C & k systems Sys3316rf User manual

16.5 VAC

25 - 40 VA

50-60 Hz

Protected by Fuse

F2: 3 AG, 0.75 A

Shared with keypads

and AUX Power

UNSWITCHED

AUX POWER

KEYPAD INFORMATION

Do not exceed 4 keypads

or max AUX POWER

Protected by Fuse F3:

3 AG, 0.75 A

REDRED

RED BLKBLK

BLKBLK

BLK

BATTERYBATTERY

BATTERY Capacity forCapacity for

Capacity forCapacity for

Capacity for

emergencyemergency

emergency

standby atstandby at

standby at

least 4 hoursleast 4 hours

least 4 hours

CAUTION: Total power from

Terminals 3, 5, 7, and 8 NOT

to exceed 750 mA, combined.

NOTE: Z7 and Z8 must be

wired manually to the panel.

All ratings listed on this page are in compli-

ance with UL 985, UL 1023, and UL 1635.

DIRECT

CONNECT

WATCH

DOG

DS1DS1

DS1

WARNING: Circuit

Damage May Result

From Incorrect

Wiring Connections.

Red = incoming ring

Green = incoming tip

Gray = seized ring

Brown = seized tip

Blue = tamper

Orange = tamper

WARNINGS:WARNINGS:

WARNINGS:

For continued protectionFor continued protection

For continued protection

against risk of fire,against risk of fire,

against risk of fire,

replace fuses only withreplace fuses only with

replace fuses only with

fuses of same type andfuses of same type and

fuses of same type and

ratingrating

rating

PHONE CORDSPHONE CORDS

PHONE CORDS

Use either:

- 9.X PCF

- 9.X PCP

U14U14

U14

U6U6

U6

F1 2.5A

BELL FUSE

F2 0.75A

AUX DEVICES

F3 0.75A

KEYPAD

SN913-I/O

PROTECTED

BY FUSE F2:

3AG, 0.75A

P/N 5-051-396-00 Rev AP/N 5-051-396-00 Rev A

P/N 5-051-396-00 Rev A

- All outputs are power limited

- Connect ground wire from door hinge to earth ground using

16 AWG, green jacketed, solid-conductor wire

- If programmed for EOL or Supervised loop, the 2.2K ohm EOL

resistor (Model 9.X, 2.2K) must be at end of circuit

GENERAL INFORMATIONGENERAL INFORMATION

GENERAL INFORMATION

- Loop voltages:

- Loop 8 can be used as standard loop or used for switched 10-

12.5 VDC at 50 mA for 2-wire powered devices. Loop 8 can

support up to 10 BRK Model 2400 2-wire smoke detectors.

Loop 7

0 - 2 VDC = short

2 - 3 VDC = normal

3 - 5 VDC = open

Loop 8

0 - 2.5 VDC = short

2.5 - 8.5 VDC =

normal

8.5 - 15 VDC = open

- SN913-I/Ocardrequires2.2Kohmresistor(P/N5-162-024-00)

- are electrically common

4 32

1

S1

TX

GND

V+

RX ON

SWITCHED

AUX POWER

10 - 12 VDC

Protected by

Fuse F2:

3 AG, 0.75 A

12 VDC

6.5 AH or 9.5 AH

sealed lead-acid

POWER SUPPLY INFORMATION

- For non-Cal-Fire requirements, only use 12 VDC, 6.5 AH sealed

lead-acid battery, C&K Model #1265.

- For Cal-Fire Installations, use 12 VDC, 9.5 AH, sealed lead-acid

battery, C&K Model 1295.

- Replace battery every 3 - 5 years with C&K Model 1265 or 1295.

- Power demand for AUX POWER, keypads, and sounders not to

exceed maximum ratings.

- Install transformer (C&K Model 1097-B) on unswitched power

recepticle.

- Remove AC and battery power before replacing fuses.

- Maximum battery charge current = 350 mA.

- Standby battery time table with 1 Alpha keypad:

Battery Time Current

6.5 AH 7.5 Hrs. 500 mA

12 Hrs. 200 mA

9.5 AH 12 Hrs. 450 mA

24 Hrs. 56 mA

SYS3316RF Installation InstructionsSYS3316RF Installation Instructions

SYS3316RF Installation Instructions

AUDIBLE

10.5-13.5 VDC

Protected by Fuse

F1: 3AG, 2.5 A

Fuse F4 3 AG,

3 A battery

protection

2

SYS3316RF Installation Manual

ULCompliance(continued)

8. The Dynamic Battery Test must be enabled.

9. TheUnitStatus Report must beenabled.

10. The24-hourCheck-inmustbeenabled.

11. The unit must not be programmed to dial a police station.

12. Use screws (supplied) to secure cover or a lock must be

installedonthecabinet.

13. All devices must be UL listed.

Table of Contents

Subject Page No.

SYS3316RFTerminalLabel FrontCover

ULCompliance 2

Installation 2

WiringthePanel 3 - 4

SystemStart-Up 4

KeypadSetup 4 - 5

AddressingKeypads 5

FactoryDefaultSettings 5

ProgrammingOptions(AlphabeticalList) 5 - 6

ProgrammingthePanel 6 - 7

ProgrammingwiththeLEDKeypad 6

ProgrammingwiththeAlphaKeypad 6

EnteringHexidecimalNumbers 6

ProgrammingtheAlphaKeypad 7

ProgrammingLetters&Numbers 7

SpecialFunctionKeys 7

ProgrammingOptions(NumericalOrder) 8 - 19

KeypadLabelDrawer 20

TelephoneLineProblems 20

WatchdogIndicator 20

FCC Notice / Industry Canada 20

KeypadOperationCommandSummary 21

HelpwithCommonProblems(Troubleshooting) 22 - 23

ReducingFalseAlarms 24 - 25

WarrantyInformation 26

ProgrammingWorksheets 27 - 30

Introduction

TheSYS3316RFisafully-programmable16-zonecontrolpanel.Itcanbe

programmed from the Alpha or LED keypad or remotely via the COM-

MANDERII/MONITORII softwarepackage.

Accuracy

This manual has been carefully checked for accuracy. However, C&K

SYSTEMSassumesnoliabilityforinaccuraciesoractionsresultingfrom

the use of this manual. In addition, C&K reserves the right to modify the

SYS3316RFhardware,software,andmanualswithoutpriornotice.

Scope of This Manual

Thismanualcontainsbasicinstallationandprogramminginformationfor

theSYS3316RF.Foradditionalinformationaboutremoteprogramming,

pleaserefertotheCommanderII/MonitorIIOperatingManual.

BEFORE YOU STARTBEFORE YOU START

BEFORE YOU START

The SYS3316RF is in compliance with Underwriters Laboratories, Inc.

StandardsUL985, HouseholdWarningSystem Units;UL1023, House-

hold Burglar Alarm System Units; and UL 1635, Digital Burglar Alarm

CommunicatorSystemUnits.Thefollowingprogrammingrestrictions

must be observed to meet UL standards.

UL COMPLIANCEUL COMPLIANCE

UL COMPLIANCE

1. The audible must be programmed to sound at least four

minutesbeforesilencing.

2. No zone may be programmed for silent alarm.

3. Firezones mustbeprogrammed forpulsingaudible alarm.

4. Burglarzonesmust be programmed forasteady audible.

5. Burglarloops(non-24-hourloops)mustbeprogrammed

for NO/NC.

6. No Entry Delay may be greater than 45 seconds.

7. No Exit Delay may be greater than 60 seconds.

SteadyAudible

NO/NC with EOL

.

.BURGLAR LOOP

FIRE LOOP

ZoneProgramming

Notshuntable

.

Supervised

- latchingforheat

- resettingforsmoke

.Pulsingaudible

.24-hourarming

.

Mounting

TheSYS3316RFshouldbemountedinalocationwhichallowsconvenient

accesstoAC power,telephoneconnections, andearthground.

RemovetheSN913-I/Ofromitscardcageandthecontrolpanel

circuit board from the cabinet. This will prevent possible

damagetothecircuit boards when removingtheknock-outs.

Removetheknock-outs.

Mark the screw mounting holes on the wall.

Mount the cabinet at the desired height and pass the cables

throughtheknock-outs.

Replacethecircuitboards,rememberingtoconnecttheground

lug to the lower left corner of the control panel circuit board.

Reconnectthespadelugtothelowerdoorhinge. Thisprovides

theearthground connectionforthe door.

INSTALLATIONINSTALLATION

INSTALLATION

.

EarthGround

To ensure the effectiveness of the lightning and transient protection

circuits,thecontrolpanelmustbeconnectedto"EarthGround". Ideally,

thisshouldbeacommongroundtothepowerlines,telephonesystem,and

security system. This type of ground, called a "Unified Earth Ground",

provides the best protection. The ground connection, from a grounding

rod,coldwaterpipeorotherestablishedgroundpoint,ismadetothegreen

jacketedwireproviding agroundto thepanelhousing.

Power Lines

Control

Panel

Unified Earth Ground

with Bonded Ground Roots

Telephone

Earth Ground

Power Line

Earth Ground

Telephone Lines

FIGURE 1 Unified Earth Ground

3

SYS3316RF Installation Manual

AUXILIARY POWERAUXILIARY POWER

AUXILIARY POWER

Fuse F1

Terminal 3 is protected by a 2.5 Amp, 3 AG fast-blow fuse (F1).

If any fuse opens, remove AC and DC power, remove the

shortoroverload condition,thenreplacethe fusebefore

restoring power. Do not substitute a higher rated fuse.

NOTE:

ElectromagneticInterference

Vibrating horns and bells can produce electromagnetic interference

(EMI). While EMI will not damage the SYS3316RF, it can cause trans-

missionerrorsandmis-dialing.TominimizeEMI,installa0.01mfd,100

volt capacitor across the terminals of the horn or bell. The capacitor

must be located at the source of the EMI (horn or bell).

AUDIBLE OUTPUTAUDIBLE OUTPUT

AUDIBLE OUTPUT

Terminal 3 provides up to 0.75 Amps at 10.5 - 13.5

VDC. The type of voltage (steady, pulsed, or chirp)

and the time is programmable.

