INTRODUCTION
Declaration of conformity
WARNING!
Congratulations on your purchase of Burrel trail camera! Trail camera is useful for animal
surveillance and security purposes. Please refer to the instructions of this manual carefully to get
most of it!
Compact trail camera is easily transportable! Built-in passive infrared sensor detects the moving
objects and camera captures image or video. Wireless trail camera works via mobile network and
delivers thumbnail pictures to email or mobile.
Burrel trail cameras support 12 x AA batteries or 6V external power source. Use of high quality AA
batteries, 6V external battery or AC adapter is recommended.
Hereby, Suomen Retkitukku Oy declares that wireless Burrel digital scouting camera Edge HD+3G
is in compliance with the essential requirements and other relevant provisions of Directice 1999/5/
EC. A copy of the DOC may be obtained through the manufacturer/importer.
Check the local legislation for camera surveillance before placing the
camera in the forest. It may also be required to use camera surveillance
signs within surveillance area. Camera is not allowed to be used for any
illegal purposes.
EN
3

PACKAGE CONTENTS
Following parts are provided with standard product packing. Check the contents before starting
use the camera.
Trail Camera
USB Cabel
Antenna
User Manual
Mounting Belt
Trail camera with built-in PIR,
camera unit and IR.
Connect trail camera to PC
using USB cabel.
External antenna for better
signal reception.
Read the User Manual carefully
before using the camera.
Mounting belt is used to mount
the camera around the tree.
EN
4
S12 HD+SMS II
User Manual
EN English
SE Sverige
NO Norsk
FI Suomi

CONSTRUCTION EN
Black IR
PIR sensor
Antenna
Microphone
Lens
Latch
5

INSTALLATION (PART 1)
Loading batteries
Open the camera’s latch and install 12 x AA size batteries.
Alternatively you may use 6V external battery or AC
adapter to plug in camera.
1.
Inserting SIM card
Open the camera’s latch and insert SIM card in the slot
on the left side of the display. SIM card with data plan is
needed in order to use wireless function. Disable PIN-
code before using the SIM card in the camera!
3.
Inserting SD card
Open the camera’s latch and insert SD card into the
memory card slot. Up to 32GB SD cards are supported. We
recommend using Class 6 or 10 SD card, not an UHS card.
2.
Attaching antenna
Attach the antenna in the top of the camera to the
antenna thread. Do not remove the black o-ring around
the thread that blocks the water from leaking inside
camera housing!
4.
●IF YOU HAVE RECEIVED THE CAMERA AS PRE-INSTALLED, MOVE TO PART 4. ATTACHING
ANTENNA AND THEN TO PAGE 9.
EN
2 alternative ways for wireless function setup are presented on the
next pages. You may choose between them (2A or 2B)
6

INSTALLATION (PART 2A)
7
Go to Sensegram online
Adding a new camera
Go to sensegram.com/burrel
After creating an account and signing in, choose DEVICES and
after that “Add a new camera”. You can now add your new
Burrel camera to the service.
1.
3.
Quick wireless setup on Sensegram, starting from 4,90€/month
Creating a new account
Making the settings
Fill in the required information setting up a new account. You
may use the coupon if one was delivered in the camera packing.
Sensegram Wizard will guide you through the settings by
following the steps. Finally download the setup le on your
computer and transfer it to the camera’s SD card using USB
cable or SD card reader. Finally update the camera wireless
settings in the camera MENU Wireless -> Update Para.
2.
4.
EN

INSTALLATION (PART 2B)
Go to Burrel Online Tool
Testing the sending function
Go to burrelhunting.com/setup
Turn camera switch to SETUP. Wait until the camera shows
signal strength and operator name. Press OK and camera
captures picture manually. Conrm manual sending and
camera will send the picture. If an error occurs during the
sending, please go through the wireless settings again.
1.
3.
Wireless setup with Burrel Online Tool (alternative for Sensegram)
Making the settings
Online tool will guide you through the settings step by step.
Finally download the setup le and transfer it to the camera’s
SD card using USB cable or SD card reader. After this, turn
camera switch to SETUP and press Menu to get to settings. Go
to Wireless -> Update Para.
2.
NOTICE!
Using Burrel online setup tool requires email account for sending pictures.
Check the email settings (server, port) from your email provider!
EN
8

INSTALLATION (PART 3)
9
Placing the camera
Directing the camera
Place the camera in open area. Moving brushes or other
objects in front of the camera may cause false triggers. Avoid
placing the camera towards direct sunlight. Optimal distance
from the object is 5-10m.
When mounting the camera on a tree with mounting belt, it
is rotated slightly downwards. Directing the camera plays an
important role for PIR functionality and illumination of nigh-
time images. Use some time to nd the most optimal position
for your camera!
1.
3.
Camera can be mounted on a tree or wall
Mounting the camera
Camera is now ready for use!
Camera unit can be mounted on a tree with mounting belt
included in the package. Choose the optimal height for the
camera based on the object you are about to monitor: 0,8-1,5
meters. Special tree mounts and wall mounts are available as
accessories.
You may now turn the camera switch ON. The green indicatord
LED blinks few times and the camera is now ready for
surveillance.
2.
4.
EN

