Caisun XK315A1 Series User manual

User Manual
XK315A1 series Weighing Indicators
Applications: Electronic platform scale, weighing scale, etc.

1
Contents
Introductions---------------------------------------------------------------------------2
Specifications------------------------------------------------------------------------- 2
Front Panels---------------------------------------------------------------------------3
Basic functions----------------------------------------------------------------------- 4
Applications--------------------------------------------------------------------------- 5
External interfaces------------------------------------------------------------------- 6
Services-------------------------------------------------------------------------------- 7

2
1 Introductions
1.1 Safety precautions
WARNING!
▲Don’t use XK315A1 series indicators in hazardous area or in dusty environments.
▲Never flood the indicator, immerse it in liquid or pour liquids on it.
▲Don’t expose indicator to either direct sun light or any heat sources.
▲Don’t open the indicator!
▲The warranty is void if this stipulation is ignored. The indicator may only be opened
by authorized persons.
DANGER!
Electric shock hazard!
▲Always unplug AC adapter before performing any work on the indicator hazard of
electric shock if the power cable is damaged!
▲Check the power cable for damage regularly. Unplug the power cord immediately if
the power cable is damaged.
DISPOSAL!
In conformance with the European Directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE), this device may not be disposed of in domestic waste.
This also applies to countries outside the EU as per their specific regulations.
Please dispose of this product in accordance with local regulations at the collecting
point specified for electrical and electronic equipment.
If you have any questions, please contact the responsible authority or the distributor
from which you purchased this indicator.
Should this indicator be passed on to other parties (for private or professional use), the
content of this regulation must also be related.
The indicator has a rechargeable internal battery. The battery contains heavy metals.
Please observe the local regulations on the disposal of environmentally hazardous
materials.
1.2 Descriptions
The purpose of this manual is to help the user get to know the indicator’s various weighing modes,
keys’ functions and display indications.
In addition to having all the characteristics of a high precision scale, the indicator has weight unit in kg
and lb, gross and net weighing, manual and automatic weight accumulation with serial output, counting
functions and 4 set points. The indicator is applicable in either industrial settings or legal for trade
applications. It provides the frequently needed ability to transmit and print the data through its serial
ports.
Please carefully follow the instructions to configure the indicator. By taking actions not
indicated this manual, one could cause the indicator to not work properly.
2 Specifications
Version number
7.9
Accuracy class
III
Maximum number of verification scale intervals
nind = 3000
Divisions
3000 –15000
Load cell excitation voltage
Uexc = 5 V
Minimum input voltage
Umin = 0.5 Mv
Minimum input voltage per verification scale interval
Δumin = 1 Μv
Minimum/maximum load cell impedance
87 Ω to 1000 Ω
Fraction of mpe
pind = 0.5
Cable connection
4 wires
Maximum value of cable length per wire cross section
(L/A)max = 150 m/mm2
Maximum number of load cells
4 x 350 Ω load cells
8 x 700 Ω load cells
Display
6-bit Display: 0.8 inches LED
High Resolution (× 10) display
Weight unit in kg / lb
Display resolution
1/2/5/0.1/0.2/0.5/0.01/0.02/0.05/0.001/
0.002/0.00510/20/50/100/200/500
0.10/0.20/0.50/0.010/0.020/0.050

3
Weighing modes
Gross and net weight weighing
Manual and automatic weight accumulation
Serial interface
RS232 interface with continuous ASCII data
output
Baud rate 1200, 2400, 4800, 9600
Optional RS485 interface
External AC adapter
100-240VAC 50/60Hz
Rechargeable internal battery
XK315A1X: 6V/4AH
XK315A1-2: 6V/4AH
XK315A1-9: 6V/2.8AH
XK315A1GB-3: 6V/2.8AH
XK315A1GB-5: 6V/2.8AH
Full charge battery operation
XK315A1X: 30 hours
XK315A1-2: 30 hours
XK315A1-9: 20 hours
XK315A1GB-3: 20 hours
XK315A1GB-5: 20 hours
Full charge battery recharge time
12 hours
Operating temperature
–10 ° C to +40 ° C
Storage temperature
–25 ° C to +55 ° C
Relative humidity
10% to 85% non-condensing
Housing
XK315A1X: plastic
XK315A1-2: plastic
XK315A1-9: plastic
XK315A1GB-3: stainless steel
XK315A1GB-5: stainless steel
Dimensions
XK315A1X: 255 x 170 x 130mm
XK315A1-2: 255 x 170 x 130mm
XK315A1-9: 275 x 160 x 120mm
XK315A1GB-3: 275 x 160 x 120mm
XK315A1GB-5: 275 x 160 x 80 mm
Weight
XK315A1X: 1.5kg
XK315A1-2: 1.5kg
XK315A1-9: 1.3kg
XK315A1GB-3: 1.6kg
XK315A1GB-5: 1.6kg
3 Front Panels
3.1 Status indicators
Status
Meaning
AC
Mains power is applied to the indicator.
Battery capacity less than 20%.
AUTO
Automatic accumulation
◣◢
Weight is stable

