cable matters 202049 User manual

USB 3.0 to DisplayPort™4K Adapter
Model 202049
User Manual
[e-mail]
• Locate instructions and driver information at:
www.cablematters.com/dl/202049
• Locate troubleshooting information at:
kb.cablematters.com (search for 202049)

Table of Contents
1. INTRODUCTION.....................................................................1
1.1 Introduction
1.2 Copyright and Trademarks
1.3 FCC Compliance Statement
2. PRODUCT OVERVIEW
2.1 Package Contents
2.2 Product Description ........................................................................ 2
2.3 Product Features
2.4 System Requirements
3. CONNECTION AND OPERATION.................................................. 3
3.1 Installation Checklist
3.2 Driver Installation
3.3 Connection Instructions.................................................................. 4
3.4 Configuring a monitor with Windows OS ....................................... 5
3.5 Troubleshooting Notes ................................................................... 8
4. TECHNICAL SPECIFICATIONS............................................ 9
5. WARRANTY AND SUPPORT ............................................. 10
5.1 Customer Support and Contact Information
5.2 Warranty Information
5.3 Limitations of Liability
USB 3.0 to DisplayPort™4K Adapter
www.cablematters.com

1
www.cablematters.com
USB 3.0 to DisplayPort™4K Adapter
1. Introduction
1.1 Introduction
Thank you for your purchase from Cable Matters® Inc., the ‘Reliable Connectivity’ company. This
User Manual provides an overview of the features and installation of your new:
USB 3.0 to DisplayPort™4K Adapter
Please read these instructions carefully before connecting, operating or configuring this product.
Please keep this manual for future reference.
Contact [email protected] for questions or product support.
1.2 Copyright and Trademarks
Specifications are subject to change without notice. Cable Matters is a registered trademark or
trademark of Cable Matters Inc. All rights reserved. All other trademarks are the property of their
respective owners.
Windows is a registered trademark of Microsoft Corporation in the U.S. and other countries.
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association
(VESA®) in the United States and other countries.
1.3 FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
2. PRODUCT OVERVIEW
2.1 Package Contents
Please check that the following items are contained in the package:
USB 3.0 to DisplayPort Adapter
Quick Start Guide

2
www.cablematters.com
USB 3.0 to DisplayPort™4K Adapter
2.2 Product Description
The Cable Matters USB 3.0 to DisplayPort Adapter provides an easy way
to connect a 4K monitor with DisplayPort to a computer with USB. Add a
monitor to a computer without DisplayPort or add an additional monitor
when the other video ports on your computer are occupied.
2.3 Product Features
• Adapter converts a USB port to DisplayPort to connect a monitor
• Supports Main, Extended, or Mirrored display modes
• Video Resolution support up to 3840 x 2160 @ 30 Hz
• Enable an older computer to connect a 4K monitor
• Portable and lightweight adapter is easy to carry and store
• Simple installation with drivers from the Cable Matters website
2.4 System Requirements
Computer: USB 3.0 computer port (2.0 is not recommended)
Minimum i5 Core 2+ GHz CPU / 4 GB Ram
i7 Core (or similar) for video playback
Internet access for driver download
Supported OS: Windows 7, 8, 8.1, 10 (32 or 64 bit)
Monitor: DisplayPort input port and DisplayPort cable
(DisplayPort 4K rated cable is required for UHD)

3
www.cablematters.com
USB 3.0 to DisplayPort™4K Adapter
3. Connection and Operation
3.1 Installation Checklist
• A DisplayPort cable is required (sold separately)
• Use a high quality DisplayPort cable in the shortest length needed
• 4K UHD resolution support requires a 4K rated DisplayPort cable
• Disconnect any other cables from the computer to the monitor
• Close all unnecessary programs before installing the drivers
• Be prepared to reboot your computer after the driver installation
• Connect to a USB 3.0 extension cable for more flexibility
3.2 Driver Installation
1) If the Adapter is not recognized, download the drivers from
cablematters.com/downloads
2) Click on the setup application and follow the instructions
3) Reboot your computer after the installation is complete
Installation Notes:
• DisplayLink software installer checks for any incompatible drivers
• Windows and Mac users with the latest OS versions can check for
updated drivers from the Cable Matters download link
• Consult kb.cablematters.com (search for 202049) for more
information

