C.T.M. HS-850 User manual

C.T.M. MOBILITY SCOOTER
C.T.M. MOBILITY SCOOTER
C.T.M. MOBILITY SCOOTER
8-Series Instruction Booklet
HS-850
HS-890

Instruction Booklet8-Series
TABLE OF CONTENTS
INTRODUCTION
IMPORTANT PRECAUTIONS
ELECTROMAGNETIC INTERFERENCE AND WARNINGS
IDENTIFICATION OF PARTS
OPERATING YOUR SCOOTER
DISASSEMBLING YOUR SCOOTER
ASSEMBLING YOUR SCOOTER
CHARGING THE BATTERIES
CARE AND MAINTENANCE
TROUBLESHOOTING
TECHNICAL SPECIFICATIONS
--------------------------------------------------------1
----------------------------------------2
----3
----------------------------------------5
-------------------------------------7
-------------------------------9
----------------------------------11
--------------------------------------12
----------------------------------------13
------------------------------------------------14
------------------------------------15

Instruction Booklet8-Series
If you have any question, you can contact :
C.T.M.HOMECARE PRODUCT, INC.
6191 Schaefer Ave Suite B Chino CA 91710
Tel : [phone] Fax : [phone]
E-Mail : [email protected] http : //www.ctmhomecare.com
or your local dealer:
INTRODUCTION
1
Thank you and congratulation on purchasing your new C.T.M. Mobility Scooter.
It is designed to provide you with transportation ability indoors and outdoors.
We pride ourselves on providing safe and comfortable products. Our goal is to ensure your
complete satisfaction. We sincerely hope you enjoy your C.T.M. Mobility Scooter.
Please read and observe all warning and instruction provided in owner's manual before you
operate with various convenient function of this scooter. Also, please retain this booklet for
future reference.

Instruction Booklet8-Series
IMPORTANT PRECAUTIONS
2
•Only one person at a time could ride a C.T.M. Mobility Scooter.
•Maximum load is HS-850 205 kgs/ 450 lbs & HS-890 227 kgs/ 500 lbs.
•Turn key off before getting on or off.
•Always drive carefully and be aware of others using the same area.
•Always use pedestrian crossings wherever possible. Take extreme care when crossing
roads.
•
Do not drive on slope exceeding 12 degree, and take extreme care when turning on slope.
•Do not use full power when turning to sharp corner.
•Take great care and drive in low speed when backing up, riding downhill or on uneven
surface, and climbing curb.
•Scooter may not operate well in high humidity.
•If you are caught in rain, it is handy to carry a scooter canopy. It offers complete
protection for your and scooter.
•Never put scooter in neutral when staying on slopes.
•Follow traffic laws when riding outside.

Instruction Booklet8-Series
2.Medium-range mobile transceivers, such as those used in police cars, fire trucks,
ambulances, and taxis. These usually have the antenna mounted on the outside of the
vehicle; and
3.Long-range transmitters and transceivers such as commercial broadcast transmitters
(radio and TV broadcast antenna towers) and amateur (HAM) radios
Other types of hand-held devices, such as cordless phones, laptop
computers, AM/FM radios, TV sets, CD players, and cassette players,
and small appliances, such as electric shavers and hair dryers, so far as.
we know, are not likely to cause EMI problems to your motorized scooter.
ELECTROMAGNETIC INTERFERENCE
AND WARNINGS
3
CAUTION: It is very important that you read this information regarding the possible
effects of Electromagnetic Interference on your motorized scooter.
Powered wheelchairs and motorized scooters may be susceptible to electromagnetic
interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources
such a radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and
cellular phones. The interference (from radio wave sources) can cause the motorized
scooter to release its brakes, move by itself, or move in unintended directions. It can also
permanently damage the motorized scooter control system. The intensity of the interfering
EM energy can be measured in volts per meter (V/m). Each motorized scooter can resist
EMI up to a certain intensity. This is called its "immunity level." The higher the immunity
level, the greater the protection. At this time, current technology is capable of achieving
at least a 20 V/m immunity level, which would provide useful protection from the more
common sources of radiated EMI. The immunity level of this motorized scooter model is
not known.
There are a number of sources of relatively intense electromagnetic fields in the everyday
environment. Some of these sources are obvious and easy to avoid. Others are not
apparent and exposure is unavoidable. However, we believe that by following the warnings
listed below, your risk to EMI will be minimized.
Some cellular telephones and similar devices transmit signals while
they are ON, even when not being used
The sources of radiated EMI can be broadly classified into three types :
1.Hand-held portable transceivers (transmitters-receivers) with the antenna mounted
directly on the transmitting unit. Examples include: citizens band (CB) radios, "walkie
talkie," security, fire, and police transceivers, cellular telephones, and other personal
communication devices

