CalMag CALULTRA 132 User manual

CALULTRADISINFECTIONUNITS
OWNERSMANUAL
Operation&InstallationInstructions
CALULTRA132
CALULTRA220
CALULTRA322
CALULTRA416
CALULTRA530
CALULTRA662
CALULTRA1500
CALULTRA2400
R
Reemmeemmbbeerr ddoonn’’tt gguueessss……....AASSKK
Calming troubled waters

CongratulationsonpurchasingthisCALMAGYORKSHITELIMITEDultravioletdisinfectionsystem.
BypurchasingaCALMAGYORKSHIRELIMITEDUVDisinfectionsystemyouarereceivingnotonly
ahighqualityproductbutalsopeaceofmind.
Protecting your water supply with a UV system gives you reassurance that the water being
treated by this UV system is microbiologically safe without the addition of any potentially
harmfulchemicals.
This process is simple, effective and carries the lowest O&M costs of all the disinfection
processes.
Simple maintenance, continuous disinfection and ultimately safe water, CALMAG YORKSHIRE
LIMITEDmakesitthateasy.

TABLEOFCONTENTS
SafetyConsiderations............................................................................................................................Page4
BeforeYouBegin...................................................................................................................................Page4
WaterQualityParameters.....................................................................................................................Page5
Assembly................................................................................................................................................Page6
SystemSizing.........................................................................................................................................Page7
Location.................................................................................................................................................Page7
Installation.............................................................................................................................................Page9
SystemDisinfection…………………………………………………………………………………………………………………………Page12
Cleaningquartzsleeve…………………………………………………………………………………………………………………….Page12
CleaningUVsensor………………………………………………………………………………………………………………………….Page13
Operation………………………………………………………………………………………………………………………………………..Page14
LampCountdown&Reset……………………………………………………………………………………………………………….Page16
FailureModes………………………………………………………………………………………………………………………………….Page16
CalUltraOptions………………………………………………………………………………………………………………………………Page17
WarrantyRegistration……………………………………………………………………………………………………………………..Page18
LimitedWarrantyStatement……………………………………………………………………………………………………………Page18
CALULTRASpecifications………………………………………………………………………………………………………………….Page20
Page

SafetyConsideration:
AlthoughyourUVsystemhasbeenmanufacturedtothehighestsafetystandards,extremecaremustbe
followedwhenoperatingand/ormaintainingyoursystem.
1. Wheneveryouareservicingthisequipment,alwaysdisconnectthepowercord.
2. AstheenergygivenoffbytheUVlampcanbeharmfultoyoureyesandskin,NEVERlookdirectly
atanilluminatedUV lampwithoutadequateeyeprotectionandalwaysprotectyourskinfrom
directexposuretotheUVlight.
3. Toensurethesystemprovidesadequatedisinfection,ALWAYSreplaceanycomponent(lampand
sleeve)withagenuinemanufacturer’sreplacementpart.
4. Donotoperatetheunitifithasanydamagedormissingcomponents.
5. Toavoidpossibleelectricalshock,useonlywithaproperlygroundedelectricaloutlet.
6. Neverperformanymaintenancetothesystemunlessyouarecomfortableindoingso.Contact
themanufacturerforserviceinstructionsifrequired.
7. Do not use this system for any purpose other than what it was intended for. Misuse of this
systemcouldpotentiallycauseharmtotheuser.
8. Yoursystemisintendedtobeinstalledindoorsandawayfromleakingplumbing.DONOTplug
theunitinifthesystemoranyofthecomponentsarewet.
9. Thedisinfectionsystemshouldbedirectlyinstalledintoagroundfaultcircuitinterrupter(GFCI).
Please note that as the CALMAG commercial units are available in 230 volt only, special High
current GFCI’s (GFI’s) are required. These special GFCI’s can easily be obtained through an
electricalsupplyhouse,orarereadilyavailableformalocalspa/hottubsupplystoreastheyare
commonlyusedintheseapplications.
10. WerecommendthatacompetentplumberorcertifiedUVtechniciancarryouttheinstallation.
BeforeYouBegin:
Beforeyoubegin,you’llneedthefollowing:
Tools
•Pipecutter,hacksaworotherspecializedtoolsrequiredtocutintoyourexistingplumbing(e.g.if
youhavePEXpiping)
•Solderingtools(torch,flux,emeryclothandsolder)
•Wrench(fortighteningfittings)
OtherMaterials
•Variousfittingsdependentonapplication/installation
•PTFEtape
Page
4

