Cadenceberge CAD-HDV-UA60 User manual
All to USB3.0 Video Capture Dongle
MODEAL No: CAD-HDV-UA60
VER 1.0
pg. 2
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please keep this manual
for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the
life of your equipment.
Table of Contents
Table of Contents ...............................................................................................................................2
1. Introduction....................................................................................................................................3
2. Features...........................................................................................................................................3
3. Package Contents ...........................................................................................................................3
4. Specifications ..................................................................................................................................4
5. Operation Controls and Functions...............................................................................................5
6. Software instruction.......................................................................................................................6
7. Device source logic .......................................................................................................................10
8. Application Example.................................................................................................................... 11
pg. 3
1. Introduction
This product has a superior performance, superior compatibility, easy to carry,
simple installation and many other features. It can capture HDMI, DVI (VGA,
YPbPr, AV) and SDI input and output signal, video resolution the maximum
up to 1920×1200. It compatibles Windows, Linux, Mac OS X operating system
and USB3.0 interface. It compatibles USB3.0 chipset (Intel, Renesas, ASMedia,
Fresco Logic etc.), compatible with PCIe Gen 1.1 x1 expansion via USB3.0
interface. The product meets UVC and UAC standard. Simple plug and play,
no driver and setting installation required.
2. Features
☆Supports AV, YPbPr, VGA, DVI, HDMI and SDI video input capture.
☆Supports input interface automatic recognition.
☆Supports resolution 480i~1920×1200 input format video capture.
☆Supports AV, YPbPr, VGA and DVI analog stereo audio inputs.
☆Compatibles Windows, Linux, OS X operating systems.
☆Compatibles USB3.0 about transmission rate up to 300~350MB/s.
☆Compatibles VLC, OBS, XSPLIT and AMCAP etc. PC capture software.
☆It can automatically detect the input video format, adjust the set output size
and frame rate.
☆Simple plug and play, no drive and setting installation required
3. Package Contents
①1×All to USB3.0 Video Capture Dongle
②1×USB3.0 male to Type-A male Cable
③1×YPbPr/AV female to DVI male convert connector
④1×VGA female to DVI male convert connector
⑤1×User Manual
pg. 4
4. Specifications
Technical
Host port
1×USB [USB Type A, USB3.0 —300~350MB/s]
Input ports
1×DVI IN [DVI-I, Attention: This is a common interface, it can
also connect VGA/YPbPr/ AV source input though converter joint.]
1×HDMI IN [19-pin female]
1×SDI IN [BNC]
1×AUDIO IN [3.5mm Stereo Mini-jack]
HDMI input
resolution
480i, 480p, 576i, 576p, 720p50/60, 1080i50/60,
1080p24/25/30/50/60
SDI input resolution
480i, 576i, 720p50/60, 1080I50/60, 1080P24/25/30/50/60
VGA input resolution
640x480,800x600,1024x768,1280x1024,1400x1050,
1600x1200
DVI input resolution
720x480i/p60Hz, 720x576i/p50Hz, 1280x720p50Hz,
1280x720p60Hz, 1920x1080i/p50Hz, 1920x1080i/p60Hz
YPbPr inputresolution
480i, 576i, 480p, 576p, 720p50/60, 1080I50/60
AV input resolution
480i, 576i
Output resolution
640×360, 640×480, 720×480, 720×576, 800×600,
856×480, 960×540, 1024×576, 1024×768, 1280×720,
1280×1024, 1280×960, 1280×800, 1368×768, 1440×900,
1600×1200, 1680×1050, 1920×1080, 1920×1200
Frame Rate
25/29.97/30/50/59.94/60fps
Audio and video
capture
UVC (USB video class) and UAC (USB audio class)
standard
Supports OS
Windows 7/8/10, Linux (Kernel version 2.6.38 and
above), OS X (10.8 and above)
Software compatibility
Windows Media Encoder (Windows), Adobe Flash Media
Live Encoder (Windows, OS X), Real Producer Plus
(Windows), VLC (Windows, OS X, Linux), QuickTime
Broadcaster (OS X), QuickTime Player (OS X), Wirecast
(Windows, OS X) and Potplayer (Windows) etc.
pg. 5
Mechanical
Housing
Metal Enclosure
Color
White
Dimensions
114mm [W] x 82mm [D] x 22mm [H]
Weight
168g
Power Consumption
3.9W
Operating
Temperature
32 - 104°F / 0 - 40°C
Storage
Temperature
-4 - 140°F / -20 - 60°C
Relative Humidity
20 - 90% RH (no condensation)
5. Operation Controls and Functions
Number
Name
Function description
1
HDMI IN
Connect to the HDMI source device such as a DVD
player or a Set-top Box with a HDMI cable.
2
DVI-I IN
Connect to the DVI source device such as a DVD
player or a Set-top Box with a DVI-I cable.
(Note: This is a common interface, it can also connect
VGA/YPbPr/ AV source input though converter joint.)
3
SDI IN
Connect to the SDI source device such as a DVD
player or a Set-top Box with a SDI cable.
4
USB3.0 Capture out
USB3.0 output port, connect to PC or NoteBook.
pg. 6
5
AUDIO IN
Analog stereo audio input. (When the input source
is DVI/VGA/YPbPr/AV, the USB voice capture from
external AUDIO input.)
6
Action LED
This LED will illuminate when the device captures
video normally.
7
Power LED
This LED will illuminate when the device has
connected PC’s or NoteBook’s USB port.
6. Software instruction
For example: OBS (Open Broadcaster Software) software, windows10 system.
1. Install “OBS”application software on the computer.
2. Double click “OBS Studio”shortcut to open the application.
3. Click the “+”, you can see a up-down menu and select “Video Capture
Device”, and then click “OK”button.
→ →
4. In the Device option box to select “USB3.0 Capture Video”, at the buttom
of the box to option for “Use custom audio device”, and select “USB3.0
Capture Audio”. Then click “OK”button.
pg. 7
5. In the Setting page, you can select “Audio”option. In the page, you need
select “Sample Rate”and the “Mic/Auxiliary Audio Device”to select
pg. 8
“USB3.0
Capture Audio”. Then click “Apply”button and “OK”button.
→
6. Use your mouse to click the Setting icon, you need select “Advanced Audio
Properties”option. In the Advanced Audio Properties page, you need select
“Monitor and Output”option. Then click “Close”button.
→
7. In the Setting page, you can select “Video”option. In the page, you can
select “Base Resolution”and “Output Resolution”. Then click “Apply”
button
and “OK”button.
pg. 9
→
8. Open Setting page, you can select “Output”option. In the page, you can
browse recording path for capture video, select the recording quality, select
recording format etc. Then click “Apply”button and “OK”button.
→
9. When you have finished all settings, you need click the “Start Recording”
button to starting video capture. If it has finished, click this button again to stop
video capture.
pg. 10
10. When the video capture is over, you can click the “Exit”button to close
the software.
Attention: The all instruction of the software is only about video capture settings
at the above content. You can brower other related settings function.
7. Device source logic
①Insert Interface Logic: The video capture will display the last insert interface
signal.
②Pull out Interface Logic: When pull out current interface signal, the signal
displays priority order about SDI->HDMI->DVI->VGA(YPBPR/AV).
③Power on/off Logic: Before power off, displaying the last dispaly signal.
After power off, if the signal has pulled out, the signal displays priority order
pg. 11
about SDI->HDMI->DVI->VGA(YPBPR/AV).
④Sound logic: When the HDIM/SDI is input source, the sound is built-in audio.
When the DVI/VGA (YPbPr, AV) is input source, the sound is from external
analog stereo audio input.
8. Application Example
