Camera Motion Research Connex Mini User manual

Accessory Quick Guide
1
© 2018 Camera Motion Research, LLC

Accessory Quick Guide
2
A. Installing the Connex Mini transmitter CMR battery support and mounting cage
Step 1. The Connex Mini transmitter cage ships assembled, and must be dis-assembled to install the transmitter. To
dis-assemble, remove the top two screws from the shipped assembled Connex Mini Cage as shown below.
The two screws to remove are located between the
battery clips that lock the small right angle bracket
Then remove the small right angle bracket.
Step 2. Insert the Connex Mini into the cage.
Main
Mounting
Bracket
Step 3. Position the hole in the small right angle bracket over the small protruding tab on the main mounting bracket.
Replace the two screws that were removed in step 1., and tighten firmly.

Accessory Quick Guide
3
Step 4. Attach the provided rod antennas to the Connex Mini transmitter by screwing them on.
Step 5. Insert the battery with the battery power port and the transmitter power port on the same side.
Step 6. Insert the JST connector on the power cable into the power port of the transmitter (note it will click when fully
inserted) , and insert the barrel plug into the battery.

Accessory Quick Guide
4
Step 7. Insert the micro HDMI to standard HDMI converter and locking bar assembly into the transmitter
micro HDMI input port as shown below.
Secure the locking bar with the ¼-20 nut, and tighten securely.
Note: the HDMI locking bar nut also has a ¼-20 tapped hole for mounting the transmitter.

Accessory Quick Guide
5
B1. Installing the Connex Mini Receiver CMR Battery Support
Step 2. Insert the battery into the receiver battery
cage as shown in picture, so that the power ports are
on the same side. Insert the power cable.
Step 1. Screw the battery cage captive thumb screw into the
bottom of the ¼-20 tapped hole on the receiver.
(Mount the receiver assembly to your gear such as monitor
yoke, light stand, etc. using the ¼-20 tapped hole on the
bottom of the thumb screw.)
B2. Installing the Connex Fusion receiver CMR Battery Support
Step 1. Screw the battery cage captive thumb screw into the bottom of
the ¼-20 tapped hole on the receiver.
(Mount the receiver assembly to your gear such as monitor yoke, light
stand, etc. using the ¼-20 tapped hole on the bottom of the thumb
screw.)

Accessory Quick Guide
6
Step 2. Insert the battery into the
receiver battery cage as shown in
picture, so that the power ports
are on the same side. Insert the
power cable.
C. Removing the Batteries
This applies to both the transmitter and the receiver.
Hold the cage in your hands so that you have a grasp of
the cage and the battery. Use your thumbs to press up
on the clips and your index fingers to push out on the
battery. Remove battery.

Accessory Quick Guide
7
D. Removing the Transmitter Battery Clips if the Lithium Battery is not used
The battery clips can be removed by unscrewing the 4 screws.
Save the screws and clips so they can be re-installed later.
E. Using a D-tap Power Cable for the Transmitter
The D-tap power cable, PN:
DT15 must be purchased
separately. It includes a strain
relief which can be mounted to
the Mini transmitter cage as
shown left if the battery clips
have been removed.
F. Lithium Battery Operation
The Connex Mini transmitters and receivers do not have power (on/off) switches, so they power up whenever
voltage is applied. The lithium batteries have a power button to turn them on and off. You must press and
hold the button for about 2 seconds to either turn on, or turn off the battery.
Note: The battery must be turned off when being charged. Watch for the walking lights to confirm charging
is taking place. Charging time is about 4 hours.

Accessory Quick Guide
8
Brief Operational Notes for the transmitter/receiver set (See the Connex/ Connex Mini
User Guide for more detailed information)
The Connex Mini transmitter with Mini or Fusion receiver provides plug and play wireless transmission
of HDMI video signals, but does not transmit audio.
Frequency selection from one of 11 available channels is automatic.
The Connex Mini can transmit to up to 4 receivers simultaneously.
Refer to the Amimon Connex/Connex Mini User Guide for information about how the two LEDs (video
and network) on the transmitter and receiver show the status of a connection and video input.
Note that the receiver has an On Screen Display (OSC) button to turn on, or turn off the On Screen
Display. Normally you would have the On Screen Display turned off so that the OSD information is not
overlaid onto the camera video.
