C Prox CP002-EM User manual
C Prox Ltd (inc Quantek)
Unit 11 Callywhite Business Park, Callywhite Lane, Dronfield, S18 2XP
Network Proximity Reader
CP002-EM / CP002-EM-M
User Manual
Please read the manual carefully before installing this unit
1. Packing list
Name
Quantity
Remarks
Reader
1
Rubber plug
2
Φ6mm×30 mm, used for fixing
Self tapping screws
2
Φ4mm×28 mm, used for fixing
Please ensure that all the above contents are correct. If any are missing please notify us immediately.
2. Specification
Operating Voltage
9-16V DC
Output
Wiegand 26 / 34
Card type
EM 125KHz
Reading Distance
2-5 cm
Communication Distance
Up to 100M
Idle Current
<30mA
Operating Temperature
-45℃～60℃
Operating Humidity
10%- 90% RH
Waterproof
Conforms to IP68
Dimensions
110 x 48 x 20 mm
3. Installation
•Remove the back cover from the front using a Phillips screw driver.
•Use back plate to drill two holes on the wall for the self-tapping fixing screws and one for the cable.
•Put the two wall plugs into the fixing holes.
•Fix the back cover firmly on the wall with the two self-tapping screws.
•Thread the cable through the cable hole, connect the wires needed, wrap unused wire with
insulating tape isolated to prevent shortcircuit.
•Attach the reader to the back cover.
4. Wiring
5. Wiring Diagram
