Burco CT5L User manual

1
INSTRUCTION MANUAL
Autofill Countertop Waterboilers
(Filtration & Non-Filtration models)
Burco is part of:
Glen Dimplex Heating & Ventilation
Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF.
Aftersales Tel: [phone]
www.burco.co.uk
Please keep these instructions in a safe place.
08/54070/0 (Jan 19)
These instructions cover the following Burco models:
Burco Filtration Autofills: 5L 069764, 10L 069771 & 070005 , 20L 069788 & 069795
Burco Autofill (without Filter): 10L 069825, 20L 069832
Burco Slimline Autofills: 5L 070012 &10L 070043, 070029 &070067

2
Contents Page
About my product (please complete the details below) 2
Warning & Precautions 3-4
Introduction 5
Warranty Information 5
Accessories Kit 5
Technical Data 6
Installation Burco water boiler 6
Operating Instructions 9-12
Descaling & Cleaning advice and information 13-14
Changing Water Filter 14
Troubleshooting 15
Spare / Replacement Part information 15
Frequently asked questions (FAQ’s) 16
About my product
Please take some time to complete the information below, it may save time if you
need to contact us for any reason.
Model Number
0
Serial Number
(this can be found on the data badge
on the back of the product)
Date of purchase
Purchased from
In your instruction pack you will find a duplicate data badge which contains all the critical information
above. You can peel off the backing and stick in the box below:

3
Warnings and Precautions
WARNING. THIS SYMBOL MEANS THERE IS A RISK OF
PERSONAL INJURY.
IMPORTANT. THIS SYMBOL MEANS THERE IS A RISK OF
DAMAGING THE APPLIANCE.
THIS APPLIANCE MUST BE INSTALLED, COMMISSIONED
AND SERVICED BY A QUALIFIED PERSON IN ACCORDANCE
WITH THE NATIONAL AND LOCAL REGULATIONS IN FORCE
IN THE COUNTRY OF INSTALLATION. ALSO TAKE INTO
CONSIDERATION.
HEALTH AND SAFETY AT WORKS ACT
IEE REGULATIONS
BS CODES OF PRACTICE
LOCAL AND NATIONAL BUILDING REGULATIONS
LOCAL AND NATIONAL WATER REGULATIONS
THIS APPLIANCE CAN BE USED BY CHILDREN AGED
FROM 8 YEARS AND ABOVE AND PERSONS WITH REDUCED
PHYSICAL SENSORY OR MENTAL CAPABILITIES OR LACK
OF EXPERIENCE AND KNOWLEDGE IF THEY HAVE BEEN
GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE
OF THE APPLIANCE IN A SAFE WAY AND UNDERSTANDING
THE HAZARDS INVOLVED. CHILDREN SHALL NOT PLAY
WITH THE APPLIANCE. CLEANING AND USER MAINTENANCE
SHALL NOT BE MADE BY CHILDREN WITHOUT
SUPERVISION.
DISCONNECT APPLIANCE BEFORE SERVICING,
MAINTENANCE OR CLEANING.

4
IF THE SUPPLY CORD IS DAMAGED, IT MUST BE
REPLACED BY THE MANUFACTURER, ITS SERVICE AGENT
OR SIMILARLY QUALIFIED PERSONS IN ORDER TO AVOID A
HAZARD.
DO NOT IMMERSE CORD, PLUG, OR WATER BOILER IN
WATER OR ANY OTHER LIQUID.
THE FLEXIBLE HOSE CONNECTED FROM THE OVER
FLOW ALSO ACTS AS A VENT FOR THE APPLIANCE. UNDER
NO CIRCUMSTANCES SHOULD THIS FLEXIBLE HOSE
BECOME BLOCKED OR RESTRICTED IN ANY WAY.
THIS APPLIANCE MUST ONLY BE USED FOR HEATING
WATER.
THE UNIT MUST BE INSTALLED ON A SOLID CONCRETE
/ BRICK WALL BY A QUALIFIED FITTER. BURCO DOES NOT
ACCEPT ANY RESPONSIBILITY FOR THE SAFETY OF ANY
UNIT NOT INSTALLED IN THIS WAY.
DURING OPERATION PARTS & SURFACES MAY BECOME
HOT –AVIOD ACCIDENTAL CONTACT.
THIS APPLIANCE IS NOT SUITABLE FOR OUTDOOR USE.

