INSTRUCTION MANUAL
CCFC Field Camera
May 2016
Copyright © 2016
Campbell Scientific (Canada) Corp.

WARRANTY AND ASSISTANCE
This equipment is warranted by CAMPBELL SCIENTIFIC (CANADA) CORP. ("CSC") to
be free from defects in materials and workmanship under normal use and service for
twenty-four (24) months from date of shipment unless specified otherwise. *****
Batteries are not warranted. ***** CSC's obligation under this warranty is limited to
repairing or replacing (at CSC's option) defective products. The customer shall assume
all costs of removing, reinstalling, and shipping defective products to CSC. CSC will
return such products by surface carrier prepaid. This warranty shall not apply to any
CSC products which have been subjected to modification, misuse, neglect, accidents of
nature, or shipping damage. This warranty is in lieu of all other warranties, expressed or
implied, including warranties of merchantability or fitness for a particular purpose. CSC
is not liable for special, indirect, incidental, or consequential damages.
Products may not be returned without prior authorization. To obtain a Return
Merchandise Authorization (RMA), contact CAMPBELL SCIENTIFIC (CANADA) CORP.,
at [phone]. An RMA number will be issued in order to facilitate Repair Personnel
in identifying an instrument upon arrival. Please write this number clearly on the outside
of the shipping container. Include description of symptoms and all pertinent details.
CAMPBELL SCIENTIFIC (CANADA) CORP. does not accept collect calls.
Non-warranty products returned for repair should be accompanied by a purchase order to
cover repair costs.

Precautions
DANGER —MANY HAZARDS ARE ASSOCIATED WITH INSTALLING, USING, MAINTAINING, AND WORKING ON OR AROUND
TRIPODS, TOWERS, AND ANY ATTACHMENTS TO TRIPODS AND TOWERS SUCH AS SENSORS, CROSSARMS, ENCLOSURES,
ANTENNAS, ETC. FAILURE TO PROPERLY AND COMPLETELY ASSEMBLE, INSTALL, OPERATE, USE, AND MAINTAIN TRIPODS,
TOWERS, AND ATTACHMENTS, AND FAILURE TO HEED WARNINGS, INCREASES THE RISK OF DEATH, ACCIDENT, SERIOUS
INJURY, PROPERTY DAMAGE, AND PRODUCT FAILURE. TAKE ALL REASONABLE PRECAUTIONS TO AVOID THESE HAZARDS.
CHECK WITH YOUR ORGANIZATION'S SAFETY COORDINATOR (OR POLICY) FOR PROCEDURES AND REQUIRED PROTECTIVE
EQUIPMENT PRIOR TO PERFORMING ANY WORK.
Use tripods, towers, and attachments to tripods and towers only for purposes for which they are designed. Do not exceed design
limits. Be familiar and comply with all instructions provided in product manuals. Manuals are available at www.campbellsci.ca or by
telephoning [phone] (Canada). You are responsible for conformance with governing codes and regulations, including safety
regulations, and the integrity and location of structures or land to which towers, tripods, and any attachments are attached. Installation
sites should be evaluated and approved by a qualified personnel (e.g. engineer). If questions or concerns arise regarding installation,
use, or maintenance of tripods, towers, attachments, or electrical connections, consult with a licensed and qualified engineer or
electrician.
General
Prior to performing site or installation work, obtain required approvals and permits.
Use only qualified personnel for installation, use, and maintenance of tripods and towers, and
any attachments to tripods and towers. The use of licensed and qualified contractors is
highly recommended.
Read all applicable instructions carefully and understand procedures thoroughly before
beginning work.
Wear a hardhat and eye protection, and take other appropriate safety precautions while
working on or around tripods and towers.
Do not climb tripods or towers at any time, and prohibit climbing by other persons. Take
reasonable precautions to secure tripod and tower sites from trespassers.
Use only manufacturer recommended parts, materials, and tools.
Utility and Electrical
You can be killed or sustain serious bodily injury if the tripod, tower, or attachments you are
installing, constructing, using, or maintaining, or a tool, stake, or anchor, come in contact
with overhead or underground utility lines.
Maintain a distance of at least one-and-one-half times structure height, 6 meters (20 feet), or
the distance required by applicable law, whichever is greater, between overhead utility lines
and the structure (tripod, tower, attachments, or tools).
Prior to performing site or installation work, inform all utility companies and have all
underground utilities marked.
Comply with all electrical codes. Electrical equipment and related grounding devices should
be installed by a licensed and qualified electrician.
Elevated Work and Weather
Exercise extreme caution when performing elevated work.
Use appropriate equipment and safety practices.
During installation and maintenance, keep tower and tripod sites clear of un-trained or non-
essential personnel. Take precautions to prevent elevated tools and objects from dropping.
Do not perform any work in inclement weather, including wind, rain, snow, lightning, etc.
Maintenance
Periodically (at least yearly) check for wear and damage, including corrosion, stress cracks,
frayed cables, loose cable clamps, cable tightness, etc. and take necessary corrective actions.
Periodically (at least yearly) check electrical ground connections.
WHILE EVERY ATTEMPT IS MADE TO EMBODY THE HIGHEST DEGREE OF SAFETY IN ALL CAMPBELL SCIENTIFIC PRODUCTS,
THE CLIENT ASSUMES ALL RISK FROM ANY INJURY RESULTING FROM IMPROPER INSTALLATION, USE, OR MAINTENANCE OF
TRIPODS, TOWERS, OR ATTACHMENTS TO TRIPODS AND TOWERS SUCH AS SENSORS, CROSSARMS, ENCLOSURES, ANTENNAS,
ETC.

