Bush BCR35DABRED User manual

BCR35DAB
Introduction
Thank you for buying this BUSH product, which is designed to give you many years of
trouble-free service.
You may already be familiar with using a similar unit, but please take time to read these
instructions. They are designed to familiarise you with the unit's many features and to
ensure you get the very best from your purchase.
Safety is important
Your safety and the safety of others is important.
Please therefore, ensure you read the "Safety Instructions" before you operate this unit.
Warranty
In the unlikely event that your product fails to work normally, please call the below free
phone number to discuss the problem with one of our qualified service engineers
Bush Warranty: 1300 055 518
- 2 -

BCR35DAB
- 3 -
Safety Instructions
Ensure that you read all of the safety instructions before using this unit.
Safety Considerations
Position the power cable and other connected cables so that they are not likely to
be walked on, pinched or where items can be placed on or against them.
Do not use the unit in humid or damp conditions.
Do not allow the unit to get wet.
Never allow children to insert foreign objects into holes or slots on the unit.
The ventilation should not be impeded by covering the openings with items such as
newspapers, tablecloths, curtains, etc. This may cause overheating.
No naked flame sources, such as lit candles, should be placed on the unit.
Do not expose the unit to dripping or splashing, and no objects filled with liquids,
such as vases, should be placed on the apparatus.
Do not place the unit in closed bookcases or racks without proper ventilation.
Cleaning
Disconnect the unit from the mains supply before cleaning.
Do not use any liquids or aerosol cleaners, as this may damage the unit. Use a soft,
dust free cloth.
Servicing
There are no user serviceable parts in the unit. When servicing, refer to qualified
service personnel.
Consult your dealer if you are ever in doubt about the installation / operation / safety
of the product.

BCR35DAB
- 4 -
CONTENTS
Introduction ...................................................................................2
Safety Instructions ........................................................................3
Contents... ....................................................................................4
Location Controls .........................................................................5
Preparation For Use .....................................................................6
Main Operation..............................................................................6
DAB+ Operation......................................................................7 - 11
FM Operation........................................................................12 - 13
Auxiliary Input ..............................................................................14
System Setting ............................................................................15
Factory Reset ..............................................................................15
Alarm Time Setting ......................................................................16
Snooze Function .........................................................................16
Backlight Dimmer.........................................................................17
Sleep Function ............................................................................17
...................................17
.....................................................................................18
Troubleshooting / Technical Specification
Warning .

BCR35DAB
- 5 -
Location Controls
FRONT VIEW
1. DISPLAY
2. SPEAKER
3. INFO
4. PRESET
5. SCAN
6. ALARMS
7. MODE
8. POWER ON/OFF
9. VOL-
10. < BUTTON
11. VOL+
12. > BUTTON
13. MENU
14. SELECT
15. SNOOZE
16. DC POWER
INPUT
17. AUXILIARY INPUT
18. HEADPHONE OUT
19. DC 5V OUT
20. ANTENNA
TOP VIEW
BACK VIEW
17 18 2016 19
1 2
3456
7
8
9
10
11
12
13
14
15

BCR35DAB
- 6 -
Power Source
This unit is supplied with an AC adaptor; follow these steps to connect the Power Source.
1. Unwind the power cord of the AC adaptor to its full length.
2. Connect the small end of the AC adaptor to the DC socket
on the left side of the unit.
3. Then plug the AC adaptor into the AC outlet (AC100-240V~,
50/60 Hz). Connecting this system to any other power source
may cause damage to the system. For sufficient ventilation,
keep other objects at least 10cm away from the unit.
4. To switch the unit off completely, turn the power off at the
wall outlet and unplug the ac adaptor.
Preparation For Use
Switching On
Press the " " button to power on the unit.
Press the " " button again to switch to standby mode.
Adjusting the Volume
1. To increase the volume, press the VOL+ button.
2. To decrease the volume, press the VOL- button.
Adjusting the Antenna
The antenna should be extended to ensure good reception in both FM and DAB+ modes.
It may be necessary to alter the position of the unit and/or antenna to achieve the best
signal.
Using for Main Operation
AC Adaptor
AC Outlet
DON'T FORGET!
1. Do not touch the AC adaptor with wet hands.
2. Once connected to the power supply, the unit will switch directly to DAB+ mode.
3. Please disconnect the AC adaptor from the power supply if the appliance is not
going to be used for a long period time.
DON'T FORGET!
Make sure the antenna is at full length for good reception.