WIRINGWIRING

WIRING

Standby Battery

The SYS3316RF is designed to operate with a 12-volt, 6.5 AH, sealed

lead-acid battery (C&K Model 1265)**. Do not use non-rechargeable

batteriesorbatteriesother than sealed lead-acid.It is recommended

that you replace the standby battery every three to five years.

Connecttheredleadtothepositiveterminalofthebatteryandtheblack

lead to the negative battery terminal. The battery is reverse-polarity

protected by a 3 amp, 3 AG, fast-blow fuse (F4).

**To comply with CAL-FIRE requirements for 24-hour standby, a 12

VDC, 9.5 A-H, sealed lead-acid battery must be connected in place of

the 6.5 AH battery. Use C&K Model 1295 Battery.

AC POWERAC POWER

AC POWER

Available Power

ThemaximumtotalpoweravailablefromtheAudible,AUX(Switched

and Unswitched), and Keypad Terminals (terminals 3, 5, 7, and 8) is

750mA.TheSwitchedAux,UnswitchedAux,Receiver/InterfaceBoard

and Keypads Terminals share the same power bus. Combined power

for these outputs should not exceed 500 mA.

AC Power Failure

IfanACpowerfailurelastsmorethan15minutes,thekeypadswilldisplay

asystemtrouble.AnACfailurereportwillbesent,ifprogrammed.When

AC is restored for five minutes, a restoral report will be sent.

AC power is supplied by a 16.5 VAC, 25 - 40 VA

transformer at 50 or 60 Hz. A UL listed Class 2

transformer(suchastheC&KModel1097-B)mustbe

used. Connect the transformer secondary to termi-

nals1and 2. Useatleast 18 AWG(1.02mm) wireto

reducevoltagedrops.Thetransformerprimarymustbeconnectedto

anunswitchedreceptacle.DonotconnectprimarytoGround-Fault-

Interrupt (GFI) circuits. Securethetransformerto the wall.

DO NOT share the secondary of the transformer with other

devices. A foreign ground can damage the power supply,

voiding the warranty.

DO NOT use any transformer other than that specified in the

AC POWER section above.

PrecautionsPrecautions

Precautions

Terminals 3 and 4

Terminals 5, 6, and 7

Terminals 5 and 7 provide positive 10 - 12.5 VDC power.

Terminal5isusedfordevicesthatrequireswitchedpowerfor

resetting. Typical devices are glass-breaks and smoke de-

tectors.Terminal6providesthecommonforSwitchedAUX,

UnswitchedAUX,andKeypadpower.TheSN913-I/OInter-

face Board is connected to terminals 6 and 7 at the factory.

FuseF2

Terminals5and7(AUXPOWER)areprotectedbya0.75amp,3AG,fast-

blowfuse(F2).

Maximum wire length for connecting any keypad is 500' (152 m) of 22

AWG (0.643 mm) copper wire.

TheSYS3316RFiscapableofaddressingupto16keypads(8AlphaIIand

8 LED). Each LED keypad uses 35 mA of current. Each LCD (Alpha)

keypad uses 64 mA of current. See Available Power for current limita-

tions.Seepage 4foradditional informationonkeypad setup.

FuseF3

Terminal8 (keypadpower)isprotectedby a0.75 amp,3AG,fast-blow

fuse (F3).

SYSTEM 3316 Loops Terminals

N.O.

Alarm

N.C.

Alarm

++

+

--

-

EOL Loop

Loop 7

0 - 2 VDC = short

2 - 3 VDC = normal

3 - 5 VDC = open

Loop 8

0 - 2.5 VDC = short

2.5 - 8.5 VDC = normal

8.5 - 15 VDC = open

Two loops may be independently

configuredthrough programming.

Loops can be wired with an open

circuitswitch,closedcircuitswitch,

orwitha2.2K-ohmend-of-line(EOL)

resistor.

WhenprogrammedasanEOLcir-

cuit, either an open or a short will

bereportedasanalarmifthesystem

is in an armed state.

SYSTEM 3316 Loops Terminals

++

+N.C.

Alarm

N.O.

Alarm

Supervised Loop When operated as a Supervised

Loop,anopenwillbe reportedas

a Trouble, whether the system is

armed or disarmed. A short on a

SupervisedLoopisreportedasan

alarm if the system is armed, but

willhave noeffect ifthe systemis

disarmed.

--

-

Loop 8

The terminals for zone 8 (20 and 21) are a standard loop that can also

power 2-wire devices. The loop supplies 10 - 12.5 VDC at 50 mA. Use

Loop 8 to power 2-wire glass-breaks and smoke detectors. The 50 mA

on Loop 8 is part of the 500 mA AUX Power.

Pre-wired Loops

Loops 1 - 6 and 9 - 16 are pre-wired to the SN913-I/O Interface Board

and are configured as supervised loops for use with the WIRELESS

transmitters.EOL resistorsfortheseloopsareinstalledontheSN913-

I/O Interface Board.

Terminals 1 and 2

ARMING STATIONSARMING STATIONS

ARMING STATIONS Terminals 6, 8, and 9

Terminal 6 (black) is common.

Terminal 8 (red) provides 11 - 14 VDC keypad

power.

Terminal 9 (green) is data from the keypad to the

panel.

LOOP INPUTSLOOP INPUTS

LOOP INPUTS Terminals 19, 20, and 21

4

SYS3316RF Installation Manual

TAMPERSWITCHINSTALLATIONTAMPERSWITCHINSTALLATION

TAMPERSWITCHINSTALLATION

C&KhasdesignedtheSYS3316RFcabinettousethe AdemcoModel

19 tamperswitch. Thecabinetis constructedinordertoaccommodate

two switches. One tamper for the cover and a second switch for a wall

tamper. To install the tamper switches:

Positionthetamperswitchinsidethecabinetatthelowerrightcorner

of the cabinet. For the wall tamper, the plunger should go through

the small hole in the back of the cabinet. For the door tamper, the

plunger should face out from the cabinet. Refer to the drawing

below.

1.

2.

3.

Once the tamper switches are installed, opening the cabinet door or

removing the cabinet from the wall will result in a tamper signal at the

panel.

Connectthetamperswitchesinseriesandwirethetamperterminals

to a dedicated zone of the control panel.

Program the dedicated zone as desired: NC, EOL, 24-hour, etc.

TELEPHONEINTERFACE

Connect the SYS3316RF to the phone line using the

9.X PCP or 9.X PCF cord (not included). Each of the

cordshasan8-pintelcoplugononeend.Plugthisend

ofthecordintoJ1atthelowerrightcornerofthePCB.

Connecttheother endas outlinedbelow:

Incoming

Telco Line

123

4

8

76

T1

R1

T1 = Seized Tip

R1 = Seized Ring

Red

Green

Protector

Ring

Tip

Tamper Jumper

House

Phones

Tamper Switches installed in the SYS3316RF cabinet

PRINTED CIRCUITPRINTED CIRCUIT

PRINTED CIRCUIT

BOARDBOARD

BOARD SN913SN913

SN913SN913

SN913

I/OI/O

I/O

WALLWALL

WALL

TAMPER SWITCHTAMPER SWITCH

TAMPER SWITCH

DOORDOOR

DOOR

TAMPER SWITCHTAMPER SWITCH

TAMPER SWITCH

TB1TB1

TB1

6.5 A-H6.5 A-H

6.5 A-H

oror

or

9.5 AH9.5 AH

9.5 AH

LEAD-ACIDLEAD-ACID

LEAD-ACID

BATTERYBATTERY

BATTERY

5

ControlPanel

TelcoJack (J1) RJ-38XWiring

Diagram

YELLOW and BLACK = not usedGRAY = ring seized

GREEN = tip BLUE and ORANGE = tamper

RED = ring BROWN = tip seized

9.X PCF

The 9.X PCF has eight flying leads on the other end. Wire them to the

phonelineterminalsasfollows:

IfyoureplacethebatteryafteraSYSTEM TROUBLE-LOWBATTERY

message,youmust test thebatteryunder load conditions.Press[*] [6]

[4] [#] to start the Dynamic Battery Test.

Five minutes after the panel is powered up, it will dynamically test the

standbybatterybyinterruptingACpowerfortwominutesandmonitoring

the battery under load.

SYSTEM START-UP

VoltageVariations

Outputvoltagesat terminals 5,7, and 8mayvary from 9.0to14.4 VDC

(worst case), depending on the load, battery condition, and AC line

voltage.

KEYPAD SETUP

ALPHA II KEYPAD INFORMATION

TheAlphaIIkeypadusesatopviewingdisplay.Thismeansthedisplay

reads most clearly when viewed from a top angle rather than straight

onorfrombelow.Mountingthekeypadatlightswitchlevelandadjusting

the viewing angle gives the best results.

Adjusting the LCD Display

Toadjusttheviewingangle,removethekeypadfromthebackmounting

plate. Towards the bottom center of the circuit board is a small hole.

Insert a small screwdriver into the hole and adjust R23 for optimum

viewing, while holding the keypad at its mounting height.

ADDRESSING KEYPADS

Each Alpha II and LED keypad installed in the system must have an

address.Addressesmustnot berepeated.Whenreplacingakeypad,

make sure the replacement has the same address as the previous

keypad.Once allkeypads havebeenaddressed, resetthepanelby

pressing [Master Combination] [*] [6] [8] [#] or by removing and

restoring both AC and DC power.

Addressing Alpha II Keypads

Thefirsttime you powerup the system,unaddressedAlpha II keypads

will display KEYPAD ADDRESS?. Press any number from 0 through

7ateachkeypad.Theexactnumberyoupressisnotimportant,aslong

as each keypad has a different address number. The keypad will not

accept values outside of this range. Should you accidentally use the

sameaddressformorethanonekeypad,thesystemwillfailtoproperly

respond to keypad input. Refer to page 23 for assistance in correcting

this problem.

Hook switches SW1, SW2, and SW3 are used to set the address of

LED keypads. Refer to the chart at the top of page 5.

Addressing LED Keypads

The LED keypad also requires an address. The address on the LED

keypad is set by the three hook switches on the LED keypad's PCB.