IR Warning
Infrared (IR) is emitted from the CCFC. Do not look directly at the IR
LED when the CCFC is connected to power.
The CCFC utilizes 2 high intensity nonvisible IR (850nm) LEDs for
night vision illumination.
Do not make physical contact with the IR LEDs or place any body part
near the IR LEDs (less than 5cm) while the camera is powered on.
When in close proximity with the illuminated IR LEDs, there is a
potential skin burn hazard.
See Section 5 Cautionary Statements for more information.
IR LEDs

i
Table of Contents
PDF viewers: These page numbers refer to the printed version of this document. Use the
PDF reader bookmarks tab for links to specific sections.
1. Introduction................................................................1
2. Specifications.............................................................2
3. Initial Inspection.........................................................4
4. Quick Notes................................................................5
4.1 CCFC General ...................................................................5
4.2 Campbell Dataloggers Users.............................................6
4.3 Configuration Process........................................................6
5. Cautionary Statements..............................................8
6. Factory Setup.............................................................9
7. Camera Hardware.....................................................10
7.1 Power I/O Connection .....................................................11
7.2 Setup Button/Status LED.................................................11
7.2.1 Status LED.................................................................12
7.2.2 Setup Button ..............................................................13
7.3 Camera Memory..............................................................13
7.3.1 Link to Most Recent Photo and Video ......................14
7.3.2 FTP Photo Collection from Camera Memory ...........14
7.4 Modem Power Control ....................................................15
7.5 Lens .................................................................................16
7.5.1 Camera Lens and Field of View................................16
7.5.2 Camera Auto Focus ...................................................16
7.5.3 Temperature Variations and Focus............................16
7.5.4 Lens IR Cut Filter......................................................17
8. Cables/Wiring...........................................................17
8.1 Power & I/O Cable Connections.....................................17
8.2 Power & I/O Cable Details..............................................19
8.3 Ethernet Cables................................................................20
9. Using Device Configuration Utility .........................21
10. Photo Quality............................................................23

