4000 Series Irrigation Traveller
We would like to thank you for purchasing your new Cadman 4000 Series Traveller.
You have purchased a product of superior quality that will serve your needs for a long time as
long as you follow this manual and safety procedures.
Figure 1 - 3750XL Wide Body Traveller img-01380
BEFORE operating your new Cadman 4000 Series Traveller, inspect the machine for
any damage or parts that may have come loose during shipping. REPORT ANY DAMAGE TO
CADMAN POWER EQUIPMENT LIMITED OR YOUR LOCAL DEALER IMMEDIATELY.

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 4 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
Warranty Policy
CADMAN POWER EQUIPMENT LIMITED warrants that each machine it manufactures
shall be free from defects in materials and workmanship. The terms of this warranty are as
follows:
All components manufactured by CADMAN POWER EQUIPMENT LIMITED shall be
warranted for a period of one (1) year from the date of delivery, except the frame and hose
drum structures which shall be warranted for a period of three (3) years.
CADMAN POWER EQUIPMENT LIMITED makes no warranty whatsoever in regard to
tires, engines, and other trade accessories used on its equipment. The customer shall rely
solely on the warranties offered (if any) by the respective manufacturer of these trade
accessories.
The sole obligation to CADMAN POWER EQUIPMENT LIMITED under this warranty is
limited to the repair or replacement of any part it manufactured, which, in the judgment of
CADMAN POWER EQUIPMENT LIMITED, failed under normal and proper use and
maintenance due to defective materials or workmanship. All freight charges incurred shall be
the sole responsibility of the customer.
CADMAN POWER EQUIPMENT LIMITED and its dealers (who are neither authorized
nor qualified to undertake any obligations on behalf of CADMAN POWER EQUIPMENT
LIMITED) DO NOT, under any circumstances, accept any responsibility for any losses or costs
incurred due to parts failure and/or delays during the parts replacement process.
This warranty will be considered void if any alterations or modifications have been made
to the machine without the express written consent of CADMAN POWER EQUIPMENT
LIMITED outlining the nature and the extent of such modifications. CADMAN POWER
EQUIPMENT LIMITED will not provide any warranty express or implied to any overdue
accounts.
CADMAN POWER EQUIPMENT LIMITED, whose policy is one of continuous
improvement, reserves the right to change specifications and designs without notice or
incurring obligation.
The warranties expressed herein are non-transferable and replace any other warranties,
either written or verbal, which may have been given or implied.

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 5 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
When Applying Liquid Manure
Current and pending laws in agricultural regions of North America change the ways in
which the agricultural community needs to manage their liquid animal waste products. As a
manufacturer of agricultural equipment, we feel it necessary to make you aware that the
municipal, regional and state governing bodies in your area may have created new laws or
updated current laws for nutrient handling practices and procedures. The changes in these
laws typically target run-off prevention and soil nutrient loading.
Run off may result from several factors. Some (but not all) of the factors are:
Incorrect application
Difficult application areas containing steep hills or other features that may make run off
more likely to happen
Changes in weather that would allow run off to happen (sudden storms just before or just
after applying, ground frost, etc.…)
Constant watch must be kept and immediate action taken when needed to prevent run off from
happening.
Soil nutrient loading depends on several variables. Some (but not all) of these variables are:
The type of crop(s) being grown
The type of soil the crop(s) are growing in
Nutritional value of what you are applying
Nutritional needs of the crop(s) and soil they are growing in
Application timing, nutritional value of what you are applying, and the type of soil will determine
the intake rate at which liquid may be applied. Soil analysis taken at appropriate times will
help you create a correct application plan for your crop(s). In addition; local colleges,
universities, and agricultural extension services are a good source of information. They may
be able to help you create an application program that will help prevent problems with your
application.
CADMAN POWER EQUIPMENT LIMITED is unable to provide up-to-date recommendations
for the laws you must follow in your area. It is your responsibility to make yourself aware of
and follow the law in your area. Please contact your local agricultural representative to obtain
the latest information for legal handling and application of nutrient.