5

SYS3316RF Installation Manual

SW1SW1

SW1

SW2SW2

SW2

SW3SW3

SW3

J1J1

J1

J2J2

J2

HOOKHOOK

HOOK

SWITCHESSWITCHES

SWITCHES

Closed

Open

Closed

Open

Closed

Open

Closed

Open

Closed

Open

Closed

Open

Closed

Open

KEYPADADDRESSKEYPADADDRESS

KEYPADADDRESS

88

8

99

9

1010

10

1111

11

1212

12

1313

13

1414

14

1515

15

LEDKeypadBacklighting

HookswitchJ1controlstheLEDkeypad'sbacklighting.WhenJ1isclosed

(defaultsetting),thebacklightingwillbeenabled.OpenJ1todisablethe

backlighting.

LED Keypad Piezo

Hook switch J2 controls the LED keypad's piezo audible. When J2 is

closed(defaultsetting),thepiezoisenabled.OpenJ2todisablethepiezo.

FACTORY SETTINGSFACTORY SETTINGS

FACTORY SETTINGS

DEFAULTPROGRAM SETUP

ThedefaultprogrammingoftheSYS3316RFwillallowyoutooperateitas

a local panel without any additional programming. The actual default

programming values are shown on the Programming Worksheet (last 4

pagesof thismanual).

Combinations

Installer combination: 0 1 2 3 4 5

User #1 (Master) combination: 1 2 3 4

Users #2 - 32: disabled

Defaultinstallercombination: yes

Guestcombination: no

Combinationrequired: no

FaultedArmingtype: goof-proof

Opening/Closing: noUsersauthorized to sendreports

Duress: disabled

Reporting

Account #1 and #2: disabled

Dialing type: pulse

RPS allowed: yes

Zones

Zone 1 = Entry/Exit delay - SUPERVISED EOL circuit

Zone 2 = doors or windows - SUPERVISED EOL circuit

Zone 3 = doors or windows - SUPERVISED EOL circuit

Zone 4 = doors or windows - SUPERVISED EOL circuit

Zone 5 = doors or windows - SUPERVISED EOL circuit

Zone 6 = doors or windows - SUPERVISED EOL circuit

Zone 7 = doors or windows - EOL circuit

Zone 8 = fire or smoke - supervised EOL circuit

Zones(cont.)

Zone 9 = interior - SUPERVISED EOL circuit

Zone 10 = interior - SUPERVISED EOL circuit

Zone 11 = interior - SUPERVISED EOL circuit

Zone 12 = interior - SUPERVISED EOL circuit

Zone 13 = interior - SUPERVISED EOL circuit

Zone 14 = interior - SUPERVISED EOL circuit

Zone 15 = interior - SUPERVISED EOL circuit

Zone 16 = interior - SUPERVISED EOL circuit

Emergencysoft zone: chirpaudible,non-reporting

Firesoft zone: pulsedaudible,non-reporting

Policesoft zone: steadyaudible, non-reporting

Testing

Test report interval: 7 days and disabled

Timing

Entry time: 60 seconds and prewarn

Exit time: 30 seconds and prewarn

Bell time: 5 minutes

Unit Control

Local system: yes

Dynamic battery test: off

PROGRAMMING OPTIONSPROGRAMMING OPTIONS

PROGRAMMING OPTIONS

The following is an alphabetical listing of all SYS3316RF programming

options, including Command Locations and Digit Positions. Digit Posi-

tions are inside parentheses ( ). NOTE: All Command Locations are in

Hexadecimal.

Option Location

Account#1 0C (1 - 6)

Account#2 10 (1 - 6)

AC PowerLine Frequency 2F (5)

Alarm ReceiverSelectbyLoop 1F - 26 & 49 - 50 (1)

AlarmReporting Codeby Loop 17 - 1E & 40 - 47 (1 - 2)

AudibleTime 2D (5)

BellReverseOperation 2E (3)

CancelReportCode 2A (5)

CancelReportReceiverSelect 2A (6)

ClosingReportCode 2C (3)

ClosingReportReceiverSelect 2C (4)

CombinationCommand 09 (2)

Daily BatteryTest Enable 2F (2)

DefaultInstallerCombination 09 (3)

Delay Before Dial by Loop 30 - 3F (4)

DelayBefore DialTime 0B (1)

DialAttempts 0B (6)

DialType 0B (2)

DisableLoopLEDs 2E (5)

DoorChimeEnable byLoop 30 - 3F (1)

DuressReport Code 2D (1)

DuressReport Receiver 2D (2)

EmergencyBell Type 27 (4)

EmergencyReceiverSelect 27 (3)

EmergencyReportCode 27 (1 - 2)

Entry DelayTime 2D (3)

EntryPre-alarmEnable 2E (1)

Exit Delay Time 2D (4)

ExitPre-alarmEnable 2E (2)

FaultedArmingType 09 (4)

Fire Bell Type 28 (4)

FireReceiver Select 28 (3)

FireReportCode 28 (1 - 2)

Four MinutePower UpDelay Enable 2F (3)

GroupShuntEnable 30 - 3F (3)

GuestCombination 08 (2 - 6)

GuestCombinationTime 09 (1)

InstallerCombination 00 (1 - 6)

Anyaddressfrom8to15canbeused.Theexact

number is not important, as long as each LED

keypad in the system has a different address

number.Shouldyou accidentallyusethe same

address for more than one keypad, the system

willfailtorespondtokeypadinput.Refertopage

23 (Alpha II keypads with same addresses) for

assistancein correctingthis problem.

SW3SW3

SW3

SW2SW2

SW2

SW1SW1

SW1

Note: If you connect power before wiring the loops, install a

2.2K-ohm EOL resistor across each loop.

6

SYS3316RF Installation Manual

OptionOption

Option LocationLocation

LocationLocation

Location

KeypadRPSEnable 0B (3)

Local System Only 2F (1)

LoopArmingType 1F - 26 & 49 - 50 (4)

LoopBell Type 1F - 26 & 49 - 50 (5)

LoopCircuit Type 1F - 26 & 49 - 50 (6)

LoopResponseTime 1F - 26 & 49 - 50 (2)

LoopRestoreType 1F - 26 & 49 - 50 (3)

Master Code (User #1) 01 (2 - 6)

OpeningReportCode 2C (1)

OpeningReportReceiver 2C (2)

PhoneRingType 0B (5)

Police BellType 29 (4)

PoliceReceiverSelect 29 (3)

PoliceReportCode 29 (1 - 2)

Receiver#1 MessageFormat 0A (2)

Receiver#1PhoneNumber 0D - 0F (1 - 6)

Receiver#1 ReceiverFormat 0A (1)

Receiver#2 MessageFormat 0A (4)

Receiver#2PhoneNumber 11 - 13 (1 - 6)

Receiver#2 ReceiverFormat 0A (3)

RestoreReceiverSelect 2A (2)

RestoreReporting Codeby Loop 17 - 1E & 40 - 47 (3 - 4)

RingBack Enable 2E (4)

RPSEnable 0B (4)

RPSPhoneNumber 14 - 16 (1 - 6)

SetTest ReportCountdownTimer A0 (1)

SetReal-TimeClock B3 & B4 (1 - 6)

ShuntEnable 30 - 3F (2)

ShuntReceiverSelect 2A (1)

ShuntReporting CodebyLoop 17 - 1E & 40 - 47 (5 - 6)

SoftZoneOperationEnable 2F (4)

TestReport Code 2B (1 - 2)

TestReportInterval 2B (4)

TestReportReceiver Select 2B (3)

TroubleReportCode 48 (1)

TroubleReportReceiverSelect 48 (2)

TroubleRestoreCode 48 (3)

TroubleRestoreReceiver Select 48 (4)

UnitStatus Code 2A (3)

UnitStatus Receiver 2A (4)

UserArmingType 01 - 08 & 51 - 68 (1)

UserCombinations 01 - 08 & 51 - 68 (2 - 6)

PROGRAMMING THE PANELPROGRAMMING THE PANEL

PROGRAMMING THE PANEL

Youcanprogramthe SYS3316RF from theLEDorLCD keypad, as well

asremotelyusing theCOMMANDERII software.Informationon remote

programmingisavailableintheCOMMANDERII/MONITORIIOperating

Manual. This installation manual includes a brief description of each

programmingoptionbeginningonpage8.

StartingPanelProgramming

Keyinthe[InstallerCombination][*][0][#].ThedefaultInstallerCombina-

tion is 0 1 2 3 4 5. When using the SYSTEM 2316 LED keypad, the

PROGRAMLEDwill light steadyto indicate programmingmode.On the

2316PlusLEDkeypadtheREADY,ARM,andSERVICELED'swillflash

to indicate programming mode. The Alpha II keypad will display CMD

DATA acrossthe topofthe LCDdisplaytoindicateprogramming mode.

NOTE: To program Command Locations A0, B3, and B4 with an

LED keypad, remember to enter the Command Location,

followed by the program data, then press the [#] key.

Warning: IfyouenteraCommandLocationandthenpressthe

[#]keywithoutenteringanyprogramdata,thekey-

padwillbeep5times,indicatinganerror.Tocorrect

this problem, simply re-enter the Command Loca-

tionand Data, then press the [#] key.

Programming with the Alpha Keypad

EnteringprogramdatawithanAlphakeypadisatwo-stepprocess.First,

keyinthetwo-digitaddress(CommandLocation)tobeprogrammedand

pressthe[#]key.TheAlphakeypaddisplaystheCommandLocationand

thedatapreviouslystored.Enterthenewdatayouwishtostoreandpress

the [#] key to write the data. You can also scroll through the Command

Locationsinnumericalorderbyalternatelypressingandreleasingthe[#]

key.

NOTE: Command Location A0 must be addressed directly. When pro-

gramming this Command Location with an Alpha keypad, the

previouslystoreddataisnotdisplayed.Toprogramthislocation,

entertheCommandLocationfollowedbythe[#]key.Thenenter

the data to be stored and again press the [#] key.

Programming Hexadecimal Numbers

TheAlphakeypadmaybeusedtoprogramthecontrolpanel.Thecursor

ismovedusingthe"E"and"P"keys,asindicatedinthefigurebelow.The

"F" key enters a blank space and moves the cursor one position to the

right.

C

E

B

F

D

132

45 6

789

0

A

Panel ProgrammingKeys

PROGRAMMINGCONVERSIONSPROGRAMMINGCONVERSIONS

PROGRAMMINGCONVERSIONS

HexadecimalValueHexadecimalValue

HexadecimalValue KeyStrokesKeyStrokes

KeyStrokesKeyStrokes

KeyStrokes

A

B

C

D

E

F

0

1

2

3

4

5

The same procedure is used with both the LED and the Alpha keypads.