Instruction Booklet8-Series
4
There is no easy way to evaluate their effect on the overall immunity of
the motorized scooter.
Because EM energy rapidly becomes more intense as one moves closer to the transmitting
antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of
special concern. It is possible to unintentionally bring high levels of EM energy very close
to the motorized scooter control system while using these devices. This can affect
motorized scooter movement and braking. Therefore, the warnings listed below are
recommended to prevent possible interference with the control system of the motorized
scooter.
Motorized Scooter Electromagnetic Interference：
Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur
radio (HAM) transmitters, two-way radios, and cellular phones can affect motorized scooters.
Following the warnings listed below should reduce the chance of unintended brake release
or motorized scooter movement which could result in serious injury.
1.Do not operate hand-held transceivers (transmitters-receivers), such as citizens band
(CB) radios, or turn ON personal communication devices, such as cellular phones, while
the motorized scooter is turned ON;
2.Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming
close to them;
3.If unintended movement or brake release occurs, turn the motorized scooter OFF as
soon as it is safe;
4.Be aware that adding accessories or components, or modifying the motorized scooter,
may make it more susceptible to EMI; and
Warnings：
1.20 volts per meter (V/m) is a generally achievable and useful immunity level against
EMI (as of May 1994). The higher the level, the greater the protection.
2.The immunity level of this product is at least 20/Vm.
5.Report all incidents of unintended movement or brake release to the distributor listed
on the inside front cover of this manual. Note whether there is a source of EMI nearby.
Important Information：

Instruction Booklet8-Series
Thumb Lever
Tiller Angle
Adjustment
Seat Sliding
Slide Lever
Swivel Seat
With Head Rest
Storage Area
Seat Rotation
Lever
Reflectors
12" Front and Rear Wheels
Basket
Head light
Turn Signals
Front Bumper
Tiller Angle
Adjustment
Figure 1 - HS-890 Front View
Figure 2 - HS-890 Control Panel
Figure 3 - HS-890 Rear View
IDENTIFICATION OF PARTS
5
Before attempting to drive this scooter on your own, it is important that you familiarize
yourself with the controls, and how to operate
Battery Gauge
Armrest
Width
Adjustment
Thumbscrews
Rear
Turn Signals
Anti-tip Wheels
Rear Bumper
Storage
Area
Hi/Lo Speed Switch
Left Turn Signal Headlight
Horn Right Turn
Signal
Speed Dial Knob
Warning
Light
Power/Self-Diagnostic
Warning Light

Instruction Booklet8-Series
6
FUNCTION OF PARTS：
TOP CONTROL PANEL
•Speed Dial Knob
The Rabbit means fast and Turtle is slow. By turning this you control total speed
transferred to thumb controls.
•Battery Gauge
There is a meter shows batteries capacity status.
ADJACENT TO TOP CONTROL PANEL
•Thumb Lever
Pushing right thumb lever moves scooter forward. Pushing left thumb lever moves the
scooter backward. (This can be reversed if required by local dealer.) Releasing both,
engages automatic brake. These are also your accelerator. The further you depress
them, the faster you go. (Subject to the position of the Rabbit/Turtle control).
AT BASE OF STEERING TILLER
•Tiller Angle Adjustment
Pull downward the tiller adjustment to adjust tiller angle and release to lock at
comfortable position.
BELOW SEAT
•Seat Height Adjuster
There are three holes on seat tube to adjust seat height. Be sure the detent pin is fully
inserted at its new height before sitting.
•Armrest width Adjustment Thumbscrews
Loosen the two thumbscrews to adjust arm width; tighten again to lock in at desired
position.
•Legroom Adjuster
There are few holes on front and rear frame tube for adjusting legroom. Pull the toggle
latch to loosen and insert the detent pin to locate the position. Push the toggle latch
again to lock.
REAR BODY
•Rear Compartment Cover
Open the compartment Cover to access on board charger.
•Anti-tip wheels
Helps keep scooter from tipping over.
•Free-Wheeling Lever
When lever is in N (Neutral) position, scooter can be moved without power.
When lever is in D (Drive) position, scooter can be driven. Normal position is D.