Table of Contents
ii
11. Connecting to the Web Interface ............................23
11.1 Setup Using Wi-Fi...........................................................23
11.2 Setup Using Ethernet.......................................................24
11.2.1Link Local IP Address Auto-Configuration..............24
12. Camera Operation using the Web Interface...........24
12.1 Installing MultiMedia Player...........................................24
12.1.1RTSP Video Stream...................................................25
12.1.1.1Sources..............................................................25
12.1.1.2Embedding........................................................26
12.1.2UPnP Discovery ........................................................26
12.2 Web Interface Overview..................................................26
12.2.1Live Video Modal......................................................30
12.2.2Power Icon.................................................................31
12.2.3Set Up Progress Bar...................................................31
12.3 Dashboard........................................................................31
12.4 Capture Modes.................................................................33
12.4.1Timed Capture...........................................................34
12.4.2External Trigger.........................................................39
12.4.3Motion Detect............................................................44
12.5 Lens Position ...................................................................50
12.6 Media Settings.................................................................52
12.6.1Photo Capture............................................................53
12.6.2Video Capture............................................................57
12.7 File Explorer....................................................................59
12.8 Settings ............................................................................61
12.8.1General.......................................................................61
12.8.1.1SNTP.................................................................63
12.8.2Network.....................................................................64
12.8.2.1Wired Ethernet Settings....................................65
12.8.2.2Wi-Fi Settings...................................................67
12.8.2.3Wi-Fi Access Mode..........................................68
12.8.2.3.1Wi-Fi Access Point..................................68
12.8.2.3.2Existing Network.....................................70
12.8.3File Transfer ..............................................................71
12.8.3.1FTP ...................................................................72
12.8.3.2Email.................................................................74
12.8.3.3PakBus..............................................................76
12.8.4Camera Operation......................................................78
12.8.4.1Camera Power Modes.......................................78
12.8.4.2Ethernet Power Mode.......................................81
12.8.4.3Wi-Fi Power Mode...........................................82
12.8.4.4Night Mode.......................................................83
12.8.4.4.1IR LED Power Control............................84
12.8.4.4.2Filter Control ...........................................85

12.8.4.4.3Light Power Control................................85
12.8.4.5Digital I/O.........................................................86
12.8.4.5.1Modem Power Control ............................86
12.8.4.5.2Lens Defroster Control............................87
12.8.5Advanced...................................................................88
12.8.5.1GPS...................................................................88
12.8.5.2Import/Export ...................................................89
12.8.5.3Update...............................................................91
12.8.5.4Users.................................................................92
12.8.5.5History ..............................................................94
13. RS-232 Communications.........................................94
14. RS-485 Communications.........................................96
15. Send Via PakBus: PakBus Communications.........97
15.1 Send Via PakBus: Concurrent PakBus Communications98
15.2 Send Via PakBus: PakBus Graph Operations .................98
15.2.1Dataogger Settings.....................................................98
15.2.2Discovery...................................................................98
15.3 Setting Up Datalogger to Work with CCFC: PakBus
Variable Control ...........................................................99
15.3.1PakBus Control of Window Defroster Function .....100
15.3.2PakBus Control of CCFC Power.............................100
15.3.3Example Program –SendVariable Instruction –CR1000
..............................................................................101
15.3.4Example Program –Adding GPS Coordinates to the
Photo Banner –CR1000.......................................102
15.4 PakBus Neighbouring Address......................................103
16. Power Calculations and Timings ..........................103
16.1 Standalone Operation ....................................................103
16.2 Operation with Communications...................................105
17. CCFC Compatability ..............................................107
18. CR1000 Interface Guide.........................................108
18.1 CR1000 Memory Setup.................................................108
18.2 CR1000 Files Manager..................................................108
18.3 CR1000 COM Port (Control Port) Communications....109
19. Remote Photo Retrieval.........................................110
19.1 LoggerNet File Retrieval...............................................110
19.2 Using LoggerNet File Control.......................................112

