIST.
ADJUST THE BACK LUMBAR PAD
TO SUPPORT YOUR LOWER BACK.
CARRIER USE FOR AN INFANT:
PARENT FACING POSITION
PARENT FACING POSITION
STEP 3
FASTEN THE RIGHT SHOULDER
STRAP BUCKLE TO THE LEFT SIDE
CLOSURE BUCKLE, MAKING SURE
TO HEAR A CLICK. ADJUST STRAP
FOR A SNUG FIT.
STEP 2
HUG BABY CLOSE TO YOUR
CHEST AND DRAPE THE RIGHT
STRAP OVER YOUR RIGHT
SHOULDER GOING DIAGONALLY
ACROSS YOUR BACK TOWARDS
THE LEFT SIDE OF YOUR BODY,
MAKING SURE TO KEEP ONE
HAND ON BABY AT ALL TIMES.
STEP 4
REPEAT STEPS 2-3 ON THE
OPPOSITE SIDE TO SECURE THE
LEFT SHOULDER STRAP TO THE
RIGHT SIDE CLOSURE BUCKLE
MAKING SURE TO HEAR A CLICK.
STEP 5
ONCE BOTH SHOULDER STRAPS
ARE BUCKLED, PULL THE ADJUST-
ABLE STRAPS FOR A CUSTOM FIT,
MAKING SURE BOTH YOU AND
BABY FEEL SECURE AND SNUG.
IMPORTANT: KEEP ONE HAND ON THE BABY UNTIL ALL
BUCKLES AND STRAPS ARE PROPERLY FASTENED.
MAKE SURE YOUR BABY’S LEG GOES THROUGH THE
LEG OPENING ON THE CLOSED SIDE OF THE CARRIER.
11
PARENT FACING POSITION

12
PARENT FACING POSITION
STEP 6
TO ADJUST HOW HIGH THE BABY
RIDES ON YOUR CHEST, LIFT THE
BABY SLIGHTLY AND PULL THE
SHOULDER STRAP END DOWNWARD,
FIRST ON ONE STRAP, THEN ON THE
OTHER.
WHEN THE BABY IS PROPERLY PO-
SITIONED, YOU SHOULD BE ABLE TO
TILT YOUR HEAD FORWARD AND KISS
THE TOP OF YOUR BABY’S HEAD.
REMOVING CHILD FROM THE
PARENT FACING POSITION
IMPORTANT! WHEN REMOVING THE BABY FROM THE CARRIER, KEEP
AT LEAST ONE HAND ON THE BABY AT ALL TIMES.
KEEPING ONE HAND SECURELY ON THE BABY, INSIDE THE CARRIER,
HOLDING THEM CLOSE TO YOUR CHEST.
RELEASE THE SIDE CLOSURE BUCKLE. MAKING SURE TO KEEP YOUR
BABY SECURE AT ALL TIMES.
RELEASE THE OTHER SIDE CLOSURE BUCKLE ON THE CLOSED SIDE
OF THE CARRIER. WITH BOTH HANDS, LIFT YOUR BABY AND PLACE
THEM IN A SAFE LOCATION.
YOU CAN NOW REMOVE THE CARRIER FROM YOUR BODY BY
RELEASING THE BACK WAIST BAND BUCKLE.
1. LAY CARRIER FLAT ON
TABLE.
2. REMOVE VELCRO TAB
FROM PROTECTIVE FABRIC
POCKET.
3. ADJUST POSITION TOWARDS
INNER SEAM.
4. REPEAT STEPS 1-3 ON
OPPOSITE SIDE.
TO ADJUST CARRIER TO
WORLD FACING POSITION
INSTRUCTIONS FOR
CONVERTING TO WORLD
FACING POSITION
ADJUSTABLE GUARD/LEG
OPENING FOR PARENT
FACING POSITION
ADJUSTABLE GUARD/LEG
OPENING FOR WORLD
FACING POSITION
13
CONVERSION TO WORLD FACING POSITION

