BW Technologies GasAlertMicro 5 IR User manual

Quick Reference Guide
GasAlertMicro 5 IR
O2, CO, H2S, PH3, SO2, Cl2, NH3, NO2, HCN, ClO2, O3, VOC, CO2and Combustibles
1, 2, 3, 4, and 5 Gas Detectors
D6041/1 [English]
iERP: 124970
© 2007 BW Technologies, all rights reserved. Printed in Canada.
All product names are trademarks of their respective companies.
Non Printing line
11.500"
4.000"

Limited Warranty & Limitation of Liability
BW Technologies LP (BW) warrants this product to be free from defects in material and workmanship under normal use and service for a
period of two years, beginning on the date of shipment to the buyer. This warranty extends only to the sale of new and unused products to
the original buyer. BW’s warranty obligation is limited, at BW’s option, to refund of the purchase price, repair, or replacement of a defective
product that is returned to a BW authorized service center within the warranty period. In no event shall BW’s liability hereunder exceed the
purchase price actually paid by the buyer for the Product. This warranty does not include:
a) fuses, disposable batteries or the routine replacement of parts due to the normal wear and tear of the product arising from
use;
b) any product which in BW’s opinion, has been misused, altered, neglected or damaged by accident or abnormal conditions of
operation, handling or use;
c) any damage or defects attributable to repair of the product by any person other than an authorized dealer, or the installation
of unapproved parts on the product; or
The obligations set forth in this warranty are conditional on:
a) proper storage, installation, calibration, use, maintenance and compliance with the product manual instructions and any other
applicable recommendations of BW;
b) the buyer promptly notifying BW of any defect and, if required, promptly making the product available for correction. No
goods shall be returned to BW until receipt by the buyer of shipping instructions from BW; and
c) the right of BW to require that the buyer provide proof of purchase such as the original invoice, bill of sale or packing slip to
establish that the product is within the warranty period.
THE BUYER AGREES THAT THIS WARRANTY IS THE BUYER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. BW SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, WHETHER ARISING FROM BREACH OF WARRANTY OR
BASED ON CONTRACT, TORT OR RELIANCE OR ANY OTHER THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or limitation of incidental or
consequential damages, the limitations and exclusions of this warranty may not apply to every buyer. If any provision of this warranty is
held invalid or unenforceable by a court of competent jurisdiction, such holding will not affect the validity or enforceability of any other
provision.
Contacting BW Technologies by Honeywell
USA: 1-888-749-8878 Canada: 1-800-663-4164
Europe: +44 (0) 1295 700300 Other countries: +1-403-248-9226
Visit BW Technologies by Honeywell’s website at: www.gasmonitors.com

1
GasAlertMicro 5 IR
Introduction
The quick reference guide provides basic information to
operate the GasAlertMicro 5 IR gas detector. For complete
operating instructions, refer to the GasAlertMicro 5/PID/IR User
Manual provided on CD-ROM. The GasAlertMicro 5 IR detector
(“the detector”) is designed to warn of hazardous gas levels
above user-selectable alarm setpoints.
The detector is a personal safety device. It is your responsibility
to respond properly to the alarm.
Note
The detector is shipped with English as the default
displayed language. Additional languages provided are
Portuguese, Spanish, German, and French. The screens
for the additional languages are displayed on the
detector and in the corresponding Quick Reference
Guides.
Safety Information - Read First
Use the detector only as specified in this guide and the user
manual, otherwise the protection provided by the detector
may be impaired. Read the following Cautions before using
the detector.
aCautions
⇒Warning: Substitution of components may impair
Intrinsic Safety.
⇒Caution: For safety reasons, this equipment must
be operated and serviced by qualified personnel
only. Read and understand the user manual
completely before operating or servicing.
⇒Calibrate the detector before first-time use and
then on a regular schedule, depending on use and
sensor exposure to poisons and contaminants.
BW recommends at least once every 180 days (6
months).