5
Introduction
Thank you for purchasing this Burco Autofill Water Boiler.
To ensure you obtain the full benefits from your new appliance:
Please read this instruction book carefully and follow all advice given. Please pay particular attention
to any warnings.
If you are unsure of any aspects of the information provided, or the setup and performance of the
product, please contact our Aftersales team on 0344 879 3470.
The products are intended for commercial use as detailed in these instructions. The Company has a policy of
continuous improvement in product quality and design. The company therefore reserves the right to change
the specification at any time.
Warranty Information:
This Burco boiler comes with a comprehensive 1 year parts andlabourwarranty. If you have purchased
a Burco boiler with a water filter, then the warranty is 2 years parts and labour.
If you experience any problems with the water boiler, please contact our Aftersales team on 0344 879 3470.
To ensure we can offer you the best possible service, please ensure you have the product code and serial
number available (from page 2).
Your warranty is given subject to the appliance being used in accordance with the instructions supplied and
on the supply voltage marked on the rating label. It is also subject to fair wear and tear conditions. The warranty
does not cover:
Consequential damage arising out of any failure acceptable under warranty.
Accidental damage or misuse as detailed in these instructions.
Unauthorised alterations made to the appliance that aren’t made by a Burco-approved engineer.
Consumable items such as filter cartridges and drip trays.
Any damage due to incorrect installation, or build-up of scale or food debris.
It is important that you descale your water boiler regularly, particularly in hard water areas.
Failure to descale your water boiler, or replace your filter cartridge when
prompted to do so, will invalidate your warranty.
Accessories Kit
Descale Drain
Tube
Water Inlet
Hose
Drip Tray
Insert
Drip Tray

6
Technical Data
Installing your Burco boiler
Before connecting to the power supply
Remove all packaging and plastic coating from the appliance
Check the unit has not been damaged in any way during transportation. Report any damage to the
company who sold you the boiler right away.
Check the available power supply corresponds to that shown on the rating label of the appliance, which
must be A.C. (Alternating Current).
Ensure the yellow steam cap is removed from the steam vent prior to powering appliance.
The location must be frost free.
Connecting to the water supply
Connection from the cold water supply to the appliance should only be made by the hose supplied.
In hard water areas, it is always advisable to fit an inline filtration unit to limit scale build-up. If you
have purchased a Burco boiler that does not have a water filter system included, we recommend you
fit a separate water filter between the boiler and the mains supply.
Always ensure mains water supply is turned off, or localised isolation valves are closed before
attempting to connect boiler to the mains water supply.
The inlet water connection to the inlet solenoid valve is ¾” BSP, this should be connected to the mains
water supply via an accessible isolating tap.
The blue pipe connects to the grey fitting which can be found underneath the appliance.
Firmly push the blue pipe into the small outlet hole on the grey fitting.
Ensure grey connection is screwed tight on the appliance and not leaking.
Locate the second grey connection fitting. Connect the other end of the blue pipe to this. This second
grey connection fitting is connected to the mains water supply forming a cold water feed from the
mains water supply to the Burco boiler.
Do not use old water hoses.
Model
CT5L
CT10L, PB
CT20L
CT20L TT
SL5L, PB
SL10L,PB
SL10L EH
Height (mm)
457
578
695
518
627
668
Width (mm)
358
215
Depth (mm)
464
373
Capacity (Litres)
5
10
20
5
10
10
Weight (Kg)
11
12
13
14
10
11
11.5
Ambient Temperature
5°C –30°C
Water Inlet Pressure
1 –8 (Bar)
Voltage
220-240V (50/60Hz)
Power Rating
3kW
6kW
3kW