14
WORLD FACING POSITION
WORLD FACING POSITION
IMPORTANT! YOUR BABY MUST FACE TOWARD YOU
UNTIL THEY ARE ABLE TO HOLD THEIR HEAD UPRIGHT.
WHEN USING THIS CARRIER IN THE WORLD FACING
POSITION, PLEASE FIT IT TO THE USER BEFORE
PLACING THE BABY IN THE CARRIER.
KEEP ONE HAND ON THE BABY UNTIL ALL THE
BUCKLES AND STRAPS ARE PROPERLY FASTENED.
CARRIER USE FOR AN INFANT:
WORLD FACING POSITION
STEP 1
UNFASTEN THE WAIST
BELT BUCKLES.
POSITION THE CARRIER BELT AT
HIP LEVEL AND SECURE STRAP &
WAIST BELT BY FASTENING THE
BELT BUCKLE UNTIL YOU HEAR A
CLICK SOUND.
PULL WAIST BELT ADJUSTER TO
TIGHTEN UNTIL THE WAIST BELT
FEELS SECURE AND AND FITS
SNUGLY AROUND YOUR WAIST.
ADJUST THE BACK LUMBAR PAD
TO SUPPORT YOUR LOWER BACK.
STEP 3
WITH THE CARRIER OPEN ON
ONE SIDE AND BABY FACING
AWAY FROM YOU, CAREFULLY
SLIDE BABY INTO CARRIER,
ENSURING BABY’S LEG GOES
THROUGH THE LEG OPENING ON
THE CLOSED SIDE OF CARRIER.
STEP 2
HUG BABY CLOSE TO YOUR
CHEST FACING OUTWARD AND
DRAPE THE RIGHT STRAP OVER
YOUR RIGHT SHOULDER GOING
DIAGONALLY ACROSS YOUR
BACK TOWARDS THE LEFT SIDE
OF YOUR BODY, MAKING SURE
TO KEEP ONE HAND ON BABY AT
ALL TIMES.
STEP 4
WHILE ALWAYS SUPPORTING
THE BABY WITH ONE HAND,
POSITION THE SECOND
SHOULDER STRAP, DIAGONALLY
OVER YOUR SHOULDER AND
FASTENING TO THE BUCKLE.
YOU WILL HEAR A ‘CLICK’
WHEN THE BUCKLE IS SECURE.
ADJUST BOTH LEG OPENINGS TO
SNUGLY FIT THE BABY’S LEGS.
15
WORLD FACING POSITION

16
WORLD FACING POSITION
THE BABY SHOULD NEVER BE LEANING FORWARD IN
THE CARRIER.
PLEASE NOTE: THE ARMS OF SMALLER BABIES SHOULD BE
POSITIONED BELOW THE HEAD SUPPORT BUCKLES. LARGER
BABIES’ ARMS SHOULD BE ABOVE THE BUCKLE, AND REST
COMFORTABLE OVER THE FOLDED DOWN HEAD SUPPORT.
STEP 6
TO ADJUST HOW HIGH THE BABY
RIDES ON YOUR CHEST, LIFT
THE BABY SLIGHTLY AND PULL
THE SHOULDER STRAP END
DOWNWARD, FIRST ON ONE
STRAP, THEN ON THE OTHER.
WHEN THE BABY IS PROPERLY
POSITIONED, YOU SHOULD
BE ABLE TO TILT YOUR HEAD
FORWARD AND KISS THE TOP OF
YOUR BABY’S HEAD.
STEP 5
ONCE BOTH SHOULDER STRAPS
ARE BUCKLED, PULL THE ADJUST-
ABLE STRAPS FOR A CUSTOM FIT,
MAKING SURE BOTH YOU AND
BABY FEEL SECURE AND SNUG.
IMPORTANT: KEEP ONE HAND ON THE BABY UNTIL ALL
BUCKLES AND STRAPS ARE PROPERLY FASTENED. MAKE
SURE YOUR BABY’S LEG GOES THROUGH THE LEG
OPENING ON THE CLOSED SIDE OF THE CARRIER.
1. LAY CARRIER FLAT ON TABLE.
2. REMOVE VELCRO TAB
FROM PROTECTIVE FABRIC
POCKET.
3. ADJUST POSITION TOWARDS
OUTER SEAM.
4. REPEAT STEPS 1-3 ON
OPPOSITE SIDE.
TO ADJUST CARRIER TO
PARENT FACING POSITION
INSTRUCTIONS FOR
CONVERTING TO PARENT
FACING POSITION
ADJUSTABLE GUARD/LEG
OPENING FOR PARENT
FACING POSITION
ADJUSTABLE GUARD/LEG
OPENING FOR WORLD
FACING POSITION
17
CONVERSION TO PARENT FACING POSITION

REMOVING CHILD FROM THE
WORLD FACING POSITION
IMPORTANT! WHEN REMOVING THE BABY FROM THE CARRIER,
KEEP AT LEAST ONE HAND ON THE BABY AT ALL TIMES.
KEEPING ONE HAND SECURELY ON THE BABY, INSIDE THE
CARRIER, HOLDING THEM CLOSE TO YOUR CHEST.
RELEASE THE SIDE CLOSURE BUCKLE. MAKING SURE TO KEEP
YOUR BABY SECURE AT ALL TIMES.
RELEASE THE OTHER SIDE CLOSURE BUCKLE ON THE CLOSED
SIDE OF THE CARRIER. WITH BOTH HANDS, LIFT YOUR BABY AND
PLACE THEM IN A SAFE LOCATION.
YOU CAN NOW REMOVE THE CARRIER FROM YOUR BODY BY
RELEASING THE BACK WAIST BAND BUCKLE.
18
WORLD FACING POSITION

TO REGISTER YOUR CARRIER
PLEASE GO ONLINE:
WWW.BUMPSUIT.CO/REGISTER
BUMPSUIT
1155 BARTON SPRINGS RD, #502
AUSTIN, TX 78704-9918
HOURS: 8:30 AM – 5:00 PM MONDAY TO FRIDAY
EMAIL: [email protected]
PHONE: [phone]
HOURS: 8:30 AM – 5:00 PM MONDAY TO FRIDAY