Table of Contents
iv
20. Mounting.................................................................113
21. Maintenance ...........................................................115
21.1 Lithium Battery..............................................................115
21.2 Window and Lens Cleaning ..........................................116
22. System Limitations ................................................116
22.1 High Resolution 5 Megapixel Photos............................116
22.2 Simultaneous Processes.................................................116
Appendix A. CCFC Camera Accessories.............A-117
A.1 CCFCCBL1-L Power & I/O Cable ...........................A-117
A.2 CCFCCBL2-L Environmental Ethernet Cable..............A-2
A.3 L18549 Mounting Kit....................................................A-2
A.4 L28840 DB9 FEMALE To Terminal Block Adaptor ...A-3
Figures
Figure 1-1 CCFC Camera............................................................1
Figure 7-1 CCFC Connector Layout.........................................11
Figure 7-2 Photo Collection from Installed Camera Memory...15
Figure 9-1 CCFC shown in Device Configuration Utility ........22
Figure 12-1 Dashboard - Desktop view....................................27
Figure 12-2 Dashboard - Mobile views....................................27
Figure 12-3 Top Navigation Bar –Desktop view .....................30
Figure 12-4 Live Video Modal...................................................30
Figure 12-5 Set Up Progress bar ...............................................31
Figure 12-6 CCFC Dashboard..................................................32
Figure 12-7 Manual Capture Modal..........................................33
Figure 12-8 Timed Capture.......................................................34
Figure 12-9 Timed Capture: Create New Profile......................35
Figure 12-10 External Trigger ..................................................40
Figure 12-11 External Trigger: Create New Profile.................41
Figure 12-12 Motion Detect ......................................................44
Figure 12-13 Motion Detect: Create New Profile.....................46
Figure 12-14 Lens Position .......................................................50
Figure 12-15 Lens Position Modal............................................51
Figure 12-16 Lens Position Modal (in Capture Modes)............51
Figure 12-17 Media Settings .....................................................53
Figure 12-18 Media Settings: Edit Photo Profile ......................53
Figure 12-19 Photo Settings Modal...........................................54
Figure 12-20 Media Settings: Edit Video Profile......................58
Figure 12-21 Video Settings Modal...........................................58
Figure 12-22 File Explorer: Camera Memory Details..............60
Figure 12-23 File Explorer: File Details...................................60

Figure 12-24 General Settings...................................................62
Figure 12-25 Date and Time Settings: Sync with SNTP Server64
Figure 12-26 Network................................................................65
Figure 12-27 Network Pop-up on Google Chrome...................65
Figure 12-28 Wired Ethernet Settings.......................................66
Figure 12-29 Wi-Fi Settings ......................................................67
Figure 12-30 Access Point Settings...........................................68
Figure 12-31 Connect to Existing Network...............................70
Figure 12-32 FTP Settings ........................................................72
Figure 12-33 FTP Settings Modal.............................................72
Figure 12-34 Email Settings......................................................74
Figure 12-35 Email Settings Modal...........................................74
Figure 12-36 PakBus Settings ...................................................76
Figure 12-37 PakBus Modal......................................................76
Figure 12-38 Camera Power Modes .........................................78
Figure 12-39 Ethernet Power Modes ........................................81
Figure 12-40 Wi-Fi Power Mode ..............................................82
Figure 12-41 Night Mode ..........................................................84
Figure 12-42 Digital I/O Settings..............................................86
Figure 12-43 Modem Power Control ........................................87
Figure 12-44 Lens Defroster Control: Always On....................87
Figure 12-45 Lens Defroster Control: Prior to Capture...........88
Figure 12-46 GPS......................................................................88
Figure 12-47 GPS: Degrees, Minutes, Seconds ........................89
Figure 12-48 GPS: Decimal Degrees........................................89
Figure 12-49 Import/Export Camera Settings...........................90
Figure 12-50: Update ................................................................91
Figure 12-51 Users and Security Settings.................................93
Figure 12-52 History .................................................................94
Figure 13-1 PakBus Settings .....................................................95
Figure 13-2 L28840 DB9 FEMALE to Terminal Block Adapter95
Figure 19-1 File Retrieval Setup Screen .................................111
Figure 19-2 Loggernet Connection Screen..............................112
Figure 19-3 USR Drive View in File Control.........................113
Figure 20-1 CCFC Mounting Kit............................................114
Figure 20-2 CCFC Mounting Holes........................................114
Figure 20-3 CCFC Mounted to Crossarm...............................115
Tables
Table 4-1 Power Mode Summary................................................7
Table 6-1 CCFC Factory Default Configuration.......................10
Table 7-1 Setup Button Status LED..........................................12
Table 8-1 Power & I/O Cable Connections...............................18
Table 9-1 RS-232 Wiring Diagram...........................................21

