Cambridge Sound Works Oontz Angle 3 Ultra User manual

Play 2, 3 or 4 Speakers Together
Waterproof Bluetooth Speaker, Incredible Sound,
Powerful Volume, 100 Foot Wireless Bluetooth Range
OontZ App for the OontZ Angle 3 ULTRA
Control the OontZ Angle 3 ULTRA Advanced Features
from your iPhone or Smartphone
User Guide
4th Generation

In the Package
USB Type C Charging Cable
User Guide
3.5mm Stereo Audio Cable
Play 2, 3 or more SpeakersTogether
WaterproofBluetooth Speaker,Incredible Sound,
PowerfulVolume, 100 Foot WirelessBluetooth Range
OontZ App for the OontZ Angle 3 ULTRA
Control the OontZ Angle 3 ULTRAAdvanced Features
from your iPhone or Smartphone
User Guide
4th Generation

Buttons, Lights, and Connectors
Battery Features and Charging the Battery
Turning On and Off
Pair & Connect with Your Device
IPX7 Water Resistance
Talk to Siri and Hands Free Speakerphone
To Play with Non-Bluetooth Devices Use a 3.5mm Stereo Audio Cable
Dual Mode - Connect Two OontZ Angle 3 ULTRA Speakers Together
Surround Mode -
Connect 2, 3 or 4 OontZ Angle 3 ULTRA speakers together
Using The OontZ App
Contacting Customer Support and Reset Function
Safety and Precautions
Table of Contents Pages
1 - 3
4 - 5
6
7 - 10
11
12
13
14 - 18
19 - 22
23 - 33
34
35 - 36

Buttons
Page 1
Important - The volume control on your device and the speaker work independently of each other.
To play the speaker at the loudest volume, set the volume on your device to maximum and raise the volume on the speaker to maximum.
Important - Some apps may not support track back, track forward, or play/pause
Track Back Track Forward
Power
Play/Pause
Bluetooth (Dual Function)
Press and Release to Pause/Play
Press and Release to go
to next track
Volume Down
Press to decrease volume
Volume Up
Press to increase volume
Press and Release to go to
the beginning of the track.
Press and Release twice to
go to previous track

Page 2
Lights
Power Light lit when charging:
- Slowly flashing Red
battery is charging
- Solid Red
battery is fully charged
Bluetooth Light lit when speaker is on:
- Flashing Blue
speaker is in pairing mode
- Solid Blue
speaker is connected
- Blue Light will turn to Solid Green
when the 3.5mm audio cable is
plugged into the AUX IN Jack
- With a second OontZ Angle 3
ULTRA speaker (sold separately)
you can wirelessly connect both
speakers together to play in Left
Channel-Right Channel or Dual
Stereo.
- For Dual Speaker Mode
instructions please see page 14.
White Light lit when speaker is in
Dual Speaker Mode
Orange Light lit when speaker is in
The Surround Mode
- With a 2, 3 or 4 OontZ Angle 3
ULTRA speakers (sold separately)
you can wirelessly connect all the
speakers together to play in The
Surround Mode.
- For The Surround Mode
instructions please see page 19.

Connectors
Page 3
AUX IN Jack
USB Type C
Charging
Connector
Rubber Flap
- covers connectors
- pull gently from the top to access
connectors, it is a snug fit to provide water
resistance
Built-in Mic for
Speakerphone &
Siri
Note: The rubber flap needs to be closed
to keep the speaker water resistant

Page 4
Battery Features
Music Play Time
- Up to 20 hours on a full charge, at 2/3 volume. - Louder volumes will reduce the battery play time.
- The rechargeable battery comes with a partial charge and the speaker is ready to play.
- For maximum playtime, fully charge the battery.
- You can play while charging.
* Exception: certain devices, including the Amazon Echo Input, Amazon Echo Dot and Amazon Echo, disable the Power Saving Feature
and the speaker will remain on until you turn the power off.
Power Saving Feature
- When playing from battery power the OontZ Angle 3 ULTRA will turn off after 30 minutes of not playing audio to conserve the battery
charge. *
- When plugged into a charging source the OontZ Angle 3 ULTRA will remain on until you turn the power off.
- You can continue to keep the speaker plugged into a charging source even when it is fully charged, keeping the speaker turned on and
available.
Low Charge Remaining
- When the battery charge has less than 15% remaining the Power Button Light will begin flashing Red rapidly.
- The volume will decrease to preserve the the remaining battery charge. To return to full volume follow the steps to charge the battery on
Page 5.

