Cameo EVOS W3 User manual

USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D´UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D´USO
EVOS®W3
LED WASH-BEAM MOVING HEAD WITH SINGLE PIXEL CONTROL
CLEW3

CONTENTS / INHALTSVERZEICHNIS / CONTENU / CONTENIDO / TREŚĆ / CONTENUTO
ENGLISH
SAFETY INFORMATION 3
INTRODUCTION 5
CONNECTIONS, CONTROL, AND DISPLAY ELEMENTS 5
OPERATION 7
W-DMX™ 8
W-DMX™ STATUS 8
CONTROL MENU (Control) 8
SYSTEM SETTINGS (Settings) 19
DEVICE INFORMATION (Info) 21
SERVICE MENU (Service) 22
QUICK LIGHT 24
SETUP AND INSTALLATION 24
DMX TECHNOLOGY 25
TECHNICAL SPECIFICATIONS 26
MANUFACTURER´S DECLARATIONS 27
DEUTSCH
SICHERHEITSHINWEISE 28
EINFÜHRUNG 30
ANSCHLÜSSE, BEDIEN- UND ANZEIGEELEMENTE 30
BEDIENUNG 32
W-DMX™ 33
W-DMX™ STATUS 33
KONTROLLMENÜ (Control) 33
SYSTEMEINSTELLUNGEN (Settings) 44
GERÄTEINFORMATIONEN (Info) 46
SERVICEMENÜ (Service) 47
QUICK-LIGHT 49
AUFSTELLUNG UND MONTAGE 49
DMX TECHNIK 50
TECHNISCHE DATEN 51
HERSTELLERERKLÄRUNGEN 52
FRANCAIS
MESURES PRÉVENTIVES 53
INTRODUCTION 55
RACCORDEMENTS, ÉLÉMENTS DE COMMANDE ET
D’AFFICHAGE 55
MODE D’EMPLOI 57
W-DMX™ 58
ÉTAT W-DMX™ 58
PANNEAU DE COMMANDE (Control) 58
PARAMÈTRES DU SYSTÈME (Settings) 69
INFORMATIONS SUR L’APPAREIL (Info) 72
MENU DE SERVICE (Service) 73
QUICK-LIGHT 75
INSTALLATION ET MONTAGE 75
TECHNIQUE DMX 76
CARACTÉRISTIQUES TECHNIQUES 77
DECLARATIONS 78
ESPAÑOL
MEDIDAS DE SEGURIDAD 79
INTRODUCCIÓN 81
CONEXIONES, ELEMENTOS DE MANEJO Y ELEMENTOS
DE VISUALIZACIÓN 81
MANEJO 83
W-DMX™ 84
ESTADO W-DMX™ 84
MENÚ DE CONTROL (Control) 84
AJUSTES DEL SISTEMA (Settings) 95
INFORMACIÓN DEL EQUIPO (Info) 97
MENÚ DE SERVICIO (Service) 98
QUICK-LIGHT 100
INSTALACIÓN Y MONTAJE 100
TECNOLOGÍA DMX 101
DATOS TÉCNICOS 102
DECLARACIÓN DEL FABRICANTE 103
POLSKI
ŚRODKI OSTROŻNOŚCI 104
WPROWADZENIE 106
PRZYŁĄCZA, ELEMENTY OBSŁUGI I WSKAŹNIKI 106
OBSŁUGA 108
W-DMX™ 109
STATUS W-DMX™ 109
MENU STEROWANIA (Control) 109
USTAWIENIA SYSTEMU (Settings) 120
INFORMACJE O URZĄDZENIU (Info) 122
MENU SERWISOWE (Service) 123
QUICK-LIGHT 125
USTAWIANIE I MONTAŻ 125
TECHNIKA DMX 126
DANE TECHNICZNE 127
DEKLARACJE PRODUCENTA 128
ITALIANO
MISURE PRECAUZIONALI 129
INTRODUZIONE 131
CONNESSIONI, ELEMENTI DI COMANDO E DI
VISUALIZZAZIONE 131
UTILIZZO 133
W-DMX™ 134
STATO W-DMX™ 134
MENU DI CONTROLLO (Control) 134
IMPOSTAZIONI DI SISTEMA (Settings) 145
INFORMAZIONI SUL DISPOSITIVO (Info) 147
MENU ASSISTENZA (Service) 148
QUICK-LIGHT 150
INSTALLAZIONE E MONTAGGIO 150
TECNOLOGIA DMX 151
DATI TECNICI 152
DICHIARAZIONI DEL PRODUTTORE 153
DMX
DMX CONTROL / DMX STEUERUNG / PILOTAGE DMX /
CONTROL DMX / STEROWANIE DMX / CONTROLLO DMX 154