WaterQualityParameters:
UVdisinfectionisextremelyeffectiveagainstmicroorganismsbutonlyiftheUVlightcanpassthroughthe
waterit needsto treat.This means that the qualityof yourwater isvery importantin orderto ensure
completedisinfection.
Itisimperativethatyouhaveyourwatertestedforattheleasttheparameterslistedbelow.Ifthewater
exceeds the listed parameters CALMAG YORKSHIRE LTD strongly recommends that appropriate
pretreatmentequipmentbeinstalled(pretreatmentwilldependonparameterstargeted):
Hardness: <7GPG(120mg/L)–ifhardnesslevelis7GPG(grainspergallon)
orslightlybelowthequartzsleevemustbecleanedperiodicallyinordertoensureefficientUV
penetration;ifabovethewatermustbesoftened
Iron(Fe):<0.3ppm(0.3mg/L)
Manganese(Mn):<0.05ppm(0.05mg/L)
Turbidity:<1NTU
Tannins(organics):<0.1ppm(0.1mg/L)
UVT(transmittance):>85%(PleasecontactCALMAGYORKSHIRELTDifwaterhasaUVT
thatislessthan80%forpretreatmentrecommendations)
Youcanhaveyourwatertestedataprivateanalyticallaboratoryorcontactyourlocalcouncilforadvicein
regardstoyourlocalenvironmentalhealthofficer.Itisalwaysrecommendedtoinstallprefiltrationofat
least 5 microns prior to a CALMAG YORKSHIRELIMITED UV disinfection system. CALMAG YORKSHIRE
LIMITEDcansupplyprefiltersonallCommercialunitsrangingfromtheCALULTRA132totheCALULTRA
2400.
Page
5

Assembly:
Step1:Unpackthesystemandensureallthecomponentsareincludedwiththesystem.Yoursystemis
shippedwiththefollowingcomponents:
Page
6

SystemSizing:
AllCALMAGYORKSHIRELIMITEDUVsystemsareratedforaspecificflowrateunderspecificwaterquality
parameters. The equipment has been designed to ensure that the appropriate dose will be delivered
provided all outlined parameters are met. PLEASE NOTEthat unless a flow restrictor is part of the
installation,thesystemmaypassmorewaterthroughthesystemthanwhatthesystemisratedat.Ifthis
happens,thesystemmaybedeliveringaUVdoselevelthatisbelowwhatmaybeexpected.Asaresult,
themaximumflowasspecifiedintheequipmentspecificationsshouldbestrictlyadheredto(alowerflow
isnotaconcernasthedosewillincreaseduetoalongercontacttime).
Itisimportanttoknowthemaximumflowratethatyourwatersystemdelivers.Ifyoudonothavethis
informationyoucansimplyfilla1gallonbucketwithwaterfromafaucetandtimehowlongittakestofill
up.Thiswillbethemaximumflowrateforthatparticularwatersystem.TheappropriateCalmagUVunit
shouldthenbechosen.
PLEASE NOTE:It is always better to oversize your UV system than to undersize. For example, if your
pumpdelivers190litresperminuteitisrecommendedtoinstalltheCALULTRA220UVunit.Therewillbe
occasionswhereyourhomeisusingwateratthepump’smaximumcapacity.
Location:
Step 1:Find a suitable location to mount the UV chamberand the accompanying control panel. In
choosingyourlocationensurethatthepanelislocatedwithin5feetofagroundfaultcircuitinterrupter
(GFCI)andthatthereiseasyaccesstothemaincoldwaterlinepriortoanybranchlinesandbeforethe
hotwater heater.The panelcan be upto 8 feetaway from thechamberoramaximumof5metersif
custom lamp cables are ordered (for an additional cost). If you have any other water treatment
equipment,suchasasoftenerorwaterfilter,ensurethattheUVisthelastpieceoftreatmentequipment.
PLEASENOTE:AllCALMAGYORKSHIRELTDUVdisinfectionsystemsareintendedforindooruseonlyas
theyshouldnotbeexposedtotheelements.
Step2:TherearetwodifferentCALULTRAcontrolpanels,dependingonwhichsystemispurchased.The
threesinglelampsystems(“35”,“55”and“85”series)useacontrolpanelthatis30.0x20.0x16.0cm
(11.8x7.9x6.3")insize(seeFigure2),whilethethreetwolampsystemsuseacontrolpanelthatis40.0
x30.0x16.0cm(15.8x11.8x6.3")insize(seeFigure3).
Figure2.OneLampSystemsFigure3.TwoLampSystems
Page
7

Step3:Your UV systemincludes mounting hardwarefor the UV chamberand the control panel. If the
suppliedfastenersarenot compatiblewith thestructurein whichyou are mountingthe device,please
ensureyouusethecorrectfasteners.
Step4:Tofacilitatelampremoval,ensurethereisenoughspaceatoneendtosafelyremovetheUVlamp
and/orquartzsleeve(aspaceequaltothelengthoftheunitwillsuffice)(seeFigure4).
Figure4.LampRemovalSpacing
Page
8