Table of Contents
vi
Table 12-1 Video Stream Sources.............................................25
Table 12-2 Web Interface Components.....................................28
Table 12-3 Dashboard Components..........................................32
Table 12-4 Timed Capture Variables for Photos.......................36
Table 12-5 Timed Capture Variables for Videos......................38
Table 12-6 External Trigger Variables for Photos....................41
Table 12-7 External Trigger Variables for Video .....................43
Table 12-8 Motion Detect Settings for Photo Options..............46
Table 12-9 Motion Detect Settings for Video Options .............48
Table 12-10 Lens Positions Modal............................................52
Table 12-11 Photo Capture Variables .......................................54
Table 12-12 Photo Resolution Details.......................................56
Table 12-13 Video Capture Variables.......................................58
Table 12-14 Typical Video File Sizes.......................................59
Table 12-15 General Settings Variables....................................62
Table 12-16 Wired Ethernet Settings........................................66
Table 12-17 Wi-Fi Settings.......................................................67
Table 12-18 Access Point Settings............................................69
Table 12-19 Exisitng Network Settings for Wi-Fi Clients........71
Table 12-20 FTP Settings..........................................................73
Table 12-21 Email Settings.......................................................75
Table 12-22 PakBus Settings ....................................................77
Table 12-23 Camera Power Modes...........................................79
Table 12-24 Capture Response Time........................................81
Table 12-25 Ethernet Power Modes..........................................82
Table 12-26 Wi-Fi Power Modes..............................................83
Table 12-27 Import/Export Settings..........................................90
Table 12-28 Users .....................................................................93
Table 13-1 CCFC Connections to RS-232 Port ........................96
Table 13-2 Datalogger Connections to RS-232 Port.................96
Table 16-1 File Transfer Times Using PakBus.......................106
Table 17-1 CCFC Compatibility with Contemporary and Retired
Dataloggers.................................................................107

1
CCFC Field Camera
1. Introduction
Figure 1-1 CCFC Camera
The CCFC is designed to meet the stringent operational
requirements necessary for remote battery powered installations,
while producing HD video and photos of up to 5 megapixels. The
CCFC can operate over a wide temperature range and has several
advanced power saving modes to suit a variety of needs.
The CCFC incorporates an integrated rugged environmental
enclosure to reduce cost and installation time. Communication
options include Ethernet, Wi-Fi, RS-232, and RS-485. The CCFC
is fully web-enabled with HTTP, FTP, and Email capabilities.
Campbell Scientific’s PakBus protocol is supported by the CCFC
for integration with Campbell Scientific dataloggers.
The camera contains an onboard camera memory that enables the
camera to function as a powerful photo and video datalogger. The
internal 16GB camera memory enables the CCFC to archive
photos and video internally.
The CCFC can operate in a stand-alone mode with photo
acquisitions triggered by the camera’s own precision real time
clock. Media (photo and video) acquisitions can also be triggered
by events through an external trigger or motion detect.

CCFC Field Camera
2
2. Specifications
Power Supply Operating
9 –30 Vdc Input voltage
Current Draw Specifications
Average current draw: 250 mA (excludes defroster and IR
LEDs)
Maximum momentary peak current draw: 400mA
Current draw with defroster on: 1.5A
Current draw with IR LEDs on: 700mA
Quiescent Off power mode: < 1mA
Deep Sleep power mode: < 6mA
General
Operating Temperature: -40°C to + 60°C*
Weight: 2.4 kg (5.25 lb)
Clock Accuracy: ± 2 Minutes/Year (-40°C to +60°C)
*Full functionality of the motorized zoom lens is available in
the temperature range of -30°C to +60°C. Image and video
capture can still occur but the motorized lens will remain in a
fixed position at temperatures below -30°C.
Dimensions
Length: 28.4 cm (11.2”)
Height: 13.0 cm (5.1”)
Width: 13.2 cm (5.2”)
Lens
Lens: 4.7 to 84.5 mm, 3° to 55° horizontal field of view
Photo or Video Capture Triggers
Two Independent Self Timers
Motion Detect
Web Page Control
External Trigger
Photo and Video Capture Times (from wake up to start of
capture)
Fully On: < 1 s (5 MP images take longer; using lens
positions adds time)