Instruction Booklet8-Series
OPERATING YOUR SCOOTER
7
You could make the following adjustments to increase your comfort when driving.
•adjust seat height and location
•adjust armrest width to comfortable position.
•adjust legroom.
This scooter has automatic braking system. Release the thumb lever
and brake will stop scooter.
1.Before operating your scooter, check the following:
•free-wheeling lever in D
•speed dial knob is at turtle picture.
2.Sit on scooter and turn on key, Battery Gauge meter should be indicate at F.
The Self-Diagnostic Warning Light should not be blinking.
3.When your hands rest comfortably on handlebars, the thumb levers should be
within easy
reach. The right lever moves scooter forward, the left one moves it backward. When you
release both levers, scooter will stop.
4.Steer scooter by turning tiller toward the way you want to go.
5.Practice driving where there are is No obstacle. Start at the slowest speed and drive
forward and backward; make some turns. As you get more comfortable, you can increase
speed by turning speed dial toward picture of rabbit.
6.
If Battery Gauge indicates E, you should plan to recharge batteries very soon.
7.If scooter stops, locate the circuit breaker on top of battery pack. Push it and try
driving again.
8.When you are finished riding, turn off the key before getting off.
9.If you are finished riding for the day, immediately recharge batteries.
See CHARGING THE BATTERIES, page 12.

Instruction Booklet8-Series
In unlikely event of a panel display error, you need to re-set the display
system by cycling the on/off main switch. The display circuitry is independent
of the motor control system. A display console error does not affect scooter
speed control.
8
Keep in mind these rules：
•Release thumb levers and allow scooter to stop completely before changing from
forward to reverse, or reverse to forward.
•When turning to corner, swing front wheels widely, so back wheels will turn more tightly.
•Use scooter only where it is safe for walting.
•Drive in low speeds when reversing, riding dowhill, over rainp or curb, or on uneven
sukpace, downhills, ramps, curbs, or uneven surfaces.
Other Operating Information：
Hill climbing: You may need to use a higher speed. Turn to lower speed before going
downhill.
Down slopes: proceed with downward slopes slowly, and set speed control in proximity
of turtle. The closer speed control is set toward turtle, the slower scooter
travels. However, this scooter will not self accelerate down hills due to the
automatic braking, taking effect should you attempt to drive too fast.
Kerb climbing: Approach slowly from right angles to curb. A slight angle is permissible
with a 4-wheel scooter, but a direct approach is needed on a 3-wheel
scooter. Do not attempt greater than a 3" curb.
If Self-Diagnostic Warning Light starts to blink, identify problem from
chart on page 14 and take action.
If the scooter breaks down and must be moved, get off scooter, engage
Free-Wheeling Lever to N, push scooter slowly to a safe location, and
push lever back to D.

Instruction Booklet8-Series
Figure 4
Figure 4
Figure 5
Figure 5
Figure 6
Figure 6
Figure 7
Figure 7
Figure 9
Figure 9
Figure 8
Figure 8
(A)
(B)
(E)
(C)
(F)
(D)
9
DISASSEMBLING YOUR SCOOTER
The HS-890's compact design and light weight style make it fit easily into trunk or back
seat of most vehicle. No tools are necessary to disassemble scooter.
Remove seat by releasing Seat Rotation Lever (A) and then lift seat off. (See Fig. 4)
Remove rear shroud (B) off scooter. (See Fig. 5)
Unscrew two wire connectors (C) between front and rear units. (See Fig. 6)
Remove battery fixing Velcro (D). (See Fig. 7)
Detach battery power plugs (E). (See Fig. 8)
Remove batteries (F). (See Fig. 9)

Instruction Booklet8-Series
Figure 10
Figure 10
Figure 11
Figure 11
(G)
(H)
10
Remove front basket (G) and lower tiller by pulling tiller adjustment (H) and push tiller
doun. (See Fig. 10)
When fintsh instruction from figure (4) to figure (10) , there are 5 main parts. (See Fig. 11)

Instruction Booklet8-Series
11
ASSEMBLING YOUR SCOOTER
To assemble scooter, you can repeat disassembly directions in reverse. Abbreviated
directions are given below. Refer to Figures on pages 9 - 11 to locate parts.
1.Use the tiller adjustment to move tiller up and out of the way.
2.Place front basket.
3.Place battery pack in battery compartment.
4.Place seat on seat post and tighten seat locker knob.