GasAlertMicro 5 IR
Quick Reference Guide
2
⇒It is recommended that the combustible sensor be
checked with a known concentration of calibration
gas after any known exposure to contaminants or
poisons (sulfur compounds, silicon vapors,
halogenated compounds, etc.).
⇒BW recommends to “bump test” the sensors
before each day’s use to confirm their ability to
respond to gas by exposing the detector to a gas
concentration that exceeds the alarm setpoints.
Manually verify that the audible and visual alarms
are activated. Calibrate if the readings are not
within the specified limits.
⇒Only the combustible gas detection portion of this
instrument has been assessed for performance by
CSA International.
⇒The combustible sensor is factory calibrated to
50% LEL methane. If monitoring a different
combustible gas in the % LEL range, calibrate the
sensor using the appropriate gas.
⇒Caution: High off-scale readings may indicate an
explosive concentration.
⇒Protect the combustible sensor from exposure to
lead compounds, silicones, and chlorinated
hydrocarbons. Although certain organic vapors
(such as leaded gasoline and halogenated
hydrocarbons) may temporarily inhibit sensor
performance, in most cases the sensor will
recover after calibration.
⇒For use only in potentially explosive atmospheres
where oxygen concentrations do not exceed
20.9% (v/v).
⇒Any rapid up-scaling reading followed by a
declining or erratic reading may indicate a gas
concentration beyond upper scale limit, which can
be hazardous.
⇒Extended exposure of the GasAlertMicro 5 IR to
certain concentrations of combustible gases and
air may stress the detector element that can
seriously affect its performance. If an alarm
occurs due to a high concentration of combustible
gases, recalibration should be performed, or if
needed, the sensor replaced.
⇒The BW pump module (M5-PUMP) is certified for
use with the GasAlertMicro 5, GasAlertMicro 5
PID, and GasAlertMicro 5 IR models only.
⇒When calibrating O3and ClO2sensors that are
located in the Toxic 2 position of the detector, a
single gas calibration cap must be used to ensure
accurate calibration.
⇒Use only the GasAlertMicro 5 IR battery pack with
the GasAlertMicro 5 IR detector. The IR battery pack
is not compatible with other GasAlertMicro 5/PID
products and vice versa.
⇒Replace the CO2sensor only in a safe area that is
free of hazardous gas.

GasAlertMicro 5 IR
Parts of the GasAlertMicro 5 IR
Parts of the GasAlertMicro 5 IR
Item Description
1 Visual alarm bars (LEDs)
2 Toxic 1/IR (CO2) sensor
3 Toxic 2 sensor
4 LEL sensor
5 Audible alarms
6 Oxygen sensor
7 Pushbuttons
8 Liquid crystal display (LCD)
9 Battery pack
10 Alligator clip
3

GasAlertMicro 5 IR
Quick Reference Guide
Display Elements
Item Description
1 Alarm condition
2 Automatically span sensor
3 Gas cylinder
4 Gas identifier bars
5 Battery life indicator
6 Pass code lock
7 Data transmission
8 Clock
9 Stealth mode
10 Optional pump indicator
11 Optional datalogger card indicator
12
Alarm condition (low, high, TWA, STEL, or
multi-gas) or view TWA, STEL, and
maximum gas exposures (MAX)
13 Automatically zero sensor
4

GasAlertMicro 5 IR
Pushbuttons
5
Pushbuttons
Pushbutton Description
A
•To activate the detector press A.
•To deactivate the detector, press and hold Auntil the countdown is complete.
G
•To increment the displayed value or scroll up, press G.
•To enter the user options menu, press Gand Hsimultaneously and hold until the countdown
is complete.
•To clear the TWA, STEL, and maximum (MAX) gas exposure readings, press Cand G
simultaneously and hold until the countdown is complete.
•To view the date and time, alarm setpoints (TWA, STEL, low, and high) of all the sensors, and
the LEL correction factor (if applicable), press G.
H
•To decrement the displayed value or scroll down, press H.
•To initiate calibration and setting alarm setpoints, press Cand Hsimultaneously and hold
until the countdown is complete.
C
•To view the TWA, STEL, and maximum (MAX) hold readings, press C.
•To acknowledge latched alarms press C.