SETTINGS MENU
Camera comes with default settings that are suitable for most of the users. You can still change the
settings from camera settings menu, such as image resolution or PIR sensitivity.
Turn camera switch to SETUP. When camera is powered ON, press MENU-button. Move between
dierent settings by pressing arrow buttons “UP” or “DOWN”. Change the setting by pressing “LEFT”
or “RIGHT” and conrm by pressing OK. You can access to submenus by pressing OK. There you
can change the settings with arrow buttons and confrim by pressing OK. Get back to start screen
by pressing Menu.
Camera Settings
●Camera settings are presented in the rst row with camera icon. Here you can
change all the settings related to images and videos.
Setting Description
Mode Photo, Video or Photo + Video.
Photo Size 3MP, 5MP, 8MP or 12MP.
Photo Burst Set the number of images taken for each trigger (1-3). The camera
will transmit the rst photo.
Video Size Choose video size QVGA, WVGA, 720p or 1080p.
Video Length Choose length of the video clip 1-30s.
Sound Turn Video sound On or O.
EN
10

PIR Settings
●PIR settings are presented in the second row with clock icon. Here you can change
all the settings related to PIR and Timer.
Setting Description
Sensitivity
O (time lapse only, not triggered)
Low (temperature below -12°C)
Normal (temperature -12°C – +27°C)
High (temperature > +27°C)
Trigger Interval Time between when a photo is sent and the next photo can be trig-
gered. 1 min trigger interval is recommended!
Time Lapse The camera will take pictures at specied intervals. Camera will also
use PIR unless the Sensitivity is turned O.
Start-Stop 1/2
The camera can be set to operate only during specic time periods.
Select ON, then press OK to access the submenu. It is possible to
use 2 dierent timers. Make sure the times do not overlap.
Work Day
The camera can be set to operate only on selectet working days us-
ing the week calendar. Press OK in order to move to the submenu.
Go through the week day using Up or Down button. Change the
value pressing Left or Right button.
SETTINGS MENU EN
11

SETTINGS MENU
System Settings
●System settings are presented in the third row with settings icon. Here you can
change all the settings related to camera system such as time, time stamp and
menu language.
Setting Description
Clock Set the date and time.
Time Stamp Select if Time Stamp is shown in the pictures.
Format Format the SD card. This will erase all the data on the SD card.
Overwrite Select if the camera deletes the oldest photo/video to write the
newest when SD card is full.
Default Restore all settings to factory default values.
Information Show hardware and software versions.
Password Set a 6-digit password.
Language Select the camera language.
Beep Select if the camera sounds are O or ON.
LED Indicator Turn LED indicator located in the front of the camera O or ON.
FW Update Updates the FW from a le from SD card.
EN
12

Wireless Settings
●Wireless settings are presented in the last row with signal icon. Here you can
change all the settings related to wireless function. We reccommend making the
wireless settings with the tools presented earlier in this manual.
Setting Description
Send Mode
Choose the sending mode:
Instant = pictures are sent immediately (recommended)
Daily report = sends report daily of captured photos/videos
O = sending mode turned o
Send Via Choose if the pictures are sent to e-mail (internet) or phone (MMS).
Send To Choose where pictures will be delivered:
Email, Phone or Both
SMS Control Turn SMS Control O or On. If SMS Control is turned On, make sure
to ll in your phone number in the settings.
Update Para
After you have transferred the wireless settings le on SD card,
choose Update Para and press OK. Camera will now update the
new settings for SD card.
Phone Set receiving phone number.
Email Set receiving email address.
Setup Tool Download the wireless setup tool on your SD card. You can open
the tool using a PC.
Image Quality Choose the size for sent picture: VGA, 1.3M or Original.
Image From You can name the camera that will show in email title. No special
characters allowed (å,ä,ö,.-+,)
SETTINGS MENU EN
13

SMS CONTROL
14
Function Message Example
Add phone number *100#phonenumber# *100#0401234567#
Delete phone number *101#phonenumber# *101#0401234567#
Add email *110#emailaddress# *110#[email protected]#
Delete email *111#emailaddress# *111#[email protected]#
Send Via *120#sendvia# *120#0# //MMS
*120#1# //Internet
EN
NOTICE!
Using SMS Control will increase the camera power consumption quite
remarkably and use of external power source is reccommended.
Your network provider may charge for each SMS command message sent
to the camera. Check the pricing from your provider.
Turn SMS Control ON from camera settings menu: Wireless -> SMS Control.
1.
Android and iOS:
When camera is at ON mode, you can send following SMS messages to camera:
3.
Add phone number of the phone that is used for SMS Control: Wireless -> Phone.
2.