7
Electrical Connection
All electrical work must comply with all relevant wiring regulations and carried out by a qualified
electrician.
To protect against fire, electric shock and personal injury, do not immerse cord, plug, or water boiler
in water or any other liquid.
If the supply cord is damaged, it should be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid hazard.
This appliance must be earthed.
Fitting or replacing a plug (3kW models).
If the socket outlets are not suitable for the plug supplied with the appliance, the plug should be removed and
an appropriate one fitted.
An appropriate plug must be fitted as follows:
The wires in the mains lead are coloured in accordance with the following code:
Green & Yellow Wires Earth E
Blue Wire Neutral N
Brown Wire Live L
The supply cord on the 3kW appliance is of a special type. If replaced, only a Burco supply cord must be
used. Note: the supply cord may become warm when the appliance is in use.
Make sure the connections are tight and there are no loose strands of wire and no insulation trapped under
the terminals. Tighten the clamp in the plug making sure that it grips the outer covering of the cord. If fitting a
BS 1363 13A fused plug, then fit a 13A fuse and tighten the plug cover securely. If you are in any doubt,
consult a qualified electrician.
Means of isolation with at least 3mm contact separation in all poles must be incorporated into fixing of this
appliance.
The fixed wiring insulation must be protected by insulated sleeving having a temperature of at least 60˚C.
Supply cords should be oil resistant, sheathed flexible cable not lighter than ordinary polychloroprene or
equivalent elastomer sheathed cord (code 60245 IEC 57)
The appliance is supplied with a terminal block suitable for flexible wires up to 6mm².
Always destroy a plug that has been removed from the mains lead as a plug with bared flexible cord is
hazardous, if plugged into a live socket outlet
6kW Twin Tap Model
The 6kW appliance is supplied with an internal terminal block for connection to the main power supply. This
must be connected using suitable flexible cable. The supply end of the cord must be fitted with an easily
accessible, all pole disconnection isolator switch, with a minimum of 3mm contact separation. For safety
regulations the means of disconnection must be accessible after installation.
Disposal
At the end of the appliances useful life, it should not be disposed of with household waste. Please recycle
where facilities exist. Check with your local authority for recycling facilities and advice in your area.

8
Overflow and Drainage
Due to the electronic function of this water boiler, it is highly unlikely that an overflow would occur. The boiler
is primarily designed so that any overflow occurrence and condensation is directly vented to the spillage tray.
As an option, the boiler overflow outlet may be connected to a drainage system.
There may be some steam emitted from the vent at the base of the appliance during the initial fill
stages (or if the tank is refilled after being fully emptied) but this will reduce as the volume of water increases
in the tank. As an alternative, a flexible hose may be used to redirect steam to a sink/draining board.
The flexible hose connected from the over flow also acts as a vent for the appliance. Under no
circumstances should this flexible hose become blocked or restricted in any way.
Should the boiler overflow, the water will be collected in the drip tray. The water in the drip tray can then be
emptied out into a drain. Check and empty the drip tray on a regular basis.
Optional drip tray connection to a waste water supply (not supplied).
The drip tray may be connected directly to the waste water supply if required. However, we still recommend
this is disconnected and the drip tray cleaned regularly. The drip tray is dishwasher proof.
1. Turn the drip tray over 2. Carefully drill the plastic 3. Connect to the waste drainage
and locate the black lug. barrier inside the lug. with a flexible pipe.

