CALEFFI 5026 series User manual

SAFETY INSTRUCTION
This safety alert symbol will be used in this manual to draw attention to safety related
instructions. When used, the safety alert symbol means ATTENTION! BECOME ALERT!
YOUR SAFETY IS INVOLVED! FAILURE TO FOLLOW THESE INSTRUCTIONS MAY
RESULT IN A SAFETY HAZARD.
CAUTION: All work must be performed by qualified personnel trained in the
proper application, installation, and maintenance of systems in accordance
with all applicable codes and ordinances.
CAUTION: Over-tightening and breakage can occur with the use of Teflon®
pipe joint compounds. Teflon®provides lubricity so that care must be
exercised not to over-tighten joints. Failure to follow these instructions
could result in property damage and /or personal injury.
WARNING: System fluids are under pressure or temperature can be
hazardous. Be sure the pressure has been reduced to zero and the
system temperature is below 100°F (38°C). Failure to follow these
instructions could result in property damage and/or personal injury.
Function
Float type automatic air vent designed to vent air that is released
from the water while being heated. Check valve on 5027 series
allows for easy replacement of air vent without purging the system.
Technical Characteristics
Connection: 1/8” NPT Male
1/4” NPT Male
Material: Body Brass
Seals EPDM
Maximum Working Pressure: Hot Water: 150 psi (10 bar)
Maximum Venting Pressure: 90 psi (6 bar)
Maximum Working Temperature: 240°F (115°C)
Automatic Air Vent -
Automatic Air Vent with check valve
38459.01
www.caleffi.com
CALEFFI
5026-5027 Series

Installation
The vent is installed in the vertical position, on the air
separator, on manifolds, on riser pipes and generally in
parts of the system where a concentration of air pockets is
to be expected.
Check valve on 5027 series should be installed prior to air
vent. Insure air vent is properly lined-up with female check
valve guide.
Service Instructions
There is no service required for the automatic air vent.
Operation Instructions
The automatic air vent can be used for manual or automatic venting of sealed hydronic
systems.
• For normal automatic venting, open cap one full turn for a slow release of air. A fast release
of the air will allow dirt or scale in the water to plug the operating mechanism. The small hole
in the side of the cap allows air to escape.
• To shutoff automatic air vent, screw cap down tight.
CAUTION: Corrosion or leakage can cause damage or injury.
Periodically inspect for signs of corrosion or leakage. If corrosion or
leakage is note, the vent must be replaced. Failure to follow these
instructions could result in property damage and/or personal injury.
CAUTION: Uncontrolled venting of water can occur with the automatic
air vent if dirt, scale, pipe joint compound or any other foreign materials
becomes trapped in the operating mechanism. Keep vent cap closed
during filling to prevent dirt from flowing into vent mechanism. Failure to follow
these instructions could result in property damage and/or personal injury.
WrongCorrect
Caleffi North America, Inc.
9850 South 54th Street
Milwaukee, WI 53132
T: 414.421.1000 F: 414.421.2878
CALEFFI