4
→T←
A weight is tare and display net weight
→O←
-1/4 e < weight < 1/4 e
lb〖-0〗
Unit of weighing is lb
〖0.〗× 10
Display is temporarily set to high resolution
3.2 Keypad functions
Keys
Meaning
【OFF】
Off function
【ON】
On function
【∴】
Manual accumulation function
【﹡】
Function selection during normal operation and configuration
【→】
Move flashing digit to the right during configuration or setting preset tare
【↑】
The display is temporarily set to high resolution increment flashing digit during configuration or
setting preset tare
【→O←】
Zero the display, set the zero point or enter a tare value
3.3 Error code
Code
Meaning
〖OUEr〗
Weight > FS + 9d
〖–OUEr〗
Weight < -2%FS
〖Error 〗
Calibration error
〖OFF 〗
Low battery warning to recharge the battery
4 Basic Functions
4.1 Switching on
In power off states, press【ON】key switch on the indicator. The indicator will check the LED.
4.2 Switching off
Press【OFF】to switch off the indicator.
4.3 Weight unit
The weight unit is kg and lb. Press【﹡】for 2 seconds to change the unit.
4.4 Enter a number
1. Press【→】to move the flashing digit that can be changed to the right by 1 digit.
2. Press【↑】to increment the flashing digit by 1.
3. Repeat the above 2 steps until the desired value is set.
4.5 Select a parameter value
Press【↑】to scroll to the next available value.
4.6 Zero
1. The display can be zeroed only when the weight is less than 2%FS.
2. Unload the platform.
3. Press【→O←】for 2 seconds to set the zero point and zero the display.
4. The zero status →O←is turned on.
4.7 Tare
4.7.1 Acquire tare
1. Tare can be set only after the display has been zeroed. Check to make sure zero status →O←is
turned on.
2. Place the empty container on the platform.
3. Wait until the weight is stable when the stable status ◣◢ is displayed.
4. Press【→O←】to set tare and zero the display.
5. The tare status →T←is turned on.
6. The indicator switches to in net weight mode.
4.7.2 Digital tare
1. Press【→】to set digital tare and the 1st on the right is flashing.
2. Press【→】to move the flashing digit to desired digit.
3. Press【↑】to increment the flashing digit to the desired value.
4. Repeat step 2 and 3 until the digital tare is entered.

5
5. Press【→O←】to set the digital tare.
6. The tare status →T←is turned on.
7. The indicator switches to in net weight mode.
4.7.3 Remove tare
1. Check that the tare status →T←is displayed.
2. Press【→O←】to remove tare and switch to gross weight mode.
4.8 Simple weighing
1. Place sample on the platform.
2. Wait until the weight is stable when the stable status ◣◢ is displayed.
3. Read the weight of the sample
5 Applications
5.1 Accumulation mode
There are 8 accumulation modes AUt = 0 to 7. The factory default AUt is 0.
Step
Operation
Displaying
Contents
1
Press【﹡】
〖n 12〗
To display times of accumulation.
2
Press【﹡】
〖AUt 0〗
The selection of manual/automatic accumulation.
AUt=0, manual accumulation.
AUt=1, automatic accumulation and print when weight is added,
〖AUTO〗is on.
AUt=2, automatic memorize displayed value when weight is added.
Accumulate and print final stable values after load down to below 20d.
〖AUTO〗is on.
AUt=3, dynamic weighing method. At weighing >20d: the buzzer sounds
“du” and lock is displayed for 6 seconds. When a new data is fixed, lock
is displayed again for 6 seconds. Then lock is released for weighing
<20d; automatic accumulation and print. Suggest FLt>30, 〖AUTO〗is
on.
AUt=4, peak value fixed weighing method. At weighing>20d, the buzzer
sounds “du” and lock is displayed. When weighing <20d, fixed data
displays with flash, automatic accumulation and print. Lock can be
released by pressing any key. 〖AUTO〗is on.
AUt=5, dynamic weighing method. Manual accumulation and print.
AUt=6, peak value fixed weighing method. Manual accumulation and
print.
AUt=7, counting function. ★note
3
Press【↑】
〖AUt 0〗
Digit displays with flash
4
Press【↑】
Press【↑】
Press【↑】
Press【↑】
〖AUt 0〗
〖AUt 1〗
〖AUt 2〗
〖AUt 3〗
Sets F·S.
Move blinking digit to the right bit.
E.g. AUt=3 expresses dynamic weighing method.
5
Press【﹡】
〖0〗
Return to normal weighing status
Note: (1) sampling: When net weight on scale is zero (tare can be removed by pressing tare key if net
weight is not zero), the sample, which must be <200 pieces, i.e. from 1 to 199, is put on the scale.
Press【→】and【↑】, input quantity of the sample (e.g.30), 〖Cnt030〗is displayed. Press【*】, confirm
the completion of sampling. Weighing status is redisplayed. Sampling is memorized even with power
off.
Step
Operation
Display
Description
1
Place sample
Place selected sample, weight: 27, quantity: 30.
2
Press【→】
Press【→】
〖Cnt000〗
〖Cnt000〗
Ready to input sample‟s quantity.
Decimal digit display with flash.
3
Press【↑】
Press【↑】
Press【↑】
〖Cnt010〗
〖Cnt020〗
〖Cnt030〗
4
Press【﹡】
〖27〗
Display sample weight:27,【*】is a confirmation key, sample collection
completed.
5
Press【↑】
〖C 30〗
Display sample quantity,【↑】is change-over key between weight and
quantity display.