9
Operating Instructions
Burco boilers are designed for continuous operation and should only be switched off for the purpose of
maintenance or emergency.
Boiler Overview
Boiler Overview
Before general use, please follow these important commissioning steps:
Ensure boiler is connected to the mains water supply.
Turn on the mains power and press and hold the power button for 10 seconds. The boiler should begin
filling and heating.
Ensure boiler is set to 98˚C, fully drain the boiler contents from the tap and repeat. Boiler should be fully
drained twice before general use.
Controller Set Up
On/Off Switch
Lift off lid for access
to descale cap
Controller Screen
Piping for connection
to potable water
Hot Water Tap
Water Filter Access
Drip Tray

10
Touch Screen Display (filtered models only):
The LCDscreen will illuminate with the Burco logo.The
default temperature and the time will flash waiting to be
set. The hour figure will flash. Use the scroll buttons
and press MENU to set when the correct time is shown.
To change default temperature, press UP/DOWN
SCROLL buttons to adjust to required temp.
Touch Screen Safety Lock:
Pressing and holding both the MENU and the UP
SCROLL button for 3 seconds activates the screen lock
function. When the Screen Lock function is active
settings cannot be changed. Press and hold the same
buttons to deactivate the screen lock function. If in
locked mode, the lock logo will blink on the screen for
a couple of seconds if any button is pressed.
Set Time:
Press MENU, SET CLOCK will be highlighted. Press MENU to enter the SET CLOCK menu. The time will be
displayed and the hour value will be flashing. Use the SCROLL buttons to select the correct value then press
MENU. The minute values will now be flashing. Use the SCROLL buttons again to select the correct values.
To store the time press MENU button again, this will also take you back to the SET UP menu. To exit the
SET UP menu press the STANDBY button.
Set Temperature:
Use the UP and DOWN buttons to adjust the temperature. Press and hold the UP or Down button for3 seconds
before setting desired temperature.
Screen Settings:
UP
DOWN
STANDBY
MENU
STANDBY
SETTINGS
ECO MODE

11
Press MENU and navigate down using the SCROLL button until SCREEN SETTINGS is highlighted, and then
press MENU. For the backlight brightness, the values will flash. Use the SCROLL buttons to choose between
5 levels of backlight brightness.Hold MENU to store. Now the contrast values will flash. Repeat for thecontrast.
Hold MENU to store and to exit.
Language:
Press MENU and navigate down using the SCROLL button until LANGUAGE is highlighted, the press
MENU. Scroll down to which language you want. Hold MENU to store and exit. Luxembourgish can also
be selected in this menu.
Eco Mode (Filter models only):
When no water is drawn from the boiler in 2 hours, the eco mode is engaged. The backlight turns off and the
only data displayed is the Burco logo along with the time and the status indicator. Water should be drawn off
to resume normal operation. To set the Eco mode timer, simply scroll down to ‘ON’ to set the desired time.
Once you are happy with the time that has been set, press the menu button to confirm this. This will then take
you to ‘OFF’, where you can then set the time that you want the Eco mode to finish. If you want to turn the Eco
mode off altogether, simply scroll down and select ‘OFF’.
TO EXIT MENUS, PRESS THE STANDBY BUTTON
LANGUAGE
ECO MODE
SCREEN SETTINGS
SET CLOCK
ECO MODE
LANGUAGE
SET CLOCK
SCREEN SETTINGS
ENGLISH
DEUTSCH
FRANÇAIS
ESPAÑOL
HOLANDÈS
ITALIANO
ECO MODE
SET CLOCK
SCREEN SETTINGS
LANGUAGE