Dataisprogrammedintothepanelusingthehexadecimalnumbersystem,

which consists of the digits 0 - 9 and the letters A - F. The digits 0 - 9 are

entereddirectlyfromthekeypad.Thechartbelowshowshowtoenterthe

hexadecimaldigits Athrough F.

Programming with the LED Keypad

ProgrammingwithanLEDkeypadisaone-stepprocess. Keyinthetwo-

digitaddress(CommandLocation),followedimmediatelybythedesired

programming values (program data), then press the [#] key to store the

data.TheLEDkeypaddoesnotdisplayanyprogrammedvalues.Ifyouare

notsurethatthecorrectprogrammingvalueshavebeenentered,program

theCommandLocationagain.

7

SYS3316RF Installation Manual

Thelasttwo CommandLocationsare CL37and CLA0.Pressing the[#]

key at these locations will advance you to CL 38 or CL A1, respectively.

Locations CL 38 and CL A1 are not used in the SYS3316RF. If you

accidentallyentereitherof these locations, press[*][#] to exit program-

ming,orentertheCommandLocationnumber,followedbythe[#]key,for

the location you wish to program.

To Exit Panel Programming

Whenyou havefinishedprogramming,press[*] [#].

Thepanelwill also

exittheprogrammingmodeifyoudonotpressanykeywithinafive

minuteperiod.

PROGRAMMING the ALPHA KEYPADPROGRAMMING the ALPHA KEYPAD

PROGRAMMING the ALPHA KEYPAD

EnsuretheAlphakeypadiswiredtotheSYS3316RFandpowerisapplied

tothecontrolpanel.Youcanonlyaccesstheprogrammingmodewhen

thecontrol panel isdisarmed.

NOTE: Programming the Keypad is not the same as Keypad

Programming.

The Alpha Keypad

YoucanprogramtheAlphakeypadsforspecialmessages,eachofthe16

zone labels, and the keypad address. Zone Labels display during the

walk-testandwhenthe[#]keyispressedduringalarmmemoryorfaults.

TheprogrammableServiceMessageisdisplayedduringACfailure,fuse

failure, communication failure, or low battery. The Dealer Message

displays when the system is disarmed. The keypad address is initially

displayedonlyduringsystemstartup(seepage4,KeypadAddressing).

Thesemessagescan be programmeddirectlyfrom the Alphakeypador

remotelyusingtheCommanderII/MonitorIIsoftwarepackage.Formore

detailedinformationaboutremoteprogramming,refertotheCommander

II/MonitorIIOperatingManual.

Keypad Message Programming

The Alpha keypad programming template is used to allow the installer

to program messages and zone descriptions into the Alpha keypads.

The template shown on the next page should be used when program-

ming the keypad.

To activate the keypad programming mode, enter the [Installer's Code]

[*] [0] [1] [#]. Information may be entered into the keypad in the form

of letters (upper and lower case), numbers (0 - 9), and 22 special symbols.

All characters are displayed in the order listed above, i.e. upper and

lower case letters, numbers, and special symbols.The [Space] char-

acter precedes the letter A.

To enter a Message or Label, use the [2] key to scroll through the

characters until you reach the desired character.If you scroll past the

desired character, the [8] key may be used to scroll backwards.When

the desired character is displayed, press the [6] key to move the cursor

to the next character position.The [4] key moves the cursor to the left.

When all characters have been entered, press the [#] key to write the

message and move to the next message position. Use the [0] key to

move backward through the messages.

The message order is:

• SERVICEMESSAGE

• DEALERMESSAGE

• SOFT ZONE IDENTIFIERS (A, B, and C)

• HARDWIREDLOOP IDENTIFIERS

• KEYPADADDRESS

BoththeAlpha (shown at thetopof the next column)andthe Alpha Plus

(shown below in the next column) use the same procedure to program

messages.

ALPHA PLUS Programming TemplateALPHA PLUS Programming Template

ALPHA PLUS Programming Template

11

122

22

233

33

3

66

6

55

5

44

4

77

788

88

899

99

9

00

0

NOTE: If you do not press any key for 5 minutes, the

keypadwillautomaticallyexittheprogramming

mode.

To Exit Keypad Programming

Whenyouhavefinishedprogramming,press[*][#].

Thekeypadwillalso

exittheprogrammingmodeifyou donot pressany keywithinafive

minuteperiod.

11

122

22

233

33

3

44

455

55

566

66

6

77

788

88

899

99

9

00

0

ALPHA II Programming TemplateALPHA II Programming Template

ALPHA II Programming Template

8

SYS3316RF Installation Manual

Command Location 00: Installer CombinationCommand Location 00: Installer Combination

Command Location 00: Installer Combination

(1) (2) (3) (4) (5) (6)

012345

00

0

00

0

DefaultValuesDefaultValues

DefaultValues

#

Digit Positions (1) - (6): Installer Combination

Combination must have 6 digits. Valid entries are 0 - 9.

Command Location 01 - 08 and 51 - 68:Command Location 01 - 08 and 51 - 68:

Command Location 01 - 08 and 51 - 68: User Arming Type and CombinationUser Arming Type and Combination

User Arming Type and CombinationUser Arming Type and Combination

User Arming Type and Combination

(1) (2) (3) (4) (5) (6)

91234E

11

1

00

0

**DefaultValues**DefaultValues

**DefaultValues

**Default Values are different for each user.

Refer to the SYS3316RF Programming

Worksheet at the end of this manual for

other user default values.

#

01 = User #1 (Master)

02 = User #2

03 = User #3

04 = User #4

05 = User #5

06 = User #6

07 = User #7

08 = User #8 (Guest)

51 = User #9

52 = User #10

53 = User #11

54 = User #12

55 = User #13

56 = User #14

57 = User #15

58 = User #16

59 = User #17

5A = User #18

5B = User #19

5C = User #20

5D = User #21

5E = User #22

5F = User #23

60 = User #24

61 = User #25

62 = User #26

63 = User #27

64 = User #28

65 = User #29

66 = User #30

67 = User #31

68 = User #32

0 = Arm Only, with Closing Report, Shunting Allowed

1 = Disarm Only, with Opening Report, Shunting Allowed

2 = Arm and Disarm, with O/C Reports, Shunting Allowed

7 = Arm Only, No Closing Report, Shunting Allowed

8 = Disarm Only, No Opening Report, Shunting Allowed

9 = Arm and Disarm, No O/C Reports, Shunting Allowed

4 = Arm Only, with Closing Report, No Shunting

5 = Disarm Only, with Opening Report, No Shunting

6 = Arm and Disarm, with O/C Reports, No Shunting

Digit Positions (2) - (6): Arming Combination (PIN)

Combination may have from 2 - 5 digits. Valid entries are 0 -9.

1 = Arm Only, No Closing (C) Report, No Shunting

2 = Disarm Only, No Opening (O) Report, No Shunting

3 = Arm and Disarm, No O/C Reports, No Shunting

Digit Position (1): Arming Type

A

B

C

D

E

F

Hexadecimal ValueHexadecimal Value

Hexadecimal Value Key StrokesKey Strokes

Key StrokesKey Strokes

Key Strokes

0

1

2

3

4

5

PROGRAMMINGCONVERSIONSPROGRAMMINGCONVERSIONS

PROGRAMMINGCONVERSIONS

CL 00 - 08 & 51 - 68CL 00 - 08 & 51 - 68

CL 00 - 08 & 51 - 68

NOTE: Opening and Closing Reports

must be enabled. See CL 2C

Digit Positions 1 and 3 for

additional information.

NOTE: Someprogramminglocationsallow

variable-length data and require an End-

of-Number (EON) character. Program

4 ("E") after the last digit. Fill

remainingunusedPositions with "0".

The EON character is not required if the

last digit is in Position 6.

9

SYS3316RF Installation Manual

Command Location 09: Arming/Combination OptionsCommand Location 09: Arming/Combination Options

Command Location 09: Arming/Combination Options

(1) (2) (3) (4)

0011

DefaultValuesDefaultValues

DefaultValues

00

099

99

9

Digit Position (1): Guest Combination Time

#

0 = Guest Time Disabled

1 = 1 day

2 = 2 days

3 = 3 days

4 = 4 days

5 = 5 days

6 = 6 days

7 = 7 days

8 = 8 days

9 = 9 days

0 = 10 days

1 = 11 days

2 = 12 days

3 = 13 days

4 = 14 days

5 = 15 days

Digit Position (2): Combination Command

0 = No

1 = Yes; requires combination for Bypass, Group Bypass, Instant Arm,

keypad activated RPS, and Test (central station and bell)

Digit Position (3): Default Installer Combination

0 = No; this enables the Pirate-GuardTM feature for added security

1 = Yes; combination changes back to factory value on power loss

Digit Position (4): Faulted Arming Type

1 = Goof-Proof: zones must be normal or shunted to arm

2 = Force Arm: faulted zones will be shunted at end of Exit Delay

3 = Chirp Alert: faulted zones will chirp bell upon transition from Exit Delay to Entrance Delay

Command Location 0A: Communications FormatsCommand Location 0A: Communications Formats

Command Location 0A: Communications Formats

(1) (2) (3) (4)

1212

DefaultValuesDefaultValues

DefaultValues

00

0AA

AA

A

Digit Position (1): Receiver #1 Receiver Format

1 = Fast "A", 2300 Hz

2 = Slow "B", 1400 Hz 3 = SumCheck, 1400 Hz

4 = SumCheck, 2300 Hz 5 = CFSK III

6 = DTMF, 1400 Hz

#

Digit Position (2): Receiver #1 Message Format

2 = 3/1 Extended

3 = 4/2 (2-digit reporting code) 5 = CFSK III

6 = SumCheck (DTMF)

Digit Position (3): Receiver #2 Receiver Format

1 = Fast "A", 2300 Hz

2 = Slow "B", 1400 Hz 3 = SumCheck, 1400 Hz

4 = SumCheck, 2300 Hz 5 = CFSK III

6 = DTMF, 1400 Hz

Digit Position (4): Receiver #2 Message Format

2 = 3/1 Extended

3 = 4/2 (2-digit reporting code) 5 = CFSK III

6 = SumCheck (DTMF)

3/1Extended All formats, exceptexcept

exceptexcept

except CFSK III and DTMF, 1400 Hz

Message Format Receiver Format(s)

SumCheck (DTMF) DTMF, 1400 Hz only

CFSK III CFSK III only

Valid combinations of Receiver Format and Message Format are listed below.

