21-C Conveyor
Operation and Maintenance
Manual

Page 1
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Table of Contents
Precautionary Steps........................................................................................................ 2
Installation Instructions.................................................................................................... 3
System Overview ............................................................................................................ 5
Important Cleaning Information....................................................................................... 6
Adjustments .................................................................................................................... 7
Lubrication....................................................................................................................... 7
Motor Controls................................................................................................................. 7
Lacing Instructions .......................................................................................................... 8
Belt Repair Tool .............................................................................................................. 9
Nomenclature for the Overlapping Belt Splicing Tool.................................................... 10
Instructions for using the Overlapping Belt Splicing Tool .............................................. 11
Care and Cleaning of Stainless Steel ........................................................................... 15
Product Warranty .......................................................................................................... 17
Parts List ....................................................................................................................... 18

Page 2
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Precautionary Steps
1. Housing doors must be in place when conveyor is in operation in order to prevent bodily injury to operating
personnel.
Conveyor must NOT be operated without housing doors in place.
2. Turn conveyor circuit breaker OFF when performing maintenance on equipment. Since equipment acts as a
conductor of electricity, respect all grounding and bonding codes.
3. When inspecting operation of conveyor, keep away from pulleys, motors, etc.
4. A word to the wise! Limit switches supplied with equipment are there for specific purposes: such as safety, tray
control, wear prevention, etc. Circumventing the operation of these switches can cause personal injury and
conveyor damage, and may void warranty and manufacturer's liability.
5. Conveyor wiring is water-tight but will not withstand direct hosing down of electrical parts. Such hosing is
hazardous to operating personnel; it will cause severe damage to the equipment resulting in costly repairs and
long periods of down time, and will void the warranty
6. When the conveyor is off, rotating the motor by hand can cause damage to electrical controls if the motor leads
remain attached.
7. Important:
Detergent or disinfectants containing chlorine, ammonia or iodine must not be used on the Caddy non-steel
components. Use of these chemicals will cause serious deterioration of plastic parts, and most importantly the
belt itself.
CAUTION
 Never place your hands where you cannot see them!
 Do not place your hands anywhere in the belt drive area!
 Do not spray water directly onto motor, wires or any electrical parts.
 Do not block limit switches with an object in order to stop conveyor! If trays are coming too fast, slow the
conveyor down!
 Do not permit materials to clog drains!

Page 3
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Installation Instructions
This system must be installed and serviced by qualified electrical maintenance personnel familiar with
electrical and mechanical systems. This manual is designed to give general information on the electrical
and mechanical operation of this conveyor system. The system must be installed as per the applicable
electrical codes.”
The following Grounding Instructions are dependant upon the ratings and power connection of each
system.
GROUNDING INSTRUCTIONS (Any permanently connected systems)
This appliance must be connected to a grounded, metal, permanent wiring system; or an equipment-
grounding conductor must be run with the circuit conductors and connected to the equipment-grounding
terminal or lead on the appliance.
GROUNDING INSTRUCTIONS (Systems rated 120 V, 15 A or less; cord connected)
This appliance must be grounded. In the event of malfunction or breakdown, grounding provides a path of
least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a
cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and
ordinances.
DANGER - Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
The conductor with insulation having an outer surface that is green with or without yellow stripes is the
equipment-grounding conductor. If repair or replacement of the cord or plug is necessary, do not connect
the equipment-grounding conductor to a live terminal. Check with a qualified electrician or serviceman if
the grounding instructions are not completely understood, or if in doubt as to whether the appliance is
properly grounded. Do not modify the plug provided with the appliance – if it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
This appliance is for use on a nominal 120 V circuit, and has a grounding plug that looks like the plug
illustrated in sketch A in the following figure. A temporary adaptor, which looks like the adaptor illustrated in
sketches B and C, may be used to connect this plug to a 2-pole receptacle as shown in sketch B if a
properly grounded outlet is not available. The temporary adaptor should be used only until a properly
grounded outlet can be installed by a qualified electrician. The green colored rigid ear, lug, and the like,
extending from the adaptor must be connected to a permanent ground such as a properly grounded outlet
box cover. Whenever the adaptor is used, it must be held in place by the metal screw.

