BYOC Bass Chorus User manual

Build Your Own Clone
Bass Chorus
Kit Instructions
Warranty:
BYOC, Inc. guarantees that your kit will be complete and that all parts and components
will arrive as described, functioning and free of defect. Soldering, clipping, cutting,
stripping, or using any of the components in any way voids this guarantee. BYOC, Inc.
guarantees that the instructions for your kit will be free of any majors errors that would
cause you to permanently damage any components in your kit, but does not guarantee
that the instructions will be free of typos or minor errors. BYOC, Inc. does not warranty
the completed pedal as a whole functioning unit, nor do we warranty any of the
individual parts once they have been used. If you have a component that is used, but feel
it was defective prior to you using it, we reserve the right to determine whether or not the
component was faulty upon arrival. Please direct all warranty issues to:
[email protected] This would include any missing parts issues.
Return:
BYOC, Inc. accepts returns and exchanges on all products for any reason, as long as they
are unused. We do not accept partial kit returns. Returns and exchanges are for the full
purchase price less the cost of shipping and/or any promotional pricing. Return shipping
is the customer’s responsibility. This responsibility not only includes the cost of
shipping, but accountability of deliver as well. Please contact
[email protected] to receive a return authorization before mailing.

Tech Support:
BYOC, Inc. makes no promises or guarantees that you will successfully complete your
kit in a satisfactory manor. Nor does BYOC, Inc. promise or guarantee that you will
receive any technical support. Purchasing a product from BYOC, Inc. does not entitle
you to any amount of technical support. BYOC, Inc. does not promise or guarantee that
any technical support you may receive will be able to resolve any or all issues you may
be experiencing.
That being said, we will do our best to help you as much as we can. Our philosophy at
BYOC is that we will help you only as much as you are willing to help yourself. We
have a wonderful and friendly DIY discussion forum with an entire section devoted to the
technical support and modifications of BYOC kits.
www.byocelectronics.com/board
When posting a tech support thread on the BYOC forum, please post it in the correct
lounge, and please title your thread appropriately. If everyone titles their threads
“HELP!” then it makes it impossible for the people who are helping you to keep track of
your progress. A very brief description of your specific problem will do. It will also
make it easier to see if someone else is having or has had the same problem as you. The
question you are about to ask may already be answered. Here is a list of things that you
should include in the body of your tech support thread:
1. A detailed explanation of what the problem is. (more than, “It doesn’t work, help”)
2. Pic of the topside of your PCB.
3. Pic of the underside of your PCB.
4. Pic that clearly shows your footswitch/jack wiring and the wires going to the PCB
5. A pic that clearly shows your wiring going from the PCB to the pots and any other
switches(only if your kit has non-PC mounted pots and switches)
6. Is bypass working?
7. Does the LED come on?
8. If you answered yes to 6 and 7, what does the pedal do when it is in the "on" position?
9. Battery or adapter (if battery, is it good? If adapter, what type?)
Also, please only post photos that are in focus.
Copyrights:
All material in this document is copyrighted 2014 by BYOC, Inc.

Bass Chorus Kit Instruction Index
Parts Checklist……………………….................…....page 6
Populating the Circuit Board…….................…...…..page 8
Main PCB Assembly..................................................page 17
Wiring……………………………….........................page 19
Installing the IC/Finishing up………………….......page 25
Operation Overview...................................................page 26
Schematic....................................................................page 27

This is what your kit should look like when it’s complete. Your kit may come with
different color capacitors, switches etc. Don’t be alarmed by this. They all still do
the exact same thing.

Parts Checklist for Bass Chorus Kit
Resistors:
1 – 100R (101) (Brown/Black/Black/Black/Brown)
1 – 470R (471) (Yellow/Purple/Black/Black/Brown)
1 - 1k (102) (Brown/Black/Black/Brown/Brown)
2 – 2k7 (272) (Red/Purple/Black/Brown/Brown)
3 - 4k7 (472) (Yellow/Purple/Black/Brown/Brown)
16 - 10k (103) (Brown/Black/Black/Red/Brown)
2 – 12k (123) (Brown/Red/Black/Red/Brown)
1 – 15k (153) (Brown/Green/Black/Red/Brown)
2 – 33k (333) (Orange/Orange/Brown/Red/Brown)
4 – 47k (473) (Yellow/Purple/Black/Red/Brown)
1 – 56k (563) (Green/Blue/Black/Red/Brown)
3 - 100k (104) (Brown/Black/Black/Orange/Brown)
1 – 150k (154) (Brown/Green/Black/Orange/Brown)
1 – 220k (224) (Red/Red/Black/Orange/Brown
2 – 330k (334) (Orange/Orange/Black/Orange/Brown)
1 – 1M (105) (Brown/Black/Black/Yellow/Brown)
Visit www.byocelectronics.com/resistorcodes.pdf for more information on how to
differentiate resistors.
Capacitors:
1 – 47p Ceramic Disc
2 – 470p Ceramic Disc (may say “471” on the body)
2 – 3n3/.0033uF film cap (may say “332” on the body)
2 – 6n8/.0068uF film cap (may say “682” on the body)
2 – 8n2/.0082uF film cap (may say “822” on the body)
1 – 10n/.01uF film cap (may say “103” on the body)
3 – 33n/.033uF film cap (may say “333” on the body)
1 – 47n/.047uF film cap (may say “473” on the body)
1 – 100n.1uF film cap (may say “104” or “u1” on the body)
1 – 470n.47uF film cap (may say “474” or “u33” on the body)
1- 1uf film cap (may say “105” or “1u” on the body)
3 – 10uf Aluminum Electrolytic
1 – 47uf Aluminum Electrolytic
Visit www.byocelectronics.com/capcodes.pdf for more info on how to differentiate
capacitors.
Diodes:
1 - 1N4001
2 – 1N4148