12
Heating up:
HEATING will flash on controller screen during the
heating up period. LOW TEMP may be shown on the
screen during this time. When selected temperature is
achieved –READY is shown.
Filling:
Once the INITIAL SET UP is complete, the filling process
will start. The LCD Screen will show the word FILLING.
After the filling is complete, the heating will start until it
reaches the settemperature. The LCD Screen will show
the word HEATING.
Filter Life (Filtration models only):
During operation, the bars fill to represent filter usage. Once
exhausted, all the bars are solid and the fault code for
changing the filter is displayed. The unit should be powered
down. Filters replaced and filter counter reset (refer to
replacement parts).
Power Down:
To power down the product, the STANDBY button should be
held when on the normal operation screen for 10 seconds.
The shutdown screen will appear and using the scroll
buttons, ‘Yes’ should be selectedby pressing MENU. The unit
will thenshutdown.
Tap function:
The tap can be changed between a controllable and constant
flow. For ‘Controllable’ flow, simply pull the plastic handle away
from you to dispense water and release to stop, see image 1. If
you turn the plastic tap handle through 180 degrees, the tap will
be in ‘Constant’ mode, see image 2. Now when you pull the tap
towards you, it will remain locked downwards in an ‘open’ state
until you lift the black handle back upwards to stop. The tap
function is the same on tap models on both our Filtered and
Unfiltered boilers.
Always take care when operating the tap as the water will
be boiling hot.
1.
2.

13
Descaling & Cleaning advice and information
Descaling
The descaling procedure must be performed by suitable personnel as it requires the removal of panels from
the boiler and access to live electrical components. Always use a descaling agent suitable for stainless steel.
1. Isolate the boiler from electrical supply.
2. Allow the water to cool to approximately 60oC
3. Lift up the lid on the top of the boiler (Picture 1).
4. Twist the black tank cap clockwise and remove it. (Picture 2)
5. Add descaling agent through opening (Picture 3) in accordance with manufacturer’s instructions.
6. Replace the black tank cap (anti-clockwise) and ensure it is secure.
7. Turn on the electricity and allow the boiler to operate normally for approximately 45 minutes.
8. Isolate / turn off the boiler and allow to cool down.
9. Remove the tank cap again to inspect the tank and level detectors for scaledeposits.
10. Drain and flush the de-scaling agent from the tank, using tap on the front of theappliance.
11. FILTEREDMODELSONLYTodrain the tank completely, locate the drain valve at base (picture 4).
12. UNFILTEREDMODELSONLYTodrainthetankcompletely,locatedrainvalvebehindfrontpanel.Removethetwoscrews
securingtopplasticmoulding. Then removethetwoscrewssecuringthe bottom of the front panel. Liftfrontpanelup&towardsyou
toremove.(Philips headscrewdriverrequiredforthisstep)
13. Attach drain pipe from accessories kit (picture 5) & open drain valve to drain water through flexible pipe (picture 6).
14. Connect a hose from the overflow pipe into a bucket and open the valve to drain the tank.
15. When empty, close the drain valve. CHANGE WATER FILTER AT THIS STAGE, SEE PAGE 14 OF INSTRUCTIONS.
16. Replace tank cap and lid.
17. Turn the boiler back on.
It is important that you descale your water boiler regularly, particularly in hard
water areas.
Failure to descale your water boiler, or replace your filter cartridge when
prompted to do so, will invalidate your warranty.
1.
2.
3.
4.
5.
6.

14
Changing Water Filter (Filtered models only).
The boiler will alert when a new filter cartridge is required. The boiler should be descaled in conjunction with
the filer change, see page 17 of instructions.
The water filter cartridge is unique to Burco. Only Burco “BC02” replacement filter (Part No. 01/74334/0)
will fit these models. Please either purchase a replacement from your catering equipment supplier, or
alternative order replacements via: 0344 879 3470 www.burco.co.uk
Please ensure all packaging is removed before inserting new filter.
Failure to use the correct filter cartridge will affect performance and invalidate the boilers warranty.
Cleaning Instructions
It is recommend that your water boiler is cleaned on a regular basis. Failure to do so may result in
the appliance not operating to its full potential and may invalidate your warranty.
Disconnect from the electrical supply before cleaning and allow water boiler to cool.
Do not immerse the water boiler in water or any other liquids and take care to keep water away from
the supply cord and connections. Do not use a water jet or steam cleaner.
External Cleaning
Wipe the external surfaces & dispensing tap of the appliance with a damp cloth. It is recommended that this is
done dailyto prevent lime scale build up. Stubborn stains may beremoved using agood stainless steel cleaner
or non-abrasive cleaner. Hard to reach areas should be cleaned using a soft brush & mild cleaning solution.
Failure to clean on a regular basis may invalidate your warranty.
1. With the boiler empty and lying
on it back, locate the filter at
base of the boiler.
2. Twist cartridge anticlockwise to
remove. Twist new cartridge
clockwise until locked in position
(residual water may be present)
3. Press & hold the UP & DOWN
buttons for 3 seconds to reset filter
alarm on controller.

