Camo EDGECLIP Instruction Manual

INSTALLATION GUIDE & WARRANTY INFORMATION
Note: Before beginning installation, please visit camofasteners.com/installation for
best practices.
INSTALL DECKING IN HALF THE TIME
FOR ANY ANGLED INSTALL
REV. 8/19/19

Fastening the first board and last board: Secure the first board along the house or at the outside
of the deck. By face fastening with the appropriate screw for the deck material at each joist.
FOR USE WITH COMMON 90° DECKING PATTERN
1. On the outside edge
of your installed starter
board, simply place
EDGECLIP™onto the joist
allowing the "legs" of the
clip to snugly grasp the
joist and hold the clip
in place.
2. Place EDGECLIP™at
every joist along the
length of the board.
3. You are now ready to
slide your next board up
against the EDGECLIPS
between the two boards.
4. Holding the new board
tightly in place, screw
down all of the clips
between the boards.
Use the yellow
Never-Miss™ Guide
(shown here) included, to
perfectly engage the
driver bit with the screw
head for fastest
installation.
5. Follow the same
process for each deck
board.
At the same time, slide the
metal gusset into to the
groove of the deck board.
NO NEED TO PRE-SET
SCREW INTO JOIST.
The clip will now stand
firmly in place.

Fastening the first board and last board: Secure the first board along the house or at the outside
of the deck. By face fastening with the appropriate screw for the deck material at each joist.
FOR USE WITH ANY ANGLED DECKING PATTERN
1. On the outside edge
of your installed starter
board, simply pinch the
"wings" of EDGEXCLIP™
together and slide the clip
into the groove.
2. Place EDGEXCLIP™
at every joist along the
length of the board.
3. You are now ready to
slide your next board up
against EDGEXCLIPS
between the two boards.
4. Holding the new board
tightly in place, screw
down all of clips between
the board.
Use the yellow
Never-Miss™ Guide
(shown here) included, to
perfectly engage the
driver bit with the screw
head for fastest
installation.
5. Follow the same
process for each deck
board.
The "wings"of the clip will
expand, holding the clip
in place.
NO NEED TO PRE-SET
SCREW INTO JOIST.

INSTALLING EDGECLIP™ OR EDGEXCLIP™ AT BUTT JOINTS
Always install a double joist at
the butt joints. Use a separate
clip to secure each board end.
Please follow your deck board
manufacturer's instructions
for end to end board gapping
distance to allow for expansion
and contraction at this joint.
Once boards are positioned
correctly, place the clips in
the board groove, centered
on joists on both sides of the
boards and partially fasten the
screws to hold the clips in place
until next parallel board is in
place and then fully tighten
screws securing the clips.
You will need 4 clips for each
butt joint.
Simply remove the snap-o
legs o EDGECLIP™or the
wings o EDGEXCLIP™so that
the clips can sit side-by-side on
the double joists.
HOW MANY CLIPS DO YOU NEED?
JOIST SPACING (ON CENTER) NUMBER OF CLIPS NEEDED
50 SQ. FT. 100 SQ. FT. 200 SQ. FT.
12 in. 117 233 466
16 in. 90 180 360
24 in. 59 117 234

REMOVING AND REPLACING A DECK BOARD - FOR EITHER CLIP
1. EDGECLIP™and EDGEXCLIP™
make removing or replacing a
board easy. Start by backing all
of the screws out of the joist
that are holding the board.
2. Pull up on the board and it
will come easily out of position.
3. Clean away any clips
remaining on the joists and lay
the new deck board in position
without any clips in place.
4. Count the number of clips
needed and snap-o both legs
or wings on each clip.
5. Take the clip (screws and
gussets) and from the board
end, slide down the groove
and positioning a clip over
each joist.
6. Repeat for all joists and
fasten clips securely in place
using the Never-Miss™Guide.

WARRANTY
CAMO® CLIPS (UNIVERSAL HIDDEN FASTENERS), CAMO® EDGECLIP™
AND CAMO® EDGEXCLIP™ LIMITED WARRANTY
What This Limited Warranty Covers; Period of Coverage. NNC warrants to the first
retail purchaser that CAMO® Clips, EdgeClip™ or EdgeXClip™ (the “Product”) will
be (1) free from defects in material and workmanship for the life of the Product,
and (2) is guaranteed against rust and corrosion for the life of the project in which
the Product is first used. NNC will replace any defective Product at no charge,
including shipping cost of replacement Product, subject to the limitations or
exclusions contained in this Limited Warranty.
Additionally, if CAMO®Clips, EdgeClip™or EdgeXClip™, installed in accordance
with applicable building codes, laws, rules and regulations, and CAMO®and deck
board manufacturers’ installation instructions, and accepted building practices,
cause the deck board product to fail, NNC will replace the damaged deck board
product at no charge. This does not replace any deck board manufacturers’
warranties, does not apply in cases where defects or damage are not solely and
exclusively attributable to the Product,and is subject to the limitations described
below. This Limited Warranty does not apply where damage to the deck board
product is attributable, in whole or in part, to improper installation of either
the deck board product itself or the CAMO®Clips, EdgeClip™and EdgeXClip™.
This is your sole and exclusive remedy for any product defect. NNC assumes no
liability for confirming that any product is appropriate for a particular purpose,
and each intended use of a product must be reviewed and approved by qualified
professionals. This warranty is not transferable.
To review the complete CAMO® Clips (Universal Hidden Fasteners), CAMO®
EDGECLIP™ and CAMO® EDGEXCLIP™ Limited Warranty, please visit
camofasteners.com/warranty-clips.