3
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
ENGLISH
YOU HAVE MADE THE RIGHT CHOICE!
This device was developed and produced under the highest standards of quality in order to ensure smooth operation for many years. Please
read these operating instructions carefully so that you can use your new Cameo Light product quickly and optimally. You can find more
information on Cameo Light on our website WWW.CAMEOLIGHT.COM.
SAFETY INFORMATION
1. Please read through these instructions carefully.
2. Store all information and instructions in a secure location.
3. Follow the instructions.
4. Heed all warnings. Do not remove any safety warnings or other information from the device.
5. Use the device only in the intended manner.
6. Use only stable and suitable stands and/or mounts (for fixed installations). Make sure that wall mounts are properly installed and
secured. Make sure that the device is securely installed and will not fall.
7. During installation, heed all safety provisions that apply in your country.
8. Do not install and operate the device in the vicinity of heaters, heat reservoirs, ovens, or other heat sources. Make sure that the device is
installed in such a way that it is sufficiently cooled and will not overheat.
9. Do not place any ignition sources, e.g. candles, on the device.
10. Do not block the ventilation slits.
11. The device was designed to be used only in interior spaces, do not operate the device in the direct vicinity of water (this does not apply
to specialty outdoor devices - in this case, please note the special instructions given in the following). Do not bring the device into
contact with combustible materials, fluids, or gases.
12. Make sure that no water can drop or splash into the device. Do not place any containers filled with fluids, such as vases or drinking
vessels, onto the device.
13. Ensure that no objects can fall into the device.
14. Operative the device using only those accessories recommended and specified by the manufacturer.
15. Do not open the device, and do not modify it.
16. After connecting the device, inspect all cable paths in order to avoid damage or accidents, such as those caused by tripping over said cables.
17. During transport, ensure that the device will not fall and potentially cause material damage and personal harm.
18. If your device no longer functions properly, fluids or objects have made their way into the device interior, or the device is otherwise
damaged, switch it off immediately and remove it from the power outlet (provided the device is active).
This device is to be repaired only by authorized specialists.
19. Use a dry towel to clean the device.
20. Follow all laws on disposal applicable in your country. Please separate plastic and paper or cardboard when disposing of the packaging.
21. Plastic bags must be kept out of reach of children.
FOR DEVICES CONNECTED TO A POWER SUPPLY:
22. ATTENTION: If the device power cable is equipped with a ground pin, it must be inserted into an outlet with a grounding conductor. Never
disable the grounding conductor of a power cable.
23. Do not immediately switch on the device when it has been exposed to stark temperature deviations (for example after transport).
Humidity and condensation could damage the device. Switch on the device only when it has reached room temperature.
24. Before you connect the device to the outlet, first ensure that voltage and frequency of the power supply complies with the values given
on the device. If the device has a voltage selector switch, connect the device to the outlet only if the device values comply with the
values of the power supply. If the provided power cable or power adapter does not fit your power outlet, contact an electrician.
25. Do not step on the power cable. Make sure that live cables, in particular those at the power socket or at the power adapter and the
device socket, are not bent.
26. With regard to the device cables, always make sure that the power cable or power adapter is always freely accessible. Always separate
the device from the power supply when the device is not in use or when you would like to clean the device. Always unplug the power
cable and power adapter from the power outlet using the plug or adapter, not the cord. Never touch the power cable and power adapter
with wet hands.
27. If possible, do not switch the device on and off quickly because this may impair the service life of the device.
28. IMPORTANT INFO: Replace fuses only with fuses of the same type and value. If a fuse trips repeatedly, please contact an authorized
service center.
29. In order to completely separate the device from the power supply, remove the power cable or power adapter from the outlet.
30. If your device is equipped with a Volex power cord, release the correct Volex device connector before removing the cord. However, this
also means that the device may slide and fall when removing the power cord, which may cause personal harm and/or material damage.
Therefore, always lay cables carefully.
31. Remove the power cable and power adapter from the outlet when there is a risk of lighting or when you no longer want to use the device.
32. The device may only be installed when it carries no voltage (separate the power plug from the power supply).
33. Dust and other debris within the device may damage it. The device should be serviced or cleaned regularly by qualified specialists
depending on the environmental conditions (dust, nicotine, smoke, etc.) in order to avoid overheating.
34. The distance to combustible materials must be at least 0.5 m.
35. Power cables for powering multiple devices must have a core cross-section of at least 1.5 mm². In the EU, lines must be H05VV-F or
similar. Adam Hall provides suitable cables. Using these cables, you can connect multiple devices via the Power Out connection with the
Power In connection of another device. Ensure that the total power consumption of all connected devices does not exceed the specified
value (printed on the device). Be sure to keep power lines as short as possible.