IC's:
4 - DIP 8 Socket
1- TL022
1- 3102
1- 3207
1- 4558
Transistor:
6 – 2N3904, 2N5088, 2N2222 or other similar transistor with EBC pinout.
Trimpot:
1 - 25k
Potentiometers: SNAP THE SMALL TABS ON THE TOP OF THE POTS OFF WITH A
PAIR OF NEEDLE NOSE PLIERS
2 – B100k (Rate and Depth)
1 – B10k (Blend)
Hardware:
1 - predrilled enclosure w/ 4 screws
1 – Bass chorus circuit board
1 - 3pdt footswitch
3 - knobs
1 - AC adaptor jack
1 - ¼”stereo jack
1 - ¼” mono jack
1 - battery snap
1 - red LED
4 – rubber bumpers
2 – lock washers (for in and out jacks)
hook-up wire

Populating the Circuit Board
Step 1: Add all the resistors. Resistors are not polarized and can be inserted in either
direction. NOTE: Your kit will come with all or mostly 1/8th watt resistors. These
are small and can lay down flat on the PCB. Your kit may come with some ¼watt
resistors. These are larger and will need to stand vertically on one end. See pics on
page 4 and 5 for examples.

Step 2: Add the diodes. Be sure to match the end of the diode with the stripe
to the layout on the PCB. The striped end should go in the square solder pad.
The 1N4148 diodes will go in the 2 smaller spaces. The 1N4001 goes in the
larger space. The 1N4001 will need to stand vertically on one end.

Step 3:Add 4 pin IC sockets. ONLY SOLDER THE SOCKET! NOT
THE ACTUAL IC! This is a socket. The sockets get soldered to the PCB.
The ICs get inserted into the sockets. The actual IC chip itself, never gets
soldered. You will insert the IC into the socket after the entire pedal has
been built.

Step 4: Add the transistors. Orient them so that the flat side matches up with the flat side
on the PCB layout.

Step 5: Add the 25k Trim pot. Note that there are 5 holes on the PCB, but only 3 leads
on the actual trimpot. Please do not let this confuse you. This is so that the PCB can
accommodate a variety of trimpots. There should only be one way to fit the trimpot into
the PCB. You do not need to bend the leads to make it fit (unless the leads were bent in
shipping).
You will need to adjust the trimpot when you are finished building the pedal. It controls
the circuit’s bias voltage. You start by setting the trimpot at the middle of its rotation or
“noon”. This will get you started and should definitely produce a chorus sound when you
plug in for the first time. You fine tune the trimpot by strumming or plucking as hard as
you can and dialing the trim pot till you get the least amount of distortion. If you have a
guitar with hotter pickups, you should use it for this step.

Step 6: Add the film and ceramic disc capacitors. These are non-polarized so they can go
in either direction.

Step 7: Add the aluminum electrolytic capacitors. These ARE polarized, meaning there
is a positive and negative end. The positive side will have a longer lead and goes in the
square solder pad. The negative side will have a shorter lead and a stripe running along
the body of the cap, and goes in the round solder pad.

At this point your board should look like this:

Step 8: Add wires to the IN, OUT, LED, POS, and the two Ground eyelets located in the
bottom corners of the board. . Start by cutting six 3.5” pieces of wire. Strip 1/4” off
each end and tin the ends. Tinning means to apply some solder to the stripped ends of the
wires. This keeps the strands from fraying and primes the wire for soldering. Load the
wires in from the top and solder on the bottom of the PCB.

Main PCB Assembly
Step 1: Flip the PCB over so that the bottom or solder side is up. Insert the
three potentiometers, and the LED into the bottom side of the PCB. DO
NOT SOLDER ANYTHING YET!!! The LED will have one lead that is
longer than the other. THIS WILL GO INTO THE SQUARE SOLDER
HOLE. Don’t forget to remove the nuts and washers from the pots and also
to snap off the tabs before you do this step.

Step 2:Hold the PCB in one hand so that the component side of the PCB is
in the palm of your hand and the bottom side with the pots and LED are
facing up. Now use your other hand to guide the predrilled enclosure onto
the PCB assembly so that the pots and LED all go into their respective holes.
Once the PCB assembly is in place, secure it by screwing on the washers and
nuts for the pots. Only tighten them with your fingers. You do not want
them very tight yet. Make sure you’ve removed the nuts and washers from
the pots and that you’ve also snapped the tabs off the pots as well before
installing.
Step 3:Turn the entire pedal over so that the component side of the PCB is
facing up. Lift the PCB up off the pots about 2mm just to make sure that the
back of the PCB does not short out against the pots. Make sure the PCB is
level and symmetrically seated inside the enclosure.
Step 4:Solder the pots and LED. You will solder these parts on the
component side of the PCB. After you have soldered them in place, be sure
to tighten up their nuts. Be careful not to burn any of the components on the
PCB. If you do, it won’t harm anything, but it will look ugly.

Wiring
Step 1: Mount the DC adapter jack to the enclosure. Your kit may come
with either an external thread or internal thread. Don’t get confused by this.
They still function exactly the same. You just thread the external nut on the
outside and the internal nut on the inside. The picture below is of an internal
nut jack.