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 6 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
Safety Precautions
Please take the time to read and understand this manual to avoid errors and
unnecessary risks. If you have any questions or concerns, please contact CADMAN POWER
EQUIPMENT LIMITED or your local dealer/distributor.
FAILURE TO FOLLOW ALL SAFETY INSTRUCTIONS CAN RESULT IN DEATH OR
SERIOUS INJURY FOR YOU AND/OR ANY SPECTATORS.
DO NOT move or operate this machine until you have read and understand these
instructions in this manual.
NEVER allow untrained persons to operate this machine.
DO NOT perform service this machine while it is in operation.
MAKE SURE all mechanical and hydraulic tension has been released before
attempting any service on the machine.
CHECK all fasteners (nuts and bolts) regularly for tightness.
PERFORM REQUIRED MAINTENANCE as prescribed or as necessary to keep this
machine in safe operating condition.
KEEP ALL SPECTATORS at a safe distance.
STAY CLEAR of high pressure supply lines, especially when first pressurizing the
system.
DO NOT remove or alter any shielding on this machine.
MAKE SURE that the machine is securely anchored (using a tractor) before
unwinding the hose.
KEEP CLEAR of all moving parts.
NEVER tow this machine at speeds greater than 10 mph [16 km/h] and be certain
the tow vehicle has adequate braking capacity to maintain safe control at all times.
NEVER tow this machine with the hose loaded with fluid.
BE AWARE of any obstacles (i.e. mail boxes, fence posts, and other equipment)
that you may encounter when transporting the machine.
REGULAR INSPECTION of your pipe/hose couplings, tubing and gaskets should be
a part of your regular set-up routine. Any defective parts MUST be replaced or
repaired before the machine is put into service.
This symbol, the safety-alert symbol, indicates a hazard. When you come
across the safety-alert symbol in this manual, make sure you fully
understand and abide by the given instructions or warnings.

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 7 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
Safety Decals
Cadman Power Equipment Limited has determined the potential hazards on your 4000
Series Traveller and has labeled the machine accordingly. The safety decals on this machine
are there to warn operators of potential hazards. Each safety decal on this machine contains a
Signal Word Panel which shows the degree of hazard. Definitions of the Signal Words are as
noted below.
Figure 2 - Danger Decal img-00340-A
DANGER - an immediate, hazardous situation that if not avoided, WILL RESULT IN
DEATH OR SERIOUS INJURY.
Figure 3 - Warning Decal img-00340-B
WARNING - a potentially hazardous situation that if not avoided could result in death
or serious injury. This includes hazards that are exposed when guards are removed.
Figure 4 - Caution Decal img-00340-C
CAUTION - a potentially hazardous situation that if not avoided may result in minor
or moderate injury.

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 8 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
Safety Decals Continued
All safety decals must be clean, clear, and easy to read
Replace any decal that is not in good condition
Replace any missing decals, it is important to double check that all labels are on
your machine, especially if you have modified your machine or have had your
machine serviced
Figure 5 - Replace Decals img-00131-B

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 9 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
Planning Your Application
Complete the steps shown in order to create a plan to irrigate your field:
Step 1
If you are using a new traveller for the first time, or a traveller that was drained beforeA )storage, you must start somewhere that will allow you to pull out the hose. You must
leave at least one full coil of hose on the drum after pulling the hose out. Verify that the
hose coils on the base layer are packed tightly with no gaps between coils.
Failing to leave at least one coil of hose on the traveller drum will result in
damage to the hose. You also risk pulling the hose off of the drum barb.
Damaging the traveller’s hose and/or pulling the hose off of the drum barb
will lead to pooling/ponding of water. This will muddy the area around the
traveller and may cause injury to operators and/or spectators. This will
also damage the traveller.
Check the traveller’s fluid levels and verify all fluid levels are correct.B )
Step 2
Determine your application depth in inches. Do not irrigate deeper than the root zone of
the crops you are irrigating as you will over water. Over watering your crops will result in
wasting time and raising irrigation cost of your crops.
Figure 6 - Root Zone: Depth of Application img-00197-A

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 10 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
Step 3
Divide your field into the least number of sections for complete coverage.
Choose the area you plan to irrigate. If this area is greater than what you can irrigate inA )one pull you need to divide the area into the least number of sections. Use the
performance data tables on page 151 to determine your traveller’s irrigation area.
Figure 7 - Reel Coverage img-00193-A
The total length of your irrigation pull can be calculated from the following equation:
𝑨 = 𝑩
𝟐+ 𝑪
A is the total irrigated length in feet.
B is the diameter of your sprinkler throw in feet. See page 151 for sprinkler
performance data.
C is the length of your machine’s hose. See the table below for your traveller’s
hose length.