Instruction Booklet8-Series
Keep in mind these rules：
•Fully charge batteries at least once a month, or more if you use scooter regularly.
Charge after each trip exceeding 3 kilometers.
•If storing your scooter for some time (1 month or more), make sure that batteries are
fully charged, and on returning, charge them again before using scooter.
•
Batteries will only give maximum performance after scooter has been used, and batteries
have been recharged up to 10 times. A bit like breaking in a new car.
Batteries must be charged before using the scooter for the first time and should be
recharged after each day use. You will need the scooter and the battery charger.
1.Insert battery charger cord into the charger connector on the charger output. Refer to
above figure for correct position
2.Plug the other end of the battery charger cable into a standard electrical outlet.
3.Turn the power on. Normally, The LED (Power) Light will turn on when electric current
passes.
4.Charging starts. During charging, LED (Charge) will indicate orange light, when it turns
to green light, that means well-charged.
5.LED indication
•LED(POWER) - GREEN LIGHT ON : Power On.
•LED(CHARGE) - ORANGE LIGHT ON : Charging / GREEN LIGHT ON : Fully Charged
6.Charger Trouble Shooting
(A)If LED (POWER) light is off
•Check the input voltage (115V/230V) is the same as you adjust.
•If light is still off, please check and repair the battery charger.
(B)If LED (CHARGE) light is off
•Check to see clips connection is correct.
•If the battery is fully charged, the LED (CHARGE) light will be off.
•If light is still off, the battery may be defective.
(C)If ORANGE light can turn to GREEN
•The battery can not be charged. Please check and recover it.
(D)If ORANGE light turns to GREEN immediately
•Check to see the battery is fully charged, if not, The battery may be defective
Check and recover it.
Each country may supply different
charger. The charging procedure
may be different from below.
If you require more details, please
contact your authorized dealer.
Be sure the scooter key is in the
OFF position
The time needed to recharge will vary depending on the depletion of the
batteries. Charging for longer than necessary will not harm the batteries.
They can not be overcharged.
12
CHARGING THE BATTERIES
Figure 12
Figure 12

Instruction Booklet8-Series
Cleaning Your Scooter：
If your scooter is dirty, use a damp or lightly soapy cloth to wipe it down. Do not use running
water to wash or rinse scooter in order to protect electrical parts. Polish with an automotive
liquid polish.
Maintaining Your Scooter：
All maintenance and repair of scooter should be done by an authorized dealer.
The following areas required periodic inspection:
•Tire pressure between 30-50 lbs
•All electrical connections are firmly attached
Storing Your Scooter：
Between uses, your scooter is best stored in a dry location.
13
CARE AND MAINTENANCE

Instruction Booklet8-Series
14
TROUBLESHOOTING
Number of
Flashes Problem Solution
1
2
3
4
5
6
7
8
9
Battery needs
recharging Recharge the batteries soon.
Must recharge before using. Check
battery condition and connections.
Check battery condition and connections.
Contact your authorized dealer to check
your battery charger.
Contact your authorized dealer.
Contact your authorized dealer.
Contact your authorized dealer.
Contact your authorized dealer.
Contact your authorized dealer.
Contact your authorized dealer.
Battery voltage too low
to operate scooter
Short in motor
Brake malfunction
Thumb lever not in
neutral
Thumb lever malfunction
Motor problems
Other internal errors
Battery voltage too high
Here are some suggestions about solving problems you may have with your scooter. There
is a Self-Diagnostic Warning Light on the Control Panel. To check the Self-Diagnostic
Warning Light, turn on the key and count the number of blinks on the Warning Light.
Other Problems
Low tire pressure: pump up tires to 30-50 lbs.
During charging, light on charger does not change to green: Contact your authorized dealer.
Scooter will not move when key is turned on:
1.Check Power Reserve Indicator on control panel, it should be lighting in green, yellow, and
red zones.
2.Check Self-Diagnostic Warning Light, it should be steady. If it is flashing, see chart above
for problem identification.
3.Check all electrical connections to be sure they are tight.
4.If none of above correct problem, contact your authorized dealer.

Instruction Booklet8-Series
TECHNICAL SPECIFICATIONS
15
Overall Length
Overall Width
Overall Height
Wheels: Front
Wheels: Rear
Weight w/ Batteries
Max. Speed
Weight Capacity
Ground Clearance
Grade Climbable
Curb Climbing
Turning Radius
Suspension
Brake
Seat Type
Seat Width
Motor Size
Battery Size
Battery Weight
Travel Range
Battery Charger
Electronics
57.1"
27"
42.9"
13"
13"
214 lbs
9.3 mph
450 lbs
3.3"
12 degree
2.4"
68.1"
Front & Rear
Electro-Mechanical
19"
700W 5400r.p.m
(2) 12V . 50Ah
69 lbs
23.4 Miles
5A Off Board
60.2"
27"
42.1"
13"
13"
241 lbs
8 mph
500 lbs
3.3"
10 degree
2.8"
68.1"
Front & Rear
Electro-Mechanical
22"
700W 5400r.p.m
(2) 12V . 50Ah
69 lbs
23.4 Miles
5A Off Board
SPECIFICATIONS HS-850 HS-890
On/Off Key Switch, Battery Level Indicator,
Speed Control Knob
*Subject to change without notice.
Sliding and Swivel RecliningCaptain W/Headrest