Installation:
Step 1:The UV disinfection system should always be the last piece of treatment before the water
branchesofftoanyhotorcoldwaterlines.
Step2:CALMAGYORKSHIRELTDstronglyrecommendsthata5micronfilterbeinstalledbeforetheUV
systemforafinalpolishingstepbeforethewaterisdisinfected.
Step3:Thechambercanbeinstalledeitherhorizontallyorverticallyusingtheclampsprovided.
Step4:Ifyoudonotknowtheflowrateofthewatersupplyintheapplication,itisrecommendedthat
youuseaflowrestrictorsothattheratedflowofyourparticularCALULTRAsystemisnotexceededand
the UV dose is not compromised. The flow restrictor should be installed on the outlet port of the
chamber.
Step 5:It is strongly recommended to have a licensed plumber connect the UVchamberto the water
supply and may be a requirement depending on where you are located. If you are attempting this
yourself,ensureyouhaveallthenecessarytoolsandfittingstoaccomplishthistask.
Step 6:Although there are many methods of installation, this manual will provide a recommended
procedure using copper plumbing and standard soldering methods. CALMAG YORKSHIRE LTD
recommendstheuseofunions,abypassassemblyandshutoffvalvesasthiswillallowyoutoisolateand
remove the UV chamberif necessary (this is a recommended method only however it allows for the
maximumconveniencebutitrequiresextracomponentsandmoretimeforinstallation).
Step 7: Before you cut into the cold water line, measure and cut all piping as per the recommended
layout.Onceallthecomponentsareready,startbyinstallingthefemaleadaptersontotheportsofthe
chamber.Toensureaproperseal,theuseofPTFE™tapeisrecommendedonallthreadedconnections.
Step8:Nextsolderalltheassemblytogether,includingballvalvesandunionsandfinallyconnectedthe
bypassassemblytothecoldwaterfeedline(waterinandwaterout).
Step9:YoucannowgentlyremovethequartzsleevefromitspackagingbeingVERYcarefulnottotouch
thelengthwithyourhands.Theuseofcottongloves(notincluded)isrecommendedforthisprocedureas
oilsfromourhandscanleaveresidueonthesleeveandlampwhichcanultimatelyblocktheUVlightfrom
gettingtothewater.Inthepackage,youwillfindtwolubricatedOrings.
Step 10:Carefully slide the sleeve into the chamberuntil you can feel it hit the opposite end of the
chamber.Maneuverthesleevegentlyuntilitslidesthroughtheoppositeendofthechamber.Witha¼”
ofthesleevestickingouteachendofthechamberslideoneOringontoeachend.EnsurethateachO
ring is butted up against the chamber(see Figure 5). Assemble the bottom gland nut (the black nut
without the through hole) onto the threaded end of the chamberand tighten. The gland nuts have a
positivestoptoavoidovertightening,handtightenONLY.Next,assemblethetopglandnut(theblacknut
withthe throughhole) ontothethreaded endof the chamberandtighten.Slidetheprovidedstainless
steel compression spring inside the quartz sleeve. This spring simply sits in the bottom of the quartz
sleeveandworkswiththelampandconnectortocreatetheproperlampalignment.
Page
9

UV Sensor port
UV Chamber
UV Controller
UV Sensor
UV Sensor port
chamber
PTFE
chamber
chamber
chamber
chamberrin
chamber
leaks.
Page
10

Step 13:The control panel can now be mounted on the wall. It should always be above or beside the
chamberto ensure that no moisture can deposit on any of the connections. For safety purposes the
controlpanelshould be connectedto aground fault circuit interrupter(GFCI) (alsoknown asa ground
faultinterrupter(GFI)). The controlpanel can bemountedupto8feetawayfromthechamberunless
customcableshavebeenpurchased.
Step14:YoucannowremovetheUVlampfromitspackagingbeingcarefulnottotouchthelampquartz
with your hands. Again, the use of cotton gloves is recommended to avoid deposited oils on the lamp
glass.Alwaysholdthelampbytheceramicends.CarefullyinserttheUVlampintothechamberslidingit
insidethequartzsleevelocatedinsidethechamber(donotdropthelampintothechamber).Withthe
lampoutsideofthechamber,affixtheUVlamptothelampconnectorasshowninFigure8.
Step15:Beforethelampiscompletelyinsertedintothe sleeve,affixthelamtothelamp connectoras
shown in Figure 8. Affix the connector into the gland nut by inserting the connector into the nut and
turningtheconnectorapproximately¼turntolocktheconnectortotheglandnut(seeFigure9).
Figure8.UVLampConnection
Figure9.Connector
Step16:AffixthecaptivegroundscrewtothegroundlugontheUVchambertoensurepropergrounding
continuity(seeFigure10).
Figure10.GroundScrewConnection
Page
11

