Bushnell 06-1729/03-01 User manual

Congratulations on the purchase of your Bushnell Night
Vision Product. Bushnell Night Vision products are comprised
of high quality image intensifier tubes and optics. Bushnell
Night Vision products amplify existing light, allowing you to
see in dark conditions too dark for the naked eye.
HOW NIGHT VISION WORKS
Bushnell Night Vision products collect and amplify existing light through the
objective lens, which is then focused on the image intensifier. Inside the
intensifier, a photocathode is "excited" by the light and converts the photon
energy into electrons. These electrons accelerate across an electrostatic field
inside the intensifier and strike a phosphor screen (like a green monochrome
TV screen) which emits an image that you can see. It is the acceleration of
electrons, which provides gain and enhances the image. This particular
product is a Generation I device.
GETTING STARTED
Installing Batteries
• Open the Battery Compartment Cover.
•Connect a 9V battery to the connector and place it inside the compartment.
• Close the Battery Compartment Cover.
Using The Power Button
•Never turn the scope on in daylight conditions with the lens cap off. The
pinhole in the lens cap allows you to test the scope in daylight conditions.
• To use the scope, depress and hold the Power Button located near
the eyepiece.
•After you release the Power Button, the image will slowly fade out. This is
normal and is not a defect.
To Focus
• First, remove the Lens Cap.
•Adjust the Objective Lens Focusing Ring to infinity.
•While looking at a distant object (at least 36 ft. away), adjust the Eyepiece
Focusing Ring for the sharpest image.
•Once the Eyepiece Focusing Ring is adjusted, you need only adjust the
Objective Lens Focusing Ring as needed.
To Activate The IR Illuminator
• Your Bushnell Night Vision Product includes a built-in infrared illuminator. This
allows you to see in complete darkness when no ambient light source is
available.
•Pressing the momentary power button also activates the infrared illuminator.
TROUBLESHOOTING
Spots in the Image.
You may see spots in the image. These vary from scope to scope and are
cosmetic blemishes inside the scope. These are normal for Night Vision scopes
and are not a defect.
Scope will not turn on.
Check that the batteries are installed properly. Replace the batteries with new
ones. Check the battery contacts to ensure they are clean and free of corrosion.
Press and hold the power button firmly and completely.
Image is not focused.
Adjust the focus on the Focusing Eyepiece. Adjust the Objective Lens Focusing
Ring. You must be at least 1 ft. (30.5 cm) from the subject you are viewing.
If still no improvement, clean the lenses; they may be foggy or dusty.
(See To Focus).
Image is very faint or dim.
Replace the battery in the Illuminator with a new one.
Visibility decreases or disappears.
Bright light sources such as headlights may cause visibility to degrade or
disappear completely. Release the Power Button and turn the scope away
from the light source. The unit will restore itself in 1 or 2 minutes. Conditions
such as fog or extremely dark environments will decrease visibility.
Scope flashes.
The scope may flash when used in a bright environment. It may also flash
during the first few seconds of use in dark environments.
CARE & MAINTENANCE
•When not using for an extended amount of time, remove batteries and store
the product in a dry location.
• Avoid turning the product on in extremely bright light conditions.
•Handle this product like you would a camera. Though Bushnell Night
Vision products are durably constructed, the image intensifier tube consists of
glass and is subject to breakage.
• Keep the optics clean. We recommend using a camera cleaner kit to
clean the outside of the objective and eyepiece lenses. Follow the
directions with the kit.
•Do not disassemble this product. Unauthorized disassembly not only voids
the warranty but may also cause damage from the lack of special tools
and techniques.
WARRANTY / REPAIR
TWO-YEAR LIMITED WARRANTY
Your Bushnell®product is warranted to be free of defects in materials and workmanship
for two years after the date of purchase. In the event of a defect under this warranty, we
will, at our option, repair or replace the product, provided that you return the product
postage prepaid. This warranty does not cover damages caused by misuse, improper
handling, installation, or maintenance provided by someone other than a Bushnell
Authorized Service Department.
Any return made under this warranty must be accompanied by the items listed below:
1) A check/money order in the amount of $10.00 to cover the
cost of postage and handling
2) Name and address for product return
3) An explanation of the defect
4) Proof of Date Purchased
5) Product should be well packed in a sturdy outside shipping carton, to prevent
damage in transit, with return postage prepaid to the address listed below:
IN U.S.A. SEND TO: IN CANADA SEND TO:
Bushnell Performance Optics Bushnell Performance Optics
Attn.: Repairs Attn.: Repairs
8500 Marshall Drive 25A East Pearce Street, Unit 1
Lenexa, Kansas 66214 Richmond Hill, Ontario L4B 2M9
For products purchased outside the United States or Canada please contact your local
dealer for applicable warranty information. In Europe you may also contact Bushnell at:
33 141 44 94 80
Bushnell Performance Optics Germany GmbH
Morsestrasse 4
50769 - Cologne
Germany
This warranty gives you specific legal rights.
You may have other rights which vary from country to country.
©2002 Bushnell Corporation
Class 1 LED product per IEC 60825-1/nov 1993, appendix EN 60825-1A11/oct 1996
NIGHT VISION
INSTRUCTIONS
Lit. #: 06-1729/03-01
SPECIFICATIONS
Image Magnification 1.7x
Objective Size 29mm
Viewing Range 1 - 225 ft.
FOV (ft. @ 100 yds.) 121
1.7x29 Compact Monocular With
Built-In Infrared Illuminator