A

B

C

D

E

F

Hexadecimal ValueHexadecimal Value

Hexadecimal Value Key StrokesKey Strokes

Key StrokesKey Strokes

Key Strokes

0

1

2

3

4

5

PROGRAMMINGCONVERSIONSPROGRAMMINGCONVERSIONS

PROGRAMMINGCONVERSIONS

CL 09 and 0ACL 09 and 0A

CL 09 and 0A

4/2 (2-digitreporting) Fast "A", 2300 Hz and Slow "B", 1400 Hz only

1010

10

SYS3316RF Installation Manual

Command Location 0B: Communications ControlCommand Location 0B: Communications Control

Command Location 0B: Communications Control

Digit Position (1): Delay Before Dial Time

0 = 0 secs

1 = 10 secs

2 = 20 secs

3 = 30 secs

4 = 40 secs

5 = 50 secs

6 = 60 secs

7 = 70 secs

8 = 80 secs

9 = 90 secs

0 = 100 secs

1 = 110 secs

2 = 120 secs

3 = 130 secs

4 = 140 secs

5 = 150 secs

DefaultValuesDefaultValues

DefaultValues

31100

00

0

BB

B

8

(1) (2) (3) (4) (5) (6)

#

Digit Position (2): Dial Type

1 = DTMF - Touch Tone (10/sec)

2 = DTMF (5/sec)

3 = Pulse (10/sec)

Digit Position (3): Enable Keypad Activated RPS

0 = No

1 = Yes; allows remote programming to start from on-site keypad command

Digit Position (4): RPS Enable

0 = No

1 = Yes; allows remote programming to start from off-premise location

Digit Position (5): Phone Ring Type

0 = Single ring; uniformly timed rings with long pauses between rings

1 = Double ring; rings twice quickly followed by a long pause then rings twice again

Digit Position (6): Dialing Attempts

1 = 1 try

2 = 2 tries

3 = 3 tries

4 = 4 tries

5 = 5 tries

6 = 6 tries

7 = 7 tries

8 = 8 tries

9 = 9 tries

0 = 10 tries

1 = 11 tries

2 = 12 tries

3 = 13 tries

4 = 14 tries

5 = 15 tries

(1) (2) (3) (4) (5) (6)

000000

CC

C

00

0

DefaultValuesDefaultValues

DefaultValues

Digit Positions (1) - (6): Account Number

#

Valid entries are 0 - F.

The Account Number is right justified. The last digit must be in Position (6).

The SYS3316RF will read the account number using:

Digit Positions (4) - (6) with 3-digit accounts

Digit Positions (3) - (6) with 4-digit accounts

Digit Positions (1) - (6) with 6-digit accounts

Fill all unused Digit Positions with 0's.

Account Number 1 is used in

conjunction with Receiver Number 1

Command Location 0C: Account Number 1Command Location 0C: Account Number 1

Command Location 0C: Account Number 1

A

B

C

D

E

F

Hexadecimal ValueHexadecimal Value

Hexadecimal Value Key StrokesKey Strokes

Key StrokesKey Strokes

Key Strokes

0

1

2

3

4

5

PROGRAMMINGCONVERSIONSPROGRAMMINGCONVERSIONS

PROGRAMMINGCONVERSIONS

CL 0B and 0CCL 0B and 0C

CL 0B and 0C

1111

11

SYS3316RF Installation Manual

Command Locations 0D - 0F: Receiver #1 Phone NumberCommand Locations 0D - 0F: Receiver #1 Phone Number

Command Locations 0D - 0F: Receiver #1 Phone Number

Command Location 0DCommand Location 0D

Command Location 0D

(1) (2) (3) (4) (5) (6)

Command Location 0ECommand Location 0E

Command Location 0E

(1) (2) (3) (4) (5) (6)

Command Location 0FCommand Location 0F

Command Location 0F

(1) (2) (3) (4) (5) (6)

Digit (1) is dialed first.

You must place a 4 (EON) after the last digit to be

dialed. Fill in remaining positions with "0". The zeroes will

not be dialed.

Command Location 0D: Receiver #1 Phone Number (digits 1 - 6)Command Location 0D: Receiver #1 Phone Number (digits 1 - 6)

Command Location 0D: Receiver #1 Phone Number (digits 1 - 6)

00

0DD

DD

D

(1) (2) (3) (4) (5) (6)

00000

DefaultValuesDefaultValues

DefaultValues

Digit Positions (1) - (6):Digit Positions (1) - (6):

Digit Positions (1) - (6):

#

Command Location 0E: Receiver #1 Phone Number (digits 7 - 12)Command Location 0E: Receiver #1 Phone Number (digits 7 - 12)

Command Location 0E: Receiver #1 Phone Number (digits 7 - 12)

00

0EE

EE

E

(1) (2) (3) (4) (5) (6)

00000

DefaultValuesDefaultValues

DefaultValues

Command Location 0F: Receiver #1 Phone Number (digits 13 - 18)Command Location 0F: Receiver #1 Phone Number (digits 13 - 18)

Command Location 0F: Receiver #1 Phone Number (digits 13 - 18)

#

0

00

0FF

FF

F

(1) (2) (3) (4) (5) (6)

000000

DefaultValuesDefaultValues

DefaultValues

#

Command Location 10: Account Number 2Command Location 10: Account Number 2

Command Location 10: Account Number 2

11

100

00

0

(1) (2) (3) (4) (5) (6)

000000

DefaultValuesDefaultValues

DefaultValues

#

Account Number 2 is used in

conjunction with Receiver Number 2

Digit Positions (1) - (6): Account NumberDigit Positions (1) - (6): Account Number

Digit Positions (1) - (6): Account Number

Valid entries are 0 - F.

The Account Number is right justified. The last digit must be in Position (6).

The SYS3316RF will read the account number using:

Digit Positions (4) - (6) with 3-digit accounts

Digit Positions (3) - (6) with 4-digit accounts

Digit Positions (1) - (6) with 6-digit accounts

Fill all unused Digit Positions with 0's. A

B

C

D

E

F

Hexadecimal ValueHexadecimal Value

Hexadecimal Value Key StrokesKey Strokes

Key StrokesKey Strokes

Key Strokes

0

1

2

3

4

5

PROGRAMMINGCONVERSIONSPROGRAMMINGCONVERSIONS

PROGRAMMINGCONVERSIONS

Order in which the numbers will be dialedOrder in which the numbers will be dialed

Order in which the numbers will be dialed

0 - 9 = dialing digits

0 = dial tone detect

2 = * (DTMF dialing only, not used in pulse dialing)

3 = # (DTMF dialing only, not used in pulse dialing)

4 = end of number

5 = 5 second delay

CL 0D - 10CL 0D - 10

CL 0D - 10

E

1212

12

SYS3316RF Installation Manual

Command Locations 11 - 13: Receiver #2 Phone NumberCommand Locations 11 - 13: Receiver #2 Phone Number

Command Locations 11 - 13: Receiver #2 Phone Number

Command Location 11Command Location 11

Command Location 11

(1) (2) (3) (4) (5) (6)

Command Location 12Command Location 12

Command Location 12

(1) (2) (3) (4) (5) (6)

Command Location 13Command Location 13

Command Location 13

(1) (2) (3) (4) (5) (6)

Order in which the numbers will be dialedOrder in which the numbers will be dialed

Order in which the numbers will be dialed

Command Location 11: Receiver #2 Phone Number (digits 1 - 6)Command Location 11: Receiver #2 Phone Number (digits 1 - 6)

Command Location 11: Receiver #2 Phone Number (digits 1 - 6)

11

111

11

1

(1) (2) (3) (4) (5) (6)

E00000

DefaultValuesDefaultValues

DefaultValues

#

Digit Positions (1) - (6):Digit Positions (1) - (6):

Digit Positions (1) - (6):

Digit (1) is dialed first.

You must place a 4 (EON) after the last digit to be dialed.

Fill in remaining positions with "0". The zeroes will not be

dialed.

0 - 9 = dialing digits

0 = dial tone detect

2 = * (DTMF dialing only, not used in pulse dialing)

3 = # (DTMF dialing only, not used in pulse dialing)

4 = end of number

5 = 5 second delay

11

122

22

2

(1) (2) (3) (4) (5) (6)

000000

DefaultValuesDefaultValues

DefaultValues

#

Command Location 12: Receiver #2 Phone Number (digits 7 - 12)Command Location 12: Receiver #2 Phone Number (digits 7 - 12)

Command Location 12: Receiver #2 Phone Number (digits 7 - 12)

Command Location 13: Receiver #2 Phone Number (digits 13 - 18)Command Location 13: Receiver #2 Phone Number (digits 13 - 18)

Command Location 13: Receiver #2 Phone Number (digits 13 - 18)

11

133

33

3

(1) (2) (3) (4) (5) (6)

000000

DefaultValuesDefaultValues

DefaultValues

#

Command Locations 14 - 16: RPS Phone NumberCommand Locations 14 - 16: RPS Phone Number

Command Locations 14 - 16: RPS Phone Number

Command Location 14: RPS Phone Number (digits 1 - 6)Command Location 14: RPS Phone Number (digits 1 - 6)

Command Location 14: RPS Phone Number (digits 1 - 6)

11

144

44

4

(1) (2) (3) (4) (5) (6)

E00000

DefaultValuesDefaultValues

DefaultValues

#

Command Location 15: RPS Phone Number (digits 7 - 12)Command Location 15: RPS Phone Number (digits 7 - 12)

Command Location 15: RPS Phone Number (digits 7 - 12)

11

155

55

5

(1) (2) (3) (4) (5) (6)

000000

DefaultValuesDefaultValues

DefaultValues

#

Command Location 16: RPS Phone Number (digits 13 - 18)Command Location 16: RPS Phone Number (digits 13 - 18)

Command Location 16: RPS Phone Number (digits 13 - 18)

11

166

66

6

(1) (2) (3) (4) (5) (6)

000000

DefaultValuesDefaultValues

DefaultValues

#

Command Locations 14 - 16 store the RPS Phone

Number used by the the COMMANDER II Remote

Programming Software. For additional information on

programming these Locations, refer to Receiver #2 above.