GasAlertMicro 5 IR
Quick Reference Guide
Calibration
Procedure Display Procedure Display
Calibrate only in a safe area that is free of
hazardous gas.
1. Activate the detector. To enter
calibration, press and hold Cand H
simultaneously. The detector beeps
and flashes to the corresponding
countdown. The detector then displays
Starting calibration.
4. The following three screens display:
- Apply span gas now to calibrate
- or press Cto select sensor(s)
- or press Ato skip calibration
If none of the buttons are pressed,
proceed to step #6. If Cis pressed,
proceed to step #5. If Ais pressed,
proceed to the end of step #7.
2. flashes while the detector
zeroes all of the sensors (except CO2)
and calibrates the oxygen sensor. If a
sensor fails to auto zero, it will bypass
the span.
5. Select which sensor to span. Press G
and Hto scroll to the required sensor
and then press Cto select. Sensors
must be spanned in the following order:
Exotics (NH3, ClO2, O3, Cl2, and CO2),
Single gas, Quad gas (H2S, CO, O2, and
LEL).
3. The Zero CO2?screen displays. Press
C to zero the CO2sensor or press A
to bypass.
If Cis pressed to zero the CO2
sensor, the following screens display:
- Apply CO2zero gas now (nitrogen
must be used to zero the CO2sensor).
- The Auto-Zero CO2screen displays
and flashes.
6. Attach the calibration cap and apply gas
at a flow rate of 500 ml/min.
Kflashes while the detector determines
which gas is being applied.
After 30 seconds, flashes and
a countdown displays while the detector
completes the span.
6

GasAlertMicro 5 IR
Attach the Gas Cylinder to the Detector
7
Procedure Display
7. When the span is complete, the following
three screens display:
- Calibration successful
- Press Gto apply a new cal gas
- Press Hto end span
Repeat steps #4-7 to calibrate the
remaining sensors.
The LCD displays the following options:
Press Cto set or press Ato bypass the
calibration due dates.
8. Press Hor Gto change the calibration
due date. Press Cto accept the value
and proceed to the next due date. If a
sensor failed or did not span, the
calibration due date cannot be changed
for that sensor.
The LCD displays the following options:
Press Cto set or press Ato bypass the
alarm setpoints.
9. Press Hor Gto change the alarm
setpoint. Press Cto save the value and
proceed to the next setpoint.
Set the remaining setpoints. The
detector beeps twice when all of the
alarm setpoints have been set or
bypassed.
Procedure Display
10. When calibration is complete, Saving
calibration displays.
Note
Only use the calibration cap and single
gas calibration cap during the calibration
process.
Attach the Gas Cylinder to the Detector
If an O3or ClO2sensor is located in the Toxic 2 sensor
position, a single gas calibration cap must be used. For
complete information and procedures, refer to the
GasAlertMicro 5/PID/IR User Manual.

GasAlertMicro 5 IR
Quick Reference Guide
Alarms
Refer to the following table for information about alarms and corresponding screens.
Alarm Display Alarm Display
Low Alarm:
•Fast beep
•Slow flash
•Land target gas bar flash
•Vibrator alarm activates
TWA Alarm:
•Fast beep
•Slow flash
•Land target gas bar flash
•Vibrator alarm activates
High Alarm:
•Constant beep
•Fast flash
•Land target gas bar flash
•Vibrator alarm activates
STEL Alarm:
•Constant beep
•Fast flash
•Land target gas bar flash
•Vibrator alarm activates
8

