Cal Test Electronics CT4432 User manual

User Manual
CT4432
10 kV High-Voltage Oscilloscope
Probe, cTUVus Listed

2CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Notices
Copyright © 2021 Cal Test Electronics, Inc. All rights reserved.
Unauthorized duplication of this documentation material is strictly prohibited. Users are permitted to
duplicate and distribute this documentation for internal educational purposes only. Cal Test Electronics
is governed by United States and international copyright laws.
Made in Taiwan
User Manual Part Number
451-051-001 Rev. B
Available in electronic format only
Published by:
Cal Test Electronics, Inc.
22820 Savi Ranch Parkway
Yorba Linda, CA 92887 USA
Warranty
LIMITED ONE-YEAR WARRANTY
Cal Test Electronics, Inc warrants these products to be free from defective material or workmanship
for a period of 1 year from the date of original purchase. Under this warranty, Cal Test Electronics, Inc
is limited to repairing this product when returned to the factory, shipping charges prepaid, within the
warranty period.
Units returned to Cal Test Electronics, Inc that have been subject to abuse, misuse, damage, or
accident, or have been connected, installed, or adjusted contrary to the instructions furnished by Cal
Test Electronics, Inc, or that have been repaired by unauthorized persons, will not be covered by this
warranty.
Cal Test Electronics, Inc reserves the right to discontinue models, change specications, price, or de-
sign of this device at any time without notice and without incurring any obligation whatsoever.
The purchaser agrees to assume all liabilities for any damages and/or bodily injury which may result
from the use or misuse of this device by the purchaser, his employees, or agents.
THIS WARRANTY IS IN LIEU OF ALL OTHER REPRESENTATIONS OR WARRANTIES EXPRESSED
OR IMPLIED AND NO AGENT OR REPRESENTATIVE OF CAL TEST ELECTRONICS, INC IS
AUTHORIZED TO ASSUME ANY OTHER OBLIGATION IN CONNECTION WITH THE SALE AND
PURCHASE OF THIS DEVICE.

3CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Contents
Notices......................................................2
User Manual Part Number .......................................2
Warranty.....................................................2
Contents ....................................................3
Compliance Information .........................................4
Safety .......................................................4
EC Declaration of Conformity - Low Voltage........................4
U.S. and Canadian Recognized Agency Certication.................4
Environmental ................................................4
Restriction of Hazardous Substances (RoHS 2) .....................4
Product End-of-Life Handling ...................................4
Terms & Symbols..............................................5
Terms .......................................................5
Symbols .....................................................5
Safety Information .............................................6
Usage Precautions.............................................6
IEC Measurement Category & Pollution Degree Denitions .............9
Introduction ..................................................10
Overview ....................................................10
Supplied Accessories...........................................10
Using Accessories .............................................11
Round Tip & Hook Tip.........................................11
Flat Bar Tip .................................................11
Optional Accessory ............................................11
Measurement Instructions .......................................12
Steps .......................................................12
Frequency Compensation .......................................14
Low Frequency Compensation Adjustment ..........................14
Specications.................................................15
Voltage Derating ..............................................17
Cleaning.....................................................18
China RoHS 2 ................................................19
Hazardous Substances Disclosure Table ...........................19

4CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Compliance Information
Safety
EC Declaration of Conformity - Low Voltage
Compliance was demonstrated to the following specication as listed in the Ofcial Journal of the Euro-
pean Communities: Low Voltage Directive: 2014/35/EU.
EN 61010-031:2015 Ed 2.0. Safety requirements for electrical equipment for measure-
ment, control and laboratory use - Part 031: Safety requirements for hand-held probe
assemblies for electrical measurement and test.
U.S. and Canadian Recognized Agency Certication
The probe is has been certied by TUV Rheinland Taiwan Ltd. (TUV) to conform to the following safety
standard and bears the cTUVus mark.
IEC 61010-031:2015 Ed. 2.0. Safety requirements for electrical equipment for mea-
surement, control and laboratory use - Part 031: Safety requirements for hand-held
probe assemblies for electrical measurement and test.
Environmental
Restriction of Hazardous Substances (RoHS 2)
The product and its accessories conform to the Directive 2011/65/EU (RoHS 2) on the restriction of the
use of certain hazardous substances in electrical and electronic equipment, inclusive of any modica-
tion and addendum to said Directive.
EN ISO 63000:2018 Technical documentation for the assessment of electrical and
electronic products with respect to the restriction of hazardous substances.
China RoHS 2 refers to the Ministry of Industry and Information Technology Order No.
32, effective July 1, 2015. See “Hazardous Substances Disclosure Table” on page
19.
Product End-of-Life Handling
The equipment may contain substances that could be harmful to the environment or human health if im-
properly handled at the product’s end of life. To avoid release of such substances into the environment
and to reduce the use of natural resources, we encourage you to recycle this product to an appropriate
system that will ensure that most of the materials are reused or recycled appropriately.
This product is subject to Directive 2012/19/EU of the European Parliament and the
Council of the European Union on waste electrical and electronic equipment (WEEE),
and in jurisdictions adopting that Directive, is marked as being put on the market after
August 13, 2005, and should not be disposed of as unsorted municipal waste. Please
utilize your local WEEE collection facilities in the disposition of this product.

5CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Terms & Symbols
The following terms, symbols, and denitions, individually or combination may appear on the product or
in this user manual.
Terms
A caution statement calls attention to an operating procedure, practice, or condition,
which, if not followed correctly, could result in damage to or destruction of parts or the
entire product.
Une mise en garde attire l’attention sur une procédure, une pratique ou une condition
d’utilisation qui, si elles ne sont pas suivies correctement, pourraient endommager ou
détruire une partie du produit ou le produit entier.
A warning statement calls attention to an operating procedure, practice, or condition,
which, if not followed correctly, could result in injury or death to personnel.
Un avertissement attire l’attention sur une procédure, pratique ou condition de
fonctionnement qui, si elles ne sont pas suivies correctement, pourraient entraîner des
blessures, voire la mort de l’utilisateur.
A note statement calls attention to an operating procedure, practice, or condition,
which, should be noted before proceeding.
Un énoncé de note attire l’attention sur une procédure, une pratique ou une condition
d’exploitation, qui doit être notée avant de continuer.
Symbols
CAUTION – Statements or instructions that must be consulted in order to nd
out the nature of the potential hazard and any actions which must be taken.
WARNING - HIGH VOLTAGE - possibility of electric shock.
The Conformitè Europëenne (CE) Mark is the European Union’s (EU) man-
datory conformity marking for regulating the goods sold within the European
Economic Area (EEA).
CAUTION
MISE EN GARDE
WARNING
AVERTISSEMENT
NOTE
REMARQUE

6CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Safety Information
Usage Precautions
The high-voltage probe is designed to prevent accidental shock to the operator when
properly used. This operating note must be read and understood prior to using the
probe. Improper procedure or incorrect analysis of the measurement situation can
result in serious shock.
La sonde haute tension est conçue pour éviter les chocs accidentels à l’opérateur
lorsqu’elle est correctement utilisée. Cette notice d’utilisation doit être lue et comprise
avant d’utiliser la sonde. Une procédure incorrecte ou une analyse incorrecte de la
situation de mesure peut entraîner un choc grave.
This high-voltage probe must only be used by personnel who are trained, experienced,
or otherwise qualied to recognize hazardous situations and who are trained to the
safety precautions that are necessary to avoid possible injury when using such a de-
vice.
Cette sonde haute tension ne doit être utilisée que par du personnel formé, expéri-
menté ou autrement qualié pour reconnaître les situations dangereuses et qui est
formé aux précautions de sécurité nécessaires pour éviter les blessures possibles lors
de l’utilisation d’un tel appareil.
When measuring higher frequency signals, be sure to comply with the Voltage vs
Frequency Derating Curve. Do not apply to the input any potential that exceeds the
maximum rating of the probe.
Lors de la mesure de signaux de fréquence plus élevée, assurez-vous de respecter la
courbe de déclassement tension/fréquence. N’appliquez à l’entrée aucun potentiel qui
dépasse la valeur nominale maximale de la sonde.
This high-voltage probe is designed for use with Measurement Category other than
II, III and IV only (formally CAT I). Do not use the probe for measurements performed
on circuits dened by any other measurement category or transient overvoltages of
more than 1500 V. Refer to IEC Measurement Category Denitions on page 9 for a
denition of measurement categories.
Cette sonde haute tension est conçue pour être utilisée avec des catégories de
mesure autres que II, III et IV uniquement (anciennement CAT I). N’utilisez pas la
sonde pour des mesures effectuées sur des circuits dénis par une autre catégorie de
mesure ou des surtensions transitoires de plus de 1 500 V. Reportez-vous à Déni-
tions des catégories de mesure CEI à la page 9 pour une dénition des catégories
de mesure.
The ground lead is critical to the safe operation of the probe. Failure to make this
connection when making high-voltage measurements may result in personal injury or
damage to the probe or oscilloscope. This connection must always be made BEFORE
the probe tip comes in contact with the high voltage and must not be removed until the
probe tip has been removed from the high-voltage source.
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING

7CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Le l de terre est essentiel au fonctionnement sûr de la sonde. Le non-respect de cette
connexion lors de mesures à haute tension peut entraîner des blessures corporelles
ou endommager la sonde ou l’oscilloscope. Cette connexion doit toujours être effec-
tuée AVANT que la pointe de la sonde n’entre en contact avec la haute tension et
ne doit pas être retirée tant que la pointe de la sonde n’a pas été retirée de la source
haute tension.
Do not exceed 60 seconds of contact between the probe and the circuit-under-test
when measuring voltages ≥8 kV DC, ≥5 kV ACrms, or ≥15 kVpk-pk AC. It is recom-
mended to wait 5 minutes between measurements.
Ne pas dépasser 60 secondes de contact entre la sonde et le circuit à tester lors de la
mesure de tensions ≥8 kV DC, ≥5 kV ACrms ou ≥15 kVpk-pk AC. Il est recommandé
d’attendre 5 minutes entre les mesures.
Hands, shoes, oor, and work bench must be dry. Avoid making measurements under
humidity, dampness, or other environmental conditions that might affect safety.
Les mains, les chaussures, le sol et l’établi doivent être secs. Évitez d’effectuer des
mesures dans des conditions d’humidité, d’humidité ou d’autres conditions environne-
mentales susceptibles d’affecter la sécurité.
To avoid injury, remove jewelry such as rings, watches, and other metallic objects. Do
not touch exposed connections and components when power is present.
Pour éviter les blessures, retirez les bijoux tels que bagues, montres et autres objets
métalliques. Ne touchez pas les connexions et composants exposés lorsque l’alimen-
tation est présente.
Do not work alone when working with high-Voltage Circuits.
Ne travaillez pas seul lorsque vous travaillez avec des circuits à haute tension.
The probe is designed to be used in ofce-type indoor environments.
• Do not operate in the presence of noxious, corrosive, ammable fumes, gases,
vapors, chemicals, or nely-divided particulates.
• Hands, shoes, oor, and workbench must be dry. Avoid making measurements
under humid, damp, or other environmental conditions that might effect the safety of
the measurement situation.
• The probe body should be kept clean and free of any conductive contamination.
Refer to the section on cleaning.
La sonde est conçue pour être utilisée dans des environnements intérieurs de type
bureau.
• Ne pas utiliser en présence de fumées nocives, corrosives, inammables, de gaz,
de vapeurs, de produits chimiques ou de particules nement divisées.
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT

8CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
• Les mains, les chaussures, le sol et l’établi doivent être secs. Évitez d’effectuer des
mesures dans des conditions environnementales humides, humides ou autres qui
pourraient affecter la sécurité de la situation de mesure.
• Le corps de la sonde doit être maintenu propre et exempt de toute contamination
conductrice. Reportez-vous à la section sur le nettoyage.
To reduce the risk of shock or re:
• Connect the probe to the oscilloscope before connecting probe to the circuit under
test. Disconnect the probe input from the circuit before disconnecting the probe from
the oscilloscope.
• Do not exceed the voltage rating category rating of the probe. Use only accessories
provided with probe.
• Keep nger behind the nger guard of the probe body.
• For your own safety, inspect the probe for cracks and frayed or broken leads before
each use. If defects are noted, DO NOT use the probe.
• Keep the probe’s output cables away from the circuit under test, as they are not
intended to be in contact with these circuits.
Pour réduire le risque de choc ou d’incendie:
• Connectez la sonde à l’oscilloscope avant de connecter la sonde au circuit à tester.
Déconnectez l’entrée de la sonde du circuit avant de déconnecter la sonde de l’os-
cilloscope.
• Ne dépassez pas la catégorie de tension nominale de la sonde. Utilisez uniquement
les accessoires fournis avec la sonde.
• Gardez le doigt derrière le protège-doigts du corps de la sonde.
• Pour votre propre sécurité, inspectez la sonde à la recherche de ssures et de ls
eflochés ou cassés avant chaque utilisation. Si des défauts sont constatés, NE
PAS utiliser la sonde.
• Gardez les câbles de sortie de la sonde éloignés du circuit à tester, car ils ne sont
pas destinés à être en contact avec ces circuits.
It is advisable to turn the high-voltage source off before connecting or disconnecting
the probe.
Il est conseillé d’éteindre la source haute tension avant de connecter ou de déconnect-
er la sonde. Éteindre la source haute tension.
Do not attempt to take measurements where the source and the test instrument chas-
sis or return lead is not properly grounded.
N’essayez pas de prendre des mesures lorsque la source et le châssis de l’instrument
de test ou le câble de retour ne sont pas correctement mis à la terre.
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT

9CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
IEC Measurement Category & Pollution Degree Denitions
Measurement Category (CAT) - classication of testing and measuring circuits according to the types of
mains circuits to which they are intended to be connected.
Measurement Category other than II, III, or IV: circuits that are not directly connected
to the mains supply.
Measurement Category II (CAT II): test and measuring circuits connected directly to ul-
tilzation points (socket outlets and similar prints) of the low-voltage mains installation..
Measurement Category III (CAT III): test and measuring circuits connected to the distri-
bution part of a building’s low-voltage mains installation.
Measurement Category IV (CAT IV): test and measuring circuits connected at the
source of the building’s low-voltage mains installation.
Pollution - addition of foreign matter, solid, liquid, or gaseous (ionized gases) that may produce a reduc-
tion of dielectric strength or surface resistivity.
Pollution Degree 2 (P2)- only non-conductive pollution occurs except that occasionally
a temporary conductivity caused by condensation is expected.

10 CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Introduction
Overview
The Cal Test CT4432 High-Voltage divider probe can be used with analog or digital oscilloscopes that
have an input resistance of 1 MΩ (±1%) and nominal input capacitance between 5 and 50 pF. The
CT4432 is a 1000:1 divider which extends the voltage measurement capability to 7 kV ACrms.
Features of the probe:
• Up to 10 kV (DC + ACpeak) or 7 kV (ACrms)
• 40 MHz bandwidth (-3dB)
• ±3% accuracy
• IEC/EN 61010-031
Figure 1 Probe and Supplied Accessories
Supplied Accessories
Table 1 CT4432 Accessory Replacements
Accessory Model No. Quantity
Round Tip CT2960A 1
Hook Tip CT2961A 1
Flat Bar Tip CT2962A 1
Deluxe Trimmer Tool CT3648 1
Compensation
Adjustment
Oscilloscope Connector
Insulated BNC male
Round Tip
Hook Tip
Flat Bar Tip
Trimmer Tool
Alligator Clip Ground
Lead (Fixed)
M5 Threaded
Stud

11 CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Using Accessories
Round Tip & Hook Tip
Thread either the Round Tip or the Hook Tip onto the probe’s M5 tip stud and securely hand-tighten.
Figure 2 Attaching the Round and Hook Tips
Flat Bar Tip
The end of the Flat Bar Tip can be clamped to the device-under-test (DUT). To secure the Flat Bar Tip
to the probe, use the supplied M5 ange nut (8 mm wrench or nut driver) as show in Figure 3.
Figure 3 Attaching the Flat Bar Tip
Optional Accessory
For connecting the probe to a Digital Multimeter (DMM) you can use the CT3197B High-Voltage Probe
BNC Converter. The high-voltage probe converter allows impedance matching of the probe’s 1 MΩ out-
put to a DMM’s 10 MΩ input. Usable with most quality DMMs, you can order this converter separately.
Figure 4 CT3197B High-Voltage Probe BNC Converter