15
Troubleshooting
If you believe your Burco Boiler isn’t working correctly, please contact our Aftersales Team
on 0344 879 3470.
Your boiler is fitted with a fault system that is able to detect fault conditions. Some of the conditions are less
serious and the boiler will continue to operate normally, while other faults are more serious and will disable
the appliance. Before calling the service line, switch off appliance at the main supply, then draw off a small
amount of water and switch back on after 10 minutes. If the fault continues, please call the service line for
advice on 0344 879 3470
QR codes that appear on the screen can be scanned using an iPhone, Android and Windows device, which
will take you to the Burco website.
Spare / Replacement Parts
Genuine replacement Burco parts must be fitted. If generic non-Burco parts are
fitted, you may prevent your appliance from operating safely and in the most efficient
manner and also invalidate your warranty.
Examples of spare / replacement parts include:
Element
Solenoid Valve
Electronic Controller
Mains Lead (where applicable)
Tap
Drip Tray and Insert
Filter Head
Filter Cartridge
Tank Cover
Tank Cap
For further information or to purchase spare parts, please contact our Aftersales team on 0344 879 3470.
Please ensure you have the details of the model and serial numbers to hand. These can be found in the “About
my product” section on page 2. These can also be found on the data label at on the back of the appliance.

16
Frequently Asked Questions (FAQ’s).
The following list of FAQ’s may help you with any information or problems with your Burco boiler.
Alternatively, please contact our Aftersales Team on 0344 879 3470 if your question is no covered below or if
you aren’t sure about something.
1. Are there any restrictions as to where I should locate my Burco waterboiler?
a. Yes,your appliance should be positioned on aflat,vertical wall that is capable of taking the weight
of the appliance when full of water.Consideration must also begiven to serving requirements and
safe operational access to the appliance must also be ensured. For a detailed overview of
installation requirement, please refer to Page 6 of this instruction book.
2. There is no water coming from the tap?
a. Check that the appliance is connected to mains power/water and that there is no blockage/kink
in the supply hose.
3. My screen is not illuminating?
a. Check the appliance is connected to mains power and turned on then adjust thebrightness/contrast
setting if required.
4. My boiler displays ‘CHANGE FILTER’?
a. Replace filter and reset the filter counter. If you need further help, see the demonstration video
on our website at www.burco.co.uk/changefilter
5. The water from the tap is cold?
a. Check appliance is connected to mains power and set temperature at the desired setting.
6. The water in my appliance has a strange taste?
a. All new appliances must be heated and drained tosanitise. Follow the instructions outlined on page
9to complete this process.
7. What Warranty does my water boiler have?
a. Your Burco boiler will come with a 1 year parts and labour warranty. If you have purchased a boiler with
awater filter,it willcomewitha 2 yearspartsandlabour warranty. Pleasesee the ‘Warranty’ section on
page 5 for details.
8. My boiler doesn’t seem to be heating what is wrong with it?
a. It could be that your boiler requires descaling. Follow the instructions on page 14 to do this.
Regular descaling is the responsibility of the site. If the boiler has not been descaled when
our Service Engineer visits, the service call will be chargeable.
9. Can I purchase any replacementparts?
Yes, we have a number of replacement parts available. If you require any spare parts, please do not
hesitate to contact our Aftersales Team on 0344 879 3470 and they will be happy to assist.