4
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
36. The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge.
37. Children must be instructed not to play with the device.
38. If the power cord of the device is damaged, do not use the device. The power cord must be replaced by an adequate cable or assembly
from an authorized service center.
CAUTION:
To reduce the risk of electric shock, do not remove cover (or back).There are no user serviceable
parts inside. Maintenance and repairs should be exclusively carried out by qualified service
personnel.
The warning triangle with lightning symbol indicates dangerous uninsulated voltage inside the unit, which may cause an
electrical shock.
The warning triangle with exclamation mark indicates important operating and maintenance instructions.
Warning! This symbol indicates a hot surface. Certain parts of the housing can become hot during operation. After use, wait
for a cool-down period of at least 10 minutes before handling or transporting the device.
Warning! This device is designed for use below 2000 metres in altitude.
Warning! This product is not intended for use in tropical climates.
Caution! Intense LED light source! Risk of eye damage. Do not look into the light source.
CAUTION! IMPORTANT INFORMATION ABOUT LIGHTING PRODUCTS!
1. The product has been developed for professional use in the field of event technology and is not suitable as household lighting.
2. Do not stare, even temporarily, directly into the light beam.
3. Do not look at the beam directly with optical instruments such as magnifiers.
4. Stroboscope effects may cause epileptic seizures in sensitive people! People with epilepsy should definitely avoid places where
strobes are used.

5
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
INTRODUCTION
MOVING HEAD EVOS® W3
CLEW3
CONTROL FUNCTIONS
16-, 18-, 23-, 33-, 39-, and 43-channel control plus 11- and 18-channel dual input control
Art-Net4
sACN
Kling-Net
W-DMX™
RDM-enabled
Master/slave mode
Stand-alone functions
PROPERTIES
7 × 40 W RGB+warm white LEDs. Zoom function. Stroboscope. Pan and tilt motors with 16-bit resolution. Automatic position correction.
Temperature-controlled fans. 5-pin DMX connectors. Network connectors. Neutrik powerCON TRUE1 power connection. 2 omega mounting
brackets included. Operating voltage: 100–240 V AC. Power consumption: 325 W.
The spotlight complies with the RDM standard (Remote Device Management). Remote device management allows the user to view the
status and configuration of RDM terminals via an RDM-enabled controller.
1POWER IN
Neutrik powerCON TRUE1 power input connector. Operating voltage: 100–240 V AC / 50–60 Hz. A suitable power cable with powerCON
TRUE1 connector plug is included with product.
2POWER IN
Neutrik powerCON TRUE1 power output connector to supply power to additional CAMEO spotlights. Ensure that the total power consumption
of all connected devices does not exceed the ampere (A) value specified on the device.
3FUSE
Fuse holder for 5 × 0.79 inch micro fuses. IMPORTANT NOTE: Only replace the fuse with a fuse of the same type and value.
If a fuse trips repeatedly, please contact an authorized service center.
4DMX IN
Male 5-pin XLR connector to connect a DMX control device (e.g., DMX console).
5DMX OUT
Female 5-pin XLR connector to transmit the DMX control signal.
6NET
RJ45 network connections to connect with an Art-Net, sACN, or KlingNet network and for connecting additional Art-Net, sACN, or
KlingNet-enabled devices to the network. Use CAT-5e, or later, cables to set up the network.
CONNECTIONS, CONTROL, AND DISPLAY ELEMENTS
4
3
5
6
6
7
8
1 2

6
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
9LC DISPLAY
The backlit LC display shows the currently active operating mode (main display), the menu items in the Options menu, and the numerical
values or operating status for certain menu items. If there is no input within approx. 1 minute, the display screen automatically switches
to the main display. Note on the main display in operating modes with external control: As soon as the control signal is interrupted, the
symbols on the display will begin to flash. When the control signal is present again, the flashing will stop.
The battery-powered display can be activated even if the device is not connected to the power. To do so, press and hold the encoder for
approx. 5 seconds.You can now view device information and change and save system settings, even if the device is not connected to the
power. The spotlight’s external controller will not activate in this case. This means that the display will show that there is no control signal
present, even if there is one present for the device.
10 PUSH-BUTTON ROTARY ENCODER
Push-button rotary push encoder for navigating the editing menu and for adjusting system settings and changing values in the correspond-
ing menu items. Starting from the main display, press the push-button rotary encoder to move to the main menu. Rotate the encoder to
select the individual menu items in the main menu (Control, Settings, Info, etc.) and in the submenu. Confirm your selection by pressing the
encoder. Rotate the encoder to change the value or status in a menu item and press the encoder to confirm the change.
7STATUS LEDS NET
Yellow status LED lights up = network connection.
Green status LED flashes = control signal is present.
8W-DMX™ ANTENNA
The antenna for W-DMX™ control remains in its holder during operation (= operating position).
9 10