NOTE: In order to utilize the Remote Programming

feature, CL 0B, Digit Positions (3) and (4) must

also be programmed with YES.

CL 11 - 16CL 11 - 16

CL 11 - 16

1313

13

SYS3316RF Installation Manual

Command Locations 17 - 1E & 40 - 47: Loop Reporting CodesCommand Locations 17 - 1E & 40 - 47: Loop Reporting Codes

Command Locations 17 - 1E & 40 - 47: Loop Reporting Codes

(1) (2) (3) (4) (5) (6)

01E100

17 = Loop 1

18 = Loop 2

19 = Loop 3

1A = Loop 4

1B = Loop 5

1C = Loop 6

1D = Loop 7

1E = Loop 8

40 = Loop 9

41 = Loop 10

42 = Loop 11

43 = Loop 12

44 = Loop 13

45 = Loop 14

46 = Loop 15

47 = Loop 16

77

7

11

1

**DefaultValues**DefaultValues

**DefaultValues

#

**Default Values are different

for each loop. Refer to the

SYS3316RF Programming

Worksheet at the end of this

manual.

Digit Positions (1) & (2): Alarm Reporting Code

Program 00 to disable Event Reporting for a loop.

Digit Positions (3) & (4): Restore Reporting Code

Program 00 to disable Event Reporting for a loop.

Digit Positions (5) & (6): Shunt Reporting Code

Program 00 to disable Event Reporting for a loop.

Command Locations 1F - 26, & 49 - 50: Loop ControlCommand Locations 1F - 26, & 49 - 50: Loop Control

Command Locations 1F - 26, & 49 - 50: Loop Control

(1) (2) (3) (4) (5) (6)

111325

FF

F

11

1

1F = Loop 1

20 = Loop 2

21 = Loop 3

22 = Loop 4

23 = Loop 5

4B = Loop 11

4C = Loop 12

4D = Loop 13

4E = Loop 14

4F = Loop 15

50 = Loop 16

24 = Loop 6

25 = Loop 7

26 = Loop 8

49 = Loop 9

4A = Loop 10

**DefaultValues**DefaultValues

**DefaultValues

#

**Default Values are different

for each loop. Refer to the

SYS3316RF Programming

Worksheet at the end of this

manual.

Digit Position (2): Loop Response TimeDigit Position (2): Loop Response Time

Digit Position (2): Loop Response Time

Digit Position (1): Alarm Receiver SelectDigit Position (1): Alarm Receiver Select

Digit Position (1): Alarm Receiver Select

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only

2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

0 = 5 milliseconds

1 = 250 milliseconds 2 = 500 milliseconds

3 = 750 milliseconds

Digit Position (3): Loop Restore TypeDigit Position (3): Loop Restore Type

Digit Position (3): Loop Restore Type

0 = No Restoral Report sent

1 = Restoral sent when loop normal 2 = Restoral sent when loop normal and bell silences

3 = Restoral sent when loop normal and system disarmed

Digit Position (4): Loop Arming TypeDigit Position (4): Loop Arming Type

Digit Position (4): Loop Arming Type

1 = Interior: delayed during E/E delays

2 = Instant

3 = Delay

4 = Long Delay: delay two times as long

5 = Day/Instant: buzzer on day fault

6 = Day/Delay: buzzer on day fault

7 = Day/Instant with bell

8 = Day/Delay with bell

9 = 24 Hours: always armed

Digit Position (5): Loop Bell TypeDigit Position (5): Loop Bell Type

Digit Position (5): Loop Bell Type

1 = Pulsing

2 = Steady 3 = Chirp

4 = Silent with no LED 5 = Silent with LED

Digit Position (6): Loop Circuit TypeDigit Position (6): Loop Circuit Type

Digit Position (6): Loop Circuit Type

1 = Normally Open Circuit

2 = Normally Closed Circuit

3 = End Of Line (EOL)

4 = Supervised, bell latched

5 = Supervised, bell not latched NOTE: A Loop programmed as type 4 or 5 will report any open

as a Trouble condition, regardless of panel armed status.

A

B

C

D

E

F

Hexadecimal ValueHexadecimal Value

Hexadecimal Value Key StrokesKey Strokes

Key StrokesKey Strokes

Key Strokes

0

1

2

3

4

5

PROGRAMMINGCONVERSIONSPROGRAMMINGCONVERSIONS

PROGRAMMINGCONVERSIONS

CL 17 - 1E & 40 - 47, 1F - 26 & 49 - 50CL 17 - 1E & 40 - 47, 1F - 26 & 49 - 50

CL 17 - 1E & 40 - 47, 1F - 26 & 49 - 50

1414

14

SYS3316RF Installation Manual

Command Location 27: Soft Zone A (Emergency)Command Location 27: Soft Zone A (Emergency)

Command Location 27: Soft Zone A (Emergency)

(1) (2) (3) (4)

0013

DefaultValuesDefaultValues

DefaultValues

22

277

77

7#

Digit Positions (1) and (2): Emergency Report CodeDigit Positions (1) and (2): Emergency Report Code

Digit Positions (1) and (2): Emergency Report Code

Program 00 to disable alarm reporting for Emergency zone.

Digit Position (3): Emergency Zone Receiver SelectDigit Position (3): Emergency Zone Receiver Select

Digit Position (3): Emergency Zone Receiver Select

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only

2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

Digit Position (4): Loop Bell TypeDigit Position (4): Loop Bell Type

Digit Position (4): Loop Bell Type

1 = Pulsing

2 = Steady 3 = Chirp

4 = Silent

Command Location 28: Soft Zone B (Fire)Command Location 28: Soft Zone B (Fire)

Command Location 28: Soft Zone B (Fire)

(1) (2) (3) (4)

0011

DefaultValuesDefaultValues

DefaultValues

22

288

88

8#

Digit Positions (1) and (2): Fire Report CodeDigit Positions (1) and (2): Fire Report Code

Digit Positions (1) and (2): Fire Report Code

Digit Position (3): Fire Receiver SelectDigit Position (3): Fire Receiver Select

Digit Position (3): Fire Receiver Select

Digit Position (4): Loop Bell TypeDigit Position (4): Loop Bell Type

Digit Position (4): Loop Bell Type

A

B

C

D

E

F

Hexadecimal ValueHexadecimal Value

Hexadecimal Value Key StrokesKey Strokes

Key StrokesKey Strokes

Key Strokes

0

1

2

3

4

5

PROGRAMMINGCONVERSIONSPROGRAMMINGCONVERSIONS

PROGRAMMINGCONVERSIONS

CL 27 - 29CL 27 - 29

CL 27 - 29

NOTE: Command Location 2F Digit Position (4) must

be programmed to YES to enable Soft Zones.

Command Location 29: Soft Zone C (Police)Command Location 29: Soft Zone C (Police)

Command Location 29: Soft Zone C (Police)

(1) (2) (3) (4)

0012

DefaultValuesDefaultValues

DefaultValues

22

299

99

9#

Digit Positions (1) and (2): Police Report CodeDigit Positions (1) and (2): Police Report Code

Digit Positions (1) and (2): Police Report Code

Digit Position (3): Police Zone Receiver SelectDigit Position (3): Police Zone Receiver Select

Digit Position (3): Police Zone Receiver Select

Digit Position (4): Loop Bell TypeDigit Position (4): Loop Bell Type

Digit Position (4): Loop Bell Type

Refer to CL 27 for information

about programming this zone.

Refer to CL 27 for information

about programming this zone.

This Zone is identified by the "E" key

on the Alpha II and LED keypads.

This Zone is identified by the "F" key

on the Alpha II and LED keypads.

This Zone is identified by the "P" key

on the Alpha II and LED keypads.

1515

15

SYS3316RF Installation Manual

Digit Positions (1) and (2): Test Report CodeDigit Positions (1) and (2): Test Report Code

Digit Positions (1) and (2): Test Report Code

Command Location 2A: Event ReportingCommand Location 2A: Event Reporting

Command Location 2A: Event Reporting

(1) (2) (3) (4) (5) (6)

11A1D1

AA

A

22

2

Digit Position (1): Shunt Receiver SelectDigit Position (1): Shunt Receiver Select

Digit Position (1): Shunt Receiver Select

DefaultValuesDefaultValues

DefaultValues

#

See also CL 17 - 1E & 40 - 47 Digit Positions (5) and (6).

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only 2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

Digit Position (2): Restore Receiver SelectDigit Position (2): Restore Receiver Select

Digit Position (2): Restore Receiver Select

See also CL 17 - 1E & 40 - 47 Digit Positions (3) and (4).

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only 2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

Digit Position (3): Unit Status Report CodeDigit Position (3): Unit Status Report Code

Digit Position (3): Unit Status Report Code

Valid entries are 0 - F.

The panel will add a fixed extension digit when reporting. Fixed codes are listed below.

Program a 0 at this position to disable Unit Status Reporting.

Digit Position (4): Unit Status Receiver SelectDigit Position (4): Unit Status Receiver Select

Digit Position (4): Unit Status Receiver Select

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only 2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

Digit Position (5): Cancel Report CodeDigit Position (5): Cancel Report Code

Digit Position (5): Cancel Report Code

Valid entries are 0 - F.

The panel will add the User ID # as the second digit when reporting.

Program a 0 at this position to disable Cancel Reports.

Digit Position (6): Cancel Report Receiver SelectDigit Position (6): Cancel Report Receiver Select

Digit Position (6): Cancel Report Receiver Select

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only 2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

7 = AC restore

8 = Bell fuse restore

B = Watchdog reset

C = Completed programming

1 = Low battery

2 = AC fail

3 = Bell fuse fail

5 = Failed to communicate

6 = Battery restore

UNIT STATUS FIXED EXTENSION CODESUNIT STATUS FIXED EXTENSION CODES

UNIT STATUS FIXED EXTENSION CODES

Command Location 2B: Test ReportCommand Location 2B: Test Report

Command Location 2B: Test Report

(1) (2) (3) (4)

0016

DefaultValuesDefaultValues

DefaultValues

22

2BB

BB

B#

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only 2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

Digit Positions (4): Test Report IntervalDigit Positions (4): Test Report Interval

Digit Positions (4): Test Report Interval

NOTE: CL A0 must be programmed to

correctly set time of test.