Step17:YoursystemisnowreadytobepluggedintotheappropriateGFCIprotectedoutlet.Plugtheunit
inandrefertothe“SystemDisinfection”sectionbeforeanywaterisallowedtoflowthroughthesystem.
SystemDisinfection:
Nowthatthesystemisinstalledyouwillneedtodisinfectthelinesthroughouttheentirehomeorfacility.
Toaccomplishthis,pleasefollowthesesimplesteps:
Step1:Beforeperformingthistask,checktomakesurethatthereareno“deadends”inthelineswithin
the water system you are treating as these can harbor bacteria. Also ensure that the UV system is
poweredupandreadyforoperationbeforeyoustartthisdisinfectionprocess.
Step 2:Remove the cartridge from the filter sump and fill with 12 cups of household bleach (most
householdbleachesare5.25%chlorine).Replacefiltersumpandslowlyturnonthewatersupply.
Step 3:Go to each location in the home or facility (including outdoor taps) and run some water until
chlorine can be detected (by smell). Ensure all faucets, dishwasher, shower heads, washing machine,
toilets,showers,refrigerators,etc.areallchecked.Oncethechlorineisdetectedateachlocationcloseall
faucetsandletthechlorinesitinthelinesforaminimumof30minutes.
Step 4:After 30 minutes, reinstall the filter cartridge into the filter sump and then flush the chlorine
solutionbyopeningallfaucetsandletthemrununtilchlorinecannolongerbedetected(bysmell).Your
home/facilityhasnowbeencompletelydisinfectedandyourCALULTRAUVsystemisreadytoinactivate
anymicroorganismsthatenterthewatersystem.
PLEASE NOTE:This procedure must be performed following any time the UV is shut down for service,
withoutpower,orisinoperativeforsomereasoninordertoavoidpossiblecontaminationofthewater
lines.
CleaningtheQuartzSleeve:
Depending on the water quality, the quartz sleeve may require periodic cleaning. At a minimum, the
quartz sleeve should be cleaned on an annual basis. The following steps outline a basic cleaning
procedure.
Step1:Ifthesystem hasan inletshutoffvalve, shut thisvalve offto preventwater flowthrough the
system.Ifthereisnoinletshutoffvalve,turnoffmainwaterinletvalve(andturnoffwaterpumpifyou
haveone).
Step2:DisconnectpowercordofUVsystemfromelectricaloutlet.
Step3:Releasewaterpressurebyopeningadownstreamfaucetandclosetheoutletshutoffvalveifthe
installation incudes one (if there is no outlet shutoff valve, be prepared for water leakage from the
systemastheheadpressureinthesystemwillcausewatertoflowbackthroughtheoutletplumbingand
throughthechamber).
Step4:RemovethecaptivegroundscrewfromthegroundlugontheUVchamber.
Page
12

Step5:Remove the lamp connector from the chamber(gland nut) by pushing the connector in and
turning it ¼ turn counterclockwise (gently pull on the lamp cable to ensure the connector is seated
properly).
Step6:Pulllampoutofchamberstillattachedtoconnector.
Step7:Removetheglandnutfromeachendofthechamberexposingtheendsofthequartzsleeve.
Step8:WhileholdingontobothendsofthesleevecarefullyremovetheOringfromtheendopposite
from the lamp connection and then pull the quartz sleeve out of the chamber (ensure that no water
enterstheinsideofthequartzsleeve);removesecondOring
Step9:Usingasoft,lintfreeclothortowelwipethesleevedownusingagoodcommercialscalecleaner
toremoveanyscalingorirondepositsthatmaybeontheoutsideofthequartzsleeve.Becarefulnotto
getanymoistureorliquidsontheinsideofthesleeve.
Step10:Wipethesleevewithseparatedrycloth.
Step11:Oncethesleeveiscleanedslideitbackintothechamberfollowingthestepsoutlined.
Step12:ReplacebothOrings.
CleaningtheUVSensor(ifapplicable):
Depending on the water quality, the UV sensor may require periodic cleaning. At a minimum, the UV
sensorshouldbecleaningonanannualbasis.Thefollowingstepsoutlineabasiccleaningprocedure.
Step1:Ifthesystem hasan inletshutoffvalve, shut thisvalve offto preventwater flowthrough the
system.Ifthereisnoinletshutoffvalve,turnoffmainwaterinletvalve(andturnofwaterpumpifyou
haveone).
Step2:DisconnectpowercordofUVsystemfromelectricaloutlet.
Step3:Releasewaterpressurebyopeningadownstreamfaucetandclosetheoutletshutoffvalveifthe
installation incudes one (if there is no outlet shutoff valve, be prepared for water leakage from the
systemastheheadpressureinthesystemwillcausewatertoflowbackthroughtheoutletplumbingand
throughthechamber).
Step4:Place something under the chamberto catch any water that may come out of the chamber
duringtheremovaloftheUVsensor.
Step5:Unscrew(counterclockwise)sensornutfromthechamberandpullthesensorslowlyoutofthe
sensorport.
Step6:Holdingthesensorinyourhandwipetheflatportion(sensorface)ofthesensorwithisopropyl
alcoholusingacleanlintfreecloth.
Step7:Replacesensorasperinstructionsofthismanual.
Page
13