Page 4
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Grounding Methods
To Reduce the Risk of Electric Shock, this appliance has a polarized plug (one blade is wider than the
other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the
plug in any way.
GROUNDING INSTRUCTIONS (Systems rated more than 120V and/or more than 15 A; cord connected)
This appliance must be grounded. In the event of malfunction or breakdown, grounding provides a path of
least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a
cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and
ordinances.
DANGER - Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
The conductor with insulation having an outer surface that is green with or without yellow stripes is the
equipment-grounding conductor. If repair or replacement of the cord or plug is necessary, do not connect
the equipment-grounding conductor to a live terminal. Check with a qualified electrician or serviceman if
the grounding instructions are not completely understood, or if in doubt as to whether the appliance is
properly grounded. Do not modify the plug provided with the appliance – if it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
This appliance is for use on a circuit having a nominal rating more than 120 V (or This appliance is rated
more than 15 A and is for use on a circuit having a nominal rating of 120 V), and is factory equipped with a
specific electric cord and plug. No adapter should be used with this appliance. If the appliance must be
reconnected for use on a different type of electric circuit, the reconnection should be made by qualified
service personnel; and after the reconnection, the appliance should comply with all local codes and
ordinances.

Page 5
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
System Overview - Model 21-C Conveyor
This instruction manual is specifically designed to aid in the installation and maintenance of the 21-C Caddy
Conveyor system.
Simplicity of design, in this Conveyor model, eliminates the need for much of what would be described as routine
maintenance procedures. There are no drive shafts, sprockets or conventional bearings to adjust or lubricate.
Simple care and cleaning, with a mild detergent, is all that is necessary to insure proper operation.
The 21-C is made of two separate DURA-SAN belts, driven directly from the same gearbox. The belt runs through a
series of pulleys that smoothly guide the belt while holding it firmly in place. The pulleys have sealed stainless steel
bearings that require little lubrication. The belt is circular in profile. The circular shape fits well into the grooved
pulleys and provides a tight fit with no slippage, when properly adjusted. The belt is fused using an overlapping belt
splicing tool, making it one continuous belt.
The DURA-SAN belt has outstanding tensile strength, flex-life and resistance to wear. The DURA-SAN belt, as well
as other items made with base plastic or poly material, can be subject to attack by chemical agents. Cleaning agents
containing ammonia, chlorine, bleach, quating agents or other harsh chemicals must be
avoided. Use of these products can cause belt damage and will void the warranty.
Caddy Corporation recommends cleaning the 21-C Conveyor with the following:
 Ivory liquid (1% solution).
 Tide detergent (1% solution).
 Any comparably mild detergent.
Then rinse with copious amounts of water.

Page 6
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Important Cleaning Information
Cleaning: The conveyor must always be in the off position while cleaning the conveyor. Clean the bed surface with
a mild soap and water. Always rinse the belts thoroughly after washing. Remove all covers for cleaning. The tail
cover should be removed at least weekly for cleaning around the tail pulleys. Also a light oil should be applied to the
pulley bearings alter cleaning.
Conveyor must not be operated without the covers in place.
The turn covers, (if applicable), should also be removed weekly or as needed, for cleaning. This is very important
because without the proper cleaning of the turn pulleys they will become clogged with dirt and cease to rotate,
putting additional strain on the belts. The turn covers are removed by loosening the four screws and removing the
two drive belts (the exposed belts), from the grooves in the turn cover. After cleaning, reinstall covers prior to start-
up.
Do not operate conveyor without the tail turn cover in place.
NOTICE
The use of cleaning agents containing AMMONIA,
CHLORINE, and BLEACH as well as QUAT agents
MUST BE AVOIDED
The use of cleaning agents containing the chemicals
listed above will damage any product made of
Plastic.
C A U T I O N
The use of abrasive cleaners when cleaning the conveyor, such as Comet, Dutch Cleanser or any other gritty
compound will damage the stainless steel.
Damage caused by these cleaning agents may not become apparent for several months. Their use will void the
warranty and any necessary repairs will be charged to the user.
A good method of determining if a cleanser can be used on the conveyor is to dissolve a cup of it in a bucket of
water. If the cleanser does not dissolve completely it will damage the conveyor.