GasAlertMicro 5 IR
Alarms
9
Alarm Display Alarm Display
Multi-Gas Alarm:
•Alternating low and high alarm
beep and flash
•Land target gas bars flash
•Vibrator alarm activates
Over Limit (OL) Exposure Alarm:
•Fast beep and flash
•Land target gas bar flash
•Vibrator alarm activates
Sensor Alarm:
•One beep every 15 seconds
•FAIL flashes above the failed
sensor
Automatic Shutdown Alarm:
•Eight beeps and flashes
•Vibrator alarm temporarily
activates
Low Battery Alarm:
•One beep and two flashes every
25 seconds
•flashes
Normal Shutdown:
•Three beeps and flashes

GasAlertMicro 5 IR
Quick Reference Guide
10
Alarm Display Alarm Display
Confidence Beep:
•One beep, one flash, and one
vibrate every 10 seconds
Pump Alarm:
•Screen flashes:
- Pump flow change detected
- Check for blocked inlet
- or press Cto run a pump test
•Two fast beeps and alternating
flashes
•Vibrator alarm activates
•Land Jicons flash
MMC Fail Alarm:
•One beep every 5 seconds
•Sicon flashes
Note
Alarms can be set to be latching or non-latching. To enable/disable latching, select Latch in the user options menu.
In stealth mode the backlight, audible, and visual alarms are disabled. Only the vibrator and LCD activate during an alarm
condition.

GasAlertMicro 5 IR
User Options Menu
11
User Options Menu
To access the user options menu, press and hold Gand H
until the detector completes the countdown. To scroll through
the options press Hor G. Press C to select the option. The
following are the available user options.
1. Exit: Exits the user options menu.
2. Options:
•Backlght (Backlight): Enables/disables the automatic
backlight in low-light conditions.
•Confibeep (Confidence beep): When enabled, the
confidence beep provides continuous confirmation
that the detector is operating correctly (audible beep
every 10 seconds).
•Due-lock (Calibration user lockout): If enabled, upon
start-up a passcode is required to operate a detector
that is overdue for calibration.
•Latch (Latched alarm): Enable to ensure an alarm
persists until it is acknowledged (press Cto
acknowledge).
•Passcode (Passcode protection): Enable to prevent
unauthorized personnel from accessing the user
options menu, calibration function, and alarm setpoint
adjust function.
•Safe (Safe mode): If enabled, Safe displays
continuously unless an alarm condition occurs.
•Fast pump (Maximize pump speed): Enable if the
sampling hose length is longer than 50 ft. (15.24 m).
Note
Maximizing the pump speed greatly reduces the
battery life.
3. Sensors:
•Sens on (Sensor enabled): Enables/disables a
sensor (the detector continues operating if a sensor is
disabled).
•Span gas: Set the span gas concentration for each
sensor (must match the value on the gas cylinder).
•STEL period (Short-term exposure limit): Set the
STEL period from 5 to15 minutes (applicable to toxic
sensors only).

GasAlertMicro 5 IR
Quick Reference Guide
12
•TWA method (Time-weighted average): Select either
the Occupational Safety and Health Administration
(OSHA) or American Conference of Government
Industrial Hygienists (ACGIH) method.
OSHA: 8 hour moving average
ACGIH: Infinite accumulated average to 8 hours
•Resolution: Sets the resolution of the gas
measurement as either regular or extra (if applicable).
•% vol CO2:If enabled, the detector displays the
carbon dioxide (CO2) reading as %vol.
•% vol CH4:Enable to display the LEL reading as
% vol assuming a methane (CH4) environment.
•Correction (Compensation factor): Enter
compensation factors for hydrocarbons other than
methane (only applicable to LEL sensors).
•Autocal (Automatic oxygen calibration):
Enable/disable the detector to automatically calibrate
the oxygen sensor during start-up.
4. Logger (Datalogging): Sets how often the detector
records a datalog sample (once every 1 to 127 seconds).
5. Clock: Sets the date and time for the detector.
6. Language: Displays the LCD screens in English,
French, Spanish, German, or Portuguese. The detector
is shipped displaying English as the default language.
Maintenance
To maintain the detector in good operating condition,
perform the following basic maintenance as required.
•Calibrate, bump test, and inspect the detector on a
regular schedule.
•Maintain an operations log of all maintenance, bump
tests, calibrations, and alarm events.
•Clean the exterior with a soft damp cloth. Do not use
solvents, soaps, or polishes.
•Do not immerse the detector in liquids.