Insert the larger end of the USB Type C Charging Cable into a USB
wall charger for a Smartphone or iPhone (USB wall charger* that is
5V 3A maximum) to charge the OontZ Angle 3 ULTRA battery.
* Only use a USB wall charger that is UL listed. A UL listed USB wall charger will
have the logo printed on it.
Charging the Battery
Page 5
Insert the small end of the USB Type C Charging Cable into the
Charging Connector as shown.
Charging Time - Up to 7 hours to fully charge a low battery.
Power Light Lit Red when charging:
- Slowly flashing battery is charging
- Solid battery is fully charged
Important: When the OontZ Angle 3 ULTRA is plugged in to a charging source with the USB Type C Charging Cable, never use
the speaker in the shower, bath, or near water, to prevent risk of electric shock.

Turning On and Off
Page 6
Bluetooth Light
- Flashing Blue in pairing mode
- Solid Blue your device has
connected with the OontZ Angle 3
ULTRA and is ready to play
- Press and Release the Power Button
- Power Light will turn Red for 3 seconds
then turn off
- Bluetooth Light will turn Blue
- Press and Hold Down the Power Button
for 2 Seconds
- Bluetooth Light will turn off
Turn ON
Turn OFF

Turn ON your OontZ Angle 3 ULTRA
Bluetooth Light Flashing Blue
- The OontZ Angle 3 ULTRA is ready to pair and connect.
Bluetooth Light Solid Blue
- Your device has connected to the OontZ Angle 3 ULTRA and is ready to play.
- The OontZ Angle 3 ULTRA allows the last device it was connected with to automatically reconnect
with the speaker each time the speaker is turned on and that device is within range.*
The OontZ Angle 3 ULTRA can be connected to one device at a time.
- To pair and connect to a different device, you need to first disconnect the currently paired device.
- To disconnect the current device, press and hold down the Bluetooth button for 3 seconds.
- The Bluetooth Light will begin flashing blue and the OontZ Angle 3 ULTRA is ready for the next device to pair and connect.
Pair & Connect with Your Device -- Step 1
Page 7
- Your device needs to be within 100 unobstructed feet of the OontZ Angle 3 ULTRA to pair and connect.
If there is an issue when connecting please move your device closer to the speaker, then pair and connect.
- When the charge is too low indicated by a flashing red light on the speaker, your device will not be able to connect with the speaker.
*Exception: certain devices may not automatically reconnect. When connected to an Amazon Echo device it will not automatically
reconnect. You will need to say to your Amazon Echo device, "Alexa, connect my speaker".

Pair & Connect with Your Device -- Step 2 --
Page 8
- Go to Settings > Bluetooth, check Bluetooth is on
- Select 'OontZ Angle 3U SS xxx' when it appears under DEVICES (xxx: 3 characters which are unique to your speaker)
- Your device will connect in a few seconds
- The Bluetooth Light will turn solid blue and there will be a quiet chime
- You can now play your audio wirelessly to your OontZ Angle 3 ULTRA
Note: Your Smartphone or Tablet instructions may vary
-- With Your iPhone, iPad, iPod, Smartphone, Tablet & Mobile Devices
-- With Your Apple Mac or Windows Laptop/Computer
For the pairing and connecting guide for your Apple Mac or Windows laptop/computer, please visit: TheOontZ.com/pairing.
Important - The volume control on your device and the speaker work independently of each other. To play the speaker at the loudest
volume, set the volume on your device to maximum and raise the volume on the speaker to maximum.