6
(2) Counting operation: place object on scale, weight is displayed, press【↑】, 〖C 255〗is displayed,
and the display changes over to the quantity of the object. When the display is stable, press【∴】,
accumulate the weight and quantity. Accumulation can be done only at counting status.
Step
Operation
Display
Description
1
Place object
〖230〗
Object weight: 230.
2
Press【↑】
〖C 255〗
Object quantity: 255.
3
Press【∴】
〖n 4〗
〖C 255〗
Display after 1.5 seconds.
At counting status.
(3) Accumulate inquiries and delete: both at weighing stage and counting status.
Step
Operation
Display
Description
1
Press【﹡】
〖C 1203〗
Display the total quantity of the object: 1203.
2
Press【↑】
〖H 0〗
Display accumulated weight 4 digits higher.
3
Press【↑】
〖L 1085〗
Display accumulated weight 4 digits lower=1085.
4
Press【↑】
〖C 1203〗
Back to counting status.
5
Press【→0←】
〖C 0〗
Delete accumulated quantity.
5.2 High resolution display mode
Press【↑】to display the weight in X10 resolution for 5 seconds. The last digit of the display will be
blinking. Press【↑】key return to normal weight display mode.
6 External interfaces
6.1 Load cell connector
6.1.1 Load cells to indicator DB 9 Pin plug
6.1.2 Load cells to indicator 5 Pin plug
6.2 RS232 serial interface
6.2.1 RS232 settings
Number of bits
Parity
Number of stop bit
8
No
1
6.2.2 RS232 / RS485 connector
6.2.3
6.2.4 Connecting to PC
XK315A1-1x DB9 Pin No.
PC DB9 Pin No.
3(TxD)
2 (RxD)
Indicator
1 -----------------------
5 -----------------------
7 -----------------------
8 -----------------------
3 -----------------------
+
-
+
-
Load cell
Excitation
Excitation
Signal
Signal
GND
Indicator
1 -----------------------
2 -----------------------
3 -----------------------
4 -----------------------
5 -----------------------
Load cell
+ Excitation
+ Signal
- Signal
- Excitation
GND

7
2 (RxD)
3 (TxD)
5(GND)
5 (GND)
6.2.5 Connecting to a printer (Adr=01-98, baud=2400)
At weighing status, weighing data >20d and display is stable, press【∴】, weighing sheet is printed out.
The second printing can be operated only when the weighing data is back to <20d.
At weighing status, press【*】, then press【∴】, accumulated printing can be operated.
XK315A1-1x DB9 Pin No.
Printer DB25 Pin No.
3 (TxD)
2 (RxD)
5 (GND)
7 (GND)
6.2.6 RS232 continuous ASCII output
When the indicator address (Adr) is set to 00 or 99, the indicator continuously transmits the weight in
RS232 ASCII data format.
Display format
Digit position
X6
X5
X4
X3
X2
X1
Weight –1234.5
–
1
2
3
4.
5
Adr = 00 output format
Byte No.
1
2
3
4
5
6
7
8
Output format
=
X1
X2
X3
X4
X5
X6
S
HEX
3D
35
2E
34
33
32
31
2D
Weight –1234.5
=
5
.
4
3
2
1
–
Adr = 99 output format
Byte No.
1
2
3
4
5
6
7
8
Output format
=
S
X6
X5
X4
X3
X2
X1
HEX
3D
20
31
32
33
34
35
36
Weight 1234.5
=
„ „
1
2
3
4
.
5
6.3 Printer format
n = 3, gross = 88.69kg, tare = 29.41kg, net = 59.28kg
No:XXXX No: 3
G:XXXXXXkg G: 88.69kg
T:XXXXXXkg T: 29.41kg
N:XXXXXXkg N: 59.28kg
Accumulated weight
No:XXXX No: 3
W:XXXXXXXkg W: 118.09kg
7 Services
Services include a full range of technical on site services and workshop repair, preventative
maintenance and calibration facilities.
NOTE: Battery is not under warranty