7
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
Art-Net / sACN + DMX operating mode Kling-Net + DMX operating mode
Temperature of LED unit Temperature of LED unit
Operating modeOperating mode
Main addressUniverse
IP address
Main address
W-DMX status W-DMX status
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
OPERATION
NOTES
As soon as the spotlight is properly connected to the power supply, “Welcome to Cameo”, the model name, and then the software version
are displayed one after the other on the display as part of the startup process. Once the process is complete, the spotlight is ready for use
and resumes whichever mode was most recently activated.
MAIN MENU DISPLAY
The main menu display shows different information relevant to the operating mode in the different operating modes.
DMX and W-DMX operating modes Art-Net and sACN operating mode
Temperature of LED unit Temperature of LED unit
Operating mode and DMX mode
DMX start address and DMX mode
Universe
Warning
IP address
DMX address
W-DMX status W-DMX status
Note on the main display in operating modes with external control: As soon as the control signal is interrupted, the symbols on the display
will begin to flash. When the control signal is present again, the flashing will stop.
Warning: If the warning symbol (triangle with exclamation mark) appears on the display, there is an error in one or more of the device’s
components. You can see which components are affected in the Info Menu under Error Info. If resetting or restarting the device does not
fix the error, please contact an authorized service center.
Warning
Pixel address
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
Slave and Scene operating mode
Temperature of LED unit
Operating mode
Warning
W-DMX status
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!

8
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
W-DMX™
To pair the W-DMX receiver with the W-DMX-compatible transmitter, execute the Reset command in the receiver menu (select Reset and
confirm). The receiver is now ready to pair and waits for a transmitter to request pairing. Start pairing by selecting Link in the transmitter
menu and then confirm your selection. Pairing will then be carried out automatically. These same steps can be used to pair several receivers
to a transmitter at the same time or in succession (e.g., for master/slave operation). In general, a W-DMX connection will remain connected
until it is severed by selecting Reset in the receiver menu or Unlink in the transmitter menu, regardless of whether a device is temporarily
disconnected from the power supply.
CONTROL MENU (Control)
The control menu allows different operating modes and their setting options to be selected in the corresponding submenus. The DMX ad-
dress, DMX operating mode, universe, IP address, and subnet mask can be set across modes in every operating mode, if they are relevant.
DMX OPERATION VIA XLR CABLE
Starting from the main display, press the push-button rotary encoder to navigate to the main menu. Rotate the encoder to select the control
menu Control and then press the encoder. Rotate the encoder to select the DMX menu item and confirm by pressing the encoder. The table
below provides information on the submenu items in the DMX menu and the corresponding setting options.
W-DMX™ STATUS
DMX
Rotate the encoder to select, press the encoder to confirm, rotate to change value or status, press to confirm. Return with .

Address Sets the DMX start address 001–xxx
Channel Mode Selects the DMX mode 
16CH / 18CH / 23CH /
33CH / 39CH / 43CH
W-DMX
deactivates
W-DMX
activated as
receiver, not
paired
W-DMX ac-
tivated and
paired as
a receiver,
transmitter
switched
off or out of
range
W-DMX ac-
tivated and
paired as a
receiver, no
DMX signal
W-DMX
activated
and paired
as a receiv-
er, DMX
signal is
present
W-DMX
activated as
transmitter
with G3
standard,
DMX signal is
present
W-DMX activated
as transmitter
with G4s stan-
dard, DMX signal
is present
W-DMX
activated as
transmitter with
G3 standard, no
DMX signal
W-DMX activated
as a transmitter
with G4s standard,
no DMX signal

9
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
DMX OPERATION VIA W-DMX
Starting from the main display, press the push-button rotary encoder to navigate to the main menu. Rotate the encoder to select the control
menu Control and then press the encoder. Rotate the encoder to select the W-DMX menu item and confirm by pressing the encoder. The
table below provides information on the submenu items in the W-DMX menu and the corresponding setting options.
W-DMX
Rotate the encoder to select, press the encoder to confirm, rotate to change value or status, press to confirm. Return with .

Address Sets the DMX start address 001–xxx
Channel Mode Selects the DMX mode 
16CH / 18CH / 23CH /
33CH / 39CH / 43CH
Wireless Selects the receiving options:
1. Backup by XLR = If W-DMX is interrupted, XLR takes over (cable
connection required).
2. Send to XLR = Transmits the DMX signal via DMX OUT (XLR)
3. Wireless Only = W-DMX reception only, no backup, no DMX signal
transmission.