Operation:
The CALMAG YORKSHIRE LTD CALULTRAsystem comes with a feature laden control system that
incorporatesboththelampdriver(ballast)andcontrolfeaturesinonemodularpanel.CAUTION:Priorto
performinganymaintenanceonyourUVsystem,youmustalwaysdisconnectthepower(DONOTSIMPLY
USETHESWITCHONTHEFRONTOFTHECONTROLLER).
CALULTRAControlPanel
Thecontrolpanelfeaturesapowerfactorcorrectedandconstantcurrentlamp
driver.Simplisticinoperation,thepanelfeaturesanLEDdisplayforremaining
lamplife,totalrunninghours,audibleand visuallampfailure,remote onand
solenoidready.Whenthe UVlamp(s)is/areon,thesecond LEDboxwillread
“ON”.WhentheUVlamp(s)is/arenoton,theLEDboxwillread“OFF”andan
audiblealarmwillsound.PleaseNote:IftheLEDreads“OFF”andthealarmis
sounding then the water from the system should NOT be consumed. If any
water does pass through the UV system during this period,please follow the
disinfection procedure as outlined in this manual before the water is
consumed.ItshouldalsobenotedthatontheCALULTRAsystemeventhough
thissystemdoeshaveavisualandaudiblewarningbuiltintothecontrols,the
LEDreading“ON”doesnotnecessarilyindicatethatthewatercomingfromthis
systemisinfactpotable(safetodrink).Thissystemdoesnotmeasurethelevel
of disinfection; it simply measures the “ONOFF” status of the lamp. For a
constantreassuranceofsafewaterqualityyoushouldconsidertheCALULTRA
upgradewithaUVsensor(youcanalsoaddtheoptionalRSRUVsensoronall
CALULTRAsystems). Please have your water checked for microbiological
contaminantsonaregularbasis.
CALULTRA3PositionSwitch
Thecontrolpanelfeaturesa3positionuserselectableswitch.ThisswitchisNOTapowerswitchandit
shouldbenotedthatoncethecontrolpanelispluggedintoanelectricaloutlet,theunitispoweredand
considered“ON”.Theswitchfunctionsasfollows:
“ON”position – Power issupplied tothe lamp(s)and the controllerwillread
“ON”onthelowerLEDdisplayonunitswithoutaUVsensorinstalledandwill
read the intensity (or UV output) on units with a UV sensor installed. Please
note that when first starting the lamp(s), the system will cycle through a
decliningnumericalsequencewhilethelamp(s)reachesfullpower.
“OFF”position–PowerisNOTsuppliedtothelamp(s)andthelamp(s)willbe
off.Thecontrollerwillread“OFF”onthelowerLEDdisplay.
Page
14