SMS CONTROL EN
Function Message Example
Send To *130#sendto#
*130#0# //Phone
*130#1# //Email
*130#2# //Both
Send Mode *140#sendmode#
*140#0# //Instant
*140#1# //Daily report
*140#2# //O
SMS Control *170# SMS Control O
Max. no of sent pic-
tures per 24h *180#
*180#0# //no limit
*180#100# //limit 100
*180# //reset the counter
Mode *200#mode#
*200#0# //Photo
*200#1# //Video
*200#2# //Photo+Video
PIR Sensitivity *202#sensitivity#
*202#0# //High
*202#1# //Normal
*202#2# //Low
*202#3# //O
Ask for a photo or
video *500# The camera captures and
sends a photo or video clip
Camera Status *160# signal/batteries/SD card
Image Quality (sent
pictures) *190#
*190#0# // 640x480px
*190#1# //1280x960px
*190#2# //original
Format SD card *204# Erases the data on SD card
Set time and date
*205#YYYYMMDDHHMMSS#
YYYY=year, MM=month,
HH=hours, MM=minutes, SS=sec-
onds
PIR Work Day
*206#???????#
?=0 surveillance O, ?=1 sur-
veillance On. Days from Mon-
day-Sunday.
*206#1001001# means,
camera surveillance on during
Mondays, Thursdays and Sun-
days.
15

EN
TECHNICAL SPECIFICATIONS
Camera
Resolution 12MP/8MP/5MP/3MP
Video resolution WVGA (800*480@30FPS) / QVGA (320*240@30FPS) / 720p @30fps / 1080p
@30fps
FOV 58°
Photo Burst 1-10 photos
Video length 1-30s
PIR
Trigger Time 0.6s
Sensitivity Adjustable
Trigger Interval 0-60min
Time Lapse Yes
General
Size 153x124x90mm
Weight 363g
Temperature -20 – +60°C
Waterproof IP54
Display 2.0” LCD
Memory Max. 32GB SD
Power Source 12AA / 6V external
Power Consump-
tion
< 0.12 mA
EN
16

17

JOHDANTO
Vaatimustenmukaisuus
VAROITUS
Onnittelut Burrel -riistakameran hankinnasta. Riistakamera on hyödyllinen apuväline niin riistan
kuvaamiseen kuin valvontaan. Tutustu tähän ohjeeseen huolellisesti ennen kameran käyttöä.
Pienikokoinen paristoilla tai ulkoisella virralla toimiva kamera on kätevästi siirrettävissä paikasta
toiseen. Kamerassa on sisäänrakennettu liiketunnistin, joka reagoi ympäristön lämpövaihteluihin ja
kamera ottaa kuvan tai videon liikkeen havaittuaan. Lähettävät riistakamerat vaativat lisäksi SIM-
kortin mobiilidatayhteydellä, jolloin kamera voi lähettää kuvia sähköpostiin tai matkapuhelimeen.
Burrel -riistakamera toimii 12 x AA paristoilla tai vaihtoehtoisesti 6V ulkoisella virtalähteellä.
Suosittelemme käyttämään talviaikaan laadukkaita litium AA-paristoja, 6V ulkoista akkua tai
verkkovirtalähdettä parhaan toimintavarmuuden takaamiseksi.
Hereby, Suomen Retkitukku Oy declares that wireless Burrel digital scouting camera Edge HD+3G
is in compliance with the essential requirements and other relevant provisions of Directice 1999/5/
EC. A copy of the DOC may be obtained through the manufacturer/importer.
18
Tarkista paikallinen lainsäädäntö kameravalvontaan ennen riistakameran
asettamista maastoon. Käyttö voi vaatia luvan maanomistajalta tai valtiolta.
Kameravalvonnasta tylee myös ilmoittaa esimerkiksi valvontakyltillä.
Kamera ei saa asettaa kuvaamaan julkisia paikkoja tai naapurin kiinteistöä.
FI

PAKKAUKSEN SISÄLTÖ
Riistakameran pakkaukseen sisältyvät seuraavat tarvikkeet. Tarkista sisältö ennen käyttöönottoa.
●Jos huomaat kamerapakkauksen sisällössä puutteita, ota yhteys jälleenmyyjääsi.
Riistakamera
USB-kaapeli
Antenni
Käyttöohje
Kiinnitysremmi
Riistakamerayksikössä on
integroitu liiketunnistin,
kamera ja mustasalama.
Voit selailla kameran ottamia
kuvia kytkemällä sen USB-
kaapelilla tietokoneeseen.
Erillinen tehoantenni parantaa
signaalin voimakkuutta.
Tutustu käyttöohjeeseen ennen
laitteen käyttöönottoa.
Kiinnitysremmin avulla kamera
voidaan kiinnittää helposti
puun ympärille.
19
FI
S12 HD+SMS II
User Manual
EN English
SE Sverige
NO Norsk
FI Suomi

KAMERAN RAKENNE
20
Mustasalama
Liiketunnistin
Antenni
FI
Mikrofoni
Kameran linssi
Lukitussalpa