Digit Positions (3): Test Report Receiver SelectDigit Positions (3): Test Report Receiver Select

Digit Positions (3): Test Report Receiver Select

Program 00 to disable Test Reports.

Valid entries are 0 - F.

1 = 1 hour

2 = 2 hours

3 = 4 hours

4 = 12 hours

5 = 24 hours

6 = 7 days

7 = 14 days

8 = 21 days

9 = 30 days

0 = 1 hour if armed

1 = 2 hours if armed

2 = 4 hours if armed

3 = 12 hours if armed

4 = 24 hours if armed

CL 2A and 2BCL 2A and 2B

CL 2A and 2B

1616

16

SYS3316RF Installation Manual

Command Location 2C: Opening and Closing Report CodesCommand Location 2C: Opening and Closing Report Codes

Command Location 2C: Opening and Closing Report Codes

(1) (2) (3) (4)

B1C1

DefaultValuesDefaultValues

DefaultValues

22

2CC

CC

C

Digit Position (1): Opening Report CodeDigit Position (1): Opening Report Code

Digit Position (1): Opening Report Code

#

Valid entries are 0 - F.

The User ID # is transmitted after the opening code.

Program 0 to disable Opening Reports.

Digit Position (2): Opening Report Receiver SelectDigit Position (2): Opening Report Receiver Select

Digit Position (2): Opening Report Receiver Select

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only 2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

Digit Position (3): Closing Report CodeDigit Position (3): Closing Report Code

Digit Position (3): Closing Report Code

Valid entries are 0 - F.

The User ID # is transmitted after the opening code.

Program 0 to disable Closing Reports.

Digit Position (4): Closing Report Receiver SelectDigit Position (4): Closing Report Receiver Select

Digit Position (4): Closing Report Receiver Select

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only 2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

Command Location 2D: Duress Report and DelaysCommand Location 2D: Duress Report and Delays

Command Location 2D: Duress Report and Delays

Digit Position (4): Exit Delay TimeDigit Position (4): Exit Delay Time

Digit Position (4): Exit Delay Time

DefaultValuesDefaultValues

DefaultValues

(1) (2) (3) (4) (5)

13620

22

2

DD

D

Digit Position (1): Duress Report CodeDigit Position (1): Duress Report Code

Digit Position (1): Duress Report Code

#

Valid entries are 0 - F.

The User ID # will be reported as the second digit when reporting.

Program 0 to disable Duress Reports.

Digit Position (2): Duress Receiver SelectDigit Position (2): Duress Receiver Select

Digit Position (2): Duress Receiver Select

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only 2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

Digit Position (3): Entry Delay TimeDigit Position (3): Entry Delay Time

Digit Position (3): Entry Delay Time

NOTE: To program delay times greater

than 150 secs, see CL 1F - 26 &

49 - 50 Digit Position (4)

1 = 110 secs

2 = 120 secs

3 = 130 secs

4 = 140 secs

5 = 150 secs

6 = 60 secs

7 = 70 secs

8 = 80 secs

9 = 90 secs

0 = 100 secs

1 = 10 secs

2 = 20 secs

3 = 30 secs

4 = 40 secs

5 = 50 secs

1 = 110 secs

2 = 120 secs

3 = 130 secs

4 = 140 secs

5 = 150 secs

6 = 60 secs

7 = 70 secs

8 = 80 secs

9 = 90 secs

0 = 100 secs

1 = 10 secs

2 = 20 secs

3 = 30 secs

4 = 40 secs

5 = 50 secs

Digit Position (5): Audible TimeDigit Position (5): Audible Time

Digit Position (5): Audible Time

1 = 2 min

2 = 5 min

3 = 10 min

4 = 15 min

5 = 30 min

A

B

C

D

E

F

Hexadecimal ValueHexadecimal Value

Hexadecimal Value Key StrokesKey Strokes

Key StrokesKey Strokes

Key Strokes

0

1

2

3

4

5

PROGRAMMINGCONVERSIONSPROGRAMMINGCONVERSIONS

PROGRAMMINGCONVERSIONS

CL 2C and 2DCL 2C and 2D

CL 2C and 2D

NOTE: To program delay times greater

than 150 secs, see CL 1F - 26 &

49 - 50 Digit Position (4)

1717

17

SYS3316RF Installation Manual

Command Location 2E: Audible/Visual SwitchesCommand Location 2E: Audible/Visual Switches

Command Location 2E: Audible/Visual Switches

DefaultValuesDefaultValues

DefaultValues

(1) (2) (3) (4) (5)

10001

22

2

EE

E

Digit Position (1): Entry Pre-alarm EnableDigit Position (1): Entry Pre-alarm Enable

Digit Position (1): Entry Pre-alarm Enable

#

0 = No

1 = Yes: sounds keypad buzzers during entry delay

Digit Position (2): Exit Pre-alarm EnableDigit Position (2): Exit Pre-alarm Enable

Digit Position (2): Exit Pre-alarm Enable

0 = No

1 = Yes: sounds keypad buzzers during exit delay

Digit Position (3): Bell Reverse OperationDigit Position (3): Bell Reverse Operation

Digit Position (3): Bell Reverse Operation

0 = No

1 = Yes: supplies bell voltage in non-alarm state; Bell requires external power supply

Digit Position (4): Ring BackDigit Position (4): Ring Back

Digit Position (4): Ring Back

0 = No

1 = Yes: Automatic Bell test after arming for local or non-supervised accounts;

follows closing report for supervised accounts; sounds bells for 2 seconds.

Digit Position (5): Disable Loop LEDsDigit Position (5): Disable Loop LEDs

Digit Position (5): Disable Loop LEDs

0 = No

1 = Yes: turn off zone LEDs after 5 minutes (panel must be disarmed)

Command Location 2F: Unit ControlCommand Location 2F: Unit Control

Command Location 2F: Unit Control

DefaultValuesDefaultValues

DefaultValues

(1) (2) (3) (4) (5)

00111

22

2

FF

F

Digit Position (1): Local System OnlyDigit Position (1): Local System Only

Digit Position (1): Local System Only

#

0 = No

1 = Yes: disables all communications except RPS

Digit Position (2): Enable Daily Dynamic Battery TestDigit Position (2): Enable Daily Dynamic Battery Test

Digit Position (2): Enable Daily Dynamic Battery Test

0 = No

1 = Yes: performs a 2-minute battery test (under load conditions) once every 24 hours

Digit Position (3): Enable Four Minute Power-Up DelayDigit Position (3): Enable Four Minute Power-Up Delay

Digit Position (3): Enable Four Minute Power-Up Delay

0 = No

1 = Yes: all alarms suppressed for 4 minutes on power-up

Digit Position (4): Enable Soft Zone OperationDigit Position (4): Enable Soft Zone Operation

Digit Position (4): Enable Soft Zone Operation

0 = No

1 = Yes: allow use of Emergency (E), Fire (F), and Police (P) keys (See also CL 27 - 29)

Digit Position (5): AC Power Line FrequencyDigit Position (5): AC Power Line Frequency

Digit Position (5): AC Power Line Frequency

0 = 50 Hz

1 = 60 Hz

A

B

C

D

E

F

Hexadecimal ValueHexadecimal Value

Hexadecimal Value Key StrokesKey Strokes

Key StrokesKey Strokes

Key Strokes

0

1

2

3

4

5

PROGRAMMINGCONVERSIONSPROGRAMMINGCONVERSIONS

PROGRAMMINGCONVERSIONS

CL 2E and 2FCL 2E and 2F

CL 2E and 2F

1818

18

SYS3316RF Installation Manual

Command Locations 30 - 3F: Loop SwitchesCommand Locations 30 - 3F: Loop Switches

Command Locations 30 - 3F: Loop Switches

(1) (2) (3) (4)

0100

DefaultValuesDefaultValues

DefaultValues

33

300

00

030 = Loop 1

31 = Loop 2

32 = Loop 3

33 = Loop 4

34 = Loop 5

35 = Loop 6

36 = Loop 7

37 = Loop 8

38 = Loop 9

39 = Loop 10

3A = Loop 11

3B = Loop 12

3C = Loop 13

3D = Loop 14

3E = Loop 15

3F = Loop 16

#

Digit Position (1): Enable Door ChimeDigit Position (1): Enable Door Chime

Digit Position (1): Enable Door Chime

0 = No

1 = Yes: keypads beep 2 seconds when faulted (disarmed condition)

Digit Position (2): Allow Shunting of This LoopDigit Position (2): Allow Shunting of This Loop

Digit Position (2): Allow Shunting of This Loop

0 = No: makes it a priority zone (not shuntable)

1 = Yes: authorized users can bypass or force arm Refer to CL 01 - 08 & 51 - 58 Digit Position (1) for

Arming Types (Authorization Levels)

Digit Position (3): Allow Group Shunting for This LoopDigit Position (3): Allow Group Shunting for This Loop

Digit Position (3): Allow Group Shunting for This Loop

0 = No

1 = Yes: this loop will shunt with Group Shunt

Digit Position (4): Delay Before DialDigit Position (4): Delay Before Dial

Digit Position (4): Delay Before Dial

0 = No

1 = Yes: this loop will delay dialing on alarm for time programmed in 0B (1)

Command Location 48: Trouble ReportsCommand Location 48: Trouble Reports

Command Location 48: Trouble Reports

(1) (2) (3) (4)

F1E1

DefaultValuesDefaultValues

DefaultValues

44

488

88

8#

Digit Position (1): Trouble Report CodeDigit Position (1): Trouble Report Code

Digit Position (1): Trouble Report Code

This is a one-digit reporting code.

Program 0 to disable Trouble Report.

Digit Position (2): Trouble Report Receiver SelectDigit Position (2): Trouble Report Receiver Select

Digit Position (2): Trouble Report Receiver Select

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only 2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

Digit Position (3): Trouble Restoral Report CodeDigit Position (3): Trouble Restoral Report Code

Digit Position (3): Trouble Restoral Report Code

This is a one-digit reporting code.

Program 0 to disable Trouble Restoral Report.