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 11 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
4000 Series Hose Lengths:
WB MODEL
HOSE LENGTH (FT)
3750XL
1320
4000SWB
1250
4500SWB
1175
Avoid quarter circle irrigation pulls whenever possible. Reduce your sprinkler’s nozzle B ) size and/or lowering the operating pressure may reduce the spray so that you can
irrigate your field without using quarter circle irrigation pulls. If you change your flow
rate you must adjust your retrieval rate to match the new flow rate.
Figure 8 - Multiple Pass Setup img-00199-A

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 12 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
If a quarter pull unavoidable, prepare the travel lane with a shallow trench for the hoseC )to follow. You may also add weights to the sprinkler cart to assist in the sprinkler cart
track in a straight line. If you are unable to set the sprinkler cart up for a quarter circle
irrigation pull then you must change your plan to use full irrigation pulls.
If you need to perform a curved irrigation pull, you must pull out at least 200 feetD )(61 meters) of hose straight out of the machine before starting a long, gradual curve.
The curve must not form a 90 degree bend.
Failing to provide a trench or furrow during a quarter circle pull or curved
pull will lead to the sprinkler cart tracking unpredictably. This may result in
the sprinkler cart colliding with anything in the sprinkler cart path.
Collision with an unpredictably tracking sprinkler cart will cause serious
injury to operators and/ or spectators. It will also cause damage to the
sprinkler cart and any object it collides with.
Plan to leave open travel lanes and ample head lands. Travel lanes and head landsE ) that have been hilled and cultivated will lower the towing effort needed to pull the
sprinkler cart into position. Hilled and cultivated lands will also provide guidance for the
hose. Make sure to provide ample head land space to safely turn your traveller and set
it up.
Some crops (e.g. alfalfa, peas, potatoes, sod) will provide high resistance to pulling theF ) hose out. If you irrigate a crop that provides high resistance for hose pull out
decoupling the feeder hose at the mainline valve and pulling the hose out slower may
assist hose pull out.
Decoupling the feeder hose at the mainline valve will drain the irrigation
traveller’s hose. The hose contains several hundred gallons of water and
will muddy the area around the traveller. This may cause injury to
operators and/or spectators.

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 13 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
Start your irrigation pull at the section furthest from your water source when possible.G )This will prevent changing water sources during a multiple pass irrigation pull.
Figure 9 - Multi Pass Setup img-00233-A
Pull the hose up or down sloping terrain when possible. If operating on the side of a hillH )cannot be avoided you must dig a hilled trench for the hose to follow in addition to
adding extra weight to the sprinkler cart to prevent it from tipping and falling downhill.
Failing to provide a hilled trench and/or adding weights to the sprinkler cart
will result in the sprinkler cart sliding or falling downhill during operation.
This may cause serious injury and/or death to operators and/or spectators.
This will also cause damage to the sprinkler cart.
Make sure to note all the obstacles in the area you want to irrigate. You will need to
adjust your plan for obstacles in order to safely irrigate the area you are planning for.

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 14 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
Determine the retrieval rate using the sprinkler data charts, system pressure, and fieldI ) width. See the retrieval rate selection example below…
Retrieval Rate Selection Example
For this example a 4000SWB traveller is fitted with a Nelson SR150 sprinkler. The
Nelson SR150 will be using a 1.34 inch ring nozzle operating at 90 psi.
Use the above information to plan for a field using 300 foot lane spacing that needs
1.25 inches of irrigation depth.
Use example Table 1 to find the GPM you will be pumping. For this example, cross theA ) 1.34 inch ring diameter with the 90 psi operating pressure.
A 1.34 inch ring nozzle operating at 90 psi will irrigate at 405 GPM.
Next, use example Table 2 to look up the time it will take to cover one acre in minutesB ) by crossing the GPM from step A and the 1.25 inch irrigation depth used in this
example. If the GPM from step A does not match with one of the flow rates in example
table 2, the flow rate in example Table 2 that is closest to the GPM from step A is
chosen.
A flow rate of 245 GPM with an irrigation depth of 0.75 inches
will give a time of 68 minutes.
Use example table 3 to look up the retrieve rate you need by crossing the time neededC )to cover 1 acre from step B with the 300 foot lane spacing.
81 minutes to cover 1 acre with a 300 foot wide lane
will give a retrieval rate of 21 inches per minute.
You must set the sprinkler up so that the 300 foot section is covered in addition toD )enough overlap to provide adequate watering at the edge of your field.
The following charts are to be used as a guide only. Always verify the
application amount with rain gauges to confirm that your application is
correct.

