Camlogic PFG-86 Instruction Manual

PFG-86 - PFG-86/F - PFG-86/C - PFG-86/X - PFG-86/X/F
Installation and Maintenance Rules for:
STANDARD FEATURES
INSTALLATION
Fig.1 Fig.2
Bladed level gauges PFG-86
00625 97.06 - Rev. 05
The PFG-86 level gauge is made in compliance with the regulations in force in the European Union and specifically with:
- Die-cast aluminium casing UNI 5076. IP65 protection.
- Stainless steel shaft on ball bearings, watertight with permanent lubrication, with neoprene Corteco ring for dust sealing.
- Standard Nylon screw, on request made of stainless steel or other materials and versions with 1, 2, 3 or 4 blades.
- Electrical construction in compliance with Directives 2014/35/EU (low-voltage electrical material) and 2014/30/EU (electromagnetic
compatibility).
- Output speed (screw shaft): 1rpm.
SAFETY RULES
All the appropriate safety precautions must be taken when electrically operated equipment is used, in order to reduce
the risk of fire outbreaks, electric shock and injuries to persons.
- Keep the work zone clean and orderly. Accidents are more likely to occour in untidy areas and environments.
- Before beginning work, make sure that the level gauge is in a perfect condition. Damaged or broken parts must be
repaired or replaced by competent personnel authorized by the Manufacturer.
- All verifications, inspections, cleaning and maintenance operations, part changes and replacements must be carried
out with the level gauge disconnected and the plug removed from the power socket.
- It is absolutely forbidden for children, unauthorized and/or inexpert persons to touch or use the level gauge.
- Make sure that the electricity system complies with the laws in force. Make sure that the earthing is efficiently
connected when the instrument is installed. Check to be sure that the power socket is suitable, that it complies
- The level gauge must never be stopped by detaching the plug from the power socket. Moreover, never use the
cable to pull the plug from the socket.
- Periodically check to be sure that the cable is in a perfect condition and replace it if damage is discovered.
This operation must only be carried out by competent and authorized persons. Only use extensions cables of the
- Protect the cable against high temperatures, lubricants and sharp edges. Do not twist or knot the cable.
- Do not allow children or unauthorized persons to touch the cable when the instrument is plugged in.
Before installation, inspect the outer structure of the level gauge. Check the movement of the screw shaft and
the operation of the clutch assembly. If this check reveals anything irregular, the level gauge must be sent to
CAMLogic to be restored to efficiency. CAMLogic level gauges can be installed in any position. With the shaft in a
M
REGGIO EMILIA ( Italy )
BREVETTO N. 656961
PFG 86
Tipo
N.
10A.250V.c.a.
110
220
0
VUOTO
PIENO
7
6
5
4
1
2
3
horizontal or sloping position, the level gauge must
be mounted with the wiring plate inside the casing
in an upright position and the cable passages on
the right-hand side ( Fig.1 ).
The level gauge is mounted on the chambers or
silos, on the side or top.
It is important to choose the position so that
the device is not hit by the falling load, likewise
taking care that the material can move freely all
weighing on the shaft or when material that flows
badly is likely to move in a block.
with the laws in force and that it has a build in automatic protection circuit-breaker.
permitted type and marked.
The level gauge can be mounted on the silos by the standard connection with threaded sleeve ( 2" 1/2 Gas ) to be
welded onto the silos ( PFG-86 ) or by flange connection with 6MA screws ( PFG-86/F ). These two methods involve
around the gauge. Protective deflectors ( Fig.2 )
are advisable when there is considerable weight
no modifications to the level gauge since the flange uses the thread on the body of the gauge envisaged for the
sleeve. When mounting with the sleeve, the gauge must be fully screwed onto the sleeve, then it is necessary to
turn it to obtain an upright position of the wiring plate, then tighten the securing screw on the threaded sleeve.
R
S.a.s. di Guazzetti Giovanni & C.
COSTRUZIONI MECCANICHE ELETTRICHE
Via dell' Industria 12 - 12/A - 42025 CAVRIAGO - RE - Italy
Tel. [phone] - Fax [phone]
www.camlogic.it e-mail [email protected]
0948
ATEX MARKING: II 1/2 D Ex ta/tb IIIC T85°C Da/Db
Group II, intended for use in surface industry.
Suitable for Cat. 1 - Zone 20 inside silos (shaft with screw); Cat. 2 – Zone 21 external (indicator casing).
Temperature class - maximum superficial temperature of the device 85°C.
Equipment Protection Level for dust atmospheres. Da (very high) for zone 20 (internal); Db (high) for zone 21 (external).
Protection method Ex t - protected against dust (ta internal / tb external).
Dust group C (suitable for operation in presence of all types of dust, conductives included).
II
1/2 D
Ex ta/tb
IIIC
T85°C
Da/Db
- Noise level measured in open field: zero.
- Motor absorption: 4 Watts. - Use contact capacity: 10 A. at 250 VAC.