Page 7
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Adjustments: The DURA-SAN belt has an inner cord of many strands that seriously limit stretch. However, over a
period of time some adjustment may be necessary. Caddy Corporation has allowed for this stretch with two
adjusting points. The primary slack adjusting point is under the tail cover. The tail cover is secured by one screw.
After the screw is removed and the cover is lifted off, two pulleys with threaded rods will be obvious. With the
conveyor in the OFF position, to increase tension on the belts simply tighten the lock nuts until desired tension is
achieved.
Be careful not to over tighten the belts, the threaded rod should not be moved more than half an inch at one time. If
you require more adjustment than half an inch, there may be another problem. Call the Caddy Corporation Service
Department (856-467-4222 ext. 331) with any questions.
The second slack adjustment point is at the pulleys in the motor compartment. There are two pulleys mounted on
the top of the gear box. These pulleys can be moved up in three steps increasing tension on the belts.
The adjustment at the tail should be maximized prior to moving the pulleys in the motor compartment. When it
becomes necessary to move the adjustment pulleys in the motor compartment, relax the tension adjustment at the
tail, make the adjustment in the motor compartment then reapply tension at the tail, as needed.
Caution: The use of cleaning agents containing ammonia, chlorine or bleach should be avoided.
Lubrication: There are no grease fittings anywhere on this conveyor. A light oil (3 in 1 oil or sewing machine oil)
may be applied to the pulley bearings periodically. The gear box is sealed and it is seldom necessary to add gear oil.
However, it is a good idea to check the oil level after the first 90 days of operation and then every three months
following. Add oil as needed (Mobile 600 W cylinder oil or any equivalent gear box oil is acceptable).
Caution: Conveyor must in the OFF position for any inspection.
Motor Controls: Caddy Corporation currently provides a DC motor control (Caddy part number 6235-02). This
controller offers a wide range of selections. We, for the purposes of this manual, will concern ourselves with two,
speed and torque. The speed is regulated through a potentiometer which at it highest setting will run the conveyor at
forty feet per minute. The speed can be reduced to whatever setting is comfortable for your operation.
The current limit (CL/Torque adjustment) CL circuitry, is provided to protect the motor and control against overloads.
The CL also limits the inrush current to a safe level during startup. The CL is factory set to approximately 1.5 times
the full load rating of the motor. The trimpot is preset at the factory but may need to be adjusted, as time goes on,
due to resistance build up.
The normal Trimpot settings are as follows, (expressed as a % of full clockwise rotation)
MIN (minimum speed): 0%
MAX (maximum speed): 60%
IR (IR compensation): 15%
CL (current limit/torque): 65%
ACCEL (acceleration start): 50%

Page 8
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Lacing Instructions - Belt Assembly For 21-C Drive

Page 9
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Belt Repair Tool
The tool on this page is for repairing the ½” diameter, round, Dura-San Conveyor Belt
Permanent Belt Repairs
Proper splicing requires “overlapping” the two belt ends.
Use Caddy Overlap Belt Repair Tool #6394-03.
Please refer to:
 Nomenclature for the Overlapping Belt Splicing Tool
 Instructions for using the Overlapping Belt Splicing Tool
Contact your local service agency, or the Caddy Service Department, for additional information.

Page 10
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Nomenclature for the Overlapping Belt Splicing Tool (6394-03)
A Power Cord K Capstan
B Thermocouple L Holding Clamp
C Control Box M Holding Clamp
D Main Power Cord N Clamp Thumb Nut
E Power Switch O Clamp Thumb Nut
F Power Indicator Light P Heating Assembly Knob
G Heating Indicator Light Q Hold Down Pin
H Thumb Nut R Heating Tip
I Thumb Nut S Slide Knob
J Belt Shears T Flash Cutters
Note: Caddy Corporation recommends making a practice weld using a short piece of belt before making a final
weld on the conveyor.

Page 11
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Instructions for Using the Overlapping Belt Splicing Tool (6394-03)
Before attempting a splice, the belt must be cut to size. When sizing the belt, make sure that the belt is laced
properly. The belt must be on each pulley so that the proper size of the belt can be determined. Once it is
determined that the belt is laced properly, pull the two belt ends together, as tight as possible by hand and allow
them to overlap 1 1/4 inches, then cut excess. If you do not have enough belt to overlap the 1 1/4 inches required to
make a splice, a piece of belt must be added. Caddy Corporation suggests adding, at least, a ten foot piece to keep
the splices that far apart. Simply add the ten foot piece and then size as indicated. Once the correct sizing has been
determined, continue with the belt splicing operation.
1. Plug power cord A and thermocouple B into control box C. Plug main power cord D into electrical outlet or
extension cord.
2. Set the temperature control dial (Fig. 2) to 450 degrees F. Turn on power switch E. Red power light F will
remain on, indicating that there is power to the unit. Indicator light G will stay on while tip is heating. DO
NOT start welding until this light, (indicator light G) goes out the first time.
Fig. 2
3. Using shears J, cut to the correct belt length and add 1½ inches for the overlap. Cut each end on
approximately 25 degree opposite angles.

Page 12
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
4. Screw capstan K all the way open. Fit the first end of the belt into the rear die. The Caddy Belt should
overhang the die approximately 1/16 of an inch, and the angle on belt should line up with the angle on the
die. Tighten clamp by turning thumb nut O. Now fit the other end of the belt into front (or sliding) die. This
belt is situated exactly the same as the rear belt. NEVER OVERHANG THE BELT MORE THAN 1/8 OF
AN INCH.