Digit Position (4): Trouble Restoral Report Receiver SelectDigit Position (4): Trouble Restoral Report Receiver Select

Digit Position (4): Trouble Restoral Report Receiver Select

0 = Receiver 1 with Receiver 2 as back-up

1 = Receiver 1 only 2 = Receiver 2 only

3 = Receiver 1 and Receiver 2 (Dual Reporting)

A

B

C

D

E

F

Hexadecimal ValueHexadecimal Value

Hexadecimal Value Key StrokesKey Strokes

Key StrokesKey Strokes

Key Strokes

0

1

2

3

4

5

PROGRAMMINGCONVERSIONSPROGRAMMINGCONVERSIONS

PROGRAMMINGCONVERSIONS

CL 30 - 3F & 48CL 30 - 3F & 48

CL 30 - 3F & 48

1919

19

SYS3316RF Installation Manual

Digit Position (4): Minutes - 1'sDigit Position (4): Minutes - 1's

Digit Position (4): Minutes - 1's

(1) (2) (3) (4) (5) (6)

BB

B44

44

411

11

133

33

322

22

288

88

822

22

266

66

6

Example: If the time were 26 seconds past 1:28 pm, B4 would be programmed

HOUR MINUTE SECOND

#

Digit Position (6): Seconds - 1'sDigit Position (6): Seconds - 1's

Digit Position (6): Seconds - 1's

Digit Position (3): Minutes - 10'sDigit Position (3): Minutes - 10's

Digit Position (3): Minutes - 10's

Digit Position (2): Hour - 1'sDigit Position (2): Hour - 1's

Digit Position (2): Hour - 1's

This command will set the hour, minute, and second in

the panel. The time is set in BCD (military time).

Previously stored data is not displayed during programming.

Command Location B4: Set Real-Time Clock (Hour, Minute, Second)Command Location B4: Set Real-Time Clock (Hour, Minute, Second)

Command Location B4: Set Real-Time Clock (Hour, Minute, Second)

(2) (3) (4) (5)

(1) (6)

BB

B44

44

4#

Digit Position (5): Seconds - 10'sDigit Position (5): Seconds - 10's

Digit Position (5): Seconds - 10's

Command Location B3: Set Real-Time Clock (Year, Month, Day)Command Location B3: Set Real-Time Clock (Year, Month, Day)

Command Location B3: Set Real-Time Clock (Year, Month, Day)

This command will set the day, month, and year in the

panel, and will not take effect until Command B4 is

programmed.

(2) (3) (4) (5) (6)

BB

B33

33

3

(1)

#

Previously stored data is not displayed during programming.

Digit Position (1): Year - 10'sDigit Position (1): Year - 10's

Digit Position (1): Year - 10's

Digit Position (2): Year - 1'sDigit Position (2): Year - 1's

Digit Position (2): Year - 1's

Digit Position (3): Month - 10'sDigit Position (3): Month - 10's

Digit Position (3): Month - 10's

Digit Position (4): Month - 1'sDigit Position (4): Month - 1's

Digit Position (4): Month - 1's

Digit Position (5): Day - 10'sDigit Position (5): Day - 10's

Digit Position (5): Day - 10's

Digit Position (6): Day - 1'sDigit Position (6): Day - 1's

Digit Position (6): Day - 1's

(1) (2) (3) (4) (5) (6)

BB

B33

33

399

99

955

55

500

00

044

44

411

11

122

22

2

Example: If the date were April 12, 1995, B3 would be programmed

YEAR MONTH DAY

#

Command Location A0: Test Report Countdown TimerCommand Location A0: Test Report Countdown Timer

Command Location A0: Test Report Countdown Timer

This command will set the time when the first Test Report is transmitted to the central

station. The panel will use this transmission time each time it's powered up or the CPU

is reset (unless Command Location A0 is reprogrammed).

Previously stored data is not displayed during programming.

(1)

AA

A00

00

0#

Digit Position (1): Set Test Report Countdown TimerDigit Position (1): Set Test Report Countdown Timer

Digit Position (1): Set Test Report Countdown Timer

NOTE: Refer to CL 2B for setting the

time interval between Reports.

0 = 1/4 hour

1 = 1/2 hour

2 = 1 hour

3 = 2 hours

4 = 3 hours

5 = 4 hours

6 = 6 hours

7 = 8 hours

8 = 10 hours

9 = 12 hours

0 = 14 hours

1 = 16 hours

2 = 18 hours

3 = 20 hours

4 = 22 hours

5 = 24 hours Example: The time is 1500 hours (3:00 pm). You want the first Test Report to

transmit at 0100 hours (1:00 am). 3:00 pm + 10 hours = 1:00 am.

Program the value "8" in Memory Location A0.

CL A0,CL A0,

CL A0, B3 and B4B3 and B4

B3 and B4B3 and B4

B3 and B4

Digit Position (1): Hour - 10'sDigit Position (1): Hour - 10's

Digit Position (1): Hour - 10's

2020

20

SYS3316RF Installation Manual

Each keypad comes with a Label Drawer and quick reference operating

label. Follow the diagram below to set up the Label Drawer for each

keypad.

KEYPAD LABEL DRAWERKEYPAD LABEL DRAWER

KEYPAD LABEL DRAWER

Example of drawer pulled

from the left

KEYPAD PLASTIC BASEKEYPAD PLASTIC BASE

KEYPAD PLASTIC BASE

Rotate keypad base soRotate keypad base so

Rotate keypad base so

drawer slot faces the correct directiondrawer slot faces the correct direction

drawer slot faces the correct direction

Plastic drawer

Plastic

drawer Plastic drawer and label slide into

drawer on back of keypad base

Example of drawer pulled

from the right

TO THE INSTALLERTO THE INSTALLER

TO THE INSTALLER

Regularmaintenanceandinspection(atleastmonthly)bytheinstallerand

frequent testing by the user are vital to the continuous and satisfying

operation of any alarm system. The installer should assume the respon-

sibilityfor developingandoffering aregular maintenanceprogramtothe

user, as well as acquainting the user with the proper operation and

limitations ofthe alarm systemand its componentparts. Recommenda-

tions must include a specific program of regular testing (at least

weekly) to insure that the system is operating properly at all times.

TELEPHONE LINE PROBLEMSTELEPHONE LINE PROBLEMS

TELEPHONE LINE PROBLEMS

Watchdog IndicatorWatchdog Indicator

Watchdog Indicator

Intheeventoftelephonelineproblems,disconnecttheSYSTEM3316by

removing the modular connector plug from the Telco interface jack. Do

notdisconnecttheconnectioninsidetheSYS3316RFcabinet.Doing

so will prevent the premise phones from operating. If your phone works

correctly after the control panel has been disconnected from the phone

line, the control panel has a problem and should be returned for repair.

Ifthephonedoesnotworkafteryou havedisconnectedthecontrolpanel

from the phone line, notify the telephone company and request prompt

repair. The user may not under any circumstance (in or out of

warranty) attempt any service or repairs on the SYS3316RF. The

controlpanelmustbereturnedtoC&KSYSTEMSoranauthorizedservice

agency for repairs.

1. Fill in the zone descriptions inside the label.

2. Mark "Y" or "N" to indicate if zones can be bypassed or not.

3. Determine if the drawer will slide from the right or left.

4. Peel the cover off the drawer glue.

5. Align the edge of the label with the edge of the drawer. Center the

label top to bottom.

6. Press the label onto the glue. Avoid trapping air bubbles under the

label.

7. Slide the drawer/label into the slot on the back of the keypad base.

Once the installation is complete, connect AC and DC power. Complete

programming,ifrequired. Test all panel operations.

DS1DS1

DS1

WATCHWATCH

WATCH

DOGDOG

DOG

The SYS3316RF is protected by an advanced circuit,

calledaWatchdogcircuit,thatconstantlymonitorsthe

microprocessor.

As long as the panel has power and is operating

normally,theWatchdogLED(DS1)onthecircuitboard

will flash. If the Watchdog circuit detects a failure, it will attempt to reset

thepanel.

If the panel does not operate properly, and the Watchdog LED no longer

flashes, call the C&K Technical Support Hotline at 1-800-227-8065 in

the U. S. or your local C&K representative.

FCC NOTICEFCC NOTICE

FCC NOTICE

InaccordancewithPart68oftheFCCRules,thisdevicemustnotbeused

on party lines or coin operated phone lines.

If you experience trouble with the telephone lines, disconnect the panel

fromthelinetodeterminethesourceofthetrouble.Ifitisdeterminedthat

thecontrol panelismalfunctioning, discontinueits useuntilthemalfunc-

tion has been corrected.

.

Connect the AC transformer to a different outlet so that the control

panel and radio/television are on different branch circuits.

.Re-orienttheradio/televisionantenna.

Relocate the control panel with respect to the radio/television.

.

Consultthedealer or anexperiencedradio/television technician

forhelp.

.

If this equipment does cause harmful interference to radio or television

reception,which canbe determinedby turningthe equipmentoffandon,

theuserisencouragedtotrytocorrecttheinterferencebyoneormoreof

thefollowingmeasures:

Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergy,

and if not installed and used in accordance with the instructions, may

causeharmfulinterferencetoradiocommunications.However,thereisno

guarantee that interference will not occur in a particular installation.

Thisequipmenthas been tested andfoundto comply withthelimits for a

ClassBdigitaldevices,pursuanttoPart15oftheFCCRules.Theselimits

are designed to provide reasonable protection against harmful interfer-

enceina residential installation.

WARNING: This device is intended to be installed by a

professionalalarminstaller.

Theuser shallbecautioned thatchanges ormodifica-

tionsnotexpresslyapprovedbyC&KSYSTEMScould

void the user's authority to operate the equipment.

CANADIAN EMISSION REQUIREMENTSCANADIAN EMISSION REQUIREMENTS

CANADIAN EMISSION REQUIREMENTS

This digital apparatus does not exceed the Class B limits for radio noise

emmissions from digital apparatus set out in the Radio Interference

Regulationsofthe Industry Canada.

Le présent appariel numérique n'émet pas de bruits radioélectriques

dépassantleslimitesapplicablesauxappareilsnumériquesdelaClassB

prescritesdansleRèglementsurlebrouillageradioélectriquesédictépar

leministèredesIndustrie Canada.

TESTINGTESTING

TESTING

C & K Systems SYS3316RF User manual

Popular Control Panel manuals by other brands