CCFC Field Camera
A-1
Partially On: 10 sec
Deep Sleep: 10 sec
Off State: 90 sec
Photo Resolutions (JPEG)
2592 x 1944
1200 x 960
1280 x 720
640 x 480
640 x 352
320 x 240
320 x 176
Video Recording
MPEG4 720p
MPEG4 320 x 240
Video Frame Rate Options: 30, 15, and 7.5 frames per
second (FPS)
External Trigger Signal
Logic Low Level: < 0.65 V (-20 Vdc Absolute Min)
Logic High Level: > 2.0 Vdc (+20 Vdc Absolute Max)
Communication Interfaces
Ethernet 10/100
RS-232 port or RS-485 port
Wi-Fi (supports 802.11bgn in the 2.4 GHz ISM band on
channels 1-11)
Communication Protocols
Web interface via web browser
FTP
Email
PakBus (for Campbell Scientific dataloggers)
Modem Power Control
Maximum Output Current: 750 mA
12 Vdc
RS-232 or RS-485
Maximum Baud rate: 115.2 KBaud

CCFC Field Camera
4
For RS-232: The maximum recommended cable
length at 115.2 K BAUD rate is 15 m. The use of the
57.6 KBAUD rate has a recommended maximum
cable length of 30 m (90 ft).
For RS-485: A user-supplied (twisted pair) cable
could be spliced onto the communication wires to
extend to a maximum cable length of 305 m (1000 ft).
Power wires still need to be kept to the 20 m (65 ft)
factory length (or 0.7 Ohm user-supplied spliced
cable) limit.
Camera Memory
File Type : jpeg (photo) ; avi (video)
Size: 16 GB
Zoom
18x Optical zoom
3. Initial Inspection
Upon receipt of the CCFC, inspect the packaging and contents
for damage. File any damage claims with the shipping
company. Immediately check package contents against the
shipping documentation. Contact Campbell Scientific about
any discrepancies.
The model number and cable length are printed on a label at
the connection end of the cable (if a cable was purchased).
Check this information against the shipping documents to
ensure the expected product and cable length are received.
The CCFC is shipped with a Quick Start Guide, 2 screws, 2
lock washers, 2 flat washers, 4 Lens wipes, a ResourceDVD,
and the Female DB9 to Terminal block adaptor (L28840).
Note

CCFC Field Camera
A-1
4. Quick Notes
4.1 CCFC General
When ordering the CCFC series, use the model numbers
CCFC RS2332 or CCFC RS485 (see Sections 13 RS-232
Communications and Section 14 RS-485
Communications).
The Setup Button’s Status LED will flash when the camera
is in an Active Power State.
When the Status LED is steadily on, the camera is booting
up. Avoid interrupting this process.
Briefly pressing the Setup Button always causes the
camera to exit from any low powered quiescent states and
enables the Ethernet interface for communications. The
camera will remain in this state for 5 minutes.
An active session to the camera with a web browser
prevents the camera from entering a low powered state.
Avoid removing power from the camera when it is in an
active state. If the camera is in an active state (Status LED
is flashing), properly shutdown the camera to avoid any
memory corruption before removing power. The camera
can be shut down by holding the Setup Button
continuously for more than 10 seconds or by using the
Power Icon on the web interface.
Always ensure that all cable connectors and covers are
securely in place.
Record any changes to the IP settings of the camera. This
information is important to gain access to the camera for
focusing or reconfiguration.
The camera configuration file can be imported or exported
via the web interface. This feature can be found under
Import/Export.
Check the Campbell Scientific website for firmware
updates that may apply.