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 15 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
NOZZLE
PSI
Ø 0.86
Ø 0.97
Ø 1.08
Ø 1.18
Ø 1.26
Ø 1.34
Ø 1.41
GPM
DIA.
GPM
DIA.
GPM
DIA.
GPM
DIA.
GPM
DIA.
GPM
DIA.
GPM
DIA.
50
100
245
130
265
165
285
205
300
255
320
300
335
350
350
60
110
260
143
280
182
300
225
315
275
335
330
350
385
365
70
120
270
155
290
197
310
245
330
295
350
355
365
415
380
80
128
280
165
300
210
320
260
340
315
360
380
380
445
395
90
135
290
175
310
223
330
275
350
335
370
405
390
475
405
100
143
300
185
320
235
340
290
360
355
380
425
400
500
415
110
150
310
195
330
247
350
305
370
370
390
445
410
525
425
Table 1 - Nelson SR150 Big Gun (27° Trajectory, Ring Nozzle)
PRECIPITATION RATE ( ACRE INCHES )
GPM
0.25"
0.50"
0.75"
1.00"
1.25"
1.50"
1.75"
2.00"
2.50"
150
45
90
135
180
225
270
315
360
453
200
34
68
102
136
170
204
238
272
340
250
27
54
81
108
135
162
189
216
272
300
23
46
69
92
115
138
161
184
226
350
19
38
57
76
95
114
133
152
194
400
17
34
51
68
85
102
119
136
170
450
15
30
45
60
75
90
105
120
151
500
14
28
42
56
70
84
98
112
136
550
12
24
36
48
60
72
84
96
123
600
11
22
33
44
55
66
77
88
113
650
10
20
30
40
50
60
70
82
104
Table 2 - Time required for watering one acre (inch/min)
MIN /
ACRE
LANE SPACING ( FEET )
200
225
250
275
300
325
350
375
400
10
----
----
----
----
----
----
----
139
131
15
----
----
139
126
116
107
100
93
87
20
131
116
104
95
87
80
75
70
65
25
105
93
84
76
70
64
60
56
52
30
87
77
70
63
58
54
50
46
44
35
75
66
60
54
50
46
43
40
37
40
65
58
52
47
44
40
38
35
33
45
58
52
46
42
39
36
33
31
29
50
52
46
42
38
35
32
30
28
26
55
48
42
38
35
32
29
27
25
24
60
44
39
35
32
29
27
25
23
22
65
40
36
32
29
27
25
23
21
20
70
37
33
30
27
25
23
21
20
19
75
35
31
28
25
23
21
20
19
17
80
33
29
26
24
22
20
19
17
16
85
31
27
25
22
21
19
18
16
15
90
29
26
23
21
19
18
17
16
15
95
28
24
22
20
18
17
16
15
14
100
26
23
21
19
17
16
15
14
13
Table 3 - Retrieval rate in inches

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 16 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
4000 Series Traveller Start Up
Prepare your 4000 series traveller for use in the field by completing the following steps
in order:
Step 1
Ensure the drive system is disengaged before towing. Move the shifter towards rightA ) as shown in the graphic below.
Figure 10 - Disengage Drive System img-01427
Failure to disengage the drive system before towing will result in excess
shock in the drive system. This may lead to damage to the traveller.

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 17 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
Verify the engine fuel valve is in the off position by pulling it to the right. The engine fuelB )valve is located on the rear side of the engine as shown. If the engine fuel valve is not
off you must switch it to the off position before towing.
If you need to shut the engine fuel valve off immediately after use, avoid touching the
engine.
Figure 11 - Shut Fuel Valve img-01422
Failure to verify that the engine fuel valve is off before towing will result in
the fuel system remaining on during transport. This may lead to damage to
the traveller.
The engine will be hot due to running continuously while doing irrigation
pulls. Touching the engine during, or after an irrigation pull without time to
cool down will lead to operator injury.
Verify that the drum brake is applied. If the drum brake is not applied, you must apply itC )before towing.
Failure to verify that the drum brake is applied may lead to the drum
rotating during transport. This may lead to damage to the traveller.

TR-MAN-4000
Operator's Manual - 4000 Series Traveller
Page 18 of 158
Cadman Power Equipment Limited ▪ BOX 100, Courtland, Ontario, Canada N0J-1E0 ▪ Phone: [phone] ▪ Fax: [phone] ▪ www.cadmanpower.com
Step 2
Verify that the sprinkler cart lift chains are secure.A )
Figure 12 - Verify Sprinkler Cart Chain Connection img-01423
Failing to verify that the sprinkler cart lift chains are secure may lead to the
cart falling off the traveller during transport. This may cause serious injury
and/or death to operators and or spectators. This will also damage the
sprinkler cart, and may lead to damage to the traveller.