Page 13
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
5. Position Teflon heating tip R above and between the dies. Push down on knob P and press pin Q in to hold
heating assembly down.
6. Screw capstan K forward until both overlapping surfaces contact heating tip R. Continue turning capstan as
belt ends melt. Apply just enough pressure to squeeze the melted material out of the welding area.
Continue until capstan stops. DO NOT OVER TIGHTEN.
7. After approximately 20 seconds, loosen capstan one turn. Place left hand on side knob S. With your right
hand pull pin Q, which will let the heating assembly pop up and clear the weld area. Slide the front die
home immediately with slide knob S. Quickly spin capstan in and tighten until the stop is reached. It is
IMPORTANT that this sequence is done quickly.

Page 14
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
8. As weld cools use a clean, dry cloth to wipe excess material from the hot tip. CLEAN HEATING TIP
BETWEEN EVERY WELD. DO NOT SCRATCH ITS TEFLON COATING.
9. After approximately five minutes, remove the belt from the welder.
10. Using the special flat-edged flash cutters T, trim excess material from around the weld area.
NOTE: These flash cutters are not standard diagonal cutters and should only be used for trimming the belt.
NOTE: Should the use of a Belt Tool become necessary, the Overlapping Belt Splicing Tool is available from Caddy
Corporation.
Note: This 21-C Conveyor is not designed to convey Bus Boxes/Tote Boxes.
Note: The 21-C Conveyor is designed and fabricated for your specified tray size.

Page 15
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Care and Cleaning of Stainless Steel Equipment
Contrary to popular belief, stainless steels ARE susceptible to rusting and pitting.
Corrosion on metals is everywhere. It is recognized quickly on iron and steel as unsightly yellow/orange rust.
Such metals are called “active” because they actively corrode when their atoms combine with oxygen to form
rust.
Stainless steels are passive metals because they contain other metals, like chromium, nickel and manganese
that stabilize the atoms.
Chromium provides an invisible passive film that covers the steel’s surface acting as a shield against corrosion. As
long as the film is intact and not broken or contaminated, the metal is passive and stainless. If the passive film of
stainless steel has been broken, equipment starts to corrode. At its end, it rusts.
The Enemies of Stainless Steel
There are three basic things which can break down stainless steel’s passivity layer and allow corrosion to occur.
1. Mechanical Abrasion - Steel pads, wire brushes and scrapers are prime examples of things that will
scratch a steel surface.
2. Water and Deposits - Water has varying degrees of hardness. Depending on the area you live in, you may
have hard or soft water. Hard water may leave spots, and when heated, leave deposits that will break down
the passive layer and rust stainless steel. Other deposits from food preparation and service must be
properly removed.
3. Chlorides - Chlorides are found nearly everywhere. They are in water, food and table salt. Some of the
worst chloride perpetrators come from household and industrial cleaners.
Here are a few steps that can help prevent stainless steel rust and pitting.
1. Use the proper tools.
When cleaning stainless steel products, use non-abrasive tools. Soft cloths and plastic scouring pads will
not harm steel’s passive layer. Stainless steel pads also can be used but the scrubbing motion must be in
the direction of the manufacturers’ polishing marks.
2. Clean with the polish lines
Some stainless steel comes with visible polishing lines or “grain”. When visible lines are present,
always scrub in a motion parallel to the lines. When the grain cannot be seen, play it safe and use a
soft cloth or plastic scouring pad.
3. Use alkaline, alkaline chlorinated or non-chloride containing cleaners.
While many traditional cleaners are loaded with chlorides, the industry is providing an ever-increasing
choice of non-chloride cleaners. If you are not sure of chloride content in the cleaner used, contact your
cleaner supplier. If your present cleaner contains chlorides, ask your supplier if they have an alternative.
Avoid cleaners containing quaternary salts; they can attack stainless steel and cause pitting and rusting.
4. Treat your water.
Though this is not always practical, softening hard water can do much to reduce deposits. There are certain filters
that can be installed to remove distasteful and corrosive elements. To insure proper water treatment, call a
treatment specialist.