4
www.cablematters.com
USB 3.0 to DisplayPort™4K Adapter
3.3 Connection Instructions
CONNECTING TO A MONITOR WITH DISPLAYPORT
1) Directly connect the adapter to the computer
2) Install the DisplayLink software drivers, if needed
3) Connect a DisplayPort cable to the monitor and the adapter
4) Configure the video from the computer
5) Select the video input from the monitor
6) Configure the audio from the computer
7) Select the audio input from the monitor

5
www.cablematters.com
USB 3.0 to DisplayPort™4K Adapter
3.4 Configuring a monitor with Windows OS
Method 1: Open the DisplayLink utility from the Taskbar
notification area in Windows
COMPUTER CONFIGURATION
1) Select a Screen Resolution that is compatible with both your computer
and the connected monitor
2) Set the connected monitor as the Main Monitor, an Extended Desktop,
or a Mirrored Display
3) Select the Audio Setup to configure the sound from Windows
• Click and drag on an application window to view it on the connected
monitor in Extended Mode
CONNECTED MONITOR CONFIGURATION
1) Select the DisplayPort input on the connected monitor
2) Select the audio input from the monitor audio menu

6
www.cablematters.com
USB 3.0 to DisplayPort™4K Adapter
Method 2: Use the Windows Desktop
Video Settings
1) Right-click on the desktop and select Screen resolution
2) Select Duplicate these displays
3) Click on Advanced settings to change the display refresh rate
Sound Settings
1) Confirm the sound output from the Control Panel > Sound menu
2) Select the connected monitors
from the Playback tab
3) Adjust the volume from the con-
nected monitor
NOTE: Refer to the user manual of your monitor for changing the video
and sound settings. Verify that audio is supported by the connected
monitor

7
www.cablematters.com
USB 3.0 to DisplayPort™4K Adapter
3.6 Troubleshooting Notes
CABLING
• Check that all cable and adapter connections are secure
• Inspect the adapter and cable to check that no pins are damaged
• Test the DisplayPort cable by connecting it with other equipment
• Test the adapter with a different computer or port on the computer
COMPUTER SOURCE
• Check for updated OS, USB, or video graphics card drivers
• Uninstall any other video graphics software
• Try different video resolution settings supported by the monitor
• Verify that the audio from your computer is not muted or extremely low
• Reboot the computer after making multiple changes
• A USB 2.0 port will not support a 4K video resolution
• NOTE: Playback of encrypted Blu-ray disks or iTunes is not supported
CONNECTED MONITOR
• Select the DisplayPort input from the connected monitor menu
• Select a video resolution setting supported by your computer
• Adjust the audio level from the monitor menu
• Consult the monitor manufacturer technical support for audio and video
setting information
Contact [email protected] with a description of your
hardware configuration and your computer OS

8
www.cablematters.com
USB 3.0 to DisplayPort™4K Adapter
4. TECHNICAL SPECIFICATIONS
Computer Connector USB 3.0 - Male
Video Port DisplayPort - Female
OS Support USB Host Windows 7, 8, 8.1, 10
Chipset/Drivers DisplayLink
Video Resolution Support Up to 3840 x 2160 @ 30Hz
Audio Output Support 2 Channel LCPM
Operating Temperature 0 ℃to +70℃@ 10% to 85 % RH
Storage Temperature -10℃to +80℃@ 5% to 90 % RH
Power USB bus-powered
Housing Size (H x W x L) 3.3 x 1.7 x 0.5 Inches
Cable Tail Length 4 Inches
Weight 1.6 Ounces
Certifications C E, FCC
Warranty Limited One-Year
Note: Specifications are subject to change without notice

9
www.cablematters.com
USB 3.0 to DisplayPort™4K Adapter
5. Warranty and Support
5.1 Customer Support and Contact Information
Cable Matters offers lifetime technical support as an integral part of our commitment to
provide industry leading solutions.
Email us with any questions at [email protected].
5.2 Warranty Information
This product is backed by a limited one-year warranty. The warranty covers parts and
labor costs only. Cable Matters does not warrant its products from defects or damages
arising from misuse, abuse, or normal wear.
5.3 Limitation of Liability
In no event shall Cable Matters Inc. (including their officers, directors, employees or
agents) be liable for any damages (whether direct or indirect, special, punitive, inci-
dental, consequential, or otherwise), loss of profits, loss of data, loss of business, or
any pecuniary loss, arising out of, or related to the use of this product exceeding the
actual price paid for the product (as allowed by state law).

10
www.cablematters.com
USB 3.0 to DisplayPort™4K Adapter
v2 03/2019