12 CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Measurement Instructions
Before connecting the probe for your measurement, read all the warnings in this section and all of the
warnings in the section “Safety Information” on page 6.
Frequency compensate the probe to your oscilloscope prior to usage. See “Frequency Compensation”
on page 14.
Steps
1. Whenever possible, turn the high-voltage source off before making any connections.
2. Connect the alligator ground clip lead to a good earth ground or reliable chassis ground.
3. Connect the probe’s BNC connector to the oscilloscope’s BNC output.
4. On the oscilloscope, select the desired volts/division range. If the oscilloscope has probe attenua-
tion ration setting, set it to 1000:1, if available.
Before turning on the high voltage source, make sure that no part of the person holding
the prove is touching the device under test.
Avant d’allumer la source haute tension, assurez-vous qu’aucune partie de la per-
sonne tenant la preuve ne touche l’appareil à tester.
5. After conrming that the probe operator is not touching the device under test, turn on the high-volt-
age source.
6. Measure the voltage under test and observe the waveform on the oscilloscope.
Remember the actual voltage is 1000 times greater than the oscilloscope waveform if
the probe attenuation has not been set to 1000:1.
N’oubliez pas que la tension réelle est 1000 fois supérieure à la forme d’onde de l’os-
cilloscope si l’atténuation de la sonde n’a pas été réglée sur 1000:1.
7. Turn off the high voltage source.
8. Disconnect the probe tip from the high-voltage source.
9. Disconnect the probe’s ground clip lead.
Disconnect the probe tip from the high voltage source BEFORE disconnecting the
alligator ground clip lead.
Déconnectez la pointe de la sonde de la source haute tension AVANT de déconnecter
le l de la pince de masse crocodile.
Do not exceed 60 seconds of contact between the probe and the circuit-under-test
when measuring voltages ≥8 kV DC, ≥5 kV ACrms, or ≥15 kVpk-pk AC. It is recom-
mended to wait 5 minutes between measurements.
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING

13 CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Ne pas dépasser 60 secondes de contact entre la sonde et le circuit à tester lors de la
mesure de tensions ≥8 kV DC, ≥5 kV ACrms ou ≥15 kVpk-pk AC. Il est recommandé
d’attendre 5 minutes entre les mesures.
Do not attempt to take measurements from sources where the chassis or return lead is
not grounded.
N’essayez pas de prendre des mesures à partir de sources où le châssis ou le câble
de retour ne sont pas mis à la terre.
The ground lead is critical to the safe operation of the probe. Failure to make this
connection when making high-voltage measurements may result in personal injury or
damage to the probe or oscilloscope. This connection must always be made BEFORE
the probe tip comes in contact with the high voltage and must not be removed until the
probe tip has been removed from the high-voltage source.
Le l de terre est essentiel au fonctionnement sûr de la sonde. Le non-respect de cette
connexion lors de mesures à haute tension peut entraîner des blessures corporelles
ou endommager la sonde ou l’oscilloscope. Cette connexion doit toujours être effec-
tuée AVANT que la pointe de la sonde n’entre en contact avec la haute tension et
ne doit pas être retirée tant que la pointe de la sonde n’a pas été retirée de la source
haute tension.
Do not connect the ground clip to the high voltage source or the probe tip to the ground
for any reason.
Ne connectez pas la pince de mise à la terre à la source haute tension ou la pointe de
la sonde à la terre pour quelque raison que ce soit.
Do not make any oating measurements with the probe.
Ne faites aucune mesure ottante avec la sonde.
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT
WARNING
AVERTISSEMENT

14 CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Frequency Compensation
Use the following frequency compensation adjustments to compensate the probe for the oscilloscope’s
input capacitance. You should preform this adjustment whenever you connect the probe to a different
oscilloscope input channel or to a different oscilloscope.
Low Frequency Compensation Adjustment
1. Connect the probe to the oscilloscope.
2. Connect the probe tip to a square-wave function generator.
3. Adjust the function generator’s output to square-wave, 200 Hz frequency and 10 V amplitude.
4. Adjust the oscilloscope time base for approximately 2 ms/div so that you can see several waveform
cycles.
5. Using supplied trimmer tool, adjust the Low Frequency Adjustment Point (Figure 5) for the attest
square-wave top. Figure 6 shows the correctly compensated waveform.
Figure 5 Low Frequency Adjustment Point
Figure 6 Frequency Compensation Waveforms
Overcompensated Undercompensated Correctly Compensated

15 CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Specications
The probe and oscilloscope should be warmed up for at least 20 minutes before any testing and the
environmental conditions should not exceed the probe’s specied limits.
All entries included in the following tables are characteristics unless otherwise stated.
Toutes les entrées incluses dans les tableaux suivants sont des caractéristiques, sauf
indication contraire.
Table 2 Safety Specications
Parameter Condition
IEC/EN 61010-031:2015 Measurement Category other than II, III, or IV (formally CAT I)
Table 3 Electrical Specications (Not Warranted)
Parameter Characteristic
Maximum Input Voltage 10 kV (DC + ACpeak)
7 kV (ACrms)
Maximum Loading Current 100 µA
Attenuation 1000x
Bandwidth DC to 40 MHz (-3 dB)
Rise Time ≤ 8.8 ns
Input Resistance 100 MΩ ± 5%
Input Capacitance 2.0 pF
Accuracy
± 3% (below 10 kV) DC
± 3% at 1 kHz VAC
± 3 dB 0 to 40 MHz VAC
Temperature Coefcient ≤ 200 ppm/°C
Compensation Range 5 pF to 50 pF
NOTE
REMARQUE