Page 16
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
5. Keep your food equipment clean.
Use alkaline, alkaline chlorinated or non-chloride cleaners at recommended strength. Clean frequently to
avoid build-up of hard, stubborn stains. If you boil water in stainless steel equipment, remember the single
most likely cause of damage is chlorides in the water. Heating cleaners that contain chlorides have a similar
effect.
6. Rinse, rinse, rinse.
If chlorinated cleaners are used, rinse and wipe equipment and supplies dry immediately. The sooner
you wipe off standing water, especially when it contains cleaning agents, the better. After wiping
equipment down, allow it to air dry; oxygen helps maintain the stainless steel’s passivity film.
7. Never use hydrochloric acid (muriatic acid) on stainless steel.
Review
 Stainless steels rust when passivity (film-shield) breaks down as a result of scrapes, scratches,
deposits and chlorides.
 Stainless steel rust starts with pits and cracks.
 Use the proper tools. Do not use steel pads, wire brushes or scrapers to clean stainless steel.
 Use non-chlorinated cleaners at recommended concentrations. Use only chloride-free cleaners.
 Soften your water. Use filters and softeners whenever possible.
 Wipe off cleaning agents and standing water as soon as possible. Prolonged contact eventually causes
problems.

Page 17
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
WARRANTY
Products manufactured by Caddy Corporation are warranted to the original purchaser as follows:
Mechanical components are warranted to be free from defects in material and workmanship under normal
use, storage and service for a period of one year from the date of installation or eighteen months from
factory shipment, whichever occurs first.
Electrical components are warranted to the original purchaser to be free from defects in material and
workmanship under normal use, storage and service for a period of ninety days from the date of shipment.
Caddy Corporation shall repair or replace, at our discretion, any part or product which we determine to be
defective during the warranty period.
Under no circumstances will Caddy Corporation honor any repair or back charges by any party regardless
of whether such equipment is within the warranty period, unless the Service Department of Caddy
Corporation has authorized such work in writing.
If the equipment is repaired or altered in any way whatsoever by any person without prior written consent
by Caddy Corporation, this warranty shall not apply.
The following are NOT covered under this warranty:
˗ Normal wear on parts, such as bulbs, gaskets, etc.
˗ Defects or damages resulting from accidents, alterations, abuse or misuse of equipment and/or
any of its components.
- Damage of electrical components resulting from connecting the equipment to any power
supply other than specified on the nameplate, or resulting from unauthorized altering of the
equipment.
- Damage from water conditions causing malfunction of electric components and/or control
equipment.
There is no other express warranty.
Any and all implied warranties are excluded to the extent permitted by law. Implied warranties, when
included by law, including those merchantability and fitness for a particular purpose, are limited to one
year from the date of shipment.
Liability for consequential damages under any and all warranties is excluded. This warranty is the buyer’s
exclusive remedy.
It is Caddy’s policy to constantly improve the design and manufacture of our products. Accordingly, all
equipment is subject to change consistent with such policy without prior notice and some items may be
discontinued without obligation.

Page 18
509 Sharptown Road P.O. Box 345 Bridgeport, NJ 08014
Email: [email protected] Fax: [phone]
Internet: http://caddycorp.com Phone: [phone]
Parts List
Series 21-C Soiled Tray Conveyors
See electrical drawing or contact Caddy.
Please have conveyor Model, Serial Number and facility location prior to contact.
Part Description Part Number
Belt, Round, 1/2" Dia. Dura-San 6843-05
5" Idler Pulley 6881-01
7 1/2" Idler Pulley 6881-02
Spacer, Pulley (1 Per Idler Pulley) 6892-01
Tensioner Assembly, Tail End 6960-01
Double Drive Pulley 1" Bore (1/2 HP Motor) 6880-01
Double Drive Pulley 1 1/8" Bore (3/4 HP Motor) 6880-02
Belt Guide Short (2" Long) 6865-02
Belt Guide, Long (7" Long) 6909-01
Return Channel Cover (48" Long, 2 Finger Holes) 6885-01
45° and 90° Turn Components
Part Description Part Number
21-C Turn, Drive Pulley (3 Req'd. Per 45° Turn) (6 Req'd. Per
90° Turn)
6887-01
21-C Turn, Drive Bushing (3 Req'd. Per 45° Turn) (6 Req'd. Per
90° Turn)
6889-01
21-C Turn, Return Pulley (2 Req'd. Per 45° Turn) (6 Req'd. Per
90° Turn)
6888-01
21-C Turn,Return Bushing (2 Req'd. Per 45° Turn) (6 Req'd. Per
90° Turn) 6890-01
Turn Pulley Mtg. Shaft (5 Req'd. Per 45° Turn) (12 Req'd. Per
90° Turn)
6933-01
Bolt, 1/4-
20, S/S, 1/2" (5 Req'd. Per 45° Turn) (12 Req'd. Per 90°
Turn) 1016-01
Electrical Information and Parts