- Envisaged power supplies: 110/220 VAC or 24/48 VAC 50/60 Hz - 24 VDC.

EU DECLARATION OF CONFORMITY
The manufacturer CAMLogic declares under its own responsability that the product PFG-86/./././. answers to the requisites
of the European Directive 2014/34/EU in consideration of the standards : EN IEC 60079-0:2018 and EN 60079-31:2014.
00625 97.06 - Rev. 05
SGC2014
ELECTRICAL WIRING
Fig.3
MAINTENANCE
WARRANTY
Instructions Manual No. 00625 97.06 - Rev. 05
The conductors forming the power supply and signal carrying cable must have an adequate cross-section so that
the current density, in each conductor, is no higher than 4 A/mm². One of these is used only for the earthing of
the level gauge. The cross-section of the conductors must also be adequate in relation to the length of the cable
used to avoid a drop in voltage along the cable over the values prescribed by the regulations on the subject.
It is likewise reccomended to use flexible cables with an adequate outside diameter for the cable entries used
( not supplied ) to ensure a perfect seal of the cable clamp on the power supply and signal carrying cable.
CAUTION : The terminal box contains a screw whose position is marked by the
symbol made in the casting ( Fig.3 ) which has the function of making the ground
connection for the level gauge. This screw must be connected to the yellow-green
conductor ( only green for the USA ) of the power cable. The ground connection of
the level gauge, through the yellow-green conductor, is compulsory.
By the terminal box there is the wiring plate ( Fig.1 ) which has printed on it the
that the mains voltage and frequency correspond to those given on the plate of the level gauge before powering up.
CAMLogic level gauges need no routine
maintenance. Possible extraordinary maintenance
is restricted to replacing parts that are
deteriorated by use.
The gauge must not be lubricated; the shaft,
the only moving part, is mounted on ball
bearings with permanent lubrication.
Reccomended spare part:
-
-
-
-
-
Geared motor
Return spring
Neoprene seal ring ( Corteco )
Braket complete with limit switch
and terminal board
CAMLogic, in addition to the terms of the supply
contract, guarantees its products for a period
of twenty-four ( 24 ) months from the date of
shipment. This warranty is expressed only in the
repair or replacement free of charge of parts that,
after careful examination by the Manufacturer,
turn out to be defective.
Warranty, excluding all liability for direct or
indirect damage, is considered to be restricted
to only defects in materials and has no effect
if the parts returned turn out to have been
anyhow dismantled, tampered with or repaired
by anyone other than the Manufacturer.
Warranty likewise excludes damage deriving
from negligence, carelessness, bad or improper
use of the level gauge, or from bad handling
by the operator and faulty installation.
Warranty is moreover forfeit if non-genuine
spare parts have been used.
A returned level gauge, even if under
warranty, must be shipped carriage free.
All the information contained in this manual is confidential and no
part of it may be disclosed without written authorization from CAMLogic.
This manual, even after the sale of the level gauge, is lent and remains the property of the Manufacturer.
For connections to the terminal board use
For the grounding connection use an eyelet
cable terminal.
fork cable terminals.
REGGIO EMILIA ( Italy )
N. 656961
N.
A.250V.c.a.
110 220
0
7 6 5 4 1 2 3
Ball bearings
Use exclusively cable entries certified according to directive 2014/34/EU, Category 2 and EN 60079-31.
wiring diagram for the power supply and use of the level gauge. Always check
- The external earthing has to be carried out by the installator.
- The equipment has to be protected against impact and electrostatic inside the silo.
- The user has to protect the equipment circuits with fuses against short circuit.
- The max. surface temperature considered is without dust and not safety distance.
REFERENCE FIGURES
PFG-86
SLEEVE
Double ø1/2" Gas horizontal
cable inlet on the right side
Screw ø5 MA
346,5
92,5 138 16 100
10533
ø154
18
ø2" 1/2 Gas
ø82,5
65
ø2" 1/2 Gas
FLANGE
283,5
92,5 55 36 100
33 22
100
ø154
ø2" 1/2 Gas
15,5 22
Model AC4 screw
60
100
136,5
108
344,5
ø32
ø2" 1/2 Gas
PFG-86/F
PFG-86/C PFG-86/X
PFG-86/X/F
FLANGE
ø100
302
92,5 54,5 95 60
4 vanes model AC3 screw in stainless steel
ø154
6 equidistant ø7 mm holes
ø203
ø178
ø33
2 mm thick
316,5
92,5 21 203
16 70
120
6 equidistant ø7 mm holes
ø203
ø178
ø154
8 mm thick
Notified corporate body that releases the examination and entrusted of the periodic overseeing TÜV ITALIA.
Certificate number TÜV IT 13 ATEX 070 Rev.1.
The permitted ambient temperature range is -20 to +70 °C. Marking: II 1/2 D Ex ta/tb IIIC T85°C Da/Db
Firma: Giovanni Guazzetti (AD) - Data di produzione: 10/2019