CCFC Field Camera
6
4.2 Campbell Dataloggers Users
If interfacing to a datalogger, ensure that the datalogger
has the latest PakBus operating system.
Use either the CCFC built in-web interface, the Device
Configuration Utility, or PakBus Graph to change settings
in the camera.
Use the Device Configuration Utility to change settings in
MD485 or other PakBus devices.
The Device Configuration Utility can also be used to set
the datalogger memory and PakBus parameters.
Files (pictures or video) must be less than 2 MB for
PakBus transmissions.
The datalogger instruction SendVariables can be used to
send variables or text to the camera, for use in photo or
video captions. The instruction can also be used to control
the window defroster.
4.3 Configuration Process
1. Determine what will trigger the capture of a photo or video.
Options include:
a. Timed Capture –Enable and configure Timed Capture 1,
Timed Capture 2, or both. To set this up using the web
interface, see Section 12.4.1 Timed Capture.
b. External Trigger –Enable and configure the External
Trigger Capture. To set this up using the web interface, see
Section 12.4.2 External Trigger.
c. Motion Detect –Enable and configure Motion Detect
Capture. To set this up using the web interface, see Section
12.4.3 Motion Detect.
2. Select the Power Mode that best suits the requirements (see
Table 4-1 Power Mode Summary). Options are:
a. Fully On –Used if no power constraints exist or if high
performance is required.

CCFC Field Camera
A-1
b. Partially On –Provides substantial reduction in power
(especially with the Ethernet Power Mode set to Full Power
Save).
c. Deep Sleep –Provides very good power savings. The camera
does not need to reboot when activated by a trigger.
Recommended for use if more than 24 triggers are expected per
day.
d. Off Mode –Offers the best power savings. Useful, if less
than 24 photos or video captures are required per day. It takes
about 90 seconds for the camera to wake up to start acquiring a
picture.
Table 4-1 Power Mode Summary*
Power
Mode
Ethernet
Power
Save
Mode
Quiescent
Current
Draw
Max.@12
Vdc
Time (Seconds)
from wakeup
to start of
capture
Time (Seconds) in
Fully On Mode
(Active Current
Draw)
Fully On
Always
On
250 mA
< 1
0 –Always Active
Full
Power
Save
Mode
200 mA
< 1
0 –Always Active
Partially
On
Always
On
90 mA
10
20
Full
Power
Save
Mode
10 mA
10
20
Deep
Sleep
Always
On
6 mA
15
25
Full
Power
Save
Mode
6 mA
15
25

CCFC Field Camera
8
Off State
Always
On
1 mA
90
120
Full
Power
Save
Mode
1 mA
90
120
* This table takes into account the camera power settings. It does
not include the power draws associated with activating the IR
LEDs (see Section 12.8.4.4.1 LED Power Control) or Lens
Defroster (see Section 12.8.4.5.2 Lens Defroster Control).
3. Set the details of the media event
a. Set the photo settings
b. Set the video settings
4. Set other details related to Communications and I/O. These
other parameters are located under:
a. Section 12.8.2 Network.
b. Section 12.8.4.5 Digital I/0.
c. Section 13 RS-232 Communications and Section 14 RS-485
Communications.
5. Cautionary Statements
Although the CCFC is designed to be a rugged and reliable
device for field use, care should be taken when handling or
moving it to avoid aesthetic damage.
Other than the desiccant, there are no user-serviceable parts.
Improper disassembly or re-assembly of the device will void
the warranty. Contact Campbell Scientific Canada or the
reseller for details.
The CCFC has three stickers on the bottom of the camera:
1. IR Warning Sticker.

CCFC Field Camera
A-1
2. FCC Information Sticker.
3. Model #, Serial #, and MAC Address Sticker.
6. Factory Setup
Table 6-1 outlines the CCFC factory settings that are relevant for
initially communicating with the camera.