16 CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Table 4 Mechanical Specications
Parameter Characteristic
Alligator Clip Lead Length 1 m (39”)
BNC Cable Length 2 m (6.6 ft)
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Humidity ≤ 80% RH @ 40°C (104°F)
Dimensions 340 mm length, 75 mm wide, 75 mm hight
Weight 250 g (0.55 lb)

17 CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
The following graph shows the voltage verses frequency derating curve for the probe.
When measuring higher frequency signals, be sure to comply with the Voltage vs
Frequency Derating Curve. Do not apply to the input any potential that exceeds the
maximum rating of the probe.
Lors de la mesure de signaux de fréquence plus élevée, assurez-vous de respecter la
courbe de déclassement tension/fréquence. N’appliquez à l’entrée aucun potentiel qui
dépasse la valeur nominale maximale de la sonde.
Figure 7 Voltage Derating Curve
WARNING
AVERTISSEMENT
Voltage (DC + ACpk)
Frequency
100V
1KHz 10KHz 100KHz 1MHz 10MHz 100MHz
1KV
10KV
100KV
20KV
(7KV)
(7 kV/1 kHz, 3 kV/100 kHz, 1 kV/1 MHz, 100 V/100 MHz)
Voltage Derating

18 CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
Cleaning
Clean only the exterior probe body and cables. Use a soft cotton cloth light moistened with a mild solu-
tion of detergent and water. Do not allow any portion of the probe to be submerged at any time.
Dry the probe thoroughly before attempting to make voltage measurements.
Séchez soigneusement la sonde avant d’essayer d’effectuer des mesures de tension.
Do not subject the probe to solvents or solvent fumes as these can cause deterioration
of the probe body and cables.
Ne soumettez pas la sonde à des solvants ou à des vapeurs de solvants car ceux-ci
peuvent détériorer le corps de la sonde et les câbles.
WARNING
AVERTISSEMENT
CAUTION
MISE EN GARDE

19 CT4432 10 kV High-Voltage Oscilloscope Probe User Manual
China RoHS 2
Hazardous Substances Disclosure Table
China RoHS 2 refers to the Ministry of Industry and Information Technology Order No.
32, effective July 1, 2015, titled Management Methods for the Restriction of the Use
of Hazardous Substances in Electrical and Electronic Products. To comply with China
RoHS 2, we determined this product’s Environmental Protection Use Period (EPUP)
to be 25 years in accordance with the Marking for the Restricted Use of Hazardous
Substances in Electronic and Electrical Products, SJT 11364.
中國 RoHS 2 指工業和信息化部令第 32 號，自 2015 年 7 月 1 日起生效，題為《電氣電子產品有害物質限制使用管
理辦法》。為符合中國 RoHS 2，我們根據電子電氣產品有害物質限制使用標誌 SJT 11364 將本產品的環保使用期限
(EPUP) 確定為 25 年。
Part Name
零件名稱
Hazardous Substance 有害物質
Lead
(Pb)
鉛
Mercury
(Hg)
汞
Cadmium
(Cd)
鎘
Hexavalent
Chromium
(Cr (VI))
六價鉻
Polybrominated
biphenyls (PBB)
多溴聯苯
Polybrominated
diphenyl ethers
(PBDE)
多溴二苯醚
Printed Circuit Board Assemblies
印刷電路板組件 x o o o o o
Electrical Components
電氣元件 x o o o o o
Metal Components
金屬部件 x o o o o o
Plastic Components
塑料部件 o o o o o o
This table is made per guidance of SJ/T 11364.
該表是根據 SJ/T 11364 的指南製作的。
O: Indicates that this hazardous substance contained in all of the homogeneous materials for the part is below the
limit requirement in GB/T 26572.
O: 表示該有害物質在該部件的所有均質材料中的含量低於 GB/T 26572 中的限量要求。
X: Indicates that this hazardous substance contained in at least one of the homogeneous materials used for this
part is above the limit requirement in GB/T 26572.
X: 表示該有害物質在用於該部件的至少一種均質材料中的含量高於 GB/T 26572 中的限量要求。

© Cal Test Electronics, Inc.
Electronic Format Only
Manual Part Number: 451-051-001
Revision: B