Receive Mode 
Backup by XLR
Send to XLR
Wireless Only
Reset = Terminates the connection to all W-DMX devices and puts
them in “ready to pair” mode.
Connect 
Reset
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
Wireless Activates (select G3 or G4s) or deactivates (Disable) W-DMX trans-
mission, sets the W-DMX standard (G3/G4s), and establishes (Link) or
disconnects (Unlink) a connection with another W-DMX device.

Send Mode 
G3
G4s
Disable
Connect 
Link
Unlink

10
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
Art-Net
Rotate the encoder to select, press the encoder to confirm, rotate to change value or status, press to confirm. Return with .

Address Sets the DMX start address 001–xxx
Channel Mode Selects the DMX mode 
16CH / 18CH / 23CH /
33CH / 39CH / 43CH
Network
Settings
Network settings:
IP address: Set 1st block, set
2nd block, confirm ...
Subnet mask: Set 1st block, set
2nd block, confirm ...

IP Address xxx.xxx.xxx.xxx
Subnet Mask xxx.xxx.xxx.xxx
Universe 000–254
Universe Group 000–127
Send to DMX The Art-Net control signal can
be transmitted in the defined
universe to DMX OUT (Art-Net
to DMX), to W-DMX (Art-Net to
W-DMX), or to both (Art-Net to
DMX and W-DMX). The function
is deactivated with “Disable“.

Disable
Current Universe
(alternative to “User
Universe“)

Art-Net to DMX
Art-Net to DMX
and W-DMX 
Send Mode 
G3
G4s
Connect 
Link
Unlink
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
OPERATION VIA ART-NET
Starting from the main display, press the push-button rotary encoder to navigate to the main menu. Rotate the encoder to select the control
menu Control and then press the encoder. Rotate the encoder to select the Art-Net menu item and confirm by pressing the encoder. The
table below provides information on the submenu items in the Art-Net menu and the corresponding setting options.
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!

11
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
OPERATION VIA SACN
Starting from the main display, press the push-button rotary encoder to navigate to the main menu. Rotate the encoder to select the control
menu Control and then press the encoder. Rotate the encoder to select the sACN menu item and confirm by pressing the encoder. The
table below provides information on the submenu items in the sACN menu and the corresponding setting options.
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
sACN
Rotate the encoder to select, press the encoder to confirm, rotate to change value or status, press to confirm. Return with .

Address Sets the DMX start address 001–xxx
Channel Mode Selects the DMX mode 
16CH / 18CH / 23CH /
33CH / 39CH / 43CH
Network
Settings
Network settings:
IP address: Set 1st block, set
2nd block, confirm ...
Subnet mask: Set 1st block, set
2nd block, confirm ...

IP Address xxx.xxx.xxx.xxx
Subnet Mask xxx.xxx.xxx.xxx
Universe 000–254
Universe Group 000–127
The Art-Net control signal can
be transmitted in any universe
from 000 to 254 (Select
Universe) to DMX OUT (Art-Net
to DMX), to W-DMX (Art-Net to
W-DMX), or to both (Art-Net to
DMX and W-DMX).
User Universe
(alternative to “Cur-
rent Universe“)

Select Universe 000–254
Sending Options 
Art-Net to DMX
Art-Net to DMX
and W-DMX 
Send
Mode 
G3
G4s
Connect 
Link
Unlink
Art-Net to
W-DMX 
Send
Mode 
G3
G4s
Connect 
Link
Unlink

12
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
Send to DMX The sACN control signal can
be transmitted in the defined
universe to DMX OUT (sACN
to DMX), to W-DMX (sACN to
W-DMX), or to both (sACN to
DMX and W-DMX). The function
is deactivated with "Disable".

Disable
Current Universe
(alternative to "User
Universe")

sACN to DMX
sACN to DMX and
W-DMX 
Send Mode 
G3
G4s
Connect 
Link
Unlink
sACN to W-DMX 
Send Mode 
G3
G4s
Connect 
Link
Unlink
The sACN control signal can
be transmitted to any universe
from 000 to 254 (Select
Universe) to DMX OUT (sACN
to DMX), to W-DMX (sACN to
W-DMX), or to both (sACN to
DMX and W-DMX).
User Universe
(alternative to "Cur-
rent Universe")

Select Universe 000–254
Sending Options 
sACN to DMX
sACN to DMX
and W-DMX 
Send Mode 
G3
G4s
Connect 
Link
Unlink
sACN to
W-DMX 
Send Mode 
G3
G4s
Connect 
Link
Unlink
OPERATION VIA ART-NET AND DMX
The Art-Net+DMX operating mode makes it possible to separately control the LEDs and move the heads with Art-Net and DMX. This lets
you select whether the LEDs are controlled with Art-Net and the heads moved with DMX, or vice versa. When selecting this operating mode,
there are two channel modes to select from for the control functions. Only the motion functions are available in 11-channel mode and the
pixels are only controlled with the second input signal. Illumination functions are also available in 18-channel mode.
Starting from the main display, press the push-button rotary encoder to navigate to the main menu. Rotate the encoder to select the control
menu Control and then press the encoder. Rotate the encoder to select the Art-Net+DMX menu item and confirm by pressing the encoder.
The table below provides information on the submenu items in the Art-Net+DMX menu and the corresponding setting options.