GasAlertMicro 5 IR
Maintenance
Replacing the Batteries
aWarning: Use only the GasAlertMicro 5 IR battery pack with the GasAlertMicro 5 IR detector (not compatible with
other Micro 5/PID models and vice versa). Refer to the warning label located on the battery pack lid.
aWarning: Always deactivate the detector before removing the battery pack.
The battery packs are user-changeable in hazardous areas, but the alkaline batteries inside the pack must be changed
in a safe area that is free of hazardous gas.
1. Open the latch on the bottom of the detector and remove the battery pack by lifting the bottom end of the pack upwards.
2. Unscrew the two captive screws on the battery pack cover, open the pack, and replace the three alkaline batteries.
3. Replace the battery pack cover and reinsert the screws.
4. Replace the battery pack on the detector and secure the latch.
13

GasAlertMicro 5 IR
Quick Reference Guide
Replacing a Sensor or Sensor Filter
14
aCaution
Replace the CO2sensor only in a safe area that is free of
hazardous gas.
Item Description
1 Sensor cover
2 Sensor filter
3 Sensors
4 Detector
5 Machine screws (2)
Specifications
Instrument dimensions: 14.5 x 7.4 x 3.8 cm
(5.7 x 2.9 x 1.5 in.)
Weight: 370 g (13.1 oz.)
Operating and storage conditions
Temperature: -20°C to +50°C (-4°F to +122°F)
Humidity: CO2IR: 0% to 95% relative humidity (non-
condensing)
O2: 0% to 99% relative humidity (non-condensing)
Combustibles: 5% to 95% relative humidity (non-condensing)
Cl2: 10% to 95% relative humidity (non-condensing)
HCN, ClO2: 15% to 95% relative humidity (non-condensing)
Other gases: 15% to 90% relative humidity (non-condensing)
Pressure: 95 to 110 kPa

GasAlertMicro 5 IR
Specifications
15
Alarm setpoints: May vary by region and are user-settable
Detection range:
O2: 0–30.0% vol. (0.1% vol. increments)
CO: 0–999 ppm (1 ppm increments)
CO (TwinTox sensor): 0–500 ppm (1 ppm increments)
H2S: 0 – 500 ppm (1 ppm increments)
H2S (TwinTox sensor): 0–500 ppm (1 ppm increments)
Combustibles: 0–100% LEL (1% LEL increments) or
0–5.0% v/v methane
PH3: 0–5.0 ppm (0.1 ppm increments)
SO2: 0–150 ppm (1 ppm increments)
Cl2: 0–50.0 ppm (0.1 ppm increments)
NH3: 0–100 ppm (1 ppm increments)
NO2: 0–99.9 ppm (0.1 ppm increments)
HCN: 0–30.0 ppm (0.1 ppm increments)
ClO2: 0–1.00 ppm (0.01 ppm increments)
O3: 0–1.00 ppm (0.01 ppm increments)
CO2IR: 0–50,000 ppm (150 ppm increments) or
0-5.0% v/v CO2
Sensor type:
H2S/CO: Twin plug-in electrochemical cell
Combustibles: Plug-in catalytic bead
CO2: IR detector
Other gases: Single plug-in electrochemical cell
O2measuring principle: Capillary controlled concentration
sensor
Alarm conditions: TWA alarm, STEL alarm, low alarm, high
alarm, multi-gas alarm, over range alarm, sensor alarm, pump
alarm, MMC fail alarm, low battery alarm, confidence beep,
automatic shutdown alarm
Audible alarm: 95 dB at 1 ft. (0.3 m) variable pulsed dual
beepers
Visual alarm: Dual red light-emitting diodes (LED)
Display: Alphanumeric liquid crystal display (LCD)
Backlight: Automatically activates whenever there is
insufficient light to view the display (if enabled) and during
alarm conditions
Self-test: Initiated at activation
Calibration: Automatic zero and automatic span
Oxygen sensor: Automatic span on activation (selectable)
User field options: Confidence beep, latching low and high
alarms, pass code protection, enable/disable safe display
mode, enable/disable fast pump, combustible sensor
measurement, sensor disable, TWA and STEL, language
selection, enable/disable automatic oxygen calibration, set
span concentration values, set STEL calculation period, set
TWA method, gas measurement resolution, enable/disable
automatic backlight, adjust clock calendar, and set logging rate
(datalogger models only), and CO2sensor measurement.
Datalogger units: Approved for GasAlertMicro 5 IR
models: Delkin 128 MB MMC and Transcend 128 MB MMC.