Page 9
Pair & Connect with Your Device -- Step 2 --
-- With Your Amazon Echo, Amazon Echo Dot or Amazon Echo Input
- Open the Alexa app
- Select your Amazon Echo device by pressing 'Devices' in the lower right corner of the screen.
- Press 'Echo & Alexa'
- Select your Amazon Echo device by pressing it
- Press 'Bluetooth Devices'
- Press 'Pair a New Device'
- Select the 'OontZ Angle 3U SS xxx' (xxx: 3 characters unique to your speaker) when it appears in the list of 'Available
Speakers'
To connect the next time, turn on the OontZ Angle 3 ULTRA and say "Alexa, connect my speaker" or "Alexa, pair"
To pair and connect with the Amazon Echo, Amazon Echo Dot or Amazon Echo Input for the first time use the Alexa app.
For other Amazon Alexa devices please refer to their pairing and connecting instructions.

Page 10
Important Note: When the OontZ Angle 3 ULTRA is playing from battery power and connected to the Amazon Echo device, the
speaker will remain on and it will not automatically turn off after 30 minutes of not playing audio.
This will use up the battery charge.
We recommend to:
1) Keep the OontZ Angle 3 ULTRA plugged into a USB wall charger.
It can remain on and available to play from the Amazon Echo device.
- Or -
2) Turn off the OontZ Angle 3 ULTRA when you are done listening.
- Either turn off the speaker by pressing and holding down the power button for 2 seconds,
- or say "Alexa, disconnect my speaker" and the OontZ Angle 3 ULTRA will automatically turn off after 30 minutes.
- When you want to connect and play to the speaker again turn on the OontZ Angle 3 ULTRA and say "Alexa, connect my
speaker" or "Alexa, pair".
Pair & Connect with Your Device -- Step 2 --
-- With Your Amazon Echo or Amazon Echo Dot (continued)
For assistance with the Alexa app, contact Amazon's Customer Service.
Open the Alexa app and select Help & Feedback > Email Customer Service

Page 11
The OontZ Angle 3 ULTRA is Waterproof and it is IPX7 certified
The perfect speaker for listening to your favorite music in any environment
Perfect for taking to the lake, the beach, listening by the pool, listening in the shower
IPX7 means the OontZ Angle 3 ULTRA is WaterProof and can handle water spray or being splashed and can handle being partially or
fully submerged in water up to a maximum of 3 feet deep, for up to a maximum of 30 minutes
The rubber flap needs to be closed for the speaker to be waterproof and dustproof.
Important Safety Precaution: When the OontZ Angle 3 ULTRA speaker is plugged in to a charging source with the USB Type C
Charging Cable, never use the speaker in the shower, bath, or near water, to prevent risk of electric shock.
IPX7 WaterProof

Page 12
- Press and Release the Power Button once on the
OontZ Angle 3 ULTRA
- The Bluetooth Light will turn to green and flash 3 times
-Wait for about two seconds until you hear a "chime"
- After the "chime" say what you need into the mic on the OontZ
Angle 3 ULTRA
- The response from Siri will then play through the
OontZ Angle 3 ULTRA, and may display information on your
iPhone or iPad
Your iPhone or iPad needs to be on the latest version of iOS
- Press and Hold Down the Bluetooth Button for 2 Seconds
- Please keep the speaker close in front of you so you may be heard
clearly by the listener.
- You can use your Smartphone or iPhone to switch between using
Hands Free Speakerphone and your phone.
- When two speakers are paired together in Dual Speaker Mode or
The Surround Mode, calls will come through the Master Speaker.
For more information on Dual Speaker Mode please see page 14
and for The Surround Mode please see page 19.
Wireless Hands Free Personal Speakerphone
The Wireless Hands Free Personal Speakerphone feature works
over Bluetooth with Smartphones and iPhones only; this
feature is not supported when connected to other types of
devices.
To answer an Incoming Call / To End a Call
- Press and Release the Bluetooth Button
To Reject an Incoming Call
Talk to Siri on your iPhone or iPad
through the OontZ Angle 3 ULTRA
This feature works when connected to an iPhone or an
iPad over Bluetooth.
To talk to Siri through the OontZ Angle 3 ULTRA