“REMOTE” position – In this position, the control of the unit is placed in a
remote location (i.e. a computer) via an attached remote cable. Through this
cable, the operator must supply a 24 volt power source that will allow these
“drycontacts”tooperate.Thescreensandthe“ON”and“OFF”functionswill
now all be operated remotely. While the UV controller is in the remote
position,EXTREMECAUTIONmustbeexercisedaroundtheUVchamberwhile
servicingtheUVlampsastheymaybeturnedonoroffremotelywithoutthe
operatorsknowledgeorcontrol.Asaresult,itisnotrecommendedtoservice
the lamp(s) while the controller is in the “REMOTE” mode and the system
should be physically disconnected from the power source, or the controller
manuallyswitchedtothe“OFF”positionwhileservicingthelamp(s).
CALULTRAPowerupSequence
Uponstartup, the CALULTRAcontrolswillindicatewhen thesystemis ready
fortreatmentby the indicatedcountdownonthebottomLEDscreen.Inthis
time,theUVOutputofthelampisincreasingandthe“ReadyForFlow”logicis
“NO”.After180seconds,iftheUVoutputlevelisadequatefordisinfection,the
“ReadyforFlow”logicis“YES”andthesystemwilloperateasintended.
UVOutput
If your system is equipped with a UV sensor, CALULTRAwill display the UV
outputin either“% UV Intensity”or “mW/cm2”.The defaultoutput is“% UV
Intensity” and to toggle between these two outputs, simply press the button
locateddirectlybeneaththebottomLEDscreen.TheUVOutputLEDscreenwill
indicatethelevelofUVintensitythatisbeingdetectedwithinthechamberby
thesensor.Thiswillalwaysbevisibleonthefrontofthecontrolpanel.Things
that can affect the UV Output are poor water quality, scaling of the quartz
sleeveand/orsensor,lampfailure,expiredlamplifeandsensorfailure.
WhentheUVoutputdropsto60%(or12mW/cm2),the systemwilldisplaya
“LOW UV” warning light in yellow and the system will emit an intermittent
audiblechirptosignalthis“LOWUV”condition.WhentheUVoutputdropsto
50%(or10mW/cm2),thesystemwilldisplaya“LOWUV”warninglightinred
andthesystemwillemitanconstantaudiblealarmtosignalthiscritical“LOW
Page
15

UV”condition.Additionally,atthispoint,thecontrolleralsoprovidesasignalto
deactivatetheflowofwater ifimplimentedinthe system.Whenthesystem
registersalowUVcondition,theonlywaytosilencethealarmsistocorrectthe
reasonforthislowUVcondition.Thismaybetheresultofanagedlamp,ora
fouledsleeveand/orsensor,orperhapsachangeinwaterquality.Pleaserefer
toothersectionsinthismanualfordirectiononremedyingthesesituations.
CALULTRALampCountdownSequence
TheCALULTRAcontrolpaneldisplaysacountdownfeaturethatdisplaysthenumberofhoursremaining
until a lamp change is required. At 512 hours until lamp change the numerical lamp change value will
begintoflashindicatingthatlampexpirationisnear.At“zerohoursremaining”,thesystemregisteran
audiblealarm.Ifyouwishtosilencethisaudiblealarmcondition,simplypressandholddownthebutton
located directly beneath the top LED screen for a period of three seconds.PLEASE NOTE:During the
condition of lamp expiration, the water may be unsafe for consumption and should not be consumed
withoutanotherformofdisinfection.
CALULTRALampCountdownResetSequence
After changing the lamp on the CALULTRAsystems, the control panel must be reset in order for the
systemtobeginitscountdownfunctiononthenewlyinstalledlamp.Toreset,simplypressandholddown
thebuttonlocateddirectlybeneaththetopLEDscreenforaperiodoffifteenseconds.Releasethebutton
andthelampcountdownfeaturehasnowbeenreset.
CALULTRAFailureModes
TheCALULTRAcontrolpanelcontinuouslymonitorsyourUVsystemandifthereisaproblemwiththe
systemthepanelwillprovidebothavisualandaudiblesignalindicatingthespecificfaultthatmaybe
adverselyaffectingtheoperationofyoursystem.Thefaultconditionsarelistedinaprioritysequenceas
follows:
LAMPFAILURE:Ifatanytimeduringtheoperationofthesystem,theUV
lamp fails to be illuminated, the controller will return both an audible and
visualsignalindicatinglampfailure.Inaddition,aconstantaudiblebuzzerwill
soundduringlampfailure.
Page
16

UVSENSORFAILURE:AssumingthesystemhasaUVSensorinstalled,ifat
anytimeduringtheoperationofthesystem,aUVsensorfails,thecontroller
willreturna“FAIL”indicatoronthebottomLEDscreenandaconstantaudible
buzzerwillsoundduringsensorfailure.
CALULTRAOptions
Althoughfeaturessuchasremotemonitoringand420mAoutputarebuiltintothecontroller,their
outputrequiresoptionalcablesasshownbelow.Eachcableandmatingconnectorareuniqueinregards
totheirsize,sothereisnochanceofinstallingthewrongcableinthewrongconnector.
ThefollowingoptionalcablesareavailableforuseonyourCALULTRAsystems.Contactyourauthorized
distributorforpurchasinginformation.
420maCable:Includesconnectorand10m(33’)ofcable
toprovidea420mAsignaltoaremotelocation.
RemoteMonitoringCable:Includesconnectorand10m
(33’)ofcabletoremotelycontroladrycontactsignal.Canbeusedfor
drycontactsand/or420mAoutput.
EthernetModule:Allowsforall controllerfunctionstobeconnectedtoacomputerviaanEthernet
cable.Thismoduleiscurrentlyindevelopmentandisnot availableatthispointintime.Pleasecontact
formoredetails.
4-20 mA port
(for 210011 cable)
UV Sensor port
remote monitoring (dry contacts)
(for 210010 cable)
Page
17