13
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
Art-Net + DMX
Rotate the encoder to select, press the encoder to confirm, rotate to change value or status, press to confirm. Return with .

Address Sets the DMX start addresses Main and Pixel 
Main Address 001–xxx
Pixel Address 001–xxx
Signal Selects the control signal for pixel control 
Art-Net > Pixel
DMX > Pixel
Pixel Control Main address with master dimmer (Yes) or without master dimmer (No) 
Master Dimmer 
Yes
No
RGB or RGBW pixel control Pixel Mode 
RGB
RGBW
Sets the channel mode Channel Mode 
11CH
18CH
Network Settings Network settings:
IP address: Set 1st block, set 2nd block, confirm ...
Subnet mask: Set 1st block, set 2nd block, confirm ...

IP Address xxx.xxx.xxx.xxx
Subnet Mask xxx.xxx.xxx.xxx
Selects the universe and universe group Universe 000–254
Universe Group 000–127
DMX Settings DMX control via XLR cable (XLR Only) or W-DMX (Wireless Only). If “XLR
First” is selected, W-DMX serves as a backup; if “Wireless First” is selected,
control via XLR cable serves as a backup.

Receive Mode 
XLR Only
XLR First
Wireless First
Wireless Only
Reset = Terminates the connection to all W-DMX devices and puts them in
“ready to pair” mode.
Connect 
Reset

14
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
OPERATION VIA SACN AND DMX
The sACN+DMX operating mode makes it possible to separately control the LEDs and move the heads with sACN and DMX. This lets you
select whether the LEDs are controlled with sACN and the heads moved with DMX, or vice versa When selecting this operating mode, there
are two channel modes to select from for the control functions. Only the motion functions are available in 11-channel mode and the pixels
are only controlled with the second input signal. Illumination functions are also available in 18-channel mode.
Starting from the main display, press the push-button rotary encoder to navigate to the main menu. Rotate the encoder to select the control
menu Control and then press the encoder. Rotate the encoder to select the sACN+DMX menu item and confirm by pressing the encoder.
The table below provides information on the submenu items in the sACN+DMX menu and the corresponding setting options.
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
sACN + DMX
Rotate the encoder to select, press the encoder to confirm, rotate to change value or status, press to confirm. Return with .

Address Sets the DMX start addresses Main and Pixel 
Main Address 001–xxx
Pixel Address 001–xxx
Signal Selects the control signal for pixel control 
sACN > Pixel
DMX > Pixel
Pixel Control Main address with master dimmer (Yes) or without master dimmer (No) 
Master Dimmer 
Yes
No
RGB or RGBW pixel control Pixel Mode 
RGB
RGBW
Sets the channel mode Channel Mode 
11CH
18CH
Network Settings Network settings:
IP address: Set 1st block, set 2nd block, confirm ...
Subnet mask: Set 1st block, set 2nd block, confirm ...

IP Address xxx.xxx.xxx.xxx
Subnet Mask xxx.xxx.xxx.xxx
Selects the universe and universe group Universe 000–254
Universe Group 000–127

15
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
OPERATION VIA KLING-NET AND DMX
When selecting this operating mode, there are two channel modes to select from for the control functions. Only the motion functions are
available in 11-channel mode and the pixels are only controlled with the second input signal. Illumination functions are also available in
18-channel mode.
Starting from the main display, press the push-button rotary encoder to navigate to the main menu. Rotate the encoder to select the control
menu Control and then press the encoder. Rotate the encoder to select the Kling-Net+DMX menu item and confirm by pressing the
encoder. The table below provides information on the submenu items in the Kling-Net+DMX menu and the corresponding setting options.
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
Kling-Net + DMX
Rotate the encoder to select, press the encoder to confirm, rotate to change value or status, press to confirm. Return with .

Address Sets the DMX start address Main 
Main Address 001–xxx
Pixel Control RGB or RGBW pixel control 
Pixel Mode 
RGB
RGBW
Sets the channel mode Channel Mode 
11CH
18CH
DMX Settings DMX control via XLR cable (XLR Only) or W-DMX (Wireless Only). If “XLR
First” is selected, W-DMX serves as a backup; if “Wireless First” is selected,
control via XLR cable serves as a backup.