Page 13
- Plug one end of the included 3.5mm Stereo Audio Cable into the
AUX IN jack on the speaker.
- The Bluetooth Light will turn solid Green.
- Plug the other end of that 3.5mm Stereo Audio Cable into the
headphone jack on your device.
- Make sure both ends of the cable are fully inserted
- You are now ready to play.
Important: The Bluetooth on the OontZ Angle 3 ULTRA is disabled when the 3.5mm Audio Cable is connected to the speaker. You
need to remove the 3.5mm Audio Cable from the speaker in order to connect to a Bluetooth Device.
Important Notes:
- Note: The rubber flap needs to be closed before the speaker is exposed to water. The speaker is not water-resistant or
waterproof when the flap is open.
- The volume control on your device and the speaker work independently of each other. To play the speaker at the loudest volume,
set the volume on your device to maximum and raise the volume on the speaker to maximum.
Turn ON your OontZ Angle 3 ULTRA
To Play with Non-Bluetooth Devices Use the 3.5mm Stereo Audio Cable

Page 14
Play your music wirelessly through both speakers up to 100 feet apart*
*Placing the speakers on the ground or having walls or obstructions between the
speakers will significantly reduce the distance apart the two speakers can play together
Dual Mode - Connect two OontZ Angle 3 ULTRA speakers together
Left Channel - Right Channel
for stereo separation
Left Channel Right Channel
Bluetooth
for playing music
Audio Cable
for playing the
audio from a video
or
Bluetooth
for playing music
Audio Cable
for playing the
audio from a video
or
Dual Stereo
for full stereo in separate areas
Full Stereo Full Stereo
Note: The OontZ Angle 3 ULTRA 4th Generation is NOT compatible
with the previous generations of OontZ Angle 3 ULTRA speakers.

Page 15
– Turn on both OontZ Angle 3 ULTRA speakers.
– Pair and Connect one of the speakers with your device. When connected the Bluetooth Light will be lit Solid Blue.
This speaker will serve as the Master Speaker.
– The second speaker must not be connected to any device, its Bluetooth Light needs to be flashing. If the second speaker has a solid
Blue Light it is connected to a device and you need to disconnect it by pressing and holding down the Bluetooth Button for 3 seconds
until the Bluetooth Light begins flashing.
- On the Master Speaker (speaker with solid Blue Light) press and hold down the Play/Pause button for 3 seconds until the light
above the Play/Pause Button is flashing with a White Light and the speaker says “Dual Pairing”.
- After a few seconds both speakers the light above the Play/Pause Button will be lit with a solid White light. The Master Speaker will say
“Left Channel” and the second speaker will say “Right Channel”. The speakers will be connected together for Left Channel - Right
Channel and you are ready to play.
Connecting two OontZ Angle 3 ULTRA speakers together for Left Channel - Right Channel
You can also us the OontZ app to connect two OontZ Angle 3 ULTRA speakers together - See page 26 for instructions on using the OontZ app

Page 16
– Use the buttons on the Master Speaker for play/pause, track back, track forward, answer and end phone calls. These controls
are disabled on the second speaker when paired together.
– Use the Master Speaker for connecting to different audio devices via Bluetooth or AUX IN. The Bluetooth and AUX IN are
disabled on the second speaker when paired together.
– Speakerphone call audio will only play through the Master Speaker
Master Speaker Second Speaker
Two OontZ Angle 3 ULTRA Speakers connected for Left Channel - Right Channel
Light lit solid Blue or Green
Light lit solid White
Light OFF
Light lit solid White

Page 17
Changing to Dual Stereo from Left Channel - Right Channel
Changing back to Left Channel - Right Channel from Dual Stereo
– To change back to Left Channel - Right Channel, press and hold down the Track Forward button on the Master Speaker for 3
seconds until the
Master Speaker will say “Left Channel” and the second speaker will say “Right Channel” and you are ready to play.
Use Dual Stereo when placing the two speakers in different areas, and both speakers will play in full stereo.
– To set both speakers for Dual Stereo they must first be connected together for Left Channel - Right Channel (see page 15).
– With the speakers connected together for Left Channel - Right Channel, you can change the speakers to Dual Stereo.
–
To change to Dual Stereo, press and hold down the Track Forward button on the Master Speaker for 3 seconds until Both speakers
say “Dual Stereo” and you are ready to play.