WarrantyRegistration
It is imperative that you complete the warranty registration process. This not only registers your UV
disinfectionsystemfortheprovidedmanufacturer’swarranty,butalsoallowsthefactorytoprovideyou
with any important product updates or technical bulletins concerning your product. The registration
process is a simple process and can be done online at http://www.calmagltd.comor by filling out the
enclosedwarrantycard.PleaseensurethatALLinformationisfilledin,includingavalidemailaddress.
PLEASENOTE:Thisinformationisforthesolepurposeoftechnicalsupportforyourdisinfectionsystem
andwillnotbeused,orsold,toanyotherorganizationforanyotherpurpose.PleaserefertoCALMAG
YORKSHIRELTD’sPrivacyPolicystatementathttp://www.calmagltd.comforfurtherinformation.
LimitedWarrantyStatement
ProductsmanufacturedbyCALMAGYORKSHIRELIMITEDarewarrantedtotheoriginaluseronlytobefree
ofdefectsinmaterialandworkmanshipforaperiodasspecifiedbelow.Thiswarrantyonlyappliestothe
originalpurchaserandisnottransferable.
UVSYSTEMS
Five(5)yearLimitedWarrantyonthestainlesssteelunits,fromthedateoforiginalpurchase,or
installation(documentationrequiredforverification).
ELECTRONICS
One(1)yearLimitedWarrantyontheballastsandcontrollers,fromthedateoforiginalpurchase,or
installation(documentationrequiredforverification).
UVLAMPS,UVSENSORS&QUARTZSLEEVES
One(1)yearLimitedWarrantyonallCALMAGYORKSHIRELIMITEDultravioletlamps,UVsensorsand
quartzsleevesfromthedateoforiginalpurchase(documentationrequiredforverification).
CALMAGYORKSHIRELIMITEDwarrantsthatitwillrepairorreplace,atCALMAGYORKSHIRELIMITED’ssole
discretion,anyultravioletsystemorcomponentthatisdefectiveinmaterialsorworkmanshipforthe
periodasoutlinedabove,subjecttothe“LimitationsofWarranty”asoutlinedbelow.CALMAGYORKSHIRE
LIMITED'sliabilityunderthiswarrantyshallbelimitedtorepairingorreplacingatCALMAGYORKSHIRE
LIMITED'sdiscretion,withoutcharge,anyproductthatCALMAGYORKSHIRELIMITEDmanufactures.
CALMAGYORKSHIRELIMITEDwillnotbeliableforanycostsofremoval,installation,transportation,or
anyotherchargeswhichmayariseinconnectionwithawarrantyclaim.Productswhicharesoldbutnot
manufacturedbyCALMAGYORKSHIRELIMITEDaresubjecttothewarrantyprovidedbythemanufacturer
ofsaidproductsandnotbyCALMAGYORKSHIRELIMITED’swarranty.CALMAGYORKSHIRELIMITEDwill
notbeliablefordamageorweartoproductscausedbyabnormaloperatingconditions,accident,abuse,
misuse,unauthorisedalterationorrepair,oriftheproductwasnotinstalledinaccordancewithCALMAG
YORKSHIRELIMITED’sprintedinstallationandoperatinginstructions.
Page
18