Receive Mode 
XLR Only
XLR First
Wireless First
Wireless Only
Reset = Terminates the connection to all W-DMX devices and puts them in
“ready to pair” mode.
Connect 
Reset
DMX Settings DMX control via XLR cable (XLR Only) or W-DMX (Wireless Only). If “XLR
First” is selected, W-DMX serves as a backup; if “Wireless First” is selected,
control via XLR cable serves as a backup.

Receive Mode 
XLR Only
XLR First
Wireless First
Wireless Only
Reset = Terminates the connection to all W-DMX devices and puts them in
“ready to pair” mode.
Connect 
Reset

16
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
SLAVE MODE (Slave)
Starting from the main display, press the push-button rotary encoder to navigate to the main menu. Rotate the encoder to select the control
menu Control and then press the encoder. Rotate the encoder to select the Slave menu item and confirm by pressing the encoder. The
table below provides information on the submenu items in the Slave menu and the corresponding setting options. Connect the slave and
master unit (same model, same software version) using a DMX cable (Master DMX OUT – Slave DMX IN) or via W-DMX, and activate the
stand-alone operating mode Scenes in the master unit. The slave unit will now follow the master unit.
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
Slave
Rotate the encoder to select, press the encoder to confirm, rotate to change value or status, press to confirm. Return with .

Input Settings DMX control via XLR cable (XLR Only) or W-DMX (Wireless Only). If “XLR
First” is selected, W-DMX serves as a backup; if “Wireless First” is selected,
control via XLR cable serves as a backup.

Receive Mode 
XLR Only
XLR First
Wireless First
Wireless Only
Reset = Terminates the connection to all W-DMX devices and puts them in
“ready to pair” mode.
Connect 
Reset
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!
STAND-ALONE OPERATION (Scenes)
The stand-alone operating mode Scenes allows you to set Pan, Tilt, Dimmer, RGBW, Zoom, Pan/Tilt macros, etc. and select values ranging
from 000 to 255 directly on the device, much like you would with a DMX control unit. A total of eight individual scenes (Scene 1–8) can be
created, edited, saved, and retrieved. Starting from the main display, press the push-button rotary encoder to navigate to the main menu.
Rotate the encoder to select the control menu Control and then press the encoder. Now rotate the encoder to select the Scenes menu item
and confirm by pressing the encoder. The Scenes and Edit Scene tables below provide information on the submenu items in the
Scenes menu and the corresponding setting options.
Main Menu
Control
Settings
Info
Service
Quick-Light
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Control
DMX
W-DMX
Art-Net
sACN
Art-Net+DMX
sACN+DMX
Kling-Net+DMX
Slave
Scenes
Mode
Slave
(Scene x)
030°C
!
030°C
Mode: Art-Net (sACN)+DMX
Universe:
IP:
Main Address:
Pixel Address:
0
192.168.000.150
001
001
!
030°C
Mode: Kling-Net+DMX
Main Address: 001
!
030°C
Mode: Art-Net (sACN)
Universe:
IP:
DMX Address:
43CH
0
192.168.000.150
001
!
001
43CH
030°C
!

17
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
Scenes
Rotate the encoder to select, press the encoder to confirm, rotate to change value or status, press to confirm. Return with .

Run Scene Starts the scene 
Scene 1–8
Record Scene Records the scene from an external controller
(activate DMX, W-DMX, Art-Net, or sACN mode, configure
the desired setting in the corresponding controller, select
the desired scene, and confirm)

Scene 1–8
Edit Scene Edits the scene (see table Edit Scene)
Scene 1–8
Master/Alone Sends scene as control signal to a slave unit via XLR,
wireless, or XLR and wireless 
Master 
XLR 
Wireless Send Mode 
G3
G4s
Connect 
Link
Unlink
XLR+Wireless Send Mode 
G3
G4s
Connect 
Link
Unlink
Sends scene as control signal (Stand Alone No)
Does not send scene as control signal (Stand Alone Yes)
Stand Alone 
No
Yes
Copy to Slave Transmits scenes 1 to 8 to one or more slave units via
XLR cable (same model, same software version). Executes
operation by selecting Yes. The scene memory for the
slave units is overwritten. Cancels operation by selecting
No.