BCR35DAB
- 7 -
DAB+ Operation
Listening to DAB+ Radio
1. Press the " " button to turn the unit on.
2. Press the MODE button to select the DAB mode.
3. Press the SCAN button, the following screen will be displayed. A bar graph indicating
the progress of the DAB+ station search. The number of stations found increases as
the scan progresses.
DAB
Progress bar
Number of stations found
DON'T FORGET!
To improve reception, try adjusting the position of the antenna.
Changing DAB+ Stations
1. Press the " <" & " >" buttons to scroll through the stations in the station list.
3. The radio will tune to the new station.
DON'T FORGET!
If no new station is selected the unit will display the currently playing station after
5 seconds.
From time to time new DAB+ stations may be added to the DAB+ station list. If
you wish to see if any new stations have been added, press the SCAN button to
activate a full scan.
Storing DAB+ Presets
1. You can preset up to 10 DAB+ stations for easy access as follows:
2. Press the " <" & " >" buttons to scroll through the stations in the station list.
3. Press the SELECT button to confirm to the station you wish to preset.
4. Press and hold the PRESET button, preset position 1 will show in the display.
5. Press the " <" & " >" buttons to select the required preset memory position.
6. Press the SELECT button to confirm.
7. Repeat steps 2-6 to store more preset stations.
DAB Mode display
Volume bar

BCR35DAB
- 8 -
DAB+ Operation
Selecting a Preset Station
1. Press the PRESET button briefly, preset position 1 will show in the display.
2. Use " <" & " >" buttons to select the desired preset and press the SELECT button
to confirm.
DON'T FORGET!
If you select a preset location that has not been programmed with a station,
"Not set" will be displayed. The unit will return to the previously selected station
after a few seconds.
Changing the DAB+ Station Information
It is possible to change the information displayed on
the second line of the display when listening to a
DAB+ station. There are seven types of information
available as listed below with examples to the right.
1. Dynamic Label Segment (DLS) This is scrolling
text information supplied by the DAB+ station.
It may comprise information on music titles or details
of the programme and is provided by the broadcaster.
2. Signal Bar Shows the transmission signal level.
3. Program Type (PTY) This is a description of the
type of programme provided by the DAB+ station
and is provided by the broadcaster.
4. Multiplex Name This will show the multiplex that
is broadcasting the programme you are listening.
5. Time/ Date This displays the time and date provided
by the broadcaster.
6. Channel and Frequency This displays the channel
number and the transmission frequency.
7. Signal Information This shows the digital bit-rate
and the signal mode.
DAB
AM
12
DAB
AM
12
DAB
AM
12
DAB
AM
12
DAB
AM
12
DAB
AM
12
DAB
AM
12
Press INFO button
Press INFO button
Press INFO button
Press INFO button
Press INFO button
Press INFO button
Press INFO button
2013
01
01

BCR35DAB
- 9 -
Using the MENU Control (DAB+ mode)
The MENU control allows you to change some of the system options on your unit.
These options are arranged in a menu structure as shown below.
DAB+ Operation
DAB
AM
12
DAB
DAB
AM
12
AM
12
Press MENU buttons
DAB
AM
12
DAB
DAB
AM
12
AM
12
DAB
DAB
AM
12
AM
12
DAB
AM
12
Press the button
to cloose radio frequency,
Press SELECT button to confirm.
" <" & " >"
Press the button
to cloose DRC off / high / low,
Press SELECT button to confirm.
" <" & " >"
Press the button
to cloose Prune No / Yes,
Press SELECT button to confirm.
" <" & " >"
Press SELECT button
Press SELECT button
Press SELECT button
Press SELECT button
Press buttons" <"&" >"
Press buttons" <"&" >"
Press buttons" <"&" >"
Press buttons" <"&" >"

BCR35DAB
- 10 -
DAB+ Operation
Using the Menu
Press the MENU button to enter the menu. Press the " <" & " >" buttons to scroll
through the options described below.
Full Scan
1. Press the MENU button to access the menu.
2. Press the " <"&" >" buttons until "Full scan" is displayed.
3. Press the SELECT button to activate a full scan for DAB+ stations.
Manual Tune
It is possible to manually tune to a specific channel/frequency and add this to the station
list. This function can be used to obtain the optimum reception for a specific channel/
frequency.
1. Press the MENU button to access the menu.
2. Press the " <" & " >" buttons until "Manual tune" is displayed. Press the SELECT
button to select.
3. Press the " <" & " >" buttons to select the desired channel/frequency.
4. Press the SELECT button, a rectangle will be displayed on the second line of the
display. The position of this rectangle indicates the signal strength (the further towards
the right, the greater the signal strength).
5. Adjust the position of the wire antenna to obtain the optimum signal strength.
6. Press the SELECT button to confirm.
AM
1
DAB