LIMITATIONSOFWARRANTY
Thiswarrantydoesnotapplytoanyofthefollowing:
•WaterQualityParameterslieoutsideofthefollowingranges
•Hardness>120mg/L(7gpg)
•Iron>0.3mg/L(ppm)
•Manganese>0.05mg/L(ppm)
•Tannins>0.1mg/L(ppm)
•Turbidity>1NTU
•Transmittance(UVT)<75%
•Aproductthathasbeenincorrectlyinstalledaccordingtothetechnicalinstallationmanual.
•Aproductthathasbeenmodifiedinanymanner,unlessapprovedbythemanufacturer.
TOOBTAINWARRANTYSERVICE
Toobtainserviceunderthiswarranty,youmustfirstcontactCALMAGYORKSHIRELIMITED’SCustomer
Serviceat01535210320toobtainaGoodsReturnNumberandauthorisation.Youwillthenneedto
returntheproductthroughtheoutletwheretheproductwasoriginallypurchased,togetherwithproofof
purchaseandinstallationdate,failuredate,andsupportinginstallationdata.Unlessotherwiseprovided,
themerchantwillcontactCALMAGYORKSHIRELIMITEDforinstructionsonreturningtheproduct.Any
defectiveproducttobereturnedtoCALMAGYORKSHIRELIMITEDmustbesentcarriageprepaid;
documentationsupportingthewarrantyclaimand/oraGoodsReturnNumbermustbeincludedifso
instructed.
CALMAGYORKSHIRELIMITEDWILLNOTBELIABLEFORANYINCIDENTALORCONSEQUENTIALDAMAGES,
LOSSES,OREXPENSESARISINGFROMINSTALLATION,USE,ORANYOTHERCAUSES.THEREARENO
EXPRESSORIMPLIEDWARRANTIES,INCLUDINGMERCHANTABILITYORFITNESSFORAPARTICULAR
PURPOSE,WHICHEXTENDBEYONDTHOSEWARRANTIESDESCRIBEDORREFERREDTOABOVE.
THISLIMITEDWARRANTYISTHESOLEANDEXCLUSIVEWARRANTYMADEBYCALMAGYORKSHIRE
LIMITEDWITHRESPECTTOTHEPRODUCT,ANDISGIVENINLIEUOFANYOTHERWARRANTY.TOTHE
EXTENTALLOWEDBYAPPLICABLELAW,ANYANDALLEXPRESSORIMPLIEDWARRANTIESNOTSETFORTH
HEREINAREWAIVEDANDDISCLAIMED,INCLUDINGANYIMPLIEDWARRANTYOFMERCHANTABILITYOR
FITNESSFORAPARTICULARUSE.CALMAGYORKSHIRELIMITED’SLIABILITYUNDERTHISLIMITED
WARRANTYISLIMITEDSOLELYTOTHOSELIABILITIESSETFORTHABOVE.INTHEEVENTTHATANY
PROVISIONOFTHISLIMITEDWARRANTYSHOULDBEORBECOMEINVALIDORUNENFORCEABLEUNDER
APPLICABLELAW,THEREMAININGTERMSANDCONDITIONSHEREOFSHALLREMAININFULLFORCEAND
EFFECTANDSUCHINVALIDORUNENFORCEABLEPROVISIONSHALLBECONSTRUEDINSUCHAMANNER
ASTOBEVALIDANDENFORCEABLE.
Page
19

CALMAGYORKSHIRELIMITEDEQUIPMENT
SPECIFICATIONS
CalUltracommercialultravioletsystems
MODEL
CalUltra132CalUltra220CalUltra322CalUltra416
FlowRate@30mJ/cm2
@95%UVT
35GPM58GPM85GPM110GPM
132lpm220lpm322lpm416lpm
8m3/hr.13.2m3/hr.19.3m3/hr.25m3/hr.
Alternativeflow@
16mJ/cm2@95%UVT
66GPM109GPM167GPM207GPM
250lpm413lpm632lpm784lpm
15m3/hr.24.8m3/hr.37.9m3/hr.47m3/hr.
PortSize1½"2"2"2½"
Electrical230240V./5060Hz.
PlugTypeBritishStandard,BS1363
LampWatts104152207304
Power(watts)120170220320
ReplacementLampBULBB132BULBB220BULBB322BULBB416(2)
ReplacementSleeveSLEEVEQS132SLEEVEQS220SLEEVEQS322SLEEVEQS416(2)
ChamberDimensions4x27.2x5.6”
(10x69x14cm)
4x35.8x5.6"
(10x91x14cm)
4x46.8x5.6"
(10x119x14cm)
6x35.8x7.9"
(15x91x20cm)
ChamberMaterialPolished304StainlessSteel,A249PressureRatedTubing
ControllerDimensions11.8x7.9x6.3"(30.0x20.0x16.0cm)15.8x11.8
x6.3”
MaximumOperatingPressure10.3bar(150psi)
OptimumWaterTemperature260°C(36148°F)
UVMonitorPort
(upgradeability)YesYes
RemoteON&DryContactsYes
420mAOutputYes
LampAgeCounterYes
VisualLampOutIndicator&
AudibleLampOutAlarmYes
Page
20
This manual suits for next models
7
Table of contents
Popular Water Filtration System manuals by other brands

CARVIN
CARVIN Splash Pak Owner's manual and installation guide

Watts
Watts SmartStream UV WB002 Installation, operation and maintenance manual

Schenker
Schenker ZEN 30 Installation, use and maintenance manual

West Marine
West Marine 13915137 instructions

Kobold
Kobold MFR-00 operating instructions

Sealey
Sealey SMC30.V2 manual

Acqua Brevetti
Acqua Brevetti BravoMAX A Installation and operating manual

Berbel
Berbel permalyt BUR 125 DL installation instructions

Grizzly
Grizzly G5955 owner's manual

Watts
Watts PWFGAC1 Installation, operation and maintanance manual

Pentair
Pentair FRESHPOINT U440 Service manual

ZeroWater
ZeroWater ZeroWater owner's manual