No
Yes

18
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
Edit Scene

Pan 000 – 255 0% -> 100%
Tilt 000 – 255 0% -> 100%
Dimmer 000 – 255 Master dimmer 0% -> 100%
Red 000 – 255 0% -> 100%
Green 000 – 255 0% -> 100%
Blue 000 – 255 0% -> 100%
White 000 – 255 0% -> 100%
Zoom 000 – 255 Narrow -> wide
Pixel Pattern 000 – 005 Off
006 – 010 Pattern 1
011 – 015 Pattern 2
016 – 020 Pattern 3
021 – 025 Pattern 4
026 – 030 Pattern 5
031 – 035 Pattern 6
036 – 040 Pattern 7
041 – 045 Pattern 8
046 – 050 Pattern 9
051 – 055 Pattern 10
056 – 060 Pattern 11
061 – 065 Pattern 12
066 – 070 Pattern 13
071 – 075 Pattern 14
076 – 080 Pattern 15
081 – 085 Pattern 16
086 – 090 Pattern 17
091 – 095 Pattern 18
096 – 100 Pattern 19
101 – 255 All LEDs On
Pattern Speed 000 – 005 Pattern stop
006 – 127 Pattern speed, slow -> fast, forward
128 – 255 Pattern speed, fast -> slow, backward
Pan/Tilt Macro
(starts from current Pan/Tilt position)
000 – 005 off
006 – 040 Pan, small -> large
041 – 075 Tilt, small -> large
076 – 110 Pan/Tilt, small -> large
111 – 145 Pan/Tilt, inverse small -> large
146 – 180 Circle, small -> large
181 – 215 Circle, inverse small -> large
216 – 255 Random, small -> large
Pan/Tilt Speed 000 – 255 Pan movement speed, fast -> slow

19
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
Settings (bold = factory setting)
Rotate the encoder to select, press the encoder to confirm, rotate to change value or status, press to confirm. Return with .
Display Display settings 
Flip 
Floor Use Display does not rotate
Rig Use Display rotates by 180° (when installed
overhead)
Off after 1 min. 
1 Minute Off Deactivates display backlight after approx. 1
minute of inactivity
Always On Display backlight permanently on
Intensity 001–010 Display brightness
Contrast 001–010 Display contrast
Signal Fail Operating status
if control signal
is lost

Hold Latest
Value
Last command is held
Run Scene 1 Activates Scene 1
Blackout Activates blackout
Main Menu
Control
Settings
Info
Service
Quick-Light
Main Menu
Control
Settings
Info
Service
Quick-Light
Settings
Display
Signal Fail
Dimmer
Color Calibration
Pan/Tilt Motors
Fan Settings
Auto Lock
Default
Info
Firmware
Temperature
Fan Speed
Runtime
RDM UID, MAC, NET
DMX Values
Error Info
DMX Tables
Main Menu
Control
Settings
Info
Service
Quick-Light
Service
Reset
Test
Password
Main Menu
Control
Settings
Info
Service
Quick-Light
Quick-Light
Pan
Tilt
Dimmer
Hue
Saturation
Color Temperature
Zoom
SYSTEM SETTINGS (Settings)
Starting from the main display, press the push-button rotary encoder to navigate to the main menu. Turn the encoder to access the menu for
the system settings Settings and then press the encoder.
This will take you to the submenu for setting the submenu items, see table:

20
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
Dimmer Selects dimmer
curve, dimming
behavior, and
PWM frequency

Curve 
Linear Light intensity increases linearly with DMX value
Exponential Light intensity can be finely adjusted at lower
DMX values and broadly adjusted at higher DMX
values
Logarithmic Light intensity can be broadly adjusted at lower
DMX values and finely adjusted at higher DMX
values
S-curve Light intensity can be finely adjusted at lower
and higher DMX values, and broadly adjusted at
medium DMX values
Response 
LED Response The spotlight responds abruptly to changes in
the DMX value
Halogen Response The spotlight behaves like a halogen spotlight
with soft changes in brightness
PWM 
800Hz, 1200 Hz, 2000Hz,
3600Hz, 12 kHz, 25kHz
Color
Calibration
Color calibration 
User Calibration 
Red Balance 125–255 User-defined calibration of R, G, B, and W
Green Balance 125–255
Blue Balance 125–255
White Balance 125–255
Raw R, G, B, and W with
maximum brightness
The Raw mode is always active in pixel control
Factory Cali-
bration
Factory preset calibration
of R, G, B, and W
Pan/Tilt
Motors
Configures the
device head 
Pan/Tilt Speed 000–255
Pan Reverse 
Normal Pan movement direction does not reverse
Reversed Pan movement direction reverses
Tilt Reverse 
Normal Tilt movement direction does not reverse
Reversed Tilt movement direction reverses
Sensors 
ON Automatic position correction activated
OFF Automatic position correction deactivated
Move In Black 
OFF No blackout when head moves
ON Blackout when head moves
Fan Set-
tings
Fan control 
Automatic The fan speed will adjust automatically to the temperature of the device head
Normal Reduced maximum fan speed, resulting in a slightly reduced brightness, as
necessary
Silent Consistently low fan speed with reduced brightness, as necessary