GasAlertMicro 5 IR
Quick Reference Guide
16
Battery operating time
Toxic, O2, and LEL sensors: 20 hours (three alkaline cells or
one rechargeable battery pack)
Toxic, O2, LEL, and CO2sensors: 10 hours (three alkaline
cells or one rechargeable battery pack)
Year of manufacture: The detector’s year of manufacture is
determined from the serial number. The second and third
number after the first letter determines the year of manufacture.
E.g., H306-Y000001 = 2006 year of manufacture
Approved batteries for M5IR-BAT0501 and M5IR-BAT0502
Approved batteries for product (standards IEC 60079-11,
EN50020, UL913, C22.2 No. 157)
Alkaline: Temperature Code
Duracell MN1500 -20°C ≤Ta ≤50°C T3C (139.8°C)
-20°C ≤Ta ≤40°C T4 (129.8°C)
Energizer E91 -20°C ≤Ta ≤50°C T3B (163°C)
-20°C ≤Ta ≤40°C T3C (153°C)
Xellex LR6 -20°C ≤Ta ≤50°C T4 (107°C)
NiMH rechargeable:
M5IR-BAT04 -20°C ≤Ta ≤50°C T4
Battery charger: GasAlertMicro 5 battery charger
First-time charge: 4 hours per battery pack
Normal charge: 3-4 hours per battery pack
Warranty: 2 years including sensors (1 year NH3sensor)
Approvals
Approved by CSA to both U.S. and Canadian Standards
ATEX: CE 0539 gII 2 G EEx d ia IIC
KEMA 06ATEX 0206X
Approved: Class I, Division 1, Group A, B, C, and D
Standards: CAN/CSA C22.2 No. 157 and C22.2 152
ANSI/UL – 913 and ANSI/ISA – S12.13 Part 1
IECEx: Ex d ia IIC
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules and ICES-003 Canadian EMI requirements. These
limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician
for help.

Quick Reference Guide
GasAlertMicro 5 IR
O2, CO, H2S, PH3, SO2, Cl2, NH3, NO2, HCN, ClO2, O3, VOC, CO2and Combustibles
1, 2, 3, 4, and 5 Gas Detectors
D6041/1 [English]
iERP: 124970
© BW Technologies 2007, all rights reserved. Printed in Canada.
All product names are trademarks of their respective companies.
Non Printing line
11.500"
4.000"
Table of contents
Other BW Technologies Security Sensor manuals

BW Technologies
BW Technologies GasAlertMicro 3 User manual

BW Technologies
BW Technologies GasAlert MicroClip XT User manual

BW Technologies
BW Technologies GasAlert Extreme User manual

BW Technologies
BW Technologies GasAlertClip Extreme 2 Year User manual

BW Technologies
BW Technologies GasAlertMax XT II Use and care manual

BW Technologies
BW Technologies GasAlert Extreme User manual

BW Technologies
BW Technologies Quattro Use and care manual

BW Technologies
BW Technologies NH3 RESPONDER User manual

BW Technologies
BW Technologies GasAlertMax User manual

BW Technologies
BW Technologies CONNEX1 User manual
